LG Multi V CRUN Series User manual

System
Heat Pump Outdoor Unit
INSTALLATION MANUAL
LG
MODELS: CRUN Series
website http://www.lgservice.com
e-mail http://www.lgeservice.com/techsup.html
IMPORTANT
• Please read this installation manual completely before
installing the product.
• Installation work must be performed in accordance with
the national wiring standards by authorized personnel
only.
• Please retain this installation manual for future reference
after reading it thoroughly.
ENGLISH ITALIANO ESPAÑOL FRANÇAIS DEUTSCH
PORTUGUESE

2Outdoor Unit
CRUN Series Outdoor Unit Installation Manual
TABLE OF CONTENTS
Safety Precautions.........................3
Installation Process.....................10
Combination of indoor and
Outdoor Units...............................11
Selection the Best Location........12
Installation Space ........................13
Lifting Method..............................16
Installation....................................17
Refrigerant Pipe Installation.......19
Elecrical wiring.............................33
Test Run........................................45
Appendix.......................................50
System Check List.......................58

Installation Manual 3
ENGLISH
Safety Precautions
Safety Precautions
To prevent injury to the user or other people and property damage, the following instructions must be followed.
■Be sure to read before installing the air conditioner.
■Be sure to observe the cautions specified here as they include important items related to safety.
■Incorrect operation due to ignoring instruction will cause harm or damage. The seriousness is classified by the
following indications.
■Meanings of symbols used in this manual are as shown below.
This symbol indicates the possibility of death or serious injury.
This symbol indicates the possibility of injury or damage to properties only.
Be sure not to do.
Be sure to follow the instruction.
Indicates a part which must be grounded.
Indicates that caution should be taken with rotating parts.
(This symbol is displayed on the main unit label.) <Color: Yellow>
Indicates that the main switch must be turned off before servicing.
(This symbol is displayed on the main unit label.) <Color: Blue>
Beware of electric shock
(This symbol is displayed on the main unit label.) <Color: Yellow>
Beware of hot surface
(This symbol is displayed on the main unit label.) <Color: Yellow>
Please pay attention to electric shock. And at servicing, please shut down
the power supply for both of Indoor Unit and Outdoor Unit.
ELV
WARNING Carefully read the labels affixed to the main unit.

4Outdoor Unit
Safety Precautions
Ask the dealer or an authorized technician to
install the air conditioner.
- Improper installation by
the user may result in
water leakage, electric
shock, or fire.
Install the air unit at a place that can with-
stand its weight.
- Inadequate strength may
cause the unit to fall
down, resulting in
injuries.
Use the specified cables for wiring. Make the
connections securely so that the outside force
of the cable is not applied to the terminals.
- Inadequate connection and fastening may gen-
erate heat and cause a fire.
Prepare for typhoons and other strong winds
and earthquakes and install the unit at the
specified place.
- Improper installation may cause the unit to top-
ple and result in injury.
Cautions before installation
Always use accessories specified by LG
Electronics.
- Ask an authorized tech-
nician to install the
accessories. Improper
installation by the user
may result in water leak-
age, electric shock, or
fire.
Never repair the unit. If the air conditioner
must be repaired, consult the dealer.
- If the unit is repaired
improperly, water leak-
age, electric shock, or
fire may result.
Do not touch the heat exchanger fins.
- Improper handling may
result in injury.
If refrigerant gas leaks during installation
work, ventilate the room.
- If the refrigerant gas
comes into contact with
a flame, poisonous
gases will be released.

