LG Lifeband Touch User manual

LG Lifeband
Touch
OWNER’S MANUAL
To understand information offered by LG Heart
Rate Earphones correctly, read the owner’s
manual carefully.
Model : FB84-BM / FB84-BL / FB84-BX / FB84-SM /
FB84-SL / FB84-SX / FB84-RM / FB84-RL /
FB84-RX
www.lg.com

Before using2
Before using
1
Safety Information
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
This lightning ash with
arrowhead symbol within an
equilateral triangle is intended to
alert the user to the presence of
uninsulated dangerous voltage
within the product’s enclosure that may be
of sucient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within
an equilateral triangle is
intended to alert the user to the
presence of important operating
and maintenance (servicing)
instructions in the literature accompanying the
product.
WARNING: This product contains chemicals
known to the State of California to cause cancer
and birth defects or other reproductive harm.
Wash hands after handling.
WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK
HAZARD, DO NOT EXPOSE THIS PRODUCT TO
RAIN OR MOISTURE.
CAUTION: The apparatus shall not be exposed
to water (dripping or splashing) and no objects
lled with liquids, such as vases, shall be placed
on the apparatus.
WARNING: Do not install this equipment in a
conned space such as a book case or similar
unit.
CAUTION: Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
Slots and openings in the cabinet are provided
for ventilation and to ensure reliable operation of
the product and to protect it from over heating.
The openings shall be never be blocked by
placing the product on a bed, sofa, rug or other
similar surface. This product shall not be placed
in a built-in installation such as a bookcase or
rack unless proper ventilation is provided or the
manufacturer’s instruction has been adhered to.
CAUTION concerning the Power Cord
Most appliances recommend they be placed
upon a dedicated circuit;
That is, a single outlet circuit which powers only
that appliance and has no additional outlets or
branch circuits. Check the specication page
of this owner’s manual to be certain. Do not
overload wall outlets. Overloaded wall outlets,
loose or damaged wall outlets, extension cords,
frayed power cords, or damaged or cracked wire
insulation are dangerous. Any of these conditions
could result in electric shock or re. Periodically
examine the cord of your appliance, and if its
appearance indicates damage or deterioration,
unplug it, discontinue use of the appliance, and
have the cord replaced with an exact replacement
part by an authorized service center. Protect the
power cord from physical or mechanical abuse,
such as being twisted, kinked, pinched, closed in
a door, or walked upon. Pay particular attention
to plugs, wall outlets, and the point where the
cord exits the appliance. To disconnect power
from the mains, pull out the mains cord plug.
When installing the product, ensure that the plug
is easily accessible.

Before using 3
Before using
1
This device is equipped with a portable battery
or accumulator.
Safety way to remove the battery or the battery
from the equipment: Remove the old battery
or battery pack, follow the steps in reverse order
than the assembly. To prevent contamination of
the environment and bring on possible threat
to human and animal health, the old battery or
the battery put it in the appropriate container
at designated collection points. Do not dispose
of batteries or battery together with other
waste. It is recommended that you use local,
free reimbursement systems batteries and
accumulators. The battery shall not be exposed
to excessive heat such as sunshine, re or the like.
NOTICE: For safety making information including
product identication and supply ratings,
please refer to the main label on the rear of the
apparatus.
CAUTION when using this product in environments
of low humidity
yIt may cause static electricity in
environments of low humidity.
yIt is recommended to use this product
after touching any metal object which
conducts electricity.
> Caution

Before using4
Before using
1
IMPORTANT SAFETY
INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including ampliers) that produce
heat.
9. Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide blade
or the third prong are provided for your safety.
If the provided plug does not t into your
outlet, consult an electrician for replacement
of the obsolete outlet.
10. Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus.
11. Only use attachments/accessories specied
by the manufacturer.
12. Use only with the cart, stand,
tripod, bracket, or table
specied by the manufacturer,
or sold with the apparatus.
When a cart is used, use
caution when moving the cart/
apparatus combination to avoid injury from
tip-over.
13. Unplug this apparatus during lightning
storms or when unused for long periods of
time.
14. Refer all servicing to qualied service
personnel. Servicing is required when the
apparatus has been damaged in any way, such
as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate
normally, or has been dropped.

