LEXGO LEX R9 User manual

LEX R9 USER GUIDE

2
Dear Customer,
thank you for buying a LEXGOelectricscooter!
What is commonly referred to as "Kick Scooter" or, in Italian, electric scooter, is a personal transport
device that is based both on muscle thrust and on the aid of an electric motor. The principles that
govern the driving of this vehicle are practically the same as for a traditional scooter
This manual provides the user with a description of the characteristics and operation of the
vehicle.
The use of the vehicle takes place under the sole responsibility of the driver who, after reading
se and understanding this manual and having requested to the seller and/or the
manufacturer any clarifications deemed necessary, considers himself to be psycho-physically
suitable for the use of the vehicle.
The manufacturer disclaims any liability for damages of any kind and entities caused to persons
or things as a result of the use of the vehicle.
The illustrations in the manual may differ slightly from your product, but the content of the
indications also remains valid.
TOPIC INDEX
1. WARNING FOR SECURITYpage ........................................................................... 1. 3
2. WARNINGS FOR SAFE USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
page 5
3. TECHNICAL FEATURES .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
page 6
4. DESCRIPTION . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
page 7
5. ASSEMBLY AND ADJUSTMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . page 8
6. HOW TO START THE SCOOTER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . page 8
7. CONTROL PANEL .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
page 10
8. BATTERY . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
page 11
9. CLEANING AND MAINTENANCE .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . page 13
10. PROBLEM SOLVING .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. page 14

3
1. SAFETY WARNINGS
THIS OPERATING MANUAL MUST REMAIN AN INTEGRAL PART OF THE
PRODUCT: KEEP IT FOR FUTURE CONSULTATION.
This device should not be handled and/or used by children under the age
of 14 and/or people with reduced physical, sensory and cognitive abilities unless
they are supervised and/or adequately instructed by a person responsible for their
safety regarding how they are used and aware of all possible inherent risks.
Keep the appliance and its power supply (including cable) out of reach of children
under the age of 8 and prevent them from playing with it.
This device is not suitable for the transport of objects or animals. .
Any use of the product that does not comply with the guidelines in this manual
and in violation of the road code is to be considered improper and dangerous. .
The manufacturer cannot be held liable for any damages arising from misuse
and/or unreasonable. .
The elements of the packaging (plastic bags, expanded styroforo, etc. ) should
NOT be left within the reach of children or incapable as they represent
potential sources of danger.
Before using the device, visually check its integrity. . If in doubt, contact qualified
staff for any repairs. .
If the external power supply is damaged, it must be replaced by the manufacturer
or its technical assistance service or by a person with similar qualifications, in
order to prevent any risk. .
Before connecting the appliance's power supply to the power grid, make
sure that the connection data, indicated on the nameplate, is in line with those of
the power grid.
Connect and disconnect the power supply cables with dry hands and hold them
tightly. .
Fully carry out the power supply cables to avoid overheating, avoid tendering them
in any case (do not pull them, pull them or use them to drag the devices to which
they areconnected).
Avoid placing power supply cables where they can be easily damaged. .
DO NOT dip the appliance or its feeder in water or other liquids. .
Using the device for the first time, make sure that you have removed any
label or protection sheet that prevents it from working properly.
The device must be kept at a safe distance from free flames and any flammable
or potentially explosive objects and/or substance.
In case of abnormal operation, turn off the device and contact a qualified
technician for appropriate repairs. . DO NOT perform operations that are not
covered by this user manual (such as disassembling the device and/or tampering
with it).

4
In case of anomalies during the charging phase, immediately disconnect the
power supply from the power grid and contact the technical support service. .
Do not leave the power supply connected to the power grid when unused. .
Use only the supplied power supply or, if it is damaged, contact the technical
support for replacement .
The cleaning and maintenance, intended and carried out by the user, should not
be carried out by children without supervision .
Store the appliance and all its accessories/components exclusively indoors, with
little humidity, protected from dust and weathering such as rain, direct radiation of
the sun etc. .
When it is decided to stop using the device, it is recommended that those parts
that may pose a danger to people or dispose of them in accordance with the
relevant regulations are made harmless.

