Lexus IS200t 2017 User manual

2017 IS200t/IS300/IS350 Pre-Delivery Service Manual
Lexus Technician:
Before you perform Pre-Delivery Service (PDS) on this vehicle, be sure you:
• ReadandunderstandthisPDSManual
• ReadandunderstandallapplicablePDSTechnicalServiceInformationBulletins(TSIBs)forthisvehicle
• ReadandunderstandthePDSPrecautionsintheTSIBs and on pages 4 and 45.
• Attendthe“TechnicalIntroductiontoLexusCourseL005”attheLexusAreaOffice
When performing PDS on this vehicle:
• UsethePDSManualwhenperformingthisservice
• CheckTechnicalInformationSystem(TIS)forupdatedPDSTSIBsand applicable Repair Manual information
• VerifythattheVehicleIdentificationNumber(VIN)onrepairorderandvehiclematch
• Liftvehicleandperformunder-vehiclesafety/damageinspection
• Roadtestvehiclelongenoughtotesthotengine;driveoverroughroad(Bottdots)totestforrattles/squeaks
• WhenPDSiscompleted,completeCheckSheet,attachprintouts,andfilewithPDSrepairorder
The following TSIBs are available on TIS:
BatteryMaintenanceforIn-StockVehicles&Pre-Delivery
DCCFuseInstallationDuringPDS
EnformApps&DataServicesDownload&InstallationProcess
FloorMatInstallationDuringPDS
FrontLicensePlate&MountingBracketInstallation
FrontWheelOpeningExtensionPadInstallationDuringPDS
InitialCalibrationofCompassDuringPDS
Long-TermVehicleStorageGuidelines
TirePositioningBeforeNewVehicleDelivery
TirePressureWarningSystemInitialization
Wheel Film for Brake Rotor Rust Prevention
XMActivationConfirmationDuringPDS
To obtain PDS material:
Manual
• DownloadfromTIS
CheckSheet
• DownloadandprintfromTIS
OtherPDSTSIBs
• DownloadfromTIS
Contact your District Service & Parts Manager if you have any questions.
MM/JBS201608
©2016Lexus,aDivisionofToyotaMotorSalesUSA,Inc.
TPWS Operation Verication
1. ConnectTechstreamtoDLC3.
2. Adjustalltires(exceptthespare
tire)tothestandardtireination
pressureasindicatedonthetireand
loadinginformationlabelonvehicle.
NOTE:
• Toadjusttirepressurecorrectlywhen
outsidetemperatureissignicantly
colderorwarmerthanshop
temperature,performaHealth
CheckusingTechstreamandselect
the“CompensationTirePressure”
checkbox.Compensationpressures
willbedisplayedontheHealthCheck
resultsscreen.
• Adjustthetirepressurewhenthetires
arecold.

2017MY
IS200t/IS300/IS350
Pre-Delivery
Service Manual
IS200t/IS300/IS350

INSPECTION DETAILS
A.ENGINECOMPARTMENT........................................................ 1
B.LOCKSANDLIGHTS................................................................ 5
C.LEFTFRONT............................................................................. 11
D.LEFTREAR............................................................................... 32
E. TRUNK...................................................................................... 34
F. RIGHTREAR............................................................................. 35
G.RIGHTFRONT.......................................................................... 36
H.FRONTBUMPER...................................................................... 39
I. UNDERVEHICLE(SAFETY/DAMAGE).................................... 40
J. ROADTEST.............................................................................. 43
COMPLETION....................................................................................... 51
INDEX ................................................................................................... 54
IIS200t/IS300/IS350
TABLE OF CONTENTS

