LG PC100 Quick start guide

P/NO. : MFL69325402(1506-REV00)
Printed in Korea
Please read these safety precautions carefully before using the product.
■ Make sure to connect the power cable a grounded outlet.
- You may be electrocuted or injured.
■ Use the rated voltage only.
- The product can be damaged, or you may be electrocuted.
■ During a thunder or lightning storm, unplug the power cable or signal cable.
- You may be electrocuted or a fire can break out.
■ Do not touch the power plug with wet hands. Additionally, if the cord pin is wet or covered
with dust, dry the power plug completely or wipe dust off.
- You may be electrocuted due to excess moisture.
■ Do not insert a conductor (like a metal chopstick) into one end of the power cable while
the other end is connected to the input terminal on the wall. Additionally, do not touch the
power cable right after plugging into the wall input terminal.
- You may be electrocuted.
■ The appliance coupler is used as the disconnect device.
■ Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries
according to the instructions.
Safety Precautions
Mini-PC for Signage
PC100/PC200/PC700
Easy Setup Guide
Please read this guide carefully before using this product and keep it for future reference.
Please record the model number and serial number of the product on this guide. You will
need to provide this information (if applicable) when you require service.
Installation Environment of Mini-PC for Signage
Leave at least 10 cm of space at each side of the product from an obstacle when installing
the product to ensure sufficient ventilation.
< Install Mini-PC for Signage Attached
to Monitor >
< Install Mini-PC for Signage>
10 cm
10 cm
10 cm
10 cm
10 cm
10 cm
10 cm
10 cm
*MFL69325402*

2
Please check that these components are present prior to installing.
PC100 Components
Weight ● The specifications shown above may change
without prior notice for quality improvement.
1.590 kg
PC100 Box Guide
Power Cable RS-232C Cable Rail x 2
M3, L12 x 4
(for attachment of Box Guide on
the monitor)
Handle x 2 M3, L8 x 8
(for attachment of handle)
Owner’s Manual / Cards
●SuperSign software and manual.
- Downloading from the LG Electronics website.
- Visit the LG Electronics website (http://www.lgecommercial.com/supersign) and download the
latest software for your model.
(Depending on the model, this feature may not be supported.)
Note

3
PC100
PC100 Monitor Integration
1Place the handle into the slots on the side of the product.
2Use screws to secure the handle.
3Place the rail in the slots on the side of the product.
We recommend you to use the items provided with your PC100 and follow our instructions for inte-
grating the product with your monitor in order to ensure the correct results.
Warning
● Be careful of sharp edges on the rail and the handle.
● Fixing the product with non-standard screws may cause damage or the product to fall
down. LG Electronics is not liable for any accidents relating to the use of non-standard
screws.
● Do not over tighten the screws as this may cause damage to the product and void your
warranty."
The illustrations shown are to guide your integration and may differ from your product.
Attention

4
4As shown below, use screws to secure the Box Guide in the four tap holes at the back of the
monitor.
5Attach the Box Guide to the rail slots, and press it upward.
6Use screws to secure the product and the Box Guide as shown below.
2 Connect the D-sub port of PC100 and RGB-IN port of the monitor with a D-sub cable.

5
PC100
4As shown below, use screws to secure the Box Guide in the four tap holes at the back of the
monitor.
5Attach the Box Guide to the rail slots, and press it upward.
6Use screws to secure the product and the Box Guide as shown below.
PC100 In/Out Cable Connection
1 Connect the appropriate power cables to a monitor and PC100 respectively.
Connecting a Monitor with D-sub Cable
Attention
Audio is not available when only the D-SUB cable is connected to the monitor. A LINE-OUT cable
must be connected for audio output to function.
D-sub cables are also known as RGB cables.
Note
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
2 Connect the D-sub port of PC100 and RGB-IN port of the monitor with a D-sub cable.
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP

6
3Connect PC100 (OUT) to the monitor (IN) with an RS-232C cable.
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
5Connect a LAN cable to the PC100.
4Connect the PC100 to the monitor with a LINE-OUT cable.
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP

7
PC100
3Connect PC100 (OUT) to the monitor (IN) with an RS-232C cable.
5Connect a LAN cable to the PC100.
4Connect the PC100 to the monitor with a LINE-OUT cable.
2Connect PC100 to a monitor with an HDMI cable.
1 Connect the appropriate power cables to a monitor and PC100 respectively.
Connecting a Monitor with an HDMI Cable
● The monitor to connect with PC100 should have the HDMI in for the HDMI connection.
● To use the HDMI device, you need to activate the HDMI device in Microsoft Windows Embedded
Standard, the operating system of the PC100. To connect and disconnect the HDMI audio
device, see the Connecting/Disconnecting HDMI Audio Device in Windows section of this
document.
HDMI connections allow digital video and audio signals to be transferred with one cable.
HDMI cable connections do not require an additional audio in cable.
Attention
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
DP
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
DP
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
DP
DP

8
4Connect a LAN cable to PC100.
3Connect PC100 (OUT) to the monitor (IN) with an RS-232C cable.
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
1 Connect the appropriate power cables to a monitor and PC100 respectively.
2Connect PC100 to the monitor via a DP cable.

9
PC100
4Connect a LAN cable to PC100.
3Connect PC100 (OUT) to the monitor (IN) with an RS-232C cable.
Connecting a Monitor with DP Cable
● To enable DP connection, the monitor that will be connected to PC100 must support the DP
input port.
● When connecting the DP (DisplayPort) cable, use the standard cable. Using a non-standard
cable may cause a malfunction.
Attention
1 Connect the appropriate power cables to a monitor and PC100 respectively.
2Connect PC100 to the monitor via a DP cable.
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
DP
DP

10
3Connect PC100 (OUT) to the monitor (IN) with an RS-232C cable.
4Connect the PC100 to the monitor with a LINE-OUT cable.
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
5Connect a LAN cable to PC100.
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP
MIC IN
P/W
DP

11
PC200
3Connect PC100 (OUT) to the monitor (IN) with an RS-232C cable.
4Connect the PC100 to the monitor with a LINE-OUT cable.
5Connect a LAN cable to PC100.
Please check that these components are present prior to installing.
PC200 Components
Weight ● The specifications shown above may change
without prior notice for quality improvement.
0.288 kg
PC200
Owner’s Manual/Cards
screw x 2
●SuperSign software and manual.
- Downloading from the LG Electronics website.
- Visit the LG Electronics website (http://www.lgecommercial.com/supersign) and download the
latest software for your model.
(Depending on the model, this feature may not be supported.)
Note

12
PC200 Monitor Integration
If card does not become fully inserted into the insertion direction.
Hit by hand carefully to make fully connected.
Note
1Remove the screw & metal cover.
2Attach the product to the rail slots, and press it upward.
3Use screws to secure the product and the product as shown below.

13
PC700
1Remove the screw & metal cover.
2Attach the product to the rail slots, and press it upward.
3Use screws to secure the product and the product as shown below.
PC700 Components
Weight ● The specifications shown above may change
without prior notice for quality improvement.
SSD 2.3kg / 1T HDD 2.4kg
The PC700 comes with the following components. Please check that these components have been
included prior to installation.
The following items are supported by the PC700, but are not provided with the product.
Please purchase optional items as needed.
● DP(Display Port) cable, LINE-OUT(Audio Out) cable, LAN cable, mouse, keyboard.
● These illustrations may differ from your product and are subject to change.
● In some countries, a Y-type cable may be provided instead of the power cord.
● Always use genuine components to ensure safety and product life. Any damages or injuries by
misuse or using an improper accessory are not covered by the warranty.
Attention
Optional Items
M 3.0 mm x Pitch 0.5 mm
x Length 6.0 mm X 4ea
PC700
Power Cable
Owner’s Manual / Cards
●SuperSign software and manual.
- Downloading from the LG Electronics website.
- Visit the LG Electronics website (http://www.lgecommercial.com/supersign) and download the
latest software for your model.
(Depending on the model, this feature may not be supported.)
Note

