L3000A
COLOR MONITOR
SERVICE MANUAL
CAUTION
BEFORE SERVICING THE UNIT,
READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
CHASSIS NO. : CL-36
FACTORY MODEL: L3000AL
MODEL: L3000A (L3000AL-AL), (L3000AL-SL)

1. LCD CHARACTERISTICS
Type : TFT Color LCD Module
Size : 30inch
Pixel Pitch : 0.5025 x 0.1675 x RGB
Color Depth : 8-bit, 16,777,216 colors
Electrical Interface : LVDS
Active Display Area : 643.2mm x 385.92mm
Surface Treatment : Anti-Glare, Hard Coating(3H)
Operating Mode : Normally Black
Backlight Unit : 16-CCFL (Cold Cathode
Fluorescent Lamp)
2. OPTICAL CHARACTERISTICS
2-1. Viewing Angle by Contrast Ratio
≥ 10
Left : -80° min., -85°(Typ)
Right : +80° min., +85°(Typ)
Top : +80° min., +85°(Typ)
Bottom : -80° min., -85°(Typ)
2-2. Luminance : 350(min), 414(Typ)
2-3. Contrast Ratio : 2300(min), 350(Typ)
3. SIGNAL (Refer to the Timing Chart)
3-1. Video Input
1)Signal Input : 15pin D-sub Connector/ S-video,
RCA
2)Input Form : RGB Analog(0.7Vp-p/75ohm), CVBS,
Digital, Y/C
3)Resolution(max) : Analog -1280 x 1024@60Hz
Digital -1024 x 768@75Hz
3-2. Audio Signal
1) Input: PC : 700mVrms
VCR: 450mVrms
DVD: 450mVrms
3-3. Sync Input
Horizontal : 30 ~ 66kHz(Digital: 30~63kHz)
Vertical : 56 ~ 85Hz
Input Form : Separate, TTL,
Positive/Negative Digital, SOG
4. POWER SUPPLY
4-1. Power Adaptor
Input : AC 100~240V, 50/60Hz , 2.0A
Output : DC 5V 0.9A, DC12V 1.5A
DC18V 1.0A, DC24V 5.0A
4-2. Power Consumption
5. ENVIRONMENT
6-1. Operating Temperature: 10°C~35°C (50°F~95°F)
(Ambient)
6-2. Relative Humidity : 10%~80%
(Non-condensing)
6-3. MTBF : 30,000 Hours(Typ.)
6. DIMENSIONS (with TILT/SWIVEL)
Width : 734 mm (28.90'')
Depth : 487 mm (19.17')
Height : 96 mm (3.78'')
7. WEIGHT (with TILT/SWIVEL)
Net. Weight : 18.0kg (39.68 lbs)
Gross Weight : 22.0kg (48.51 lbs)
CONTENTS
SPECIFICATIONS
- 2 -
SPECIFICATIONS ................................................... 2
PRECAUTIONS ....................................................... 4
TIMING CHART ....................................................... 5
OPERATING INSTRUCTIONS ................................ 6
WIRING DIAGRAM ................................................. 9
BLOCK DIAGRAM ................................................. 10
DESCRIPTION OF BLOCK DIAGRAM...................11
ADJUSTMENT ...................................................... 13
TROUBLESHOOTING GUIDE .............................. 14
PRINTED CIRCUIT BOARD................................... 19
EXPLODED VIEW...................................................22
REPLACEMENT PARTS LIST ...............................24
PIN CONFIGURATION............................................31
SCHEMATIC DIAGRAM......................................... 35
MODE
POWER ON (NORMAL)
STAND-BY
SUSPEND
DPM OFF
POWER OFF
H/V SYNC
ON/ON
OFF/ON
ON/OFF
OFF/OFF
-
POWER CONSUMPTION
less than 165 W
less than 5 W
less than 5 W
less than 5 W
less than 1 W
LED COLOR
GREEN
AMBER
AMBER
AMBER
OFF
VIDEO
ACTIVE
OFF
OFF
OFF
-

