DISPLAY DEVICES CATALOGUE
2008 SPRING EDITION
LG Twin Towers, 20 Yeouido-dong,
Yeongdeungpo-gu, Seoul 150-721, Korea
Yeouido P.O.Bo 335, Seoul, Korea
www.lge.com | www.flatron.com
About LG Electronics, Inc. | LG Electronics, Inc. (KSE: 066570.KS) is a global leader and technology innovator in
consumer electronics, home appliances and mobile communications, employing more than 82,000 people working in
over 110 operations including 81 subsidiaries around the world. With 2007 global sales of USD 44 billion, LG is comprised
of four business units - Mobile Communications, Digital Appliance, Digital Display and Digital Media. LG is the world’s
leading producer of mobile handsets, flat panel TVs, air conditioners, front-loading washing machines, optical storage
products, DVD players and home theater systems. For more information, please visit www.lge.com.
About LG Electronics Digital Display Company | LG Digital Display Company is a leading producer of LCD and plasma
TVs and is one of the world’s top makers of plasma modules. While focusing on creating feature-rich TVs, the company is
also pursuing stylish designs and pushing technological boundaries to provide a more e citing viewing e perience. LG's
product areas include: televisions and computer monitors, plasma display panels, projectors and others.
2008 SPRING EDITION

THE ADVANTAGE OF
FLATRON LCD
Clear Vision
•As real as it gets
- As if looking at a real object
•Reduces eye strain when looking
at small image
◉
The Art of Design
Winner of Consecutive Design Award since 2003
◉
DFC (Digital Fine Contrast ratio) 10000:1
Experience clear and sharp images on an
LG FLATRON LCD Colors literally jump off
the screen
WIDE FORMAT
SERIES
Ideal for Movies
•Optimized for maximum image
brightness
- Suitable for moving images
with various brightness levels.
e.g. movies, cartoons, games, photos, etc.
•Enjoy clear, crisp and bright images
Advanced Dark Color Control
•Displays top-quality dark images
- Images remain clear even on
dark backgrounds
•Superior range of dark colors
•Automatically displays perfect
black tones
Technology Behind DFC
•1st Step: Analyze
input content and
automatically
recognizes the need
to boost contrast
•2nd Step: Activate
contrast enhancer
control to boost
contrast
•3rd Step: Display an
improved digital
image with optimal
contrast
ONOFF
ONOFF
ONOFF
FLATRON L2320A
FLATRON L172WT FLATRON L1530TM
FLATRON L1740P
FLATRON LX60 Series
FLATRON L1780U
FLATRON LX70 Series
FLATRON Fantasy
FLATRON L1982U
FLATRON W2284F FLATRON W52 Series
•
2008 - FLATRON W2284F
(iF Product Design Award 2008)
FLATRON W52 Series (iF Product Design Award 2008)
•
2007 - FLATRON Fantasy (reddot design award 2007)
(iF Product Design Award 2007)
FLATRON L1982U (reddot design award 2007)
•
2006 - FLATRON LX70 Series (reddot design award)
(iF Product Design Award)
FLATRON LX60 Series (reddot design award)
•
2005 - FLATRON L1780U (reddot design award)
FLATRON L1740P (iF Material Design Award)
•
2004 - FLATRON L172WT (reddot design award)
FLATRON L1530TM (reddot design award)
•
2003 - FLATRON L2320A (reddot design award)
(iF Design Award)

WOO SERIES
WIDE FORMAT
SERIES
WOO & L7W SERIES
Enjoy Vivid Color
Images
Get the True Color
that You Want
Achieve the True
Color into Your
Work
◉
uilt-in US 2.0 Hub
•1 up / 4 down
•Easy connection for various
external inputs
◉
Wide Color Gamut
Enjoy crystal clear images and rich colors on your LCD with a
Wide Color Gamut precision of 115%
Play MOVIES, Play GAMES, Play Wide, Play LG!
•Conventional •Color Gamut 115%
Change of Lamp
Phosphor Material
Features
•Color Gamul:115% NTSC
•New Phosphor Development:
red and green
- Red phosphor peak
wavelength shift
(Type 611 nm Type 640 nm)
- Green phosphor peak
wavelength shift
(Type 544 nm Type 530 nm)
Advantage Points
-No change of LCM
(Liquid Crystal Module)
dimension
-Applicable to CCFL
premium products
0.9
0.8
0.
0.6
0.5
0.4
0.3
0.2
0.1
0.0
0.0 0.1 0.2 0.3 0.4 0.5 0.6 0. 0.8 0.9
72%
3D Game
Graphic
Standard
Monitor
FLATRON
W2600HP
H:178˚ V:178˚
◉
S-IPS
S-IPS technology allows
viewers to see still or
moving images from any
vertical or horizontal angle
without substantial loss in
picture quality.
◉
Ergonomic Design
Fatigue and eye strain are
diminished thanks to the tilt,
swivel, and height adjustment.
