LG LHD457B Specification sheet

www.lg.com
ENGLISH
SIMPLE MANUAL
DVD Home
Theater
System
To view the instructions of advanced features,
visit http://www.lg.com and then download Owner’s Manual.
Some of the content in this manual may differ from your unit.
MODEL
LHD457B
*MFL69573602*
Specication
Power
requirements Refer to main label.
Power
consumption
Refer to main label.
Networked standby : 0.5 W
(If all network ports are
activated.)
Dimensions
(W x H x D)
Approx. 360 mm x 58mm
x 293 mm
Net Weight Approx. 2.3 kg
Bus Power Supply
(USB) 5 V 0 500 mA
Amplier
(Total RMS output
power)
330 W
Design and specications are subject to change without
notice.
How to disconnect the wireless network
connection or the wireless device
Turn off the unit by pressing the power button for more
than 5 seconds.
Replacement of battery
POWER: This unit operates on a mains supply of
200 - 240 V ~, 50 / 60 Hz.
Wiring: This unit is supplied with a BS 1363 approved main plug.
When replacing the fuse, always use of the same rating approved
to BS 1362. Never use this plug with the fuse cover omitted. To
obtain a replacement fuse cover contact your dealer. If the type of
plug supplied is not suitable for the mains sockets in your home,
then the plug should be removed and a suitable type tted. Please
refer to the wiring instructions below:
Warning: A mains plug removed from the mains lead of this unit
must be destroyed. A mains plug with bared wires is hazardous
if inserted in a mains socket. Do not connect either wire to the
earth pin, marked with the letter E or with the earth symbol 6or
coloured green or green and yellow. If any other plug is tted, use
same rating of fuse in the plug.
Important: The wires in this mains lead are coloured in accordance
with the following codes:
- BLUE: NEUTRAL, BROWN: LIVE - As the colours of the wires in
the mains lead of this unit may not correspond with the coloured
marking identifying the terminals in your plug, proceed as follows:
The wire which is coloured blue must be connected to the terminal
which is marked with the letter N or coloured black. The wire which
is coloured brown must be connected to the terminal which is
marked with the letter L or coloured red.
Additional Information
LHD457-FC_ANGAFLK_SIM_ENG_3602.indd 1-2 2016-05-30  3:19:51

Front Panel Rear Panel
MIC 1/2···················· Connect a microphone.
PORT. IN ··············Connect to a Portable device.
USB Port····················Connect a USB device.
R··························Disc Tray Open / Close
T·······················Starts / Pauses playback.
I·································Stops playback.
F············· Changes the input source or function.
VOL. ······························Adjusts volume.
1·································Power On / Off
SPEAKERS ··················· Connect to speakers.
HDMI OUT TO TV··················· Connect to TV.
VIDEO OUT ························ Connect to TV.
AUX (L/R) INPUT······ Connect to analogue device.
ANTENNA FM ·········· Connect to radio antenna.
Home menu appears on the TV screen. Enjoy various
functions on the unit.
TV Connection3Home Menu4
HDMI Connection
aConnect the unit to the TV using HDMI cable.
bSet the input selector to HDMI on the TV.
cFollow the instructions on the TV screen
using remote control.
Speaker design and connection method may
be different according to models.
,
Speaker Connection2Speaker Assembling1
For more information, download the online owner’s manual. http://www.lg.com
Front
(Right)
Front
(Left)
Center
Subwoofer
Unit
Surround
(Left) Surround
(Right)
