LG RH735T Specification sheet

SIMPLE MANUAL
HDD / DVD RECORDER
Please read this manual carefully before operating
your set and retain it for future reference.
RH735T / RH733T / RH732T / RH731T
ENGLISH

1 Getting Started
Getting Started2
Getting Started
1
Safety Information
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER (OR BACK) NO
USER-SERVICEABLE PARTS INSIDE REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
This lightning ash with arrowhead
symbol within an equilateral triangle
is intended to alert the user to the
presence of uninsulated dangerous
voltage within the product’s
enclosure that may be of sucient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an
equilateral triangle is intended
to alert the user to the presence
of important operating and
maintenance (servicing)
instructions in the literature accompanying the
product.
WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK
HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE.
WARNING: Do not install this equipment in a
conned space such as a book case or similar unit.
CAUTION: Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
Slots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the
product and to protect it from over heating. The
openings shall be never be blocked by placing
the product on a bed, sofa, rug or other similar
surface. This product shall not be placed in a built-
in installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer’s
instruction has been adhered to.
CAUTION: This product employs a Laser System.
To ensure proper use of this product, please read
this owner’s manual carefully and retain it for future
reference. Shall the unit require maintenance,
contact an authorized service centre.
Use of controls, adjustments or the performance of
procedures other than those specied herein may
result in hazardous radiation exposure.
To prevent direct exposure to laser beam, do not
try to open the enclosure.
CAUTION concerning the Power Cord
Most appliances recommend they be placed upon
a dedicated circuit;
That is, a single outlet circuit which powers only
that appliance and has no additional outlets or
branch circuits. Check the specication page of this
owner’s manual to be certain. Do not overload wall
outlets. Overloaded wall outlets, loose or damaged
wall outlets, extension cords, frayed power cords, or
damaged or cracked wire insulation are dangerous.
Any of these conditions could result in electric
shock or re. Periodically examine the cord of your
appliance, and if its appearance indicates damage
or deterioration, unplug it, discontinue use of the
appliance, and have the cord replaced with an
exact replacement part by an authorized service
centre. Protect the power cord from physical or
mechanical abuse, such as being twisted, kinked,
pinched, closed in a door, or walked upon. Pay
particular attention to plugs, wall outlets, and
the point where the cord exits the appliance. To
disconnect power from the mains, pull out the
mains cord plug. When installing the product,
ensure that the plug is easily accessible.

Getting Started 3
Getting Started
1
This device is equipped with a portable battery or
accumulator.
Safety way to remove the battery or the
battery from the equipment: Remove the
old battery or battery pack, follow the steps
in reverse order than the assembly. To prevent
contamination of the environment and bring on
possible threat to human and animal health, the
old battery or the battery put it in the appropriate
container at designated collection points. Do
not dispose of batteries or battery together with
other waste. It is recommended that you use
local, free reimbursement systems batteries and
accumulators. The battery shall not be exposed to
excessive heat such as sunshine, re or the like.
CAUTION: The apparatus shall not be exposed to
water (dripping or splashing) and no objects lled
with liquids, such as vases, shall be placed on the
apparatus.
Disposal of your old appliance
1. All electrical and electronic products
should be disposed of separately
from the municipal waste stream
via designated collection facilities
appointed by the government or the
local authorities.
2. The correct disposal of your old
appliance will help prevent potential
negative consequences for the
environment and human health.
3. For more detailed information about
disposal of your old appliance,
please contact your city office, waste
disposal service or the shop where
you purchased the product.
Disposal of waste batteries/accumulators
Pb
1. This symbol may be combined with chemical
symbols for mercury(Hg), cadmium(Cd) or
lead(Pb) if the battery Contains more that
0.0005% of mercury,0.002% of cadmium or
0.004% of lead.
2. All batteries/accumulators should be disposed
separately from the municipal waste stream via
designated collection facilities appointed by the
government or the local authorities.
3. The correct disposal of Your old batteries/
accumulators will help to prevent potential
negative consequences for the environment,
animal and human health.
4. For more detailed information about disposal of
Your old batteries/accumulators, please contact
Your city office, waste disposal service or the
shop where You purchased the product.
LG Electronics hereby declares that this/these
product(s) is/are in compliance with the essential
requirements and other relevant provisions of
Directive 2004/108/EC, 2006/95/EC, 2009/125/EC
and 2011/65/EU.
Contact oce for compliance of this product :
LG Electronics Inc.
EU Representative, Krijgsman 1,
1186 DM Amstelveen, The Netherlands
yPlease note that this is NOT a Customer Service
contact point. For Customer Service Information,
see Warranty Card or contact the dealer that you
purchased this product.

