LCD TV

SERVICE MANUAL

CAUTION

BEFORE SERVICING THE CHASSIS,

READ THE SAFETY PRECAUTIONS IN THIS MANUAL.

CHASSIS : LP91A

MODEL : 22LU50R 22LU50R-MB

North/Latin America http://aic.lgservice.com

Europe/Africa http://eic.lgservice.com

Asia/Oceania http://biz.lgservice.com

Internal Use Only

Printed in KoreaP/NO : MFL60021542 (0906-REV00)

Only for training and service purposes LGE Internal Use Only

- 2 -

CONTENTS

CONTENTS .............................................................................................. 2

PRODUCT SAFETY ..................................................................................3

SPECIFICATION........................................................................................6

ADJUSTMENT INSTRUCTION................................................................11

TROUBLE SHOOTING............................................................................16

BLOCK DIAGRAM...................................................................................19

EXPLODED VIEW .................................................................................. 20

SVC. SHEET ...............................................................................................

Only for training and service purposes LGE Internal Use Only

- 3 -

SAFETY PRECAUTIONS

Many electrical and mechanical parts in this chassis have special safety-related characteristics. These parts are identified by in the

Schematic Diagram and Exploded View.

It is essential that these special safety parts should be replaced with the same components as recommended in this manual to prevent

Shock, Fire, or other Hazards.

Do not modify the original design without permission of manufacturer.

General Guidance

An isolation Transformer should always be used during the

servicing of a receiver whose chassis is not isolated from the AC

power line. Use a transformer of adequate power rating as this

protects the technician from accidents resulting in personal injury

from electrical shocks.

It will also protect the receiver and it's components from being

damaged by accidental shorts of the circuitry that may be

inadvertently introduced during the service operation.

If any fuse (or Fusible Resistor) in this TV receiver is blown,

replace it with the specified.

When replacing a high wattage resistor (Oxide Metal Film Resistor,

over 1W), keep the resistor 10mm away from PCB.

Keep wires away from high voltage or high temperature parts.

Before returning the receiver to the customer,

always perform an AC leakage current check on the exposed

metallic parts of the cabinet, such as antennas, terminals, etc., to

be sure the set is safe to operate without damage of electrical

shock.

Leakage Current Cold Check(Antenna Cold Check)

With the instrument AC plug removed from AC source, connect an

electrical jumper across the two AC plug prongs. Place the AC

switch in the on position, connect one lead of ohm-meter to the AC

plug prongs tied together and touch other ohm-meter lead in turn to

each exposed metallic parts such as antenna terminals, phone

jacks, etc.

If the exposed metallic part has a return path to the chassis, the

measured resistance should be between 1MΩand 5.2MΩ.

When the exposed metal has no return path to the chassis the

reading must be infinite.

An other abnormality exists that must be corrected before the

receiver is returned to the customer.

Leakage Current Hot Check (See below Figure)

Plug the AC cord directly into the AC outlet.

Do not use a line Isolation Transformer during this check.

Connect 1.5K/10watt resistor in parallel with a 0.15uF capacitor

between a known good earth ground (Water Pipe, Conduit, etc.)

and the exposed metallic parts.

Measure the AC voltage across the resistor using AC voltmeter

with 1000 ohms/volt or more sensitivity.

Reverse plug the AC cord into the AC outlet and repeat AC voltage

measurements for each exposed metallic part. Any voltage

measured must not exceed 0.75 volt RMS which is corresponds to

0.5mA.

In case any measurement is out of the limits specified, there is

possibility of shock hazard and the set must be checked and

repaired before it is returned to the customer.

Leakage Current Hot Check circuit

1.5 Kohm/10W

To Instrument’s

exposed

METALLIC PARTS

Good Earth Ground

such as WATER PIPE,

CONDUIT etc.

AC Volt-meter

When 25A is impressed between Earth and 2nd Ground

for 1 second, Resistance must be less than 0.1

*Base on Adjustment standard

IMPORTANT SAFETY NOTICE

0.15uF

Ω

Only for training and service purposes LGE Internal Use Only

- 4 -

CAUTION: Before servicing receivers covered by this service

manual and its supplements and addenda, read and follow the

SAFETY PRECAUTIONS on page 3 of this publication.

NOTE: If unforeseen circumstances create conflict between the

following servicing precautions and any of the safety precautions on

page 3 of this publication, always follow the safety precautions.

Remember: Safety First.

General Servicing Precautions

1. Always unplug the receiver AC power cord from the AC power

source before;

a. Removing or reinstalling any component, circuit board

module or any other receiver assembly.

b. Disconnecting or reconnecting any receiver electrical plug or

other electrical connection.

c. Connecting a test substitute in parallel with an electrolytic

capacitor in the receiver.

CAUTION: A wrong part substitution or incorrect polarity

installation of electrolytic capacitors may result in an

explosion hazard.

2. Test high voltage only by measuring it with an appropriate high

voltage meter or other voltage measuring device (DVM,

FETVOM, etc) equipped with a suitable high voltage probe.

Do not test high voltage by "drawing an arc".

3. Do not spray chemicals on or near this receiver or any of its

assemblies.

