LG LG-R105 User manual

User Guide
360 CAM
LG-R105
ENGLISH ESPAÑOL
MFL69583301 (1.0) G

ENGLISH
WARNING: This product contains chemicals
known to the State of California to cause cancer
and birth defects or reproductive harm.
Call [phone] for more information.
Wash hands after handling.
Note: Please read all information carefully prior to
using the LG 360 CAM in order to enjoy the best
performance and prevent damage to the product.
User Guide
360 CAM
LG-R105

2
Contents
© 2016 LG Electronics Inc. ALL RIGHTS RESERVED. LG, LG Life’s Good, and the LG logo are
registered trademarks of LG Corp. All other trademarks and trade names are property of
their respective owners. Design, features, functionality, and other product specications are
subject to change without notice.
Open Source Software Notice Information
To obtain the source code under GPL, LGPL, MPL, and other open source licenses, that is
contained in this product, please visit http://opensource.lge.com. In addition to the source
code, all referred license terms, warranty disclaimers, and copyright notices are available for
download. LG Electronics will also provide open source code to you on CD-ROM for a charge
covering the cost of performing such distribution (such as the cost of media, shipping, and
handling) upon email request to opensour[email protected]om. This offer is valid for three (3) years
from the date on which you purchased the product.
Product Overview..........................................................................................................................................................................3
Important Safety Information................................................................................................................................................4
Product Components..................................................................................................................................................................8
Product Description.....................................................................................................................................................................9
Connections..................................................................................................................................................................................12
Features and Usage ..................................................................................................................................................................13
Specications and Features..................................................................................................................................................16
Limited Warranty Satement.................................................................................................................................................17

3
The LG 360 CAM is a smart device that allows you to easily take high-quality photos and
videos with dynamic audio.
• Take 16-megapixel spherical photos or record QHD videos using dual cameras.
• Record 5.1-channel surround sound using three microphones.
• Using the LG 360 VR product (sold separately), you can view your vivid photos and videos,
as well as enjoy a more realistic sound environment.
Trademarks
• Bluetooth® is a registered trademark of Bluetooth SIG, Inc. worldwide.
• Wi-Fi® and the Wi-Fi logo are registered trademarks of the Wi-Fi Alliance.
Product Overview
This wireless device may cause electromagnetic interference. To prevent possible
interference with sensitive medical equipment, turn off the device when requested to do so
in hospitals, clinics, or healthcare facilities.

4
• Always use genuine products. Do not use this product for any unintended purpose.
• Using or connecting products that are not genuine may shorten the product’s longevity or
cause an explosion. Doing so may also damage the product and thereby void the service
warranty.
• Do not disassemble the product or allow anything to impact it. Doing so may cause an
electrical shock, short-circuit, or re.
• Applying heavy pressure to the product may damage it.
• Some functions of this product may be damaged, or its appearance may be altered or
impaired, if it is bent or crushed and not repaired right away.
• In order to prevent damage, be careful not to drop the product on a hard surface or
subject it to severe shock.
• Keep the product away from water, alcohol, benzene, etc.
• Use the product at temperatures between 32°F and 95°F (0°C and 35°C). Do not use, or
store the product, in extreme temperatures. Do not leave the product in direct sunlight
for long periods of time. Doing so may cause damage or an explosion.
• Use a soft cloth to wipe the product.
• Do not place the product near metal objects such as necklaces, keys, coins, nails, or clocks.
In the case of a short-circuit, there is also the risk of an explosion.
• Keep the product out of the reach of small children and pets. Do not put the product in
your mouth or subject it to severe shock. There is a risk of electric shock, an explosion,
or suffocation.
• Do not connect or insert conductive materials (metal pieces, pencil leads, etc.) into the
connectors.
• Do not cover or wrap the product with a blanket while using the product.
Important Safety Information

5
• The product may become hot after long periods of use. Avoid touching the product when
it becomes hot as it may cause a low-temperature burn.
• When shooting video for a long period of time, the camera may become hot. To prevent
damage from high temperatures, the camera may stop operating.
• Do not dispose of the product as household waste. Doing so may cause a re or damage
the environment.
Part 15.19 Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
Part 15.21 Statement
Changes or modications not expressly approved by the manufacturer (or party responsible)
for compliance could void the user’s authority to operate the equipment.

