LG Flatron L1510B User manual

MENU
AUTO/SELECT
COLOR MONITOR
SERVICE MANUAL
Website:http://biz.LGservice.com
E-mail:http://www.LGEservice.com/techsup.html
CAUTION
BEFORE SERVICING THE UNIT,
READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
CHASSIS NO. : CL-32
FACTORY MODEL: LB504J
MODEL: L1510B (LB504J-GL)
L1510B (LB504J-GU)
*( ) ID LABEL MODEL No.

CONTENTS
SPECIFICATIONS
- 2 -
1. LCD CHARACTERISTICS
Type : TFT XGA LCD Module
Size : 352.0(H) x 263.5(V) x 14.0(T)
Pixel Pitch : 0.297mm x 0.297mm
Color Depth : 8Bits/ 16,194,277 colors
Active Video Area : 15.0inch
(304.128 x 228.096)
Surface Treatment : Anti-Glare, Hard Coating (3H)
Backlight Unit : Top/Bottom edge side 2CCFL
Electrical Interface : LVDS
(LPL Module) /TTL (AU Module)
2. OPTICAL CHARACTERISTICS
2-1. Viewing Angle by Contrast Ratio
≥ 10
Left : 60° min.
Right : 60° min.
Top : 45° min.
Bottom : 45° min.
2-2. Luminance : 150(min.), 180(typ.) at Center point
2-3. Contrast Ratio : 200(min.), 300(typ.) -LPL Module
250(min.), 350(typ.) -AU Module
3. SIGNAL (Refer to the Timing Chart)
3-1. Sync Signal
1) Type : Separate Sync. (Horizontal & Vertical)
2) Input Voltage Level: Low=0~0.8V, High=2.1~5.5V
3) Sync Polarity : Positive or Negative
3-2. Video Input Signal
1) Type : R, G, B Analog
2) Voltage Level : 0~0.714 V
a) Color 0, 0 : 0 Vp-p
b) Color 7, 0 : 0.467 Vp-p
c) Color 15, 0 : 0.714 Vp-p
3) Input Impedance : 75 Ω
3-3. Operating Frequency
Horizontal : 31 ~ 61kHz
Vertical : 56 ~ 75Hz
4. POWER SUPPLY
4-1. Power
100~240V, 50/60Hz 0.6A
4-2. Power Consumption
5. ENVIRONMENT
5-1. Operating Temperature: 10°C~35°C (50°F~95°F)
(Ambient)
5-2. Relative Humidity : 10%~80%
(Non-condensing)
5-3. MTBF : 50,000 Hours (Min.)
Lamp Life : 30,000 Hours (min.)
6. DIMENSIONS (with TILT/SWIVEL)
Width : 356mm (14.01'')
Depth : 229mm (9.01'')
Height : 380mm (14.96'')
Width : 356mm (14.01'')
Depth : 291.4mm (11.47'')
Height : 103.3mm (4.06'')
7. WEIGHT (with TILT/SWIVEL)
Net. Weight : 5.1kg (11.24 lbs)
Gross Weight : 6.6kg (14.55 lbs)
SPECIFICATIONS ................................................... 2
PRECAUTIONS ....................................................... 3
TIMING CHART ....................................................... 4
OPERATING INSTRUCTIONS ................................ 5
WIRING DIAGRAM ................................................. 7
BLOCK DIAGRAM ................................................... 9
DESCRIPTION OF BLOCK DIAGRAM...................10
ADJUSTMENT ...................................................... 13
TROUBLESHOOTING GUIDE .............................. 14
PRINTED CIRCUIT BOARD................................... 18
EXPLODED VIEW...................................................21
REPLACEMENT PARTS LIST ...............................23
PIN CONFIGURATION............................................27
SCHEMATIC DIAGRAM......................................... 28
MODE
POWER ON (MAX)
POWER ON (NORMAL)
STAND-BY
SUSPEND
POWER OFF
H/V SYNC
ON/ON
ON/ON
OFF/ON
ON/OFF
-
POWER CONSUMPTION
less than 30 W
less than 28 W
less than 3 W
less than 3 W
less than 3 W
LED COLOR
GREEN
GREEN
AMBER
AMBER
OFF
VIDEO
ACTIVE
ACTIVE
OFF
OFF
-

