LG 27UD68-W User manual

www.lg.com
Please read the safety information carefully before using the
product.
LED LCD Monitor (LED Monitor) Model List
Owner's Manual
LED LCD MONITOR
(LED MONITOR*)
*LG LED Monitors are LCD Monitors with LED Backlighting.
27UD68

2
ENG
ENGLISH
Contents
CONTENTS
16 USER SETTINGS
17 Customizing settings
17 - Menu Settings
17 - -Quick Settings
18 - -PBP
19 - -Picture
22 - -General
23 - -Reset
24 TROUBLESHOOTING
26 SPECIFICATIONS
26 27UD68
27 Factory Support Mode (Preset Mode, PC)
27 HDMI
27 DisplayPort
28 HDMI Timing (Video)
28 Power LED
3LICENSE
4ASSEMBLING AND
PREPARING
4Product Components
5Component and Button Description
5- How to Use the Joystick Button
6Input Connector
7Moving and Lifting the Monitor
8Installing the Monitor
8- Assembling the stand base
9- Detaching the Stand Base
10 - Using the cable holder
10 - Installing onto a table
11 - Adjusting the angle
12 - Using the Kensington lock
12 - Installing the wall mount plate
13 - Installing to a wall
14 USING THE MONITOR
14 Connecting to a PC
14 - HDMI connection
14 - DisplayPort connection
15 Connecting to AV Devices
15 - HDMI connection
15 Connecting to External Devices
15 - Connecting Headphones

3
ENG
ENGLISH
LICENSE
LICENSE
Each model has different licenses. Visit www.lg.com for more information on the license.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the
HDMI Logo are trademarks or registered trademarks of HDMI Licensing Ad-
ministrator, Inc.
VESA, VESA logo, DisplayPort Compliance Logo and DisplayPort
Compliance Logo for dual-mode source are all registered trademarks of the
Video Electronics Standards Association.
The following content is only applied to the monitor which is sold in Europe market and which needs to meet
the ErP Directive:
* This monitor is set to be turned off automatically in 4 hours after you turned on display if there is no
adjustment to display.
* To make this setting be disabled, change the option to ‘Off’ in OSD menu of “Automatic Standby”.

4
ENG
ENGLISH
ASSEMBLING AND PREPARING
ASSEMBLING AND PREPARING
Product Components
Please check whether all the components are included in the box before using the product. If there are
missing components, contact the retail store where you purchased the product. Note that the product and
components may look different from those shown here.
yAlways use genuine components to ensure safety and product performance.
yThe product warranty will not cover damage or injury caused by the use of counterfeit components.
yIt is recommend that use the supplied components.
yIf you use generic cables not certified by LG, the screen may not display or there may be image
noises.
yNote that the components may look different from those shown here.
yWithout prior notice, all information and specifications in this manual are subject to change to im-
prove the performance of the product.
yTo purchase optional accessories, visit an electronics store or online shopping site or contact the
retail store where you purchased the product.
CAUTION
NOTE
CD / Card
DisplayPort Cable
Stand Base Stand Body
HDMI Cable
( This cable is not in-
cluded in all countries. )
( Depending on the country ) ( Depending on
the country )
Power Cord AC-DC Adapter AC-DC Adapter
or
Cable Holder Screw Cover 2 Screws

5
ENG
ENGLISH
ASSEMBLING AND PREPARING
Component and Button Description
Power LED
yOn: power is on
yOff: power is off
Joystick Button
How to Use the Joystick Button
You can easily control the functions of the monitor by pressing the joystick button or moving it left/right with
your finger.
Basic Functions
Power on Press the joystick button once with your finger to turn on the
monitor.
Power off Press and hold the joystick button once with your finger to turn off
the monitor.
◄/►Volume
Control You can control the volume by moving the joystick button left/right.
yThe joystick button is located at the bottom of the monitor.
NOTE