◉
Dual Hinge
Advanced dual hinge with
tilt, height adjustment,
and folding functions. The
height can be adjusted by
175 mm, the highest range
in the market today.
05 | WIDE FORMAT SERIES
PANEL SPEC Size
Brightness
Contrast Ratio
Response Time
Viewing Angle
Supported Colors
Resolution
PHYSICAL Connector
FEATURES Dimension (Net)
(Gross)
Weight
POWER On Mode
CONSUMPTION DPM Off Mode
SPECIAL Multimedia
FEATURES
AV / TV
Stand
USB
VESA Wall mounting
Regulation
DEPLOYED MODEL
30" Wide (WCG 115%)
370 cd/m2(Typical)
3000:1 (DFC)
5ms (GTG)
H : 178°, V : 178° (CR>10) (S-IPS)
16.7M Colors
2560 x 1600 (WQXGA)
DVI-D (Dual Link)
703 x 270 x 525 mm
789 x 276 x 600 mm
Net : 12.3 kg, Gross : 15.4 kg
130W (Typical)
1W (Typical)
HDCP, Sound
-
Tilt, Swivel, Height Adjustment
1 Up 4 Down
VESA (100 x 100, 200 x 100)
TCO-99
25.5" Wide (26" Class)(WCG 102%)
400 cd/m2(Typical)
5000:1 (DFC)
5ms (GTG)
H : 178°, V : 178° (CR>10) (S-IPS)
16.7M Colors
1920 x 1200 (WUXGA)
15 Pin D-Sub, DVI-D
602 x 270 x 463 mm
688 x 276 x 535 mm
Net : 9.7 kg, Gross : 12.3 kg
110W (Typical)
1W (Typical)
FLATRON f Engine, HDCP,
4:3 in Wide, ez Zooming, Sound
-
Tilt, Swivel, Height Adjustment
1 Up 4 Down
VESA (100 x 100)
TCO-03
25.5" Wide (26" Class)
300 cd/m2(Typical)
5000:1 (DFC)
5ms (GTG)
H : 170°, V : 160° (CR>10)
16.7M Colors
1920 x 1200 (WUXGA)
15 Pin D-Sub, DVI-D, HDMI, PC Audio Out
602 x 270 x 463 mm
688 x 276 x 535 mm
Net : 9.7 kg, Gross : 12.3 kg
90W (Typical)
1W (Typical)
FLATRON f Engine, HDCP,
4:3 in Wide, ez Zooming, Sound
-
Tilt, Swivel, Height Adjustment
1 Up 4 Down
VESA (100 x 100)
-
25.5" Wide (26" Class)
300 cd/m2(Typical)
5000:1 (DFC)
5ms (GTG)
H : 170°, V : 160° (CR>10)
16.7M Colors
1920 x 1200 (WUXGA)
15 Pin D-Sub, DVI-D
602 x 270 x 463 mm
688 x 276 x 535 mm
Net : 9.7 kg, Gross : 12.3 kg
50W (Typical)
1W (Typical)
FLATRON f Engine, HDCP,
4:3 in Wide, ez Zooming, Sound
-
Tilt, Swivel, Height Adjustment
1 Up 4 Down
VESA (100 x 100)
-
W3000H W2600HP W2600V W2600H
WIDE FORMAT SERIES
W2600V

06 | WIDE FORMAT SERIES
L7W SERIES
PANEL SPEC Size
Brightness
Contrast Ratio
Response Time
Viewing Angle
Supported Colors
Resolution
PHYSICAL Connector
FEATURES Dimension (Net)
(Gross)
Weight
POWER On Mode
CONSUMPTION DPM Off Mode
SPECIAL Multimedia
FEATURES
AV / TV
Stand
USB
VESA Wall mounting
Regulation
DEPLOYED MODEL
22" Wide (WCG 100%)
300 cd/m2(Typical)
10,000:1 (DFC)
2ms (GTG)
H : 176°, V : 170° (CR>5)
16.7M Colors
1680 x 1050 (WSXGA+)
15 Pin D-Sub, DVI-D
508 x 230 x 424 mm
575 x 160 x 453 mm
Net : 5.3 kg, Gross : 6.2 kg
45W (Typical)
1W (Typical)
FLATRON f Engine, HDCP,
4:3 in Wide, ez Zooming
-
Tilt
-
VESA (100 x 100)
-
22" Wide
300 cd/m2(Typical)
10,000:1 (DFC)
2ms (GTG)
H : 176°, V : 170° (CR>5)
16.7M Colors
1680 x 1050 (WSXGA+)
15 Pin D-Sub, DVI-D
508 x 230 x 424 mm
575 x 160 x 453 mm
Net : 5.3 kg, Gross : 6.2 kg
45W (Typical)
1W (Typical)
FLATRON f Engine, HDCP,
4:3 in Wide, ez Zooming
-
Tilt
-
VESA (100 x 100)
-
20" Wide (WCG 100%)
300 cd/m2(Typical)