Before using 5
Before using
1
FCC Compliance Statement
This device complies with part 15 of the FCC
rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful
interference, and
(2) This device must accept any interference
received, including interference that may cause
undesired operation.
NOTE: This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment generates,
uses, and can radiate radio frequency energy
and, if not installed and used in accordance with
the instructions, may cause harmful interference
to radio communications. However, there is no
guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference
to radio or television reception, which can be
determined by turning the equipment o and
on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
yReorient or relocate the receiving antenna.
yIncrease the separation between the
equipment and receiver.
yConnect the equipment into an outlet on a
circuit dierent from that to which the receiver
is connected.
yConsult the dealer or an experienced radio/TV
technician for help.
CAUTION: Any changes or modications not
expressly approved by the party responsible for
compliance could void the user’s authority to
operate this equipment.
FCC WARNING : This equipment may generate
or use radio frequency energy. changes or
modications to this equipment may cause
harmful interference unless the modications are
expressly approved in the instruction manual.
The user could lose the authority to operate
this equipment if an unauthorized change or
modication is made.
FCC RF Radiation Exposure Statement : This
equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment.
CAUTION: Regulations of the FCC and FAA
prohibit airborne operation of radio-frequency
wireless devices because their signals could
interfere with critical aircraft instruments.
Responsible Party :
LG Electronics USA, Inc.1000 Sylvan Avenue
Englewood Clis, NJ 07632
TEL. : [phone]
+%%QORNKCPEG5VCVGOGPV
7KLV GHYLFH FRPSOLHV ZLWK ,QGXVWU\ &DQDGD
OLFHQVHH[HPSW566VWDQGDUGV2SHUDWLRQLV
VXEMHFWWRWKHIROORZLQJWZRFRQGLWLRQV
 WKLV GHYLFH PD\ QRW FDXVH LQWHUIHUHQFH
DQG  WKLV GHYLFH PXVW DFFHSW DQ\
LQWHUIHUHQFHLQFOXGLQJLQWHUIHUHQFHWKDWPD\
FDXVHXQGHVLUHGRSHUDWLRQRIWKHGHYLFH
&HW DSSDUHLO HVW FRQIRUPH DYHF ,QGXVWULH
&DQDGDH[HPSWVGHOLFHQFHVWDQGDUG566V
/RSpUDWLRQHVWVRXPLVHDX[GHX[FRQGLWLRQV
VXLYDQWHV
 FHW DSSDUHLO QH SHXW FDXVHU
GLQWHUIpUHQFHV HW  FHW DSSDUHLO GRLW
DFFHSWHU WRXWH LQWHUIpUHQFH \ FRPSULV OHV
LQWHUIpUHQFHVTXLSHXYHQW FDXVHUXQPDXYDLV
IRQFWLRQQHPHQWGHODSSDUHLO
%'%QORNKCPEG5VCVGOGPV
+HUHE\/*(OHFWURQLFV,QFGHFODUHVWKDWWKLV
+/%0LVLQFRPSOLDQFHZLWKWKHHVVHQWLDO
UHTXLUHPHQWV DQG RWKHU UHOHYDQW SURYLVLRQV
RI'LUHFWLYH(&

Before using6
Before using
1
Warning
Do not place the device near
the children.
y Children may hurt by
stepping accessories
Be sure whether there is any
obstacle when using the
device.
y There is a danger of
accident.
Do not check your device
while driving.
y Check the device in safe
place for your safety.
Do not place the device and
accessories near/in heating
appliance.
y It may cause deformation.
Do not let children put the
device in his/her mouth.
y Children may swallow a
small part of the device in
curiosity because the parts
are small. When the child
swallows the part, see a
doctor immediately after
giving first-aid.
y There is a danger of electric
shock or damage of the
product.
Disconnect the AC adapter
and the cable in case of a
lightning or thunder.
y Otherwise, an electric shock
may occur.

