LG MFL69311714 User manual

www.lg.com
Please read this manual carefully before operating your set and
retain it for future reference.
Safety and Reference
OWNER’S MANUAL
LED TV*
* LG LED TV applies LCD screen with LED backlights.
*MFL69311714* P/NO : MFL69311714(1601-REV00)
Printed in Korea
Downloaded from www.vandenborre.be

2
ENGLISH
Safety instructions
Please read these safety precautions carefully before
using the product.
WARNING
Do not place theTV and/or remote control in the following
environments:
• A location exposed to direct sunlight
• An area with high humidity such as a bathroom
• Near any heat source such as stoves and other devices that
produce heat
• Near kitchen counters or humidiers where they can easily be
exposed to steam or oil
• An area exposed to rain or wind
• Near containers of water such as vases
Otherwise, this may result in re, electric shock, malfunction or product
deformation.
Do not place the product where it might be exposed to dust.This may
cause a re hazard.
Mains Plug is theTV connecting/disconnecting device to AC mains
electric supply.This plug must remain readily attached and operable
whenTV is in use.
Do not touch the power plug with wet hands. Additionally, if the cord
pin is wet or covered with dust, dry the power plug completely or wipe
dust o. You may be electrocuted due to excess moisture.
Make sure to connect Mains cable to compliant AC mains socket with
Grounded earth pin. (Except for devices which are not grounded on
earth.) Otherwise possibility you may be electrocuted or injured.
Insert power cable plug completely into wall socket otherwise if not
secured completely into socket, re ignition may break out.
Ensure the power cord does not come into contact with hot objects
such as a heater.This may cause a re or an electric shock hazard.
Do not place a heavy object, or the product itself, on power cables.
Otherwise, this may result in re or electric shock.
Bend antenna cable between inside and outside building to prevent
rain from owing in.This may cause water damaged inside the Product
and could give an electric shock.
When mountingTV onto wall make sure to neatly install and isolate
cabling from rear ofTV as to not create possibility of electric shock /
re hazard.
Downloaded from www.vandenborre.be

3
ENGLISH
Do not plug too many electrical devices into a single multiple electrical
outlet. Otherwise, this may result in re due to over-heating.
Do not drop the product or let it fall over when connecting external
devices. Otherwise, this may result in injury or damage to the product.
Keep the anti-moisture packing material or vinyl packing out of the
reach of children. Anti-moisture material is harmful if swallowed. If
swallowed by mistake, force the patient to vomit and visit the nearest
hospital. Additionally, vinyl packing can cause suocation. Keep it out
of the reach of children.
Do not let your children climb or cling onto the TV.
Otherwise, theTV may fall over, which may cause serious injury.
Dispose of used batteries carefully to ensure that a small child does not
consume them. Please seek Doctor- Medical Attention immediately if
child consumes batteries.
Do not insert any metal objects/conductors (like a metal chopstick/
cutlery/screwdriver) between power cable plug and inputWall Socket
while it is connected to the input terminal on the wall. Additionally,
do not touch the power cable right after plugging into the wall input
terminal.You may be electrocuted. (Depending on model)
Do not put or store inammable substances near the product.There is a
danger of combustion/explosion or re due to careless handling of the
inammable substances.
Do not drop metallic objects such as coins, hair pins, chopsticks or wire
into the product, or inammable objects such as paper and matches.
Children must pay particular attention. Electrical shock, re or injury
can occur. If a foreign object is dropped into the product, unplug the
power cord and contact the service centre.
Do not spray water on the product or scrub with an inammable
substance (thinner or benzene). Fire or electric shock accident can
occur.
Do not allow any impact, shock or any objects to fall into the unit,
and do not drop anything onto the screen. You may be injured or the
product can be damaged.
Downloaded from www.vandenborre.be

4
ENGLISH
Never touch this product or antenna during a thunder or lighting storm.
You may be electrocuted.
Never touch the wall outlet when there is leakage of gas, open the
windows and ventilate. It may cause a re or a burn by a spark.
Do not disassemble, repair or modify the product at your own
discretion. Fire or electric shock accident can occur.
Contact the service centre for check, calibration or repair.
If any of the following occur, unplug the product immediately and
contact your local service centre.
• The product has been impacted by shock
• The product has been damaged
• Foreign objects have entered the product
• The product produced smoke or a strange smell
This may result in re or electric shock.
Unplug theTV from AC mains wall socket if you do not intend to use the
TV for a long period of time. Accumulated dust can cause re hazard
and insulation deterioration can cause electric leakage/shock/re.
Apparatus shall not be exposed to dripping or splashing and no objects
lled with liquids, such as vases, shall be placed on the apparatus.
Do not install this product on a wall if it could be exposed to oil or oil
mist.This may damage the product and cause it to fall.
If water enters or comes into contact with TV, AC adapter or power
cord please disconnect the power cord and contact service centre
immediately. Otherwise, this may result in electric shock or re.
Only use an authorized AC adapter and power cord approved by
LG Electronics. Otherwise, this may result in re, electric shock,
malfunction or product deformation.
Never Disassemble the AC adapter or power cord.This may result in re
or electric shock.
Be careful in handling the adapter to prevent any external shocks to it.
An external shock may cause damage to the adapter.
Downloaded from www.vandenborre.be

