LG 55WS50BS-B User manual

47" class (46.9" measured diagonally)
42" class (42.0" measured diagonally)
47WS50BS-B

42WS50BS-B

IPS Edge LED
Full HD Capable Monitor
Specifications
Native Display Resolution 1,920 x 1,080 (FHD)
High Brightness 450 cd/m2
Contrast Ratio 1,300:1 (Typ.), 500,000:1 (DCR)
178°/178° Ultra Wide Viewing Angle viewing angle and life expectancy
enhanced in portrait and landscape mode
RJ-45 LAN Control
Display Port, HD I and DVI Connection
RS-232C Control
Convenient External Speaker-Out
Energy Star® 5.1 compliant
Split Zoom (Self Video Wall) Up to 15 x 15 matrix - Adjusts for bezel width
Bezel Width 11.5mm
USB Playback
USB Port
Temperature Sensor
PIP/PBP
3-Year Limited Warranty Parts/Labor/Backlight
Features
TCO Total Cost of Ownership
The WS50BS series are nergy Star® 5.1 compliant consuming
approximately 40% less energy than non-compliant models. In standby
mode, they use less than one watt of power and meet the environmental
regulations such as PA and rp, while excluding the use of harmful
materials (RoHS) and reducing CO2 emissions.
IPS In Plane Switching
IPS accurately display an image’s quality and color at an 178° ultra wide
viewing angle. There is no fall-off in color accuracy and no diversion in
contrast ratio at wide angles. From bright sunlight to the most challenging
lighting environments these displays are designed to maintain optimal color
temperature for lifelike images.
BEZEL WIDTH
The WS50BS series with ultra slim bezel widths of 11.5mm equal on all
sides will draw attention to screen images and not the display for impactful
messaging. With the ability for a 15x15 matrix the image will almost
seamlessly broadcast larger than life images.
LGsolutions.com
55" class (54.6" measured diagonally)
55WS50BS-B


24/7 Operation
The high durability of LG's PD Module allows operation 24 hours a day.
It is highly effective and provides continuous performance.
Reduce energy consumption by approximately 30%
Smart Energy Saving
Slot type Media Player
MP500
CPU Upgrade
(Intel CPU
P4500 or i5)
The MP500, external Media Player, has a slim profile and will help your signage
look professional while providing easy accessibility for maintenance.
Easy Installation & aintenance High Picture Quality &
Brightness
Clear and vivid picture quality with the deepest
black. Consumes approximately 40% less energy
the LCD (CCFL) models.
NARROW BEZEL
11.5mm (42", 47")
11.2mm (55")
SA E BEZEL SIZE ALL
AROUND TILE ODE
The slim bezel creates a powerful and impactful video wall that can easily
be installed, maintained and managed.
Narrow & Equal Bezel On All Sides
USB multi-media playback
Easy & Fast Delivery of Content
Advantage
NO BLACKENING DEFECT
Display has a built-in temperature control
that adjusts to light and heat eliminating
dark or blackened areas.
IPS Competition
If the outdoor temperature is 86°F
the surface temperature of display is 185°F
TRUE WIDE VIEWING
Color shifts and distortion are eliminated from
any viewing angle.
PANEL STABILITY
Minimized image distortion and shows no tailing
when external pressure is applied.
I PS Competition
Color change average @ 60°
Gamma change average @ 60°
IPS Competition

LIF ’S GOOD...
when it’s green.
LG is committed to improving product
development, manufac turing and usage
to meet the demand
for products with
environmentally friendlier features.
Our televisions have technologies to
reduce power consumption and in
return increase cost savings per room.
EcoSmart
• Intelligent Sensor - Continually monitors room light conditions to automatically optimize
the picture quality for a more enjoyable viewing experience, which can help save energy.
• Dynamic Power Savings - Using built-in algorithms, TV will automatically reduce the
power consumption based on incoming video, while maximizing picture performance.
• Static Power Savings - Picture brightness level can be set at the preferred power
consumption level to reduce power and increase energy savings.
• CEC Compliant - Meets the Appliance fficiency Regulations of the California nergy
Commission.
• RoHS Compliant - Meets directive on restriction of hazardous substances.
• Energy Star 5.1 Qualified - Meets current reduction requirements of energy
consumption.
47WS50BS-B
42WS50BS-B
Rear Jack Panel
55WS50BS-B

47" class (46.9" measured diagonally)
42" class (42.0" measured diagonally)
47WS50BS-B