- 3 -
Signal Connector Pin Assignment
Pin Signal (DVI-D)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
T. M. D. S. Data2-
T. M. D. S. Data2+
T. M. D. S. Data2/4 Shield
T. M. D. S. Data4-
T. M. D. S. Data4+
DDC Clock
DDC Data
Analog Vertical Sync.
T. M. D. S. Data1-
T. M. D. S. Data1+
T. M. D. S. Data1/3 Shield
T. M. D. S. Data3-
T. M. D. S. Data3+
+5V Power
Ground
(return for +5V,
H. Sync. and V. Sync.)
Pin Signal (DVI-D)
18
9
17 24
16
16
17
18
19
20
21
22
23
24
Hot Plug Detect
T. M. D. S. Data0-
T. M. D. S. Data0+
T. M. D. S. Data0/5 Shield
T. M. D. S. Data5-
T. M. D. S. Data5+
T. M. D. S. Clock Shield
T. M. D. S. Clock+
T. M. D. S. Clock-
T. M. D. S. (Transition Minimized Differential Signaling)
• DVI-D Connector (Digital)

- 4 -
WARNING FOR THE SAFETY-RELATED COMPONENT.
•There are some special components used in LCD
monitor that are important for safety. These parts are
marked on the schematic diagram and the
replacement parts list. It is essential that these critical
parts should be replaced with the manufacturer’s
specified parts to prevent electric shock, fire or other
hazard.
•Do not modify original design without obtaining written
permission from manufacturer or you will void the
original parts and labor guarantee.
TAKE CARE DURING HANDLING THE LCD MODULE
WITH BACKLIGHT UNIT.
•Must mount the module using mounting holes arranged
in four corners.
•Do not press on the panel, edge of the frame strongly
or electric shock as this will result in damage to the
screen.
•Do not scratch or press on the panel with any sharp
objects, such as pencil or pen as this may result in
damage to the panel.
•Protect the module from the ESD as it may damage the
electronic circuit (C-MOS).
•Make certain that treatment person’s body are
grounded through wrist band.
•Do not leave the module in high temperature and in
areas of high humidity for a long time.
•The module not be exposed to the direct sunlight.
•Avoid contact with water as it may a short circuit within
the module.
•If the surface of panel become dirty, please wipe it off
with a softmaterial. (Cleaning with a dirty or rough cloth
may damage the panel.)
WARNING
BE CAREFUL ELECTRIC SHOCK !
•If you want to replace with the new backlight (CCFL) or
inverter circuit, must disconnect the AC adapter
because high voltage appears at inverter circuit about
650Vrms.
•Handle with care wires or connectors of the inverter
circuit. If the wires are pressed cause short and may
burn or take fire.
PRECAUTION
CAUTION
Please use only a plastic screwdriver to protect yourself
from shock hazard during service operation.

TIMING CHART
- 5 -
VIDEO
SYNC
B
D
CFE
A
<< Dot Clock (MHz), Horizontal Frequency (kHz), Vertical Frequency (Hz), Horizontal etc... (µs), Vertical etc... (ms) >>
H + 31.469 800 640 16 96 48
V–70.8 449 350 37 2 60
H–43.269 832 640 56 56 80
V–85.0 509 480 1 3 25
H–31.469 800 640 16 96 48
V–59.94 525 480 10 2 33
H–37.5 840 640 16 64 120
V–75 500 480 1 3 16
H–31.468 900 720 18 108 54
V + 70.8 449 400 12 2 35
H + 37.879 1056 800 40 128 88
V + 60.317 628 600 1 4 23
H + 46.875 1056 800 16 80 160
V + 75.0 625 600 1 3 21
H + 53.674 1048 800 32 64 152
V + 85.061 631 600 1 3 27
H+/–49.725 1152 832 32 64 224
V+/–74.55 667 624 1 3 39
H–48.363 1344 1024 24 136 160
V–60.0 806 768 3 6 29
H–60.123 1312 1024 16 96 176
V–75.029 800 768 1 3 28
H + 63.981 1688 1280 48 112 248
V + 60.02 1066 1024 1 3 38
H + 47.7 1680 1280 66 134 200
V + 60 795 768 1 3 23
Mode H/V
Sort
1
2
3
4
5
6
7
8
9
10
11
12
13
25.175
28.321
25.175
31.5
36.0
40.0
49.5
56.25
57.283
65.0
78.75
108.0
80.14
640x350
70Hz
640x480
85Hz
640x480
60Hz
640x480
75Hz
720x400
70Hz
800x600
60Hz
800x600
75Hz
800x600
85Hz
832x624
75Hz
1024x768
60Hz
1024x768
75Hz
1280x1024
60Hz
1280x768
60Hz
Sync
Polarity Frequency
Dot
Clock Total Period
(E)
Video Active Time
(A)
Sync Duration
(D)
Back Porch
(F)
Front Porch
(C)
Resolution