4. Unless specified otherwise in this service manual, clean

electrical contacts only by applying the following mixture to the

contacts with a pipe cleaner, cotton-tipped stick or comparable

non-abrasive applicator; 10% (by volume) Acetone and 90% (by

volume) isopropyl alcohol (90%-99% strength)

CAUTION: This is a flammable mixture.

Unless specified otherwise in this service manual, lubrication of

contacts in not required.

5. Do not defeat any plug/socket B+ voltage interlocks with which

receivers covered by this service manual might be equipped.

6. Do not apply AC power to this instrument and/or any of its

electrical assemblies unless all solid-state device heat sinks are

correctly installed.

7. Always connect the test receiver ground lead to the receiver

chassis ground before connecting the test receiver positive

lead.

Always remove the test receiver ground lead last.

8. Use with this receiver only the test fixtures specified in this

service manual.

CAUTION: Do not connect the test fixture ground strap to any

heat sink in this receiver.

Electrostatically Sensitive (ES) Devices

Some semiconductor (solid-state) devices can be damaged easily

by static electricity. Such components commonly are called

Electrostatically Sensitive (ES) Devices. Examples of typical ES

devices are integrated circuits and some field-effect transistors and

semiconductor "chip" components. The following techniques

should be used to help reduce the incidence of component

damage caused by static by static electricity.

1. Immediately before handling any semiconductor component or

semiconductor-equipped assembly, drain off any electrostatic

charge on your body by touching a known earth ground.

Alternatively, obtain and wear a commercially available

discharging wrist strap device, which should be removed to

prevent potential shock reasons prior to applying power to the

unit under test.

2. After removing an electrical assembly equipped with ES

devices, place the assembly on a conductive surface such as

aluminum foil, to prevent electrostatic charge buildup or

exposure of the assembly.

3. Use only a grounded-tip soldering iron to solder or unsolder ES

devices.

4. Use only an anti-static type solder removal device. Some solder

removal devices not classified as "anti-static" can generate

electrical charges sufficient to damage ES devices.

5. Do not use freon-propelled chemicals. These can generate

electrical charges sufficient to damage ES devices.

6. Do not remove a replacement ES device from its protective

package until immediately before you are ready to install it.

(Most replacement ES devices are packaged with leads

electrically shorted together by conductive foam, aluminum foil

or comparable conductive material).

7. Immediately before removing the protective material from the

leads of a replacement ES device, touch the protective material

to the chassis or circuit assembly into which the device will be

installed.

CAUTION: Be sure no power is applied to the chassis or circuit,

and observe all other safety precautions.

8. Minimize bodily motions when handling unpackaged

replacement ES devices. (Otherwise harmless motion such as

the brushing together of your clothes fabric or the lifting of your

foot from a carpeted floor can generate static electricity

sufficient to damage an ES device.)

General Soldering Guidelines

1. Use a grounded-tip, low-wattage soldering iron and appropriate

tip size and shape that will maintain tip temperature within the

range or 500°F to 600°F.

2. Use an appropriate gauge of RMA resin-core solder composed

of 60 parts tin/40 parts lead.

3. Keep the soldering iron tip clean and well tinned.

4. Thoroughly clean the surfaces to be soldered. Use a mall wire-

bristle (0.5 inch, or 1.25cm) brush with a metal handle.

Do not use freon-propelled spray-on cleaners.

5. Use the following unsoldering technique

a. Allow the soldering iron tip to reach normal temperature.

(500°F to 600°F)

b. Heat the component lead until the solder melts.

c. Quickly draw the melted solder with an anti-static, suction-

type solder removal device or with solder braid.

CAUTION: Work quickly to avoid overheating the circuit

board printed foil.

6. Use the following soldering technique.

a. Allow the soldering iron tip to reach a normal temperature

(500°F to 600°F)

b. First, hold the soldering iron tip and solder the strand against

the component lead until the solder melts.

c. Quickly move the soldering iron tip to the junction of the

component lead and the printed circuit foil, and hold it there

only until the solder flows onto and around both the

component lead and the foil.

CAUTION: Work quickly to avoid overheating the circuit

board printed foil.

d. Closely inspect the solder area and remove any excess or

splashed solder with a small wire-bristle brush.

SERVICING PRECAUTIONS

Only for training and service purposes LGE Internal Use Only

- 5 -

IC Remove/Replacement

Some chassis circuit boards have slotted holes (oblong) through

which the IC leads are inserted and then bent flat against the

circuit foil. When holes are the slotted type, the following technique

should be used to remove and replace the IC. When working with

boards using the familiar round hole, use the standard technique

as outlined in paragraphs 5 and 6 above.

Removal

1. Desolder and straighten each IC lead in one operation by gently

prying up on the lead with the soldering iron tip as the solder

melts.

2. Draw away the melted solder with an anti-static suction-type

solder removal device (or with solder braid) before removing the

IC.

Replacement

1. Carefully insert the replacement IC in the circuit board.

2. Carefully bend each IC lead against the circuit foil pad and

solder it.

3. Clean the soldered areas with a small wire-bristle brush.

(It is not necessary to reapply acrylic coating to the areas).

"Small-Signal" Discrete Transistor

Removal/Replacement

1. Remove the defective transistor by clipping its leads as close as

possible to the component body.