10,000:1 (DFC)
2ms (GTG)
H : 170°, V : 170° (CR>5)
16.7M Colors
1680 x 1050 (WSXGA+)
15 Pin D-Sub, DVI-D
472 x 230 x 402 mm
535 x 160 x 409 mm
Net : 3.9 kg, Gross : 5.0 kg
40W (Typical)
1W (Typical)
FLATRON f Engine, HDCP,
4:3 in Wide, ez Zooming
-
Tilt
-
VESA (100 x 100)
-
19" Wide
300 cd/m2(Typical)
10,000:1 (DFC*)
2ms (GTG)
H : 170°, V : 170° (CR>5)
16.7M Colors
1440 x 900 (WXGA+)
15 Pin D-Sub, DVI-D
440 x 237 x 436 mm
495 x 172 x 396 mm
Net : 5.7 kg, Gross : 6.8 kg
36W (Typical)
1W (Typical)
FLATRON f Engine, HDCP,
4:3 in Wide, ez Zooming
-
Dual Hinge, Height Adjustment, Tilt
VESA (100 x 100)
-
L227WT L227WTG L207WT L197WH
WIDE FORMAT SERIES
WIDE FORMAT
SERIES
W52 SERIES
Clear Vision
•As real as it gets
- As if looking at a real object
•Reduces eye strain when looking
at small image
◉
DFC (Digital Fine Contrast ratio) 10000:1
Experience clear and sharp images on an
LG FLATRON LCD. Colors literally jump
off the screen
Ideal for Movies
•Optimized for maximum movie
image brightness
- Suitable for moving images
with various brightness levels
ex) Movies, Animations, Games, Photos, etc.
•Enjoy clear, crisp and bright images
Advanced Dark Color Control
•Excels in displaying dark images
- Image remain clear in dark
backgrounds
•Superior classification of dark
colors
•Displays ‘PERFECT BLACKS’
through automatic control
ONOFF
ONOFF
ONOFF
Play tastic Wide_
Here comes the tastic World you wa t!
4:3 in Wide
- Enjoy original 4:3 images with LG Wide Monitor.
- When playing a 4:3 format game, you can enjoy
real 4:3 image with this monitor.
- If you do not use the monitor that supports this
wide aspect ratio, you will not get "undistorted
characters" images and " true to nature" scenes.
ez Zooming
- You can switch the resolution with a touch of a
button. (screen resolution reduces by one level)
Photo Effect
- You can easily change an image's tone & color
like in Photoshop program.
(Blur/sepia/Monochrome Effect)
- You cna give the photo shop effect to all kinds of
UCC (Moving picture stell cut, etc) with a touch
of a key.
Sound
- Press a POWER button to turn on the screen with
a pleasant sound.
◉
Play on the tastic World, All
pleasure is here!
L227WT L197WH

08 | WIDE FORMAT SERIES
W52 SERIES W52 SERIES
PANEL SPEC Size
Brightness
Contrast Ratio
Response Time
Viewing Angle
Supported Colors
Resolution
PHYSICAL Connector
FEATURES Dimension (Net)
(Gross)
Weight
POWER On Mode
CONSUMPTION DPM Off Mode
SPECIAL Multimedia
FEATURES
AV / TV
Stand
USB
VESA Wall mounting
Regulation
DEPLOYED MODEL
22" Wide
300 cd/m2(Typical)
10,000:1 (DFC)
2ms (GTG)
H : 170°, V : 170° (CR>5)
16.7M Colors
1680 x 1050 (WSXGA+)
15 Pin D-Sub, DVI-D
519 x 221 x 429 mm
582 x 127 x 449 mm
Net : 4.4 kg, Gross : 5.4 kg
40W (Typical)
1W (Typical)
FLATRON f Engine, HDCP, 4:3 in Wide,
ez Zooming, Photo Effect, Sound
-
Tilt
-
-
-
*Color (Stand) : Black, White (Back) : Black, White
22" Wide
300 cd/m2(Typical)
10,000:1 (DFC)
5ms (Typical)
H : 170°, V : 170° (CR>5)