- 3 -
WARNING FOR THE SAFETY-RELATED COMPONENT.
• There are some special components used in LCD
monitor that are important for safety. These parts are
marked on the schematic diagram and the
replacement parts list. It is essential that these critical
parts should be replaced with the manufacturer’s
specified parts to prevent electric shock, fire or other
hazard.
• Do not modify original design without obtaining written
permission from manufacturer or you will void the
original parts and labor guarantee.
TAKE CARE DURING HANDLING THE LCD MODULE
WITH BACKLIGHT UNIT.
• Must mount the module using mounting holes arranged
in four corners.
• Do not press on the panel, edge of the frame strongly
or electric shock as this will result in damage to the
screen.
• Do not scratch or press on the panel with any sharp
objects, such as pencil or pen as this may result in
damage to the panel.
• Protect the module from the ESD as it may damage the
electronic circuit (C-MOS).
• Make certain that treatment person’s body are
grounded through wrist band.
• Do not leave the module in high temperature and in
areas of high humidity for a long time.
• The module not be exposed to the direct sunlight.
• Avoid contact with water as it may a short circuit within
the module.
• If the surface of panel become dirty, please wipe it off
with a softmaterial. (Cleaning with a dirty or rough cloth
may damage the panel.)
WARNING
BE CAREFUL ELECTRIC SHOCK !
• If you want to replace with the new backlight (CCFL) or
inverter circuit, must disconnect the AC adapter
because high voltage appears at inverter circuit about
650Vrms.
• Handle with care wires or connectors of the inverter
circuit. If the wires are pressed cause short and may
burn or take fire.
PRECAUTION
CAUTION
Please use only a plastic screwdriver to protect yourself
from shock hazard during service operation.

TIMING CHART
- 4 -
VIDEO
SYNC
B
D
CFE
A
H / V
H (Pixels)
V (Lines)
H (Pixels)
V (Lines)
H (Pixels)
V (Lines)
H (Pixels)
V (Lines)
H (Pixels)
V (Lines)
H (Pixels)
V (Lines)
H (Pixels)
V (Lines)
H (Pixels)
V (Lines)
H (Pixels)
V (Lines)
H (Pixels)
V (Lines)
H (Pixels)
V (Lines)
H (Pixels)
V (Lines)
H (Pixels)
V (Lines)
H (Pixels)
V (Lines)
Sync
Polarity
+
–
–
+
–
–
–
–
–
–
–
–
+
+
+
+
+
+
+
+
–
–
–
–
–
–
+
+
Dot
Clock
25.175
28.322
25.175
30.24
31.5
31.5
36.0
40.0
50.0
49.5
57.2832
65
75
78.75
Frequency
31.468 KHz
70.0 Hz
31.468 KHz
70.0 Hz
31.469 KHz
60.0 Hz
35.0 KHz
66.67 Hz
37.861 KHz
72.8 Hz
37.50 KHz
75 Hz
35.156KHz
56.25 Hz
37.879 KHz
60.3 Hz
48.077 KHz
72.188 Hz
46.875 KHz
75.0 Hz
49.725 KHz
74.55 Hz
48.363 KHz
60.0 Hz
56.476 KHz
70.0 Hz
60.023 KHz
75.0 Hz
Resolution
640 x 350
720 x 400
640 x 480
640 x 480
640 x 480
640 x 480
800 x 600
800 x 600
800 x 600
800 x 600
832 x 624
1024 x 768
1024 x 768
1024 x 768
Total
Period
( E )
800
449
900
449
800
525
864
525
832
520
840
500
1024
625
1056
628
1040
666
1056
625
1152
667
1344
806
1328
806
1312
800
Video
Active
Time ( A )
640
350
720
400
640
480
640
480
640
480
640
480
800
600
800
600
800
600
800
600
832
624
1024
768
1024
768
1024
768
Blanking
Time
( B )
160
99
180
49
160
45
224
45
192
40
200
20
224
25
256
28
240
66
256
25
320
43
320
38
304
38
288
32
Sync
Duration
( D )
96
2
108
2
96
2
64
3
40
3
64
3
72
2
128
4
120
6
80
3
64
3
136
6
136
6
96
3
Back
Porch
( F )
48
60
55
34
48
33
96
39
128
28
120
16
128
22
88
23
64
23
160
21
224
39
160
29
144
29
176
28
Front
Porch
( C )
16
37
17
13
16
10
64
3
24
9
16
1
24
1
40
1
56
37
16
1
32
1
24
3
24
3
16
1
MODE
1
2
3
4
5
6
7
8
9
10
11
12
13
14
(MAC)
(TEXT)

