Lex Voltstack 5k User manual

LM-VOLTSTACK5K REV.000
TYPE 3R Rainproof
PowerGATE®
Switches & Panels
PowerPLUS
Installed Distribution Boxes
TM
PowerRAMP®
Cable Protectors
Power Control Solutions
™
Dimming & Control
™
PowerHOUSE
Portable Distribution Boxes
TM
PowerPARTS
Wiring Devices
TM
PowerRACK
Rolling Distribution Racks
TM
WeldingRACK
WR6
TM
PowerFLEX
Cable Assemblies
TM
LuxCommander®
Portable Work Lights
Smart Power™
Energy Storage Systems
*Battery level certification
Voltstack®5k
Entertainment Energy Storage System - Entertainment
User Manual
Power Storage and Distribution Touring Rack

Contact Lex Products: 800.643.4460 [e-mail]
2
Inlets (front)
• (2) NEMA 5-20, 20 Amp, 125 VAC,
Single Phase, 2-pole, 3-Wire, Panel
Mount Inlets
Introduction
Surrounding Handles
• Protect unit while providing room to grip
• Not intended for suspension of Voltstack®5k
Voltstack®5k is the trailblazing electricity storage and distribution system that reigns supreme in the realm of silent, emission-free,
off-grid portable power. With its cutting-edge technology and sleek design, the Voltstack®5k stands tall as an industry leader. This
powerhouse of a portable battery energy storage system effortlessly handles the power needs of temporary projects of almost any
scale.
This user manual reviews the proper use of the wide range of locking and non-locking inlet, feed-thru and receptacle versions
available. Please take time to review all precautions and warnings in the manual prior to making the proper connections for use. Store
this manual in a safe location for future reference.
Voltstack®Power Storage and Distribution Rack Components - Typical
Receptacles (rear)
• (2) 5VDC 2.4A Type-A USB
Receptacles
User Interface
• Monitor state of charge, wattage in/out, operating
and charging times
High-capacity Casters
• (2) locking and (2) stationary standard
Inlet Circuit Breakers
• Provides protection during charging
Receptacle Circuit Breakers
• Provides receptacle protection during discharge
Receptacles (front)
• (2) NEMA 5-20, 20 Amp, 125 VAC,
Single Phase, 2-pole, 3 Wire, Duplex
Panel Mount Receptacles
Inlets (rear)
• (3) Sunstack Solar MPPT 4-pin
Panel Mount Inlets
Selector Knob
• Selects device condition
When you get your Voltstack®5k, check the shipment carefully to confirm it arrived complete and undamaged.
1. Check the contents against the packing list to ensure the devices are the correct models
2. Check the unit for loose or broken components, which might have resulted from shipping
3. Inspect for signs of damage to wiring devices or circuit breakers
If there is any damage to the Voltstack®5k Power Storage and Distribution Rack, contact Lex Products toll free at 800.643.4460 or
email [e-mail].
Introduction
Effortless Setup, Seamless Power
• Engineered to be up and running in minutes
Contact Lex Products: 800.643.4460 [e-mail]
2

Contact Lex Products: 800.643.4460 [e-mail] 3
Voltstack® 5k Entertainment Energy Storage System
Surrounding Handles
• Protect unit while providing room to grip
• Not intended for suspension of Voltstack®5k
Setting Up the Voltstack® 5k
– The Voltstack® 5k is designed to be used in outdoor locations
– Each Voltstack® 5k Rolling Distribution Rack should rest on its own casters, on a level surface capable of supporting the weight of
the unit and in a location with suitable ventilation
– DO NOT locate any Voltstack® 5k in any area prone to standing water
– DO NOT use the handles to suspend the rack
– Once properly located, make certain to lock the swivel casters
– ALL inlet and receptacle circuit breakers for the rack must be in the ‘O/OFF’ position during connection, transport and storage
1. Turn the Selector Knob to the “STANDBY” or “ON” position.
– If the knob is in the “OFF” position, the Voltstack®5k will
not charge
2. Plug the de-energized input cord(s) into the charging ports.
3. Energize the line cord(s), then move the charging port circuit
breakers to the ‘I/ON’ position
4. The orange indicators will illuminate to designate that the
Voltstack®5k is charging
5. Charging is complete when the User Interface displays
“100%”
1
2
3
44
1. Turn the Selector Knob to the “STANDBY” position
2. Wait for the User Interface screen to illuminate
3. Turn the Selector Knob to the “ON” position
4. The green indicators will illuminate to designate that the
Voltstack®5k is ready to use
– Best practices dictate that load connections are completed
prior to power being applied to the circuit
– Fully insert the male plug into the female receptacle, ensuring
it is properly seated
– Turn the associated circuit breaker to the ‘I/ON’ position
2
35
Charging the Voltstack® 5k
Turning On the Voltstack® 5k
Turning Off the Voltstack® 5k
13
2
4 4
1
2 2
1. Turn the Selector Knob to the “OFF” position.
2. Wait for the green indicators to darken to designate the unit
it off.

