LEYBOLD ECODRY plus 25 User manual

ECODRY plus
Multi-stage roots vacuum pump
Operating instructions 300902516_002_C0
162025V001
162035V001

Copyright notice
©Leybold GmbH. All rights reserved.
Trademark credit
Leybold and the Leybold logo are trademarks of Leybold GmbH, Bonner
Strasse 498, D-50968 Cologne.
Disclaimer
The content of this manual may change from time to time without notice.
We accept no liability for any errors that may appear in this manual nor do
we make any expressed or implied warranties regarding the content. As far
as practical we have ensured that the products have been designed and
constructed to be safe and without risks when properly installed and used
in accordance with their operating instructions.
We accept no liability for loss of prot, loss of market or any other indirect
or consequential loss whatsoever.
Product warranty and limit of liability are dealt with in our standard terms
and conditions of sale or negotiated contract under which this document is
supplied.
You must use this product as described in this manual. Read the manual
before you install, operate, or maintain the product.

1 Safety and compliance. . . . . . . . . . . . . . . . . . . . . . . 7
1.1 Denition of Warnings and Cautions. . . . . . . . . . . . . . . . . . 7
1.2 Safety symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2 General description. . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.1 Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.2 Pump controller. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.3 Interface control panel. . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.3.1 Auxiliary connector socket. . . . . . . . . . . . . . . . . . . . . . . 11
2.4 Logic interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.5 Gauge connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.6 Auto-run. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.7 Pump controller conguration. . . . . . . . . . . . . . . . . . . . . . 13
3 Technical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.1 Operating and storage conditions. . . . . . . . . . . . . . . . . . . 14
3.2 Mechanical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.3 Performance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.4 Materials exposed to gases pumped. . . . . . . . . . . . . . . . 16
3.5 Electrical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4 Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4.1 Unpack and inspect. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4.2 Mechanical installation. . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4.3 Leak test the system. . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.4 Electrical installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.4.1 Pump voltage setting. . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.4.2 Connect the electrical supply. . . . . . . . . . . . . . . . . . . . . 23
4.5 Connection for remote control and monitoring. . . . . . . . . 23
5 Commission the pump. . . . . . . . . . . . . . . . . . . . . . 24
6 Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
6.1 Operation safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
6.2 Operational modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
6.2.1 Control panel interface. . . . . . . . . . . . . . . . . . . . . . . . . . 26
6.3 Logic interface data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Contents

6.4 Parallel control and monitoring. . . . . . . . . . . . . . . . . . . . . 28
6.4.1 X1 Control Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
6.5 Analogue speed control. . . . . . . . . . . . . . . . . . . . . . . . . . 29
6.6 Operational modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
6.7 Start the pump. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
6.8 Shut down the pump. . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
6.9 Restart the pump. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
6.10 X104 SUB-D9 (female) Serial RS-485 Interface. . . . . . . . 32
6.11 MODBUS RTU Protocol. . . . . . . . . . . . . . . . . . . . . . . . . 32
6.11.1 Physical layer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
6.11.2 Data link layer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
6.11.3 Application protocol layer. . . . . . . . . . . . . . . . . . . . . . 34
6.11.4 ECODRY plus Protocol. . . . . . . . . . . . . . . . . . . . . . . . 35
6.11.5 Register Addresses. . . . . . . . . . . . . . . . . . . . . . . . . . . 36
6.12 Gas ballast operation. . . . . . . . . . . . . . . . . . . . . . . . . . . 43
6.13 Gas ballast adaptor t. . . . . . . . . . . . . . . . . . . . . . . . . . . 44
6.14 Extra silencer removal. . . . . . . . . . . . . . . . . . . . . . . . . . . 44
6.15 Mounting kit use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
6.16 Pressure gauge connectivity and automatic eco-mode. . 46
7 Maintenance and service. . . . . . . . . . . . . . . . . . . . 48
7.1 General maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
7.2 Maintenance plan. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
7.3 Inspect and clean the inlet strainer. . . . . . . . . . . . . . . . . . 48
7.4 Clean the external fan grill. . . . . . . . . . . . . . . . . . . . . . . . . 48
7.5 Replace the pump bearings. . . . . . . . . . . . . . . . . . . . . . . 49
7.6 Replace the pump controller. . . . . . . . . . . . . . . . . . . . . . . 49
7.7 Electrical safety check. . . . . . . . . . . . . . . . . . . . . . . . . . . 49
7.8 Service indicator codes. . . . . . . . . . . . . . . . . . . . . . . . . . 49
8 Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
8.1 Leybold Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
9 Fault nding. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
9.1 Alarm indicator codes. . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
10 Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
300902516_002 - 10/2020 - © Leybold
4
Contents

