LG DLGX8001W User manual

Life's Good
DR ER
Before beginning installation, read these instructions carefully_ This
will simplify installation and ensure that the dryer is instaDDed correctly
and safely_ Leave these instructions near the dryer after installation
for future references
DLEXSOOOW
DLEXSOOOV
DLGXSOOlW
DLGXSOO1V
P/No. : MFL62512869

2 TABLE OF CONTENTS
TABLE OF CONTENTS
.3 SPECIAL FEATURES
4IMPORTANT SAFETY INSTRUCTIONS
4
5
5
6
6
7
8
WHAT TO DO IF YOU SMELL GAS
BASIC SAFETY PRECAUTIONS
CALIFORNIA SAFE DRINKING WATER AND TOXIC
ENFORCEMENT ACT
GROUNDING INSTRUCTIONS
SAFETY INSTRUCTIONS FOR INSTALLATION
SAFETY INSTRUCTIONS FOR STEAM FUNCTIONS
SAFETY INSTRUCTIONS FOR CONNECTING
ELECTRICITY
9 INTRODUCING YOUR DRYER
9 Parts
9 Accessories
10 Control panel features
11 Time and status display
12 INSTALLATION INSTRUCTIONS
12 Installation steps
13 Installation location requirements
13 Clearances
15 Installation with optional pedestal base or stacking
kit
16 Leveling the dryer
17 To remove the door
18 To install the door
19 Changing the dryer vent location
20 Venting requirement
22 Connecting gas dryers
24 Connecting electric dryers
29 Special requirements for manufactured or mobile
homes
29 Final installation check
30 Installation test (Exhaust check)
32 HOWTO USE
32 Operating the dryer
33 Cycle guide
34 Sorting load
34 Loading the dryer
34 Check the lint filter before every load
35 Cycle setting buttons
36 Special functions
37 Custom program
37 Steam functions
39 Steam cycle guide
40 MAINTENANCE
40 Regular cleaning
41 TROUBLESHOOTING
41 Before calling for service
43
44
45
45
47
SPECIFICATIONS
USING SMARTDIAGNOSIS TM
OPTIONAL ACCESSORIES
Stacking kit installation
WARRANTY

SPECIAL FEATL/RES 3
SPECIAL FEATURES
The ultra-large stainless steel drum offers superior durability.
The wide-opening door provides easy access for loading and unloading. The door hinge can be reversed to adjust for installation location.
LG's steam technology allows you to inject fabrics with a swirling jet of hot steam to refresh clothes, reduce static, simplify ironing and
assist in the removal of lightly stained spots. Simply select the STEAM FRESHTM or SpotClean TM cycle, oryou can add a Steam option to
select cycles.
Should you experience any technical difficulty with your dryer, it has the capability of transmitting data via your telephone to the
Customer Information Center.The call center agent records the data transmitted from your machine and uses it to analyze the issue,
providing a fast and effective diagnosis.
The FLOW SENSETM duct blockage sensing system detects and alerts you to blockages in the ductwork that reduce exhaust flow from the
dryer. Clean exhaust systems increase efficiency and reduce drying times.
Rotate the cycle selector knob to select the desired dry cycle. Add cycle options or adjust settings with the touch of a button.
Protocol P154
Sanitization Performance of
Residential Clothes dryer

4IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
AWARNING
For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent
property damage, injury to persons, or death.
Your Safety and the safety of others it is very important.
/Vehaveprovided many important safety messages in this manual and on your appliance. Always read and obey all safety messages.
This isthe safety alert symbol.
This symbol alerts you to potential hazardsthat can kill or hurt you and others.
All safety messageswill follow the safety alert symbol and either the word DANGER,WARNINGor CAUTION.
These words mean:
ADANGER
You will be killed or seriously injured if you don't immediately follow instructions.
AWARNING
You can be killed or seriously injured if you don't follow instructions.
ACAUTION
You may be slightly injured or cause damage to the product if you do not follow instructions.
All safety messages will tell you what the potential hazard is,tell you how to reduce the chance of injury, and tell you what can happen if
the instructions are not followed.
• Do not install a clothes dryer with flexible plastic venting materials. If flexible metal (foil type) duct isinstalled, it must be of
aspecific type identified by the appliance manufacturer as suitable for usewith clothes dryers. Flexible venting materials are
known to collapse, be easily crushed, and trap lint. These conditions will obstruct clothes dryer airflow and increase the risk of
fire.
• Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this appliance or any other appliances.
• Installation and service must be performed by a qualified installer, service agency, or the gassupplier.
• Install the clothes dryer according to the manufacturer's instructions and local codes.
• Save these instructions.
WHAT TO DO iF YOU SMELL GAS:
1.Do not try to light a match or cigarette, or turn on any gas or electrical appliance.
2. Do not touch any electrical switches. Do not use any phone in your building.
3. Clear the room, building, or area of all occupants.
4. Immediately call your gas supplier from a neighbor's phone. Follow the gassupplier's instructions carefully.
S.If you cannot reach your gas supplier, call the fire department.