16.7M Colors
1680 x 1050 (WSXGA+)
15 Pin D-Sub
519 x 221 x 429 mm
582 x 127 x 449 mm
Net : 4.4 kg, Gross : 5.4 kg
40W (Typical)
1W (Typical)
FLATRON f Engine, 4:3 in Wide,
ez Zooming, Photo Effect, Sound
-
Tilt
-
-
-
20" Wide
300 cd/m2(Typical)
10,000:1 (DFC)
2ms (GTG)
H : 170°, V : 170° (CR>5)
16.7M Colors
1680 x 1050 (WSXGA+)
15 Pin D-Sub, DVI-D, HDMI, PC Audio Out
477 x 221 x 403 mm
539 x 135 x 420 mm
Net : 4.0 kg, Gross : TBD
40W (Typical)
1W (Typical)
FLATRON f Engine, HDCP, 4:3 in Wide,
ez Zooming, Photo Effect, Sound
-
Tilt
-
-
-
20" Wide
300 cd/m2(Typical)
10,000:1 (DFC)
2ms (GTG)
H : 170°, V : 170° (CR>5)
16.7M Colors
1680 x 1050 (WSXGA+)
15 Pin D-Sub, DVI-D
477 x 221 x 403 mm
539 x 135 x 420 mm
Net : 4.0 kg, Gross : TBD
40W (Typical)
1W (Typical)
FLATRON f Engine, HDCP, 4:3 in Wide,
ez Zooming, Photo Effect, Sound
-
Tilt
-
-
-
*Color (Stand) : Black, White (Back) : Black, White
W2252T W2252S W2052V W2052T
WIDE FORMAT SERIES
09 | WIDE FORMAT SERIES
W2452V
PANEL SPEC Size
Brightness
Contrast Ratio
Response Time
Viewing Angle
Supported Colors
Resolution
PHYSICAL Connector
FEATURES Dimension (Net)
(Gross)
Weight
POWER On Mode
CONSUMPTION DPM Off Mode
SPECIAL Multimedia
FEATURES
AV / TV
Stand
USB
VESA Wall mounting
Regulation
DEPLOYED MODEL
24" Wide
400 cd/m2(Typical)
10,000:1 (DFC)
2ms (GTG)
H : 170°, V : 170° (CR>5)
16.7M Colors
1920 x 1200 (WUXGA)
15 Pin D-Sub, DVI-D, HDMI, PC Audio Out
574 x 243 x 463 mm
646 x 160 x 485 mm
Net : 6.1 kg, Gross : 7.8 kg
85W (Typical)
1W (Typical)
FLATRON f Engine, HDCP, 4:3 in Wide,
ez Zooming, Photo Effect, Sound
-
Tilt, Swivel
-
-
-
24" Wide
400 cd/m2(Typical)
10,000:1 (DFC)
5ms (Typical)
H : 170°, V : 170° (CR>5)
16.7M Colors
1920 x 1200 (WUXGA)
15 Pin D-Sub, DVI-D
574 x 243 x 463 mm
646 x 160 x 485 mm
Net : 6.1 kg, Gross : 7.8 kg
80W (Typical)
1W (Typical)
FLATRON f Engine, HDCP, 4:3 in Wide,
ez Zooming, Photo Effect, Sound
-
Tilt, Swivel
-
-
-
22" Wide
300 cd/m2(Typical)
10,000:1 (DFC)
2ms (GTG)
H : 170°, V : 170° (CR>5)
16.7M Colors
1680 x 1050 (WSXGA+)
15 Pin D-Sub, DVI-D, HDMI, PC Audio Out
519 x 221 x 429 mm
582 x 127 x 449 mm
Net : 4.5 kg, Gross : 5.4 kg
40W (Typical)
1W (Typical)
FLATRON f Engine, HDCP, 4:3 in Wide,
ez Zooming, Photo Effect, Sound
-
Tilt
-
-
-
22" Wide (Glare)
300 cd/m2(Typical)
10,000:1 (DFC)
2ms (GTG)
H : 170°, V : 170° (CR>5)
16.7M Colors
1680 x 1050 (WSXGA+)
15 Pin D-Sub, DVI-D
519 x 221 x 429 mm
582 x 127 x 449 mm
Net : 4.5 kg, Gross : 5.4 kg
40W (Typical)
1W (Typical)
FLATRON f Engine, HDCP, 4:3 in Wide,
ez Zooming, Photo Effect, Sound
-
Tilt
-
-
-
W2452V W2452T W2252V W2252TG
WIDE FORMAT SERIES
W2452V

10 | WIDE FORMAT SERIES
W52 SERIES
PANEL SPEC Size
Brightness
Contrast Ratio
Response Time
Viewing Angle
Supported Colors
Resolution
PHYSICAL Connector
FEATURES Dimension (Net)
(Gross)
Weight
POWER On Mode
CONSUMPTION DPM Off Mode
SPECIAL Multimedia
FEATURES
AV / TV
Stand
USB
VESA Wall mounting
Regulation
DEPLOYED MODEL
20" Wide
