LG 99T User manual

Colour Monitor
USER GUIDE
MANUEL D'UTILISATION
MODEL : 99T

1
Introduction
Thank you for purchasing an LG high resolution monitor. It will give
you high resolution performance and convenient reliable operation in a
variety of video operating modes.
Features
The 99T is a 19-inch (18.0 inches viewable ) intelligent, microproces-
sor based monitor compatible with most analog RGB (Red, Green,
Blue) display standards, including IBM PC®, PS/2®, Apple®,
Macintosh®, Centris®, Quadra®, and Macintosh II family. It can also be
used with a Sun SPARC workstation as well as other sources using
the 5 BNC connectors. The monitor provides crisp text and vivid color
graphics with VGA, SVGA, XGA, and VESA Ergo modes (non-
interlaced), and most Macintosh compatible color video cards when
used with the appropriate adapter.
The monitor's wide compatibility makes it possible to upgrade video
cards or software without purchasing a new monitor.
Digitally controlled auto-scanning is done with the microprocessor for
horizontal scan frequencies between 30 and 96kHz, and vertical scan
frequencies between 50 and 160Hz. The microprocessor-based
intelligence allows the monitor to operate in each frequency mode with
the precision of a fixed frequency monitor.
The microprocessor based digital controls allow you to conveniently
adjust a variety of image controls by using the OSD (On Screen
Display).
The monitor is shipped with 12 factory pre-programmed video modes
that are permanently resident, and another 12 are set at the factory,
but may be overwritten to make more room. In addition, there are 16
user storable modes, for a total of 40 memory modes.
This monitor is capable of producing a maximum horizontal resolution
of 1600 dots and a maximum vertical resolution of 1200 lines. It is well
suited for CAD work and sophisticated windowing environments.
For greater user health and safety, this monitor complies with the
stringent Swedish TCO’95 requirements for low radiation emissions.
For low cost of monitor operation, this monitor is certified as meeting
the EPA Energy Star requirements, and utilizes the VESA Display
Power Management Signalling (DPMS) protocol for power saving
during non-use periods.
English
012W/En

Monitor Registration
The model and serial numbers are found on the rear of this unit.
These numbers are unique to this unit and not available to others.
You should record requested information here and retain this guide
as a permanent record of your purchase. Staple your receipt to this
page.
Date of Purchase :
Dealer Purchased From :
Dealer Address :
Dealer Phone No. :
Model No. :
Serial No. :
Notice
All rights reserved. Reproduction in any manner, in whole or in part, is
strictly prohibited without the written permission of LG Electronics Inc.
Trademark Acknowledgments
LG is a trademark of LG Electronics Inc.
IBM is a registered trademark and VGA is a trademark of
International Business Machines Corporation.
WARNING : To reduce the risk of fire or electric shock, do not
expose this appliance to rain or moisture.
AVERTISSEMENT : Ne pas placer cet appareil dans un endroit humide.
Cela peut entraîner un incendie ou une décharge électrique.
2

Important Precautions
This unit has been engineered and manufactured to assure your
personal safety, but improper use can result in potential electrical
shock or fire hazard. In order not to defeat the safeguards
incorporated in this monitor, observe the following basic rules for its
installation, use, and servicing. Also follow all warnings and
instructions marked directly on your monitor.
On safety
1. Use only the power cord supplied with the unit. In case you use
another power cord, make sure that it is certified by the applicable
standards (UL/CSA or VDE) if not being provided by the supplier.
2. Operate the monitor only from a power source indicated in the
specifications of this manual or listed on the monitor. If you are not
sure what type of power supply you have in your home, consult
your dealer.
3. Overloaded AC outlets and extension cords are dangerous. So are
frayed power cords and broken plugs. They may result in a shock
or fire hazard. Call your service technician for replacement.
4. DO NOT OPEN THE MONITOR. There are no user serviceable
components inside. There are Dangerous High Voltages inside,
even when the power is OFF. Contact your dealer if the monitor is
not operating properly.
5. To avoid personal injury :
Do not place the monitor on a sloping shelf unless properly secured.
Use only a stand recommended by the manufacturer.
Do not try to roll a stand with small casters across thresholds or
deep pile carpets.
6. To prevent Fire or Hazards:
Always turn the monitor OFF if you leave the room for more than
a short period of time. Never leave the monitor ON when leaving
the house.
3

