LG 37LD450C User manual

lcd tv
LCD Commercial Widescreen
w w w. LG s o l u t i o n s . c o m
PUBLIC DISPLAY SE INGS - CLONING CAPABLE
EcoSmart™
Energy Saving Levels
ENERGY S AR®4.1 AND RoHS COMPLIAN
DYNAMIC CON RAS RA IO
50,000:1
NA IVE DISPLAY RESOLU ION
1920 x 1080 (full D 1080p)
BUIL -IN A SC/N SC/QAM CLEAR UNER
INVISIBLE SPEAKER SYS EM
idden speaker grilles
LG'S EXCLUSIVE XD ENGINE®
USB 2.0 MEDIA HOS FOR PHO OS AND MUSIC
USB CLONING
CLEAR VOICE II
REAL CINEMA™
2 HDMI™ INPU S WI H HDCP
V.1.3 with deep color
AU O SENSING REMO E JACK PACK (RJP) COMPA IBLE*
2 YEAR LIMI ED WARRAN Y
(parts and labor)
Integrated Full 1080p HD V
*NOTE: Contact your LG Sales representative on the RJPs that are
compatible with the LD450C series.
47" class (47.0" diagonal) 47LD450C
42" class (42.0" diagonal) 42LD450C
37" class (37.0" diagonal) 37LD450C

•EcoSmart
Energy Saving Levels - Manually select your choice for the brightness level for the
television.
•RoHS Compliant - Meets directive on restriction of hazardous substances.
•Energy Star 4.1 Qualified - Meets current reduction requirements of energy
consumption.
L I F E ’ S G O O D . . .
W EN IT’sGREEN.
LG is committed to improving product development,
manufacturing and usage to meet the demand
for environmentally friendlier products. Our
LD450C televisions have technologies to reduce
power consumption and in return increase cost
savings per room. We’ve also placed limits in the
amounts of harmful materials used in these
televisions.
LG’s newest core technology, Picture Wizard, enables easy self-
calibration by providing on-screen reference points for key picture quality
elements such as black level, color, tint, sharpness and backlight levels. By
using this easy-to-use calibration process, the picture setting can be set to
better fit the type of room application.
BALANCED SOUND O EMPHASIZE DIALOGUE
Clear Voice technology automatically enhances dialogue when
background sounds such as those in an action sequence swell.
Enhancements made to the Clear Voice technology now allow users to
customize their personal preferences based on their home environment
through a 12-step adjustment process. This calibration process is based
on distinct voice zoom levels so as to minimize interference with
surrounding sounds.
Picture Wizard
With Picture Wizard, you can adjust the picture quality of the
original image.
G
NextPrevious
PHOTO LIST MUSIC LIST
Enter
Move

Aspect Ratio : 16:9
Picture Wizard
Energy Saving :Off
Picture Mode:Standard
•Backlight 70
• Contrast90
•Brightness50
• Sharpness70
USB 2.0 will support JPG and MP3 files from a USB storage device.
Page 2/3 No Marked
Photo List
Up Folder
1366x768, 125KB
KY101 06/10/2008
KY102 04/03/2008
JMJ001 01/01/2000
JMJ002 06/15/2008
JMJ003 04/03/2008
JMJ004 02/18/2008
KY103 03/30/2008
KY104 06/19/2008
KY105 01/31/2008
JMJ005 05/13/2008
JMJ006 05/26/2008
JMJ007 02/18/2008
JMJ008 02/18/2008
Up Folder
Drive1
JMJ001
Music List
Up Folder
noitaruDeltiT
Page 2/3 No Marked
Drive1
AA00:00 / 04:16
Up Folder
U S B 2 . 0
M E D I A H O S
Dramatizations
Manually select your choice for the brightness level for the television. By
selecting Minimum, Medium, or Maximum, the power consumption will
be reduced and an increase in energy savings can be achieved. (Note:
Selecting minimum level may slightly increase power consumption on some models)
Enter
Move
▼
Aspect Ratio:16:9
Picture Wizard
Energy Saving :Off
Picture Mode:Standard
•Backlight 70
• Contrast90
• Brightness50
•Sharpness70
Off
Minimum
Medium
Maximum
Screen off
Six distinct processes contribute to picture improvement. LG’s XD Engine®takes
the low resolution of analog signals to near D levels by improving brightness,
contrast, detail and enhancing color as well as reducing signal noise.
®
ENERGY SAVING LEVELS
Dramatization
Dramatization