OPERATING INSTRUCTIONS
- 5 -
FRONT VIEW REAR VIEW
Front Control Panel
1. Power Button
Use this button to turn the display on or off.
<Power (DPMS) Indicator>
This Indicator lights up green when the display
operates normally. If the display is in DPM (Energy
Saving) mode, this indicator color changes to
amber.
2. Menu Button
Use this button to enter or exit the On Screen
Display.
3. Button
Use these buttons to choose or adjust items in the
On Screen Display.
4.
AUTO/SELECT Button
Use this button to enter a selection in the On
Screen Display.
MENU
AUTO/SELECT
Power Connector
When adjusting your display settings, always
press the AUTO/SELECT button before entering
the On Screen Display(OSD). This will
automatically adjust your display image to the
ideal settings for the current screen resolution
size (display mode).
The best display mode is 1024x768.
See front control panel
D-Sub Signal Connector
Bring up Contrast and
Brightness adjustment.
100
100
PROCESSING
AUTO CONFIGURATION
1142 3

- 6 -
Making use of USB (Universal Serial Bus)*
USB (Universal Serial Bus) is an innovation in connecting your different desktop peripherals conveniently to your computer.
By using the USB, you will be able to connect your mouse, keyboard, and other to your monitor instead of having to
connect them to your computer. This will give you greater flexibility in setting up your system. USB allows you to connect
chain up to 120 devices on a single USB port, and you can “hot”plug (attach them while the computer is running) or unplug
them while maintaining Plug and Plug auto detection and configuration. This monitor has an integrated BUS-powered USB
hub, allowing up to 2 other USB devices to be attached it.
USB connection
1. Connect the upstream port of the Display to the downstream port of the USB compliant PC or another hub using the
USB cable. (Computer must have a USB port)
2. Connect the USB compliant peripherals to the downstream ports of the monitor.
NOTE
To activate the USB hub function, the monitor must be connected to a USB compliant PC(OS) or another hub with the USB
cable(enclosed).
When connecting the USB cable, check that the shape of the connector at the cable side matches the shape at the connecting
side.
Even if the monitor is in a power saving mode, USB compliant devices will function when they are connected the USB ports(both
the upstream and downstream) of the monitor.
USB downstream Port
connect the cables from USB
compliant peripherals-such as
keyboard, mouse, etc
This is a simplified representation
of rear view.
To USB downstream port
of the USB compliant PC or
another hub cable

- 7 -
WIRING DIAGRAM (LG Philips Module)
J702
J706
J707
J705
P902 J1
CN1
CN2
CN3
Connector Ass’y :
P/N: 6631T11012V
Connector Ass’y :
P/N: 6631T20008G
Connector Ass’y :
P/N: 6631T20015P
Connector Ass’y :
P/N: 6631T12002H
P902
CN1
CN3
J706
J707
705
N2
Connector the Control PCB Ass’y and Main PCB Ass’y.
Connector the Main PCB Ass’y and Inverter.

- 8 -
WIRING DIAGRAM (AUO Module)
J702
J706
J707
J705
P902 J1
CN1
CN2
CN3
Connector Ass’y :
P/N: 6631T11011H
Connector Ass’y :
P/N: 6631T20008G
Connector Ass’y :
P/N: 6631T20015P
Connector Ass’y :
P/N: 6631T12002H
P902
CN1
CN3
J702
J706
J707
05
2
Connector the Control PCB Ass’y and Main PCB Ass’y.
Connector the Main PCB Ass’y and Inverter.