Keep children from dropping or pushing objects into the
monitor's cabinet openings. Some internal parts carry hazardous
voltages.
Do not add accessories that have not been designed for this
monitor.
During a lightning storm or when the monitor is to be left
unattended for an extended period of time, unplug it from the
wall outlet.
Do not bring magnetic devices such as magnets or motors near
the picture tube.
On installation
1. Do not allow anything to rest upon or roll over the power cord, and
do not place the monitor where the power cord is subject to damage.
2. Do not use this monitor near water such as near a bathtub,
washbowl, kitchen sink, laundry tub, in a wet basement, or near a
swimming pool.
3. Monitors are provided with ventilation openings in the cabinet to
allow the release of heat generated during operation. If these
openings are blocked, built-up heat can cause failures which may
result in a fire hazard. Therefore, NEVER:
Block the bottom ventilation slots by placing the monitor on a
bed, sofa, rug, etc.
Place the monitor in a built-in enclosure unless proper ventilation
is provided.
Cover the openings with cloth or other material.
Place the monitor near or over a radiator or heat source.
On cleaning
Unplug the monitor before cleaning the face of the picture tube.
Use a slightly damp (not wet) cloth. Do not use an aerosol directly
on the picture tube because overspray may cause electrical shock.
On repacking.
Do not throw away the carton and packing materials. They make
an ideal container in which to transport the unit. When shipping
the unit to another location, repack it in its original material.
4

Connecting the Monitor
On the back of the monitor are three plug-in connections; one for the
AC power cord, and the others for the signal cable from the video card.
1. AC Power Connection
One end of the AC power cord is connected into the AC power connector
on the back of the monitor. The other end is plugged into a properly
grounded three-prong AC outlet. The monitor's auto-sensing power supply
can automatically detect 100-120V AC or 200-240V AC, 50 or 60Hz.
2. Signal Cable Connection
The connectors for the signal cable are located on the back of the
monitor. The BNC and 15 pin VGA connectors on the back of the
monitor allow for a wide variety of video controllers to be connected to
the monitor. Examples of signals that might be sent to the monitor
include signals from IBM PC and compatibles, Apple Macintosh,
Centris, Quadra, and SPARC workstations.
The supplied signal cable consists of 15 pin VGA connectors at both
ends, suitable for connections to an IBM PC or compatible.
Other generic cables or adapters may be used for connections to your
equipment, as long as they meet the compatible signal requirements
to activate this monitor (see page 24 for input specifications). For
Apple Macintosh use, a separate plug adapter is needed to change
the 15 pin high density (3 row) D-sub VGA connector on the supplied
cable to a 15 pin 2 row connector. Examples of typical connections
are shown below. Select the connection example that fits your needs.
5

A) Connection to any IBM VGA PC compatible system
Figure 3 shows the signal cable connections from the monitor to the
Video Graphics Array (VGA) port typical in an IBM PC or PC
compatible. This also applies to any graphics video card for PC-CAD
or workstation that has a 15 pin high density (3 row) D-Sub connector.
1.Power off both the monitor and PC.
2.Connect the 15 pin VGA connector of the supplied signal cable to
the output VGA video connector on the PC and the matching input
connector on the rear of the monitor. The connectors will mate
only one way. If you cannot attach the cable easily, turn the
connector upside down and try again. When mated, tighten the
thumbscrews to secure the connection.
3.Power ON the PC, then the monitor.
4.If you see the SELF DIAGNOSTICS message, check the signal
cable and connectors.
5.After using the system, power OFF the monitor, then the PC.
Figure 3.
6
Power Cord Signal Cable
D-15P D-15P

B) Connecting to an Apple Macintosh II, Centris, and Quadra
Figure 4 shows the connection to an Apple Macintosh, using a
separately purchased adapter.
1.Power OFF both the monitor and the PC.
2.Connect the 15 pin VGA connector of the supplied signal cable to
the matching input on the back of the monitor. Tighten the
thumbscrews to secure the connection.
3.Locate the appropriate MAC to VGA adapter block at your local
computer store. This adapter changes the high density 3 row 15
pin VGA connector to the correct 15 pin 2 row connection to mate
with your MAC. Attach the other end of the signal cable to the
side of the adapter block with 3 rows.
4.Connect the attached adapter block/signal cable to the video
output on your MAC.
5.Power ON the PC, then the monitor.
6.If you see the SELF DIAGNOSTICS message, check the signal
cable and connectors.
7.After using the system, power OFF the monitor, then the PC.
Figure 4.
7
Power Cord Signal Cable
D-15P
ADAPTER 15P
D-15P