Getting Started4
Getting Started
1
Notes on Copyrights
yRecording equipment should be used only for
lawful copying and you are advised to check
carefully what is lawful copying in the area
in which you are making a copy. Copying of
copyright material such as lms or music is
unlawful unless permitted by a legal exception
or consented to by the rights owner.
yThis product incorporates copyright protection
technology that is protected by U.S. patents
and other intellectual property rights. Use of
this copyright protection technology must be
authorized by Rovi Corporation, and is intended
for home and other limited viewing uses only
unless otherwise authorized by Rovi Corporation.
Reverse engineering or disassembly is prohibited.
yCONSUMERS SHOULD NOTE THAT NOT ALL
HIGH DEFINITION TELEVISION SETS ARE FULLY
COMPATIBLE WITH THIS PRODUCT AND MAY
CAUSE ARTIFACTS TO BE DISPLAYED IN THE
PICTURE. IN CASE OF 625 PROGRESSIVE SCAN
PICTURE PROBLEMS, IT IS RECOMMENDED
THAT THE USER SWITCH THE CONNECTION
TO THE ‘STANDARD DEFINITION’ OUTPUT. IF
THERE ARE QUESTIONS REGARDING OUR TV SET
COMPATIBILITY WITH THIS MODEL 625p UNIT
PLEASE CONTACT OUR CUSTOMER SERVICE
CENTRE.
yMany DVD discs are encoded with copy
protection. Because of this, you should only
connect your player directly to your TV, not to a
VCR. Connecting to a VCR results in a distorted
picture from copy-protected discs.
yUnder the U.S. Copyright laws and Copyright
laws of other countries, unauthorized recording,
use, display, distribution, or revision of television
programs, videotapes, DVDs, CDs and other
materials may subject you to civil and/or criminal
liability.
Important Notice for TV colour
system
The colour system of this player diers according to
currently playing discs.
For example, when the player plays the disc
recorded in the NTSC colour system, the image is
output as an NTSC signal.
Only the multi system colour TV can receive all
signals output from the player.
yIf you have a PAL colour system TV, you will see
just distorted images when using discs or video
contents recorded in NTSC.
yThe multi system colour TV changes the colour
system automatically according to input signals.
In case that the colour system is not changed
automatically, turn it o and then on to see
normal images on screen.
yEven if the disc recorded in NTSC colour system
are well displayed on your TV, these may not be
recorded correctly on your recorder.
Supplied Accesorries
Remote control (1) Battery (1)
RF cable (1) CD manual