Installation Manual 5
ENGLISH
Safety Precautions
Install the air conditioner according to this
Installation Manual.
- If the unit is installed improperly, water leakage,
electric shock, or fire may result.
Have all electric work done by a licensed
electrician according to "Electric Facility
Engineering Standard" and "Interior Wire
Regulations" and the instructions given in
this manual and always use a special circuit.
- If the power source
capacity is inadequate or
electric work is per-
formed improperly, elec-
tric shock and fire may
result.
Securely install the cover of control box and
the panel.
- If the cover and panel are not installed properly,
dust or water may enter the outdoor unit and fire
or electric shock may result.
When installing and moving the air condition-
er to another site, do not charge it with a
refrigerant different from the refrigerant
(R407C) specified on the unit.
- If a different refrigerant or air is mixed with the
original refrigerant, the refrigerant cycle may
malfunction and the unit may be damaged.
If the air conditioner is installed in a small
room, measures must be taken to prevent the
refrigerant concentration from exceeding the
safety limit when the refrigerant leaks.
- Consult the dealer regarding the appropriate
measures to prevent the safety limit from being
exceeded. Should the refrigerant leak and cause
the safety limit to be exceeded, hazards due to
lack of oxygen in the room could result.
When moving and reinstalling the air condi-
tioner, consult the dealer or an authorized
technician.
- If the air conditioner is installed improperly, water
leakage, electric shock, or fire may result.

6Outdoor Unit
Safety Precautions
Cautions before installation Site
Do not install the unit where combustible gas
may leak.
- If the gas leaks and accumulates around the
unit, an explosion may result.
Do not use the air conditioner where food,
pets, plants, precision instruments, or art-
work are kept.
- The quality of the food, etc. may deteriorate.
Do not use the air conditioner in special envi-
ronments.
- Oil, steam, sulfuric smoke, etc. can significantly
reduce the performance of the air conditioner or
damage its parts.
When installing the unit in a hospital, com-
munication station, or similar place, provide
sufficient protection against noise.
- The inverter equipment, private power generator,
high-frequency medical equipment, or radio
communication equipment may cause the air
conditioner to operate erroneously, or fail to
operate. On the other hand, the air conditioner
may affect such equipment by creating noise
that disturbs medical treatment
or image broadcasting.
After completing installation work, make sure
that refrigerant gas is not leaking.
- If the refrigerant gas leaks and is exposed to a
fan heater, stove, oven, or other heat source, it
may generate noxious gases.
Do not reconstruct or change the settings of
the protection devices.
- If the pressure switch, thermal switch, or other
protection device is shorted and operated
forcibly, or parts other than those specified by
LG Electronics are used, fire or explosion may
result.
Gasolin

Installation Manual 7
Safety Precautions
ENGLISH
Do not install the outdoor unit at the outside
of apartment balcony or veranda or the site
of the same installation condition
Do not install the unit beside or on the footway
which may be flooded or submerged and may
be an obstructions for pedestrians to walk.
- In case that inevitably
install the unit beside the
footway, it may cause a
problem for your neigh-
bors.
Do not install the unit on a structure that may
cause leakage.
- When the room humidity
exceeds 80% or when the
drain pipe is clogged, con-
densation may drip from the
indoor unit. Perform collec-
tive drainage work together
with the outdoor unit, as
required.
Take measures to prevent children from
touching the unit.
- Injuries such as cuts could occur if a child
touches the surface of the fins on the heat
exchanger.
Cautions for electrical work and movement
Ground the unit.
- Do not connect the
ground wire to gas or
water pipes, lightning
rods, or telephone
ground lines. Improper
grounding may result in
electric shock.
Install the power cable so that tension is not
applied to the cable.
- Tension may cause the
cable to break and gen-
erate heat and cause a
fire.
Install a leakage circuit breaker, as required.
- If a leakage circuit breaker is
not installed,
electric shock may result.
Use power cables of sufficient current carry-
ing capacity and rating.
- Cables that are too small
may leak, generate heat,
and cause a fire.