Before using 7
Before using
1
Caution
Read the web manual and
quick guide offered in the box
before using the device.
y Otherwise, there is a
possibility of malfunction
or failure of the product.
Do not place an object on the
product.
y It may cause failure.
Do not place the device near a
magnet or within the
magnetic field.
y It may cause failure.
Do not disassemble, repair, or
remodel the product.
y There is a danger of
damage or failure.
Do not drop an object or give
shock on the product.
y LCD may be broken.
y There is a danger of
damage or failure.
Do not soak the product in
the water.
y There is a danger of
electric shock or failure.
Maintenance
Cleaning the device
yClean the device with soft and dried cloth.
yWash the device by hand using a facial soap, neutral detergent, or wet tissue to clean the wristband.
yDo not use the strong chemicals included alcohol such as the benzene, thinner, FLUX, oil.
Handling the device
yManage the device as carefully as possible not to expose to the water because this device is not
designed to be used underwater or come into continuous contact with water.
yIn case that ooding label is discolored, free repair may not be oered when visiting our service
center because of product failure.
 Dry off the water before wearing the wristband.
it can cause skin trouble or itchy.
 Do not perform Bluetooth operation near the medical appliance,
because it may cause electromagnetic interference.

Table of Contents8
Table of Contents
1 Before Using
2 Safety Information
7 Maintenance
2 Using the LG Lifeband Touch
10 LG Lifeband Touch is your friend
10 Contents in the package
11 Product Overview
12 Charging battery
12 - Using the USB gender
12 - Checking battery status
13 - Checking charging battery status
13 - Battery charging time and average battery usage time
14 - Low Battery Warning
14 Choose your size
15 Wearing the LG Lifeband Touch
15 - Using Gesture function
3 Starting the LG Lifeband Touch App
16 Device registration and sign up
16 - Step 1 Installing the LG Fitness app
16 - Step 2 Device registration
17 - Step 3 Sign Up
17 - Reconnecting Bluetooth

4
Table of Contents 9
1
2
3
5
6
4 Operating the LG Lifeband Touch
18 Check the function of the button
18 - Bluetooth connection setting
18 - Select the hand to wear
19 - Turning o the power
19 - Auto Restarting
20 OLED touch display information
20 - Changing the mode
21 Mode Overview
21 - Time mode
22 - Activity mode
23 - Music control mode
24 - Using Workout
27 Alert
27 - Checking an incoming call
29 - Checking the received message (Android only)
30 - Checking Alarm
30 - Notication message information
31 Updating LG Lifeband Touch rmware
33 LED Indications
5 Using the LG Lifeband Touch App
34 How to use LG Fitness app
34 - Home menu
36 - Activity
38 - Workout
39 - More
6 Support
44 Frequently Asked Question (FAQ)
46 Smartphone compatibility list
46 Open source software notice
47 Specication

Using the LG Lifeband Touch10
Using the LG Lifeband Touch
2
LG Lifeband Touch is your friend
yLG Lifeband Touch helps you to check daily activity goal achievement rate and consumed calories
in real time for eective management by oering your hourly activity pattern, range and goal
achievement progress.
yLG Lifeband Touch shows not only the activity record in specic time(time, calories, step, speed, pace)
but also detailed information such as the activity course, speed, pace graph using the app.
yLG Lifeband Touch informs you of not only receipt of calls and messages but also time, date and
remaining battery in real time, and allows to play music.
yLG Lifeband Touch can be connected to your smartphone via Blutooth(Bluetooth 4.0).
.How LG Lifeband Touch works
yLG Lifeband Touch can detect human’s minute movement using 3-axis accelerometer sensor, and
calculate user’s consumed calories base on the user’s body information such as height, age, weight
and gender by analyzing user’s everyday activity such as steps, distance, time and intensity.
yLG Lifeband Touch motivates you to work out by sending the cheering message when you stay
moveless for a long.
Contents in the package
LG Lifeband Touch USB gender
USB cable Quick setup guide/
Warranty card