2. Bend into a "U" shape the end of each of three leads remaining

on the circuit board.

3. Bend into a "U" shape the replacement transistor leads.

4. Connect the replacement transistor leads to the corresponding

leads extending from the circuit board and crimp the "U" with

long nose pliers to insure metal to metal contact then solder

each connection.

Power Output, Transistor Device

Removal/Replacement

1. Heat and remove all solder from around the transistor leads.

2. Remove the heat sink mounting screw (if so equipped).

3. Carefully remove the transistor from the heat sink of the circuit

board.

4. Insert new transistor in the circuit board.

5. Solder each transistor lead, and clip off excess lead.

6. Replace heat sink.

Diode Removal/Replacement

1. Remove defective diode by clipping its leads as close as

possible to diode body.

2. Bend the two remaining leads perpendicular y to the circuit

board.

3. Observing diode polarity, wrap each lead of the new diode

around the corresponding lead on the circuit board.

4. Securely crimp each connection and solder it.

5. Inspect (on the circuit board copper side) the solder joints of

the two "original" leads. If they are not shiny, reheat them and if

necessary, apply additional solder.

Fuse and Conventional Resistor

Removal/Replacement

1. Clip each fuse or resistor lead at top of the circuit board hollow

stake.

2. Securely crimp the leads of replacement component around

notch at stake top.

3. Solder the connections.

CAUTION: Maintain original spacing between the replaced

component and adjacent components and the circuit board to

prevent excessive component temperatures.

Circuit Board Foil Repair

Excessive heat applied to the copper foil of any printed circuit

board will weaken the adhesive that bonds the foil to the circuit

board causing the foil to separate from or "lift-off" the board. The

following guidelines and procedures should be followed whenever

this condition is encountered.

At IC Connections

To repair a defective copper pattern at IC connections use the

following procedure to install a jumper wire on the copper pattern

side of the circuit board. (Use this technique only on IC

connections).

1. Carefully remove the damaged copper pattern with a sharp

knife. (Remove only as much copper as absolutely necessary).

2. carefully scratch away the solder resist and acrylic coating (if

used) from the end of the remaining copper pattern.

3. Bend a small "U" in one end of a small gauge jumper wire and

carefully crimp it around the IC pin. Solder the IC connection.

4. Route the jumper wire along the path of the out-away copper

pattern and let it overlap the previously scraped end of the good

copper pattern. Solder the overlapped area and clip off any

excess jumper wire.

At Other Connections

Use the following technique to repair the defective copper pattern

at connections other than IC Pins. This technique involves the

installation of a jumper wire on the component side of the circuit

board.

1. Remove the defective copper pattern with a sharp knife.

Remove at least 1/4 inch of copper, to ensure that a hazardous

condition will not exist if the jumper wire opens.

2. Trace along the copper pattern from both sides of the pattern

break and locate the nearest component that is directly

connected to the affected copper pattern.

3. Connect insulated 20-gauge jumper wire from the lead of the

nearest component on one side of the pattern break to the lead

of the nearest component on the other side.

Carefully crimp and solder the connections.

CAUTION: Be sure the insulated jumper wire is dressed so the

it does not touch components or sharp edges.

Only for training and service purposes LGE Internal Use Only

- 6 -

SPECIFICATION

NOTE : Specifications and others are subject to change without notice for improvement

4. Electrical specification

4.1 General Specification

1. Application range

This spec sheet is applied to LCD TV used LP91A chassis.

2. Specification

Each part is tested as below without special appointment.

1) Temperature : 25±5ºC (77±9ºF), CST : 40±5ºC

2) Relative Humidity : 65±10%

Power Voltage : Standard input voltage(100~240V@50/60Hz)

* Standard Voltage of each products is marked by models.

4) Specification and performance of each parts are followed

each drawing and specification by part number in

accordance with BOM.

5) The receiver must be operated for about 5 minutes prior to

the adjustment.

3. Test method

1) Performance: LGE TV test method followed

2) Demanded other specification

- Safety: CE, IEC specification

- EMC : CE, IEC

No Item Specification Measurement Remark

1 Screen Size 22” wide Color Display Module Resolution: 1366*768

2 Aspect Ratio 16:9

3 LCD Module 22” TFT WXGA LCD

4 Operating Environment Temp.: 0 ~ 40 deg

Humidity : 0 ~ 80 %

5 Storage Environment Temp.: -20 ~ 60 deg

Humidity : 0~ 85 %

6 Input Voltage AC100-240V~, 50/60Hz

≤65 W 22” HD

7 LDC Module HD 626 x 373 x 44.1 with inverter

(Maker : LGD) 0.1405 x 0.4215

12 EEFL

Coating 3H

Only for training and service purposes

No. Item Min. Typ. Max. Unit Maker Remark

1. Luminance 280 350 cd/m2

(W/O PC mode)