6
ENG
ENGLISH
ASSEMBLING AND PREPARING
Input Connector

7
ENG
ENGLISH
ASSEMBLING AND PREPARING
Moving and Lifting the Monitor
When moving or lifting the monitor, follow these
instructions to prevent the monitor from being
scratched or damaged and to ensure safe trans-
portation regardless of its shape or size.
yAs far as possible, avoid touching the moni-
tor screen. This may result in damage to the
screen or some of the pixels used to create
images.
yIt is advisable to place the monitor in the
original box or packing material before at-
tempting to move it.
yBefore moving or lifting the monitor, discon-
nect the power cord and all cables.
yHold the top and bottom of the monitor frame
firmly. Do not hold the panel itself.
yWhen holding the monitor, the screen should
face away from you to prevent it being
scratched.
yWhen moving the monitor, avoid any strong
shock or vibrations to the product.
yWhen moving the monitor, keep it upright,
never turn the monitor on its side or tilt it
sideways.
CAUTION
yIf you use the monitor panel without the
stand base, its joystick button may cause
the monitor to become unstable and fall,
resulting in damage to the monitor or human
injury. In addition, this may cause the joystick
button to malfunction.

8
ENG
ENGLISH
ASSEMBLING AND PREPARING
Installing the Monitor
Assembling the stand base
yTo protect the screen from scratches, cover
the surface with a soft cloth.
CAUTION
1Place the screen face down.
3
2Check the direction of the stand body
(front, back) and then mount the stand body
onto the stand hinge.
Use a tool to attach the stand body as shown
in the figure.
Stand Body
Stand Body
Stand Base
Screw Cover
Attach the Stand Base to Stand Body.
Tighten the screw to the right.
1
2
4Attach the screw cover.
Applying excessive force when tightening
the screws may cause damage to the moni-
tor. Damage caused in this way will not be
covered by the product warranty.
CAUTION
It may hurt your foot off the stand, so be
careful.
CAUTION

9
ENG
ENGLISH
ASSEMBLING AND PREPARING
Detaching the Stand Base
Screw Cover
Stand Body
Stand Base
1 Place the screen face down.
yTo protect the screen from scratches, cover
the surface with a soft cloth.
CAUTION
2
3
Turn the screw to the left.
Pull out the Stand Base.
As shown in the illustration, pull Screw Cover
out to separate it from the set.
4Remove the two screws on the back of stand
body.
As shown in the illustration, disconnect the
stand body from the stand hinge.
1
2
yIllustrations in this document represent typi-
cal procedures, so they may look different
from the actual product.
yApplying excessive force when tightening
screws may cause damage to the monitor.
Damage caused in this way will not be cov-
ered by the product warranty.
yBe careful not to hurt your hand on the edges
of the screw covers.
yDo not carry the monitor upside down by just
holding the base. This may cause the moni-
tor to fall off the stand and could result in
personal injury.
yWhen lifting or moving the monitor, do not
touch the monitor screen. The force applied
to the monitor screen may cause damage to
it.
CAUTION
It may hurt your foot off the stand, so be
careful.
CAUTION

10
ENG
ENGLISH
ASSEMBLING AND PREPARING
Using the cable holder
Cable Holder
Arrange the cables using the cable holder as
shown in the illustration.
Installing onto a table
1Lift the monitor and place it on the table in an
upright position.
Place at least 100 mm away from the wall to
ensure sufficient ventilation.
2Connect the power adapter to the monitor and
then plug the power cord into the wall outlet.
or
yUnplug the power cord prior to moving or
installing the monitor. There is risk of electric
shock.
CAUTION
3Press the joystick button on the bottom of the
monitor to turn on the monitor.
100 mm
100 mm
100 mm
100 mm

11
ENG
ENGLISH
ASSEMBLING AND PREPARING
Adjusting the angle
1Place the monitor in an upright position, mount-
ed on the stand base.
2Adjust the angle of the screen. The angle of the
screen can be adjusted forwards or backwards
for a comfortable viewing experience.
Front SideRear Side
yTo avoid injury to the fingers when adjusting
the screen, do not hold the lower part of the
monitor's frame as illustrated below.
WARNING
yBe careful not to touch or press the screen
area when adjusting the angle of the monitor.