Using the LG Lifeband Touch 11
Using the LG Lifeband Touch
2
Product Overview
Display:
Shows detailed information. Swipe left or right
and touch to select an item.
Menu button:
Holding down or pressing the Menu button will
allow you to access dierent menu functions.
LED:
Shows information such as Goal achievement
rate.
When powering on the LG Lifeband Touch for the rst time, press and hold the Menu button for 2
seconds.
, Note

Using the LG Lifeband Touch12
Using the LG Lifeband Touch
2
Charging battery
Using the USB gender
You can charge LG Lifeband Touch using the USB gender.
1. Connect the USB gender to LG Lifeband Touch.
2. Connect the USB cable to the USB gender.
3. Connect the adapter to the USB cable.
Adapter
is not
supplied.
a
b c
4. Battery of the device will be charged with the display to show you.
yFully charge the device before using for the rst time.
yTo use LG Lifeband Touch for the rst time or after leaving for long, charge the battery rst before
use.
yThe battery can be charged even if LG Lifeband Touch is connected to PC using the USB cable.
yTo charge this product, you must always use a DC 5V, 100mA or more. Certied /Listed Adapter
which complies with LPS.
, Note
Checking battery status
1. Press Menu button to select Time mode.
2. Swipe the screen in Time mode to check remaining battery.
Battery
Status Battery indicator LED indicator Battery Status Battery indicator LED indicator
Less than
10 %
Red / Blinks.
Less than
60 % -
Less than
20 % -Less than
80 % -
Less than
40 % -more than
81 % -

Using the LG Lifeband Touch 13
Using the LG Lifeband Touch
2
Checking charging battery status
Check Battery icons on the displays as below during charging.
Battery
Status Battery indicator LED indicator
more
than 33
%
/ /
Red / Turned on during
LED display time
more
than 66
%
/ /
more
than 99
%
/ /
Charged
Green / Turned on
during LED display time
yWhen the battery is low, LED indicator blinks. Charging the battery is needed.
yWhen the battery is empty, the screen is turned o automatically.
yTo use LG Lifeband Touch for the rst time or after leaving for long, charge the battery rst before
use.
yIf you use USB HUB, the bettery may not be charged.
yOperating temperature of LG Lifeband Touch is -15 °C ~ 45 °C. The battery capacity may decrease
if you use in too high or low temperature.
yYou can set [Screen auto-o time] on the LG Fitness app. [More /LG Lifeband Touch Settings]
, Note
Battery charging time and average battery usage time
Battery charging
time 3 hours to fully charge battery
Average battery
usage time (when
fully charged)
If the smartphone is not connected : up to 5 days
If the smartphone is connected : up to 2 days

Using the LG Lifeband Touch14
Using the LG Lifeband Touch
2
14
Low Battery Warning
LED blinks red when remaining battery is less than 10%.
LG Lifeband Touch is turned o with [TURNING OFF] message when the battery is empty.
Choose your size
LG Lifeband Touch’s size is dierent depending on the model. Please check before purchasing.
You can choose the size of LG Lifeband Touch to t your wrist.
Circumference
166 mm
Circumference
181 mm
Circumference
196 mm
BM BL BX

Using the LG Lifeband Touch 15
Using the LG Lifeband Touch
2
15
Wearing the LG Lifeband Touch
Stretch the band to t your wrist.
Do not bend or unfurl excessively. The product may be damaged.
, Note
Using Gesture function
Make a gesture as if to look at the watch after wearing LG Lifeband Touch. The screen is turned on
automatically. The screen is turned o when you bring your arm down.
You can set [Automatic screen on/o] in [More/LG Lifeband Touch Settings] on LG Fitness app.
Refer to the description about Enable Gestures function on LG Lifeband Touch settings. (Refer to
page 40.)
, Note