IMPORTANT SAFETY INSTRUCTIONS 5
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
AWARNING
For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent
property damage, injury to persons, or death.
BASIC SAFETY PRECAUTIONS
AWARNING
To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions, including the following:
, Read all instructions before using the dryer.
, Before use, the dryer must be properly installed as described in
this manual.
.Do not place items exposed to cooking oilsin your dryer.Items
contaminated with cooking oils may contribute to a chemical
reaction that could cause a load to catch fire.
, Do not dry articles that have been previously cleaned in,washed
in, soaked in, or spotted with gasoline, dry-cleaning solvents, or
other flammable or explosive substances as they give off vapors
that could ignite or explode.
.Donot reach into the dryer if the drum or any other part is
moving.
.Do not repair or replace any part of the dryer or attempt any
servicing unless specifically recommended in this Use and Manual
or in published user-repair instructions that you understand and
have the skills to carry out.
.Do not tamper with controls.
.Before the dryer is removed from service or discarded, remove the
door to the drying compartment.
,Do not allow children to play on or in the dryer. Close supervision
of children is necessary when the dryer is used near children.
.Do not use fabric softeners or products to eliminate static unless
recommended by the manufacturer of the fabric softener or
product.
.Donot use heat to dry articles containing foam rubber or
similarly textured rubber-like materials.
, Keep area around the exhaust opening and adjacent surrounding
areas free from the accumulation of lint, dust, and dirt.
,The interior of the dryer and exhaust vent should be cleaned
periodically by qualified service personnel.
,Do not install or store the dryer where it will be exposed to the
weather.
.Always check the inside of the dryer for foreign objects.
, Clean lint screen before or after each load.
.Do not store plastic, paper, or clothing that may burn or melt
on top of the dryer during operation.
CALIFORNIA SAFE DRINKING WATER AND TOXIC ENFORCEMENT ACT
This act requires the governor of California to publish a list of substances known to the state to cause cancer, birth defects, or other
reproductive harm and requires businesses to warn customers of potential exposure to such substances.
Gas appliances can cause minor exposure to four of these substances, namely benzene, carbon monoxide, formaldehyde, and soot, caused
primarily by the incomplete combustion of natural gas or LP fuels.
Properly adjusted dryers will minimize incomplete combustion. Exposure to these substances can be minimized further by properly
venting the dryer to the outdoors.

6 IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
AWARNING
For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent
property damage, injury to persons, or death.
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of malfunction
or breakdown, grounding will reduce the risk of electric shock
by providing a path of least resistance for electric current. This
appliance must be equipped with a cord having an equipment-
grounding conductor and a grounding plug. The plug must be
plugged into an appropriate outlet that is properly installed and
grounded in accordance with all local codes and ordinances.
Do not modify the plug provided with the appliance. If it will not fit
the outlet, have a proper outlet installed by a qualified electrician.
This appliance must be connected to a grounded metal, permanent
wiring system or an equipment-grounding conductor must be
run with the circuit conductors and connected to the equipment-
grounding terminal or lead on the appliance.
Electric shock can result if the dryer is not properly grounded.
AWARNING
Improper connection of the equipment-grounding conductor can result in a risk of electric shock. Check with a qualified electrician or
service person if you are in doubt that the appliance is properly grounded.
SAFETY INSTRUCTIONS FOR INSTALLATION
AWARNING
To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions, including the following:
. Properly ground dryer to conform with all governing codes
and ordinances. Follow details in the installation instructions.
Electric shock can result if the dryer is not properly grounded.
. Before use, the dryer must be properly installed as described
in this manual. Electric shock can result if the dryer is not properly
grounded.
.Install and store the dryer where it will not be exposed to
temperatures below freezing or exposed to the weather.
. All repairs and servicing must be performed by an authorized
servicer unless specifically recommended in this Owner's
Manual. Use only authorized factory parts. Failure to follow this
warning can cause serious injury, fire,electric shock, or death.
. To reduce the risk of electric shock, do not install the dryer in
humid spaces. Failureto follow this warning can causeserious
injury, fire, electric shock, or death.
. Connect to aproperly rated, protected, and sized power
circuit to avoid electrical overload. Improper power circuit can
melt, creating electric shock and/or fire hazard.
. Remove all packing items and dispose of all shipping
materials properly. Failureto do so can result in death, explosion,
fire, or burns.
. Place dryer at least 18 inches above the floor for agarage
installation. Failureto do so can result in death, explosion, fire, or
burns.
. Keep all packaging from children. Packaging material can be
dangerous for children. There isa riskof suffocation.
. Do not install near another source of heat suchas astove,
cooking oven. Failure to do socan cause deform, smoke and fire.
. Do not place candles, smoking materials, or other flammables
on top of the product. Dripping wax, smoke, or fire can result.
. Remove all protective vinyl film from the product. Failure to do
socan causeproduct damage, smoke or fire.