2. VIew angle (R/L, U/D) 178 / 178 degree CR > 10

3. Color Coordinates White Wx Typ 0.285 Typ LGD 22”(HD)

Wy -0.03 0.293 +0.03 LC220WXE-TBA1

RED Xr 0.642

Yr 0.333

Green Xg 0.295

Yg 0.608

Blue Xb 0.147

Yb 0.063

4. Contrast ratio 700:1 1000:1 LGD 22”(HD)

5. Luminance Variation 1.3

- 7 - LGE Internal Use Only

5. Chroma& Brightness (Optical)

5.1. LCD Module

the Color Coordinates check condition

- 50cm from the surface, Full White Pattern

- Picture mode Vivid

8. Component Video Input (Y, PB, PR)

No Specification Remark

Resolution H-freq(kHz) V-freq(Hz) Pixel Clock(MHz)

1 720* 480 15.73 59.94 13.500 SDTV, DVD 480I( 525I)

2 720* 480 15.75 60.00 13.514 SDTV, DVD 480I( 525I)

3 720* 576 15.625 50.00 13.500 SDTV, DVD 576I( 625I) 50Hz

4 720* 480 31.47 59.94 27.000 SDTV 480P

5 720* 480 31.50 60.00 27.027 SDTV 480P

6 720* 576 31.25 50.00 27.000 SDTV 576P 50Hz

7 1280* 720 44.96 59.94 74.176 HDTV 720P

8 1280* 720 45.00 60.00 74.250 HDTV 720P

9 1280* 720 37.50 50.00 74.25 HDTV 720P 50Hz

10 1920* 1080 28.125 50.00 74.250 HDTV 1080I 50Hz,

11 1920* 1080 33.72 59.94 74.176 HDTV 1080I

12 1920* 1080 33.75 60.00 74.25 HDTV 1080I

13 1920* 1080 56.25 50 148.5 HDTV 1080P

14 1920* 1080 67.432 59.94 148.350 HDTV 1080P

15 1920* 1080 67.5 60.00 148.5 HDTV 1080P

Only for training and service purposes - 8 - LGE Internal Use Only

No Specification Remark

Resolution H-freq(kHz) V-freq(Hz) Pixel Clock(MHz)

1 640* 350 31.468 70.09 25.17 EGA

2 720* 400 31.469 70.09 28.32 DOS

3 640* 480 31.469 59.94 25.17 VESA( VGA)

4 800* 600 37.879 60.317 40 VESA( SVGA)

5 1024* 768 48.363 60.004 65 VESA( XGA)

6 1280* 768 47.776 59.87 79.5 VESA( WXGA)

7 1360* 768 47.72 59.799 84.75 VESA( WXGA)

8 1280* 1024 63.668 59.895 109.00 XGA Only FHD Model

9 1920* 1080 66.587 59.934 138.50 WUXGA(Reduced Blanking) Only FHD Model

9. RGB

9.1 Analog PC, RGB- DTV –NOT SUPPORT

10. HDMI Input

10.1 PC –Spec. out but it can be shown the picture at only HDMI/ DVI IN 1 via DVI to HDMI Cable)

No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed Remark

1 640 x 480 31.469 59.94 25.17 VESA( VGA)

2 800 x 600 37.879 60.317 40.00 VESA( SVGA)

3 1024 x 768 48.363 60.004 65.00 VESA( XGA)

4 1280 x 768 47.776 59.87 79.5 VESA( WXGA)

5 1360 x 768 47.72 59.799 84.62 VESA( WXGA)

6 1366 x 768 47.7 60.00 84.62 WXGA

7 1280 x 1024 63.595 60.00 108.875 SXGA

8 1920 x 1080 66.647 59.988 138.625 WUXGA

10.2 DTV Mode

No Specification Remark

Resolution H-freq(kHz) V-freq(Hz) Pixel Clock(MHz)

1 720 x 480 15.73 59.94 13.500 SDTV, DVD 480I(525I)

2 720 x 480 15.75 60.00 13.514 SDTV, DVD 480I(525I) Spec. out

3 720 x 576 15.625 50.00 13.500 SDTV, DVD 576I(625I) 50Hz but display.

4 720 x 480 31.47 59.94 27 SDTV 480P

5 720 x 480 31.5 60.00 27.027 SDTV 480P

6 720 x 576 31.25 50.00 27 SDTV 576P

7 1280 x 720 44.96 59.94 74.176 HDTV 720P

8 1280 x 720 45 60.00 74.25 HDTV 720P

9 1280 x 720 37.5 50.00 74.25 HDTV 720P

10 1920 x 1080 28.125 50.00 74.25 HDTV 1080I

11 1920 x 1080 33.72 59.94 74.176 HDTV 1080I

12 1920 x 1080 33.75 60.00 74.25 HDTV 1080I

13 1920 x 1080 56.25 50.00 148.5 HDTV 1080P

14 1920 x 1080 67.432 59.94 148.350 HDTV 1080P

15 1920 x 1080 67.5 60.00 148.5 HDTV 1080P

16 1920 x 1080 27 24.00 74.25 HDTV 1080P

17 1920 x 1080 33.75 30.00 74.25 HDTV 1080P

1) Gap between Front Frame /Back cover and Middle Cabinet

2) Gap between Front Frame /Middle Cabinet

Only for training and service purposes

Top View

Back Cover

Front Frame

Middle Cabinet

Gap b between Front Frame (Back cover) and Middle Cabinet

-> 0 †b †B (Side gap)