1Fuseboxes............................................................................................................-
2Battery.................................................................................................................. 3
3Engineoilleveldipstick........................................................................................ 2
4Enginecoolantreservoir....................................................................................... 4
5Engineoilllercap............................................................................................... 2
6Brakeuidreservoir.............................................................................................. 3
7Washeruidtank.................................................................................................. 4
8Electriccoolingfans............................................................................................ 45
9Condenser.............................................................................................................-
10Radiator................................................................................................................. -
Page
NOTE:
Install protective fender covers prior to beginning the under-hood inspection.
IS300/IS350
II IS200t/IS300/IS350
TABLE OF CONTENTS

IS200t
1Fuseboxes............................................................................................................-
2Battery.................................................................................................................. 3
3Intercooler..............................................................................................................-
4Engineoilleveldipstick........................................................................................ 2
5Engineoilllercap............................................................................................... 2
6Enginecoolantreservoir....................................................................................... 4
7Brakeuidreservoir.............................................................................................. 3
8Washeruidtank.................................................................................................. 4
9Electriccoolingfans............................................................................................ 45
10Condenser............................................................................................................. -
  Intercoolerradiator................................................................................................ -
  Radiator.................................................................................................................-
  Intercoolercoolantreservoir................................................................................. 4
11
12
13
III IS200t/IS300/IS350
TABLE OF CONTENTS

Engineswitch....................................................................................................... 8
Shiftlever...............................................................................................................-
Meters................................................................................................................ 18
Multi-InformationDisplay.................................................................................... 22
Parkingbrake..................................................................................................... 45
Turnsignallever................................................................................................... 9
Headlightswitch................................................................................................... 9
Windshieldwiperandwasherswitch.................................................................. 17
Emergencyasherswitch.................................................................................... 9
Trunkopener...................................................................................................... 16
Hoodlockreleaselever........................................................................................ 2
Tiltandtelescopicsteeringcontrolswitch*......................................................... 22
Tiltandtelescopicsteeringlockreleaselever*................................................... 22
Airconditioningsystem....................................................................................... 23
Audiosystem...................................................................................................... 24
Trunkopenermainswitch.................................................................................. 38
Page
1
2
3
4
5
6
7
8
9
10
11
12
13
14
1 5 
6
* Ifequipped
IV IS200t/IS300/IS350
TABLE OF CONTENTS

Audioremotecontrolswitches............................................................................25
Paddleshiftswitches.............................................................................................-
Metercontrolswitches........................................................................................25
Vehicle-to-vehicledistancebutton*.....................................................................47
Cruisecontrolswitch*.........................................................................................47
Dynamicradarcruisecontrolswitch*.................................................................47
LDA(LaneDepartureAlert)withsteeringcontrolswitch....................................46
Talkswitch..........................................................................................................25
Telephoneswitches............................................................................................25
Page
* Ifequipped
1
2
3
4
5
6
7
6
8
VIS200t/IS300/IS350
TABLE OF CONTENTS

* Ifequipped
Insiderearviewmirror.........................................................................................31
Sunvisors...........................................................................................................30
Vanitymirrors......................................................................................................30
Interiorlight/Personallights................................................................................15
Moonroofswitches*............................................................................................30
SOSbutton*.......................................................................................................31
Garagedooropenerswitches............................................................................31
Page
1
2
3
4
7
5
6
VI IS200t/IS300/IS350
TABLE OF CONTENTS

* Ifequipped
Drivingpositionmemoryswitches*......................................................................13
Outsiderearviewmirrorswitches........................................................................15
Doorlockswitches...............................................................................................14
Powerwindowswitches.......................................................................................14
Windowlockswitch.............................................................................................14
Tirepressurewarningswitch................................................................................. -
Page
1
2
3
4
5
6
VII IS200t/IS300/IS350
TABLE OF CONTENTS

* Ifequipped
Seatheaterswitches*......................................................................................... 29
Seatventilatorswitches*.................................................................................... 29
Heatedsteeringwheelswitch*........................................................................... 29
Drivingmodeselectswitch................................................................................. 48
VSCOFFswitch................................................................................................. 49
Snowmodeswitch.............................................................................................. 48
Remotetouch*.................................................................................................... 26
Lexusdisplayaudiocontroller*.......................................................................... 26
Page
1
2
3
4
5
6
7
8
VIII IS200t/IS300/IS350
TABLE OF CONTENTS