8Outdoor Unit
Safety Precautions
Be careful that the installation base is not
damaged by long use.
- If the damage is left uncorrected, the unit may
fall and cause personal injury or property
damage.
Install the drain piping according to this
Installation Manual to ensure proper
drainage. Wrap thermal insulation around the
pipes to prevent condensation.
- Improper drain piping may cause water leakage
and damage to furniture and other possessions.
Be very careful about product transportation.
- Only one person should not carry the product if it weighs more than 20 kg.
- Some products use PP bands for packaging. Do not use any PP bands for a
means of transportation. It is dangerous.
- Do not touch the heat exchanger fins, which may result in injury.
- When transporting the outdoor unit, suspend it at the specified positions on
the unit base. Also support the outdoor unit at four points so that it cannot slip
sideways.
Safely dispose of the packing materials.
- Packing materials, such as nails and other metal or wooden parts, may cause
stabs or other injuries.
- Tear apart and throw away plastic packaging bags so that children will not play
with them. If children play with a plastic bag which was not torn apart, they
face the risk of suffocation.
Use only a circuit breaker and fuse of the
specified capacity.
- A fuse or circuit breaker of a larger capacity or a
steel or copper wire may result in a general unit
failure or fire.
Do not wash the air conditioner units.
- Washing them may cause an electric shock.

Installation Manual 9
Safety Precautions
ENGLISH
Cautions before the test run
Turn on the power at least 12 hours before
starting operation.
- Starting operation immediately after turning on
the main power switch can result in severe dam-
age to internal parts. Keep the power switch
turned on during the operational season.
Do not touch the switches with wet fingers.
- Touching a switch with wet fingers can cause an
electric shock.
Do not touch the refrigerant pipes during and
immediately after operation.
- During and immediately after operation, the
refrigerant pipes may be hot or cold, depending
on the condition of the refrigerant flowing
through the refrigerant piping, compressor, and
other refrigerant cycle parts. Your hands may
suffer burns or frost-bite if you touch the refriger-
ant pipes.
Do not operate the air conditioner with the
panels and guards removed.
- Rotating, hot, or high-voltage parts can cause
injuries.
Do not turn off the power immediately after stopping operation.
- Always wait at least five minutes before turning off the power.
Otherwise, water leakage and trouble may occur.

Indicate clearly who is to be responsible for switch settings.
Make relationship between outdoor, indoor, remote controller,
and option connections clear.(Prepare control circuit diagram)
Take account of gradient of drain piping.
Check model name to make sure the fitting is made correctly.
Special attention to dryness, cleanness and tightness.
Adjust to downward gradient.
Make sure airflow is sufficient.
Make sure no gaps are left where the insulating materials
are joined.
Multiple core cable must not be used.(suitable cable should
be selected)
The foundation must be level.
Avoid short circuits and ensure sufficient space is allowed
for service.
In the final check for 24hours at 3MPa(30.0 kg/cm2) there
must be no drop in pressure.
The vacuum pump must have a capacity of reaching at
least 5mmHg, 3hours
Recharge correctly as calculated in this manual,
and record the amount of additional refrigerant.
Make sure there are no gaps left between the facing mate-
rials used on the ceiling.
Refer to automatic addressing flowchart.
Run each indoor unit in turn to make sure the pipe work
has been fitted correctly.
Explain the use of the system as clearly as possible to your cus-
tomer and make sure all relevant documentation is in order.
10 Outdoor Unit
Installation Process
Installation Process
Determination of division work
Preparation of contract drawings
Sleeve and insert work
Installation of indoor unit
Refrigerant piping work
Drain pipe work
Duct work
Heat insulation work
Electrical work
(connection circuits and drive circuits)
Outdoor unit foundation work
Installation of outdoor unit
Automatic addressing of indoor unit
All tight test
Vacuum drying
Additional charge of refrigerant
Fit facing panels
Test run adjustment
Transfer to customer with explanation
The above list indicates the order in which the individual work operations are normally carried out but this order
may be varied where local conditions warrants such change.

