User Guide
This is a 「User Guide」 installed on the TV.
The contents of this guide are subject to change without prior notice for quality
improvement.

GP4
enga
 

Displays information about the current program and/or current time, etc.
✎ Image shown may differ from your TV.
Program name or external
device name
Detailed program information
(for digital broadcast)
Current time
PM 2:00 PM 4:30
Sat, Jan.1 12:02 AM
Prev./Next Ch. Change Schedule

GP4
enga
❐To set favorite channels
HOME ➾ Settings ➙ CHANNEL ➙ Channel Edit
1 Move to the desired channel on Wheel(OK) button. Channel is selected.
2 Press Set as Favorite.
3 Select the desired favorite channel group.
4 Select Enter. Favorite is set.
❐To use Favorite
HOME ➾ Ch. List
Channel list will appear. Select the desired preset favorite channel from
Favorite List A to D.

GP4
enga
HOME ➾ Program Guide
[In Digital Mode Only]
Obtains information about programs and airtime. Obtains program information
and viewing/recording schedules.
Press Wheel(OK) button after moving to
the desired program to view or view/record
programs.
Schedule reservation by selecting date/time/channel.
Makes repeat schedule reservation.
[Image shown may differ from your TV.]
After viewing the schedule, makes revisions
or deletions.
-24H +24H Select schedule
by date Schedule List Favorite Ch. Group
Today Aug. 10, 2011 7:00 AM 1/2 page
FAV
Program Guide
ALL

GP4
enga
❐To set Auto Tuning
HOME ➾ Settings ➙ CHANNEL ➙ Auto Tuning
Automatically tunes the channels.
✎Channels are not registered properly unless the antenna/cable is connected
correctly.
✎Auto Tuning only sets channels that are currently broadcasting.
✎If Lock System is turned on, a pop-up window will appear asking for
password.

GP4
enga
❐To set channels manually
HOME ➾ Settings ➙ CHANNEL ➙ Manual Tuning
Adjusts channels manually and saves the results.
For digital broadcasting, signal strength, etc. can be checked.

GP4
enga
❐To edit channels
HOME ➾ Settings ➙ CHANNEL ➙ Channel Edit
Edits the saved channels.
Set as favorite, block/unblock and skip etc. the selected channel.

 
This TV has the interactivity feature of Digital TV (DTVi) that allows using
applications, also known as Ginga®.
✎ By selecting a digital channel that has interactivity, it will be possible to
visualize and interact with applications transmitted by broadcasters. The
contents can vary and some examples are: weather forecast, real time news,
traffic situation, soap operas and program descriptions, interactive games,
access to bank accounts, government services, soccer information and other
sports.
✎ If your TV has internet connection and the application allows sending
information, it’ll be possible to interact with the applications* answering
surveys, making purchases, casting votes, between others.
* The application must make the aforementioned resources available.

✎ Observations:
1 All contents of interactive applications (DTVi) are under responsibility of
the TV broadcasters.
2 It’s not possible to visualize interactivity (DTVi) and Closed Caption
(Subtitles) at the same time.
3 More information can be obtained at:
http://www.forumsbtvd.org.br/
http://www.ginga.org.br/

 

• Automatic: At this mode, by selecting a digital channel that has interactivity,
the application (DTVi) will be shown automatically on your TV.
• Manual: At this mode, by selecting a digital channel that has interactivity,
the application (DTVi) will only be visible by pressing the red color key of the
remote control.

GP4
enga
HOME ➾ Settings ➙ PICTURE ➙ Aspect Ratio
Selects the screen aspect ratio.
16:9 Resizes the image ratio to fit a 16:9 screen.
Just Scan
Displays high-quality image without loss.
✎ In DTV/HDMI/Component (over 720p) mode, Just Scan is
available.
Set by
Program
Depending on the input signal, screen aspect ratio changes to 4:3
or 16:9.
4:3 Resizes the image ratio to fit 4:3 screen.
Zoom Resizes the image to fit the screen width. The top and bottom
parts of the image may be cut off.
Zoom2
[Only for SBTVD.]
Resizes the image to fit the screen width. The height of the image
does not change.