Notes on using the BNC connectors with other types of video cards. Follow
the example that fits your needs. (BNC cables not included with Monitor.)
IN CASE OF COMPOSITE SYNC ON GREEN VIDEO SIGNAL
(SYNC ON GREEN):
Connect R,G and B video signals to BNC receptacles on the back
of the monitor, respectively.
IN CASE OF EXTERNAL COMPOSITE SYNC SIGNAL:
Connect R, G and B video signals and Composite sync signal to
BNC receptacles on rear panel, respectively.
IN CASE OF SEPARATE HORIZONTAL AND VERTICAL SYNC
SIGNALS:
Connect R, G and B video signals and horizontal and vertical
sync signals to BNC receptacles on rear panel respectively.
8
R G B H+V V
Red Green Blue
R G B H+V V
Red Green Blue Gray
R G B H+V V
Red Green Blue Gray Black

Location and Function of Controls
9
Front View
BNC Signal Connectors
AC Power Socket
D-Sub Signal Connector
ID Label
Power (DPMS)
Indicator
Rear View
Power ON/OFF button
Digital Control Panel
Brightness Adjustment Control
Contrast Adjustment Control

Control Panel Function
All functions are adjusted from the microprocessor-based digital controls.
Buttons on the front of the monitor allow you to adjust the image
easily through an OSD menu. As you choose controls, the selected
icon shows you what the chosen control will do. These pictures give
you immediate understanding of the controls. The following is a
description of use for each button.
OSD Enter Button
Use this button to start/enter and exit from the On Screen
Display (OSD). If there is no OSD on the screen, One click
(press) of this button will show the Main Menu.
OSD Exit Button
To disappear of the OSD on the screen.
OSD Select/Adjustment Button
Use this knob for selecting (highlighting) an OSD icon to be
adjusted. It is also used for selecting the level of the selected
item to be adjusted.
Brightness Control
Used to adjust the brightness of the screen. Move the
thumbwheel located beneath this indicator to increase or
decrease the display brightness.
10
OSD Exit Button OSD Enter Button
OSD Select /Adjustment Button Brightness Contrast
Power Indicator
Power On/Off Button
BRIGHTNESS
91.1kHz / 85Hz
100%

Contrast Control
Adjust the display to the contrast desired. Move the thumbwheel
located beneath this indicator to increase or decrease the display
contrast.
Power(DPMS) Indicator
This Indicator lights up green when the monitor operates normally.
If the monitor is in DPM (Energy Saving) mode (stand-by/suspend/
power off), this indicator color changes to amber.
Power ON/OFF Button
This button is used to turn the monitor on and off.
On Screen Display (OSD) Control Adjustment
Making adjustments to the image size, position and operating
parameters of the monitor are quick and easy with the On Screen
Display Control system, using only the Enter button and Adjustment
Control knob. A quick example is given below to familiarize you with
the use of the controls. Following this section is an outline of the
available adjustments and selections you can make using the OSD.
Note : (Monitor and PC should be ON, with an image or prompt on
the screen). A single press of the ENTER button will present you with
the Main Menu of the on screen display system with the first ( )
highlighted.
1. The OSD system should look like:
2. To adjust H Size ( ), Press the enter button ( ) once.
The display will look like:
When you are done, Press the EXIT button ( )once to return to
main menu to make another selection.
11
CONTRAST
91.1kHz / 85Hz
100%
SEL:
:ENT
H SIZE
OSD
ADJ:
:
H SIZE 120
91.1kHz / 85Hz
OSD

OSD Adjustment and Selection Items
You were introduced to the procedure of selection and adjusting an
item using the OSD system.
Listed below are the icons, icon names, and icon descriptions of the
items that are shown on the Menu.
12
OSD Adjust Description
Horizontal Size
Horizontal Position To move picture image left and right.
Moves the screen image left.
Moves the screen image right.
To adjust image width.
Decreases the size of the screen image.
Increases the size of the screen image.
ADJ:
:
H SIZE 120
91.1kHz / 85Hz
OSD
ADJ:
:
H POSITION 120
91.1kHz / 85Hz
OSD
Vertical Size
Vertical Position To move image up and down.
Moves the screen image down.
Moves the screen image up.
To adjust image height.
Decreases the size of the screen image.
Increases the size of the screen image.
V SIZE 120
ADJ:
:
91.1kHz / 85Hz
OSD
V POSITION 120
ADJ:
:
91.1kHz / 85Hz
OSD

