LDT7808_
Top Control wi- Enabled Dishwasher with
QuadWash™ and TrueSteam®
PRODUCT FEATURES
10 Wash Cycles
QuadWash™
TrueSteam®
SmartThinQ® Technology with wi-
LoDecibel™ Quiet Operation (42 dBA)
Inverter Direct Drive™ Technology
EasyRack™ Plus System
Height Adjustable 3rd Rack
Smooth Operating Racks
LED Tub Light
ENERGY STAR® Qualied
Tub Material - NeveRust™ Stainless Steel
KEY FEATURES
CAPACITY
Total Place Settings 15
Upper Rack Dish Height Limit 7.1"
Lower Rack Dish Height Limit 12.5"
RACKS AND BASKETS
EasyRack™ Plus System Yes
Cutlery Baskets Yes
Cup Rack Yes
Stemware Holder Yes
Fold Down Tines Yes (Full Fold on Upper & Full Fold on Lower)
BPA-Free Nylon Coated Racks and Tines Yes
Rack Handle Yes (Upper) Yes (Lower)
Glide Rail (Upper Rack) Yes
Wheel Bearing (Lower Rack) Yes
Height Adjustable Upper Rack Yes
Height-Adjustable 3rd Rack Yes
STYLE AND DESIGN
Control Panel Location Top Control
Electronic Controls Fully Integrated Control Panel
SignaLight™ Cycle Indicator Lights 3
Time Remaining Indicator Yes (LED)
Tub Material NeveRust™ Stainless Steel
Tub Light Yes
Handle Bar Handle
All Available Colors Matte Black Stainless Steel, Black Stainless Steel,
Stainless Steel
Fingerprint Resistant Yes (only LDT7808BM & LDT7808BD)
FEATURES
TrueSteam® Yes
QuadWash™ Yes
Inverter Direct Drive Motor Yes
LoDecibel™ Quiet Operation 42 dBA
Number of Wash Cycles 10 (Auto, Heavy, Delicate, Refresh, Normal, Turbo,
Download Cycle, Machine Clean, Rinse, Express)
Number of Options 9 (Dual Zone, Half Load, Energy Saver, Steam, High
Temp, Extra Dry, Delay Start, Control Lock, Night Dry)
Number of Spray Arms 3 (Top, Upper, Lower)
SenseClean™ Wash System Yes
Vario Wash Yes
Detergent and Rinse-Aid Dispenser Yes
Hybrid Condensing Drying System Yes
End of Cycle Indicator Yes (Beeper + END indication on display)
Hidden Water Heater Yes
Safety Float Switch (Leaks) Yes
Soil (Turbidity) Sensor Yes
Tub Insulation (Damping Sheet, Sound Absorbing
Material (felt), Base)
Yes
BPA-Free Nylon Coated Racks and Tines Yes
Anti-Bacterial Treatment (Sump, Inner / Outer filter,
Drain pump case, Drain hose)
Yes
Balanced Door Yes
3-Stage Filtration System Yes
SmartThinQ® SMART FEATURES
wi-fi Enabled Yes
Voice Activation Yes
Works with Google Assistant and Amazon Alexa
SmartDiagnosis™ Yes
POWER RATINGS
ENERGY STAR® Qualified Yes
CEE Tier 1
Energy Use (kWh/Year) 258 kWh/Year
Water Factor (WF) 2.8
DIMENSIONS / CLEARANCES / WEIGHT
Product Dimensions (in) (W x H x D) 23 3/4" x 33 5/8" x 24 5/8"
Product Weight (lbs) 92.2 lbs
Depth with Door Closed with Handle (in) 26 7/8"
Depth with Door Open (in) 50 1/2"
Carton Dimensions (in) (W x H x D) 28" x 34 3/4" x 29 5/8"
Shipping Weight with Carton (lbs) 104.3 lbs
LIMITED WARRANTY
Labor 1 Year
Parts 1 Year
Control Board and Rack Parts 5 Years
Direct Drive Motor 10 Year s
Stainless Steel Door Liner or Tub Lifetime
UPC CODES
LDT7808BM (Matte Black Stainless Steel) 048231339926
LDT7808BD (Black Stainless Steel) 048231339919
LDT7808ST (Stainless Steel) 048231339803
SMART APPLIANCE
Enjoy new ways to control your
home with LG smart appliances
• Get notifications when dishes are clean
• Monitor the cycle time from your smartphone
• Works with the LG SmartThinQ®app

LDT7808_
Top Control wi- Enabled Dishwasher with
QuadWash™ and TrueSteam®
DIMENSIONS / CLEARANCES / WEIGHT
Product Dimensions (in) (W x H x D) 23 3/4" x 33 5/8" x 24 5/8"