14
We recommend you to use the items provided with your PC700 and follow our instructions for inte-
grating the product with your monitor in order to ensure the correct results.
The illustrations shown are to guide your integration and may differ from your product.
1
Place a soft cloth on the table and put the
product on the table with the screen facing
downward. Push the PC700 into the compart-
ment to mount it.
2
Secure the PC700 to the set using the four
screws provided.
PC700 Monitor Integration
**WS50, **LT55A Models
● Be careful of sharp edges on the rail and
the handle.
● Attaching the product with non-standard
screws may cause damage or the product
to fall down. LG Electronics is not liable
for any accidents relating to the use of
non-standard screws.
● Do not over tighten the screws as this
may cause damage to the product and
void your warranty.
Attention
Attention

15
PC700
2
Secure the PC700 to the set using the four
screws provided.
PC700 Monitor Integration
For proper use, it is recommended to use the basic components provided with the PC700 to attach it to a
monitor.
The picture shows an example connection and may look different to the product that you have.
2
Push the PC700 into the compartment to
mount it.
3
Secure the PC700 to the product using the
two screws provided.
**WX50MF Model
Attention
● Be careful of sharp edges on the rail
and the handle.
● Attaching the product with non-stand-
ard screws may cause damage or the
product to fall down. LG Electronics is
not liable for any accidents relating to
the use of non-standard screws.
● Do not over tighten the screws as this
may cause damage to the product and
void your warranty.
Attention
1
Place a soft cloth on the table and put the
product on the table with the screen facing
downward. Remove the opening cover by un-
fastening two screws as shown in the picture.

16
For proper use, it is recommended to use the basic components provided with the PC700 to attach it to a
monitor.
The picture shows an example connection and may look different to the product that you have.
2
Push the PC700 into the compartment at the
back of the set to mount it.
3
Secure the PC700 to the set using the four
screws provided.
84WS70MS Model
Attention
● Be careful of sharp edges on the rail and
the handle.
● Attaching the product with non-standard
screws may cause damage or the
product to fall down. LG Electronics is
not liable for any accidents relating to
the use of non-standard screws.
● Do not over tighten the screws as this
may cause damage to the product and
void your warranty.
Attention
1
Place a soft cloth on the table and put the
product on the table with the screen facing
downward.Remove the handle at the bottom
of the section where the PC700 is mounted
from the set.

17
PC700
3
Secure the PC700 to the set using the four
screws provided.
● RGB, DP(Display Port), LINE-OUT(Audio Out), and LAN cables are not included. You need to
purchase these separately, if needed.
● After cabling is complete, assign the SET ID of the monitor to be connected to PC700.
● To configure the SET ID, please refer to the owner’s manual for your monitor.
Attention
2Connect PC700 to a monitor with an RGB cable.
1 Connect the appropriate power cables to a monitor and PC700 respectively.
Connecting a Monitor with an RGB Cable
PC700 In/Out Cable Connection

18
4Connect PC700 (OUT) to the monitor (IN) with an RS-232C cable.
3Connect the PC700 to the monitor with a LINE-OUT(Audio Out) cable.
AUDIO
IN
AUDIO
IN
AUDIO
IN

19
PC700
4Connect PC700 (OUT) to the monitor (IN) with an RS-232C cable.
3Connect the PC700 to the monitor with a LINE-OUT(Audio Out) cable. 5Connect a LAN cable to PC700.

20
Connecting a Monitor with DP(Display Port) Cable
2Connect
PC700 to the monitor via a DP cable.
1Connect the appropriate power cables to a monitor and PC700 respectively.
3Connect
PC700 to the monitor (IN) with an RS-232C cable.
