LG 32MN500M-B.AAU User manual

* Disclaimer : LG LED Monitor applies LCD screen with LED backlights.
This product is a computer monitor and not for television purpose.
Please read this manual carefully before operating your set and retain it for
future reference.
32MN500M
32MN50W
32MN60T
OWNER’S MANUAL
LED LCD COMPUTER
MONITOR
(LED Computer Monitor*)
www.lg.com
Copyright © 2018 LG Electronics Inc. All Rights Reserved.

2
ENGLISH
LICENSE
Each model has different licenses. Visit www.lg.com for more information on the license.
The terms HDMI and HDMI High-Definition Multimedia Interface,
and the HDMI Logo are trademarks or registered trademarks of
HDMI Licensing Administrator, Inc.
TABLE OF CONTENTS
LICENSE ...................................................... 2
OPEN SOURCE SOFTWARE NOTICE
INFORMATION ............................................ 3
ASSEMBLING AND PREPARING .................. 3
USING THE MONITOR.................................. 8
USER SETTINGS ........................................ 10
TROUBLESHOOTING ................................. 18
PRODUCT SPECIFICATION......................... 20

3
ENGLISH
OPEN SOURCE SOFTWARE NOTICE
INFORMATION
To obtain the source code under GPL, LGPL, MPL, and other open source licenses, that is contained in this product,
please visit http://opensource.lge.com.
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available
for download.
LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing
such distribution (such as the cost of media, shipping, and handling) upon email request to [e-mail].
This offer is valid for a period of three years after our last shipment of this product.This offer is valid to anyone in
receipt of this information.
ASSEMBLING AND PREPARING
CAUTION
•Always use genuine LG components to ensure safety and product performance.
•The product warranty will not cover damage or injury caused by the use of unauthorized components.
•It is recommended that use the supplied components.
•If you use generic cables not certified by LG, the screen may not display or there may be image noises.
•Illustrations in this document represent typical procedures, so they may look different from the actual product.
•Do not apply foreign substances (oils, lubricants, etc.) to the screw parts when assembling the product. (Doing
so may damage the product.)
•Applying excessive force when tightening screws may cause damage to the monitor. Damage caused in this
way will not be covered by the product warranty.
•Do not carry the monitor upside down by just holding the base. This may cause the monitor to fall off the stand
and could result in personal injury.
•When lifting or moving the monitor, do not touch the monitor screen. The force applied to the monitor screen
may cause damage to it.
NOTE
•The components may look different from those illustrated here.
•Without prior notice, all product information and specifications contained in this manual are subject to change
to improve the performance of the product.
•To purchase optional accessories, visit an electronics store or an online shopping site, or contact the retailer
from which you purchased the product.
•The power cord provided may differ depending upon the region.
Supported Drivers and Software
You can download and install the latest version from the LGE website (www.lg.com).
Drivers and Software Installation Priority
Monitor Driver Recommended
OnScreen Control Recommended

4
ENGLISH
Product and Button Description
Joystick Button
How to Use the Joystick Button
You can easily control the functions of the monitor by pressing the joystick button or moving it left/right/up/
down with your finger.
Basic Functions
Power on Press the joystick button once with your finger
to turn on the monitor.
Power off
Press and hold the joystick button once more
than 3 seconds with your finger to turn off the
monitor.
/ Volume control You can control the volume by moving the
joystick button left/right.
NOTE
•The joystick button is located at the bottom of the monitor.
Moving and Lifting the Monitor
When moving or lifting the monitor, follow these instructions to prevent the monitor from being scratched or
damaged and to ensure safe transportation, regardless of its shape or size.
•Place the monitor in the original box or packing material before attempting to move it.
•Before moving or lifting the monitor, disconnect the power cord and all other cables.
•Hold the bottom and side of the monitor frame firmly. Do not hold the panel itself.
•When holding the monitor, the screen should face away from you to prevent it from being scratched.
•When transporting the monitor, do not expose the monitor to shock or excessive vibration.
•When moving the monitor, keep it upright and never turn the monitor on its side or tilt it sideways.
CAUTION
•Avoid touching the monitor screen as much as possible.
-This may result in damage to the screen or some of the pixels used to create images.
•If you use the monitor panel without the stand base, its joystick button may cause the monitor to become
unstable and fall, resulting in damage to the monitor or human injury. In addition, this may cause the joystick
button to malfunction.