300 cd/m2(Typical)
10,000:1 (DFC)
2ms (GTG)
H : 170°, V : 170° (CR>5)
16.7M Colors
1680 x 1050 (WSXGA+)
15 Pin D-Sub, DVI-D
477 x 221 x 403 mm
539 x 135 x 420 mm
Net : 4.0 kg, Gross : TBD
40W (Typical)
1W (Typical)
FLATRON f Engine, HDCP, 4:3 in Wide,
ez Zooming, Photo Effect, Sound
-
Tilt
-
-
-
20" Wide
300 cd/m2(Typical)
10,000:1 (DFC)
5ms (Typical)
H : 170°, V : 170° (CR>5)
16.7M Colors
1680 x 1050 (WSXGA+)
15 Pin D-Sub
477 x 221 x 403 mm
539 x 135 x 420 mm
Net : 4.0 kg, Gross : TBD
40W (Typical)
1W (Typical)
FLATRON f Engine, 4:3 in Wide,
ez Zooming, Photo Effect, Sound
-
Tilt
-
-
-
19" Wide
300 cd/m2(Typical)
10,000:1 (DFC)
2ms (GTG)
H : 170°, V : 170° (CR>5)
16.7M Colors
1440 x 900 (WXGA+)
15 Pin D-Sub, DVI-D
452 x 221 x 385 mm
511 x 140 x 395 mm
Net : 3.9 kg, Gross : 4.5 kg
36W (Typical)
1W (Typical)
FLATRON f Engine, HDCP, 4:3 in Wide,
ez Zooming, Photo Effect, Sound
-
Tilt
-
-
-
*Color (Stand) : Black, White (Back) : Black, White
19" Wide
300 cd/m2(Typical)
10,000:1 (DFC)
5ms (Typical)
H : 170°, V : 170° (CR>5)
16.7M Colors
1440 x 900 (WXGA+)
15 Pin D-Sub
452 x 221 x 385 mm
511 x 140 x 395 mm
Net : 3.9 kg, Gross : 4.5 kg
36W (Typical)
1W (Typical)
FLATRON f Engine, 4:3 in Wide,
ez Zooming, Photo Effect, Sound
-
Tilt
-
-
-
W2052TG W2052S W1952T W1952S
WIDE FORMAT SERIES
WIDE FORMAT
SERIES
USB MNT
•Pivot 90° : You can simply rotate the monitor from landscape to
portrait and vice versa without using Pivot S/W through GUI
(Graphic User Interface)
◉
Ergonomic Comfort
•Height Adjustment : It includes a sliding
control system and the latest picture
enhancement technology
◉
Easy US Connection
•You can make the multi screen environment with up to 8 monitors (USB Cables up to 6 / D-sub 1 /
Laptop computer 1) by simply connecting USB cable into the USB port on the back of FLATRON
L206WU without any graphic card installed
PANEL SPEC Size
Brightness
Contrast Ratio
Response Time
Viewing Angle
Supported Colors
Resolution
PHYSICAL Connector
FEATURES
Dimension (Net)
(Gross)
Weight
POWER On Mode
CONSUMPTION DPM Off Mode
SPECIAL Multimedia
FEATURES AV / TV
Stand
USB
VESA Wall mounting
Regulation
DEPLOYED MODEL
22" Wide
300 cd/m2(Typical)
5000:1 (DFC)
2ms (GTG)
H : 176°, V : 170° (CR>5)
16.7M Colors
1680 x 1050 (WSXGA+)
15 Pin D-Sub, DVI-D, USB
(MultiLink Technology)
502 x 271 x 430 mm
582 x 255 x 411 mm
Net : TBD, Gross : 7.8 kg
45W (Typical)
2W (Typical)
FLATRON f Engine, HDCP, 4:3 in Wide
-
Pivot (90°), Height Adjustment,
Tilt, Swivel
-
VESA (100 x 100)
-
20" Wide
300 cd/m2(Typical)
5000:1 (DFC)
2ms (GTG)
H : 170°, V : 170° (CR>5)
16.7M Colors
1680 x 1050 (WSXGA+)
15 Pin D-Sub, DVI-D, USB
(MultiLink Technology)
471 x 271 x 420 mm
557 x 244 x 379 mm
Net : 4.6 kg, Gross : 6.0 kg
45W (Typical)
2W (Typical)
FLATRON f Engine, HDCP, 4:3 in Wide
-
Pivot (90°), Height Adjustment,
Tilt, Swivel
-
VESA (100 x 100)
-
L226WU L206WU
WIDE FORMAT SERIES
MULTILINK TECHNOLOGY_
Multi Scree , Multi Task! Easy to Co ect, Easy to Use!