- 6 -
FRONT VIEW
REAR VIEW CONNECTOR PANEL
REAR VIEW
OPERATING INSTRUCTIONS
L3000A
Front Control Panel Rear View Pannel
AUDIO
Output
S-Video
Connector
RCA Cable
Connector
Factoryadjustment
orASPort
AUDIO
Input
D-Sub
Connector D-Sub Connector
DVI-D
Connector
Power
Cord

- 7 -
OPERATING INSTRUCTIONS
Front Control Panel
7
2
1568 3 4
•Use this button to turn the display on or off.
•This Indicator lights up green when the display operates normally. If the display is in
DPM (Energy Saving) mode, this indicator color changes to amber.
Power Button
Power (DPMS)
Indicator
Use these buttons to decrease or increase the volume level.
• Bring up Contrast and
Brightness adjustment.
•Use this button to enter or exit the On Screen Display.
MENU Button
• Use these buttons to choose or adjust items in the On Screen Display.
OSD Buttons
•Use this button to enter a selection in the On Screen Display.
•When adjusting your display settings, always press the AUTO/SELECT button before
entering the On Screen Display(OSD). This will automatically adjust your display image
to the ideal settings for the current screen resolution size (display mode).
AUTO/SELECT Button
1
2
3
4
5
6
8
7
This function allows you to secure the current control settings, so that they cannot be
inadvertently changed. Press and hold the MENU button and button for 3 seconds: the
message “CONTROLS LOCKED” appears.
You can unlock the OSD controls at any time by pushing the MENU button and
button for 3 seconds:
the message “CONTROLS UNLOCKED” will appear.
•Use this button to select an input signal.
•DVI DIGITAL: DVI digital signal
•DSUB ANALOG: 15-pin D-sub analog signal
•V1 (AV): Composite video
•V2 (S): S video
SOURCE
Button
CONTROLS LOCKED/UNLOCKED :
MENU and
Remote Control Sensor
Power On/Off switch
AUTO/SELECT
SOURCE

Attaching temporary stand
- 8 -
Follow below procedures to temporarily use the display on the floor.
First, check if the following parts are all present.
1. Take out 2 screws from the rear of the display.
Parts
Temporary Stand Screws Bottom Rubbers
2. As shown in the diagram, place the bottom rubbers where you took out the 2
screws and then secure them with those 2 screws.
3. Attach the temporary stand as shown.

- 9 -
WIRING DIAGRAM
CN1
CN1
J710
J19
J703
J706
J704
J705
Connector Ass’y P/N:
6631T11016A Connector Ass’y P/N:
6631T20020P
Connector Ass’y P/N:
6631T12002P
Connector Ass’y P/N:
6631T12002N