5
ENGLISH
CAUTION
Install the product where no radio wave occurs.
There should be enough distance between an outside antenna and
power lines to keep the former from touching the latter even when the
antenna falls.This may cause an electric shock.
Do not install the product on places such as unstable shelves or inclined
surfaces. Also avoid places where there is vibration or where the
product cannot be fully supported. Otherwise, the product may fall or
ip over, which may cause injury or damage to the product.
If you install theTV on a stand, you need to take actions to prevent the
product from overturning. Otherwise, the product may fall over, which
may cause injury.
If you intend to mount the product to a wall, attachVESA standard
mounting interface (optional parts) to the back of the product.When
you install the set to use the wall mounting bracket (optional parts), x
it carefully so as not to drop.
Only use the attachments / accessories specied by the manufacturer.
When installing the antenna, consult with a qualied service
technician. If not installed by a qualied technician, this may create a
re hazard or an electric shock hazard.
We recommend that you maintain a distance of at least 2 to 7 times
the diagonal screen size when watching TV. If you watchTV for a long
period of time, this may cause blurred vision.
Only use the specied type of battery.This could cause damage to the
remote control.
Do not mix new batteries with old batteries. This may cause the
batteries to overheat and leak.
Batteries should not be exposed to excessive heat. For example, keep
away from direct Sunlight, open replace and electric heaters.
Do not place non-rechargeable batteries in charging device.
Make sure there are no objects between the remote control and its
sensor.
Signal from Remote Control can be interrupted due to external/internal
lighting eg Sunlight, uorescent lighting. If this occurs turn o lighting
or darken viewing area.
Downloaded from www.vandenborre.be

6
ENGLISH
When connecting external devices such as video game consoles, make
sure the connecting cables are long enough. Otherwise, the product
may fall over, which may cause injury or damage the product.
Do not turn the product On/O by plugging-in or unplugging the power
plug to the wall outlet. (Do not use the power plug for switch.) It may
cause mechanical failure or could give an electric shock.
Please follow the installation instructions below to prevent the product
from overheating.
• The distance between the product and the wall should be more
than 10cm.
• Do not install the product in a place with no ventilation (e.g., on a
bookshelf or in a cupboard).
• Do not install the product on a carpet or cushion.
• Make sure the air vent is not blocked by a tablecloth or curtain.
Otherwise, this may result in re.
Take care not to touch the ventilation openings when watching the TV
for long periods as the ventilation openings may become hot. This does
not aect the operation or performance of the product.
Periodically examine the cord of your appliance, and if its appearance
indicates damage or deterioration, unplug it, discontinue use of the
appliance, and have the cord replaced with an exact replacement part
by an authorized servicer.
Prevent dust collecting on the power plug pins or outlet.This may cause
a re hazard.
Protect the power cord from physical or mechanical abuse, such as
being twisted, kinked, pinched, closed in a door, or walked upon. Pay
particular attention to plugs, wall outlets, and the point where the cord
exits the appliance.
Do not press strongly upon the panel with a hand or sharp object such
as nail, pencil or pen, or make a scratch on it, as it may causedamage
to screen.
Avoid touching the screen or holding your nger(s) against it for long
periods of time. Doing so may produce some temporary or permanent
distortion/damage to screen.
When cleaning the product and its components, unplug the power
rst and wipe it with a soft cloth. Applying excessive force may cause
scratches or discolouration. Do not spray with water or wipe with a wet
cloth. Never use glass cleaner, car or industrial shiner, abrasives or wax,
benzene, alcohol etc., which can damage the product and its panel.
Otherwise, this may result in re, electric shock or product damage
(Deformation, corrosion or breakage).
As long as this unit is connected to the AC wall outlet, it is not
disconnected from the AC power source even if you turn o this unit
by SWITCH.
Downloaded from www.vandenborre.be