6
Part 15.105 Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
- Consult the dealer or an experienced radio/TV technician for help.

7
Consumer Information on SAR (Specic Absorption Rate)
This model device meets the government’s requirements for exposure to radio waves.
Your wireless device is a radio transmitter and receiver. It is designed and manufactured
not to exceed the emission limits for exposure to Radio Frequency (RF) energy set by
the Federal Communications Commission of the U.S. Government. These limits are part
of comprehensive guidelines and establish permitted levels of RF energy for the general
population. The guidelines are based on standards that were developed by independent
scientic organizations through periodic and thorough evaluation of scientic studies.
The standards include a substantial safety margin designed to assure the safety of all
persons, regardless of age and health. The exposure standard for wireless mobile devices
employs a unit of measurement known as the Specic Absorption Rate, or SAR. The SAR
limit set by the FCC is 1.6 W/kg. Tests for SAR are conducted using standard operating
positions specied by the FCC with the device transmitting at its highest certied power
level in all tested frequency bands. Although SAR is determined at the highest certied
power level, the actual SAR level of the device while operating can be well below the
maximum value. Because the device is designed to operate at multiple power levels to use
only the power required to reach the network, in general, the closer you are to a wireless
base station antenna, the lower the power output. Before a device model is available for
sale to the public, it must be tested and certied to the FCC that it does not exceed the
limit established by the government-adopted requirement for safe exposure. The tests are
performed in positions and locations as required by the FCC for each model. The highest SAR
value for this device on the body, as described in this user guide, is 1.3 W/kg. While there
may be differences between SAR levels of various devices and at various positions, they all
meet the government requirement for safe exposure.

8
Product Components
• If there are any missing components, contact the retailer where you purchased the
product.
• Some items are subject to change without prior notice depending on the circumstances.
• The appearance and specications of the product are subject to change without prior
notice in order to improve performance.
LG 360 CAM USB CableCap User Guide

9
Product Description
Accessory
Connection
microSD™
Card Slot
Charger/
USB Port
Dual
Camera
Lens
Mode LEDs
Power Button
Power LED
Cap Knob
Shutter
LED
Shutter
Button

10
Using the Buttons
Power on Press and hold the Power Button (1 second).
Power off Press and hold the Power Button (4 seconds or longer).
Take a photo Press the Shutter Button.
Record a video Press and hold the Shutter Button (1 second).
Stop a recording Press the Shutter Button .
Enter Sleep mode Press and hold the Power Button (1 second).
Exit Sleep mode Press the Power Button or Shutter Button.
Forced shutdown Press and hold the Power Button (12 seconds or longer).
How to Reset the Device
Simultaneously press and hold the Power Button and the Shutter Button for 8 seconds.
Release the buttons after you hear the second beep, and then press the Power Button
within 4 seconds to reset the device.
• You can take photos and record videos only when an external SD card has been inserted.

11
Battery Charging and Alerts
The Power LED indicates the battery level.
Power LED
(with the cable disconnected) Green Red Red blinking
Battery Status More than 15% 5% ~ 15% Less than 5%
Open the bottom cover of the product and connect the charger to the USB port.
Power LED
(with the cable connected) Red Green
Battery Status Charging Completed