IMPORTANT SAFETY INSTRUCTIONS 7
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
AWARNING
For your safety,the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent
property damage, injury to persons, or death.
SAFETY INSTRUCTIONS FOR INSTALLATION
AWARNING
Toreduce the risk of injury to persons, follow all industry recommended safety procedures including the use of long sleeved gloves and
safety glasses.Failureto follow all of the safetywarnings in this manual could result in property damage, injury to persons or death.
Exhaust/Ducting:
. Gas dryers MUST be exhausted to the outside. Failureto follow
these instructions can result in fire or death.
. The dryer exhaust system must be exhausted to the outside of
the dwelling. If the dryer isnot exhausted outdoors, some fine
lint and large amounts of moisture will be expelled into the
laundry area. An accumulation of lint in any area of the home can
create ahealth and fire hazard.
. Useonly rigid metal or flexible metal 4-inch diameter
ductwork inside the dryer cabinet or for exhausting to the
outside. Useof plastic or other combustible ductwork can
cause a fire. Punctured ductwork can cause afire if it collapses or
becomes otherwise restricted in useor during installation.
. Ductwork isnot provided with the dryer, and you should
obtain the necessary ductwork locally. The end cap should
have hinged dampers to prevent backdraft when the dryer is
not in use. Failureto follow these instructions can result in fire or
death.
. The exhaust duct must be 4 inches (10.2 cm) in diameter with
no obstructions. The exhaust duct should be kept as short as
possible. Make sure to clean any old ducts before installing
your new dryer. Failure to follow these instructions can result in
fire or death.
. Rigid or semi-rigid metal ducting is recommended for use
between the dryer and the wall. In special installations
when it is impossible to make aconnection with the above
recommendations, a UL-listed flexible metal transition duct
may be used between the dryer and wall connection only.
The useof this ducting will affect drying time. Failureto follow
these instructions can result in fire or death.
.DO NOT use sheet metal screwsor other fasteners which
extend into the duct that could catch lint and reduce the
efficiency of the exhaust system. Secureall joints with duct tape.
For complete details, follow the Installation Instructions. Failureto
follow these instructions can result in fire or death.
SAFETY INSTRUCTIONS FOR STEAM FUNCTIONS
AWARNING
Toreduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions, including the following:
. Do not open the dryer door during steam cycles. Failure to
follow these instructions can result in a burn hazard.
. Do not dry articles that have been previously cleaned in,
washed in, soaked in, or spotted with gasoline, dry-cleaning
solvents, or other flammable or explosive substances as they
give off vapors that could ignite or explode. Failureto follow
these instructions can result in fire or death.
. Do not fill the steam feeder with gasoline, dry-cleaning
solvents, or other flammable or explosive substances. Failure
to follow these instructions can result in fire or death.
. Do not touch the steam nozzle in the drum during or after the
steam cycle. Failure to follow these instructions can result in a
burn hazard.
.Do not fill the steam feeder with hot water (over 86 °F/30 °C).
Failureto follow these instructions can result in a burn hazard.