5
ENGLISH
Installing on a Table
•Lift the monitor and place it on the table in an upright position. Place the monitor at least 100mm away from
the wall to ensure sufficient ventilation.
100 mm
100 mm
100 mm
100 mm
CAUTION
•Unplug the power cord before moving or installing the monitor.There is risk of electric shock.
•Make sure to use the power cord that is provided in the product package and connect it to a grounded power
outlet.
•If you need another power cord, please contact your local dealer or the nearest retail store.
Adjusting the Angle
1 Place the monitor mounted on the stand base in an upright position.
2 Adjust the angle of the screen.
The angle of the screen can be adjusted forward or backward from -5° to 15° for a comfortable viewing
experience.
WARNING
•To avoid injury to the fingers when adjusting the screen, do not hold the lower part of the monitor’s frame as
illustrated below.
•Be careful not to touch or press the screen area when adjusting the angle of the monitor.

6
ENGLISH
Using the Kensington Lock
The connector for the Kensington security system is located at the bottom of the monitor.
For more information on installation and usage, refer to the Kensington lock owner’s manual or visit the website
at http://www.kensington.com.
Connect the monitor to a table using the Kensington security system cable.
NOTE
•The Kensington security system is optional. You can obtain optional accessories from most electronics stores.
Installing the Wall Mount Plate
This monitor meets the specifications for the wall mount plate or other compatible devices.
NOTE
•The wall mount plate is sold separately.
•For more information on installation, refer to the wall mount plate’s installation guide.
•Be careful not to apply too much force while mounting the wall mount plate as it may cause damage to the
screen.
•Remove the stand before installing the monitor on a wall mount by performing the stand attachment in
reverse.
Installing on the Wall
Install the monitor at least 100mm away from the wall and leave about 100mm of space at each side of the
monitor to ensure sufficient ventilation. Detailed installation instructions can be obtained from your local retail
store. Alternatively, please refer to the manual for how to install and set up a tilting wall mounting bracket.
100 mm
100 mm
100 mm
100 mm

7
ENGLISH
CAUTION
•Unplug the power cord before moving or installing the monitor to avoid electric shock.
•Installing the monitor on the ceiling or on a slanted wall may result in the monitor falling off, which could lead
to injury. Use an authorized LG wall mount and contact the local dealer or qualified personnel.
•To prevent injury, this apparatus must be securely attached to the wall in accordance with the installation
instructions.
•Applying excessive force when tightening screws may cause damage to the monitor. Damage caused in this
way will not be covered by the product warranty.
•Use the wall mounting bracket and screws that conform toVESA standards. Damage caused by the use or
misuse of inappropriate components will not be covered by the product warranty.
•When measured from the back of the monitor, the length of each installed screw must be 8 mm or less.
Wall Mount Plate
Back of the Monitor
Standard screw:
M4 x L10
Wall Mount Plate
Back of the Monitor
Max. 8 mm
To install the monitor to a wall, attach a wall mounting bracket (optional) to the back of the monitor.
Make sure that the wall mounting bracket is securely fixed to the monitor and to the wall.
Wall Mount (mm) 100 x 100
Standard screw M4 x L10
Number of screws 4
Wall Mount Plate (Optional) LSW 149
NOTE
•A non-VESA standard screw may damage the product and cause the monitor to fall. LG Electronics is not liable
for any accidents relating to the use of non-standard screws.
•The wall mount kit includes the installation guide and all necessary parts.
•The wall mounting bracket is optional. You can obtain optional accessories from your local dealer.
•The length of the screw may differ for each wall mounting bracket. If you use screws longer than the standard
length, it may damage the inside of the product.
•For more information, please refer to the user manual for the wall mounting bracket.

8
ENGLISH
USING THE MONITOR
•Illustrations in this manual may differ from the actual product.
Press the joystick button, go to Settings Input, and then select the input option.
CAUTION
•Do not press the screen for a prolonged time. This may cause image distortion.
•Do not display a still image on the screen for a prolonged time. This may cause image retention. Use a PC
screensaver if possible.
•When connecting the power cord to the outlet, use a grounded (3-hole) power strip or a grounded power
outlet.
•The monitor may flicker when turned on in an area where the temperature is low. This is normal.
•Sometimes red, green, or blue spots may appear on the screen. This is normal.
Connecting to a PC
•This monitor supports the *Plug and Play feature.
* Plug and Play: A feature that allows you to add a device to your computer without having to reconfigure
anything or install any manual drivers.
HDMI Connection
Transmits digital video and audio signals from your PC to the monitor.
CAUTION
•Using a DVI to HDMI / DP (DisplayPort) to HDMI cable may cause compatibility issues.
•Use a certified cable with the HDMI logo attached. If you do not use a certified HDMI cable, the screen may not
display or a connection error may occur.
•Recommended HDMI cable types
-High-Speed HDMI®/TM cable
-High-Speed HDMI®/TM cable with Ethernet
D-SUB connection
Transmits analog video from your PC to the Monitor set. Connect the PC and the Monitor set with the supplied
D-sub 15 pin signal cable as shown in the following illustrations.
NOTE
•When using a D-Sub signal input cable connector for Macintosh
•Mac adapter
For Apple Macintosh use, a separate plug adapter is needed to change the 15 pin high density (3 row) D-SUB
VGA connector on the supplied cable to a 15 pin 2 row connector.