12
Connections
Connect a Device
1. Turn on your LG 360 CAM.
2. Launch the 360 CAM manager app on your phone.
3. Your LG 360 CAM and the manager app will automatically connect.
4. Your LG 360 CAM is now ready to use.
Notes
• Connecting your phone to the LG 360 CAM will turn off the Wi-Fi connection on your
phone.
• The 360 CAM manager app can be downloaded from Google Play™ Store on Android™
phones and from App Store® on an iPhone® by searching for “LG 360 CAM”.
(Supported on Android 5.0 (Lollipop OS) or later and iOS™ 8 or later.)
• The PC software can be downloaded from the LGElectronics website (http://www.lge.
com). (Supported on Windows® 7 or later and iMac® 10.10 or later.)
• When the manager app asks for a Bluetooth connection and location permissions, you
must allow the permissions before using the app.
• When launching the manager app for the rst time, you must agree to the terms and
conditions before using the app.
• The LG 360 CAM can be connected to only one phone at a time. To connect it to another
phone, rst disconnect it from the phone it is currently connected to.
• If your LG 360 CAM is password protected, enter the password to connect it.
• The default Wi-Fi password is “00” plus the last six digits of your product’s serial number.
• To reset the Wi-Fi connection, simultaneously press and hold the Power Button and the
Shutter Button for 3 seconds until you hear a beep.
• Turn on or off the device’s Wi-Fi by pressing the Power Button and the Shutter Button
twice.
• Bluetooth® is used for pairing, and Wi-Fi is used for Preview and data transfers.

13
Taking Photos and Recording Videos
• Shooting without a Connected Device
Press the Shutter Button on your LG 360 CAM to take photos or record videos.
(See Using the Buttons on page 10.)
LED mode Top LED on Bottom LED on
Shooting Mode 360° 180°
• Shooting with a Connected Device
Tap on the 360 CAM app home screen.
Features and Usage
❶
Select the image quality.
❷
Select the shooting environment.
❸
Select the camera direction.
❹
Select a Shooting mode (360°/180°).
❺
Set Normal or Manual mode.
❻
Go to the previous menu.
❼
Take a photo.
❽
Record a video.
❾
View a preview.
❶
❻
❷
❼
❸
❽
❹
❾
❺

14
Gallery
Tap on the 360 CAM app home screen.
❶
Go to the previous menu.
❷
Open the camera.
❸
Download the les from your LG 360 CAM to
your phone.
❹
Share your les.
❺
Delete any unwanted les.
❻
Spherical image icon
❼
Video play icon
❽
Access the le list on your LG 360 CAM.
❾
Access the le list on your phone.
• Avoid touching or removing the external SD card while the camera is operating or
transferring data.
• Up to 4 GB are available for each video recording.
• Video editing and message attachment may not be available on some phones.
❶❷
❻
❼
❽ ❾
❸ ❹ ❺

15
Settings
Tap the on the 360 CAM app home screen.
Wi-Fi
This allows you to set a Wi-Fi password.
Sound
Press this button to mute/unmute your LG 360 CAM.
Storage
This allows you to check or format a storage space.
Battery
This displays the battery level of your LG 360 CAM.
Power Saving Mode
This allows you to set the time before your LG 360 CAM enters Power Saving mode.
About LG 360 CAM
This displays software updates, device information, and the Terms of Service for your
LG 360 CAM.
Help
Press the button for help.

16
Bluetooth Specication V4.1
Wi-Fi Specication 802.11 b/g/n
USB Type
Type-C™ USB 2.0
Battery 1200 mAh
Charging time 120 minutes
Optics 13 M, 206° x 2 (Dual Fisheye Lens)
Max. Video Resolution 2560 x 1280 (30 fps)
Max. Photo Resolution 5660 x 2830 (16 M)
Video File Format
Still Image: JPEG
Video: MP4 (MPEG-4 AVC/H.264, Audio: AAC 5.1 Ch)
Capturing Spherical/Half-spherical image and video
Sound 3 Microphones
External SD Card Up to 2 TB
Dimensions/Weight
1.6" x 3.8" x 1" / 2.7 oz
It is recommended to use a UHS-1 (U3) read/write 10 MB or higher SD memory card (class
10 or higher).
The LG 360 CAM supports Google Street View™ and YouTube™ 360° services.
SpecicationsandFeatures
works with