8 IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
AWARNING
For your safety, the information in this manual must be followed to minimize the risk of fire or ex
property damage, injury to persons, or death. _losion, electric shock, or to prevent
SAFETY INSTRUCTIONS FOR CONNECTING ELECTRICITY
AWARNING
To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions, including the following:
. Do not, under any circumstances, cut or remove the ground
prong from the power cord. To prevent injury to persons or
damage to the dryer, the electrical power cord must be plugged
into a properly grounded outlet.
. For personal safety, this dryer must be properly grounded.
Failure to do so can result in electric shock or injury.
. Refer to the installation instructions in this manual for specific
electrical requirements for your model. Failure to follow these
instructions can create an electric shock hazard and/or a fire
hazard.
. This dryer must be plugged into aproperly grounded outlet.
Electric shock can result if the dryer is not properly grounded.
Have the wall outlet and circuit checked by a qualified
electrician to make sure the outlet is properly grounded.
Failure to follow these instructions can create an electric shock
hazard and/or a fire hazard.
. The dryer should always be plugged into its own individual
electrical outlet which has a voltage rating that matches
the rating plate. This provides the best performance and also
prevents overloading house wiring circuits which could cause a
fire hazard from overheated wires.
. Never unplug your dryer by pulling on the power cord. Always
grip plug firmly and pull straight out from the outlet. The
power cord can be damaged, resulting in a risk of fire and electric
shock.
. Repair or replace immediately all power cords that have
become frayed or otherwise damaged. Do not usea cord that
shows cracks or abrasion damage along its length or at either
end. The power cord can melt, creating an electric shock and/or
fire hazard.
. When installing or moving the dryer, be careful not to pinch,
crush, or damage the power cord. This will prevent injury and
prevent damage to the dryer from fire and electric shock.
SAVE THESE INSTRUCTIONS

INTRODUCING YOUR DRYER
INTRODUCING YOUR DRYER
Parts
Control panel
Leveling feet
Reversible
door
Power Cord
Location
(Gas Models)
Gas
Connection
Location
(Gas Models)
Block
Access Panel
(Electric
Models)
Exhaust Duct
Outlet
Accessories
Included Accessories
Drying Rack
Optional Accessories
Pedestal Stacking Kit
(sold separately) (sold separately)
,--@NOTE .....
•Contact LG Customer Service at 1-800-243-0000 (1-888-542-2623 in Canada) if any accessories are missing.
•For your safety and for extended product life, use only authorized components. The manufacturer is not responsible for product I
malfunction or accidents caused by the use of separately purchased unauthorized components or parts. /
•The images in this Manual may be different from the actual components and accessories, and are subject to change by the manufacture!
without prior notice for product improvement purposes, i
.J

10 INTRODUCING YOUR DRYER
Control panel features
4BWARNING: To reduce the risk of fire, electric shock, or injury to persons, read this entire manual,
including the important Safety Instructions, before operating this dryer.
Cycle Selector Knob
COTTON/NORMAL
_ERM. PRESS "
HEAVY DUTY
TOWELS _ =
{;f}A
LED Display
Power Button Start/Pause Dry Level Temp. Time Dry Signal
Button Button Control Button Button
Button
Operation
Button Description
•POWER ON/OFF BUTTONN
- Press to turn the dryer ON or OFF. Pressing the POWER button during a cycle will cancel that cycle and any
settings will be lost.
COTTON/NORMAL .... _ JUMBO DRY
P_RM. PR SS D_I ICATES
CL<
ANTI BACTERIAL SUPER DRY
_/ ,_4 s ............................AIRDRY
•CYCLE SELECTOR KNOB
-Turn this knob to select the desired cycle. Once the desired cycle has been selected, the standard presets
will be shown in the display. On MANUAL DRY cycles, these settings can be adjusted using the cycle setting
buttons anytime before starting the cycle.
•START/PAUSE BUTTON
- Press this button to START the selected cycle. If the dryer isrunning, use this button to PAUSE the cycle
without losing the current settings.
NOTE :If you do not press the START/PAUSE button to resume a cycle within 4 minutes, the dryer turns off
automatically.
• MORE TIME/LESS TIME BUTTONS
-To adjust the drying time, use these buttons with MANUAL DRY, TIME DRY, and STEAM FRESH TM cycles, as
well as the REDUCE STATIC and EASY IRON options. Press the MORE TIME button to increase the selected
manual cycle time by a minute; press LESSTIME to decrease the cycle time by a minute.
•CYCLE SETTING BUTTONS
- Use these buttons to adjust the settings for the selected cycle.
*OPTION BUTTONS
-The OPTION buttons allow you to select additional cycle options. Not all settings are available for all cycles.
Refer to the CYCLE GUIDE section of the manual.
*STEAM FUNCTIONS
-LG%steam technology allows you to inject fabrics with a swirling jet of hot steam to refresh clothes, reduce
static, and make ironing easier. Simply select the STEAM FRESHTM cycle, or add a STEAM option to the
selected cycles.