11 Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
12 Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
12.1 Electrical cables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Contents

Figure 1. General view. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Figure 2. Interface control panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Figure 3. Valve connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Figure 4. Gauge connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Figure 5. Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Figure 6. Performance graph. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Figure 7. Voltage selection plate. . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Figure 8. ECODRY plus X1 SUB-D 9 (male) START / STOP and
STANDBY operation conguration. . . . . . . . . . . . . . . . . . . . . . . . . . 29
Figure 9. ECODRY plus X1 SUB-D 9 (male) Speed control
conguration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Figure 10. Analogue speed control. . . . . . . . . . . . . . . . . . . . . . . . . 30
300902516_002 - 10/2020 - © Leybold
6
List of Figures

1 Safety and compliance
1.1 Denition of Warnings and Cautions
NOTICE:
For safe operation from the start, read these instructions carefully before you install or
commission the equipment and keep them safe for future use.
Read all the safety instructions in this section and the rest of this manual carefully
and make sure that you obey these instructions. The equipment must only be
operated and maintained by trained personnel in the proper condition and as
described in this instruction manual.
Obey local and state requirements and regulations. If you have any questions about
safety, operation or maintenance of the device, please contact our nearest subsidiary.
Important safety information is highlighted as warning and caution
instructions. Obey these instructions.
WARNING:
If you do not obey a warning, there is a risk of injury or death. Different symbols are
used according to the type of hazard.
CAUTION:
If you do not obey a caution, there is a risk of minor injury, damage to equipment,
related equipment or process.
NOTICE:
Information about properties or instructions for an action which, if ignored, will cause
damage to the pump or the system.
We reserve the right to change the design and the stated data. The
illustrations are not binding.
Keep the instructions for future use.
7
300902516_002 - 10/2020 - © Leybold
Safety and compliance

1.2 Safety symbols
The safety symbols on the products shows the areas where care and
attention is necessary.
The safety symbols that follow are used on the product or in the product
documentation.
Warning/Caution
An appropriate safety instruction must be followed or caution to a
potential hazard exists.
Warning - Heavy object
Identies a possible hazard from a heavy object.
Warning - Dangerous voltage
Identies possible hazards from dangerous voltages.
Warning - Protective earth (ground)
Earth point for electrical equipment.
Warning - Use protective equipment
Use appropriate protective equipment for the task.
WEEE symbol
The equipment must be discarded carefully. Obey local and national
regulations for disposal of this equipment.
300902516_002 - 10/2020 - © Leybold
8
Safety and compliance