47LD450C
42LD450C
37LD450C
STAND BODY
COVER BASE
4-Screws
(provided)
MOUN ING HOLES ON S AND
ATTAC ING T E TV TO A DESK
1
/DVI IN
RS-232C IN
( CONTROL&SERVICE)
ANTENNA
/CABLE IN
RGB IN (PC)
VIDEO
YPBPRL R
AUDIO
COMPONENT IN
OPTICAL
DIGITAL
AUDIO OUT
AUDIO IN
(RGB/DVI)
AV IN 1
VIDEO AUDIO
L(MONO)
R
44.7”
40.3”
19.7”
19.2”
27.5”
29.8”
25.0”
27.0”
2.2”
2.4”
10.6”
10.3”
18.4”
16.2”
8.8”
8.4”
10.8”
8.7”
200mm
200mm
200mm
200mm
3.0”
3.0”
REAR SIDE
AVIN2
L/MONO
R
AUDIO
VIDEO
USBIN
36.1”
19.2”
22.6”
24.6”
3.0”
2.2”
10.3”
14.1”
8.2”
6.6”
200mm
200mm
SOUND IS HEARD, NO SEEN
Enjoy a combination of smart technology
and stylish design with the invisible
speaker system custom tuned by audio
expert Mr. Mark Levinson. This unique
system provides a clean, polished look
and an enhanced auditory experience
by increasing the sweet spot and
providing a wider sound field.
PUBLIC DISPLAY SE INGS
When used in public areas, these DTVs can be
easily programmed by the installer to have the
TV turn on at a specified channel/volume level,
set the minimum/ maximum volume, lock out the
control panel/remote, set the aspect ratio, and
return to a factory reset. By using Power
Management, these displays can be
programmed to turn off if there has been no
activity (remote or control panel buttons) for a
preset time (1-7) hours.
Public Display Mode No
Start Channel No
Ch. Type TV
Major 2
Minor 0
Minimum Volume 0
Maximum Volume 100
Start Volume No
Level 20
Power Management No
Setting 1
Key Management 0
Factory Reset 0
Aspect Ratio 0
PDM Plus
Public Display Setting
USB CLONING
USB cloning will allow for easy transfer of Public
Display Settings from the “Master TV” to an unlimited
number of same type televisions.
IN 2
VIDEO
AUDIO
L(MONO)
R
H/P USB IN
AV IN 2