9
ENGLISH
Connecting Peripherals
Headphones Connection
Connect peripherals to the monitor via the headphones port.
NOTE
•Peripheral devices are sold separately.
•Depending on the audio settings of the PC and external device, headphones and speaker functions may be
limited.
•If you use angled earphones, it may cause a problem with connecting another external device to the monitor.
Therefore, it is recommended to use straight earphones.
Angled Straight
(Recommend)

10
ENGLISH
USER SETTINGS
NOTE
•Your monitor’s OSD (On Screen Display) may differ slightly from that shown in this manual.
Activating the Main Menu
1 Press the joystick button on the bottom of the monitor.
2 Move the joystick up/down and left/right to set the options.
3 Press the joystick button once more to exit the main menu.
Joystick Button
Button Menu Status Description
Main menu disabled Enables the main menu.
Main menu enabled Exits the main menu.
(Holding down the button more than 3 seconds to turn off the monitor. You can turn off the monitor this way at any time, including when the OSD is on.)
Main menu disabled Adjusts the monitor volume level.
Main menu enabled Enters the Input features.
Main menu disabled Adjusts the monitor volume level.
Main menu enabled Enters the Settings feature.
Main menu disabled Displays the information on the current input.
Main menu enabled Turns off the monitor.
Main menu disabled Displays the information on the current input.
Main menu enabled Enters the Picture Mode feature.(for HDMI only)

11
ENGLISH
Main Menu Features
Power Off
Input Settings
Picture Mode
Exit
(for HDMI only)
Main Menu Description
Input Sets input mode.
Power Off Turns off the monitor.
Settings Configures the screen settings.
Picture Mode Sets the picture mode.
Exit Exits the main menu.
Auto Configuration Operate the Auto Configuration for optimal display in D-SUB.
Power Off
Input Settings
Auto Configuration
Exit
(for D-SUB only)

12
ENGLISH
Menu Settings
1 To view the OSD menu, press the joystick button at the bottom of the monitor and then enter the Settings.
2 Move the joystick up/down and left/right to set the options.
3 To return to the upper menu or set other menu items, move the joystick to or pressing ( ) it.
4 If you want to exit the OSD menu, move the joystick to until you exit.
Quick Settings Input Picture General

13
ENGLISH
Customizing settings
Settings > Quick Settings Description
Brightness
Adjusts the contrast and brightness of the screen.
Contrast
Volume
Adjusts the volume.(for HDMI only)
NOTE
•You can adjust Mute / Unmute by moving the joystick button to in the Volume menu.
Settings > Input Description
Input List Selects the input mode.
Aspect Ratio
Adjusts the aspect ratio of the screen.
Full Wide Displays the video in wide-screen, regardless of the video signal input.
Original Displays video according to the aspect ratio of the video signal input.
NOTE
•The options may disabled at the recommended resolution (1920 x 1080).

14
ENGLISH
Customizing settings
Settings > Picture Description
Picture Mode
Custom Allows the user to adjust each element. The color mode of the main menu can be adjusted.
Reader Optimizes the screen for viewing documents. You can brighten the screen in the OSD menu.
Photo Optimizes the screen to view photos.
Cinema Optimizes the screen to improve the visual effects of a video.
Color Weakness This mode is for users who cannot distinguish between red and green. It enables users with color weakness to easily distinguish between the two colors.
Game Optimizes the screen for gameplay.
Picture Adjust
Brightness Adjusts the contrast and brightness of the screen.
Contrast
Sharpness Adjusts the sharpness of the screen.
SUPER
RESOLUTION+
Off Select this option for everyday viewing. SUPER RESOLUTION+ is turned off in this mode.
High Optimized picture quality is displayed when a user wants crystal clear images. It is effective forhigh quality video or game.
Middle The optimized picture quality is displayed when a user wants images between low and high modes for comfortable viewing. It is effective
for UCC or SD video.
Low The optimized picture quality is displayed when a user wants smooth and natural images. It is effective for slow -moving pictures or still
images.
Black Level Sets the offset level (for HDMI only).
•Offset: as a reference for a video signal, this is the darkest color the monitor can display.
High Keeps the current contrast ratio of the screen.
Low Lowers the black levels and raises the white levels from the current contrast ratio of the screen.
DFC On Adjusts the brightness automatically according to the screen.
Off Disables the DFC feature.
NOTE
•This is subsidiary for color weakness user.Therefore if you feel uncomfortable with the screen, please turn off this function.
•This function can’t distinguish some colors in some images.