Table of Contents 5
1
2
3
4
5
Table of Contents
1 Getting Started
2 Safety Information
4 – Supplied Accesorries
6 Introduction
6 – Playable Discs and symbols used in
this manual
6 – About the “7” symbol display
6 – Regional Code
7 – Compatibility Notes
7 – AVCHD (Advanced Video Codec High
Definition)
7 – System Requirements
8 – Recordable Discs
8 – Recommended recordable DVD discs
8 – File compatibility
10 Remote control
11 Main Unit
12 Connections to Your TV
12 – Antenna connection to your TV and
this unit
12 – Video/Audio (Left/Right) Connection
13 – HDMI Connection
13 – Resolution Setting
2 System Setting
14 Auto Set Up
15 Home Menu Overview
15 – Basic button operations
15 Settings
15 – Adjust the Setup Settings
3 Operating
16 General Playback
16 – Playing a disc
17 – Playing a file on Linked Devies
18 – Basic operations for video and audio
content
18 – Basic operations for photo content
19 On-Screen display
19 – Displaying content information on-
screen
19 Using the Recording title Copy
4 Troubleshooting
22 Troubleshooting
22 – General
22 – Resetting the unit
23 – Playback
23 – Recording
24 – HDMI
24 – Customer Support
24 – Open source software notice
5 Appendix
25 Trademarks and Licenses
25 About the internal hard disk drive
26 Specifications

Getting Started6
Getting Started
1
Introduction
Playable Discs and symbols used in this manual
Media/Term Logo Symbol Description
DVD-ROM
DVD-R
DVD-RW
DVD+R
DVD+RW
(12 cm, 8 cm)
r
yDiscs such as movies that can be purchased or
rented.
yVideo mode and nalized only
ySupports the dual layer disc also
oFinalized AVCHD format
y
u
i
yDVD±R/RW discs that contain Video, Audio or
Photo les.
yISO 9660+JOLIET, UDF and UDF Bridge format
DVD-RW (VR)
(12 cm) rVR mode and nalized only
Audio CD
(12 cm) tAudio CD
CD-R/RW
(12 cm, 8 cm)
y
u
i
yCD-R/RW discs that contain Video, Audio or
Photo les.
yISO 9660+JOLIET, UDF and UDF Bridge format
HDD –REC Titles recorded via this unit
Note –,Indicates special notes and operating features.
Caution –>Indicates cautions for preventing possible damages
from abuse.
About the “7” symbol display
“7” may appear on your TV display during operation and indicates that the function explained in this
owner’s manual is not available on that specic media.
Regional Code
This unit has a regional code printed on the rear of the unit. This unit can play only DVD discs labelled same
as the rear of the unit or “ALL”.

Getting Started 7
Getting Started
1
yDepending on the conditions of the
recording equipment or the CD-R/RW (or
DVD±R/RW) disc itself, some CD-R/RW (or
DVD±R/RW) discs cannot be played on the
unit.
yDo not attach any seal or label to either side
(the labeled side or the recorded side) of a
disc.
yDo not use irregularly shaped CDs (e.g.,
heart-shaped or octagonal). Doing so may
result in malfunctions.
yDepending on the recording software & the
nalization, some recorded discs (CD-R/RW,
DVD±R/RW) may not be playable.
yDVD-R/RW, DVD+R/RW and CD-R/RW discs
recorded using a personal computer or a
DVD or CD Recorder may not play if the
disc is damaged or dirty, or if there is dirt or
condensation on the Recorder’s lens.
yIf you record a disc using a personal
computer, even if it is recorded in a
compatible format, there are cases in which
it may not play because of the settings of
the application software used to create the
disc. (Check with the software publisher for
more detailed information.)
yThis player requires discs and recordings to
meet certain technical standards in order
to achieve optimal playback quality. Pre-
recorded DVDs are automatically set to
these standards. There are many dierent
types of recordable disc formats (including
CD-R containing MP3 or WMA les) and
these require certain pre-existing conditions
to ensure compatible playback.
yCustomers should note that permission
is required in order to download MP3 /
WMA les and music from the Internet.
Our company has no right to grant such
permission. Permission should always be
sought from the copyright owner.
, Note
Compatibility Notes
yViewing high-denition content and up-
converting standard DVD content may require a
HDMI-capable input or HDCP-capable DVI input
on your display device.
ySome DVD discs may restrict the use of some
operation commands or features.
yYou can use a USB device that is used to store
some disc related information. The disc you are
using will control how long this information is
retained.
AVCHD (Advanced Video
Codec High Definition)
yThis player can playback AVCHD format discs.
These discs are normally recorded and used in
camcorders.
yThe AVCHD format is a high denition digital
video camera format.
yThe MPEG-4 AVC/H.264 format is capable of
compressing images at higher eciency than
the conventional image compressing format.
ySome AVCHD discs use the “x.v.Color” format.
yThis player can playback AVCHD discs using
“x.v.Color” format.
ySome AVCHD format discs may not be played,
depending on the recording condition.
yAVCHD format discs need to be nalized.
y“x.v.Color” oers a wider colour range than
normal DVD camcorder discs.
System Requirements
For high denition video playback:
yHigh denition display that has HDMI input jacks.
yHDMI or HDCP capable DVI input on your display
device is required for some content (as specied
by disc authors).
yFor up-conversion of standard denition DVD, a
HDMI or HDCP capable DVI input on your display
device is required for copy-protected content.
For Dolby® Digital Plus, Dolby TrueHD audio
playback:
yAn amplier/receiver with a built-in (Dolby
Digital, Dolby Digital Plus, Dolby TrueHD or DTS).
yMain, centre, surround speakers and subwoofer
as necessary for chosen format.