Gap a between Front Frame and Middle Cabine

-> 0 †a †A (Side gap)

Gap a between Front Frame and Middle Cabine

-> 0 †a †A (Left/ Right gap)

3) Gap between Back Cover and Side AV

Back View Side View

Side AV

Back Cover

Gap f between Back Cover and Side AV

-> 0 †f †1.0

Gap g between Back Cover and Side AV

-> 0 †g †1.0

11. Mechical spec.

No Item Min Typ Max Unit

1. C/ A + B/ C top gap 0.5 1 1.5 mm

2. C/ A + B/ C side gap 0.5 1 1.5 mm

3. C/ A + Deco Front gap( ONE SIDE). 0.8 1 1.2 mm

*Active area

1. Active area of LCD PANEL is in bezel of cabinet

2. Interval between active area and bezel

|A-B|< 2.0 mm ,|C-D|< 2.0 mm

A:Interval between left of active area and bezel

B:Interval between right of active area and bezel

C:Interval between top of active area and bezel

D:Interval between bottom of active area and beze

4)Gap between Back Cover and Side AV

Only for training and service purposes

Side View "h"

Control Braket

Back Cover

Gap h between Back Cover and Control Bracket

-> 0 †h †0.8

AActive Area

Bezel

Only for training and service purposes LGE Internal Use Only

- 11 -

ADJUSTMENT INSTRUCTION

1. Application Range

This specification sheet is applied to all of the LCD TV,

LP91A/B/C/D chassis.

2. Specification

1) Because this is not a hot chassis, it is not necessary to use

an isolation transformer. However, the use of isolation

transformer will help protect test instrument.

2) Adjustment must be done in the correct order.

3) The adjustment must be performed in the circumstance of

25 ±5 °C of temperature and 65±10% of relative humidity if

there is no specific designation.

4) The input voltage of the receiver must keep 100~220V,

50/60Hz.

5) Before adjustment, execute Heat-Run for 5 minutes at RF

no signal.

3. Adjustment items

3.1. PCB assembly adjustment items

(1) Download the MSTAR main software

(IC800, Mstar ISP Utility)

1) Using D/L Jig

2) Using USB Memory Stick.

(2) ADC Calibration –RGB / Component

(3) Input Tool-Option/Area option.

(4) Check SW Version.

4. PCB assembly adjustment method

4.1. Mstar Main S/W program download

4.1.1. Using D/L Jig

(1) Preliminary steps

1) Connect the download jig to D-sub(RGB) jack

(2) Download steps

1) Execute ‘ISP Tool’program, the main window(Mstar ISP

utility Vx.x.x) will be opened

2) Click the “Connect”button and confirm “Dialog Box”

3) Click the “Config.”button and Change speed I2C Speed

setting : 350Khz~400Khz

4) Read and write bin file.

Click “(1)Read”tab, and then load download

file(XXXX.bin) by clicking “Read”.

- LH20/ LH30

Filexxx.bin

5) Click “(2)Auto”tab and set as below

6) Click “(3)Run”.

7) After downloading, you can see the “(4)Pass”message.

4.1.2. Using the Memory Stick

* USB download : Service Mode

1) Insert the USB memory stick to the ISB port.

2) Automatically detect the SW Version.

-> S/W download process is executed automatically.

3) Show the message “Copy the file from the Memory”

4) After Finished the Download, Automatically DC Off -> On

5) Check The update SW Version.

4.2. Adjust tool/area option.

Adjust tool/area option refer to the BOM.

4.3. Adjust tool/area option.

Adjust tool/area option refer to the BOM.

4.4. EDID D/L method

Recommend that don’t connect HDMI and RGB(D-SUB) cable

when downloading the EDID.

If not possible, recommend that connect the MSPG equipment.

There are two methods of downloading the edid data

4.4.1. 1st Method

EDID datas are automatically downloaded when adjusting the

Tool Option2.

Automatically downloaded when pushing the enter key after

adjusting the tool option2.

It takes about 2seconds.

4.4.2. 2nd Method

* Caution :

Must be checked that the tool option is right or not.

If tool option is wrong, hdmi edid data could not be

downloaded well.

1) Press the ADJ key

2) Move to the EDID D/L and Press the right direction key(G)

3) Press the right direction key(G) at Start.

4) After about a few seconds, appear “OK”, then compele.

4.4.3. RS-232C command Method

(1) Command : AE 00 10

* Caution

Don’t connect HDMI and RGB(D-SUB) cable when

downloading the EDID.

If the cables are connected, Downloading of edid could be

failed.

Only for training and service purposes

Filexxx.bin

4.4.4. EDID data

(1) HD MODEL

<Analog(RGB): 128bytes>

4.5. ADC Calibration

4.5.1. ADC Calibration - Component (Using External pattern)

(1) Required Equipments

- Remote controller for adjustment

- MSPG-925F/MSPG-1025/MSPG-3233 Pattern Generator

(2) Process

1) Change the Input to Component1 or 2 mode.

2) Input the Component 480i@60Hz 100% Color Bar

YPbPr signal into Component1 or 2.

(MSPG-925F Model: 209 / Pattern: 65 )

3) Press ADJ key on R/C for adjustment.

