LG LB580N User manual

OWNER’S MANUAL
LED Monitor*
Please read this manual carefully before operating your set and retain
it for future reference.
LB580N
www.lg.com
* LG LED Monitors are LCD Monitors with LED backlighting.
www.lg.com
P/NO : MFL68027074(1407-REV00)
Printed in Korea
*MFL68027074*

A-2 TABLE OF CONTENTS
COMMON
TABLE OF CONTENTS
A-3 SETTING UP THE MONITOR
A-3 Attaching the stand
A-4 MAKING CONNECTIONS
COMMON
B-1 SPECIFICATIONS
LANGUAGE
LANGUAGE LIST
English
Türkçe

A-3
SETTING UP THE MONITOR
SETTING UP THE
MONITOR
Image shown may differ from your monitor.
Attaching the stand
B stand base
A stand base
1
1
2
2
4EA
M4 x L14
CAUTION
yWhen attaching the stand to the monitor
set, place the screen facing down on a
cushioned table or flat surface to protect
the screen from scratches.

A-4 MAKING CONNECTIONS
MAKING CONNECTIONS
AUDIO
VIDEO
MONO
( )
VIDEO
OPTICAL AUDIO IN
H/P OUT
Headphone
Digital Audio
System
DVD/ Blu-Ray /
HD Cable Box
DVD / Blu-Ray / HD Cable
Box / VCR
RED
WHITE
RED
GREEN BLUE
RED
WHITE
RED
GREEN
BLUE
YELLOW
WHITE
RED
YELLOW
WHITE
RED

A-5
MAKING CONNECTIONS
HDMI
DVI OUT
AUDIO OUT
USB
HUB
HDD
Mobile Phone
MHL passive cable
DVD / Blu-Ray / HD Cable Box / HD STB /
PC (Only HDMI IN 1(ARC) or HDMI IN 2)
DVD / Blu-Ray / HD Cable Box / HD STB /
PC (Only HDMI IN 1(ARC) or HDMI IN 2)
WHITE
RED
English
Connect your Monitor to external devices. For the best picture and audio quality, connect the external
device and the Monitor with the HDMI cable as shown. Some separate cable is not provided.
Türkçe
Monitor’nizi harici cihazlara bağlayın. En iyi resim ve ses kalitesi için harici cihazı ve Monitor’yi gösterildiği
gibi HDMI kablosuyla bağlayın. Ayrı bir kablo sağlanmaz.

A-6 MAKING CONNECTIONS
English
Connect various external devices to the Monitor
and switch input modes to select an external
device. For more information of external device’s
connection, refer to the manual provided with
each device.
Available external devices are: HD receivers,
DVD players, VCRs, audio systems, USB storage
devices, PC, gaming devices, and other external
devices.
NOTE
yThe external device connection may differ
from the model.
yConnect external devices to the Monitor
regardless of the order of the Monitor
port.
yRefer to the external equipment’s manual
for operating instructions.
yIf you connect a gaming device to the
Monitor, use the cable supplied with the
gaming device.
yIn PC mode, there may be noise
associated with the resolution, vertical
pattern, contrast or brightness. If noise is
present, change the PC output to another
resolution, change the refresh rate to
another rate or adjust the brightness and
contrast on the PICTURE menu until the
picture is clear.
yIn PC mode, some resolution settings
may not work properly depending on the
graphics card.
Türkçe
Monitor’ye çeşitli harici cihazlar bağlayın ve bir
harici cihaz seçmek için giriş modlarına geçin.
Harici cihaz bağlantısı hakkında daha fazla bilgi
için cihazlarla birlikte verilen kılavuza bakın.
Kullanılabilir harici cihazlar şunlardır: HD alıcılar,
DVD oynatıcılar, VCR cihazları, ses sistemleri,
USB depolama aygıtları, PC, oyun cihazları ve
diğer harici cihazlar.
NOT
yHarici cihaz bağlantısı modele göre
değişiklik gösterebilir.
yHarici cihazları Monitor’ye, Monitor
bağlantı noktalarını dikkate almaksızın
bağlayın.
yKullanım talimatları için harici cihazın
kullanım kılavuzuna başvurun.
yMonitor’ye bir oyun cihazı bağlarsanız,
oyun cihazıyla birlikte verilen kabloyu
kullanın.
yPC modunda, çözünürlük, dikey desen,
kontrast veya parlaklığa bağlı parazit
görülebilir. Parazit varsa PC çıkışını başka
bir çözünürlüğe ayarlayın, yenileme hızını
değiştirin veya net bir görüntü elde edene
kadar RESİM menüsünden parlaklık ve
kontrast ayarlarını değiştirin.
yPC modunda bazı çözünürlük ayarları
grafik kartına bağlı olarak çalışmayabilir.