Getting Started8
Getting Started
1
Recordable Discs
DVD-R/ DVD+R(DL):
-Format is available (only 1 time),
with UDF type
-Record is available over and over
(Multi-session is supported)
-You may need to nalize a disc to
play it with dierent unit. Once a
disc is nalized, you can‘t record
any more.
DVD-RW/ DVD+RW:
-Format is available repeatedly,
with UDF type
-Record is available over and over
(Single-session is supported).
Recommended recordable DVD
discs
DVD-R Mitsubishi (8x, 16x), Verbatim
(8x, 16x)
DVD-RW Mitsubishi (8x, 16x), Verbatim
(8x, 16x), JVC (4x), Maxell (4x)
DVD+R Mitsubishi (8x, 16x), Verbatim
(8x, 16x)
DVD+R(DL) Verbatim (8x, 4x), MKM (8x, 4x),
CMC (4x), RITEK (4x)
DVD+RW Mitsubishi (8x, 16x), HP (4x),
Verbatim (4x), Ricoh (4x)
yIf a DVD-RW/DVD+RW discs is recorded
using a personal computer or other DVD
recorder, you cannot format the disc using
this recorder. So if you want to use the disc
on this recorder, you must format the disc
using the original recorder.
yWhile recording, in case of DVD-R/+R disc,
there may be noise from the unit. But it is
not a problem.
yRecordable DVD is used only for Recorded
Title Copy. (Refer to the maual on the
supplied CD-ROM disc.)
yRecorded Title is copied as TS Format File to
Recordable DVD. So Disc copied on this unit
may not played on other player or recorder.
, Note
File compatibility
Overall
Available File extensions: “.jpg”, “.jpeg”, “.png”, “.avi”,
“.divx”, “.mpg”, “.mpeg”, “.mkv”, “.mp4”, “.ts”, “.mp3”, “.wma”,
“.m4a”
yThe le name is limited to 128 characters.
yDepending on the size and number of the les, it
may take several minutes to read the contents on
the media.
Maximum Files/Folder: Less than 2000 (total
number of les and folders)
CD-R/RW, DVD±R/RW:
ISO 9660+JOLIET, UDF and UDF Bridge format
MOVIE
Available resolution: 1920 x 1080 (W x H) pixels
Playable subtitle: SubRip (.srt / .txt), SAMI (.smi),
SubStation Alpha (.ssa/.txt), MicroDVD (.sub/.txt),
SubViewer 1.0 (.sub), SubViewer 2.0 (.sub/.txt), DVD
Subtitle System (.txt), TMPlayer (.txt)
Playable Codec format: “DIVX 3.11”, “DIVX4”, “DIVX5”,
“DIVX6”, “MPEG4 PART2”, “MPEG4 VISUAL”
“XVID” (Standard playback only), H.264/MPEG-4 AVC,
MPEG2 PS, MPEG2 TS
y“DIVX3”, “DIVX4”, “DIVX5”, “DIVX6”, “XVID”, “MPEG4
PART2”, “MPEG4 VISUAL”: Less than 720 x 576
(resolution) and 5Mpbs (Bitrate)
Playable Audio format: “Dolby Digital”, “DTS”, “MP3”,
“WMA”, “AAC”