12
ENG
ENGLISH
ASSEMBLING AND PREPARING
Installing the wall mount plate
This monitor supports the specification of the stan-
dard wall mount plate or compatible device.
1Place the screen face down. To protect the
screen from scratches, cover the surface with a
soft cloth.
2Place the wall mount plate onto the monitor
and align it with the screw holes.
3Tighten the four screws to fix the plate to the
monitor using a screwdriver.
yThe wall mount plate is sold separately.
yFor more information on installation, refer to
the wall mount plate's installation guide.
yBe careful not to use excessive force when
mounting the wall mount plate, as this can
damage the monitor's screen.
NOTE
yUse of the Kensington lock is optional.
The accessories can be purchased at
your local electronics store.
NOTE
Using the Kensington lock
The Kensington security system connector is locat-
ed at the back of the Monitor set.
For more information on installation and usage,
refer to the Kensington lock user manual or visit
the website at http://www.kensington.com.
Connect the Kensington security system cable
between the Monitor set and a table.

13
ENG
ENGLISH
ASSEMBLING AND PREPARING
To install the monitor to a wall, attach a wall mount-
ing bracket (optional) to the back of the monitor.
Make sure that the wall mounting bracket is securely
fixed to the monitor and to the wall.
1If you use screw longer than standard, the moni-
tor might be damaged internally.
2If you use improper screw, the product might be
damaged and drop from mounted position.
In this case, LG Electronics is not responsible
for it.
Installing to a wall
Install the monitor at least 100 mm away from the
wall and leave about 100 mm of space at each
side of the monitor to ensure sufficient ventilation.
Detailed installation instructions can be obtained
from your local retail store. Please refer to the
manual to install and set up a tilting wall mounting
bracket.
yUnplug the power cord before moving or in-
stalling the monitor to avoid electric shocks.
yInstalling the monitor on the ceiling or on a
slanted wall may result in the monitor falling
off, which could lead to injury. Please use
the genuine LG wall mounting bracket. For
more information, contact your local retail
store or a qualified installer.
yApplying excessive force when fastening
screws may cause damage to the moni-
tor. Damage caused in this way will not be
covered by the product warranty.
yUse the wall mounting bracket and screws
that conform to the VESA standard. Dam-
age caused by the use or misuse of inap-
propriate components will not be covered
by the product warranty.
yScrew length from outer surface of back
cover should be under 8mm.
yUse the screws specified by the VESA stan-
dard.
yThe wall mount kit includes the installation
guide and all necessary parts.
yThe wall mounting bracket is optional. The
accessories can be purchased at your local
retail store.
yThe length of the screw may differ for each
wall mounting bracket. Ensure the correct
length screw is used.
yFor more information, please refer to the
user manual for the wall mounting bracket.
CAUTION
NOTE
Wall mount Pad
Wall mount Pad
Back Cover
Back Cover
Standard screw
Max.8mm
yWall Mount (A x B)
A
B
Wall Mount (A x B) 100 x 100
Standard screw M4 x L10
Number of screws 4
Wall Mount Plate
(Optional)
LSW 149
100 mm
100 mm
100 mm
100 mm

14
ENG
ENGLISH
USING THE MONITOR
USING THE MONITOR
Connecting to a PC
yThis monitor supports the *Plug and Play
feature.
*Plug and Play: A feature that allows you to
add a device to your computer without having
to reconfigure anything or install any manual
drivers.
yThere may be no video or audio output de-
pending on the DP version of the PC.
yIf you use generic cables not certified by LG,
the screen may not display or there may be
image noises.
DisplayPort connection
Transmits the digital video and audio signals from
your PC to the monitor. Connect your PC to the
monitor using the DisplayPort cable as illustrated
below.
Press the menu button and then select the input
option from the input menu.
NOTE
HDMI connection
Transmits the digital video and audio signals from
your PC and A/V devices to the monitor. Connect
your PC and AV device to the monitor with the
HDMI cable as illustrated below.
Press the menu button and then select the input
option from the input menu.
NOTE
yIf you use HDMI PC, it can cause compatibility
problem.
yUse a certified cable with the HDMI logo
attached. If you do not use a certified HDMI
cable, the screen may not display or a
connection error may occur.
yRecommended HDMI cable types
- High-Speed HDMI®/TM Cable
- High-Speed HDMI®/TM Cable with Ethernet