OWNER’S MANUAL
LED Monitor*
Please read this manual carefully before operating your set and retain
it for future reference.
www.lg.com
* LG LED Monitors are LCD Monitors with LED backlighting.

2
ENGLISH
LICENSES / OPEN SOURCE SOFTWARE NOTICE / EXTERNAL CONTROL DEVICE SETUP
LICENSES
Supported licenses may differ by model. For more information about licenses, visit www.lg.com.
OPEN SOURCE SOFTWARE NOTICE
To obtain the source code under GPL, LGPL, MPL and other open source licenses, that is contained in this
product, please visit http://opensource.lge.com .
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are
available for download.
LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of
performing such distribution (such as the cost of media, shipping and handling) upon email request to
[email protected]. This offer is valid for three (3) years from the date on which you purchased the
product.
EXTERNAL CONTROL DEVICE SETUP
To obtain the external control device setup information, please visit www.lg.com.

3
ENGLISH
SAFETY INSTRUCTIONS
SAFETY INSTRUCTIONS
Please read these safety precautions carefully before using the product.
WARNING
yDo not place the monitor and/or remote control in the following
environments:
- A location exposed to direct sunlight
- An area with high humidity such as a bathroom
- Near any heat source such as stoves and other devices that produce
heat
- Near kitchen counters or humidifiers where they can easily be exposed
to steam or oil
- An area exposed to rain or wind
- Near containers of water such as vases
Otherwise, this may result in fire, electric shock, malfunction or product
deformation.
yDo not place the product where it might be exposed to dust.
This may cause a fire hazard.
yMains Plug is the monitor connecting/disconnecting device to AC mains
electric supply.This plug must remain readily attached and operable when
monitor is in use.
yDo not touch the power plug with wet hands. Additionally, if the cord pin is
wet or covered with dust, dry the power plug completely or wipe dust off.
You may be electrocuted due to excess moisture.
yMake sure to connect Mains cable to compliant AC mains socket with
Grounded earth pin. (Except for devices which are not grounded on earth.)
Otherwise possibility you may be electrocuted or injured.
yInsert power cable plug completely into wall socket otherwise if not secured
completely into socket, fire ignition may break out.
yEnsure the power cord does not come into contact with hot objects such as
a heater.
This may cause a fire or an electric shock hazard.

4
ENGLISH
SAFETY INSTRUCTIONS
yDo not place a heavy object, or the product itself, on power cables.
Otherwise, this may result in fire or electric shock.
yWhen mounting monitor onto wall make sure to neatly install and isolate
cabling from rear of monitor as to not create possibility of electric shock /fire
hazard.
yDo not plug too many electrical devices into a single multiple electrical
outlet.
Otherwise, this may result in fire due to over-heating.
yDo not drop the product or let it fall over when connecting external devices.
Otherwise, this may result in injury or damage to the product.
Desiccant
yKeep the anti-moisture packing material or vinyl packing out of the reach of
children.
Anti-moisture material is harmful if swallowed. If swallowed by mistake,
force the patient to vomit and visit the nearest hospital. Additionally, vinyl
packing can cause suffocation. Keep it out of the reach of children.
yDo not let your children climb or cling onto the monitor.
Otherwise, the monitor may fall over, which may cause serious injury.
yDispose of used batteries carefully to ensure that a small child does not
consume them.
Please seek Doctor- Medical Attention immediately if child consumes
batteries.
yDo not insert any metal objects/conductors (like a metal chopstick/cutlery/
screwdriver) between power cable plug and input Wall Socket while it is
connected to the input terminal on the wall. Additionally, do not touch the
power cable right after plugging into the wall input terminal. You may be
electrocuted.
(Depending on model)
yDo not put or store inflammable substances near the product.
There is a danger of combustion/explosion or fire due to careless handling
of the inflammable substances.
yDo not drop metallic objects such as coins, hair pins, chopsticks or wire into
the product, or inflammable objects such as paper and matches. Children
must pay particular attention.
Electrical shock, fire or injury can occur. If a foreign object is dropped into
the product, unplug the power cord and contact the service centre.
yDo not spray water on the product or scrub with an inflammable substance
(thinner or benzene). Fire or electric shock accident can occur.