Installation Manual 11
ENGLISH
Combination with indoor and Outdoor Units
Combination with indoor and Outdoor Units
- The total capacity index of indoor units is the sum of capacity index of each units and should be within the
capacity index of the outdoor unit.
Model Name of Outdoor Unit
22 ~ 50 (50 ~115%)
Range of Total Capacit Index
CRUN458S0
CRUN1008T0 48~125 (50 ~ 130%)
Index
Model Name of Indoor Unit
kW Btu/h
7
Ceiling
Mounted
Cassette
T pe(one wa )
Ceiling
Mounted
Cassette
T pe(four wa )
2.1 7,000 CRNN076TCA0 CRNN076BNG0
CRNN096BJG0
CRNN286BGA0
CRNN366BGA0
CRNN426BGA0
CRNN486BEA0
CRNN126BJG0
Capacit
-
9 2.6 9,000 CRNN096TCA0 -
12 3.5 12,000 CRNN126TCA0
18 5.3 18,000 -
24 7.0 24,000 -
28 8.2 28,000 -
36 10.6 36,000 CRNN366TDA0 -
42 12.3 42,000 -
CRNN126TEA0
CRNN186TEA0
CRNN246TDA0
CRNN286TDA0
CRNN426TDA0
CRNN486TDA0
-
-
-
-
-
48 14.1 48,000 --
Wall Mounted
T pe
Floor Standing
T pe
(With Case)
Art Cool T peConvertible
T pe
Index
Model Name of Indoor Unit
kW Btu/h
7,000
Capacit
9,000
12,000
18,000
24,000
-
CRNN096SP*0
-
-
-
CRNN076SRA0
CRNN096SRA0
CRNN126SRA0
CRNN186STA0
-
-
CRNN126SV*0
CRNN186SV*0
CRNN076CAA0
CRNN096CBA0
CRNN076SU*0
CRNN096SU*0
CRNN126CBA0
CRNN186CCA0
CRNN246CDA0
CRNN126SP*0
Art Cool T pe
(Wide)
-
CRNN126SU*0
Art Cool T pe
(Deluxe)
-
-
7 2.1
9 2.6
12 3.5
18 5.3
24 7.0
Ceiling
concealed Duct
T pe
(Low-Static)
Ceiling
concealed Duct
T pe
(High-Static)
CRNN186BHA0
CRNN246BHA0
-
-
-
-
-
-
CRNN246VBA0
CRNN186VBA0
Note:
1. The mark [*] presents the color of the front panel.
Art Cool Type/Art Cool Type(Wide)
B: Blue D: Wood M: Metal
Art Cool Type(Deluxe)
R: Mirror G: Gold B: Blue
2. Combinations in which the total capacity of the connected indoor units exceeds the capacity of the outdoor unit will reduce the capacity
of each indoor unit below the rated capacity during simultaneous operation. Therefore, if circumstances allows, combine indoor units
within the capacity of outdoor unit.

12 Outdoor Unit
Select the Best Location
Select the Best Location
Select space for installing outdoor unit, which will meet the following conditions:
• No direct thermal radiation from other heat sources
• No possibility of annoying the neighbors by noise from unit
• No exposition to strong wind
• With strength which bears weight of unit
• Note that drain flows out of unit when heating
• Space out for air passage and service work.
Do not install unit to the space where generation, inflow, stagnation, and leak of combustible gas is expected.
• Avoid unit installation in a place where acidic solution and spray (sulfur) are often used.
• Do not use unit under any special environment where oil, steam and sulfuric gas exist.
• Installation restriction on outdoor unit when the outdoor air temperature is -5°C or lower on cooling operation.
• It is recommended to fence round the outdoor unit in order to prevent any person or animal from accessing the
outdoor untit.
• If installation site is area of heavy snowfall, then the following directions should be observed.
- Make the foundation as high as possible.
- Fit a snow protection hood.