15
ENGLISH
Game Adjust
Response Time
Sets a response time for displayed pictures based on the speed of the screen.
For a normal environment, it is recommended that you use Fast.
For a fast-moving picture, it is recommended that you use Faster.
Setting to Faster may cause image sticking.
Faster Sets the response time to faster.
Fast Sets the response time to fast.
Normal Sets the response time to normal.
Off Does not use the response time improvement feature.
FreeSync
Provides seamless and natural images by synchronizing the vertical frequency of the input signal with that of the output signal.
CAUTION
•Supported Interface: HDMI.
•Supported Graphic Card : A graphic card that supports AMD’s FreeSync is necessary.
•Supported Version : Make sure to update the graphic card to the latest driver.
•For more information and requirement, refer to AMD website at http://www.amd.com/FreeSync
On FreeSync function on.
Off FreeSync function off.
Black Stabilizer Black Stabilizer:
You can control the black contrast to have better visibility in dark scenes.
Increasing the Black Stabilizer value brightens the low gray level area on the screen.
(You can easily distinguish objects on dark game screens.)
Reducing the Black Stabilizer value darkens the low gray level area and increases the dynamic contrast on the screen.
Cross Hair Cross Hair provides a mark on the center of the screen for First Person Shooter(FPS) games. Users can select the cross hair that fits their gaming environment
among four different cross hairs.
•When the monitor is off or enters energy saving mode, the Cross Hair feature is automatically turned off.

16
ENGLISH
Color Adjust
Gamma Mode 1, Mode 2,Mode 3 The higher the gamma value, the darker the image becomes. Likewise, the lower the gamma value, the lighter the image
becomes.
Mode 4 If you do not need to adjust the gamma settings, select Mode 4.
Red/Green/Blue You can customize the picture color using Red, Green, and Blue colors.
Configuration Adjust (D-SUB only)
Horizontal To move image left and right.
Vertical To move image up and down.
Clock To minimize any vertical bars or stripes visible on the screen background.The horizontal screen size will also change.
Phase To adjust the focus of the display. This item allows you to remove any horizontal noise and clear or sharpen the image of characters.
Resolution (D-SUB only)
User can set the desired resolution.This option is enabled only when the screen resolution on your computer is set to the following(D-SUB only).
NOTE
The function is enabled only when the screen resolution on your computer is set to the following, except that the PC output wrong resolution.
1024x768, 1280x768, 1360x768, 1366x768,Off
1280x960, 1600x900,Off
1440x900, 1600x900,Off
Picture Reset
Do you want to reset your settings?
No Cancel the select.
Yes Returns to the default settings.

17
ENGLISH
Customizing settings
Settings > General Description
Language To choose the language in which the control names are displayed.
SMART ENERGY SAVING
High Saves energy using the high-efficiency SMART Energy Saving feature.
Low Saves energy using the low-efficiency SMART Energy Saving feature.
Off Disables the SMART Energy Saving feature.
Automatic Standby The monitor will automatically switch to standby mode after a certain period.
OSD Lock
Prevents incorrect key input.
On Key input is disabled.
NOTE
•All function except for the OSD Lock mode, brightness, Contrast, Input, Information andVolume are disabled.
Off Key input is enabled.
Information The display information will be shown the Model, Serial Number, Total Power On Time, Resolution.
Reset
Do you want to reset your settings?
No Cancel the select.
Yes Returns to the default settings.
NOTE
•The value of energy saving data may differ depending on panel and panel suppliers.
•If you select the option of SMART ENERGY SAVING is High or Low, monitor luminance become lower or higher depend on source.