7
ENGLISH
When unplugging the cable, grab the plug and unplug it, by pulling at
the plug.
Don’t pull at the cord to unplug the power cord from the power board,
as this could be hazardous.
When moving the product, make sure you turn the power o rst. Then,
unplug the power cables, antenna cables and all connecting cables.
TheTV set or power cord may be damaged, which may create a re
hazard or cause electric shock.
When moving or unpacking the product, work in pairs because the
product is heavy. Otherwise, this may result in injury.
Refer all servicing to qualied service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power
supply cord or plug is damaged, liquid has been spilled or objects have
fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
If the product feels cold to the touch, there may be a small“icker”
when it is turned on.This is normal, there is nothing wrong with
product.
The panel is a high technology display product with resolution of two
million to six million pixels. You may see tiny black dots and/or brightly
coloured dots (red, blue or green) at a size of 1ppm on the panel.This
does not indicate a malfunction and does not aect the performance
and reliability of the product.
This phenomenon also occurs in third-party products and is not subject
to exchange or refund.
You may nd dierent brightness and color of the panel depending on
your viewing position(left/right/top/down).
This phenomenon occurs due to the characteristic of the panel. It is not
related with the product performance, and it is not malfunction.
Displaying a still image for a prolonged period of time may cause image
sticking. Avoid displaying a xed image on theTV screen for a long
period of time.
Generated Sound
“Cracking”noise: A cracking noise that occurs when watching or turning
o theTV is generated by plastic thermal contraction due to tempera-
ture and humidity. This noise is common for products where thermal
deformation is required. Electrical circuit humming/panel buzzing:
A low level noise is generated from a high-speed switching circuit,
which supplies a large amount of current to operate a product. It varies
depending on the product.
This generated sound does not aect the performance and reliability
of the product.
Do not use high voltage electrical goods near the TV (e.g. electric
mosquito-swatter).This may result in product malfunction.
Downloaded from www.vandenborre.be

8
ENGLISH
Preparing
NOTE
• If theTV is turned on for the rst time after it was shipped from
the factory, initialization of theTV may take a few minutes.
(Depending on model)
• Image shown may dier from your TV.
• Your TV’s OSD (On Screen Display) may dier slightly from that
shown in this manual.
• The available menus and options may dier from the input source
or product model that you are using.
• New features may be added to this TV in the future.
• The items supplied with your product may vary depending on the
model.
• Product specications or contents of this manual may be changed
without prior notice due to upgrade of product functions.
• For an optimal connection, HDMI cables and USB devices should
have bezels less than 10 mm thick and 18 mm width. Use an
extension cable that supports USB 2.0 if the USB cable or USB
memory stick does not t into yourTV’s USB port.
A
B
A
B
*A
<
=
10 mm
*B
<
=
18 mm
• Use a certied cable with the HDMI logo attached.
• If you do not use a certied HDMIcable, the screen may not display
or a connection error may occur. (Recommended HDMICable Types)
- High-Speed HDMI®/TM Cable (3m or less)
- High-Speed HDMI®/TM Cable with Ethernet (3m or less)
CAUTION
• Do not use any unapproved items to ensure the safety and product
life span.
• Any damage or injuries caused by using unapproved items are not
covered by the warranty.
• Some models have a thin lm attached on to the screen and this
must not be removed.
• When attaching the stand to theTV set, place the screen facing
down on a cushioned table or at surface to protect the screen
from scratches.
• Make sure that the screws are fastened completely. (If they are
not fastened securely enough, theTV may tilt forward after being
installed.) Do not use too much force and over tighten the screws;
otherwise screw may be damaged and not tighten correctly.
Lifting and moving the TV
Please note the following advice to prevent theTV from being scratched
or damaged and for safe transportation regardless of its type and size.
• It is recommended to move the TV in the box or packing material
that theTV originally came in.
• Before moving or lifting theTV, disconnect the power cord and
all cables.
• When holding theTV, the screen should face away from you to
avoid damage.
• Hold the top and bottom of theTV frame rmly. Make sure not to
hold the transparent part, speaker, or speaker grill area.
• When transporting a largeTV, there should be at least 2 people.
• When transporting the TV by hand, hold theTV as shown in the
following illustration.
• When transporting the TV, do not expose theTV to jolts or
excessive vibration.
• When transporting the TV, keep theTV upright, never turn theTV
on its side or tilt towards the left or right.
• Do not apply excessive pressure to cause exing /bending of frame
chassis as it may damage screen.
• When handling theTV, be careful not to damage the protruding
buttons.
CAUTION
• Avoid touching the screen at all times, as this may result in damage
to the screen.
• Do not move theTV by holding the cable holders, as the cable
holders may break, and injuries and damage to theTV may occur.
Downloaded from www.vandenborre.be