Installation Manual 13
Installation Space
ENGLISH
Installation Space
Individual Installation
For CRUN1008T0
Basic space required
A space of at least 250 mm is necessary at the back for inlet air. Taking servicing, etc. from the rear into
account, a space of about 500 mm should be provided, the same as at the front.
When inlet air enters from right and left sides of unit
When unit is surrounded by walls
<Side view>
D
C
A
A
B
C
D
A
C
B
B
500 mm or more
250 mm or more
Back(HEX side)
150 mm from the wall
500 mm or more
250 mm or more
Back(HEX side)
A
B
C
C
A
B
B B
AB
C
H
H
A
F
B
D
E
E
F
C
250 mm or more
500 mm or more
Front panel
Top discharge (open in principle)
Side inlet (open in principle)
Rear inlet (open in principle)
A
B
C
D
E
F
<Top View> <Side View>

14 Outdoor Unit
Installation Space
For CRUN458S0
•If an awning is built over the unit to prevent direct
sunlight or rain exposure, be careful that heat radi-
ation from the condenser is not restricted.
•There should not be any animals or plants which
could be affected by hot air discharged.
•Ensure the spaces indicated by arrows from the
wall, ceiling, fence or other obstacles.
More than
30cm
More than
30cm
More than
70cm
Sunroof
Fence or
obstacles
When there is an obstruction above the unit
45°or more
300 mm or more
250 mm or more
1000 mm or more
Air outlet guide (Procured at the site)
250 mm or more
A
A
B
CE
D
F
B
C
D
E
F

Installation Manual 15
Installation Space
ENGLISH
Collective / Continuous installation
Space required for collective installation and continuous installation:When installing several units, leave
the space between each block as shown below considering passage for air and people.
C
A
A
B B B B B
C CC C E
D
A
E
A
B
CC
E
D
BD B B
(Must be open)
Front(panel side)
500 mm or more
150 mm or more
A
B
C
D
250 mm or more
E
600 mm or more
F
E E
D
A A
B
CC
D
BD B B
D
A A
B
CC
D
BD B B
E E
D
A A
B
EE
D
B
D
B B
D
A A
B
CC
D
BD B B
D
A A
B
C
C
C
C
D
BD B B
D
A A
B
FF
D
BD B B

16 Outdoor Unit
Lifting Method
•When carrying the unit suspended, pass the ropes under the unit and use the two suspension points each at
the front and rear.
•Always lift the unit with ropes attached at four points so that impact is not applied to the unit.
•Attach the ropes to the unit at an angle of 40°or less.
•Use two ropes at least 7 m long.
Lifting method
Weight of product:
CAUTION
Be very careful to carry product.
•Do not have only one person carry product if it is more than 20 kg.
•PP bands are used to pack some products. Do not use them as a mean for transportation because they
are dangerous.
•Do not touch heat exchanger fins with your bare hands. Otherwise you may get a cut in your hands.
•Tear plastic packaging bag and scrap it so that children cannot play with it. Otherwise plastic packaging
bag may suffocate children to death.
•When carrying in outdoor unit, be sure to support it at four points. Carrying in and lifting with 3-point sup-
port may make outdoor unit unstable, resulting in a fall of it.
CRUN1008T0 CRUN458S0
300 kg 125kg
40°or less
Rope suspension part
A
B
B
A

Installation Manual 17
Installation
ENGLISH
Location of anchor bolt
Installation
CRUN1008T0
•Example of collective installation
797±2
797±2
797
797±2 797±2
669±2
250
400 250 400
Installation foot
•Individual installation

18 Outdoor Unit
Installation
Foundation for Installation
CRUN1008T0
•Fix the unit tightly with bolts as shown below so that unit will not fall down due to earthquake or gust.
•Use concrete or angle for foundation of unit.
•Vibration may be transmitted to the installation section and noise and vibration may be generated from the
floor and walls, depending on the installation conditions. Therefore, provide ample vibrationproofing (cush-
ion pads, cushion frame, etc.).
A
B
C
D
E
Be sure that the corners are firmly seated. If the corners are not firmly
seated, the installation feet may be bent.
M10 anchor bolt procured at the site.
Corner is not seated.
Unit
(Provide ample vibrationproofing between the unit and the foundation by
using cushion pads, cushion frame, etc.)
Concrete foundation
A
B
D
E
C
WARNING
•Be sure to install unit in a place strong enough to withstand its weight.
Any lack of strength may cause unit to fall down, resulting in a personal injury.
•Have installation work in order to protect against a strong wind and earthquake. Any installation
deficiency may cause unit to fall down, resulting in a personal injury.
When building the foundation, give full attention to the floor strength, drain water disposal (during operation,
drain water flows out of the unit), and piping and wiring routes.