- 10 -
DVI-D
D-SUB
CVBS
L
R
PC L/R
Video
Decoder
(SAA7114H)
Deinterlacer
(SDA9400)
YUV
Flash
Memory
(M29W800DT)
EEPROM
Y/C YUV
Multi-
plexer
(74LVC257)
H V Sync
H V Sync
GVS
GHS
Video Signal
GVS
GHS
Sync_ Sel
Sync_ Sel
3.3V
3.3V
3.3V
NCTL_SCL
NCTL_SDA
GREF
GREF
3.3V
5V
8V
3.3V
3.3V
2.5V
3.3V
3.3V
Buffer
(74LVC541ct)
RDN CS0N
Data
(PWD
0...7
)
Key_Data
(0...15)
CS0N
RDN CS1N
Data
(PWD 0 ..7)
(PWA 0 ..19)
ROMOE
ROMWE
ROMWE
ROMOE
I/O expander
(74LVC273D)
Control Signals
TMDSTX_PDNN
TMDSRX_PDNN
R,G,B
Even
R,G,B
Odd
RGB
Digital
Signal
Even
Input Selection
Format Converter Circuit
Odd
ADC
(AD9883-140)
R,G,B
differential
Video Signal
Processor
(PW166B-20T)
Analo g
Switch
(BA7657F)
TMDS
Receiver
(SIL161A)
Control Board
Line-out L
Line-out R
Audio
Processor
(MSP3420G)
LCD
Module
LVDS
Transm itter
(THC63LVDM83R)
Ready
Power Block
12V
5V 3.3V
24V,18V,12V,5V
Input
from Power B/d
8V
2.5V
12V
PCB_PWR
INV_PWR
LCM_PWR
BLOCK DIAGRAM

- 11 -
DESCRIPTION OF BLOCK DIAGRAM
1. Input Selection Circuit
This block is composed of 74LVC257(U5) and peripheral devices.
There are two inputs, Analog and Digital H/V Sync.
LVC257 IC chooses one input and outputs selected input through sync selection pin (Pin 1).
2. A/D Converter
This block is composed of AD9883 (U4) and peripheral devices.
AD9883 includes A/D converter, Pre-amp, and PLL.
The Analog RGB signal (0.7Vp-p) is input to R,G,B port of AD9883(U4).
Input signal is amplified, phase locked , A/D converted in 8bits digital signal by this IC(U4), and sent to the Digital
video signal to PW166B-20T.
U4 makes clock for PW166B-20T(U8).
3. TMDS PanelLink Receiver
This Block is composed of SiI161B (U201) and peripheral devices.
This IC decodes PanelLink Digital Input signal(TMDS) from DVI-D Pin (J18) and make 8bit digital RGB signal with
Digital EVEN/ODD format to PW166B-20T(U8).
4. DDC controller
This block is composed of PW166B-20T(U8) and peripheral devices.
PW166B-20T controls peripheral devices through IIC line.
Major functions are (1) to control Flash memory through DDC-SCLA, DDC-SDAA of D-sub And (2) to store EDID
data in the EEPROM (U17, U30)
5. Video Decoder
This block is composed of SAA7114H (U7) and peripheral devices.
PW166B-20T controls this IC through IIC Line.
This IC analyzes input signal of CVBS, Y/C and outputs analyzed signal (8bit interlace signal) to De-interlace block.
Analyzed signal has video control signals like Contrast, Brightness, Sharpness, Color, tint signals Including Adaptive
Comb Filter.
6. Audio Decoder
This block is composed of MSP3420G (U49) and peripheral devices.
PW166B-20T controls this IC through IIC Line.
This IC analyzes Audio input signal through A/V Jack and PC audio.
And output the analyzed signals
7. De-interlace
This block is composed of SDA9400 (U16) and peripheral devices.
PW166B-20T (U8) controls this IC through IIC Line.
And this IC convert 8 Bit Interlaced Y/UV signal to De-interlace signal.
It outputs converted signal to Format Converter (PW166B-20T).
8. Format Converter(Scaler)
This block is composed of PW166B-20T (U8), M29W800DT (U19) and peripheral devices.
MICOM in PW166B-20T (U7) processes outputs of A/D Converter and TMDS Receiver,
De-interlace output and output processed 48 Bit Digital signal to TMDS Transmitter.
PW166B-20T is Format Converter IC that receives Digital signal and outputs proper frame signal to LCD Module
Timing(1280x768,WXGA).
9. PanelLink Circuit
TMDS Transmitter (THC63LVDM83R, U401) is the IC that receives output digital signal of PW166B-20T (U8) and
output to LCD Module.
The signal format is Panel-link.
LCD Module has Panel-link receiver that is same output of PW166B-20T.
This is the best for reduction EMI problem and the number of pin connector.