USB I put I terface for Multi Scree to Provide Easy User Experie ce
L206WU
W2452V

12 | WIDE FORMAT SERIES
W42 SERIES
PANEL SPEC Size
Brightness
Contrast Ratio
Response Time
Viewing Angle
Supported Colors
Resolution
PHYSICAL Connector
FEATURES Dimension (Net)
(Gross)
Weight
POWER On Mode
CONSUMPTION DPM Off Mode
SPECIAL Multimedia
FEATURES AV / TV
Stand
USB
VESA Wall mounting
Regulation
DEPLOYED MODEL
22” Wide
300 cd/m2(Typical)
8000:1 (DFC)
5ms (Typical)
H : 170°, V : 170° (CR>5)
16.7M Colors
1680 x 1050 (WSXGA+)
15 Pin D-Sub, DVI-D
516 x 209 x 418 mm
574 x 127 x 407 mm
Net : 4.7 kg, Gross : 6.4 kg
40W (Typical)
1W (Typical)
FLATRON f Engine, HDCP, 4:3 in Wide
-
Tilt
-
VESA (75 x 75)
TCO-03
*Color (Front) : Black (Glossy)
Black (Non-Glossy), Silver (Non-Glossy)
22” Wide
300 cd/m2(Typical)
8000:1 (DFC)
5ms (Typical)
H : 170°, V : 170° (CR>5)
16.7M Colors
1680 x 1050 (WXGA+)
15 Pin D-Sub
516 x 209 x 418 mm
574 x 127 x 407 mm
Net : 4.7 kg, Gross : 6.4 kg
40W (Typical)
1W (Typical)
FLATRON f Engine, 4:3 in Wide
-
Tilt
-
VESA (75 x 75)
TCO-03
*Color (Front) : Black (Glossy)
Black (Non-Glossy), Silver (Non-Glossy)
20" Wide
300 cd/m2(Typical)
8000:1 (DFC)
5ms (Typical)
H : 170°, V : 170° (CR>5)
16.7M Colors
1680 x 1050 (WSXGA+)
15 Pin D-Sub, DVI-D
474 x 198 x 390 mm
535 x 124 x 375 mm
Net : 4.5 kg, Gross : 5.3 kg
40W (Typical)
1W (Typical)
FLATRON f Engine, HDCP, 4:3 in Wide
-
Tilt
-
VESA (75 x 75)
TCO-03
*Color (Front) : Black (Glossy)
Black (Non-Glossy), Silver (Non-Glossy)
20" Wide
300 cd/m2(Typical)
5000:1 (DFC)
5ms (Typical)
H : 170°, V : 170° (CR>5)
16.7M Colors
1680 x 1050 (WSXGA+)
15 Pin D-Sub
474 x 198 x 390 mm
535 x 124 x 375 mm
Net : 4.5 kg, Gross : 5.3 kg
40W (Typical)
1W (Typical)
FLATRON f Engine, 4:3 in Wide
-
Tilt
-
VESA (75 x 75)
TCO-03
*Color (Front) : Black (Glossy)
Black (Non-Glossy), Silver (Non-Glossy)
W2242T W2242S W2042T W2042S
WIDE FORMAT SERIES
W42 SERIES
PANEL SPEC Size
Brightness
Contrast Ratio
Response Time
Viewing Angle
Supported Colors
Resolution
PHYSICAL Connector
FEATURES Dimension (Net)
(Gross)
Weight
POWER On Mode
CONSUMPTION DPM Off Mode
SPECIAL Multimedia
FEATURES AV / TV
Stand
USB
VESA Wall mounting
Regulation
DEPLOYED MODEL
19" Wide
300 cd/m2
8000:1 (DFC)
5ms (Typical)
H : 170°, V : 170° (CR>5)
16.7M Colors
1440 x 900 (WXGA+)
15 Pin D-Sub, DVI-D
448 x 198 x 383 mm
511 x 119 x 359 mm
Net : 4.1 kg, Gross : 4.9 kg
36W (Typical)
1W (Typical)
FLATRON f Engine, HDCP, 4:3 in Wide
-
Tilt
-
VESA (75 x 75)
TCO-03
*Color (Front) : Black (Glossy)
Black (Non-Glossy), Silver (Non-Glossy)
19" Wide
300 cd/m2
8000:1 (DFC)
5ms (Typical)
H : 170°, V : 170° (CR>5)
16.7M Colors
1440 x 900 (WXGA+)
15 Pin D-Sub
448 x 198 x 383 mm
511 x 119 x 359 mm
Net : 4.1 kg, Gross : 4.9 kg
36W (Typical)
1W (Typical)
FLATRON f Engine, 4:3 in Wide
-
Tilt
-
VESA (75 x 75)
TCO-03
*Color (Front) : Black (Glossy)
Black (Non-Glossy), Silver (Non-Glossy)
15.6" Wide
230 cd/m2(Typical)
5000:1 (DFC)
8ms (Typical)
H : 100°, V : 55° (CR>5)
16.7M Colors
1366 x 768 (WXGA)
15 Pin D-Sub
382 x 198 x 323 mm
434 x 117 x 338 mm
Net : 3.3 kg, Gross : 3.6 kg
18W (Typical)
1W (Typical)
FLATRON f Engine, 4:3 in Wide
-
Tilt
-
-
-
W1942T W1942S W1642S
WIDE FORMAT SERIES
13 | WIDE FORMAT SERIES
W2242T W2242T

MONITOR TV
SERIES
PANEL SPEC Size
Brightness
Contrast Ratio
Response Time
Viewing Angle
Supported Colors
Resolution
PHYSICAL Connector
FEATURES Dimension (Net)
(Gross)
Weight
POWER On Mode
CONSUMPTION DPM Off Mode
SPECIAL Multimedia
FEATURES AV / TV
Stand
USB
VESA Wall mounting
Regulation
DEPLOYED MODEL