5
2. WARNINGS FOR SAFE USE
Before using the product, carefully check the correct assembly, and integrity. This
device is suitable for the transport of only one person, within the weight limits
indicated in the technical characteristics, after training and practice .
Important! Do not exceed the minimum and maximum load limits in the "Technical
Features" section.
The use of this product is not recommended for children under the age of 14 and/or in
case of height less than 140cm . Use is strongly discouraged for pregnant women and
children. . Wear comfortable clothing that allows you to maintain the flexibility of the
body, in order to have better control. .
It is recommended, for proper use, always wear adequate protections (such as cyclist's
helmet, knee pads, elbow pads, etc. ) and be careful not to harm people and/or property.
.
It is recommended not to use the vehicle in crowded spaces before proper practice and to
have full control of it.
Before you start using the device habitually you need to practice and be clear about
the mechanism that allows you to brake and accelerate movement.
Especially in the phase of your apprenticeship you need to use the device in very spacious,
unobstructed environments, where there is full freedom of movement and on a floor as
smooth as possible, smooth and free of slopes. . It is also advisable to use it away from
objects that may be damaged or harm the driver as a result of accidental impacts.
Remember that it is always appropriate to maintain a speed in line with the environment in
which you are located and with the characteristics of the terrain on which you move: very
irregular terrain, not perfectly horizontal or with roughness or cushions can cause problems
of balance and falls with all the consequent risks .
Avoid performing curves at high speed or abruptly, it can be risky then falls, so it is
recommended to perform turns at moderate speed and in any case with wide warp radius
.
Do not use the product in dangerous situations for your personal safety and
that of the people close to you.
This device has a height from the support plane not negligible, especially when crossing
passages such as doors or low passages: be careful to evaluate well the height of the
passage in relation to your own sum to that of the medium .
Avoid use on slippery surfaces (such as ice) or too irregular (such as gravel)) . The
product has a degree of resistance to water and dust that makes it possible to use it in the
presence of accidental and non-persistent sketches. . Therefore, it is not allowed to be
used in the presence of standing water, puddles or adverse weather conditions (such as
rain, snow or hail). . Use the device in dry environments to avoid damage to the engine
and electrical circuits.
While driving always keep both hands on the handlebar knobs and do not carry
objects in your hand.
Do not turn off the device while driving, before stopping the movement. .
Always turn off the device after use. .
Never lift the device (e.g. for transport) by grabbing it from the wheels, danger of injury .
Before cleaning the device, make sure that it is turned off and that the power outlet is dry
and protected from the liquid input. For cleaning use a freshly moistened cloth exclusively
with water. At the end, dry immediately with a soft cloth. Do not use the medium
after using substances that can alter the psychophysical state and/or reduced normal
ability to concentrate.

6
3. TECNICHE FEATURES
Model
LEXGO-LEX R9 (anthracyte/black color)
AC-DC Power supply
100-240 V 50/60Hz
OPERATING TEMPERATURE: 10 DEGREES CELSIUS -
30 DEGREES CELSIUS
Battery
lithium-ion, 36 V, 6.0 Ah
Operating life: approximately 500 full charging cycles with
remaining 70% capacity .??
CARICA TEMPERATURE: 0C to 40C
OPERATIVE TEMPERATURA: -10 degrees
Celsius to 55 degrees Celsius
RICARICA TIME: up to 4 hours
(never exceed 10 hours of continuous charge) .
Wheel engine
brushless 350 W
Electric-powered scooter
velocità max 25 km/h
Battery operational capacity
nominal 216 Wh x 92%
Maximum autonomy
18 km
Limittable speeds
6 km/h - 20km/h - 25km/h
Load limits
20 - 100 kg
Open vehicle size
1007 X 420 X 1079 mm
Closed vehicle size
1007 X 420 X 369 mm
Platform size
535 X 145 X 58 mm
Body height
60mm (between ground and body)
Platform Height
90mm (between ground and support plane)
Bar height
1080 mm
Product mass
12.5 kg
Recommended age
14+
Tire diameter
203 mm
Slope that can be exceeded
up to 15 degrees on the horizontal plane