15
ENG
ENGLISH
USING THE MONITOR
Connecting to AV Devices
HDMI connection
Transmits the digital video and audio signals from
your PC and A/V devices to the monitor. Connect
your PC and AV device to the monitor with the
HDMI cable as illustrated below.
Press the menu button and then select the input
option from the input menu.
NOTE
yIf you use HDMI PC, it can cause compatibility
problem.
yUse a certified cable with the HDMI logo
attached. If you do not use a certified HDMI
cable, the screen may not display or a
connection error may occur.
yRecommended HDMI cable types
- High-Speed HDMI®/TM Cable
- High-Speed HDMI®/TM Cable with Ethernet
Connecting to External Devices
(sold separately)
Connecting Headphones
Connect peripherals to the monitor via the head-
phones port. Connect as illustrated.
yPeripheral devices are sold separately.
yIf you use angled earphones, it may cause
a problem with connecting another external
device to the monitor. Therefore, it is recom-
mended to use straight earphones.
Angled Straight
yDepending on the audio settings of the PC
and external device, headphones and speaker
functions may be limited.
NOTE

16
ENG
ENGLISH
User Settings
Button Menu Status Description
Main menu disabled Enables the main menu.
Main menu enabled
Exits the main menu.
(Holding down the button to turn off the monitor. You can turn off
the monitor this way at any time, including when the OSD is on.)
◄
Main menu disabled Adjusts the monitor volume level.
Main menu enabled Enters the menu features.
►
Main menu disabled Adjusts the monitor volume level.
Main menu enabled Enters the input feature.
▲Main menu disabled Enables the main menu.
Main menu enabled Enters the game mode feature.
▼
Main menu disabled Enables the main menu.
Main menu enabled Turns off the monitor.
Main Menu Features
Main Menu Description
Menu Configures the screen settings.
Game Mode You can change Picture Mode to a gaming
mode.
Input Sets input mode.
Monitor off Turns off the monitor.
Exit Exits the main menu.
USER SETTINGS
Activating the Main Menu
1 Press the joystick button on the bottom of the monitor.
2 Move the joystick up/down (▲/▼) and left/right(◄/►) to set the options.
3 Press the joystick button once more to exit the main menu.
Joystick Button

17
ENG
ENGLISH
User Settings
Each option is described below.
Customizing settings
Menu Settings
-Quick Settings
1 To view the OSD menu, press the joystick button at
the bottom of the monitor and then enter the Menu.
2 Go to Quick Settings > Brightness by moving the
joystick.
3 Configure the options following the instructions that
appear in the bottom right corner.
4 To return to the upper menu or set other menu items,
move the joystick to ◄ or pressing ( / OK) it.
5 If you want to exit the OSD menu, move the joystick
to ◄ until you exit.
Menu > Quick Settings Description
Brightness Adjusts the color contrast and brightness of the screen.
Contrast
Volume Adjusts the volume.
NOTE
yJog joystick button down (
) in the Volume menu will
enable/disable the Mute function.
Input Selects the current input mode.
Ratio Adjusts the screen ratio.
Wide Displays the video in wide-screen, regardless of the video signal input.
Original Displays a video according to the input video signal aspect ratio.
1:1 The aspect ratio is not adjusted from the original.
NOTE
yThe display may look the same for Wide, Original, and 1:1 options at the recommended resolution.
yThe ratio is disabled in the interlaced signal.