2 General description
2.1 Overview
WARNING: INCORRECT USE OF EQUIPMENT
Risk of injury or damage to the equipment. Incorrect use of the equipment can cause
damage to the equipment or injury to people. The user is responsible for the safe
operation, installation and monitoring of the system.
The ECODRY plus product family is a range of dry, multi-stage roots vacuum
pumps that offers high pumping speed in a compact form. The pump is
connected by a power cord and is designed for use on clean duty
applications.
The cord ratings are:
Supply voltage (V) Current (A) Frequency (Hz)
100 ‑127 14 50 or 60
200 ‑240 7
The pump is not designed for use with ammable, corrosive, toxic, or other
hazardous gases. Gas or oxygen can mix in the pump.
The dry pumping system can be used in either transient or steady state gas
load conditions. The pump can sustain continuous operation with a
maximum power consumption of 850 W. When the load is more than 850 W
motor power the speed temporarily reduces.When high load passes the
motor speed is increased, or when the transient overload protection has
recovered. Refer to Table: Performance data for information on maximum
inlet pressure.
Refer to Figure: General view, the system is supplied with an DN 25 ISO-KF
inlet port (1) and an DN 25 ISO-KF exhaust port (10).
The pump mechanism is operated by an electric motor driven by an internal
pump controller. The rotational elements of the pumping mechanism are
simply supported at the end by lubricated bearings. PFPE lubricant is used
and this is contained in both the gearbox and motor ends of the pump
module, these are "sealed for life" and the lubricant does not need to be
replaced until the pump service interval is reached.
The system is air cooled by a fan installed internally in the pump enclosure.
The pump has a thermal protection device that will stop the motor if a
thermal overload occurs, for example due to high ambient temperature. If
the thermal protection is triggered, you must restart the pump after it has
cooled down.
The pump is designed to pump the residual gases used in high vacuum
systems. The gases are:
▪Air
▪Nitrogen
▪Krypton
▪Argon
▪Helium
9
300902516_002 - 10/2020 - © Leybold
General description

You can use the pump to pump water vapour. You must use the gas ballast
when water vapour is pumped. The water vapour must not condense in the
pump.
To use the pump for a gas that is not listed, contact the supplier for advice.
Failure to contact the supplier can invalidate the warranty of the pump. Do
not use the pump for aggressive or corrosive gases.
Figure 1. General view
1. Inlet port 2. Dashboard or interface
3. Gas ballast 4. Vibration isolator
5. Castors x 2 6. X101, RJ45 connector
7. X201, M8 Aux Connector 8. X1 SUB-D 9 pin (male)
9. X104 SUB-D 9 pin (female) 10. Mains circuit breaker
11. Mains connector socket 12. Exhaust port
13. Protective earth stud 14. Voltage selection cover plate
15. Lifting eye position
1. Inlet port 2. Dashboard or interface
3. Gas ballast 4. Vibration isolator
5. Castors x 2 6. X101, RJ45 connector
7. X201, M8 Aux Connector 8. X1 SUB-D 9 pin (male)
9. X104 SUB-D 9 pin (female) 10. Mains circuit breaker
11. Mains connector socket 12. Exhaust port
13. Protective earth stud 14. Voltage selection cover plate
15. Lifting eye position
2.2 Pump controller
The pump controller contains the drive electronics to control the pump
operation. The pump controller controls the supply of electric current to the
motor as per the operating conditions.
The interface control panel is connected to the pump controller. The pump
can be operated:
▪manually, with the buttons on the user interface control panel. Refer to
Figure: Interface control panel.
▪remotely, with the serial communications (X104) or digital and analogue
process control (X1), through the SUB-D 9 pin connector. Refer to
Connection for remote control and monitoring on page 23.
300902516_002 - 10/2020 - © Leybold
10
General description

2.3 Interface control panel
Figure 2. Interface control panel
1. Start button 2. Standby button
3. Standby decrease button 4. Standby increase button
5. Alarm indicator LED 6. Service indicator LED
7. Auto‑run indicator LED 8. Standby increase indicator LED
9. USB port (not for operation) 10. Standby decrease indicator LED
11. Standby indicator LED 12. Run indicator LED
13. Stop button 14. Power status LED
1. Start button 2. Standby button
3. Standby decrease button 4. Standby increase button
5. Alarm indicator LED 6. Service indicator LED
7. Auto‑run indicator LED 8. Standby increase indicator LED
9. USB port (not for operation) 10. Standby decrease indicator LED
11. Standby indicator LED 12. Run indicator LED
13. Stop button 14. Power status LED
2.3.1 Auxiliary connector socket
An auxiliary control connection on the rear panel controls an optional inlet
valve. This inlet valve can be operated in parallel with the normal pump
output signal. Refer to Figure: General view, (7). The valve is usually closed
and:
▪will open when the normal signal becomes active (pump at speed)
▪will close when you select the stop button or if there is a fault
condition.
The reaction time will be in line with the valve selection and the output signal
is 24 V d.c., refer to Figure: Valve connector for the polarity of the connector
pins when the connector is energized.
The auxiliary connector is regulated to 24 V d.c. to control the accessories. If
the auxiliary load current exceeds the value in Table: Auxiliary load currents,
the output will shut down to protect the pump controller. Refer to Table:
Recommended mating plugs for the recommended mating plugs.
11
300902516_002 - 10/2020 - © Leybold
General description