Getting Started 9
Getting Started
1
yNot all the WMA and AAC Audio formats are
compatible with this unit.
yMPEG2 Audio Codec are not supported on this
unit.
yDTS is only available when this unit is connected
to the equipment supporting DTS.
Sampling frequency: within 32 - 48 kHz (WMA),
within 32 - 48 kHz (MP3)
Bit rate: within 20 - 320 kbps (WMA),
within 32 - 320 kbps (MP3)
yHD movie les contained on the CD or USB
1.0/1.1 may not be played properly. DVD or
USB 2.0 are recommended to play back HD
movie les.
yThis unit supports H.264/MPEG-4 AVC prole
Main, High at Level 4.1.
yThis unit does not support the le that
are recorded with GMC*1or Qpel*2. Those
are video encoding techniques in MPEG4
standard, like DivX or XVID.
*1 GMC – Global Motion Compensation
*2 Qpel – Quarter pixel
yHD movie les that need high performance
playback could react slowly.
yThe total playback time indicated on the
screen may not be correct for .ts les.
, Note
MUSIC
Sampling frequency: between 8 - 48 kHz (WMA),
within 32 kHz - 48 kHz (MP3)
Bit rate: between 32 - 320 kbps (MP3) and
between 8 - 320 kbps (WMA)
The total playback time indicated on the
screen may not be correct for VBR les.
, Note
Recommended size:
JPG File
yBaseline JPG : Less than 16M pixel, Max width
6000 pixel
yProgressive JPG : Less than 4M pixel,
Max width 6000 pixel
PNG File
y64bits : Less than 1M pixel, Max width 4096 pixel
y32bits : Less than 2M pixel, Max width 4096 pixel
Depending on the size and number of the
JPEG les, it may take several minutes to read
the contents of the media.
, Note
Thumbnail image:
JPG File : Less than 16M pixel, Max width 6000 pixel
PNG File : Less than 16M pixel, Max width 4096 pixel
yThis unit just supports Baseline JPG and 32bits
PNG in thumbnail.

Getting Started10
Getting Started
1
Remote control
Replacement of battery
(R03)
Remove the battery cover on the
rear of the Remote Control, and
insert a R03 (size AAA) battery
with 4and 5matched correctly.
• • • • • • a • • • • • •
1(POWER): Switches the player
ON or OFF.
INPUT: Changes the input for
recording (Tuner or AV mode).
MUTE (@): Mutes the sound.
B(OPEN/CLOSE): Opens and
closes the disc tray.
0-9 numerical buttons: Selects
numbered options in a menu.
DISC MENU/REC.LIST: Accesses
menu on a disc or switches
between recording list menu.
TITLE/Q.MENU: Displays the DVD
title menu or sets options menu, if
available.
TV (TV Control Buttons): Refer
to the maual on the supplied CD-
ROM disc.
VOL (-/+): Adjusts the sound level
of the unit.
• • • • • • b • • • • •
c/v (SCAN): Searches
backward or forward.
C/V (SKIP): Goes to the
next or previous chapter / track /
le.
Z(STOP): Stops playback.
z(PLAY): Starts playback.
M(PAUSE): Pauses playback.
TIME SHIFT: Activates pause live
TV/playback (timeshift) for a live
TV programme.
• • • • • • c • • • • •
HOME (n): Displays or exits the
[Home Menu].
INFO/MENU (m): Displays or
exits On-Screen Display.
Direction buttons: Selects an
option in the menu.
ENTER (b): Acknowledges menu
selection.
BACK (1): Exits the menu or
returns to the previous screen.
EXIT: Exits a menu or hides on-
screen information.
• • • • • • d • • • • •
CH LIST: Displays the Channel list.
CH/PAGE (S/W): Scans up
or down through memorized
programmes or previous or next
viewing page.
FAV: Displays the favourite
programme list.
Coloured (R, G, Y, B) buttons:
Use to navigate screen menus.
GUIDE: Displays the programme
guide menu.
TEXT: Switches between teletext
mode and normal TV viewing.
TIMER REC.: Displays [Timer
Recording] menu.
REC. (X): Starts recording.
REPEAT (h): Repeats a desired
section or sequence.
TV/RADIO: Switches between TV
and radio channel.
SUBTITLE: Selects a subtitle
language.

