37" LCD HD CAPABLE MONITOR
SHOWN WITH OPTIONAL STAND
M3701C-BA
37" Class (37.0" diagonal) LCD Widescreen HD Monitor
LG Electronics USA, Inc.
• 37" Class (37.0" diagonal) LCD
Widescreen HD Monitor
• 1366 768 Resolution (WXGA)
• 16:9 Aspect Ratio
• 178 degree viewing angle (S-IPS)
Super IPS Technology allows for distortion-
free viewing from almost any angle
• 500 cd/m2Brightness
• 8ms Response Time
• 1600:1 Contrast Ratio
• HDMI™/ Composite (BNC) / Component
(BNC) and S-Video inputs
• Tile Mode: 4 4 available multiplying the
size of display
• Temperature and Lamp Fault Sensor
• Limited Warranty 3 years
www.LGcommercial.com
Note: IP-ready via interface box using LG's IP card
solutions for Digital Signage applications. Contact
[e-mail] for more information.
19686_M3701CBA_031408.qxd:M3201C 3/14/08 6:58 PM Page 1

REAR JACK PANEL
www.LGcommercial.com
LG Electronics USA, Inc., Commercial Division, 2000 Millbrook Drive, Lincolnshire, IL 60069 Customer Service: 1-888-865-3026
Contact your LG Regional Sales Manager Toll-Free – Hospitality: 1-800-228-1236; B2B: 1-800-897-8788; Channel Markets: 1-800-897-8871
Screen image is simulated. Dimensions and weights are approximate. Design, specifications, and features subject to change without notice.
©Copyright 2008 LG Electronics USA, Inc. All Rights Reserved. HDTV monitors require optional set-top box to receive high-definition broadcast. “LG Life’s Good” is a registered trademark
of LG Corp. VESA™is a registered trademark of Video Electronics Association. All other product and brand names are trademarks or registered trademarks of their respective companies.
Printed in the USA. March 2008 19686_M3701CBA_031408
SPECIFICATIONS
PANEL
LCD Panel Type 37” Widescreen TFT (Thin Film Transistor) –
LCD (Liquid Crystal Display)
Display Area 37.0”
Panel Type (TN,IPS) S-IPS
Aspect Ratio 16:9
Native Resolution 1366x768
Brightness 500 cd/m2
Contrast Ratio 1600:1
Response Time 8 ms
Viewing Angle 178 / 178
MTBF 50,000 Hrs
Color Depth 16.7 Million (8bits)
Pixel Pitch 0.600 x 0.600
Lamp Quantity 16 CCFL
Surface Treatment AG (3H)
VIDEO
Max Input Resolution 768p
H-Scanning Frequency RGB : 30 - 83 kHz; HDMI/DVI : 30 - 72 kHz
V-Scanning Frequency 56 - 85 Hz
Synchronization Type Separate/Composite/SOG (Sync On
Green)/Digital
INPUTS AND OUTPUTS
15 Pin D-Sub RGB In / RGB Out
HDMI™(digital) with HDCP 1 In / DVI (through HDMI™ to DVI adapter - not
included)
S-Video 1 In
Component 2 Component In (1080i) BNC with audio
Composite 1 in / 1 out(BNC) with audio
PC Audio Input Yes
RS-232C RS-232C In / RS-232C Out
Remote Control input Yes / IR Jack
CONTROL
Key Number 8
Key Location Right Bottom
Key Type Tact Switch
LED color Amber-off/Green-on
OSD Language English,French,German,Italian,Spanish,
Portuguese,Korean
POWER
Power Supply Internal
Rated Voltage AC 100-240V~ 50/60Hz 2.0A
On Mode 180W
DPM Off 1W
Off Mode 1W
Sleep Mode < _1W (RGB) / 4W(HDMI/DVI)
ENVIRONMENTAL CONDITIONS
Operational Condition Temperature Temperature: 50°F ~ 95°F, 10°C ~ 35°C ,
Humidity: 10% ~ 80%
Storage Condition Temperature: -4°F ~ 140°F, -20°C ~ 60°C ,
Humidity: 5% ~ 95%
CABINET
Front Color Black
Rear Color Black
Monitor Dimensions (W x H x D) 36.54 inches x 22.49 inches x 4.43 inches
(Head Only)
Weight (Head Only) 67.16 lbs
Carton Dimensions (W x H x D) 41.97 inches x 32.76 inches x 14.18 inches
Packed Weight 80.16 lbs
Kensington Lock Yes
AUDIO FEATURES
Max Audio output 20Watt (10W x 2EA)
Audio Built-in AMP, Equalizer, Auto Volume Limiter, Balance,
Speaker on/off
SSM Surround Max, Flat, Music, Movie, Sports, User
SPECIAL FEATURES
XD Engine®Yes
XD Demo Yes (Not Available in RBG PC/HDMI/DVI PC Mode)
Pb Free Yes
DDC/CI Yes
Intelligent Auto (Auto Resolution) Yes
Tile Mode Yes, Max 4 x 4
Temperature Sensor Yes
Lamp Fault Sensor Yes
LG Logo Light off / on selectable
ISM Method Normal, Orbiter, Inversion, White Wash
PSM Dynamic, Standard, Mild, User 1, 2
CSM Warm, Normal, Cool, User
CERTIFICATIONS
UL(cUL) Yes
TUV-GS Yes
SEMKO Yes
FCC-B, CE Yes
VESA™ Mounting Yes (600 x 400)
CB scheme Yes
VCCI Yes
GOST Yes
MIC Yes
RoHS compliant Yes
ACCESSORIES
Remote Control/AAABatteries(2)
User's Guide/Driver CD-Rom/Warranty Card
15-pin D-Sub Signal Cable
Power Cable
Audio Cable (PC)
RCA-PC Audio Cable
OPTIONAL ACCESSORIES
Speakers (SP3700K) Black
Speaker Dimensions (W x H x D) 4.95 inches x 22.49 inches x 2.89 inches
Weight 2.56 lbs
Stand (ST3700K) Black/Silver
Stand Dimensions (W x H x D) 26.40 inches x 5.00 inches x 7.50 inches
Weight 6.86 lbs
LIMITED WARRANTY (PARTS/LABOR) 3 years
UPC CODE 719192182523
M3701C-BA 37" Class (37.0" diagonal) LCD Widescreen HD Monitor
LG Electronics USA, Inc.
FRONT VIEW SIDE VIEW BACK VIEW