21.6" Wide
300 cd/m2(Typical)
8000:1 (DFC)
5ms (Typical)
H : 170°, V : 170°
16.7M Colors
1680 x 1050 (WSXGA+)
15 Pin D-Sub
516 x 209 x 418 mm
574 x 127 x 407 mm
Net : 4.1 kg, Gross : 5.8 kg
40W (Typical)
1W (Typical)
FLATRON f Engine, 4:3 in Wide
-
Tilt
-
VESA (75 x 75)
TCO-03
22" Wide
300 cd/m2(Typical)
1000:1 (Typical)
5ms (Typical)
H : 170°, V : 160°
16.7M Colors
1680 x 1050 (WSXGA+)
15 Pin D-Sub
502 x 234 x 422 mm
566 x 190 x 415 mm
Net : 5.7 kg, Gross : 6.9 kg
40W (Typical)
1W (Typical)
4:3 in Wide
-
Tilt
-
VESA (100 x 100)
TCO-03
*Color (Front) : Black (Non-Glossy)
Silver (Non-Glossy)
(Stand) : Black (Non-Glossy)
22" Wide
300 cd/m2(Typical)
1000:1 (Typical)
5ms (Typical)
H : 170°, V : 160°
16.7M Colors
1680 x 1050 (WSXGA+)
15 Pin D-Sub
510 x 206 x 431 mm
566 x 133 x 403 mm
5.2 kg, Gross : 6.2 kg
40W (Typical)
1W (Typical)
4:3 in Wide
-
Tilt
VESA (100 x 100)
TCO-03
*Color (Front) : Black (Non-Glossy)
Silver (Non-Glossy)
(Stand) : Black (Non-Glossy)
19" Wide
300 cd/m2(Typical)
1000:1 (Typical)
5ms (Typical)
H : 170°, V : 170° (CR>5)
16.7M Colors
1440 x 900 (WXGA+)
15 Pin D-Sub
448 x 183 x 376 mm
514 x 141 x 380 mm
Net : 3.2 kg, Gross : 4.8 kg
36W (Typical)
1W (Typical)
4:3 in Wide
-
Tilt
VESA (75 x 75)
TCO-03
*Color (Front) : Black (Non-Glossy)
Silver (Non-Glossy)
(Stand) : Black (Non-Glossy)
17" Wide
250 cd/m2(Typical)
5000:1 (DFC)
8ms (Typical)
H : 170°, V : 170° (CR>5)
16.7M Colors
1440 x 900 (WXGA+)
15 Pin D-Sub
409 x 204 x 362 mm
464 x 142 x 388 mm
Net : 2.8 kg, Gross : 4.0 kg
23W (Typical)
1W (Typical)
FLATRON f Engine, 4:3 in Wide
-
Tilt
-
VESA (100 x 100)
-
W2241S L224WS W2234S W1934S L177WSB
WIDE FORMAT SERIES
14 | WIDE FORMAT SERIES

◉
Various AV / TV Functions
Users can enjoy easy and convenient access to
AV / TV devices such as a DVD Player, VCR,
Video game console, camcorder and more.
MONITOR TV
SERIES
MORE INPUTS, MORE FUN_ With the Monitor TV series, LG offers multi-purpose all-in-one display
solutions for a variety of PC and home entertainment uses. Users can en oy easy and convenient access to AV
devices such as a DVD player, VCR, Video game console, Camcorder and more.
MUSIC
TV
PC
DVD
CAMCORDER
GAME
TV PC GAME CAMCORDER DVD
MUSIC
◉
HDTV
Users can watch HD Broadcast with built-In Digital Tuner inside the Monitor. Which means no mandatory TV Card in your
PC, and you get another free digital TV. It's now possible to work, and enjoy your favorite TV shows on a single screen.
PANEL SPEC Size
Brightness
Contrast Ratio
Response Time
Viewing Angle
Supported Colors
Resolution
PHYSICAL Connector
FEATURES
Dimension (Net)
(Gross)
Weight
POWER On Mode
CONSUMPTION DPM Off Mode
SPECIAL Multimedia
FEATURES
AV / TV
Stand
USB
VESA Wall mounting
Regulation
DEPLOYED MODEL
22” Wide
300 cd/m2(Typical)
3000:1 (DFC)
5ms (Typical)
H : 176°, V : 170° (CR>5)
16.7M Colors
1680 x 1050 (WSXGA+)
15 Pin D-Sub, HDMI,
Component, SCART x 2
(Full / half), Composite,
PC Audio In
525 x 230 x 440 mm
593 x 161 x 471 mm
Net : 6.2 kg, Gross : 7.1 kg
60W (Typical)
1W (Typical)
XD Engine, HDCP, 4:3 in
Wide, RS232, Hotel Mode
TV Tuner (Digital)
Tilt, Swivel
-
VESA (100 x 100)
-
22” Wide
300 cd/m2(Typical)
3000:1 (DFC)
5ms (Typical)
H : 170°, V : 170° (CR>5)
16.7M Colors
1680 x 1050 (WSXGA+)
15 Pin D-Sub, DVI-D,
Component (SCART),
Composite, S-Video,
PC Audio In / Out
525 x 230 x 439 mm
593 x 161 x 471 mm
Net : 5.8 kg, Gross : 7.1 kg
50W (Typical)
1W (Typical)
HDCP, 4:3 in Wide
TV Tuner
Tilt, Swivel
-
VESA (100 x 100)
-
20” Wide
300 cd/m2(Typical)
3000:1 (DFC)
5ms (Typical)
H : 160°, V : 160° (CR>10)