5
ENGLISH
SAFETY INSTRUCTIONS
yDo not allow any impact, shock or any objects to fall into the unit, and do
not drop anything onto the screen.
You may be injured or the product can be damaged.
yNever touch this product during a thunder or lighting storm.
You may be electrocuted.
yNever touch the wall outlet when there is leakage of gas, open the windows
and ventilate.
It may cause a fire or a burn by a spark.
yDo not disassemble, repair or modify the product at your own discretion.
Fire or electric shock accident can occur.
Contact the service centre for check, calibration or repair.
yIf any of the following occur, unplug the product immediately and contact
your local service centre.
- The product has been impacted by shock
- The product has been damaged
- Foreign objects have entered the product
- The product produced smoke or a strange smell
This may result in fire or electric shock.
yUnplug the monitor from AC mains wall socket if you do not intend to use
the monitor for a long period of time.
Accumulated dust can cause fire hazard and insulation deterioration can
cause electric leakage/shock/fire.
yApparatus shall not be exposed to dripping or splashing and no objects
filled with liquids, such as vases, shall be placed on the apparatus.
yDo not install this product on a wall if it could be exposed to oil or oil mist.
This may damage the product and cause it to fall.
CAUTION
yDo not install the product on places such as unstable shelves or inclined
surfaces. Also avoid places where there is vibration or where the product
cannot be fully supported.
Otherwise, the product may fall or flip over, which may cause injury or
damage to the product.

6
ENGLISH
SAFETY INSTRUCTIONS
yIf you install the monitor on a stand, you need to take actions to prevent the
product from overturning. Otherwise, the product may fall over, which may
cause injury.
yIf you intend to mount the product to a wall, attach VESA standard mounting interface (optional
parts) to the back of the product. When you install the set to use the wall mounting bracket (optional
parts), fix it carefully so as not to drop.
yOnly use the attachments / accessories specified by the manufacturer.
yWe recommend that you maintain a distance of at least 2 to 7 times the
diagonal screen size when watching monitor.
If you watch monitor for a long period of time, this may cause blurred vision.
yOnly use the specified type of battery.
This could cause damage to the remote control.
yDo not mix new batteries with old batteries.
This may cause the batteries to overheat and leak.
yBatteries should not be exposed to excessive heat. For example, keep away from direct Sunlight ,
open fireplace and electric heaters .
yDo not place non-rechargeable batteries in charging device.
yMake sure there are no objects between the remote control and its sensor.
ySignal from Remote Control can be interrupted due to external/internal
lighting eg Sunlight, fluorescent lighting.
If this occurs turn off lighting or darken viewing area.
yWhen connecting external devices such as video game consoles, make
sure the connecting cables are long enough.
Otherwise, the product may fall over, which may cause injury or damage
the product.
yDo not turn the product On/Off by plugging-in or unplugging the power plug
to the wall outlet. (Do not use the power plug for switch.)
It may cause mechanical failure or could give an electric shock.
yPlease follow the installation instructions below to prevent the product from
overheating.
- The distance between the product and the wall should be more than
10 cm.
- Do not install the product in a place with no ventilation (e.g., on a
bookshelf or in a cupboard).
- Do not install the product on a carpet or cushion.
- Make sure the air vent is not blocked by a tablecloth or curtain.
Otherwise, this may result in fire.