Automatichighbeamswitch*............................................................................... 9
Windshieldwiperde-icerswitch*........................................................................ 15
Odometer/tripmeterandtripmeterresetbutton................................................ 16
Instrumentpanellightcontrolswitches............................................................... 16
Rearsunshadeswitch*....................................................................................... 29
Intuitiveparkingassistswitch*............................................................................ 27
BSM(BlindSpotMonitor)mainswitch*.............................................................. 16
Page
1
2
3
4
5
6
7
* Ifequipped
IX IS200t/IS300/IS350
TABLE OF CONTENTS

INSPECTION DETAILS
IS200t/IS300/IS350

WASHING VEHICLE
Afterwashingvehicle,makesurealladhesivewrappinglm
isremoved.
NOTE:
Handwashingisrecommended.
WATER LEAK TEST
Visuallyandbyhand,checkforwaterleaksinthevehicle
interiorfromeachofthefollowingareas(makesurethatthe
trimandoorcarpetarenotdamp):
a)Doorglassweatherstrips
b)Frontcowlsides
c)Aroundthewindshield
d)Aroundthemoonroofarea
e)Aroundthequarterwindow
f) Aroundtherearwindow
PAINT FINISH (PAINT DEFECTS, DAMAGE)
Visuallyandbyhand,inspectallbodypanels(doors,trunk,
fenders,enginehood,roofpanel)forsurfacedamagefrom
shipmentorforanyabnormalities(surfacerust,paintaking,
chips,dentsorscratches).
NOTE:
Useawell-illuminatedareatoclearlyinspectallpainted
surfaces(800-luxilluminationisrecommended).
EXTERIOR PARTS FOR FIT
Visuallyandbyhand,checkthefollowingpartsforproper
installation,rust,t,misalignmentandlooseitems:
a)Frontandrearbumpers
b)Windowmoldings(front,sideandrear)
c)Lexusemblems(frontandrear)
d)Outsiderearviewmirrors
e)Headlights,turnsignallights,sidemarkerlights,fog
lightsandtaillightlenses
f) Doors,enginehoodandfuelllerdoor
g)Moonroof
h)Front/Reardoorpanelprotector
i) Outsidedoorhandle
j) Radiatorgrille
1IS200t/IS300/IS350
INSPECTION DETAILS - A. ENGINE COMPARTMENT

ENGINE HOOD RELEASE LEVER
Usetheenginehoodreleaselevertocheckthatthelatch
operatesproperly.Ensurethattheenginehoodopensand
closessmoothly.
ENGINE OIL LEVEL (ENGINE NOT
RUNNING)
a)Removetheengineoilleveldipstickandwipeitclean.
Reinsertthedipstickandpullitouttochecktheoillevel.
Thelevelshouldbebetweenthetwomarks.
1Low
2Full
 Excessive
b)Checktheoilfordirtorimpurities.
NOTE:
Iftheoillevelislow,addspeciedengineoilandcheck
foroilleaks.
3
DCC FUSE INSTALLATION
RefertoTSIB.
2IS200t/IS300/IS350
INSPECTION DETAILS - A. ENGINE COMPARTMENT