Depth with Door Closed with Handle (in) 26 7/8"
Depth with Door Open (in) 50 1/2"
Carton Dimensions (in) (W x H x D) 28" x 34 3/4" x 29 5/8"
POWER RATINGS
ENERGY STAR® Qualified Yes
CEE Tier 1
Energy Use (kWh/Year) 258 kWh/Year
Water Factor (WF) 2.8
Water supply line
6 1/2" - 7 1/4"
Electrical cable
4 1/2" - 6"
•Make sure the house water supply is turned off before connecting
the dishwasher water lines.
•Connect the dishwasher to a hot water supply with a temperature range between
120 °F (49 °C) and 149 °F (65 °C). This temperature range provides the best
washing results and shortest cycle time. To prevent damage to dishes, the
temperature should not
exceed 149 °F (65 °C).
•When connecting the
dishwasher water
line, sealing tape or
compound should be
used on pipe threads
to avoid leaks. Tape or
compound should not
be used on compression
ttings.
•The water supply tube
must be located in the
left side channel.
•Operate this appliance with the correct voltage as shown in your User Manual and
on the rating plate. Connect it to a dedicated, properly grounded branch circuit
which is protected by a time delay fuse. Connect the appliance using 3-wires,
including a ground wire.
•If an outlet and other power connector are used, it should be in an accessible
location adjacent to
and not behind the
dishwasher and within
4 ft. of the dishwasher's
side.
•The wiring must be
grounded properly. If in
doubt, have it checked
by a qualied electrician.
Do not connect any other
appliance to the same
outlet.
•Route the wiring.
•Make sure the electrical
cable is oriented in the
right side channel.
LG DISHWASHERS
HOME APPLIANCES
QUICK INSTALL & CLEARANCES
For full installation directions/clearances please refer to
the corresponding User Manual and Installation Guide.
IMPORTANT
•This dishwasher is designed to t a standard dishwasher opening.
An opening may be needed on both sides to route plumbing and
electrical connections.
•Select a location as close to the sink as possible for easy connections to water and
drain lines.
•To ensure proper drainage,
install the dishwasher no more
than 12 ft. from the sink.
•If installing the dishwasher in a
corner, leave a minimum of 2"
between the dishwasher and
the adjacent wall.
•To allow for proper clearance
of plumbing and electrical, use
the template included with
the literature to determine
the clearance on the side of
the cabinet where the cabinet
meets the back wall. Using a 2
1/2" diameter hole saw, drill a
hole in the target area as shown
on the template.
▲
!WARNING
Don't use existing holes unless they are in the target area. Otherwise, the water
supply and drain hose may be damaged by being crushed or kinked.
▲
!CAUTION
Failure to properly locate the hole for the water and drain lines may prevent the
dishwasher from installing ush with the cabinets and could result in kinked or
damaged lines. Installation damage is not covered by the warranty, and leaks caused
by improper installation may result in property damage.
▲
!WARNING
•For personal safety, remove house fuse or open circuit breaker before installation.
•Do not use an extension cable or adapter with this dishwasher
•If you nd any damage to the dishwasher, contact your retailer or contractor.
NOTE
Use new hoses when connecting to the water supply. Do not reuse old hoses.
PREPARING WATER SUPPLY CONECTIONPREPARING ELECTRICAL WIRING
PREPARING CABINET OPENING