18
ENGLISH
TROUBLESHOOTING
Nothing is displayed on the screen.
Is the monitor's power cord plugged in? •Check if the power cord is correctly plugged into the power outlet.
Is the No Signal message being displayed? •This is displayed when the signal cable between the PC and the monitor is missing or disconnected. Check the cable and reconnect it.
Is the Out of Range message being displayed? •This occurs when signals transferred from the PC (graphics card) are out of the horizontal or vertical frequency range of the monitor. Please see the Product
Specification section of this manual to set the appropriate frequency.
Screen display is unstable and shaky. / Images displayed on the monitor leave shadow trails.
Did you select the appropriate resolution? •If the selected resolution is HDMI 1080i 60/50 Hz (interlaced), the screen may be flickering. Change the resolution to 1080p or the recommended
resolution.
•Not setting the graphics card to the recommended (optimal) resolution may result in blurred text, a dimmed screen, a truncated display area or
misalignment of the display.
•The setting methods may be different depending on the computer or operating system, and some resolutions may not be available depending on the
performance of the graphics card. If this is the case, contact the manufacturer of the computer or graphics card for assistance.
Does image sticking occur even when the monitor is turned off? •Displaying a still image for a prolonged time may cause damage to the screen, resulting in the retention of the image.
•To extend the lifetime of the monitor, use a screensaver.
Are there spots on the screen? •When using the monitor, pixilated spots (red, green, blue, white, or black) may appear on the screen. This is normal for an LCD screen. It is not an error, nor
is it related to the monitor's performance.
Some features are disabled.
Are some functions not available when you press the Menu button? •The OSD is locked. Disable OSD Lock in General.

19
ENGLISH
Do you see an "Unrecognized monitor, Plug and Play (VESA DDC) monitor found" message?
Have you installed the display driver? •Be sure to install the display driver from our web site: http://www.lg.com.
•Make sure to check if the graphics card supports Plug and Play function.
No sound from the headphone port.
Are images displayed without sound? •Make sure that the headphone port connections are made properly.
•Try increasing the volume with the joystick.
•Set the audio output of the PC to the monitor you are using. (The settings may differ depending on the operating system (OS) you use.)

20
ENGLISH
PRODUCT SPECIFICATION
Color Depth 8-bit / 10-bit color is supported.
Resolution Max Resolution 1920 x 1080 @ 60 Hz (D-Sub)
1920 x 1080 @ 75 Hz (HDMI)
Recommended Resolution 1920 x 1080 @ 60 Hz
Power Sources
Power Rating 19 V 1.3 A
Power Consumption
On mode: 25 WTyp. (Outgoing condition)*
Sleep Mode ≤ 0.3 W ***
Off Mode ≤ 0.3 W
AC/DC adaptor
Type ADS-40SG-19-3 19025G, manufactured by SHENZHEN HONOR ELECTRONIC,
or type ADS-40FSG-19 19025GPG-1, manufactured by SHENZHEN HONOR ELECTRONIC,
or type ADS-40FSG-19 19025GPBR-1, manufactured by SHENZHEN HONOR ELECTRONIC,
or type ADS-40FSG-19 19025GPI-1, manufactured by SHENZHEN HONOR ELECTRONIC,
or type ADS-40FSG-19 19025GPCU-1, manufactured by SHENZHEN HONOR ELECTRONIC,
or type ADS-40FSG-19 19025GPB-2, manufactured by SHENZHEN HONOR ELECTRONIC,
or type ADS-25SFA-19-3 19025E, manufactured by SHENZHEN HONOR ELECTRONIC,
or type ADS-25FSF-19 19025EPCU-1, manufactured by SHENZHEN HONOR ELECTRONIC,
or type ADS-25FSF-19 19025EPBR-1, manufactured by SHENZHEN HONOR ELECTRONIC,
or type ADS-25FSF-19 19025EPI-1, manufactured by SHENZHEN HONOR ELECTRONIC,
or type ADS-25FSF-19 19025EPG-1, manufactured by SHENZHEN HONOR ELECTRONIC,
or type ADS-25FSF-19 19025EPB-1, manufactured by SHENZHEN HONOR ELECTRONIC,
or type LCAP21, manufactured by LIEN CHANG ELECTRONIC ENTERPRISE,
or type LCAP26-A, manufactured by LIEN CHANG ELECTRONIC ENTERPRISE,
or type LCAP26-E, manufactured by LIEN CHANG ELECTRONIC ENTERPRISE,
or type LCAP26-I, manufactured by LIEN CHANG ELECTRONIC ENTERPRISE,
or type LCAP26-B, manufactured by LIEN CHANG ELECTRONIC ENTERPRISE,
or type WA-24C19FS, manufactured by Asian Power Devices Inc.
or type WA-24C19FN, manufactured by Asian Power Devices Inc.
or type DA-24B19, manufactured by Asian Power Devices Inc.
Output: 19 V 1.3 A