BRAKE FLUID LEVEL
Visuallychecktheuidlevelthroughthereservoir.Ifthe
uidlevelislow,replenishthebrakeuidreservoirwith
FMVSSNo.116DOT3orSAEJ1703brakeuidandcheck
foruidleaks.Brakeuidlevelshouldbeatthe“MAX”line
(within0.2inches[5.0mm]below).
NOTE:
RefertotheRepair Manualforuidspecications.
BATTERY TERMINAL TIGHTNESS AND
CHARGE
a)Checktheelectrolytelevel.Iftheelectrolytelevelislow,
checkthebatterycaseforleakage.
b)Checkthebatterycharge.Measuretheopen-circuit
batteryvoltagebetweentheterminals.Ifthevoltage
readingislessthan12.6volts,rechargethebattery.
NOTE:
Beforemeasuringthevoltage,turnofftheengineandall
electricalsystems.Wait60secondstoremovethesurface
charge.Iftheenginewasrunningbeforemeasuringthe
voltage,wait20minutesaftertheenginestopstoremove
thesurfacecharge.
c)Checkthatthebatteryterminalsareproperlyconnected
andthattheclampisrmlyinstalled.
 Terminals
 Hold-downclamp
d)PrintoutBatteryChargeTest
1
2
3IS200t/IS300/IS350
INSPECTION DETAILS - A. ENGINE COMPARTMENT

WASHER FLUID LEVEL
Openthewashertankcapandvisuallycheckthewasher
uidlevelinthewashertank.Theuidlevelshouldbelled
within2inchesofthecap.
WIRING AND HOSES
a)Checkthehoses,hoseconnectorsandvariousclamps
fortightness.
b)Visuallyinspecttheconditionofallharnessconnectors
andterminalsforproperinstallationandtightness.
ENGINE COOLANT LEVEL
Visuallycheckthecoolantlevelthroughthecoolant
reservoirtankwhentheengineiscool.Thecoolantlevelis
satisfactoryifthelevelisbetween“FULL”and“LOW.”
1Reservoircap
2FULL
3LOW
CAUTION:
Topreventburningyourself,donotremovetheradiatorcap
whentheengineishot.
IS300/IS350
IS200t
INTERCOOLER COOLANT RESERVOIR
Thecoolantlevelissatisfactoryifitisbetweenthe“F”and
“L”linesonthereservoirwhentheengineiscold.
1Reservoircap
2“F”line
3“L”line
4IS200t/IS300/IS350
INSPECTION DETAILS - A. ENGINE COMPARTMENT
CAUTION:
Topreventburningyourself,donotremovetheradiatorcap
whentheengineishot.

WIRELESS REMOTE CONTROL
Inspectthevefunctionsofthesystem.
1Locksthedoors
2Unlocksthedoors
3Opensthetrunk(pressandhold)
4Soundsalarm(pressandhold)
a)Lockingthedoors
1. Closeallthedoors.
2. Press ontheelectronickeytolockallthedoors
fromoutsidethevehicle.
NOTE:
When ispressedtolockdoors,abeepwill
soundandallturnsignallightswillashonce.
However,ifanydoorisnotclosedsecurely,
pressing willcausethebuzzertosound 
continuouslyuntilalldoorsareproperlyclosed.
b)Unlockingthedoors
1. Press ontheelectronickeyoncetounlockthe
driver’sdoor.
2. Press onceagainwithin3secondstounlockthe
otherdoors
NOTE:
Theinteriorlightandouterfootlightswill
turnonandalltheturnsignallightsashtwice,
soundingtwobeeps.
3. Checkthatalldoorsautomaticallyre-lockafter60
secondsifanydoorisnotopened.
c)Openingthetrunk
Pressandhold toopenthetrunk.
NOTE:
Abuzzersoundstoindicatethatthetrunkisopening.
d)Soundingthealarm
1. Pressandhold tosoundthealarm.
2. Tostopthealarm,pressanybutton.
5IS200t/IS300/IS350
INSPECTION DETAILS - B. LOCKS AND LIGHTS