9
ENGLISH
Using the button
(Depending on model)
You can simply operate theTV functions, pressing or moving the button.
NOTE
• LH57/59 series does not have a Joystick button but has only a
power On/O button.
Joystick Button
Dome Button
or
Basic functions
Power On (Press)
Power O (Press and hold)1
Volume Control
Programmes Control
1 All running apps will close, and any recording in progress will stop.
Adjusting the menu
When theTV is turned on, press the button one time.You can adjust
the Menu items pressing or moving the buttons.
Turns the power o.
Clears on-screen displays and returns to TV viewing.
Changes the input source.
Accesses the settings menu.
Mounting on a table
1 Lift and tilt the TV into its upright position on a table.
• Leave a 10 cm (minimum) space from the wall for proper
ventilation.
10 cm
10 cm
10 cm
10 cm
10 cm
2 Connect the power cord to a wall outlet.
CAUTION
• Do not place theTV near or on sources of heat, as this may result in
re or other damage.
Downloaded from www.vandenborre.be

10
ENGLISH
Securing the TV to a wall
(This feature is not available for all models.)
1 Insert and tighten the eye-bolts, orTV brackets and bolts on the back
of theTV.
• If there are bolts inserted at the eye-bolts position, remove the
bolts rst.
2 Mount the wall brackets with the bolts to the wall.
Match the location of the wall bracket and the eye-bolts on the rear
of theTV.
3 Connect the eye-bolts and wall brackets tightly with a sturdy rope.
Make sure to keep the rope horizontal with the at surface.
CAUTION
• Make sure that children do not climb on or hang on the TV.
NOTE
• Use a platform or cabinet that is strong and large enough to
support the TV securely.
• Brackets, bolts and ropes are not provided.You can obtain
additional accessories from your local dealer.
Mounting on a wall
Attach an optional wall mount bracket at the rear of the TV carefully
and install the wall mount bracket on a solid wall perpendicular to
the oor. When you attach theTV to other building materials, please
contact qualied personnel. LG recommends that wall mounting be
performed by a qualied professional installer. We recommend the use
of LG’s wall mount bracket. LG’s wall mount bracket is easy to move with
cables connected.When you do not use LG’s wall mount bracket, please
use a wall mount bracket where the device is adequately secured to the
wall with enough space to allow connectivity to external devices. It is
advised to connect all the cables before installing xed wall mounts.
10 cm
10 cm
10 cm
10 cm
Make sure to use screws and wall mount bracket that meet theVESA
standard. Standard dimensions for the wall mount kits are described in
the following table.
Separate purchase(Wall mounting bracket)
Model
32/43LH57**
32/43LH59**
32/40/43LH60**
32/43LH61**
49LH57**
49LH59**
49/55LH60**
49/55LH61**
VESA (A x B) (mm) 200 x 200 300 x 300
Standard screw M6 M6
Number of screws 4 4
Wall mount
bracket
LSW240B
MSW240
LSW350B
MSW240
Model 55LH57**
55LH59**
VESA (A x B) (mm) 400 x 400
Standard screw M6
Number of screws 4
Wall mount
bracket
LSW440B
MSW240
A
B
Downloaded from www.vandenborre.be

11
ENGLISH
CAUTION
• Remove the stand before installing the TV on a wall mount by
performing the stand attachment in reverse.
NOTE
• When installing the wall mounting bracket, use the adhesive label
or protective cover provided. The adhesive label or protective cover
will protect the opening from accumulating dust and dirt. (Only
when the label or cover is provided)
Provided item
Adhesive Label
Provided item
Adhesive label
Provided item
Protective cover
• When installing the wall mounting bracket, it is recommended to
cover the stand hole using tape, in order to prevent the inux of
dust and insects. (Depending on model)
Stand hole
• When attaching a wall mounting bracket to the TV, insert the wall
mount spacers into theTV wall mount holes to adjust the vertical
angle of theTV. (Only when the item of the following form is
provided)
Provided Item
Wall mount spacer
• Depending on the shape of the stand, use a at tool to remove the
stand cover as illustrated below. (e.g., a at screwdriver)
(Only when the item of the following form is provided)
Flat tool
Downloaded from www.vandenborre.be