Starting the LG Lifeband Touch App16
Starting the LG Lifeband Touch App
3
Device registration and sign up
Step 1 Installing the LG Fitness app
1. Search for“LG Fitness”in Play Store (Android phone) or App Store (iPhone).
2. Install “LGFitness”app.
Step 2 Device registration
1. Run the“LG Fitness”app.
2. Touch [Sign Up] in the screen.
Select [Sign In] if you have already signed up or want to log in with your facebook ID.
3. Set Bluetooth setting to“Enable”or“On”before searching for the device.
4. Be sure that LG Lifeband Touch is turned on and select [Search] of [LG Lifeband Touch] tab
on the LG Fitness app.
5. [Pairing? /YES | NO] appears on the screen. Touch [YES].
6. Once the device registration is completed normally, [Paired] appears on the screen.
yThe way of Bluetooth setting may dier depending on the smartphone manufacturer.
yTo connect with the smartphone, touch [YES] within 10 seconds. In case that the connection is
failed, repeat step 4 and step 5.
, Note

Starting the LG Lifeband Touch App 17
Starting the LG Lifeband Touch App
3
Step 3 Sign Up
* Enter each of the items and select [Next] to go to next page.
1. Enter the e mail ID and password to use.
2. Read the access terms and the privacy policy information, and select “agree”.
3. Enter your gender, birthday, height and weight.
4. Set your Daily goal.
Daily goal can be changed on [Home] or [More] whenever you want.
, Note
Reconnecting Bluetooth
yTo reconnect to the smartphone, turn Bluetooth setting [OFF] and [ON] again by pressing and holding
for 2 seconds the Menu button when the app is running.
/ /
yPairing is kept even if the Bluetooth connection on your smartphone is turned o and on again.

Operating the LG Lifeband Touch18
Operating the LG Lifeband Touch
4
18
Check the function of the button
Bluetooth connection setting
1. Press and hold Menu button for 2 seconds after turning on the LG Lifeband Touch.
2. [BLUETOOTH] appears with rst vibration.
3. Touch [ON] or [OFF] on the screen.
yTo use LG Lifeband Touch connecting your smartphone, select [ON]. Bluetooth icon appears on
the time screen when the device is connected with the smartphone.
yTo use LG Lifeband Touch without connection to your smartphpone, select [OFF].
(Use for battery saving)
When you purchase LG Lifeband Touch, it’s Bluetooth setting is [ON] and connection to your
smartphone is available.
, Note
Select the hand to wear
Select which hand to wear. It oers optimized measurement algorithm and on-screen display.
1. Press and hold the menu button for 4 seconds after turning on the LG Lifeband Touch.
2. [L/R WRIST] mode appears with the second vibration.

Operating the LG Lifeband Touch 19
Operating the LG Lifeband Touch
4
19
3. Touch [LEFT] or [RIGHT] on the screen.
Turning off the power
1. Press and hold Menu button for 6 seconds after turning on the LG Lifeband Touch.
2. [POWER] mode appears with third vibration.
3. Touch [OFF] on the screen to turn o the power.
Turn o the power and press and hold the menu button for 2 seconds. LG Lifeband Touch is
turned on again.
, Note
Auto Restarting
In case that the device is frozen because of an error while using, Press and hold the menu button for
about 10 seconds.
The clock screen and saved data remains even if the synchronized device is restarted
automatically.
, Note

Operating the LG Lifeband Touch20
Operating the LG Lifeband Touch
4
OLED touch display information
Changing the mode
Press the menu button when the screen turned o and the screen is turned on.
Press the menu button again when the screen turned on. 3 types of mode appears in rotation.
Display
Time mode
Activity mode
Music Control mode
yLG Lifeband Touch should be connected to your smartphone at least once to display Time
and date.
yLG Lifeband Touch should be connected to your smartphone via Bluetooth to control the
Music.
, Note