- 9 -
BLOCK DIAGRAM(LG Philips Module)

DESCRIPTION OF BLOCK DIAGRAM(LG Philips Module)
- 10 -
1. Scaler One chip IC(GMZAN-2, U201)
GMZAN-2 (U201) is one chip IC which it supports four internal function blocks of Video Amp, PLL,
A/D converter and Video processor.
Video signal (0.7Vp.p) clamped through C207, 208, 209 with matching IC’s proper cut off voltage.
This signal is processed as a proper 8 bit digital signal by U201’s amplifying, phase locking, A/D converting,
and scaling operations.
Also, U201 generates Clock, Horizontal and Vertical sync, Data Enable signals as LVDS IC’s input signals.
2. System Controller (Microprocessor) Circuit
1) Microprocessor (U501) distinguishes polarity and frequency by calculating horizontal and vertical sync input
from signal source.
2) Microprocessor (U501) carries out power control by sending power-down trigger signal to each IC.
3) Microprocessor (U501) communicates with EEPROM (U502), and GMZAN-2 (U201)
through IIC(2 lines) or 4 bit bus line. It makes all devices operated properly.
4) Microprocessor (U501) let User adjust screen by OSD function.
3. LVDS(Low Voltage Differential Signal, U411)
LVDS transmitter (U411) delivers digital signal to the receiver inside LCD module by method of abstraction.
The abstracted signals are pairs of RIN0+-, RIN1+-, RIN2+-, RIN3+-, and RCLKIN+- of which voltage swing
is 0.5V each.
When SHUTON pin’s input is High, transmitter goes to power down mode.
4. DC/DC block
This block is composed of regulators which supplies 2.5V, 3.3V, and 5V.
Each regulator’s source power is 5VS and 12V from power block.
U806 supplies 2.5VD and 2.5VA and U802 supplies 3.3VD, 3.3V_AD, and 3.3V_PL powers to GMZAN-2’s
internal PLL, ADC, Pre-amp, and scaler by dropping down 5VS from power block.
U805 supplies MODPWR-3.3V for LCD module’s operation by dropping down 5VS from power block.
U803 supplies 5VR for Microprocessor and Logic IC(U701)’s operation by dropping down 12V from power block.
5. Power Block
This block supplies DC voltages of 5VS and 12V by converting AC input voltage of 100~240Vac.
Converting method is SMPS(Switching Mode Power Supply).

- 11 -
BLOCK DIAGRAM (AUO Module)

- 12 -
DESCRIPTION OF BLOCK DIAGRAM (AUO Module)
1. Scaler One chip IC(GMZAN-2, U201)
GMZAN-2 (U201) is one chip IC which it supports four internal function blocks of Video Amp, PLL,
A/D converter and Video processor.
Video signal (0.7Vp.p) clamped through C207, 208, 209 with matching IC’s proper cut off voltage.
This signal is processed as a proper 8 bit digital signal by U201’s amplifying, phase locking, A/D converting,
and scaling operations.
Also, U201 generates Clock, Horizontal and Vertical sync, Data Enable signals as Module’s input signals.
2. System Controller (Microprocessor) Circuit
1) Microprocessor (U501) distinguishes polarity and frequency by calculating horizontal and vertical sync input
from signal source.
2) Microprocessor (U501) carries out power control by sending power-down trigger signal to each IC.
3) Microprocessor (U501) communicates with EEPROM (U502), and GMZAN-2 (U201)
through IIC(2 lines) or 4 bit bus line. It makes all devices operated properly.
4) Microprocessor (U501) let User adjust screen by OSD function.
3. DC/DC block
This block is composed of regulators which supplies 2.5V, 3.3V, and 5V.
Each regulator’s source power is 5VS and 12V from power block.
U806 supplies 2.5VD and 2.5VA and U802 supplies 3.3VD, 3.3V_AD, and 3.3V_PL powers to GMZAN-2’s
internal PLL, ADC, Pre-amp, and scaler by dropping down 5VS from power block.
U805 supplies MODPWR-3.3V for LCD module’s operation by dropping down 5VS from power block.
U803 supplies 5VR for Microprocessor and Logic IC(U701)’s operation by dropping down 12V from power block.
4. Power Block
This block supplies DC voltages of 5VS and 12V by converting AC input voltage of 100~240Vac.
Converting method is SMPS(Switching Mode Power Supply).