Installation Manual 19
Refrigerant piping installation
ENGLISH
Refrigerant piping installation
To Outdoor Unit
Capped Piping
AA
B
A
B
ARBL054 ARBL057
ARBL104 ARBL107 ARBL1010
Y branch Header
Less than 3.8kW(13,000 Btu/h)
~8.2kW(28,000 Btu/h)
~17.6kW(60,000 Btu/h)
17.6kW(60,000 Btu/h) or more
ARBL052S
ARBL052L
ARBL102S
ARBL102L
4 branch 7 branch 10 branch
-
The method of connection consists of flare connections at the indoor units, brazing connections for the piping of
the outdoor unit. Note that the branched sections are brazed.
WARNING
Always use extreme care to prevent the refrigerant gas (R407C) from the leakage while using fire or
flame. If the refrigerant gas comes in contact with the flame from any source, such as a gas stove, it
breaks down and generates a poisonous gas which can cause gas poisoning. Never weld in an
unventilated room. Always conduct an inspection for gas leakage after installation of the refrigerant
piping has been completed.
1. Use the following materials for refrigeration piping.
•Material: Seamless phosphorous deoxidized copper pipe
2. Commercially available piping often contains dust and other materials. Always blow it clean with a
dry inert gas.
3. Use care to prevent dust, water or other contaminants from entering the piping during installation.
4. Reduce the number of bending portions as much as possible, and make bending radius as big as
possible.
5. Always use the branch piping set shown below, which are sold separately.
6. If the diameters of the branch piping of the designated refrigerant piping differs, use a pipe cutter to cut
the connecting section and then use an adapter for connecting different diameters to connect the piping.
7. Always observe the restrictions on the refrigerant piping (such as rated length, the difference between
high/low pressures, and piping diameter).
Failure to do so can result in equipment failure or a decline in heating/cooling performance.
8. A second branch cannot be made after a header. (These are shown by X.)
Areas of caution

20 Outdoor Unit
Refrigerant piping installation
9. Always use good-quality materials for brazing.
10. The Multi V Series will stop due to an abnormality like excessive or insufficient refrigerant. At such a time,
always properly charge the refrigerant to the system. When servicing, always check the notes concerning
pipe length and amount of additional refrigerant at both locations.
11. Never perform a pump down. This will not only damage the compressor but also deteriorate the per-
formance.
12. Never use refrigerant to perform an air purge. Always evacuate using a vacuum pump.
13. Always insulate the piping properly. Insufficient insulation will result in a decline in heating/cooling perfor-
mance, water drops from condensation and other such problems.
14. When connecting the refrigerant piping, make sure the service valves of the outdoor unit is completely
closed (the factory setting) and do not operate it until the refrigerant piping for the outdoor and indoor units
has been connected, a refrigerant leakage test has been performed and the evacuation process has been
completed.
15. Always use a non-oxidizing brazing material for brazing the parts. If a non-oxidizing brazing material is not
used, it could cause clogging or damage to the compressor unit.
16. Charge Nitrogen gas for pipe not to be oxidized during brazing.
17. Connect a strainer (Filter/Drier) to liquid pipe outside of service port
- strainer (Filter/Drier): DANFOSS product.
18. When recharging refrigerant, the drier in outdoor unit should be replaced.
WARNING
When installing and moving the air conditioner to another site, be sure to make refrigerant recharged
after perfect evacuation.
- If a different refrigerant or air is mixed with the original refrigerant, the refrigerant cycle may malfunction and
the unit may be damaged.
CAUTION
When connecting the piping from outdoor unit(CRUN1008T0), the pipe withdraw hole of front panel
should be cut, the cutout section is so sharp that it may cause an wound on finger.
- The cut section should be eliminated and smooth.
: Cut section