7
4. DESCRIPTION
1. Handlebar
2. Lighthouse
3. Buzzer
4. Control Panel
5. Accelerator lever
6. Disc brake lever
7. Closing hook
8. Front wheel
9. Ingresso alimentazione
10. Tripod
11. Rear wheel disc brake
12. Back wheel
13. Signaling back
14. Rear fender
15. Bar folding hook
16. Platform
17. Leva blocco piantone manubrio
18. Multi-purpose tool
19. Quick (4 pz . )
20. Power supply
21. Charging cable
Note. The images may differ slightly from your product, but the indications remain valid.
14
15
16
17
13
12 11
10
18
19
20
21

8
5. ASSEMBLY AND ADJUSTMENTS
Here's how to assemble the product and open the frame before use:
CONNECT THE HANDLEBARS
• Connect the two connectors from the handlebars
and the handlebars together.
• Carefully insert the excess cable into the column,
being careful to prevent it from being crushed or
damaged.
• Slide the handlebars into the column.
• Squeeze the four screws in the tube (see image
next toit).
• Make sure the handlebars are well firm.
FRAME OPENING
Unlo
ck di
sblocco
lever
The frame can be folded and attached to the rear
fender to carry the product easily. .
On the handlebar there is a hooking system with which
to lock it to the hook on the fender .
Once closed, to open the frame proceed as explained
below.
• Unlock the hook on the rear fender.
• Lift the handlebars off the platform.
• Lock the lever by lifting it until clicked.
• Place the safety stop in the groove of the lever.
• Perform operations in reverse order to close the
medium.
6. HOW TO START THE SCOOTER
START AND BRAKE
The scooter must be started with the muscle thrust: put one foot on the platform, grab the handlebar
firmly and push the ground with the other foot to get the device moving. To take advantage of the
thrust of the electric motor you need to activate the control panel in advance and reach a minimum
speed of 5 km/h with muscle thrust .
The electric motor's thrust is activated by pushing
Towards The Low The Takes accelerator Inch
(A), The Power Delivered From Engine Varies
gradually depending on the rotation Of Takes
accelerator .
To brake the vehicle use the disc brake activated
by the lever (B) . The brake should be used
gently, too sharp a braking can cause imbalance
and falls, with the risk of damage to the driver and
mezzo vehicle.

9
SAFE DRIVING
After starting the product, you need to maintain sufficient speed to maintain balance and be suitable
for your surroundings.
With regard to the places where this vehicle can be used and the speed restrictions imposed
according to the place of use, refer to the current legislation.
This scooter is equipped with a control panel that allows you to set the limit speed that can be
reached with the help of the electric motor (see "Technical features" for details on limit speed
values").
The end user must use this feature to adjust their guidance to the limits imposed by applicable local
laws. .
AUTONOMY OF USE
The maximum distance that can be traveled on a single battery charge is indicated
approximately in the "TechnicalFeatures" section. . This value should be considered indicative as
it can be influenced by a number of factors such as:
- the type of surface covered, as uneven and obstacle surfaces (such as gravel) can increase
consumption and reduce battery life;
- The weight carried, within the weight limits specified in this manual, influences energy
consumption;
- speed and riding style, a uniform straight bike requires less energy expenditure than motions
with continuousaccelerations/decelerations or steering;
- proper management of batterycharging and dischargecycles.