- 13 -
ADJUSTMENT
All adjustment are thoroughly checked and corrected
when the monitor leaves the factory, but sometimes
several minor adjustment may be required.
Adjustment should be following procedure and after
warming up for a minimum of 10 minutes.
Alignment appliances and tools.
- IBM Compatible PC
- Programmable Signal Generator.
(eg. VG-819 made by Astrodesign Co.)
- E(E)PROM with each mode data saved.
- Alignment Adapter and Software.
1. Adjustment for Factory Preset Mode
1) Run alignment program for LB504J on the IBM
compatible PC.
2) Select EEPROM All Init. command and Enter.
3) Display cross hatch pattern at Mode 1.
4) Select COMMAND PRESET START command.
5) Select EDID WRITE command and Enter.
2. Adjustment for White Balance
1) Display color 0,0 pattern at Mode 13.
2) Set External Bright to MAX position and Contrast to
MAX Position.
3) Select PRESET START →BIAS CAL command
and Enter.
4) No attempt to manually adjust, BIAS data is auto-
matically adjusted and saved to the EEPROM.
5) Display color 15,0 pattern at Mode 13.
6) Select DRIVE CAL command and Enter.
7) Color 1 (9300K) and Color 2 (6500K) are
automatically adjusted and saved to the EEPROM.
8) Select PRESET EXIT command and Enter.
Figure 1. Cable Connection
220
IBM
Compatible PC
PARALLEL PORT
Power inlet (required)
Power LED
ST Switch
Power Select Switch
(110V/220V)
Control Line
Not used
RS232C
PARALLEL
V-SYNC POWER
ST
VGS MONITOR
E
E
V-Sync On/Off Switch
(Switch must be ON.)
F
F
A
A
B
B
C
C
1510
5
569
1
1
1
14
13
25
6
5V
5V
5V
4.7K
4.7K
4.7K
74LS06
74LS06
OFF ON
OFF
ON
11
Video Signal
Generator

- 14 -
TROUBLESHOOTING GUIDE
1. NO POWER
CHECK U803.
CHECK
U501 PIN 8
VOLTAGE
(5V) ?
NO
NO POWER
(POWER INDICATOR OFF)
CHECK POWER
BOARD, AND FIND
OUT A SHORT POINT
AS OPENING
EACH POWER LINE
CHECK J707
VOLTAGE
PIN1&PIN2(12V)
PIN4(5V)?
NO
CHECK 5VS LINE
(OPEN CHECK)
CHECK
U805 Voltage
(5V) ?
NO
CHECK IIC LINE
CONNECTION
(U501, U502)
CHECK U201 VCC,
XTAL, RESET
IS U201 PIN12
VOLTAGE REPEATED
AS PULSE SHAPE ? NO
YES
YES
YES NO PROBLEM
NO
CHECK KEY CONTROL
CONNECTOR ROUTINE

- 15 -
2. NO RASTER (OSD IS NOT DISPLAYED) – INVERTER
CHECK MICOM INV
ON/OFF PORT.
J705 PIN8
5V? NO
NO RASTER
(OSD IS NOT DISPLAYED)
CHECK POWER BOARD
J705 PIN1
12V? NO
1. CONFIRM BRIGHTNESS
OSD CONTRL STATE.
2. CHECK MICOM DIM-ADJ
PORT
J705 PIN7
5V? NO
REPLACE
INVERTER ASS’Y
CHECK
PULSE AS
CONTACTING SCOPE
PROBE TO CAUTION LABEL.
(CONTACT PROBE TO
CAUTION LABEL.
CAN YOU SEE PULSE
AT YOUR
SCOPE?
NO
REPLACE CCFL LAMP
IN THE LCD MODULE
YES
YES
YES
YES

