OWNER’S MANUAL
LED LCD MONITOR
Please read this manual carefully before operating
your set and retain it for future reference.
22MP67D
22MP67HQ
22MP67VQ
23MP67D
23MP67HQ
23MP67VQ
24MP67HQ
24MP67VQ
27MP67HQ
27MP67VQ

2
ENGLISH
TABLE OF CONTENTS
CONTENTS
3LICENSE
4ASSEMBLING AND PREPAR-
ING
4 Unpacking
6 Parts and buttons
7 - How to Use the Joystick Button
8 Moving and Lifting the Monitor
9 Setting up the Monitor set
9 - Attaching the Stand Base
10 - Detaching the Stand Base
11 - Mounting on a table
11 - Using the cable holder
13 - Mounting on a wall
14 USING THE MONITOR SET
14 Connecting to a PC
14 - D-SUB connection
14 - DVI-D connection
14 - HDMI connection
15 Connecting to AV Devices
15 - HDMI connection
16 Connecting to External Devices
16 - Peripheral device connection
17 INSTALLING THE LG MONI-
TOR SOFTWARE
17 Installing The Screen Split
19 Installing The LG Color Cloning
21 CUSTOMIZING SETTINGS
22 Customizing settings
22 - Menu Settings
22 - -Quick Settings
24 - -Picture
26 - -General
27 - -Auto Configuration
28 - -Reset
29 - -Picture mode
30 TROUBLESHOOTING
32 SPECIFICATIONS
40 Preset Modes (Resolution)
40 Indicator
41 PROPER POSTURE
41 Proper posture for using the Monitor set.
42 CUD ( COLOR UNIVERSAL
DESIGN) CERTIFICATION

3
ENG
ENGLISH
LICENSE
LICENSE
Each model has different licenses. Visit www.lg.com for more information on the license.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the
HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC
in the United States and other countries.
The following content is only applied to the monitor which is sold in Europe market and which needs to
meet the ErP Directive:
* This monitor is set to be turned off automatically in 4 hours after you turned on display if there is no
adjustment to display.
* To make this setting be disabled, change the option to ‘Off’ in OSD menu of “Automatic Standby”.
22MP67HQ 23MP67HQ 24MP67HQ 27MP67HQ22MP67VQ 23MP67VQ 24MP67VQ 27MP67VQ

4
ENG
ENGLISH
ASSEMBLING AND PREPARING
ASSEMBLING AND PREPARING
Unpacking
Check your product box for the following items. If there are any missing accessories, contact the local
dealer where you purchased your product. The illustrations in this manual may differ from the actual product
and accessories.
CD(Owner's Manual) /
Card
( Depending on the country ) ( Depending on the country )
Power Cord AC-DC Adapter
AC-DC Adapter
or
D-SUB Cable
( This cable is not included in all
countries. )
DVI-D Cable
( This cable is not included in all
countries. )
22MP67D 23MP67D 24MP67VQ
22MP67VQ 23MP67VQ
27MP67VQ24MP67VQ
27MP67VQ
22MP67VQ 23MP67VQ
22MP67HQ 23MP67HQ 24MP67HQ 27MP67HQ
22MP67D 23MP67D 24MP67VQ
22MP67VQ 23MP67VQ
27MP67VQ24MP67VQ
27MP67VQ
22MP67VQ 23MP67VQ
22MP67HQ 23MP67HQ 24MP67HQ 27MP67HQ
22MP67D 23MP67D 24MP67VQ
22MP67VQ 23MP67VQ
27MP67VQ24MP67VQ
27MP67VQ
22MP67VQ 23MP67VQ
22MP67HQ 23MP67HQ 24MP67HQ 27MP67HQ
Stand Body Stand Base Cable Holder Two Screws
HDMI Cable
( This cable is not included in all
countries. )

5
ENG
ENGLISH
ASSEMBLING AND PREPARING
yDo not use any unapproved accessories to ensure the safety and product life span.
yAny damages or injuries by using unapproved accessories are not covered by the warranty.
yThe accessories supplied with your product may vary depending on the model.
yProduct specifications or contents in this manual may be changed without prior notice due to upgrade
of product functions.
CAUTION
NOTE

6
ENG
ENGLISH
ASSEMBLING AND PREPARING
Parts and buttons
Connection panel (See p.14~16)
(Joystick Button)
Power Indicator
yOn: power is on
yOff: power is off
yThe joystick button is located at the bottom of the monitor.
NOTE

7
ENG
ENGLISH
ASSEMBLING AND PREPARING
How to Use the Joystick Button
You can easily control the functions of the monitor by pressing the joystick button or moving it left/right with
your finger.
Basic Functions
Power on Press the joystick button once with your finger to turn on the
monitor.
Power off Press and hold the joystick button once with your finger to turn off
the monitor.
◄/►Volume
Control You can control the volume by moving the joystick button left/right.