12
ENGLISH
Connections (notications)
Connect various external devices to theTV and switch input modes to
select an external device. For more information of external device’s
connection, refer to the manual provided with each device.
Available external devices are: HD receivers, DVD players,VCRs, audio
systems, USB storage devices, PC, gaming devices, and other external
devices.
NOTE
• The external device connection may dier from the model.
• Connect external devices to theTV regardless of the order of the
TV port.
• If you record aTV program on a DVD recorder orVCR, make sure to
connect the TV signal input cable to theTV through a DVD recorder
orVCR. For more information of recording, refer to the manual
provided with the connected device.
• Refer to the external equipment’s manual for operating
instructions.
• If you connect a gaming device to theTV, use the cable supplied
with the gaming device.
• In PC mode, there may be noise associated with the resolution,
vertical pattern, contrast or brightness. If noise is present, change
the PC output to another resolution, change the refresh rate to
another rate or adjust the brightness and contrast on the PICTURE
menu until the picture is clear.
• In PC mode, some resolution settings may not work properly
depending on the graphics card.
Antenna connection
Connect theTV to a wall antenna socket with an RF cable (75 Ω).
• Use a signal splitter to use more than 2 TVs.
• If the image quality is poor, install a signal amplier properly to
improve the image quality.
• If the image quality is poor with an antenna connected, try to
realign the antenna in the correct direction.
• An antenna cable and converter are not supplied.
• Supported DTV Audio: MPEG, Dolby Digital, Dolby Digital Plus,
HE-AAC
Satellite dish connection
(Only satellite models)
Connect theTV to a satellite dish to a satellite socket with a satellite RF
cable (75 Ω).
CI module connection
(Depending on model)
View the encrypted (pay) services in digitalTV mode.
• Check if the CI module is inserted into the PCMCIA card slot in the
right direction. If the module is not inserted properly, this can
cause damage to theTV and the PCMCIA card slot.
• If theTV does not display any video and audio when CI+ CAM is
connected, please contact to theTerrestrial/Cable/Satellite Service
Operator.
USB connection
Some USB Hubs may not work. If a USB device connected through a USB
Hub is not detected, connect it directly to the USB port on the TV.
Other connections
Connect yourTV to external devices. For the best picture and audio
quality, connect the external device and theTV with the HDMI cable.
Some separate cable is not provided.
NOTE
• Supported HDMI Audio format :
Dolby Digital (32 kHz, 44.1 kHz, 48 kHz),
DTS (44.1 kHz, 48 kHz),
PCM (32 kHz, 44.1 kHz, 48 kHz, 96 kHz, 192 kHz)
(Depending on model)
Downloaded from www.vandenborre.be

13
ENGLISH
Remote control
(Depending on model)
The descriptions in this manual are based on the buttons on the remote
control. Please read this manual carefully and use theTV correctly.
To replace batteries, open the battery cover, replace batteries (1.5
V AAA) matching the and ends to the label inside the
compartment, and close the battery cover.To remove the batteries,
perform the installation actions in reverse.
Make sure to point the remote control toward the remote control sensor
on theTV.
A
B
1234
5
6
7
A
(POWER)Turns theTV on or o.
Selects Radio,TV and DTV programme.
1, 4(INPUT) Changes the input source. (Depending on
model)
1, 4Recalls your preferred subtitle in digital mode.
(Depending on model)
2(Q. Settings) Accesses the Quick Settings. (Depending on
model)
2AD By pressing the AD button, audio descriptions function will be
enabled. (Depending on model)
3
Views the information of the current programme and
screen. (Depending on model)
3By zooming in on the selected area, you can view it in
full screen. (Depending on model)
3Resizes an image. (Depending on model)
B
Number buttons Enters numbers.
Alphabet buttons Enters letters. (Depending on model)
Accesses the saved programmes list.
(Space) Opens an empty space on the screen keyboard.
(Depending on model)
5, 7Shows programme guide. (Depending on model)
5Returns to the previously viewed programme.
(Depending on model)
Adjusts the volume level.
6
Views the information of the current programme and
screen. (Depending on model)
6, 7
(SEARCH) Search for content such as TV programmes,
movies and other videos, or perform a web search by entering text in
the search bar. (Depending on model)
6Accesses your favourite programme list. (Depending on
model)
(MUTE) Mutes all sounds.
Scrolls through the saved programmes.
Moves to the previous or next screen.
C
D
89
10 11
12 13
14 15
16
Downloaded from www.vandenborre.be