18
ENG
ENGLISH
User Settings
Each option is described below.
-PBP
1 To view the OSD menu, press the joystick button at
the bottom of the monitor and then enter the Menu.
2 Go to PBP by moving the joystick.
3 Configure the options following the instructions that
appear in the bottom right corner.
4 To return to the upper menu or set other menu items,
move the joystick to ◄ or pressing ( / OK) it.
5 If you want to exit the OSD menu, move the joystick
to ◄ until you exit.
Menu > PBP Description
Sub Displays the screens of two input modes on one monitor.
PBP Connection Sub Screen (Right)
HDMI 1 HDMI 2 DisplayPort
Main Screen
(Left)
HDMI 1 - - O
HDMI 2 - - O
DisplayPort O O -
Sound Out Changes the audio output in PBP mode.
Swap Toggles between the main screen and sub screen in PBP mode.
Sub Full Converts the sub screen of PBP mode to the wide screen.
Ratio Adjusts the aspect ratio of the main screen or sub screen.
Main Wide Displays the video to fit the PBP screen, regardless of the video signal input.
Original Displays the video in the aspect ratio of the video signal input on the PBP screen.
Sub Wide Displays the video to fit the PBP screen, regardless of the video signal input.
Original Displays the video in the aspect ratio of the video signal input on the PBP screen.
NOTE
yWhen the Sub mode is Off, Sound Out, Swap, Sub Full, and Ratio menus become disabled.
The Main/Sub options for Ratio become disabled if there is no signal.
yThe optimal resolution for PBP mode is set automatically when PBP mode is set.

19
ENG
ENGLISH
User Settings
Menu > Picture Description
Picture Mode Custom Allows the user to adjust each element. The color mode of the main menu can be
adjusted.
Reader Optimizes the screen for viewing documents. You can brighten the screen in the OSD
menu.
Photo Optimizes the screen for photos.
Cinema Optimizes the screen for video.
sRGB A standard RGB color space for the monitor and printer.
Color
Weakness
This mode is for users who cannot distinguish between red and green. It enables
users with color weakness to easily distinguish between the two colors.
FPS Game 1 This mode is optimized for FPS games.
FPS Game 2 It has a higher Black Stabilizer value than FPS Game 1. It is suitable for very dark
FPS games.
RTS Game This mode is optimized for RTS Game.
Custom
(Game)
In this mode, users can customize various elements including game-related options.
NOTE
yIf the picture mode is changed in the DP (DisplayPort) input, the screen
may flicker or the resolution of your PC screen may be affected.
Each option is described below.
-Picture
1 To view the OSD menu, press the joystick button at
the bottom of the monitor and then enter the Menu.
2 Go to Picture by moving the joystick.
3 Configure the options following the instructions that
appear in the bottom right corner.
4 To return to the upper menu or set other menu items,
move the joystick to ◄ or pressing ( / OK) it.
5 If you want to exit the OSD menu, move the joystick
to ◄ until you exit.

20
ENG
ENGLISH
User Settings
Picture Adjust SUPER
RESOLUTION+
High Optimized picture quality is displayed when a user wants
crystal clear images. It is effective for high quality video or
game.
Middle The optimized picture quality is displayed when a user
wants images between low and high modes for comfortable
viewing. It is effective for UCC or SD video.
Low The optimized picture quality is displayed when a user
wants smooth and natural images. It is effective for slow-
moving pictures or still images.
Off Select this option for everyday viewing. SUPER RESOLU-
TION+ is turned off in this mode.
Sharpness Adjusts the sharpness of the screen.
Black Level Sets the offset level (for HDMI only).
yOffset: as a reference for a video signal, this is the darkest color the
monitor can display.
High Keeps the current contrast ratio of the screen.
Low Lowers the black levels and raises the white levels from the
current contrast ratio of the screen.
HDMI ULTRA HD Deep
Color
Provides sharper images when connected to a device supporting UL-
TRA HD Deep Color.
4K@60 Hz Support Format1)
Resolution Frame rate
(Hz)
Color Depth / Chroma Sampling
8 bit 10 bit
3840 x 2160 59.94
60.00
YCbCr 4:2:0
YCbCr 4:2:2
YCbCr 4:4:4 -
RGB 4:4:4 -
1) Supported when HDMI ULTRA HD Deep Color is set to On.
DFC Adjusts the brightness automatically according to the screen.
NOTE
yIf the connected device does not support ULTRA HD Deep
Color, the feature may not work properly.
yIf a problem occurs, set the HDMI ULTRA HD Deep Color option
to Off.