All screen images are simulated. Dimensions and weights are approximate.
Design, features and specifications subject to change without notice.
© Copyright 2010 LG Electronics USA, Inc. All Rights Reserved. “LG Life’s Good” is a
registered trademark of LG Corp. XD Engine is a registered trademark of LG Electronics,
Inc. ealthView and EcoSmart are trademarks of LG Corp.
Dolby and the double-D
symbol are registered trademarks of Dolby Laboratories. SRS and the SRS symbol,
TruSurround XT and WOW are trademarks or registered trademarks of SRS Labs, Inc.
VESA is a trademark of Video Electronics Standards Association. All other product and
brand names are trademarks or registered trademarks of their respective companies.
Printed in the USA. July 2010
XT
®
specifications
www.LGsolutions.com
lcd tv
LCD SPECIFICA ION
Screen Size (Class) 47” class (47.0” diagonal)
42” class (42.0” diagonal)
37” class (37.0” diagonal)
Native Display Resolution 1920 x 1080
Dynamic Contrast Ratio 60,000:1
Contrast Ratio 1,400:1
Viewing Angle 178°/178°
Color Reproduction 10 Bit
Response Time 4ms
True Viewing Angle Yes
Life Span (Typical) 60,000 hrs
BROADCAS ING SYS EM
Analog Yes
ATSC/NTSC/Clear QAM Yes
VIDEO
XD Engine Yes
Aspect Ratio 16:9
Aspect Ratio Correction 6 Mode
Just Scan (1:1 Pixel Matching)
DMI 1080p/1080i/720p
Component 1080p/1080i/720p
RF/DTV 720p
EnhancedNoise Reduction (Video Noise Filter) Yes, 3D NR/MPEG NR
Digital Comb Filter Yes (3D)
Color Temperature Control 3 Modes (Warm, Med, Cool)
Black Stretcher Yes
24p Real Cinema Yes
Cinema 3:2/2:2Mode Yes
Picture Reset Yes
AV Mode II (Picture & Sound) 3Modes (Cinema, Sport, Game)
EZ Picture/PSM Yes (7 modes)
ISFccc Ready Yes
DTV Signal Strength Indicator Yes
Video Reset/Initializing Yes
AUDIO
Audio Output Power (Watts - T D 10%) 10W x 2
Invisible Speaker System Details 1 Way 2 Speaker
Dolby Digital 5.1 Decoder Yes
Surround System Type SRS TruSurround XT, SRS WOW
Bass/Treble/Balance Controls Yes
Clear Voice II Yes
Auto Volume Leveler Yes
EZ Sound Mode/SSM 5 Modes
SPECIAL FEA URES
Public Display Settings Yes , PDM2.6
Energy Saving Modes Yes
Brightness Optimization Yes (Available in Standard, Natural, Sport,
Game modes)
Splash Image - Logo (on start up) Yes
Multi Remote IR code (Bed1/2/3/4) Yes
Auto-Sensing RJP compatible Yes (with select RJP versions)
PictureWizard Yes
Backlight Control Yes
TVLink-Protocol Yes
USB Cloning Yes
Mechanical Power Off Yes
1080p Source Input
DMI 60p/30p/24p
Component 60p/30p/24p
RGB WXGA
A/V Input Navigation Yes
Input Labeling/Sub-title Yes
Quick View (Previous Channel) Yes
Quick Setup Guide Yes
e-Manual Yes
Parental Control w/V-Chip Yes
Key Lock/Child Lock Yes
Customizable Closed Caption/Sub-title Yes
LG SIMPLINK™ ( DMI CEC) Yes
CONVENIENCE FEA URES
Language English/Spanish/French/Korean
Alvin UI Yes
Auto Tuning/Programming Yes
Channel Add/Delete Yes
Channel Labeling Yes
Favorite Channel Programming Yes
Auto/Manual Clock Yes
On/Off Timer Yes
Sleep Timer Yes
Auto Off/Auto Sleep (When no video is present) Yes
AUDIO/VIDEOINPU S/OU PU S
RF In (Antenna/Cable) 1
L/R Audio/Composite Video In 1 (rear), 1(side)
D Component Video In (Y, Pb, Pr) +L/R Audio1
Digital Audio Out (Optical) 1
DMI/ DCP Input (V1.3 with Deep Color) 2
RGB In (D-Sub 15pin) -PC 1 (1920 x 1080)
PC Audio Input 1
RS-232c In (Control/Service) 1
USB 2.0 Input 1 (Side) Media ost (JPEG, MP3),
Cloning, and Service
Remote Control Port In 1
RJ45 (for RJP interface - non PIP) 1
CABINE /ACCESSORIES
Cabinet Color Glossy Black
Swivel Stand (degrees) +20°/-20°
Top Side Mounting Screw Yes
TORX Security Screw (2 each) Yes
Power Indicator Yes (on/off)
Fire Retardant Cabine tMaterial Yes
Kensington Security System Slot Yes
VESA®Mount Compliant (Wx ) 200mm x 200mm, M6 screw
Remote Control Yes
POWER
Voltage, z 100V - 240V, 50/60 z
Stand-by Mode (typ.) 0.2W
Power Consumption (typ.) 95W (37”), 115W (42”), 138W (47”)
Dynamic Power Savings Yes
Static Power Savings Yes
REQUIRED APPROVALS
ENERGY STAR®4.1 Qualified Yes
Ro S Compliant Yes
UL, cUL, NOM Yes
DIMENSIONS & WEIGH
TV without stand (Wx xD) 36.1" x 22.6" x 3.0" (37”)
40.3" x 25.0" x 3.0" (42”)
44.7" x 27.5" x 3.0" (47”)
TV with stand (Wx xD) 36.1" x 24.6" x 10.3" (37”)
40.3" x 27.0" x 10.3" (42”)
44.7" x 29.8" x 10.6" (47”)
Shipping Dimensions (Wx xD) 39.2" x 26.0" x 9.0" (37”)
43.6" x 30.3" x 9.0" (42”)
48.8" x 31.6" x 10.0" (47”)
TV without stand weight 23.8 Ibs (37”)
30.0 Ibs (42”)
38.6 Ibs (47”)
TV with stand weight 27.6 Ibs (37”)
33.2 Ibs (42”)
43.0 Ibs (47”)
ShippingWeight 35.1 Ibs (37”)
42.0 Ibs (42”)
52.7 Ibs (47”)
SERVICE/LIMI EDWARRAN Y 2 Years (Parts/Labor)
UPC CODE
37LD450C 7 1919290049 3
42LD450C 7 1919290150 6
47LD450C 7 1919290046 2
LG Electronics U.S.A., Inc.
Business Solutions Division
2000 Millbrook Drive
Lincolnshire, IL 60069
Customer Service: 888.865.3026
www.LGsolutions.com/support
Contact your LG Regional Sales Representative
Vertical Markets: 800.897.8788
Channel: 800.897.8871
Hospitality: 800.228.1236
E-mail: [e-mail]
SPEC_LD450C_051059_PR
47LD450C 47" class (47.0" diagonal)
42LD450C 42" class (42.0" diagonal)
37LD450C 37" class (37.0" diagonal)