14
ENGLISH
C
8Shows the previous history. (Depending on model)
8, 9, 10 , 11 , 12 , 13 Teletext buttons ( )
These buttons are used for teletext. (Depending on model)
(HOME) Accesses the Home menu.
9LIVE MENU Shows the list of Recommended, Programmes,
Search and Recorded. (Depending on model)
10 , 12 Returns to the previous level. (Depending on model)
10 (Q. Settings) Accesses the Quick Settings. (Depending on
model)
11 , 13 Clears on-screen displays and returns to TV viewing.
(Depending on model)
11 Accesses the Quick menus. (Depending on model)
Navigation buttons (up/down/left/right) Scrolls through menus
or options.
Selects menus or options and conrms your input.
D
14 AD By pressing the AD button, audio descriptions function will be
enabled. (Depending on model)
14
Views the information of the current programme and
screen. (Depending on model)
15 Starts to record and displays record menu.
(OnlyTime MachineReady supported model) (Depending on model)
15 By zooming in on the selected area, you can view it
in full screen. (Depending on model)
15 SLEEP Set the sleep timer. (Depending on model)
16 LIVE TV Returns to LIVE TV. (Depending on model)
Control buttons ( ) Able to access premium
content, video content on devices that support SIMPLINK.
Coloured buttonsThese access special functions in some menus.
( : Red, : Green, :Yellow, : Blue)
Licenses
Supported licenses may dier by model. For more information about
licenses, visit www.lg.com.
Open source software
notice information
To obtain the source code under GPL, LGPL, MPL and other open source
licenses, that is contained in this product, please visit http://opensource.
lge.com.
In addition to the source code, all referred license terms, warranty
disclaimers and copyright notices are available for download.
LG Electronics will also provide open source code to you on CD-ROM
for a charge covering the cost of performing such distribution (such
as the cost of media, shipping, and handling) upon email request to
[email protected]om. This oer is valid for three (3) years from the date
on which you purchased the product.
External control device
setup
To obtain the external control device setup information, please visit
www.lg.com.
Downloaded from www.vandenborre.be

15
ENGLISH
Troubleshooting
Cannot control the TV with the remote control.
• Check the remote control sensor on the product and try again.
• Check if there is any obstacle between the product and the remote
control.
• Check if the batteries are still working and properly installed (
to , to ).
No image display and no sound is produced.
• Check if the product is turned on.
• Check if the power cord is connected to a wall outlet.
• Check if there is a problem in the wall outlet by connecting other
products.
TheTV turns o suddenly.
• Check the power control settings.The power supply may be
interrupted.
• Check if the Sleep Timer / Timer Power Off is activated in the
TIMERS settings.
• If there is no signal while theTV is on, the TV will turn o
automatically after 15 minutes of inactivity.
When connecting to the PC (HDMI),‘No signal’or ‘Invalid Format’is
displayed.
• Turn the TV o/on using the remote control.
• Reconnect the HDMI cable.
• Restart the PC with the TV on.
Specications
Wireless module specification
• As band channels can vary per country, the user cannot change or
adjust the operating frequency. This product is congured for the
regional frequency table.
• For consideration of the user, this device should be installed and
operated with a minimum distance of 20 cm between the device
and the body.
Wireless LAN module (TWFM-B006D) specifications
Standard IEEE802.11a/b/g/n
FrequencyRange OutputPower(Max.)
2400 to 2483.5 MHz
5150 to 5250 MHz
5725 to 5850 MHz (for Non EU)
14 dBm
12.5 dBm
15.5 dBm
CI Module (W x H x D) 100.0 mm x 55.0 mm x 5.0 mm
Environment
condition
Operating
Temperature 0 °C to 40 °C
Operating
Humidity Less than 80 %
Storage
Temperature -20 °C to 60 °C
Storage
Humidity Less than 85 %
Downloaded from www.vandenborre.be

16
ENGLISH
Digital TV Analogue TV
Television
system
DVB-T/T2*
DVB-C
DVB-S*/S2*
PAL/SECAM B/G/I/D/K ,
SECAM L/L’
Programme
coverage
VHF, UHF, C-Band*,
Ku-Band*
VHF: E2 to E12
UHF: E21 to E69
CATV: S1 to S20
HYPER: S21 to S47
Maximum
number of
storable
programmes
6,000
2,000 (LH57**)
3,000 (LH59**, LH60**,
LH61**)
External
antenna
impedance
75 Ω
* Only DVB-T2/C/S/S2 support models.
AC/DC Adapter
32LH57** , 32LH59**
Manufacturer :APD
Model : DA-48G19
Manufacturer : Lien Chang
Model : LCAP45
In : AC 100 - 240V ~ 50/60 Hz
Out : DC 19 V 2.53 A
Downloaded from www.vandenborre.be

www.lg.com
Bitte lesen Sie dieses Handbuch aufmerksam durch, bevor
Sie Ihr Gerät zum ersten Mal verwenden und bewahren Sie
es zur späteren Verwendung auf.
Sicherheitshinweise
und Referenzen
BENUTZERHANDBUCH
LED TV*
* LG LED TV verwendet LCD-Bildschirme mit LED-
Beleuchtung.
Downloaded from www.vandenborre.be