SMART ACCESS SYSTEM
a)Withelectronickeyinsideofthevehicle,touchthelock
sensor(ontheupperpartofthedoorhandle)andtrunk
lockbutton.Checkthatthebuzzersoundsandthat
thedoorsdonotlock.
b)Taketheelectronickeyandgetoutofthevehicle.Touch
thelocksensor(ontheupperpartofthedoorhandle).
Checkthatthedoorlocks.
NOTE:
Recognitionsignalsforthelockoperationwilloperate
uptotwoconsecutivetimes.
c)Fromadistanceofatleast2.3ft.(0.7m),approachthe
vehicleandpullthedriverandpassengersidedoor
handles,andthetrunkopener.Checkthatthedoor
unlocks.
NOTE:
Thedoorscannotbeunlockeduntil3secondsafter
theywerelocked.
THEFT DETERRENT SYSTEM
Withthedoorslocked,checkthatthesystemoperates
properly.
System Test:
a)Openthewindows.
b)Lockthedoorsbysmartaccesssystem,wireless
remotecontrolormechanicalkey.Besuretowaituntil
thesecuritylightonthecenterpanelstartsashing.
c)Unlockoneofthedoorsusingtheinsidedoorlock.The
systemshouldactivatethealarm,whichuseslightand
soundwhenanintrusionisdetected.
d)Cancelthesystembyunlockingdoorswiththesmart
accesssystem,wirelessremotecontrolormechanical
key.
IMMOBILIZER SYSTEM
a)Checkthatthesecurityindicatorlightasheswhenthe
“ENGINE”switchisOFF.
b)Checkthattheenginecanbestartedusingall
thekeys.
c)Checkthatthesecurityindicatorlightturnsoffwhen
startingtheengine.
6IS200t/IS300/IS350
INSPECTION DETAILS - B. LOCKS AND LIGHTS

DOOR LOCK SYSTEM AND ILLUMINATED
ENTRY SYSTEM
a) Checkthatalldoorsopenandclosesmoothlyusingthe
insideandoutsidedoorhandles.
b) Checkthatthedoorscannotbeopenedbyusingthe
insideandoutsidedoorhandleswhenthelockbuttonis
inthelockedposition(exceptfrontinsidedoorhandles).
c) Forfrontinsidedoorhandles:Checkthatthefrontdoors
canbeopenedbyusingtheinsidedoorhandleswhen
thelockbuttonisinthelockposition.
d) Checkexteriorkeylockcontrolsystemoperationby
mechanicalkey(withdriver’sdoor).
1Locksalldoors
2Unlocksthedoor(two-stepunlockfunction):
1. Turnthekeyoncetounlockthedriver’sdoor.
2. Turnthekeytwicetounlockallthedoors.
e)Checkthattheouterfootlightilluminateswhenthe
doorisunlocked.
7IS200t/IS300/IS350
INSPECTION DETAILS - B. LOCKS AND LIGHTS

POWER SUPPLY CHANGEOVER AND
ENGINE START/STOP
Checkforproperactivationofthe“ENGINE”switch.
Powersupplychangeover
a)Carrytheelectronickeyinthevehicleandapplythe
parkingbrake.
b)Withoutdepressingthebrakepedal,pressthe
“ENGINE”switchandchangethepowersupply.
1. OFF
2. Pressonce:ACCESSORYmode
3. Presstwice:”IG-ON”mode
4. Pressthreetimes:OFF
c)Ineachmode,checkthatthepowersupplyhaschanged
properly.
Engine start/stop
a)Carrytheelectronickeyinthevehicleandapplythe
parkingbrake.
b)Checkthattheshiftleverisinthe“P”position.
c)Whiledepressingthebrakepedal,pressthe“ENGINE”
switch.
EXTERIOR LIGHTS
Walkaroundthevehicleandcheckthatthefollowinglights
illuminate:
a)Headlights
b)Parkinglightsanddaytimerunninglights
c)Frontsidemarkerlights
d)Sideturnsignallights
e)Stoplights
f) Taillights
g)Rearsidemarkerlights
h)High-mountedstoplight
i) Licenseplatelights
j) Outerfootlights
8IS200t/IS300/IS350
INSPECTION DETAILS - B. LOCKS AND LIGHTS