Getting Started 11
Getting Started
1
Main Unit
aDisc Tray
bDisplay window
cRemote Sensor
dR(Open/Close)
eT(Play/Pause)
fI(Stop)
g 1/I (Power)
hUSB Port
aANTENNA IN
bHDMI OUT (TO TV)
cOPTICAL (DIGITAL AUDIO OUT)
dVIDEO IN/2CH AUDIO IN (Left/Right)
Connect the audio/video output of an external
source.
eAC IN connector
Connect the supplied power cord.
fANTENNA OUT (TO TV)
gVIDEO OUT
h2CH AUDIO OUT (Left/Right)

Getting Started12
Getting Started
1
Connections to Your
TV
Antenna connection to your
TV and this unit
Connect one end of the RF cable to ANTENNA
OUT(TO TV) jack on the unit and other end to
ANTENNA IN jack on your TV. Passes the signal from
the ANTENNA IN jack to your TV/monitor.
Connect the Terrestrial TV antenna to the ANTENNA
IN jack on the unit. If you want to use an indoor
antenna, use one with a signal amplier rated at 5V,
100 mA and set [Antenna 5V] to [ON] in the setup
menu.
TV
RF Cable
Rear of this unit
TV
ANTENNA
Video/Audio (Left/Right)
Connection
Connect the VIDEO OUT jack on the unit to the
video in jack on the TV using the video cable
supplied. Connect the Left and Right AUDIO OUT
jacks on the unit to the audio left/right in jacks on
the TV using the supplied audio cables.
TV
Video/Audio Cable
TV
Rear of this unit

Getting Started 13
Getting Started
1
HDMI Connection
If you have a HDMI TV or monitor, you can connect
it to this unit using a HDMI cable (Type A, High
Speed HDMI™ Cable). Connect the HDMI jack on
the unit to the HDMI jack on a HDMI compatible TV
or monitor.
TV
Rear of this unit
TV
HDMI Cable
Set the TV’s source to HDMI (refer to TV’s Owner’s
manual).
Resolution Setting
The player provides several output resolutions for
HDMI OUT jacks. You can change the resolution
using [Setting] menu.
1. Press HOME (n).
2. Use
a/dto select the [Setting] and press
ENTER (b). The [Setting] menu appears.
3. Use
w/sto select [PICTURE] option then press
d or ENTER (b) to move to the second level.
4. Use
w/sto select the [Resolution] option then
press ENTER (b) to move to the third level.
5. Use
w/sto select the desired resolution then
press ENTER (b) to confirm your selection.
If your TV is NTSC SYSTEM, resolution can be
set only for AUTO mode.
, Note

2 System Setting
System Setting14
System Setting
2
Auto Set Up
You can reset the recorder to all its factory settings.
The [Auto Set up] menu appears on the screen after
the factory settings.
Step 1. Language Selection
Use w/s/a/d to select a language for the on-
screen display, and press ENTER (b).
Step 2. Screen Size Setting
Use a/d to select a screen size, and press ENTER
(b).
Step 3. Country Selection
Use w/s/a/d to select a country, and press
ENTER (b).
Step 4. Password Setting
Input the new password using numerical buttons.
Enter it again to verify.
Step 5. Auto Tuning
1. While the Start option is selected, and press
ENTER (b) to begin the channel search.
The recorder automatically searches for and
saves the programmes.
If you select [Stop], the [Auto Tuning] function
will be skipped.
2. Press ENTER (b).
Step 6. Setting is complete
Check all the settings that you have set in the
previous steps.
Press ENTER (b) while [Complete] is highlighted to
nish the auto set up settings.