7
ENGLISH
SAFETY INSTRUCTIONS
yTake care not to touch the ventilation openings when watching the monitor
for long periods as the ventilation openings may become hot. This does not
affect the operation or performance of the product.
yPeriodically examine the cord of your appliance, and if its appearance indicates damage or
deterioration, unplug it, discontinue use of the appliance, and have the cord replaced with an
exact replacement part by an authorized servicer.
yPrevent dust collecting on the power plug pins or outlet.
This may cause a fire hazard.
yProtect the power cord from physical or mechanical abuse, such as being
twisted, kinked, pinched, closed in a door, or walked upon. Pay particular
attention to plugs, wall outlets, and the point where the cord exits the
appliance.
yDo not press strongly upon the panel with a hand or sharp object such
as nail, pencil or pen, or make a scratch on it, as it may cause damage to
screen.
yAvoid touching the screen or holding your finger(s) against it for long
periods of time. Doing so may produce some temporary or permanent
distortion/damage to screen.
yWhen cleaning the product and its components, unplug the power first and
wipe it with a soft cloth. Applying excessive force may cause scratches or
discolouration. Do not spray with water or wipe with a wet cloth. Never use
glass cleaner, car or industrial shiner, abrasives or wax, benzene, alcohol
etc., which can damage the product and its panel.
Otherwise, this may result in fire, electric shock or product damage
(deformation, corrosion or breakage).
yAs long as this unit is connected to the AC wall outlet, it is not disconnected from the AC power
source even if you turn off this unit by SWITCH.
yWhen unplugging the cable, grab the plug and unplug it, by pulling at the
plug.
Don’t pull at the cord to unplug the power cord from the power board, as
this could be hazardous.
yWhen moving the product, make sure you turn the power off first. Then,
unplug the power cables and all connecting cables.
The monitor set or power cord may be damaged, which may create a fire
hazard or cause electric shock.
yWhen moving or unpacking the product, work in pairs because the product
is heavy.
Otherwise, this may result in injury.
yContact the service centre once a year to clean the internal parts of the
product.
Accumulated dust can cause mechanical failure.

8
ENGLISH
SAFETY INSTRUCTIONS
yRefer all servicing to qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, such as power supply cord
or plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
yIf the product feels cold to the touch, there may be a small “flicker” when it
is turned on. This is normal, there is nothing wrong with product.
yThe panel is a high technology display product with resolution of two million
to six million pixels. You may see tiny black dots and/or brightly coloured
dots (red, blue or green) at a size of 1 ppm on the panel. This does not
indicate a malfunction and does not affect the performance and reliability of
the product.
This phenomenon also occurs in third-party products and is not subject to
exchange or refund.
yYou may find different brightness and color of the panel depending on your
viewing position(left/right/top/down).
This phenomenon occurs due to the characteristic of the panel. It is not
related with the product performance, and it is not malfunction.
yDisplaying a still image (e.g., broadcasting channel logo, on-screen menu, scene from a video
game) for a prolonged time may cause damage to the screen, resulting in retention of the image,
which is known as image sticking. The warranty does not cover the product for image sticking.
Avoid displaying a fixed image on your monitor’s screen for a prolonged period (2 or more hours
for LCD, 1 or more hours for Plasma).
Also, if you watch the monitor at a ratio of 4:3 for a long time, image sticking may occur on the
borders of the panel.
This phenomenon also occurs in third-party products and is not subject to exchange or refund.
yGenerated Sound
“Cracking” noise: A cracking noise that occurs when watching or turning off the monitor is
generated by plastic thermal contraction due to tempera-ture and humidity. This noise is common
for products where thermal deformation is required. Electrical circuit humming/panel buzzing: A
low level noise is generated from a high-speed switching circuit, which supplies a large amount of
current to operate a product. It varies depending on the product.
This generated sound does not affect the performance and reliability of the product.

9
ENGLISH
ASSEMBLING AND PREPARING
NOTE
yImage shown may differ from your monitor.
yYour monitor’s OSD (On Screen Display) may differ slightly from that shown in this manual.
yThe available menus and options may differ from the input source or product model that you are
using.
yNew features may be added to this monitor in the future.
yThe monitor can be placed in standby mode in order to reduce the power consumption. And the
monitor should be turned off if it will not be watched for some time, as this will reduce energy
consumption.
yThe energy consumed during use can be significantly reduced if the level of brightness of the
picture is reduced, and this will reduce the overall running cost.
ASSEMBLING AND PREPARING
Unpacking
Check your product box for the following items. If there are any missing accessories, contact the local
dealer where you purchased your product. The illustrations in this manual may differ from the actual
product and item.
CAUTION
yDo not use any unapproved items to ensure the safety and product life span.
yAny damage or injuries caused by using unapproved items are not covered by the warranty.
ySome models have a thin film attached on to the screen and this must not be removed.
NOTE
yThe items supplied with your product may vary depending on the model.
yProduct specifications or contents of this manual may be changed without prior notice due to
upgrade of product functions.
yFor an optimal connection, HDMI cables and USB devices should have bezels less than 10 mm
thick and 18 mm width. Use an extension cable that supports USB 2.0 if the USB cable or USB
memory stick does not fit into your monitor’s USB port.
A
B
A
B
*A
<
=
10 mm
*B
<
=
18 mm