INTRODUCINGYOURDRYEF_11
Time and status display
Time and status display shows the settings, estimated time remaining, options, and status
messages for your dryer. When the dryer is turned on, the light in the display will illuminate.
7
Button DescriJptJon
• ESTIMATED TIME REMAINING
-When the START/PAUSE button is pressed, the dryer will display the estimated (SENSOR DRY) or set time
(TIME DRY) remaining, and begin tumbling.
NOTE :The cycle time on SENSOR DRY cycles may fluctuate as the dryer recalculates drying time for optimal
results.
• CYCLE COMPLETION INDICATORWITN CHECK FILTER REMINDER
-This portion of the display shows which stage of the drying cycle iscurrently underway (CHECK FILTER,
DRYING, COOLING, or WRINKLE CARE).
• CHILD LOCK iNDICATOR
-When CHILD LOCK is set, the CHILD LOCK indicator will appear and all buttons are disabled except the
POWER button.This prevents children from changing settings while the dryer is operating.
• CHECK FILTER REMINDER
-The display will show CHECK FILTER when the dryer is turned on as a reminder to check the filter. It turns off
when the START/PAUSE button is pressed.
•CUSTOM PROGRAM
- Custom Program allows you to store a customized dry cycle for future use. It allows you to save favorite
temperature, dry level, and other options for a cycle, and then recall them at the touch of a button.
• FLOW SENSE TM DUCT BLOCKAGE SENSING SYSTEM INDICATOR
-The FLOW SENSETM duct blockage sensing system detects and alerts you to blockages in the ductwork that
reduce exhaust flow from the dryer.This improves operating efficiency and helps minimize service calls,
saving you money.

12 INSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONS
Insfallafion sfeps
Checking and choosing
the proper location Leveling the dryer Venting the Dryer
f 240V(USA)
Connecting Gas Dryers
(Gas Dryer Type)
Plugging in the power
cord and grounding
Exhaust check test
(Refer to page 30.) Test run

INSTALLATIONINSTRUCTIONS]3
Insfallafion Iocafion requiremenfs
AWARNING
Read all installation instructions completely before installing and operating your dryer! It is important that you review this entire
manual before installing and using your dryer. Detailed instructions concerning electrical connections, gas connections, and exhaust
requirements are provided on the following pages.
,A location that allows for proper exhaust installation. A
gas dryer must be exhausted to the outdoors. See Venting
Requirements(Pc20).
,A grounded electrical outlet located within 2 ft. (61 cm) of either
side of the dryer. See Electrical Requirements(Pc24),
,A sturdy floor to support the total dryer weight of 200 Ibs (90.7
kg). The combined weight of a companion appliance should also
be considered.
,No other fuel-burning appliance can be installed in the same
closet as a dryer.
Do not operate your dryer at temperatures below 45°F (7°C). At lower temperatures, the dryer might not shut off at the end of an automatic
cycle. This can result in longer drying times. The dryer must not be installed or stored in an area where it will be exposed to water and/or
weather. Check code requirements. Some codes limit, or do not permit, installation of the dryer in garages, closets, mobile homes or
sleeping quarters. Contact your local building inspector.
,,@ NOTE .............................................................................................................................................................................................................................................................................................................................................................................................................,
•A level floor with a maximum slope of 1 inch (2.5 cm) under entire dryer. If slope is greater than Iinch (2.5 cm), install the Extended /
Dryer Feet Kit. Clothes may not tumble properly, and automatic sensor cycles may not operate correctly if dryer is not level. /
•For a garage installation, you will need to place the dryer at least 18 inches (46 cm) above the floor. If using a pedestal, you will need
18 inches (46 cm) to the bottom of the dryer.
/......................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................j
Clearances
t_¢--1_14" max.*
10_ |35,6cm) I_J I_'_"u 48 in.2. _
"+-'======'- mln,* (310crn2)
918" min.* _mcl l_ i
I (45.7 cml
24 in.2__
(155cm2)
h"*_" 32.1"_15"**1 1"*1I_ 32.1"_15"**1
(2,5cm) (81,4cm) (12,7cm) (2,5cm) (81,4cm) (12,7crn)
__ _ 3'"
(7,6 cm)
(7.6 cm)
Closet Door Vent
Requirements 1
oJo
1"-_11÷ 29"÷lp_-l"
(2,5 cm) (73,6 cm) (2,5 cm)
1"-_p_29"-_11÷1"
(2,5 cm) (73,6 cm) (2,5 cm)
INSTALLATION SPACING FOR RECESSED AREA OR CLOSET INSTALLATION
The following spacing dimensions are recommended for this dryer. This dryer has been tested for spacing of O inches (O cm) clearance on
the sides and rear. Recommended spacing should be considered for the following reasons:
,Additional spacing should be considered for ease of installation
and servicing.
,Additional clearances might be required for wall, door and floor
moldings.
,Additional spacing should be considered on all sides of the dryer
to reduce noise transfer.
For closet installation, with a door, minimum ventilation openings
in the top and bottom of the door are required. Louvered doors
with equivalent ventilation openings are acceptable.
,Companion appliance spacing should also be considered.
NOTE .................................................................................................................................................................................................................................................................................................................................................
There should be at least a little space around the dryer (or any other appliance) to eliminate the transfer of vibration from one to the
other. Too much vibration could cause the appliances to touch each other, causing paint damage and more noise, i