- 12 -
10. DC/DC Converter block
DC/DC Converters convert the input 12V, 24V to proper 2.5V, 3.3V, 5V, 8V for main control system.
For shooting heat trouble, we use the DC/DC converting IC.
11. Power Supply Block
This Block generates DC Voltages(5V, 12V, 18V and 24V) to Main Control system from AC Power(100-240 V, 50/60
Hz, 1.0 A).
This Circuit contains PFC(Power Factor correction) circuit.
The Minimum of Power efficiency is about 75%.

- 13 -
ADJUSTMENT
DVI-D Connector
220
IBM
Compatible PC
Parallel Port
Power inlet (required)
Power LED
ST Switch
Power Select Switch
(110V/220V)
Control Line
Not used
RS232C
PARALLEL
V-SYNC POWER
ST
VGS MONITOR
E
V-Sync On/Off Switch
(Switch must be ON.)
F
A
B
C5V
E
F
A
B
C
1510
5
569
1
1
1
14
13
25
6
5V
5V
4.7K
4.7K
4.7K
74LS06
74LS06
OFF ON
OFF
ON
11
Figure 1. Cable Connection
All adjustment are thoroughly checked and corrected
when the monitor leaves the factory, but sometimes
several minor adjustment may be required.
Adjustment should be following procedure and after
warming up for a minimum of 30 minutes.
•Alignment appliances and tools.
- IBM compatible PC
- Programmable Signal Generator.
(eg. VG-819 made by Astrodesign Co.)
- Oscilloscope.
- White Balance Meter. (CA-110)
1. Adjustment for Factory Preset Mode
No read to adjust FOS data for Factory Preset Mode.
2. Adjustment for White Balance
1) Set External Bright to MAX position and Contrast to
MAX position.
2) Display Color 0,0 pattern at Mode 15.
3) Press Menu key, Vp key, Right key of Remote
controller or Menu Buttons in sequence.
4) Select “WHITE BALANCE ADJUST”and Press SET
key.
5) After “INPUT WHITE PATTERN”message, Display
Color 15, 0 pattern at Mode 15.
6) No attempt to manually adjust, BIAS and Drive data
is automatically adjustde and saved to the EEPROM.
7) After “OK”message, Press SET KEY.
8) Select “SERVICE MODE EXIT”and Press SET KEY.
3. DDC Data Write Procedure-Analog
1) Use this procedure only when there is some
problem on Analog EDID data.
2) Run alignment program for LM805L on the IBM
compatible PC.
3) Select EEPROM → Analog EDID write command
and Enter.
4) This will write the Analog EDID data to EEPROM.
4. DDC Data Write Procedure-Digital
1) Use this procedure only when there is some
problem on Digital EDID data.
2) Run alignment program for LM805L on the IBM
compatible PC.
3) Select EEPROM → Digital EDID write command
and Enter.
4) This will write the Digital EDID data to EEPROM.

- 14 -
TROUBLESHOOTING GUIDE
1. OUT OF ORDER ON POWER
POWER LAMP OFF STATE
POWER BOARD OUTPUT CHECK
(5V, 12V, 24V)
KEY CHECK
74LVC541(U25),
CONN(J19)CHECK
OTHER CIRCUIT CHECK
PW166(U8)
INPUT POWER
CHECK
BA033T(U37)
=>3.3V
LM317(U10)
=>2.5STB
INVERTER
INPUT POWER
CHECK
L53,L54 => 24V
MODULE
INPUT POWER
CHECK PIN 1=>
12VS
IRF7314(U35)
=>LCD-VDD
INVERTER CHECK MODULE CHECK
M29W800DT(U19)
INPUT POWER
CHECK
BA033T(U37)
=>3.3V