System Setting 15
System Setting
2
Home Menu Overview
To access numerous functions of the unit, press
HOME (n) on the remote.
Basic button operations
HOME (n): Accesses or removes the Home Menu.
w/s/a/d: Used to navigate on-screen displays.
ENTER (b): Acknowledges menu selection.
BACK (1): Exits the menu.
[DTV] - You can watch digital broadcasts.
[Movie] - Plays video contents.
[Photo] - Plays photo contents.
[Music] - Plays audio contents.
[AV] - You can watch video from external input
mode. When you use the recording mode, you
can’t enter the AV mode.
[Setting] - Adjusts the system settings.
Settings
Adjust the Setup Settings
You can change the settings of the player in the
[Setting] menu.
1. Press HOME (n).
2. Use a/d to select [Setting] and press ENTER
(b). The [PICTURE] menu appears.
3. Use w/s to select the first setup option, and
press ENTER (b) to move to the second level.
4. Use
w/s to select a second setup option, and
press ENTER (b) to move to the third level.
5. Use w/s to select a desired setting, and press
ENTER (b) to conrm your selection.

3 Operating
Operating16
Operating
3
General Playback
Playing a disc
DVD AVCHD ACD
1. Press
B(OPEN/CLOSE), and place a disc on the
disc tray.
2. Press
B(OPEN/CLOSE) to close the disc tray.
For most Audio CD, DVD, AVCHD and DVD-ROM
discs, playback starts automatically.
3. Press HOME (n).
4. Select [Movie], [Photo] or [Music] using a/d,
and press ENTER (b).
5. Select the disc icon using a/d, and press
ENTER (b).
Playback functions described in this manual
are not always available in every les and
media. Some functions can be restricted
depending on many factors.
, Note
To stop playback
Press Z(STOP) during playback.
To pause playback
Press M(PAUSE) during playback.
Press z(PLAY) to resume playback.
To scan forward or backward
Press cor vto play fast forward or fast reverse
during playback.
You can change the various playback speeds by
pressing cor vrepeatedly.
To slow down the playing speed
While the playback is paused, press vto play at
slow motion.
To skip to the next/previous
chapter/track/file
During playback, press Cor Vto go to the
next chapter/track/le or to return to the beginning
of the current chapter/track/le.
Press Ctwice briey to step back to the previous
chapter/track/le.
In case of movie le, press Cone time. You can
play previous le.

Operating 17
Operating
3
Playing a file on Linked Devies
This unit can play video, audio and photo les
contained in the USB device.
1. Insert a USB device into the USB port until it fits
into place.
2. Press HOME (n).
3. Select [Movie], [Photo] or [Music] using a/d,
and press ENTER (b).
4. Select the [ (USB)] option using w/s/a/
d, and press ENTER (b).
5. Select a file using w/s/a/d, and press z
(PLAY) or ENTER (b) to play the file.
6. Withdraw the USB device carefully after exiting
the USB mode.
To control movie playback
You can control playback and set options while
watching videos.
During playback, press INFO/MENU (m).
aProgress bar - Selects the desired point and
plays.
bPlayback control - Refer to the basic operation
for video.
cOption - Sets options for the Screen Size or
video play.
dList - Stops playback and returns to the list.
To control photo view
Controls playback and sets options while viewing
pictures in full screen.
aSlideshow - Displays photos as a slideshow.
bBGM - Plays background music.
c
yRotation - Rotates the picture.
yEnlargement - Enlarges the picture.
dOption - Sets options for viewing photo.
eList - Stops playback and returns to the list.