Figure 3. Valve connector
Pin number Signal
1 + 24 V
3 GND
4 PE
Table 1 Auxiliary load currents
Description Data
Connector plug Plug M8 male Kst 0°Series 768 99-3379-100-03
Binder
Voltage output 24 V d.c. -25%, +10% (18 V d.c. to 26.4 V d.c.)
Output power 1 Channel with 4 Watt
Table 2 Recommended mating plugs
Mating connector plug Phoenix part number
Screw connection, straight SACC-M 8MS-4CON-M-SW
Solder connection, straight SACC-M 8MS-4CON-M
Screw connection, right angle SACC-M 8MR-4CON-M-SW
Solder connection, right angle SACC-M 8MR-4CON-M
2.4 Logic interface
The logic interface is designed to support the two connectors, both are
located on the rear of the pump.
▪Serial control is connected through a X104 SUB-D 9 pin (female)
connector.
▪Parallel control is connected through a X1 SUB-D 9 pin (male)
connector.
The signals on the logic interface are:
▪control inputs: switch type and analogue signals that control the pump.
▪status outputs: to identify the status of the system tab.
For control modes refer to Table: Control panel interface.
For logic interface data refer to Logic interface data on page 26.
2.5 Gauge connection
A compatible pressure gauge can be connected to the RJ45 (X101) socket
on the rear panel. Refer to Accessories on page 56, for suitable gauges.
300902516_002 - 10/2020 - © Leybold
12
General description

CAUTION: GAUGE MALFUNCTION
Risk of damage to equipment. Do not make connections to the gauge identication
pin (pin 4). Failure to do so can cause the gauge to malfunction.
CAUTION: GAUGE CONNECTION
Risk of damage to equipment. Do not connect a gauge input and analogue input
signal at the same time. This will result in the wrong speed demand.
Figure 4. Gauge connection
1. Electrical supply positive 2. Electrical supply ground
3. Pressure measurement input signal 4. Not connected
5. Signal ground 6. Not connected
7. Not connected 8. Not connected
1. Electrical supply positive 2. Electrical supply ground
3. Pressure measurement input signal 4. Not connected
5. Signal ground 6. Not connected
7. Not connected 8. Not connected
2.6 Auto-run
The auto‑run setting congures the pump to start automatically when the
power is switched on, without any customer intervention.
You can congure the auto‑run through serial communications, or with the
start or stop button. Push and hold the start or stop button for more than
eight seconds to enable or disable the auto-run setting. The auto-run LED
displays the auto-run setting.
The pump can be stopped by either manual, parallel or serial control modes
when in auto‑run mode.
Note:
Refer to Operation safety on page 25 for guidelines on how to congure
different operational modes and any associated warnings to consider.
2.7 Pump controller conguration
The integral pump controller monitors the power and temperature of the
pump. The pump controller protects the user and the pump when the pump
is operated under sustained high load or in fault conditions.
The pump controller is connected to the interface control panel and the
pump can be operated:
▪manually, with the buttons on the user interface control panel. Refer to
Figure: Interface control panel.
▪remotely, with serial or parallel communications through the SUB-D 9-
pin connector located on the rear of the pump. Refer to Connection for
remote control and monitoring on page 23.
13
300902516_002 - 10/2020 - © Leybold
General description