2
DEUTSCH
Sicherheitshinweise
Bevor Sie das Produkt zum ersten Mal verwenden,
lesen Sie diese Sicherheitshinweise bitte
aufmerksam durch.
WARNUNG
Stellen Sie dasTV-Gerät mit Fernsteuerung nicht in folgenden
Umgebungen auf:
• Unter direkter Sonneneinstrahlung
• In Bereichen mit hoher Luftfeuchtigkeit, wie z.B. einem
Badezimmer
• In der Nähe von Hitzequellen, wie z.B. Öfen und anderen
hitzeerzeugenden Geräten
• In der Nähe von Küchenzeilen oder Befeuchtern, wo das Gerät
leicht Dampf oder Öl ausgesetzt sein kann
• In Bereichen, die Regen oderWind ausgesetzt sind
• In der Nähe von Behältern mitWasser, wie z.B.Vasen
Andernfalls kann es zu Bränden, Stromschlägen, Fehlfunktionen oder
Produktverformungen kommen.
Schützen Sie das Gerät vor Staub. Es besteht Brandgefahr.
Wenn Sie das Gerät vom Stromnetz trennen möchten, müssen Sie den
Netzstecker aus der Steckdose ziehen. Dieser Stecker muss jederzeit gut
zugänglich sein.
Berühren Sie den Netzstecker nicht mit nassen Händen.Wenn die
Kontaktstifte nass oder verstaubt sind, trocknen Sie den Netzstecker
vollständig ab, bzw. befreien Sie ihn von Staub. Feuchtigkeit erhöht die
Gefahr eines tödlichen Stromschlags.
Stellen Sie sicher, dass das Stromkabel geerdet ist. (Außer bei Geräten,
die nicht geerdet sind.) Bei Nichtbeachtung besteht die Gefahr von
Verletzungen oder eines tödlichen Stromschlags.
Das Stromkabel muss vollständig in die Steckdose eingesteckt werden.
Ist das Stromkabel nicht fest in die Steckdose eingesteckt, besteht
Brandgefahr.
Das Stromkabel darf nicht mit heißen Gegenständen wie einem
Heizkörper in Berührung kommen. Andernfalls bestehen Brandgefahr
und die Gefahr von Stromschlägen.
Stellen Sie keinen schweren Gegenstand oder das Gerät selbst auf
das Stromkabel. Andernfalls kann es zu Bränden und Stromschlägen
kommen.
Platzieren Sie das Antennenkabel zwischen dem Innen- und
Außenbereich des Gebäudes so, dass kein Regen hereinießen kann.
EtwaigerWassereintritt kann zu Schäden am Gerät und Stromschlag
führen.
Falls das TV-Gerät an derWand montiert wird, darf es nicht an
den Strom- und Signalkabeln auf der Rückseite desTV-Gerätes
aufgehängt werden. Anderenfalls besteht die Gefahr von Bränden oder
Stromschlägen.
Downloaded from www.vandenborre.be