10
7. DI CONTROL PANEL
To enable electric motor service, you must turn on the control panel on the handlebars.
On the panel, you can see information such as battery charge, distance traveled, and set
the speed limit (displayed by the gear indicator) and the unit of measurement of the
distance traveled.
• Turn on: Press the ON/OFF OFF button
to turn on the control panel.
• Off: To turn off, hold down the ON/OFF
button for 2 seconds.
• Speedometer: This display shows the
instant speed of the vehicle. The unit
of measurement of the speed can be
km/h
• Front headlight: Press twice in a row to access or
turn off the light.
Speedome
ter
ON/OFF
button
Display
a led
Driving
indica
tion
Battery
indicator
•
Gear: Press the power button once to set the desired gear (limit speed). The gear set to
choose from the three available, will be indicated by the illuminated LED
In Green on the left indicates gear 1 (minimum speed limit) that Right gear 2 (average speed limit),
Both LED I turned on gear 3 (maximum speed limit). The speed limits you set are indicated in
the "Technical Features" section.
• Battery indicator: This indicator has 4 bright LEDs that indicate the battery charge status.
Depending on the number of LEDs on we have the following charge .
LED
Lit
1
(flashing)
1
2
3
4
% CARICA
0-20%
21-40%
41-70%
71-85%
86-100%
WARNINGS ABOUT USING THE CONTROL PANEL
Respect the following warnings when handling the control panel:
1 . Use the Control Panel with caution. Never try to disconnect the connectors, especially
when the battery is on.
2 . Prevent the control panel from being bumped. .

11
8. BATTERY
In order to avoid damage and/or the early deterioration of the battery, charging must be
carried out ta in a dry environment and at a temperature within the range indicated between the
stiche Technical Characteristics of the product.
Open the CC power outlet cover cap on the product.
Ensure that all connectors and sockets involved are dry (especially the CC power outlet on the
product).
Connect the power supply to an electrical grid, in accordance with the license plate data shown
on the medesi-mo mo (if the connection is correct the LED on it lights up green), then insert
the CC power connector into the CC power outlet on the product: when the battery is charging
the LED on the power supply will be red; on full charge its color will turn green.
At the end of charging, protect the power outlet with the plug.
The battery charge status is indicated on the display by the special icon (6 notches
corresponding- gift to the highest level of charge).
Attention! It is recommended that you do not leave the product connected to the power supply
for prolunperiods gati and no later than the time it takes to fully charge the battery because this
could adversely affect the performance and longevity of the latter.
SAFETY WARNINGS
• Keep kids away from battery and power supply.
• Always store and use the battery and power supply in dry environments with
temperatures within the range specified at Cap . 2 "Technical features" and with
adequate ventilation .
• DON'T charge the battery outdoors or with weather exposure.
• Prevent the battery from coming into contact with water or other liquids (danger of
chemical reactions).
• Keep the battery away from flames and heat sources: it could explode.
• DON'Tshort- circuit the electrical contacts of the battery: it could explode .
• DON'T bump or shake the battery violently: in case of rupture do not touch with your
bare hands .
• DO NOT open or disassemble the battery for any reason.
• DON'T use non-genuine power supplies: Using a non-genuine power supply can cause
damage and even battery explosion; If the power supply is damaged or damaged, contact
the Service.
• Verify that the power grid to which the power supply connects complies with the license
plate data on its label.
• DON'T electrically connect other devices other than the original battery to the power
supply.
• DON'T leave the power supply connected to the power grid for a long time, in
the absence of load (battery not charging).

12
BATTERY MAINTENANCE
In order to get the best performance from the battery, you should follow a few follow-to-follow
steps listed:
- When the battery charge level indicator marks two notches or less, fast-paced tà
can quickly drain the battery; we recommend that you proceed slowly and recharge your
battery as soon as possible. If the indicator flashes (no notches), the battery is
completely drained, stop and recharge as soon as possible.
- Battery maintenance should not, in any case, be namento carried out by the end user:
contact a qualified maintenance service centre, if you are unsure of its
function.
- Do not use the battery in the following cases:
1 . the battery emits abnormal odor or is very
hot; 2 . loss of substances from the battery.
- Do not touch any substances that come out of the battery.
- Keep the battery out of reach of children and animals.
- Before installing (or replacing) the battery disconnect it from the power supply.
- Always use only the supplied power supply (in case of damage to the latter contact
the replacement assistance ) service).
- Prevent the voltage level on the display from ) falling too low (helps to maintain
battery performance for longer).
- Check the current laws regarding the disposal of batteries of this type, exhausted .
Danger! In any case, the battery contained in the device must be stored in a temperature
rature within the range 0-40 degrees Celsius in a dry environment; never expose the
battery to free flames. libere.
Never attempt to open the batteries and/or disperse their contents into the environment.