42WS50BS-B

55" class (54.6" measured diagonally)
55WS50BS-B

PANEL odel 55WS50BS-B 47WS50BS-B 42WS50BS-B
Panel Size (measured
diagonally) 55" class (54.6" ) 47" class (46.9") 42" class (42.0")
Panel Technology IPS (LED BLU)
Aspect Ratio 16 : 9
Native Resolution 1,920 x 1,080 (FHD)
Brightness 450 cd/m2
Contrast Ratio (Typ.) 1,300:1
Dynamic CR (DCR) 500,000 : 1
Viewing Angle 178°/178°
Response Time 10ms (G to G) 12ms (G to G)
Life time 60,000 Hrs
Orientation Portrait and Landscape
INPUT (Rear)
Digital HDMI(1), DVI-D(1), Display Port(1) with HDCP for all input
Analog Component(1), Composite(1), RGB(1) (Shared with D-Sub)
Audio RGB/DVI-D/AV/Component(3.5Φ1)
External Control RS232C(1), R 45(1), IR(1)
HDTV Formats Component: 720p, 1080i , 1080p
HDMI: 720p, 1080i, 1080p
USB USB(1)
OUTPUT
(Rear)
Digital DVI-D(1)
Analog Component(1), Composite(1), RGB(1) (Shared with D-Sub)
Audio External speaker
External Control RS232C (1), IR (1)
AUDIO
Balance Yes
Audio Power 20W (10W x 2)
Speaker on/off Yes
Clear Voice II Yes
Sound Mode Standard, Music, Cinema, Sports, Game
CABINET
Bezel Width 11.2mm 11.5mm
Monitor Dimensions
(Head only) 48.9” x 28.1” x 1.3” 42.2” x 24.3” x 1.2” 37.9” x 21.8” x 1.3”
Monitor Weight 51.8 Ibs. 34.6 Ibs. 30.2 Ibs.
Monitor with
Optional Stand
Dimensions
48.9” x 31.1” x 11.7” 42.2” x 27.2” x 11.7” 37.9” x 24.8” x 11.7”
Weight (Head+Stand) 54.9 Ibs. 37.5Ibs. 33.1 Ibs.
Monitor with
Optional Stand &
Speaker Dimensions
48.9” x 31.1” x 11.7” 42.2” x 27.2” x 11.7” 37.9” x 24.8” x 11.7”
Weight
(Head+Stand+Speaker) 56.7 Ibs. 39.5 Ibs. 35.1 Ibs.
Carton Dimensions 52.1” x 33.8” x 6.3” 47.1” x 30.3” x 5.5” 42.7” x 29.1” x 4.9”
Packed Weight 62.8 Ibs. 42.8 Ibs. 37.9 Ibs.
VESA
TM
Standard
Mount Interface 400mm x 400mm
LG lectronics U.S.A., Inc.
H B2B Division
2000 Millbrook Drive
Lincolnshire, IL 60069
Customer Service: 888.865.3026
www.LGsolutions.com/support
Contact your LG Regional Sales Representative:
Channel: 800.897.8871
Hospitality: 800.228.1236
-mail: [email protected]
SP C_42_47_55WS50BS_B_071329_PR
All screen images are simulated. Dimensions and weights are approximate. Design, specifications,
and features subject to change without notice.
© Copyright 2013 LG lectronics USA, Inc. All Rights Reserved. “LG Life’s Good” is a registered
trademark of LG Corp.
N RGY STAR is a registered trademark of the U.S. nvironmental Protection Agency. In Plane
Switching is a trademark of LG Philips LCD Ltd. V SA is a trademark of Video lectronics
Standards Association. HDMI, the HDMI logo and High-Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing LLC.
All other product and brand names are trademarks or registered trademarks of their respective
companies.
Printed in the USA. August 2013
LGsolutions.com
IPS Edge LED
Full HD Capable Monitor
SPECIAL
FEATURES
odel 55WS50BS-B 47WS50BS-B 42WS50BS-B
Temperature Sensor
Tile mode (Up to 15x15)
Source Selection: AV, Component, RGB, Display Port, DVI-D, HDMI, SuperSign (Option)
Brightness/Contrast/Backlight
Position/Size
Auto Config/Phase
Input Label (PC/DTV)
Time: Clock, On/Off Time, Sleep Timer, Power on Delay, Auto Off, Automatic Standby
Auto Power/Source Memory
Key Lock
DPM Select
Smart Energy Saving (Minimum, Medium, Maxium)
File Play with USB
ISM Method
PIP/PBP
Key Lock
ENVIRON ENT
CONDITIONS
Operation Temp. 0°C ~40°C
Operation Humidity 10% ~80%
POWER
Power Supply 100 -240V~, 50/60Hz
Power C onsumption Normal (Typical) 130W Normal (Typical) 120W Normal (Typical) 115W
Smart Energy Saving
on 90W
Smart Energy Saving
on 85W
Smart Energy Saving
on 75W
DPM 0.7W (set only) DPM 1W (set only) DPMS Off 2W (with
external device)
Power Off 0.5W
STANDARD
CERTIFICATION
Safety UL / cUL / CB scheme / TUV
EMC FCC Class "A" / VCCI / C-tick / CE / KCC
Erp/Energy Star Yes / Yes (EPA 5.1)
EDIA PLAYER
Slot PC compatible (optional MP500)
SOFTWARE
SuperSign Elite-W / Elite-W lite/Editing, Scheduling, Distribution & Play, Control
WARRANTY
3-Year Limited Warranty (Parts/Labor/Backlight)
UPC
7 19192 19229 4 7 19192 19193 8 7 19192 19186 0
ACCESSORIES
Remote Controller, Power Cable, RGB Cable, Manual, ESG, IR Receiver
OPTIONAL
ACCESSORIES
SP-2000 (Speaker)
ST-200T (Stand)
MP500 (Media Player)
