Features
REDUCED TCO ( otal Cost of Ownership)
he 84WS70MS-B display is Energy Star® 5.1 compliant
consuming approximately 40% less energy than
noncompliant models. In standby mode, it uses less than
one watt of power and meets the environmental regulations
while excluding the use of harmful materials (RoHS) and
reducing CO2 emissions.
BEZEL WIDTH
his aesthetically superior display has the bezel width of
27.9mm that offers an elegant but modern look that will
work well with any decor.
LED Widescreen
Ultra HD Display
LGsolutions.com
Specifications
Native Display Resolution 3840 x 2160 (Ultra HD)
High Brightness 500 cd/m2
Contrast Ratio 1,400:1 ( yp.), 500,000:1 (DCR)
178°/ 178° Ultra Wide iewing Angle
Can be installed in Portrait or Landscape mode
RGB input/output (1)
D I-D input/output (1)
HDMI input (2)
DisplayPort input (1)
Convenient External Speaker-Out
Smart Energy Saving
Bezel Width 27.9mm
Temperature Sensor
USB Playback
3-Year Limited Warranty Parts/Labor/Backlight
DIGISIGN
84" class (84.04" measured diagonally)
84WS70 S-B


Super High Resolution
3,840 x 2,160 (Ultra HD)
The sheer size of the screen, equal to four 42-inch
class displays, gives you a breathtaking viewing
experience. The picture is so big and immersive,
it's as if you're in the scene and part of the action.
84" Edge LED Large Screen
Slot type edia Player
MP700, MP500
Slim design LG media players can be installedconveniently in
the back without taking up additional space.
Attachable External edia Players
(sold separately)
Create content based on the same resolution as the digital signage
monitor
Video content should be encoded at above an optimum level of bit rate
• Playback content larger than its original size
•Increasing bit rate will improve the quality of content, but
requires high performing CPU
•Dynamic content such as sports may require a higher bit rate
Recommended content creation when using a CPU i7 2.x GHz
When using the P700 follow these tips
to achieve the best playback quality
42” 42”
42” 42”
84”
Advantage
NO BLACKENING DEFECT
Display has a built-in temperature control
that adjusts to light and heat eliminating
dark or blackened areas.
IPS Competition
If the outdoor temperature is 86°F
the surface temperature of display is 185°F
TRUE WIDE IEWING
Color shifts and distortion are eliminated
from any viewing angle.
PANEL STABILITY
inimized image distortion and shows
no tailing when external pressure is
applied.
I PS Competition
Color change average @ 60°
Gamma change average @ 60°
IPS Competition
R comm ndation Ultra HD Signag FHD Signag HD Signag
Resolution 3,840 x 2,16 1,920 x 1,080 1,366 x 768
Bit Rate
80~120Mbps (full motion
video) over 40Mbps
(slideshow video)
over 20 Mbps (full motion
video) above 10Mbps
(slideshow video)
10 Mbps (full motion
video) over 5Mbps
(slideshow video)
Appropriate FPS/Hz 30 FPS 30 FPS 30 FPS
Codec H.264>MPEG4>MPEG2
(bigger file size)
H.264>MPEG4>MPEG2
(bigger file size)
H.264>MPEG4>MPEG2
(bigger file size)
Codec Pack K-Lite CodecPack K-Lite CodecPack K-Lite CodecPack
Boasting a pixel resolution 4X higher than Full HD
(1080p), its detail is so vivid and crisp, even when
viewed from a close distance.

LIFE’S GOOD...
when it’s green.
LG is committed to improving
product development, manufac-
turing and usage to meet the demand
for products with environmentally
friendlier features. Our Display has
technologies to reduce power
consumption and in return
increase cost savings per room.
EcoSmart
• Intelligent Sensor - Continually monitors room light conditions to automatically
optimize the picture quality for a more enjoyable viewing experience, which
can help save energy.
• Dynamic Power Savings - Using built-in algorithms, Display will automatically
reduce the power consumption based on incoming video, while maximizing
picture performance.
• Static Power Savings - Picture brightness level can be set at the preferred
power consumption level to reduce power and increase energy savings.
•CEC Compliant - eets the Appliance Efficiency Regulations of the California
Energy Commission.
•RoHS Compliant - eets directive on restriction of hazardous substances.
75.7” 2.0” 26.1” 600
14.0”
400
4.0”
43.7”
Rear Jack Panel