Contact Lex Products: 800.643.4460 [e-mail]
4
1. Initial Troubleshooting Procedure:
• Ensure all circuit breakers are in the ‘I/ON’ position
• Perform a power cycle
– Turn your Voltstack®off per the instructions above
– Wait (10) seconds
– Turn your Voltstack on per the instructions above
2. There is no power at the output receptacles:
• Complete troubleshooting Step #1, then check for power
at the output receptacle
• If there is no power, call 800.643.4460 for support
3. The Green Outlet indicators do not illuminate:
• Complete Troubleshooting Step #1, then check for power
at the output receptacle
• Ensure the circuit breakers above the output receptacles
are in the ‘I/ON’ position
• If there is power, it is an issue with the green outlet
indicators
– Your Voltstack®is operational
– Call 800.643.4460 for support
Best Electrical System Practices
4. The Voltstack®5k is not charging:
• Ensure the steps detailed in the section ‘Charging the
Voltstack® 5k’ have been completed
• Complete Troubleshooting Step #1, then check for power
at the User Interface
• If your Voltstack®does not charge, call 800.643.4460 for
support
5. The orange charging lights do not illuminate:
• Check the input power source to ensure it is supplying
power
• Ensure the input power cord is connected properly and
fully seated
• Ensure the circuit breakers above the inlets are in the
‘I/ON’ position
• If your Voltstack®does not charge, call 800.643.4460 for
support
6. The Voltstack® 5k charge does not last as long as normal:
• Complete Troubleshooting Step #1
• If your Voltstack®still does not last as long as normal,
please call 800.643.4460 for support
Lex West
12701 Van Nuys Blvd
Suite Q
Pacoima, CA 91331
818.768.4474
818.768.4040 Fax
www.lexproducts.com
[e-mail]
800.643.4460
© Copyright Lex Products 2023
Produced in the United States of America.
All Rights Reserved.
Lex Products logo and lexproducts.com are trademarks
or registered trademarks of Lex Products in the United
States, other countries, or both.
Lex Products
11 Forest Parkway
Shelton CT 06484
203.363.3738
203.363.3742 Fax
Lex South
15751 SW 41 Street
Suite 300
Davie, FL 33331
203.363.3738
203.363.3742 Fax
Technical Support
Lex Products is available to help answer any product related inquiries. For any questions or technical advice, please call toll free
800-643-4460 or email [e-mail].
Troubleshooting Your Voltstack®5k
• Voltstack®5kw must be fully cycled (discharged and charged) at least once a year to maintain battery life
• The unit must be stored fully charged as damage to the batteries may occur if charging from 0%
• Connections should be completed prior to energizing the circuit
– This ensures connections are not made while the circuits are energized or ‘live’, limiting the potential for shock or damage to
personnel, loads or connections
• Loads should be applied gradually the first time the system is set up
– Sequentially energizing power distribution systems simplifies locating and identifying electrical issues while isolating them from
surrounding components
– Beginning with the first connected receptacle, move the associated individual circuit breaker to the ‘I/ON’ position
– Ensure the devices fed by that circuit are ON, tracing the electrical path to the final device fed by that circuit
• If the circuit breaker cannot be energized or trips, check the system for continuity, short circuits and overload, and make the
necessary corrections before proceeding.