4) Enter Password number. Password is “0 0 0 0”.

5) Select “0. ADC calibration : Component”by using D/E

(CH +/-) and press ENTER(A).

6) ADC adjustment is executed automatically .

7) When ADC adjustment is finished, this OSD appear

4.5.2. ADC Calibration - RGB (Using External pattern)

(1) Required Equipments

- Remote controller for adjustment

- MSPG-925F/MSPG-1025/MSPG-3233 Pattern Generator

(2) Process

1) Change the Input to RGB mode..

2) Input the PC 1024x768@60Hz Horizontal Color Bar

signal into RGB.

(MSPG-925F Model: 60 / Pattern: 65 )

3) Press ADJ key on R/C for adjustment.

4) Enter Password number. Password is “0 0 0 0”.

5) Select “0. ADC calibration : RGB”by using D/E(CH +/-)

and press ENTER(A).

6) ADC adjustment is executed automatically .

7) When ADC adjustment is finished, this OSD appear

Only for training and service purposes

4.6. Input Tool-Option, Area Option.

## TOOL Option, Area Option change and AC off

Before PCBA check, you have to change the Tool option,

Area option and have to AC off/on (Plug out and in)

(If missing this process, set can operate abnormally)

4.6.1. Profile

: Must be changed the option value because being different

with some setting value depend on module maker, inch and

market

4.6.2. Equipment : adjustment remote control.

4.6.3. Adjustment method

The input methods are same as other chassis.(Use IN-START

Key on the Adjust Remocon.)

(If not changed the option, the input menu can differ the

model spec.)

*Refer to Job Expression of each main chassis ass’y

(EBTxxxxxxxx) for Option value

* Never push the IN-STOP KEY after completing the function

inspection.

4.7. Check SW Version

(1) Method

1) Push In-star key on Adjust remote-controller.

2) SW Version check

Check “SW VER : V3.xx”–LH20

5. White Balance adjstment

5.1. Overview

(1) Purpose : Adjust the color temperature to reduce the

deviation of the module color temperature.

(2) Principle : To adjust the white balance without the

saturation, Fix the one of R/G/B gain to 192 (default data)

and decrease the others.

(3) Adjustment mode : Three modes –Cool / Medium / Warm

5.2. Required Equipment

(1) Remote controller for adjustment

(2) Color Analyzer : CA100+ or CA-210 or same product -

LCD TV (ch:9)

(should be used in the calibrated ch by CS-1000)

(3) Auto W/B adjustment instrument(only for Auto adjustment)

5.3. Connecting diagram of equipment for

measuring (For automatic adjustment)

* LP91A~D Support RS-232C & I2C DDC Communication-White

Balance Mode.

(1) Enter the adjustment mode of DDC

- Set command delay time : 50ms

- Enter the DDC adjustment mode at the same time heat-

run mode when pushing the power on by power only key

- Maintain the DDC adjustment mode with same condition

of Heat-run => Maintain after AC off/on in status of Heat-

run pattern display)

(2) Release the DDC adjustment mode

- Release the adjust mode after AC off/on or std-by off/on

in status of finishing the Hear-run mode

- Release the Adjust mode when receiving the aging off

command(F3 00 00) from adjustment equipment.

- Need to transmit the aging off command to TV set after

finishing the adjustment.

- Check DDC adjust mode release by exit key and release

DDC adjust mode)

(3) Enter the adjust mode of white balance)

- Enter the white balance adjustment mode with aging

command (F3, 00, FF)

* Luminance min value is 150cd in the Cool/Medium/Warm

mode(For LCD)

.3. Adjustment of White Balance (for Manual

adjustment)

(1) Color analyzer(CA100+, CA210) should be used in the

calibrated ch by CS-1000

(2) Operate the zero-calibration of the CA100+ or CA-210,

then stick sensor to the module when adjusting.

(3) For manual adjustment, it is also possible by the following

sequence.

1) Select white pattern of heat-run by pressing “POWER

ON”key on remote control for adjustment then operate

heat run longer than 15 minutes. (If not executed this

step, the condition for W/B may be different.)

2) Push “Exit”key.

3) Change to the AV mode by remote control.

4) Input external pattern (85% white pattern)

5) Push the ADJ key -> Enter “0000”(Password)

6) Select “3. W/B ADJUST”

7) Enter the W/B ADJUST Mode

8) Stick the sensor to the center of the screen and select

each items (Red/Green/Blue Gain and Offset) using

D/E(CH +/-) key on R/C..

9) Adjust R/ G/ B Gain using F/G(VOL +/-) key on R/C.

10) Adjust three modes all (Cool / Medium / Warm) : Fix

the one of R/G/B gain and change the others

11) When adjustment is completed, Enter “COPY ALL”.

12) Exit adjustment mode using EXIT key on R/C.

Only for training and service purposes

* CASE

First adjust the coordinate far away from the target value(x, y).

1. x, y > target

i) Decrease the R, G.

2. x, y < target

i) First decrease the B gain,

ii) Decrease the one of the others.