14 INSTALLATION INSTRUCTIONS
Installation location requirements (Cont.)
AWARNING
Read all installation instructions completely before installing and operating your dryer! It is important that you review this entire
manual before installing and using your dryer. Detailed instructions concerning electrical connections, gas connections, and exhaust
requirements are provided on the following pages.
.A location that allows for proper exhaust installation. A
gas dryer must be exhausted to the outdoors. See Venting
Requirements(Po20).
. A grounded electrical outlet located within 2 ft. (61 cm) of either
side of the dryer. See Electrical Requirements(Po24)o
.A sturdy floor to support the total dryer weight of 200 Ibs (90.7
kg). The combined weight of a companion appliance should also
be considered.
.No other fuel-burning appliance can be installed in the same
closet as a dryer.
Do not operate your dryer at temperatures below 45°F (7°C). At lower temperatures, the dryer might not shut off at the end of an automatic
cycle. This can result in longer drying times. The dryer must not be installed or stored in an area where it will be exposed to water and/or
weather. Check code requirements. Some codes limit, or do not permit, installation of the dryer in garages, closets, mobile homes or
sleeping quarters. Contact your local building inspector.
Clearances (Space for Using the Dryer.)
If the duct is installed in the wall. If the duct isn't installed in the wall.
F
5g"
(151.8 crn)
_ EEl
(12.7 cm)

INSTALLATION INSTRUCTIONS 15
Insfallafion wifh opfional pedesfal base or slacking kif
RECOMMENDED INSTALLATION SPACING FOR CABINET INSTALLATION
.For cabinet installation with a door, minimum ventilation openings in the top of the cabinet are required.
_Required spacing
_For side or bottom venting,
2 inches (5.1 cm) spacing is allowed.
7"*(17.8 cm) _* (17.8cm)
I q_ 9....
I (22.9 cm)
5.... 32,1" ] .... 1" 29" 1"
J (12.7cm) (81,4cm) (2.5cm) (2.5cm)(73.6cm) (2.5cm)
CLOSETVENTILATIONREQUIREMENTS
Closets with doors must have both an upper and lower vent to prevent heat and moisture buildup in the closet. One upper vent opening
with a minimum opening of 48 sq. in. (310 cm 2) must be installed no lower than 6 feet above the floor. One lower vent opening with a
minimum opening of 24 sq. in. (155 cm2) must be installed no more than one foot above the floor. One example shown uses vent grilles in
the door.
RECOMMENDED INSTALLATION SPACING FOR RECESSED OR CLOSET INSTALLATION, WITH STACKED WASHER AND DRYER
. The dimensions shown are for the recommended spacing.
*Required spacing
**For side or bottom venting,
2 inches (5.1 cm) spacing is allowed.
48 in. 2*,,,
(310 cm2) 3;(7.6 cm)
• __7.6c.,)
24 in.2*
(155 crn2)
m
1"* (2.5 cm) 51/2"**
(14 cm)
6"*(15.2cm)
!_
81,6"
(207.2 cm)
1,,--_. ,_- 29,,_b.-
(2.5 cm) (73.6 cm) (2.5 crn)