16.7M Colors
1680 x 1050 (WSXGA+)
15 Pin D-Sub, HDMI,
Component (SCART),
Composite, S-Video,
PC Audio In / Out
484 x 230 x 414 mm
548 x 161 x 441 mm
Net : 4.8 kg, Gross : 6.8 kg
50W (Typical)
1W (Typical)
XD Engine, HDCP, 4:3
in Wide, Hotel Mode
TV Tuner
Tilt, Swivel
-
VESA (100 x 100)
-
20" Wide
300 cd/m2(Typical)
3000:1 (DFC)
5ms (Typical)
H : 170°, V : 170° (CR>5)
16.7M Colors
1680 x 1050 (WSXGA+)
15 Pin D-Sub, DVI-D,
Component (SCART),
Composite, S-Video,
PC Audio In / Out
484 x 230 x 413 mm
548 x 161 x 441 mm
Net : 4.8 kg, Gross : 6.8 kg
50W (Typical)
1W (Typical)
HDCP, 4:3 in Wide
TV Tuner
Tilt, Swivel
-
VESA (100 x 100)
-
19” Wide
300 cd/m2(Typical)
3000:1 (DFC)
16.2M Colors
H : 170°, V : 170° (CR>5)
5ms (Typical)
1440 x 900 (WXGA+)
15 Pin D-Sub, DVI-D,
Component (SCART),
Composite, S-Video, PC
Audio In / Out
455 x 230 x 392 mm
520 x 161 x 422 mm
Net : 4.9 kg, Gross : 6.4 kg
50W (Typical)
1W (Typical)
HDCP, 4:3 in Wide
TV Tuner
Tilt, Swivel
-
VESA (100 x 100)
-
19”
300 cd/m2
3000:1 (DFC)
5ms (Typical)
H : 170°, V : 170° (CR>5)
16.7M Colors
1280 x 1024 (SXGA)
15 Pin D-Sub, S-Video,
SCART, Composite,
PC Audio In / Out
445 x 243 x 457 mm
509 x 175 x 475 mm
Net : 5.5 kg, Gross : 7.1 kg
45W (Typical)
1W (Typical)
-
TV Tuner
Tilt, Swivel
-
VESA (100 x 100)
-
17”
300 cd/m2
3000:1 (DFC)
5ms (Typical)
H : 170°, V : 170° (CR>5)
16.7M Colors
1280 x 1024 (SXGA)
15 Pin D-Sub, S-Video,
SCART, Composite,
PC Audio In / Out
394 x 243 x 404 mm
448 x 161 x 406 mm
Net : 4.5 kg, Gross : 6.2 kg
40W (Typical)
1W (Typical)
-
TV Tuner
Tilt, Swivel
-
VESA (100 x 100)
-
M228WD M228WA M208WV M208WA M198WA M1921A M1721A
MONITOR TV SERIES
17 | MONITOR TV SERIES
M228WD M1921A

4:3 FORMAT
SERIES
4:3 FORMAT
SERIES
Auto Bright_The Auto
Bright function
automatically controls the
brightness of the monitor to best suit the
surrounding working environment. This
provides the user with optimal viewing
conditions and maximum convenience
◉
DFC(Digital Fine Contrast ratio) 5000:1
Experience clear and sharp mages on an
LG FLATRON LCD Colors literally jump off
the screen
THE EPITOME OF ADVANCED TECHNOLOGIES_ The FLATRON Ultra Slim Series are the fi est
mo itors that epitomize a wide variety of cutti g-edge tech ologies. High-tech desig , best picture quality a d
ergo omic fu ctio ality optimizes the user e viro me t.
Ideal for Movies
•Optimized for maximum movie
image brightness
- Suitable for moving images
with various brightness levels.
e.g. movies, cartoons, games, photos, etc.
•Enjoy clear, crisp and bright images
Advanced Dark Color Control
•Displays top-quality dark images
- Images remain clear even on
dark backgrounds
•Superior range of dark colors
•Automatically displays perfect
black tones
ONOFF
ONOFF
Clear Vision
•As real as it gets
- As if looking at a real object
•Reduces eye strain when looking
at small images
ONOFF
2 ms (GTG)
Lightening Fast
Response Time_With its speedy 2 ms
response time, LG FLATRON LCD Monitors
provide crisp images whilst minimizing
image distortion Your video games have never looked so good
FLATRON L1982U
◉
The Art of Design
FLATRON L1982U
Winner of reddot design award 2007
Standard 2ms(GTG)
◉
Top Performer for Multimedia Users
FLATRON f Engine_LG's Picture
Enhancing Chip for LCD Monitors_
FLATRON f Engine uses DAFI technology and RCM (Real Color
Management) which display vibrant and natural colors on the monitor
ACE (Adaptive Color and Contrast Enhancement) enhances brightness
and contrast. The technology optimizes image quality for videos and
high-resolution photos
