LG FLATRON L1952H Installation and operation manual

L1952H
19" (19.0" VIS) Active Matrix LCD Color Monitor
P ODUCT INFO
An ergonomically designed workhorse. The FLATRON
LCD L1952 has a footprint that's ideal for any office
environment, large or small. Its color is extraordinary, and
its viewing capabilities and digital on-screen adjustments
especially convenient. The L1952 is backed by 3 Year
Quick Swap Warranty.
• Brilliant Active Matrix TFT Display
• Integrated (Picture-Quality Enhancing Chip)
• Ultra Fast 8ms Response Time
• Digital (DVI-D) and VGA Analog (15 pin D-Sub) Inputs
• 1400:1 igh Contrast Ratio
• Tilt and eight adjustable
• Universal 90-264 VAC Power
• EPA Energy Star and VESA DPMS Compliant
• TCO'03 Low-Emission Compliant
• Simple One Touch-Auto-Setup Function
KEY FEATU ES
L1952H
IG PERFORMANCE

L1952H
SPECIFICATIONS
VIEWS UP CLOSE
DISPLAY TYPE 19.0" (19.0" VIS) Active Matrix TFT Color
LCD Screen
DISPLAY AREA (H x V) 14.8" x 11.9" (376mm x 301mm)
DISPLAY COLORS 16.2 Million
PIXEL PITCH 0.294mm x 0.294mm Pixel
PIXEL CONFIGURATION RGB Stripe Arrangement
SURFACE TREATMENT Hard Coating 3H, Anti-Glare
ELECTRONIC INTERFACE LVDS
BACKLIGHTING 4CCFL
MAXIMUM RESOLUTION 1280 x 1024
BRIGHTNESS 300cd/m2 (Typical)
CONTRAST RATIO 1400:1 (Typical)
RESPONSE TIME 8 ms (Typical)
VIEWING ANGLE H: 160°, V: 160°
HORIZONTAL SCANNING 30-83KHz, Auto-Synchronous
FREQUENCIES
VERTICAL SCANNING 56-75Hz, Auto-Synchronous
FREQUENCIES
AUTO-SYNC SUPPORT 640 x 350 up to 70Hz, 640 x 480 up to 70Hz, 720 x
400 up to 70Hz, 800 x 600 up to 75Hz, 832 x 624
up to 75Hz, 1024 x 768 up to 75Hz, 1152 x 870 up
to 75Hz, 1280 x 1024 up to 75Hz
CONTROL TYPE On-Screen Display of Adjustments
INPUT SIGNAL RGB Analog and Digital
INPUT TERMINALS Digital (DVI-D)and standard VGA D-Sub 15-pin
Connector
SYNC SIGNALING Separate H/V
VESA PLUG AND PLAY LEVEL DDC2B, DDC1
DIGITAL ON-SCREEN CONTROLS Brightness, Contrast, Horizontal/Vertical
Position, Clock, Phase (+/-), Language Select,
Auto-Adjust, OSD Position, Color Temp
(9300K, 6500K, User), Information
FRONT PANEL CONTROLS Source, Menu, f-ENGINE, Auto-Set/Select,
Power
POWER REQUIREMENTS 90-264 VAC, 50-60Hz
DPMS POWER CONSUMPTION On: 39 Watts, Standby: 1 Watts
TILT/HEIGHT ADJUSTABLE
VESA MOUNTING COMPLIANCE Standard VESA Mounting, 75mm x 75mm
Screw Spacing
DIMENSIONS (WxHxD) Set: 158.28" x 184.25" x 81.89"
Boxed: 178.35" x 151.18" x 61.02"
WEIGHT Set: 10.14 lbs, Boxed: 13.45 lbs
SAFETY/REGULATORY TCO‘03, UL1950, FCC-B, EPA Energy Star,
IEC950, CSA, CE, TUV-GS, SEMKO, GOST,
ISO 9241-3,7,8, C-TICK, VCCI-2
ACCESSORIES Power Cord, Signal Cable, Manual, Install
Disk
LGEUS WARRANTY 3 Year QuickSwap Replacement Program
UPC Code # 71919218229
WARRANTY
CONTACT US
• The L1952 LCD Monitor Comes with LG's 3 Year Quick Swap Warranty
• 3 Year Parts, Labor and Backlight
• LG Pays Shipping Both Ways
• 48 our Swap Program
• Call Toll-Free 1-800-243-0000 (24 ous 7 Days a Week)
• For More Information, please visit ww.LGUSA.com
• Phone: [phone]
• Email: [email protected]
www.LGSuperSeller.com
www.LGusa.com
Additional Products www.LGusa.com
L C D
M o n i t o r s
O p t i c a l
D r i v e s
M e m o r y
P r o d u c t s
LG ELECT ONICS U.S.A., INC.
CE Brand Division
920 Sylvan Avenue, Englewood Cliffs, NJ 07632 Tel: [phone] Fax: [phone]
Design and specifications subject to change without notice. 4/2006
FRONT SIDE