17
Limited Warranty Satement
1. WHAT THIS WARRANTY COVERS:
LG offers you a limited warranty that the enclosed unit and its enclosed accessories will be free from defects in
material and workmanship, according to the following terms and conditions:
(1) The limited warranty for the product extends for TWELVE (12) MONTHS beginning on the date of purchase of
the product with valid proof of purchase, or absent valid proof of purchase, FIFTEEN (15) MONTHS from date
of manufacture as determined by the unit’s manufacture date code.
(2) The limited warranty extends only to the original purchaser of the product and is not assignable or
transferable to any subsequent purchaser/end user.
(3) This warranty is good only to the original purchaser of the product during the warranty period as long as it is
in the U.S, including Alaska, Hawaii, U.S. Territories, and Canada.
(4) The external housing and cosmetic parts shall be free of defects at the time of shipment and; therefore, shall
not be covered under these limited warranty terms.
(5) Upon request from LG, the consumer must provide information to reasonably prove the date of purchase.
(6) The customer shall bear the cost of shipping the product to the Customer Service Department of LG. LG
shall bear the cost of shipping the product back to the consumer after the completion of service under this
limited warranty.
2. WHAT THIS WARRANTY DOES NOT COVER:
(1) Defects or damages resulting from use of the product in other than its normal and customary manner.
(2) Defects or damages from abnormal use, abnormal conditions, improper storage, exposure to moisture or
dampness, unauthorized modications, unauthorized connections, unauthorized repair, misuse, neglect, abuse,
accident, alteration, improper installation, or other acts which are not the fault of LG, including damage caused
by shipping, blown fuses, spills of food, or liquid.
(3) Breakage or damage to antennas unless caused directly by defects in material or workmanship.
(4) Alleged product defects or malfunction of which the Customer Service Department at LG was not not notied
by consumer during the applicable limited warranty period.
(5) Products which have had the serial number removed or made illegible.
(6) This limited warranty is in lieu of all other warranties, express or implied either in fact or by operations of
law, statutory or otherwise, including, but not limited to any implied warranty of marketability or tness for
a particular use.

18
(7) Damage resulting from use of non-LG approved accessories.
(8) All plastic surfaces and all other externally exposed parts that are scratched or damaged due to normal
customer use.
(9) Products operated outside published maximum ratings.
(10) Products used or obtained in a rental program.
(11) Consumables (such as fuses).
3. STATE LAW RIGHTS:
No other express warranty is applicable to this product. THE DURATION OF ANY IMPLIED WARRANTIES,
INCLUDING THE IMPLIED WARRANTY OF MARKETABILITY OR MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE, IS LIMITED TO THE DURATION OF THE EXPRESS WARRANTY HEREIN. LG SHALL NOT
BE LIABLE FOR THE LOSS OF THE USE OF THE PRODUCT, INCONVENIENCE, LOSS OR ANY OTHER DAMAGES,
DIRECT OR CONSEQUENTIAL, ARISING OUT OF THE USE OF, OR INABILITY TO USE, THIS PRODUCT OR FOR ANY
BREACH OF ANY EXPRESS OR IMPLIED WARRANTY, INCLUDING THE IMPLIED WARRANTY OF MARKETABILITY
OR MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE APPLICABLE TO THIS PRODUCT.
Some states do not allow the exclusive limitation of incidental or consequential damages or limitations on how
long an implied warranty lasts; so these limitations or exclusions may not apply to you. This warranty gives you
specic legal rights and you may also have other rights which vary from state to state.
4. HOW TO GET WARRANTY SERVICE:
To obtain warranty service, please call or fax to the following telephone numbers from anywhere in the
continental United States:
Tel. [phone] or Fax. [phone]
Or visit http://www.lg.com/us/support. Correspondence may also be mailed to:
LG Electronics Service–Mobile Handsets
P.O. Box 240007, Huntsville, AL 35824
DO NOT RETURN YOUR PRODUCT TO THE ABOVE ADDRESS.
Please call or write for the location of the LG authorized service center nearest you and for the procedures for
obtaining warranty claims.