13
OSD Adjust Description
Side Pincushion
Trapezoid
Tilt
Parallelogram
To correct the bowing in and out of the image.
Curves the image's edges inwards.
Curves the image's edges outwards.
To correct geometric distortion.
Makes the screen image narrower at
the top.
Moves the screen image wider at the top.
To correct image rotation.
Tilts the screen image left.
Tilts the screen image right.
This control adjusts for a skewing of the
screen image.
Tilts the screen image rightward.
Tilts the screen image leftward.
SIDE PIN. 120
ADJ:
:
91.1kHz / 85Hz
OSD
TRAPEZOID 120
ADJ:
:
91.1kHz / 85Hz
OSD
TILT 120
ADJ:
:
91.1kHz / 85Hz
OSD
PARALLELOGRAM
120
ADJ:
:
91.1kHz / 85Hz
OSD
Zoom Adjust To adjust Horizontal and Vertical image
size simultaneously.
Smaller the image size.
Bigger the image size.
ZOOM ADJUST
OUT / IN
ADJ:
:
OSD

14
OSD Adjust Description
Moire Reduction This item allows you to reduce the moire
(Moire is caused by interference
Horizontal Scan Line with the periodical
dot screen). It is normally OFF. If you want
to adjust it, select ON using the
adjustment control and push the Enter
Button.
NOTE:The screen image may shake slightly while the
moire reduction function is ON. Switching theOFF will
improve image stability and clarity at the expense of
slightly greater moire.
MOIRE REDUCTION
MOIRE REDUCTION
50%
SEL:
:
OSD
ADJ:
:
OSD
OFF / ON
OFF / ON
MOIRE REDUCTION
SEL:
:ENT
OSD
Color Select To select color temperature, 9300K/
6550K/ user.
Decreases the amount of color in the
image.
Increases the amount of color in the
image.
SEL:ENT
:
COLOR SELECT
9300K 6550K
ADJ:SEL
:
COLOR SELECT
120
150 R
B
COLOR RECALL :
OSD
OSD
SEL:ENT
:
COLOR SELECT
OSD

15
OSD Adjust Description
Mode Recall If the monitor is operating in a factory
preset mode, this control will reset the
image to the factory preset mode.
If the monitor is operating in a user mode,
this control has no effect.
SEL:ENT
:
OSD
MODE RECALL
OSD Adjust
OSD
This item lets you adjust the OSD position.
When you have finished, use the exit ( )
icon to retun to main menu to take another
selection.
SEL:ENT
:
OSD ADJUST
ADJ:SEL
:
OSD ADJUST
OSD
OSD
Option Select
This item gives access 3 elements; manual
degaussing, signal input selection and Video
level (0.7V or 1.0V) . Press the Enter button to
select the desired item to change.
When you
have finished, use the exit ( ) icon to
retun to main menu to take another
selection.
SEL:ENT
:
OPTION SELECT
ADJ:SEL
:
OPTION SELECT
[DEGAUSSING]
OSD
OSD

16
OSD Adjust Description
Language Select To choose the language in which the
control names are displayed.
LANGUAGE SELECT
(ENGLISH)
EN DE FR ES IT
SEL:
:
OSD
LANGUAGE SELECT
SEL:
:ENT
OSD
Mode Information To inform users of preset and user mode
data.
This item provides information about the
stored video modes. After highlighting (red
color) the mode information icon, press
Enter. Rotate the Adjustment Control to
see the desired video mode information.
The mode information screens give you
some information regarding industry
resolution terminology, resolution, and
memory mode number.
PRESET MODE
:
1 31.4kHz / 60Hz
2 43.2kHz / 85Hz
3 31.4kHz / 70Hz
4 37.8kHz / 60Hz
5 53.6kHz / 85Hz
6 48.3kHZ / 60Hz
:
USER MODE
:
1 35.5kHz / 70Hz
2 74.5kHz / 73Hz
-THE END-
:
SEL:ENT
:
MODE INFORMATION
MODE INFO.
STANDARD
91.1kHz / 85Hz
PRESET MODE : 12
USER MODE : 2
MODE DATA :
:
OSD

Self Diagnostics
The Studioworks 99T has a SELF DIAGNOSTICS OSD feature that
pops up when there may be possible causes of non-operation. The
OSD would highlight a possible reason the display is not showing an
image. An example of this may be when you turn on the monitor with
no signal cable attached. The monitor will display the SELF
DIAGNOSTICS OSD with the CHECK INPUT SIGNAL. This would be
a clue for you to check the signal connections.
DDC (Display Data Channel)
DDC is a communication channel over which the monitor
automatically informs the host system (PC) about its capabilities. This
monitor has three DDC function; DDC1, DDC2B.
DDC1 and DDC2B carry out uni-directional communication between
the PC and the monitor. Under these situations, the PC sends display
data to the monitor but not commands to control the monitor settings.
NOTE : PC must support DDC functions to do this.
If you using the 5 BNC connector with other types of video
cards, this monitor has not support DDC function.
Low Radiation Compliance (MPR II)
This monitor meets one of the strictest guidelines available today for
low radiation emissions, offering the user extra shielding and an
antistatic screen coating. These guidelines, set forth by a government
agency in Sweden, limit the amount of emission allowed in the
Extremely Low Frequency (ELF) and Very Low Frequency (VLF)
electromagnetic range.
17
SELF DIAGNOSTICS
CHECK : INPUT SIGNAL
NO SIGNAL DETECTED