3 Technical data
3.1 Operating and storage conditions
Table 3 Operating and storage conditions
Range Data
Ambient operating temperature range 5 °C to 40 °C
Ambient operating humidity range 80% up to 31 °C
Reducing linearly to 50% at
40 °C
Maximum operating altitude 3000 m
Ambient storage temperature range -30 °C to 70 °C
Maximum humidity (storage in original
packaging)
≤ 95 % RH
Equipment type Indoor use
Enclosure protection IP20
Table 4 Environmental conditions
Pollution Pollution degree 2
Installation Installation category II
Altitude restriction Maximum 3000 m
Area of use Indoor
3.2 Mechanical data
Table 5 Mechanical data
Range 25 35
Mass 28 kg 28.10
Inlet connection DN 25 ISO-KF
Overall dimensions (L x W x H) 494 x 248 x 304 mm
Maximum tilt angle for operation ± 5°
Maximum tilt angle for transport 30°
Nominal rotational speed 15000 rpm
Outlet connection DN 25 ISO-KF
300902516_002 - 10/2020 - © Leybold
14
Technical data

Figure 5. Dimensions
3.3 Performance
Table 6 Performance data
25 35
Maximum pumping speed (m3/hr)* 25 35
Maximum continuous inlet pressure ambient (mbar) 1013†
Maximum chamber size for evacuation (l) No limit
Typical ultimate pressure (mbar) 0.01
Maximum continuous exhaust pressure (mbar(g)) 200
Suck-back protection Exhaust valve design
Leak tightness (static) (mbar l/s ) < 1 x 10-6
* Values for maximum pumping speed are obtained at standard ambient
temperature and pressure. At higher temperatures or different ambient
pressures pump performance may be compromised and the rotational
speed may drop below nominal.
† At high inlet pressures pump rotational speed may reduce to sustain
continuous operation.
15
300902516_002 - 10/2020 - © Leybold
Technical data

Figure 6. Performance graph
Table 7 Sound data
Declared dual-number noise emission values in accordance with ISO 4871
25 35
Measured A-weighted emission sound pressure level,
LpA at ultimate vacuum 1 m from the pump in free
space
52
Uncertainty, KpA 2.5 dB(A)
Values determined in accordance with ISO 3744: 2010
3.4 Materials exposed to gases pumped
The materials and the components exposed to the gases in the pump are:
▪Iron
▪Aluminium alloy
▪Steel
▪Fluoroelastomer (seals)
▪PFPE lubricant
3.5 Electrical data
Table 8 Electrical rating for continuous operation
Pump Supply voltage
(V a.c. rms)
Phase Frequency
(Hz)
Input
current
(A rms)
All variants 200 - 240 ± 10% Single 50 or 60 7.0
100 - 127 ± 10% Single 50 or 60 14.0
300902516_002 - 10/2020 - © Leybold
16
Technical data

Table 9 Recommended regional supply protection
Area Voltage Rating
UK 230 V 10 A, 250 V a.c. rms
Europe 230 V 10 A, 250 V a.c. rms
US 120 V 15 A, 250 V a.c. rms
Japan 100 V 15 A, 250 V a.c. rms
17
300902516_002 - 10/2020 - © Leybold
Technical data

4 Installation
CAUTION: SAFETY INSTRUCTIONS
Follow all safety instructions and take note of all appropriate precautions.
WARNING: BLOCKED EXHAUST PIPELINE
Risk of damage to equipment. Make sure the exhaust pipeline is not blocked. If an
exhaust isolation valve is used, make sure that the pump is not operated with the
valve closed.
Possible hazards on the dry pumping system include electricity, process
chemicals, and Fomblin® (PFPE) oil:
▪Contact us or the local service centre for more information for advice
or assistance on installation.
▪Do not remove the temporary covers from the system inlet and
exhaust until ready to connect.
▪Do not operate the system unless the inlet and exhaust are connected
to the vacuum and exhaust extraction system.
▪Isolate the other components in the process system from the electrical
supply to prevent accidental operation.
▪Electrical supplies are potentially hazardous energy sources. Lockout
and tagout before you do the maintenance.
▪Obey all national and local rules and safety regulations when you install
the system.
▪Tighten the cables, hoses and pipework during installation to prevent a
trip hazard.
▪Make sure that the installation area is clean and free from debris and
contamination before you install the pump.
▪Make sure that all facilities given in this manual are available for the
system to perform correctly.
4.1 Unpack and inspect
WARNING: DAMAGED PUMP
Risk of injury to people or damage to equipment. Do not use the pump if it is
damaged. Failure to do so can result in injury to people and/or damage to equipment.
CAUTION: PUMP LIFE
Risk of damage to equipment. Unpack the pump carefully and avoid excessive shock
to the pump. Excessive shock will damage the bearings and reduce the life of the
pump.
Refer to Table: Mechanical data for the mass of the pump.
The pump is supplied in recyclable packaging.
1. Open the cardboard box from the top.
300902516_002 - 10/2020 - © Leybold
18
Installation