8
ENG
ENGLISH
ASSEMBLING AND PREPARING
Moving and Lifting the Monitor
When moving or lifting the monitor, follow these
instructions to prevent the monitor from being
scratched or damaged and to ensure safe trans-
portation regardless of its shape or size.
yAs far as possible, avoid touching the moni-
tor screen. This may result in damage to the
screen or some of the pixels used to create
images.
yIt is advisable to place the monitor in the
original box or packing material before at-
tempting to move it.
yBefore moving or lifting the monitor, discon-
nect the power cord and all cables.
yHold the top and bottom of the monitor frame
firmly. Do not hold the panel itself.
yWhen holding the monitor, the screen should
face away from you to prevent it being
scratched.
yWhen moving the monitor, avoid any strong
shock or vibrations to the product.
yWhen moving the monitor, keep it upright,
never turn the monitor on its side or tilt it
sideways.
CAUTION

9
ENG
ENGLISH
ASSEMBLING AND PREPARING
Setting up the Monitor set
Attaching the Stand Base
Stand Body
Stand Hinge
Stand Body
Stand Base
yTo protect the screen from scratches, cover
the surface with a soft cloth.
CAUTION
2Check the direction of the stand body
(front, back) and then mount the stand body
onto the stand hinge.
Tighten two screws into the back of the stand
body .
1Place the screen face down.
Screws
3Insert the stand base into the hook of the
stand body.
Tighten the screw to the right.
1
2
4Attach the Cable holder.
Applying excessive force when tightening
the screws may cause damage to the moni-
tor. Damage caused in this way will not be
covered by the product warranty.
CAUTION
It may hurt your foot off the stand, so be
careful.
CAUTION
Cable holder

10
ENG
ENGLISH
ASSEMBLING AND PREPARING
2
2
Detaching the Stand Base
2
yTo protect the screen from scratches, cover
the surface with a soft cloth.
CAUTION
1Place the screen face down.
1
2
Turn the screw to the left.
Pull out the Stand Base.
Stand Base
Stand Body
Cable holder
3As shown in the illustration,put your hand on
the right groove of cable holder, pull cable
holder out to separate it from the set.
4Remove the two screws on the back of stand
body.
As shown in the illustration, disconnect the
stand body from the stand hinge.
Stand Body
Stand Hinge
Screws
yIllustrations in this document represent typi-
cal procedures, so they may look different
from the actual product.
yDo not carry the monitor upside down by just
holding the stand base. This may cause the
monitor to fall off the stand and could result
in personal injury.
yWhen lifting or moving the monitor, do not
touch the monitor screen. The force applied
to the monitor screen may cause damage to
it.
yIf you use the monitor panel without the
stand base, its joystick button may cause
the moni-tor to become unstable and fall,
resulting in damage to the monitor or human
injury. In addition, this may cause the joystick
button to malfunction.
CAUTION

11
ENG
ENGLISH
ASSEMBLING AND PREPARING
(19 V )
(19 V )
Mounting on a table
1Lift and tilt the Monitor set into its upright
position on a table.
Leave a 10 cm (minimum) space from the wall
for proper ventilation.
Using the cable holder
2Connect the AC-DC Adapter and Power Cord
to a wall outlet.
3Press the joystick button on the bottom of the
monitor to turn on the monitor.
10 cm
10 cm
10 cm
10 cm
Unplug the power cord before moving the
Monitor to another location. Otherwise electric
shock may occur.
CAUTION
Cable holder
or