3. x > target, y < target

i) First decrease B, so make y a little more than the target.

ii) Adjust x value by decreasing the R

4. x < target, y > target

i) First decrease B, so make x a little more than the target.

ii) Adjust x value by decreasing the G

(4) Standard color coordinate and temperature when using the

CA100+ or CA210 equipment

To check the Coordinates of White Balance, you have to

measure at the below conditions.

Picture Mode : User 1

Dynamic Contrast : Off

Dynamic Colour : Off

(If you miss the upper condition, the coordinates of W/B

can be lower than the spec.)

Only for training and service purposes

Coordinate

Mode x y

Temp uv∆

Cool 0.285 ± 0.002 0.293 ± 0.002 9300K 0.000

Medium 0.295 ± 0.002 0.305 ± 0.002 8000K 0.000

Warm 0.313 ± 0.002 0.329 ± 0.002 6500K 0.000

Only for training and service purposes LGE Internal Use Only

- 16 -

TROUBLESHOOTING

No power

(LED indicator off)

Check 24V, 12V, 5,2V

of Power B/D Check short of Main B/D

or Change Power B/D

Pass

Check Output of

IC1001, IC1003, IC1007

Check P307 Connector

Change LEDAssy

: [A] PROCESS

Fail

Pass

Check LEDAssy

Change IC1002,, Q1003

Pass

Check short of IC1001,

IC1003, IC1007

Fail

Re-soldering or Change defect

part of IC1001, IC1003, IC1007

Fail

No Raster [B]: Process

Check LED status

On Display Unit Repeat A PROCESS

Pass

Fail

Check Output of IC802 Change IC802

Fail

Change Inverter Connector

Or Inverter

Fail

Pass

Fail

Pass

Change Module

Fail

Check LVDS Cable

Pass

Check Panel Link Cable

Or Module Change Panel Link Cable

Or Module

Check Inverter Connector

Or Inverter

Pass

Only for training and service purposes LGE Internal Use Only

- 17 -

No Raster on PC Signal

Check Input source Cable

and Jack

Pass

Re-soldering or

Change the defect part

Pass

Check the Input/Output

Of IC100 Fail

Re-soldering or

Change the defect part,

Check RGB EDID Data

Repeat [A], & [B] Process

Pass

Check the Input/Output

Of J104 Fail

Pass

Check the Input/Output

Of IC800 Fail Re-soldering or

Change the defect part

Pass

No Raster on COMMPONENT Signal

Check Input source

Cable And Jack

Pass

Re-soldering or

Change the defect part

Pass

Check the Input/Output

Of IC800 Fail Re-soldering or

Change the defect part

Repeat [A], & [B] Process

Check The Input/Output

Of JK101 Fail

Pass

No Raster on HDMI Signal

Check Input source

Cable And Jack

Pass

Check the Input/Output

Of JK301, JK302, JK303 Fail Re-soldering or

Change the defect part

Pass

Check the Input/Output

Of IC300, IC301, JK302 Fail

Re-soldering or

Change the defect part

Check HDMI EDID Data

Re-download HDCP

Pass

Check the Input/Output

Of IC800 Fail Re-soldering or

Change the defect part

Repeat [A], & [B] Process

Only for training and service purposes LGE Internal Use Only

- 18 -

No Raster On AV (Video, S-Video)Signal No Signal On TV(RF) Signal

Check Input source

Cable And Jack

Pass

Check Input source

Cable And Jack

Pass

Check The Input/Output

Of JK101, JK201

Pass

Re-soldering or

Change the defect part

Pass

Fail

Pass

Repeat [A], & [B] Process

Check the Input/Output

Of IC800 Fail Re-soldering or

Change the defect part

Pass

Check The Input/Output

Of TU500

Pass

Re-soldering or

Change the defect part

Pass

Fail

Check the Input/Output

Of IC800 Fail Re-soldering or

Change the defect part

Repeat [A], & [B] Process

No Sound

Check The Input Sourse.

Check The Input/Output

Of IC600. Re-soldering or

Change the defect part.Fail

Pass

Check The Speaker. Change Speaker.

Fail

Check The Speaker Wire.

Pass

Change The Source Input.

Fail

Only for training and service purposes LGE Internal Use Only

- 19 -

BLOCK DIAGRAM

RGB_PC

PC_Audio

(RF)

COMP1

HDMI1

HDMI2

RS232

232C Driver

ST3232C

Tx/ Rx : 15Vpp

PC_R/G/B/HS/VS

PC_Audio_L/R :700mVrms

MNT_OUT: 1Vpp

SIDE_V :1Vpp

SIDE_L/SIDE_R :500mVrms

DDR2(512MB)

L_SPK_OUT

R_SPK_OUT

EEPROM

24C02

Comp1_L/R :500mVrms

TUNER

AV1_VIN:1Vpp

AV11_LIN/RIN :500mVrms

PWM

NTP3100L

MNT_OUT

MNT_LOUT/ROUT: 500mVrms

AV2

(Side AV)