- 15 -
2.NO RASTER STATE ON ANALOG SIGNAL
NO RASTER ON ANALOG
SIGNAL
CONN(J17) CHECK
CHECK THE PERIPHERAL IC
OF D-SUB(J17)
CHECK THE PERIPHERAL IC
OF AD9883(U4)
CHECK THE PERIPHERAL IC
OF PW166(U8)
CHECK THE PERIPHERAL IC
OF LVDS(U401)
CHECK I/O SYNC OF
74LVC257(U5)
CHECK AD9883 I/O SIGNAL
CHECK PW166(U8) I/O SIGNAL
CHECK LVDS(U401) I/O
SIGNAL
POWER CHECK OF 74LVC257(U5) : U37(3.3V)
POWER CHECK OF AD9883 : U2(DVDD,AVD), L11(V33-ADC)
POWER CHECK OF PW166(U8) :BA033T(U37) =>3.3V, LM317(U10) =>2.5STB
POWER CHECK OF LVDS(U401) : L401(3.3V-LVDS)
NO INPUT SIGNAL
NO OUTPUT SIGNAL
NO OUTPUT SIGNAL
NO INPUT SIGNAL
NO OUTPUT SIGNAL
NO INPUT SIGNAL

- 16 -
3. NO RASTER STATE ON DIGITAL SIGNAL
NO RASTER STATE ON
ANALOG SIGNAL
CONN(J10) CHECK
CHECK THE PERIPHERAL IC
OF D-SUB(J17)
CHECK THE PERIPHERAL IC
OF SIL161(U201)
CHECK THE PERIPHERAL IC
OF PW166(U8)
CHECK THE PERIPHERAL IC
OF LVDS(U401)
CHECK I/O SYNC OF
74LVC257(U5)
CHECK SIL161(U201) I/O
SIGNAL
CHECK PW166(U8) I/O SIGNAL
CHECK LVDS(U401) I/O
SIGNAL
POWER CHECK OF 74LVC257(U5) : U37(3.3V)
POWER CHECK OF AD9883 : U2(DVDD,AVD), L11(V33-ADC)
POWER CHECK OF PW166(U8) : BA033T(U37) =>3.3V, LM317(U10) =>2.5STB
POWER CHECK OF LVDS(U401) : L401(3.3V-LVDS)
POWER CHECK OF SIL161(U201) : L4(AVCC),L5(PVCC)
L9(DVCC),L210(OVCC)
NO INPUT SIGNAL
NO OUTPUT SIGNAL
NO OUTPUT SIGNAL
NO INPUT SIGNAL
NO OUTPUT SIGNAL
NO INPUT SIGNAL

- 17 -
4. NO RASTER ON VIDEO SIGNAL INPUT
NO RASTER ON VIDEO SIGNAL
CHECK CABLE OF
VCR,DVD
CHECK VCR,DVD INPUT SIGNAL
CHECK THE PERIPHERAL IC
OF SAA7114(U7)
CHECK THE PERIPHERAL IC
OF SDA9400(U16)
CHECK THE PERIPHERAL IC
OF LVDS(U401)
CHECK THE PERIPHERAL IC
OF PW166(U8)
CHECK SAA7114(U7) I/O
SIGNAL
CHECK SDA9400(U16) I/O
SIGNAL
CHECK PW166(U8) I/O SIGNAL
CHECK LVDS(U401) I/O
SIGNAL
POWER CHECK OF SAA7114(U7) : L19,L21(3.3V)
POWER CHECK OF SDA9400(U16) : L23(3.3V)
POWER CHECK OF PW166(U8) : BA033T(U37) =>3.3V, LM317(U10) =>2.5STB
POWER CHECK OF LVDS(U401) : L401(3.3V-LVDS)
NO INPUT SIGNAL
NO INPUT SIGNAL
NO OUTPUT SIGNAL
NO OUTPUT SIGNAL
NO INPUT SIGNAL
NO INPUT SIGNAL
NO OUTPUT SIGNAL
NO INPUT SIGNAL