10
ENGLISH
ASSEMBLING AND PREPARING
FREEZE
RATIO
L/RSELECT
ENTER
BACK EXIT
Q.MENU
INFO
MENU
CHVOL
P
A
G
E
FAV
3D
MUTE
1 2 3
4 5 6
7 8
0
9
MARK
LIST
FLASHBK
ENERGY
SAVING
TV
AVMODE INPUT
Remote Control, Batteries
(AAA)
Owner’s Manual Cable Managements
2EA
Stand Bases Power Cord Stand Screws
4EA, M4 x L14
Wall Mount Spacers
2EA

11
ENGLISH
ASSEMBLING AND PREPARING
Separate purchase
Separate purchase items can be changed or modied for quality improvement without any notication.
Contact your dealer to buy these items.
These devices only work with certain models.
The model name or design may be changed depending on the upgrade of product functions,
manufacturer’s circumstances or policies.
AN-MR500
Magic Remote
AN-WF500
Wi-Fi/Bluetooth Dongle
AN-VC5**
Video Call Camera
LG Audio Device
* You can use the Magic Remote and LG Audio Device(Wireless) only when you are using the Wi-Fi/
Bluetooth Dongle.

12
ENGLISH
ASSEMBLING AND PREPARING
Parts and buttons
Remote control and
Intelligent1sensors
Power Indicator
Screen
Joystick Button2
Speakers
1 Intelligent sensor - Adjusts the image quality and brightness based on the surrounding environment.
2 Joystick Button - This button is located below the monitor screen.
NOTE
yYou can set the power indicator light to on or off by selecting OPTION in the main menus.

13
ENGLISH
ASSEMBLING AND PREPARING
Using the Joystick button
You can simply operate the monitor functions, pressing or moving the joystick button left or right.
Basic Functions
Power On When the monitor is turned off, place your finger on the joystick
button and press it once and release it.
Power Off
When the monitor is turned on, place your finger on the joystick
button and press it once for a few seconds and release it.
(However, if the Menu button is on the screen, pressing and
holding the joystick button will let you exit the Menu.)
Volume
Control
If you place your finger over the joystick button and move it left or
right, you can adjust the volume level you want.
NOTE
yWhen your finger over the joystick button and push it to the up, down, left or right, be careful not
to press the joystick button. If you press the joystick button first, you may not be able to adjust the
volume level.
Adjusting the Menu
When the monitor is turned on, press the joystick button one time.
You can adjust the Menu items( , , , ) moving the joystick button up, down, left or right.
Monitor off Turns the power off.
Settings Accesses the main menu.
Close Clears on-screen displays and returns to monitor viewing.
Input List Changes the input source.

14
ENGLISH
ASSEMBLING AND PREPARING
Lifting and moving the
Monitor
Please note the following advice to prevent the
monitor from being scratched or damaged and for
safe transportation regardless of its type and size.
CAUTION
yAvoid touching the screen at all times, as
this may result in damage to the screen.
yIt is recommended to move the monitor in
the box or packing material that the monitor
originally came in.
yBefore moving or lifting the monitor,
disconnect the power cord and all cables.
yWhen holding the monitor, the screen should
face away from you to avoid damage.
yHold the top and bottom of the monitor frame
rmly. Make sure not to hold the transparent
part, speaker, or speaker grill area.
yWhen transporting a large monitor, there
should be at least 2 people.
yWhen transporting the monitor by hand,
hold the monitor as shown in the following
illustration.
yWhen transporting the monitor, do not expose
the monitor to jolts or excessive vibration.
yWhen transporting the monitor, keep the
monitor upright, never turn the monitor on its
side or tilt towards the left or right.
yDo not apply excessive pressure to cause
exing /bending of frame chassis as it may
damage screen.
yWhen handling the monitor, be careful not to
damage the protruding joystick button.