16 INSTALLATION INSTRUCTIONS
Leveling fhe dryer
AWARNING
• To reduce the risk of injury to persons, adhere to all industry
recommended safety procedures including the use of
long sleeved gloves and safety glasses. Failure to follow this
warning can cause serious injury or death.
• The appliances are heavy. Two or more people are required
when installing the dryer. Failure to follow this warning can
cause serious injury or death.
To ensure that the dryer provides optimal drying performance,
it must be level.To minimize vibration, noise, and unwanted
movement, the floor must be a perfectly level, solid surface.
@ NOTE
Adjust the leveling feet only as far as necessary to level the
dryer. Extending the leveling feet more than necessary can
cause the dryer to vibrate.
2. Use an adjustable wrench to turn the leveling feet.Turn
clockwise to raise the dryer or counterclockwise to lower it.
Raise or lower the leveling feet until dryer is level from side to
side and front to back.
Make sure that all 4 leveling feet are in firm contact with the floor.
1. Position the dryer in the final location. Place a level across the
top of the dryer.
Leveling Feet
. All four leveling feet must rest solidly on the floor. Gently push
on the top corners of the dryer to make sure that the dryer does
not rock from corner to corner.
If you are installing the dryer on the optional pedestal, you must
use the leveling feet on the pedestal to level the dryer.The dryer
leveling feet should be fully retracted.

INSTALLATION INSTRUCTIONS 17
To remove the door
.......AWARNING ............................................................................................................................................
,To avoid damage to the dryer or the door, support the
door with a stool or box that fits under the door, or have
an assistant support the weight of the door.
, Always reverse the door BEFORE stacking the dryer on top
of the washer.
, Avoid dropping the door to avoid damage to the door or
the floor.
THE DRYER DOOR ISVERY LARGE AND HEAVY. Failure to follow
the instructions below can result in damage to the dryer,
property damage or injury to persons.
............................................................................................................... S
1. Open the door to reverse.
4. Remove two screws and disassembly Latch.
Latch Screw
/
/
5. Hold on the hinge while remove 2 screws of hinge (to prevent
door dropping).
Hinge
2. Check screws to remove (Left 6, Right 4). 6. Remove door from cabinet coven
_J
3. Remove four dummy screws by driver.
Hinge
Dummy
Screw

18 INSTALLATION INSTRUCTIONS
To install the door
......AWARNING ..........................................................................................................................................................,,
. To avoid damage to the dryer or the door, support the
door with a stool or box that fits under the door, or have
an assistant support the weight of the door.
. Always reverse the door BEFORE stacking the dryer on top
of the washer.
.Avoid dropping the door to avoid damage to the door or
the floor.
THE DRYER DOOR ISVERY LARGE AND HEAVY. Failure to follow
the instructions below can result in damage to the dryer,
property damage or injury to persons.
............................................................................................................... S
4. Screw down four dummy screws right side.
Ji
//
//
/
o _ Hinge
Dummy
Screw
//
1. Move door to left side and insert a hinge to hinge hole.
, ):
I
&l //7
Hinge hole
5. Check that the door closes and latches properly.
2. Hold on hinge while screw down a hinge
(to)revent door dropping).
_. Hinge Screw
/
i
3. Insert latch to right side and install screws.
Latch
Screw

