LG M3201T-BA User manual

w w w. LG c o m m e r c i a l . c o m
3M DST INTEGRATED TOUCH
With fast, accurate touch response
NATIVE DISPLA RESOLUTION
1366 x 768 WXGA
LG'S EXCLUSIVE XD ENGINE®
CONTRAST RATIO
1600:1
178 DEGREE VIEWING ANGLE (S-IPS)
Super IPS technology allows for distortion-
free viewing from almost any angle
HIGH BRIGHTNESS
500 cd/m2
8MS RESPONSE TIME
TEMPERATURE AND LAMP FAULT SENSOR
HDMI™/DVI WITH HDCP
3- EAR LIMITED WARRANT
(parts/labor)
Widescreen HD MonitorTouch Screen LCD
M3201T-BA
32" class (31.5" diagonal)
lcd
monitor
B R O U G H T TO Y O U BY
w w w. k r i s t e l . c o m

INPUTS AND OUTPUTS
15 Pin D-Sub RGB In/RGB Out
HDMI (digital) with HDCP 1 In/DVI (through HDMI to DVI adapter-not included)
S-Video 1 In
Component 2 Component In (1080i) BNC with audio
Composite 1 in/1 out (BNC) with audio
PC Audio Input Yes
RS-232C RS-232C In / RS-232C Out
Remote Control Input Yes / IR ack
CONT OL
Key Number 8
Key Location Right Bottom
Key Type Tact Switch
LED color Amber-off/Green-on
OSD Language English, French, German, Italian, Spanish,
Portuguese, Korean
POWE
Power Supply Internal
Rated Voltage AC 100 - 240V ~50/60Hz 1.5A
On Mode 145W
DPM Off 1W
Off Mode 1W
Sleep Mode <_1W (RGB) / 4W (HDMI/DVI)
ENVI ONMENTAL CONDITIONS
Operational Condition Temperature Temperature: 50°F
~
95°F, 10°C
~
35°C ,
Humidity: 10% ~ 80%
Storage Condition Temperature: -4°F ~140°F, -20°C ~60°C ,
Humidity: 5% ~95%
CABINET
Color Black
Monitor Dimensions (WxHxD) 31.62” x 19.41” x 3.94”
Weight 46.52 lbs
Carton Dimensions (WxHxD) 36.11” x 27.72” x 13.07”
Packed Weight 52.91 lbs
Kensington Lock Yes
AUDIO FEATU ES
Max Audio output 20Watt (10W x 2EA)
Audio Built-in AMP, Equalizer, Auto Volume Limiter,
Balance, Speaker on/off
SSM Surround Max, Flat, Music, Movie, Sports, User
SPECIAL FEATU ES
XD Engine Yes
XD Demo Yes (not available in RBG PC/HDMI/DVI PC Mode)
Pb Free Yes
DDC/CI Yes
Intelligent Auto (Auto Resolution) Yes
Temperature Sensor Yes
Lamp Fault Sensor Yes
LG Logo Light Off / On selectable
ISM Method Normal, Orbiter, Inversion, White Wash
PSM Dynamic, Standard, Mild, User 1, 2
CSM Warm, Normal, Cool, User
CE TIFICATIONS
UL (cUL) Yes
TUV-GS Yes
SEMKO Yes
FCC-B, CE Yes
VESA™ Mounting Yes (200mm x 200mm)
CB scheme Yes
VCCI Yes
GOST Yes
MIC Yes
RoHS compliant Yes
ACCESSO IES
Remote Control/AAABatteries (2)
User's Guide/Driver CD-Rom/Warranty Card
15-pin D-Sub Signal Cable
Power Cable
Audio Cable (PC)
RCA-PC Audio Cable
110/220V AC Universal Power Supply
USB Cable
OPTIONAL ACCESSO IES (O DE TH OUGH LG)
Speakers (SP3200K) Black
Speaker Dimensions (WxHxD) 4.09” x 19.41” x 2.48”
Weight 1.70 lbs
Stand (ST3200K) Black/Silver
Stand Dimensions (WxHxD) 22.89” x 4.00” x 6.75”
Weight 5.02 lbs
LIMITED WA ANTY 3 years (parts/labor)
LCD PANEL
LCD Panel Type 32” Widescreen TFT (Thin Film Transistor) -
LCD (Liquid Crystal Display) Panel
Display Area 31.5” diagonal
Touch Screen 3M DST Integrated Touch
Panel Type (TN,IPS) S-IPS
Aspect Ratio 16:9
Native Resolution 1366 x 768
Brightness 500 cd/m
2
Contrast Ratio 1600:1
Response Time 8 ms
Viewing Angle 178 / 178
MTBF 50,000 Hrs
Color Depth 16.7 Million (8bits)
Pixel Pitch 0.510 x 0.510
Lamp Quantity 20 EEFL
Surface Treatment AG (3H)
VIDEO
Max Input Resolution 768p
H-Scanning Frequency RGB : 30 - 83 kHz; HDMI/DVI : 30 - 72 kHz
V-Scanning Frequency 56 - 85 Hz
Synchronization Type Separate/Composite/SOG (Sync On Green)/Digital
specifications
37.95”
31.62”
27.66”
22.29”
19.41”
21.26”
3.15”
2.05”
1.94”
LG
200mm
200mm
3.94”
7 09”
ear Jack Pack Panel
DST
M3201T-BA 32" class (31.5" diagonal)
lcd
monitor
TO O DE M3201T-BA, CONTACT YOU K ISTEL DISPLAYS EP ESENTATIVE AT 1.630.443.1290 EXT. 103
Kristel Displays 555 South Kirk Road, St. Charles, IL 60174. Contact information: Phone: [phone] EXT. 103, Fax: [phone]. For more information visit
www.kristel.com
TO O DE OPTIONAL ACCESSO IES, CONTACT YOU LG EGIONAL SALES MANAGE TOLL-F EE AT 1.800.897.8788
LG Electronics USA, Inc. Commercial Products Division 2000 Millbrook Drive, Lincolnshire, IL 60069. Contact Information: Phone for B2B channel: 1.800.897.8788.
For more information visit www.LGcommercial.com
© Copyright 2008 LG Electronics USA, Inc. All Rights Reserved. LG Life’s Good is a registered trademark of LG Corp.
Screen image is simulated. Dimensions and weights are approximate. Design, features and specifications subject to change without notice. VESA is a registered trademark
of Video Electronics Association. All other corporate and brand names are trademarks of their respective owners. HDTV monitors require optional set-top box to receive
high-definition broadcast.
Printed in the USA. une 2008 SPEC_M3201T_LGE060805_PR
Note: Speakers and stand are optional accessories