MAIN SCALER

TXD /RXD :5VDigital

COMP1_Y/Pb/Pr: 1/0.7Vpp

COMP2_Y/Pb/Pr: 1/0.7Vpp

HDMI_DATA_1

HDMI_DATA_2

HDMI1_SCL/SDA

OUT_E_TX_CLK

OUT_E_TX_E

OUT_E_TX_D

OUT_E_TX_C

OUT_E_TX_B

OUT_E_TX_A

TU_MAIN

S I F

COMP1_Y/Pb/Pr 1/0.7Vpp

AV1_VIN

PC_Audio_L/R

COMP1_LIN/RIN

L_CH

R_CH

LVDSconnector

TU_MAIN SUB_SCLSDA

EEPROM

24C02

EEPROM

24C02

SIF

AV1_LIN/RIN

MNT_L/R OUT

AV1

MNT_OUT

Comp2_L/R :500mVrms

COMP2_Y/Pb/ :1/0.7Vpp

COMP2_LIN/RIN

COMP2

OUT_O_TX_CLK

OUT_O_TX_E

OUT_O_TX_D

OUT_O_TX_C

OUT_O_TX_B

OUT_O_TX_A

PC_R/G/B/HS/VS

HDM 2_SCL/SDA

PC_SCL/SDA

MNT_VOUT

AV2_VIN

AV2_LIN/RIN

IIS_OUT

USB USB_DN/PN

AUDIO

AMP

HDMI3_SCL/SDA

EEPROM

24C02 HDMI_DATA_3

TMDS

HDMI3

USB

For D/L

EEPROM(256K)

Serial Flash

(8MByte)

RGB_PC

PC_Audio

(RF)

COMP1

HDMI1

HDMI2

RS232

232C Driver

ST3232C

–

PC_R/G/B/HS/VS

PC_Audio_L/R :700mVrms

MNT_OUT: 1Vpp

SIDE_V :1Vpp

SIDE_L/SIDE_R :500mVrms

DDR2(512MB)

EEPROM

24C02

Comp1_L/R :500mVrms

TUNER

AV1_VIN:1Vpp

AV11_LIN/RIN :500mVrms

PWM

NTP3100L

MNT_OUT

MNT_LOUT/ROUT: 500mVrms

AV2

(Side AV)

MAIN SCALER

TXD /RXD :5VDigital

COMP1_Y/Pb/Pr: 1/0.7Vpp

COMP2_Y/Pb/Pr: 1/0.7Vpp

HDMI_DATA_1

HDMI_DATA_2

OUT_E_TX_CLK–

OUT_E_TX_ –

OUT_E_TX_C–

OUT_E_TX_B–

OUT_E_TX_A–

TU_MAIN

S I F

COMP1_Y/Pb/P :1/0.7Vpp

AV1_VIN

PC_Audio_L/R

COMP1_LIN/RIN

L_CH

R_CH

LVDSconnector

TU_MAIN /

EEPROM

24C02

EEPROM

24C02

SIF

AV1_LIN/RIN

MNT_L/R OUT

AV1

MNT_OUT

Comp2_L/R :500mVrms

COMP2_Y/Pb/Pr 1/0.7Vpp

COMP2_LIN/RIN

COMP2

OUT_O_TX_C –

OUT_O_TX_E–

OUT_O_TX_D–

OUT_O_TX_C–

OUT_O_TX_B–

OUT_O_TX_A–

PC_R/G/B/HS/VS

PC_SCL/SDA

MNT_VOUT

AV2_VIN

AV2_LIN/RIN

IIS_OUT

USB USB_DN/PN

AUDIO

AMP

HDMI3_SCL/SDAHDMI3_SCL/SDA

EEPROM

24C02 HDMI_DATA_3

TMDS

HDMI3

USB

For D/L

EEPROM(256K)

Serial Flash

(8MByte)

Only for training and service purposes LGE Internal Use Only

- 20 -

LV1

300

200

301 500 120

122 530

540

800 510

400

550

310

900

910

920

200T

EXPLODED VIEW

Many electrical and mechanical parts in this chassis have special safety-related characteristics. These

parts are identified by in the Schematic Diagram and EXPLODED VIEW.

It is essential that these special safety parts should be replaced with the same components as

recommended in this manual to prevent X-RADIATION, Shock, Fire, or other Hazards.

Do not modify the original design without permission of manufacturer.

IMPORTANT SAFETY NOTICE

This manual suits for next models

Table of contents

Popular LCD TV manuals by other brands

SOYO

SOYO Dymond DYLT032A user manual

F&U

F&U FL2D5505UH manual

PDi

PDi PDI-P14T2S user manual

Orion

Orion TV19PL110D A operating instructions

XOCECO

XOCECO LC-20Y15 Service manual

Telefunken

Telefunken D40U297M4CW instruction manual

Seiki

Seiki SC151FS Features & benefits

Audiovox

Audiovox FPE3705 - 37" LCD TV operating manual

Teac

Teac LCDV2655HD user manual

Insignia

Insignia NS-L22X-10A user guide

Philips

Philips 46PFL8505H brochure

Philips

Philips 52PFL8605H manual

Vizio

Vizio E320-C0E user manual

Daewoo

Daewoo DSL-15D1T instruction manual

AOC

AOC LE32K0D7D(U) Service manual

Palsonic

Palsonic TFTV4005FHD instruction manual

HANNspree

HANNspree K226-10H1 quick start guide

Samsung

Samsung PN64D550C1F E-manual

LG 22LU50R User manual

Popular LCD TV manuals by other brands