12
ENG
ENGLISH
ASSEMBLING AND PREPARING
3
Using the Kensington security system
The Kensington security system connector is
located at the back of the Monitor set. For more
information of installation and using, refer to the
manual supplied with the Kensington security
system or visit http://www.kensington.com .
Connect the Kensington security system cable
between the Monitor set and a table.
The Kensington security system is optional.
You can obtain it from most electronics stores.
NOTE
When you adjust the angle, do not hold the
bottom of the Monitor set frame as shown on
the following illustration, as may injure your
fingers.
Do not touch or press the screen when
adjusting the angle of the monitor.
Do not hold this set like below picture.Monitor
screen can detach from stand base and injure
your body.
WARNING
Tilt from +20 to -3 degrees up or down to adjust
the angle of the Monitor set to suit your view.
NOTE
Front Rear

13
ENG
ENGLISH
ASSEMBLING AND PREPARING
Mounting on a wall
For proper ventilation, allow a clearance of 10 cm
on each side and from the wall. Detailed
instructions are available from your dealer, see the
optional Tilt Wall Mounting Bracket Installation and
Setup Guide.
If you intend to mount the Monitor set to a wall,
attach Wall mounting interface (optional parts) to
the back of the set.
When you install the Monitor set using a wall
mounting interface (optional parts), attach it
carefully so it will not drop.
1If you use screw longer than standard, the moni-
tor might be damaged internally.
2If you use improper screw, the product might be
damaged and drop from mounted position.
In this case, LG Electronics is not responsible
for it.
10 cm
10 cm
10 cm
10 cm
yDisconnect the power cord first, and then
move or install the Monitor set. Otherwise
electric shock may occur.
yIf you install the Monitor set on a ceiling or
slanted wall, it may fall and result in severe
injury.
yUse only an authorized LG wall mount
and contact the local dealer or qualified
personnel.
yDo not over tighten the screws as this may
cause damage to the Monitor set and void
your warranty.
yUse only screws and wall mounts that
meet the VESA standard. Any damages
or injuries by misuse or using an improper
accessory are not covered by the warranty.
yScrew length from outer surface of back
cover should be under 8mm.
yUse the screws that are listed on the VESA
standard screw specifications.
yThe wall mount kit will include an installation
manual and necessary parts.
yThe wall mount bracket is optional. You can
obtain additional accessories from your local
dealer.
yThe length of screws may differ depending
on the wall mount. Be sure to use the proper
length.
yFor more information, refer to the
instructions supplied with the wall mount.
CAUTION
NOTE
Back Cover
Wall mount Pad
Wall mount Pad
Back Cover
Standard screw
Max.8mm
yWall Mount (A x B)
A
B
Model
Wall Mount
(A x B)
75 x 75 100 x 100
Standard
screw M4 x L10
Number of
screws 4
Wall Mount
Plate
(Optional)
RW120
22MP67D
22MP67HQ
22MP67VQ
23MP67D
23MP67HQ
23MP67VQ
24MP67HQ
24MP67VQ
27MP67VQ
27MP67HQ

14
ENGLISH
USING THE MONITOR SET
USING THE MONITOR SET
Connecting to a PC
yYour Monitor set supports Plug & Play*.
*Plug & Play: A PC recognizes a connected
device that users connect to a PC and turn
on, without device configuration or user
intervention.
D-SUB connection
Transmits analog video from your PC to the
Monitor set. Connect the PC and the Monitor set
with the supplied D-sub 15 pin signal cable as
shown in the following illustrations.
yMac adapter
For Apple Macintosh use, a separate plug
adapter is needed to change the 15 pin
high density (3 row) D-SUB VGA connector
on the supplied cable to a 15 pin 2 row
connector.
yWhen using a D-Sub signal input cable
connector for Macintosh
NOTE
HDMI connection
Transmits the digital video and audio signals from
your PC to the Monitor set. Connect the PC and
the Monitor set with the HDMI cable as shown in
the following illustrations.
yIf you use HDMI PC, it can cause compatibility
problem.
NOTE
DVI-D connection
Transmits a digital video signal from your PC to
the Monitor set. Connect the PC and the Monitor
set with a DVI cable as shown in the following
illustrations.
RGB OUT
PC
24MP67VQ 27MP67VQ22MP67VQ 23MP67VQ
24MP67HQ 27MP67HQ22MP67HQ 23MP67HQ
PC
DVI OUT
23MP67D
22MP67VQ
27MP67VQ
22MP67D
24MP67VQ
23MP67VQ