GP4
enga
Cinema
Zoom
Formats an image to the cinemascope ratio (2.35:1) and zooms in
on the ratio.
✎ While viewing an external device, these cases may result in image burn:
- a video with stationary caption (such as network name)
- 4 : 3 aspect ratio mode for an extended period
Take caution when using these functions.
✎ Available picture size may differ depending on the input signal.
✎ The screen aspect ratios on HDMI/RGB-PC input are available in 4:3 and 16:9
only.
✎ [For models supporting 2160p] When a 2160p signal is input or your PC
resolution is set to 3840 x 2160, the Aspect Ratio is fixed to Just Scan.

GP4
enga
 

Adjusts picture in RGB-PC mode.
Resolution
Sets the desired resolution.
✎ Resolution may only be selected when the PC resolution is
set to 1024x768, 1280x768 or 1360x768.
Auto
Configuration Optimizes picture.
Position/Size/
Phase
If screen size or location is distorted, user can directly adjust
the screen size and position.
Reset Resets all the changes on picture settings on PC input mode.

GP4
enga
 
1 Right-click on the desktop of PC and select 「Properties」.
2 Click on 「Settings」 and refer to supported formats to set the resolution.
3 Select 「Advanced → Monitor → Monitor Settings」 on the setting window.
Refer to supported formats to select the optimal vertical frequency.
✎ On PC mode, 1920x1080 resolution delivers the optimum picture quality.
✎ Resolution settings differ depending on the type of PC.

GP4
enga
 
PC Input Mode Resolution Horizontal
Frequency (KHz)
Vertical
Frequency (Hz)
HDMI-PC /
RGB-PC
640x350 31.468 70.09
720x400 31.469 70.08
640x480 31.469 59.94
800x600 37.879 60.31
1024x768 48.363 60.00
1152x864 54.348 60.053
1360x768 47.712 60.015
1920x1080 67.5 60.00
HDMI-PC 1280x1024 63.981 60.020

GP4
enga
HOME ➾ Quick Menu ➙ AV Mode
Views the TV with the best picture / audio optimized for different AV modes.
Off Views with the value set at the picture / sound menu.
Cinema /
ꔧ Cinema Optimizes picture and audio settings for movies.
Game Optimizes picture and audio settings for games.
✎ꔧ[Depending on model]
THX (Thomlinson Holman’s Experiment) is an audio and video certification
standard established by George Lucas and Thomlinson. A THX certified
display guarantees screen quality that exceeds the display standard
specification in both hardware and software.

GP4
enga
 
 
Use the remote control and follow the instructions of the Picture Wizard to
calibrate and adjust for the optimum picture quality without expensive pattern
devices or help from a specialist.
Follow the instructions to obtain the optimum picture quality.

GP4
enga
 
 
Selects the picture mode optimized for the viewing environment or the program.
Intelligent Sensor
Detects the ambient illumination and automatically
adjusts TV's brightness level to reduce power
consumption. Automatically adjusts the brightness,
sharpness, color or tint for optimum picture quality.
Vivid Heightens contrast, brightness, and sharpness to
display vivid images.
Standard Displays images in standard levels of contrast,
brightness, and sharpness.

GP4
enga
Cinema/ ꔧ Cinema
Game
Displays images that have been optimized for movies or
games. [ꔧ Cinema : Depending on model]
ꕋ Expert
Menu for adjusting picture quality that allows experts
and amateurs to enjoy the best TV viewing. This menu
is ISF-certified and provided for picture tuning experts.
(ISF logo can only be used on ISF-certified TV units.)
ISFccc: Imaging Science Foundation Certified
Calibration Control
✎ Depending on the input signal, available range of picture modes may differ.
✎ ꕋ Expert mode is for picture tuning professionals to control and fine-tune
using a specific image. For normal images, the effects may not be drastic.

GP4
enga
 
 

Selects the desired Picture Mode first.
Backlight Adjusts the display brightness by varying the brightness of the
LCD panel.
Contrast Adjusts the difference between bright and dark regions of the
screen.
Brightness Adjusts the overall screen brightness.
Sharpness Adjusts the sharpness of the borders between bright and dark.
Color Adjusts the color that appears on the screen darker or lighter.