Operating18
Operating
3
To control music playback
Controls play and sets options while listening to a
music.
aProgress bar - Selects the desired point and
plays.
bPlayback control - Refer to the basic operation
for audio and advanced playback.
c[List] - Returns to the list.
When you move the progress bar to desired
point during playback, some les may not be
moved to exact point or play next le back.
, Note
Basic operations for video and
audio content
To stop playback
Press Z(STOP) or while playback.
To pause playback
Press M(PAUSE) button on the remote control or M
(PAUSE) on the screen while playback.
Press z (PLAY) button on the remote control or
z (PLAY) icon on the screen to resume playback.
To resume playback
(Movie les)
The unit records the point where you stopped
during playback. When you play the le again on
the list, the option will be appeared on the le.
To resume the playback, Select [YES] and press
ENTER (b).
To scan forward or backward
(Movie les)
Press cor v to play fast forward or fast
reverse during playback.
You can change the various playback speeds by
pressing cor v repeatedly.
To skip to the next/previous file
(Movie/Music les)
During playback, press Cor V to go to the
next le or to step back to the previous le.
Basic operations for photo
content
To play a slide show
Press [Slide Show d] on the Photo view screen.
To stop a slide show
Press [Slide Show Z] on the Photo view screen.
To skip to the next/previous photo
While viewing a photo in full screen, press aor d
on the remote control to go to the previous or next
photo.

Operating 19
Operating
3
On-Screen display
You can display and adjust various information and
settings concerning the content.
Displaying content information
on-screen
DVD AVCHD
1. During playback, press INFO/MENU (m)to
show various playback information.
aTitle – current title number/total number of
titles
bChapter – current chapter number/total
number of chapters
cTime – elapsed playing time/total playback
time
dAudio – selected audio language or channel
eSubtitle – selected subtitle
fAngle – selected angle/total number of
angles
2. Select an option using w/s.
3. Use a/d to adjust the selected option value.
4. Press BACK (1) to exit the On-Screen display.
yIf no button is pressed for a few seconds,
the on-screen display disappears.
yA title number cannot be selected on some
discs.
yAvailable items may dier depending on
discs or titles.
, Note
Using the Recording
title Copy
You can copy recording title from to the other
storage device.
Preparations:
yInsert a blank DVD disc in the DVD deck and
close the disc tray.
yInsert a external HDD to the USB port until it ts
into place.
1. Press HOME (n).
2. Use w/s/a/d to select [Recorded TV] or
Disc icon, on the HOME menu and press ENTER
(b).
3. Press green (G) colored button to display the
[Linked Device List] menu.
If you want to copy the recorded title on disc,
internal HDD or external HDD, please select the
desired device.
4. Use w/s to select a storage device you want
to copy, and press ENTER (b).
5. Press blue (B) colored button.
6. Use w/s/a/d to select a recording title
then press ENTER (b). (shows icon)

Operating20
Operating
3
7. Press green (G) colored button to display the
[Device Selection] menu.
8. Use w/s to select [ DISC], [ HDD]
or [ USB] and press ENTER (b) for target
device.
9. (Disc only)
Use
w/s to select a desired Rec Mode Set [XP,
SP, LP or EP] and press ENTER (b).
There are four preset copying quality modes:
[XP] –Highest quality setting, gives about 1
hour of recording time on a DVD (4.7 GB).
[SP] –Default quality, sucient for many
applications, gives about 2 hours of recording
time on a DVD (4.7 GB).
[LP] –Slightly lower video quality, gives about
3 hours of recording time on a DVD disc (4.7
GB).
[EP]–Low video quality, gives about 4 hours of
recording time on a DVD (4.7 GB).
10. Use a/d to select [Yes], and press ENTER (b)
to start copying.
11. (Disc only)
It starts to copy to DVD after preparing video.
After completing copy to DVD, you can see the
copy list.
12. Press BACK (1) to exit the copy list.