- 18 -
5. SOUND TROBLE SHOOTING
NO SOUND OUTPUT
CHECK SOUND OF VCR,DVD,PC
CHECK THE PERIPHERAL IC
OFMSP3420G(U49)
CHECK SOUND INPUT
=>PC SOUND(J7)
=>VIDEO SOUND
(RDE,WHITE OF J702)
CHECK THE PERIPHERAL IC
CHECK MSP3420G(U49) INPUT
SIGNAL
POWER CHECK OF MSP3420G(U49) : L34,L35,L36(5V)
POWER CHECK OF TDA7268(U39) : 12V
POWER CHECK OF PW166(U8) : BA033T(U37) =>3.3V, LM317(U10) =>2.5STB
NO OUTPUT SIGNAL
NO INPUT SIGNAL
NO INPUT SIGNAL

PRINTED CIRCUIT BOARD
- 19 -
1. MAIN BOARD (Component Side)
C98
J19
R19 R20
J1
Q2
Q5
D6
1
D4
R230
C146
R81
C276
C147
C155
C278
C280
C287
R132
R133
R231
R232
C288
1
J4
R41 R42
C303
C101 C102
C104 C105
L15
D34
E
D35
R216
E
D36 R263
R262 R261 R250 R251
C332 R172
R171C320 C319
X5
70
C311 C310
C308
C325
C328 R168
C182 C302
L34
J7
L16 L62
C197
C317
R135
R84
R85
C77 R95
U21
C96
R264
C183
C184
C388
1
U49
60
C305
R528 R531
R246
C137 C140
ZD8
C91 C111
DATE :2002.11.27
P/N :6870T597A11
MODEL:L3000A
R148
R152
C49 U34
Q9
L2
C383
L35
C375
U32
10
50
C307 C304
R248
R245
ZD7
L64
R237
C156
C42
C374
C384
U20
R269 R270
C95
C97
C331
20
C415
C
C306
R247
ZD28
R526
R185 J5
L68
R236
R235
C143
R136
R153
R47
R179 R180
Q13
R181 C380
U9
Q1
R217
Q4
C144
C141
C142
C16 C15 Q12 R268
R267
C407
L42
30C416 40
C413
C126
R62
C128 C131 C61 C57
C377 R15
C129 C58 C130 C59 C100 C110 C125 C138
ZD29
L67
R529
R183
R4
R45
R167
C68
U23
R212
Q6
R113
R116
R218
U27
U24
L36
Q11
R266
R265
C412
R23 R82 R238
C404
R17
R18
R70
C64
R24
C53
L21
R525
C127
D9
R44
J702
R83
R128
C69
R129
R46
1
U25
C145
20
R79
R229
U18
J6
C196
R63
R68
R80
C48
R75
C62
50
40
30
C47
R523 L70
D12
R150
R66
R131
R130
10
1
U14
R124
C175
20
1
R228 C176 R100
R40
20
R115
R134
R140
L23 L19
C198
R69 R71
R253
C322
C329 C63
60
2010
D11
R532 L71
R182
Q14
R154 R73
R74
C54
10
10
U15
U33
R123 R121
C124
C178
C
R255 R259 R252
C387 C323 C324 C321
C60
80
70
U7
90
C50
C46
100
1
D32
C51
L66
R223
R67 R72
U35
20
U12
C316
R28 R29 R31 R156 R146
C83
R22
C55
L13
C65 C52
X1
D24
R191
D33
R188
ZD1
R222 R224
C385
U11
30
R76
R77
R78
R127
R141
R142 C188
R147 R149
C81
C41
C39
R145 Q22
D27
R97
R195
C89
C88
ZD9
ZD2
D31
R190
C381
L20
10
R108
R109
R90
R106
R117
50
U16
C78
40
RA3 RA25
30
R39
R157
R98
R165
D2D25 D26
R65 R196
R166
R194
C90 ZD6
ZD5
ZD11
ZD10
C40
C44
R30 R16
C36
R64
U22
40
1
R92
R93
R94
R107
R110
R151
R26
C70
C75
C85
60
RA2 RA24