15
ENG
ENGLISH
USING THE MONITOR SET
yConnect the signal input cable
and tighten it by turning the
screws clockwise.
yDo not press the screen with
your finger for a long time as this may
result in temporary distortion on the screen.
yAvoid displaying a fixed image on the
screen for a long period of time to prevent
image burn. Use a screensaver if possible.
CAUTION
yWhen you want to use two PC in our Monitor,
please connect the signal cable(D-SUB/
DVI-D/HDMI) respectively in Monitor set.
yIf you turn the Monitor set on while it is cold,
the screen may flicker. This is normal.
ySome red, green, or blue spots may appear
on the screen. This is normal.
NOTE
Connecting to AV Devices
HDMI connection
Transmits the digital video and audio signals from
your AV devices to the monitor. Connect your AV
device to the monitor with the HDMI cable as il-
lustrated below.
24MP67HQ 27MP67HQ
22MP67VQ 23MP67VQ 24MP67VQ 27MP67VQ
23MP67HQ
22MP67HQ
yIf you use HDMI PC, it can cause compatibility
problem.
NOTE

16
ENGLISH
USING THE MONITOR SET
Connecting to External Devices
Peripheral device connection
Connect peripheral devices to the monitor using
headphone ports.
yPeripheral devices are sold separately.
yCables with angled plugs may have clear-
ance issues, use straight plugs when pos-
sible.
Angle Type Straight Type
NOTE
NOTE
yHeadphones or speakers may not work nor-
mally, depending on the server PC settings.
24MP67HQ 27MP67HQ
22MP67VQ 23MP67VQ 24MP67VQ 27MP67VQ
23MP67HQ
22MP67HQ
(sold separately)

17
ENG
ENGLISH
INSTALLING LG MONITOR SOFTWARE
INSTALLING THE LG MONITOR SOFTWARE
Installing The Screen Split
1Set the default Web browser to Internet Explorer.
Insert the the owner's manual CD included in the product package into your PC's CD driver and install the
LG Monitor Software.
2
Click the "Screen Split _LG Color Cloning" on
the CD's main screen. When the file download
window appears, click the Run button. (The
file download window may vary depending on
the operating system and the Internet Explorer
version, but the installation procedures are
same.)
yService Pack 1 or higher is required for
Windows 7 & Windows 8.
3
Follow the instructions to proceed with the
installation.
4
Check "I accept the terms of the agreement" on
the License Agreement screen and then click
the [Next] button.
CAUTION

18
ENG
ENGLISH
INSTALLING LG MONITOR SOFTWARE
6
When the installation is complete, restart your
system.
NOTE
If you run Screen Split, the Screen Split icon [
] appears in the system tray at the right bottom of
the PC screen.
Right-click the Screen Split icon and select a
layout you want.
5
The Screen Split installation starts as shown
below.
yScreen Split: This program automatically
splits the program window as desired.
Monitor Selection only supported in extend
display.
This program supported Windows 7 &
Windows 8.
NOTE

19
ENG
ENGLISH
INSTALLING LG MONITOR SOFTWARE
Installing The LG Color Cloning
Insert the the owner's manual CD included in the product package into your PC's CD driver and install the
LG Monitor Software.
The installation screen images are for reference only. The actual installation screen images may vary de
pending on the model.
1
Follow the instructions to proceed with the
installation.
2
Check the I accept the terms of the agree-
ment checkbox on the License Agreement
screen and then click the Next button.
3
Click the install button.
4
The LG Color Cloning starts the installation as
shown below.
5
Click the complete button.
6
When the installation is complete, restart
your system.

20
ENG
ENGLISH
INSTALLING LG MONITOR SOFTWARE
yLG Color Cloning: This program matches
the color quality and brightness of two
monitors using your Smartphone.
NOTE
yDouble-click the LG Color Cloning icon on
des-ktop to run LG Color Cloning Application.
NOTE
yTo use the LG Color Cloning function, you
must execute both the “LG Color Cloning”
Windows application and the “LG Color
Cloning” android application at the same
time.
yFor details on supported Smartphones and
graphic cards, see the LG Color Cloning
help manual.
INSTALLING THE LG COLOR CLONING APPLI
CATION (ANDROID)
1. Open the playstore on your android phone.
2. Search “LG Color Cloning” on the playstore.
yIf you read the QR code on the first page
of the on “LG Color Cloning” Windows
Application, you can open the download page
of the“LG Color Cloning” android application.
yFor details, see the LG Color Cloning help
manual .
3. Click “install” button.
When the installation of “LG Color Cloning”
Android Application is complete, the LG Color
Cloning icon appears on your “Application”.