INSTALLATION INSTRUCTIONS 19
Changing fhe dryer venf Iocafion
.......WARNING ....................................................................................................................................................................................................................................................................................,,
, Use a heavy metal vent.
.Do not use plastic or thin foil duct.
,Clean old ducts before installing this dryer.
• To reduce the risk of injury to persons adhere to all
industry recommended safety procedures including the
use of long sleeved gloves and safety glasses.
•Failure to follow all of the safety warnings in this manual could
result in property damage, injury to person or death.
Your new dryer is shipped to vent to the rear.
It can also be configured to vent to the bottom or side (right-
side venting is not available on gas models).
An adapter kit, part number 383EELgOO1L, may be purchased
from your LG retailer.This kit contains the necessary duct
components to change the dryer vent location.
......................................................................................................................................................................................................................................................................................./
1. Remove the rear exhaust duct retaining screw. Pull out the
exhaust duct.
f
Retaining
Rear
Exhaust Duct
Preassemble a 4 inches (10.2 cm) elbow to the next 4-inches
(10.2 cm) duct section, and secure all joints with duct tape. Be
sure that the male end of the elbow faces AWAY from the dryer.
Insert the elbow/duct assembly through the side opening and
press it onto the adapter duct. Secure in place with duct tape.
Be sure that the male end of the duct protrudes 11/2inches (3.8
cm) to connect the remaining ductwork.
Attach cover plate to the back of the dryer with included screw.
Plate
11/2"
(3.8 cm)
OPTION 2: BOTTOM VENTING
2. Press the adapter duct onto the blower housing and secure to
the base of the dryer as shown.
Adapter ,
IDuct "'-..
Bracket
OPTION 1: SIDE VENTING
2. Press the tabs on the knockout and carefully remove the
knockout for the desired vent opening (right-side venting is
not available on gas models). Press the adapter duct onto the
blower housing and secure to the base of the dryer as shown.
Adapter
3. Insert the 4 inches (10.2 cm) elbow through the rear opening
and press it onto the adapter duct. Be sure that the male end of
the elbow faces down through hole in the bottom of the dryer.
Secure in place with duct tape.
Attach the cover plate to the back of the dryer with included
screw.
Plate
Knockout

20 INSTALLATION INSTRUCTIONS
Venfing requiremenf
AWARNING
To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions, including the following:
. Do not crush or collapse ductwork. Failure to follow these
instructions can result in fire or death.
. Do not allow ductworkto rest on or contact sharp objects.
Failure to follow these instructions can result in fire or death.
.If connecting to existing ductwork, make sure it is suitable
and clean before installing the dryer. Failure to follow these
instructions can result in fire or death.
. Venting must conform to local building codes. Failure to follow
these instructions can result in fire or death.
. Gas dryers MUST exhaust to the outdoors.
Failure to follow these instructions can result in fire or death.
.Use only 4-inch (10.2 cm) rigid or flexible metal ductwork
inside the dryer cabinet and for venting outside. Failure to
follow these instructions can result in fire or death.
. To reduce the risk of fire, combustion, or accumulation of
combustible gases, DO NOT exhaust dryer air into an enclosed
and unventilated area, such as an attic, wall, ceiling, crawl
space, chimney, gas vent, or concealed space of abuilding.
Failure to follow these instructions can result in fire or death.
. To reduce the risk of fire, DO NOT exhaust the dryer with
plastic or thin foil ducting.
Failureto follow these instructions can result in fire or death.
. The exhaust duct must be 4inches (10.2 cm) in diameter with
no obstructions. The exhaust duct should be kept as short as
possible. Make sure to clean any old ducts before installing
your new dryer. Failure to follow these instructions can result in
fire or death.
Rigid or semirigid metal ducting is recommended for use
between the dryer and the wall. In special installations
when it is impossible to make aconnection with the above
recommendations, a UL-listed flexible metal transition duct
may be used between the dryer and wall connection only.
The use of this ducting will affect drying time. Failure to follow
these instructions can result in fire or death.
DO NOT use sheet metal screwsor other fasteners which
extend into the duct that could catch lint and reduce the
efficiency of the exhaust system. Secureall joints with duct
tape. Failureto follow these instructionscan result in fire or death.
To maximize operating results, please observe the duct length
limitations noted in the chart next page. Failure to follow these
instructions can result in fire or death.
Ductwork isnot provided with the dryer. Youshould obtain
the necessary ductwork locally. The end cap should have
hinged dampers to prevent backdraft when the dryer isnot in
use. Failureto follow these instructionscan result in fire or death.
The Total length of flexible metal duct shall not exceed 8ft.
(2.4 m)
In Canada, that only those foil-type flexible ducts, if any,
specifically identified for use with the appliance by the
manufacturer shall be used. In the United States, that only those
foil-type flexible ducts, if any, specifically identified for use with
the appliance by the manufacturer and that comply with the
Outline for Clothes DryerTransition Duct, Subject 2158A, shall be
used.