2. Remove the packing material. Keep all the packing materials for use in
the inspection and if the pump is returned for service.
3. Examine the pump for damage. If the pump is damaged, notify your
supplier and the carrier immediately. Give the supplier and the carrier
the information that follows:
▪part number of the pump
▪serial number of the pump
▪order number
▪supplier's invoice number
4. Do not use the pump if the pump is damaged.
5. If the pump is not to be used immediately, store the pump in the
conditions given in Storage on page 54.
6. Do not remove the seals until the pump is ready to be installed on the
vacuum system. The pump is supplied with sealed inlets and an outlet
to prevent the entry of dust and vapour.
4.2 Mechanical installation
WARNING: HEAVY OBJECT
Risk of physical injury. Use suitable equipment to lift the pump.
WARNING: TRIP HAZARD
Risk of injury or damage to equipment. Make sure that any cables and/or pipe work
attached to the pump are xed carefully to avoid a slip/trip hazard and to prevent any
damage to the cable.
WARNING: LIFTING EYE INTEGRITY
Risk of injury or damage to equipment. Make sure that the maximum angle between
the paired slings used to lift the system is 45 degrees. Increased angle could
compromise the lifting eye integrity.
WARNING: INSTALLATION SAFETY
Risk of injury or damage to equipment. Install the pump in the vacuum system before
you connect the power supply. This will make sure that the pump is not operated and
this will avoid injury during the installation.
WARNING: STATIC PRESSURE
Risk of damage to equipment. Do not step or stand on the pump, it is not designed
to withstand large static loads.
19
300902516_002 - 10/2020 - © Leybold
Installation

WARNING: HEAVY OBJECT
Push-pull hazard with strain injury. Push or pull the pump system only for short
distance and over at surfaces. Lift the system with a correct lifting equipment or two
persons must lift if the oor is uneven or there are obstacles present.
WARNING: EXHAUST BLOCKAGE
Risk of injury or damage to equipment. A peak pressure of 3 bar(g) can be generated
in the pump if the exhaust or pipework attached to the exhaust are blocked.
WARNING: HAZARDOUS SUBSTANCES
Risk of injury or damage to equipment. The pump is intended for clean applications
only. It is not suitable for use with hazardous production materials.
CAUTION: INSTALLATION SAFETY
Risk of injury or damage to the environment. Follow all local legislation when the
pump is installed or removed to reduce the impact of the pump on the environment.
CAUTION: HIGH NOISE LEVEL
Risk of hearing damage. When the pump is operating and is not connected to the
vacuum system (with open inlet) the noise level may exceed 85 dB(A).
CAUTION: CONDENSATE DRAINAGE
Risk of damage to equipment. Use a catchpot to prevent the drainage of condensate
back into the system. Condensate that drains back into the system could damage the
pump.
Obey the instructions that follow when you install the pump:
▪Make sure that there is no blockage to access the pump electrical
supply cable or the other controls.
▪Make sure that there is a minimum air gap of 100 mm on all sides of
the pump to allow effective air circulation.
▪Make sure that the system is on a rm and level surface that can
support the mass of the pump.
▪Make sure that the system is installed away from combustible
materials.
▪Level the pump to a maximum of 5 degrees (measured at the pump
inlet).
▪You must do a risk assessment of the location and make sure that you
can move the pump safely and as per the local and national manual
handling guidelines.
To move the pump:
300902516_002 - 10/2020 - © Leybold
20
Installation