13
9. CLEANING AND MAINTENANCE
Cleaning
Before performing any cleaning and/or maintenance, you should make sure that the product is
turned off and is not connected to the power supply.
Clean only the external parts of the product and with a cloth slightly moistened with water, do not
use detergents or chemical solvents .
Avoid in any case the entry of water or dust inside the equipment. .
Maintenance
Avoid recharging the product in environments with a temperature of less than 0 degreesC . If you
need to refill the product, make sure that the room temperature is above 0 degrees Celsius, a
minimum temperature of 10 degreesC is recommended.
When storing the appliance choose a possibly unpoeoping environment, it is advisable to wrap it in
a plastic wrap to avoid the entry of dust . Always store the product indoors with temperature within
the operating intervals indicated in the Table of Technical Specifications and controlled humidity
(see Technical) Specifications table).
Important! When storing the product for long periods of use, make sure it is fully charged and
periodically (at least once every 2 months) check verifica the battery's charge status,
which will help prevent the battery from lost its charging capacity.
HOW TO STORE THE VEHICLE
Fully charge the battery before storing it. . Next, the battery should be fully recharged once a month.
.
Cover the scooter to protect it from dust. . Store the scooter
indoors, in a dry place.
Assistance
If there is a failure, contact your reseller for assistance.
Important! Any maintenance to and/or replacement of the battery pack must be carried out by
authorized and qualified technical personnel.
In the event of an intervention on the battery pack, it is recommended that the power supply be
disconnected from the appliance in advance.
Lithium batteries are dangerous material, in case of need of transport, comply with the rules and
laws in force in this regard.
The distributor cannot be held liable for any third-party damage caused by the misuse of
batteries.

14
10. PROBLEM SOLVING
The following short guide can help you in case of malfunctions related to the electrical
parts of the bicycle. For other mechanical failures, see a regular Repairer.
Problem
Possible Cause
Solution
Insufficient autonomy
The battery was not well
charged. . The battery has
aged. .
The battery is damaged. .
High energy
consumption .
Fully recharge the battery. Replace
the battery.
Replace the battery.
Normal uphill, on uneven terrain, with
deflated tires, and with high weight.
.
THE MOTORE does not
activate
The battery is off. .
The battery is dead.
.
The battery is not connected.
Electrical system failure.
Activate the main switch.
Charge the battery. .
Better connect the battery to its
location. .
Contact Technical Support .
Battery won't charge
The power supply is not well
connected to the electrical
outlet, or to the battery. . The
power supply is broken. .
The battery is damaged. .
Connect both power supply
terminals well.
Contact Technical Support .
Contact Technical Support .
DISPOSAL OF ELECTRICAL AND ELECTRONIC EQUIPMENT
The 2012/19/EU European Directive on Electrical and Electronic Equipment Waste (RAAE) stipulates
that used appliances cannot be disposed of in the normal flow of urban solid waste. Decommissioned
appliances must be collected separately to optimize the recovery and recycling of the
materials that make up them, to achieve significant energy savings, energia,
and to prevent potential damage to human health and the environment. . The
slashed trash container symbol is displayed on all products to remember
separate collection obligations. . Consumers will have to hand over the decommissioned appliances
to the separate collection centres set up by the municipal authorities.
Made in China

15

Due to the continuous technological evolution of the products, the data contained in this manual may vary slightly without the manufacturer's notice.