20
R32
R86 R96
Q19
D29 D30
R177 R187
J3
R9
R13
R10 R14
X3
X4
U19
R137
R138
R155
R27
R25
R33
5
10
L3
R173
R206
C12
D28
C11
SOLDERING DIRECTION
J710
1
R403
C38 U6
L27 R37
R125
R99
W
Y
C74
C76 X2
N
P
R
T
U
V
M
LK
JH
G
R126
R91
F
E
D
C
B
A
U8
R35
R208 R219
1
R197 R202
R204
R198
RA5
C67
RA4 RA7
C235
RA6
C10
C9
C106 C107
C410
30
R404 R405
C403
20
RA37
R120
R119 R221
765432
R186
R184R189
C14
C8
C7
R169
R170
C108 C112 C113
5040
R401
C402
10
RA8RA32 RA33
R220
12111098
C24
R54
R58
R59
C23
C118
C35
R55 R56
C116
C117
C33
R5
C25 C34
C234
C18 C17 C31
C32
U1
C6 C5
C3
L8
D5 R38
R207
L31
ZD3
C99
D39
C405
U401
C401
1
RA29
R122
R87
181716151413
C20
60 50 C21 C22
R60 R6
C19 C30
40
R1
C122
C4 C13
C1
L7
R34 R36
C186
R143
U29
L401
RA28
C148
C149
C152
R7 R8
R61
R227
C37
2019
70 30
L17
C123
C2
C121
L18
D1D3 L6
R176
R174
C215
R178
C223
R209 R211
U10
C172
C171
C221 C220 80
1
U4
10 20
L11
R50
D8 D10
R51
R254
R43 L1
D7
D38
C177
L28
1
R175
C204
C203
C132
U37
C801
RA1 RA21 RA19
RA22
RA20 RA23
C26
R105
C227
U2
C71
C120
ZD22
R52
R21
C72
C136
C225
R53
C73
ZD23
Q3
L57
C173
R144
R57
C179
R203
R205
R139
R700
R210 CA207 CA208
RA227 RA228
CA209 CA210
RA229 RA230
CA211 CA212
RA231 RA232
U3
R111
R213
U13
Q10
C153
R12 R342 R11
C248
J17
D37
ZD26
J704
R225
L58
TRANS801
U5
C115
U201
20
10
100
1
R164
R201
U17
D18
R192R193
U30
ZD27
ZD20
1
C158
ZD4
L25 L22
C812 C809
C802
R48R49
R215 R214 R161
4030
90
C217 C218 L5
R114 R112 R118
R103 R104 R102 R101
C103
D17
ZD25
J703
L55
ZD806
C803
20
C805
R804
15
C807
C816
CA206
RA221
R2
R3
50
60
80
70
C216
C150
R271 R272 R273 R274 R275 R276 R277 R278
C43 C109
ZD24
ZD21
C93
L29
C840
L52
U801
C86
C195
CA205
CA203 CA204
RA222
RA223 RA224 RA225 RA226
C154
C94
C806
C185
C82
L59
1
C187
C159
C79
L10
R801
C804
L30
1
C814
L54 L53
1
10
D23
C87
C92
J2
R163
L12
CA201
CA202
R162
L4
L210
L9
R233
R234
J10
J706
J705
L56
C45
R158
R159
R160
C66
D19 D21 ZD13 ZD12
D13 D15 D14
D16 D20
D22
ZD17 ZD16
ZD15 ZD14 ZD19
ZD18

- 20 -
2. MAIN BOARD (Solder Side)
L32
L33
L37
L41
L46 L45
L43
L48
L26
L44
1
L47
1
L24
L38
L39
L40
L14L14L51L51
C190
C189
TP455
C313
C139
C151
R200
C165
C166
C160
C157
C135
R199
C164
R88
R89
C170
C162
C161
C163
C167
C169
C168
C133
C134
C29
C28
C27
C811
C224
L49
C119
C810
C174 C206
C219
C214C209
C56
C208 C213C242 C212
C211
C210
C181 C180
TP815
C84
C201 C200
C80
C114