Video Memory Modes
This multi-synchronous auto-scanning monitor can automatically
detect and display several video modes falling within the monitor's
scanning range of 30-96kHz Horizontal and 50-160Hz Vertical. In the
PC area, this relates to a maximum flicker-free usable resolution of
1600x1200 at a non-interlaced refresh rate of 75Hz Vertical.
For convenience, the monitor has a 40 mode memory, of which 12
modes come from the factory preset to popular video modes as
described below.
Modes 25-40 are empty and can accept new video data.
If the monitor detects one of the signals above from your computer's
video card, it will recall that mode and any stored image adjustments
you may have made before. If the monitor detects a new video mode
that had not been present before or not one of the above listed factory
presets, it will store a new mode automatically in one of the blank
(empty) memory modes (in this example, mode 25). When you now
adjust the digital controls to your preference, these image settings will
also be stored in mode 25. Whenever your video card or PC switches
to the mode that the monitor recognizes as mode 25, your personal
image settings will also be recalled.
18
Display Mode
640 x 480
640 x 480
720 x 400
800 x 600
800 x 600
1024 x 768
1024 x 768
1024 x 768
1280 x 1024
1280 x 1024
1600 x 1200
1600 x 1200
Horizontal
Frequency
31.469 kHz
43.269 kHz
31.470 kHz
37.880 kHz
53.674 kHz
48.360 kHz
60.020 kHz
68.677 kHz
63.981 kHz
91.150 kHz
81.250 kHz
93.750 kHz
Vertical
Frequency
59.940 Hz
85.008 Hz
70.080 Hz
60.320 Hz
85.061 Hz
60.000 Hz
75.030 Hz
84.997 Hz
60.020 Hz
85.020 Hz
65.000 Hz
75.000 Hz
Horiz sync
-
-
-
+
+
-
+
+
+
+
+
+
Verti sync
-
-
+
+
+
-
+
+
+
+
+
+
Mode
1
2
3
4
5
6
7
8
9
10
11
12
Comments
Factory fixed, but
may be updated
by user's setting.
Polarity

A note about the video memory modes:
There is a total of 40 video memory modes, generally more modes than
you will use at any one time. Of these 40 modes, 12 are permanent,
factory fixed modes that cannot be changed, and another 12 are set at
the factory, but may be overwritten to make more room. The remaining
16 modes are left blank (empty). If you use up the 16 blank modes and
still have more new video modes, the monitor will store information in the
other 12 soft preset modes for the new mode storage. If additional new
modes are encountered, the monitor will delete the lowest memory mode
and add the new mode.
If you use a video card that has a number of resolutions and frequencies
that do not correspond to any of the monitor video modes set at the
factory, here's what will happen:
1) As the monitor encounters new video data, if you adjust the image
control icons, the monitor will save the new information in the next
available empty mode (mode 25 if this is the first new data
encountered).
2) If you have used up modes 25-40 with 16 new video modes, and the
monitor encounters another mode (41th mode), it will store the new
data in mode 25 and the old data of mode 25 is deleted.
In addition, If the monitor encounters 42th new video data, the old
data of mode 26 is deleted and 42th data will replace the mode 26,
with above method, when this monitor encounters new mode, it can
update from mode 25 to mode 40 sequentially and continuously.
Because the monitor is designed this way, you will always have the
most recent 28 video modes generated by your graphics card
available with your own image settings recalled automatically.
19
m1 m2 m3 m4 m5 m6 m7 m8 m9 m10 m11 m12 m13 m14 m15 m16 m17 m18 m19 m20 m21 m22 m23 m24 m25 m26 m27 m28
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28
Example:All 40 modes are filled with following data
Factory fixed
mode
data
When new data is encountered
"m25"old mode 25 deleted
38 39 40
Factory fixed
m38 m39 m40
Soft presets
m1 m2 m3 m4 m5 m6 m7 m8 m9 m10 m11 m12 m13 m14 m15 m16 m17 m18 m19 m20 m21 m22 m23 m24 m25 m26 m27 m28
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 38 39 40
m38 m39 m40