- 16 -
1. CHECK PIN141, 142
SOLDERING CONDITION
2. CHECK X201
3. TROUBLE IN U201
U201
POWER PINS
3.3V?
NO CHECK U802, U806
U201 PIN141, 142
OSCILLATE AS 14.3M?
NO
CHECK CONNECTION LINE
FROM U201 TO U401/U411
NO
TROUBLE IN CABLE
OR LCD MODULE
TROUBLE IN CABLE
OR LCD MODULE
CHECK
CONNECTION LINE
FROM U201 TO J402
CHECK U805
CHECK
U805
U401/U411 PIN1
3.3V?
NO
NO
YES
YES
YES
(LG Philips Module)
YES
(AUO Module)
YES
YES
3. NO RASTER (OSD IS NOT DISPLAYED) – gmZAN2
NO RASTER
(OSD IS NOT DISPLAYED)
U401/U411
PIN31 IS 65MHz CLOCK?
PIN27 IS 48KHz H-SYNC?
PIN28 IS 60Hz V-SYNC?
PIN30 IS 48KHz DEN?
IS PULSE APPEARED
AT SIGNAL PINS?
J402
PIN63 IS 65MHz CLOCK?
PIN66 IS 48KHz H-SYNC?
PIN70 IS 60Hz V-SYNC?
PIN69 IS 48KHz DEN?
IS PULSE APPEARED
AT SIGNAL PINS?
J402
PIN74, PIN 1
3.3V?
YES
NO

- 17 -
CHECK U802, U806
U201
POWER PIN
3.3V?
NO
1. CHECK PC
2. CHECK SIGNAL CABLE
& D-SUB CONNECTOR
LINE
CHECK
R,G,B INPUT?
U201 PIN 87, 91, 95 NO
CHECK H-SYNC LINE
(D-SUB→U701→MICOM
→U201 PIN150)
CHECK
H-SYNC INPUT
U201 PIN 150?
NO
YES
YES
YES
NO RASTER
(OSD IS DISPLAYED)
4. NO RASTER (OSD IS DISPLAYED) – gmZAN2

PRINTED CIRCUIT BOARD
- 18 -
ZD502
C517 Q503 R533
R534 R2 C706 C709
D501
C514
R540
R537
C503
U502
C1
R1
R3
R529
R581 R411
U1
D1
C414 C415
R413
R414
L701
C705
1
C708
C822
C823
J702
L703 L702
C815
C832
1
L710
J706
C803
Q506
Q505
R532 Q502
R513 R510 R528
C502 C516
R530
R531
R570
R580
U411L411
LG PANNEL C401
C701 C702 C703
U401
L401
C704
C828
X201
C224
L804
R206
C223
C833
R820
C814
C809
L705
L704
C710
R709
U801
R801
J704
R535
ZD501
C511
Q501
C501
R560
R517
R512
R516
R515
R561 R511
R571
C411
C413
U802
R519
R524
R520
C508
C507
C412
C402
C211
C829
160
C404
C405
150
C235 C212
130
140
C215
C210 C270
L805
120
C811
C812
R708
C711
L802
ZD801
X501
R536C512 C513
R523
R518
R805
R551
C818 CC817
R521
R522
Hydis
R401
C403
PANNEL
510
R403
R404
C236
C206 R714
C214
R733
C713 C808
C807
Q701
R716
R722
ZD701
R538
C504
C715
B
R539
R526
R527
C819
C835
U805
B
R501
R502
R503
R504
R505
R506
R507
20
R207
C232
C225
C230
BA205 BA206
100
R710
R713
R202
R201
C257
R715
C712 U701
R734
ZD702 C731
R717
C716
R525
C505
C506
C509
C826
C820
C262
P/N :6870T436A11 DATE :2002.02.07
C261
BA201
MODEL:LB500J-LGPL/HYDIS
R508
R509
BA202 BA203
30
C205
BA204
L203
90
C258
C259
C269
A
R711
R712
L708
R720
C515
L707
RA501
RA502
U501
C830
U803
C
L706
D801 R541
R811
R807 C813
C816
L201
C825
L202
C209
C203
40
U201
R704
C226
C204
L204
80
C802
C801
R705
C821
C824
D703 D704
D705
C717
J705 J707
R810
A
R203 R204 R205
R208
R209
R210
C207
C208
C201
C202
C254
C255
C256
D701 D702
D706
R701
R702
R703
R706
R707
C220 C271
U806 C831
C827
L803
J703
1. MAIN BOARD (Component Side)
1
C805
40
C251
C253
C252
R804
R803
R802
L709
C719
C718
5
35
C241
C263 C233
C250
C249
C806
C722
C723
10
C264
C242
C237
C267
C245
C246
C247
C244
C248
R806
15
30
C243
C227
C234
20
25
C229
C228
C265
C266
2. MAIN BOARD (Solder Side)
LG Philips Module