LG Electronics U.S.A., Inc.
HE B2B Division
2000 illbrook Drive
Lincolnshire, IL 60069
Customer Service: 888.865.3026
www.LGsolutions.com/support
Contact your LG Regional Sales Representative:
Channel: 800.897.8871
Hospitality: 800.228.1236
E-mail: [e-mail]
SPEC_84WS70 S_B_021313_PR
All screen images are simulated. Dimensions and weights are approximate.
Design, specifications, and features subject to change without notice.
© Copyright 2013 LG Electronics USA, Inc. All Rights Reserved. “LG Life’s
Good” is a registered trademark of LG Corp.
ENERGY STAR is a registered trademark of the U.S. Environmental Protection
Agency. In Plane Switching is a trademark of LG Philips LCD Ltd. VESA is a
trademark of Video Electronics Standards Association. HD I, the HD I logo
and High-Definition ultimedia Interface are trademarks or registered
trademarks of HD I Licensing LLC.
All other product and brand names are trademarks or registered trademarks
of their respective companies.
Printed in the USA. April 2013
LGsolutions.com
LED Widescreen
Ultra HD Display
DIGISIGN
PANEL
Mod l 84WS70MS-B
Screen Size 84" (84.04" measured diagonally)
Panel Technology PS
Aspect Ratio 16 : 9
Native Resolution 3840 x 2160 (UD)
Pixels(H x V x 3) 24,883,200
Brightness 500 cd/m2
Contrast Ratio 1,400:1
Dynamic CR 500,000 : 1
Color Gamut 72%
Tni 110°C (=230°F)
Viewing Angle 178°/178°
Color Depth 1.06 Billion
Response Time 12ms (G to G)
Surface Treatment Anti-glare(Haze <10%)
Orientation Portrait and Landscape
VIDEO (PC)
Max nput Resolution
3840 x 2160@30Hz (HDM , Display Port)
1920 x 1080@60Hz (RGB, DV -D)
Rec. Resolution 3840 x 2160@30Hz(HDM , Display Port)
H-Scanning Freq 30 ~83kHz (RGB, HDM /DV -D/DP)
V-Scanning Freq 56Hz ~75Hz (RGB), 56Hz~60Hz (HDM /DV -D/DP)
Pixel Frequency 300MHz(HDM , Display Port)
148.5MHz(RGB, DV -D)
Sync Compatability Separate, Composite, Digital
Video nput RGB, HDM , DV -D, Display Port, Composite
Picture mode ntelligent Sensor/Vivid / Standard / Cinema / Game/
Expert1/Expert2
Color temperature Warm, Medium , Cool
CONNECTIVITY
INPUT
(R ar)
Digital HDM (2), DV -D(1) with HDCP for all input
Analog RGB(1), Composite(1)
Audio RGB/DV -D/AV
External Control RS232C(1), RJ45(1), R(1)
USB USB(2)
HDTV Formats Component: 720p, 1080i , 1080p
HDM : 720p, 1080i, 1080p, 2160p
OUTPUT
(R ar)
Digital DV -D(1)
Analog Option1 ( ncluded): RGB(1)
Audio Yes(1)
External Control RS232C(1), R(1)
AUDIO
Balance Yes
Audio Power 20W (10W x 2)
Speaker on/off Yes
Clear Voice Yes
Sound Mode Standard / Music / Cinema / Sport / Game /Vivid/ User Setting
84" class (84.04" measured diagonally)
84WS70 S-B

PHYSICAL
SPECIFICATIONS
Mod l 84WS70MS-B
Color Black
Bezel Width 27.9mm
Monitor Dimensions 75.7” x 4.0” x 43.7” (W x H x D) (head only)
Monitor Weight 160.7 bs. (head only)
Carton Dimensions 80.0” x 12.4” x 47.8 (W x H x D)
Packed Weight 192.2 bs.
Handle Yes
VESA
TM
Standard
Mount nterface 600mm x 400mm
SPECIAL
FEATURES
Temperature Sensor
Auto Brightness Sensor
Source Selection: AV, Component, RGB, Display Port, DV -D, HDM
Brightness/Contrast/Backlight
Position/Size
Auto Config/Phase
Language (OSD)
English, French, German, Spanish, talian, Korean , Chinese(Simplified),
Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish,
Japanese, Russian, Portugues(Europe), Dutch, Czech, Greek
Language (USB
Playback)
English, French, German, Spanish, talian, Korean , Chinese(Simplified),
Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish,
Japanese, Russian, Portugues(Europe), Dutch, Czech, Greek
Language (Manual)
English, French, talian, German, Spanish, Portugues, Hungarian, Greek, Russian,
Dutch, Kazakh, Ukrainian, Polish, Arabic, ndonesian, Korean, Japanese, Turkish,
Czech, Taiwanese, Slovak
Language (ESG)
English, French, talian, German, Spanish, Portugues, Greek, Polish, Czech, Slovak
SM Method Normal, White Wash, Orbiter, nversion
Advanced Dynamic Contrast, Dynamic Color, Clear White, Skin Color, Noise Reduction,
Digital Noise Reduction, Gamma, Black Level
Time Clock, On/Off Time, Sleep Timer, Power on Delay, Auto Off, Automatic Standby
nformation Model/Type, Software Version, Serial Number, P Address,
MAC Address, Homepage
nput Label Yes(PC/DTV)
Auto Power/Source
Memory Yes
Key Lock
DPM Select
Energy Saving Yes (Minimum, Medium, Maxium)
Smart Energy Saving
Power ndicatior On/Off
File Play with USB
ENVIRONMENT
CONDITIONS
Operation Temp. 0°C ~40°C
Operation Humidity 10% ~80%
POWER
Power Supply 100 -240V~, 50/60Hz
Power C onsumption Normal (Typical) 350W
Smart Energy Saving on 200W
DPMS Off 1.5W(RGB)
Power Off 0.5W
STANDARD
CERTIFICATION
Safety UL / cUL / CB scheme / TUV
EMC FCC Class "A", VCC , C-tick, CE, KCC
MEDIA PLAYER
COMPATIBILITY
Yes (MP500, MP700)
WARRANTY
3-Year Limited Warranty (Parts/Labor/Backlight)
UPC
7 19192 19191 4
OPTIONAL
ACCESSORIES
D-Sub Cable, Power Cord, Remote Controller(include battery 2ea ), CD(Manual/Elite-C),
Eye Bolt(2EA)
Media Player: MP700/MP500