3
DEUTSCH
Schließen Sie nicht zu viele Elektrogeräte an einer einzelnen Steckdose
an. Andernfalls kann es aufgrund von Überhitzung zu Bränden
kommen.
Lassen Sie das Gerät beim Anschluss eines externen Gerätes nicht
fallen. Andernfalls könnenVerletzungen verursacht oder das Gerät
beschädigt werden.
Bewahren Sie dasTrockengranulat und dieVinyl-Verpackung außerhalb
der Reichweite von Kindern auf.Trockengranulat ist beiVerschlucken
gesundheitsschädlich. Falls es verschluckt wurde, Erbrechen
herbeiführen und die Person ins nächste Krankenhaus bringen.
Außerdem besteht Erstickungsgefahr durch die Vinyl-Verpackung.
Bewahren Sie sie außerhalb der Reichweite von Kindern auf.
Achten Sie darauf, dass sich Kinder nicht an dasTV-Gerät hängen oder
daran hochklettern. Andernfalls kann das Gerät umfallen, wodurch
schwere Verletzungen hervorgerufen werden können.
Leere Batterien müssen sicher entsorgt werden, um zu verhindern, dass
Kinder sie verschlucken.Wenn ein Kind eine Batterie verschluckt hat,
sofort den Arzt aufsuchen.
Berühren Sie das Ende des Netzkabels nicht mit einem leitenden
Gegenstand (wie einer Gabel), während das Netzkabel mit der
Steckdose verbunden ist. Berühren Sie das Netzkabel nicht, kurz
nachdem Sie es mit der Steckdose verbunden haben.
Es besteht die Gefahr eines tödlichen Stromschlags.
(Abhängig vom Modell)
Bringen Sie keine entammbaren Stoe in die Nähe des Gerätes.
Bei unsachgemäßem Umgang mit entammbaren Stoen besteht
Explosionsgefahr.
Es dürfen keine Metallgegenstände wie Münzen, Haarnadeln,
Besteck oder Draht bzw. entzündliche Gegenstände wie Papier oder
Streichhölzer in das Gerät gelangen. Achten Sie insbesondere auf
Kinder. Es besteht die Gefahr von Stromschlag, Brand oderVerletzung.
Wenn ein Gegenstand in das Gerät gelangt, ziehen Sie das Stromkabel,
und wenden Sie sich an den Kundendienst.
Sprühen Sie keinWasser auf das Produkt, und bringen Sie es nicht mit
entzündlichen Stoen (Verdünnungsmittel oder Benzol) inVerbindung.
Es besteht Stromschlag- und Brandgefahr.
Setzen Sie das Produkt keinen Schlägen und Stößen aus. Sorgen Sie
dafür, dass keine Gegenstände auf das Gerät oder den Bildschirm fallen.
Es bestehtVerletzungsgefahr. Außerdem kann das Produkt beschädigt
werden.
Downloaded from www.vandenborre.be

4
DEUTSCH
Berühren Sie das Produkt oder die Antenne nicht während eines
Gewitters. Es besteht die Gefahr eines tödlichen Stromschlags.
Im Falle eines Gasaustritts berühren Sie keinesfalls die Steckdose.
Önen Sie zum Lüften die Fenster. Durch Funken können ein Brand oder
Verbrennungen hervorgerufen werden.
Sie dürfen das Gerät nicht eigenmächtig auseinanderbauen, reparieren
oder verändern. Es besteht Stromschlag- und Brandgefahr. Wenden Sie
sich zur Überprüfung, Kalibrierung oder Reparatur an den Kundendienst.
Ziehen Sie in jedem der folgenden Fälle sofort den Netzstecker, und
setzen Sie sich mit Ihrem Kundendienst vor Ort inVerbindung.
• Das Gerät wurde einer Erschütterung ausgesetzt
• Das Gerät wurde beschädigt
• Fremdkörper sind in das Gerät gelangt
• Vom Gerät sind Rauch oder ungewöhnliche Gerüche ausgegangen
Dies kann Brand oder Stromschlag verursachen.
Ziehen Sie das Stromkabel aus der Steckdose, wenn das Gerät für
längere Zeit nicht verwendet wird. Wenn das Gerät eingestaubt ist,
besteht Brandgefahr. EinVerschleiß der Isolation kann zu Kriechverlust,
Stromschlag oder Brand führen.
Achten Sie darauf, dass keine Flüssigkeit auf das Gerät spritzt oder
tropft. Stellen Sie keine Gegenstände, die Flüssigkeiten enthalten (z.B.
Vasen), auf dem Gerät ab.
Installieren Sie dieses Produkt nicht an Wänden, falls es dadurch Öl oder
Ölnebel ausgesetzt werden könnte. Dies kann zu Schäden am Produkt
führen oder das Produkt könnte sich lösen.
Wenn Wasser oder eine andere Substanz in das Produkt (z.B.
Netzadapter, Netzkabel,TV-Gerät) eindringen, unterbrechen Sie
zuerst die Stromzufuhr (Hauptsicherung), ziehen Sie anschließend das
Netzkabel ab und kontaktieren Sie unverzüglich den Kundendienst.
Andernfalls kann es zu einem Brand oder Stromschlag kommen.
Verwenden Sie nur autorisierte Netzadapter und Netzkabel, die von
LGElectronics genehmigt wurden. Andernfalls kann es zu Bränden,
Stromschlägen, Fehlfunktionen oder Produktverformungen kommen.
Nehmen Sie den Netzadapter und das Netzkabel nicht auseinander.
Andernfalls kann es zu einem Brand oder Stromschlag kommen.
Im Umgang mit dem Adapter istVorsicht geboten– vermeiden Sie
externe Erschütterungen am Adapter. Externe Erschütterungen können
zu Schäden am Adapter führen.
Downloaded from www.vandenborre.be