- 19 -
C517 Q503 R534 U502 C16 C9 C3 C244
C265 C243 U1 R2 L710
D501
C514
R540
ZD502
C503
U501
R529
R537 R533
C502
C516
B
R528
R501
R502
R503
R504
R505
R506
R507
80
C17 C14 C19 C22 C24 C11
C8 C6
C25
C264
C249
C247
2
C233
C241
C252 C263
R1
R3
C1
D1
C708
C709
L702
L703
C832
R820
C803
J706
1
Q506
Q505
R532 Q502
R510
R530
R531
R511
R508
R509
R580
R581
79
C230
1
C227
C251
C828 C829
X201
L804
C224 R206
C223
C815
C814
C210 C270 C833
C809
L704
L705
R709
C710
U801
R801
J704
R535
ZD501
C511
Q501
C501
R513R570
R512
R560 R571
C23
U802
C20
C21
C18
C15
C13 C10
C266
C7
C12 C5
C4
C2
C253
C242
C267 C245
C246
C250
C228
C229
C234
J402
160
C235
C211
150 130
140
C212
C215
L805
120
C811
C812
R708
C711
L802
ZD801
R721
R538 R539 X501
R536C512 C513
R805
R517
R516
R551
R515
R523
R518
R561
C818
C819
C262 C817
R519
R524
R520
R521
R522
C508
C507
C248
BA24
BA7
BA8
510
C236
C205
C237
R714
C214
R733
R722
C713
C808
C807
Q701
R716
ZD701
C715
B
C504
R526 C835
R807
C261
L201
L202
U805
C
R525
BA20
BA6
20
C232
C206
BA5
100
R710
R713
R202
R201
R715
C712
U701
R734
ZD702 C731
R717
C716
C
R527
C505
C506
C509 BA19 BA21
BA22 BA23 BA3
30
C204
BA4
90
C257
C258
C259
C269
A
R711
R712
L708
R720
C515
L707
RA502
J705
RA501
C830
U803
R541
L706
D801
C826
C825
C813 C816
C820
R207
L204
40
R704
C226
C225 L203
80
C802
C801
R705
C821
C824
D704
D703
D705
C717
C822
C823
R810
J707
R811
A
D701 D702
D706 R203 R204 R205
R208
R209
R210
C207
C208
C209
C201
C202
C203
C254
C255
C256
R701
R702
R703
R706
R707
U201
MODEL:LB500J-AU
DATE :2002.02.07
P/N :6870T449A11
C220 C271
U806 C831
C827
L803
J703
3. MAIN BOARD (Component Side)
1
C805
40
R804
C718
R802
R803
C719
5
35
C723
C722
C806
L709
10
30
R806
15 20
25
4. MAIN BOARD (Solder Side)
AUO Module

- 20 -
P/N:6870T404U11
DATE:2001.11.14
C1
C2
C28
C27
U1
R40
L17
C31
R9
R1
R37C9
X1
C8
U2
R2
D1
C6 R25
L16
R8
R41
R19
C32
C18
R26
R31
R28 R30
R35 R34
L18
U3
C38
R21
L20
L13
L19
R22
C39
R32
L5 L4
ZD4
C43
C42
ZD1
C23
ZD12ZD11
C37
C24
R23
L14
ZD7
L15
C25
R24
J1
J5 J6
ZD8
5. USB BOARD (Component Side)
