PLASMA MONITOR

SERVICE MANUAL

CAUTION

BEFORE SERVICING THE CHASSIS,

READ THE SAFETY PRECAUTIONS IN THIS MANUAL.

CHASSIS : NP-00LG

MODEL : MP-42PZ12

website:http://biz.LGservice.com

e-mail:http://www.LGEservice.com/techsup.html

- 2 -

CONTENTS

SAFETY PRECAUTIONS ...................................................................................3

ADJUSTMENT INSTRUCTIONS ........................................................................4

BLOCK DIAGRAM...............................................................................................7

EXPLODED VIEW..............................................................................................12

EXPLODED VIEW PARTS LIST........................................................................13

REPLACEMENT PARTS LIST...........................................................................14

SCHEMATIC DIAGRAM ........................................................................................

PRINTED CIRCUIT BOARD ..................................................................................

- 3 -

SAFETY PRECAUTIONS

Many electrical and mechanical parts in this chassis have special safety-related characteristics. These parts are identified by in

the Schematic Diagram and Replacement Parts List.

It is essential that these special safety parts should be replaced with the same components as recommended in this manual to

prevent X-RADIATION, Shock, Fire, or other Hazards.

Do not modify the original design without permission of manufacturer.

General Guidance

An lsolation Transformer should always be used during

the servicing of a receiver whose chassis is not isolated from

the AC power line. Use a transformer of adequate power rating

as this protects the technician from accidents resulting in

personal injury from electrical shocks.

It will also protect the receiver and it's components from being

damaged by accidental shorts of the circuitary that may be

inadvertently introduced during the service operation.

If any fuse (or Fusible Resistor) in this monitor is blown, replace

it with the specified.

When replacing a high wattage resistor (Oxide Metal Film

Resistor, over 1W), keep the resistor 10mm away from PCB.

Keep wires away from high voltage or high temperature parts.

Due to high vacuum and large surface area of picture tube,

extreme care should be used in handling the Picture Tube.

Do not lift the Picture tube by it's Neck.

Leakage Current Cold Check(Antenna Cold Check)

With the instrument AC plug removed from AC source,

connect an electrical jumper across the two AC plug prongs.

Place the AC switch in the on positioin, connect one lead of

ohm-meter to the AC plug prongs tied together and touch other

ohm-meter lead in turn to each exposed metallic parts such as

antenna terminals, phone jacks, etc.

If the exposed metallic part has a return path to the chassis, the

measured resistance should be between 1MΩ and 5.2MΩ.

When the exposed metal has no return path to the chassis the

reading must be infinite.

An other abnormality exists that must be corrected before the

receiver is returned to the customer.

Leakage Current Hot Check (See below Figure)

Plug the AC cord directly into the AC outlet.

Do not use a line Isolation Transformer during this check.

Connect 1.5K/10watt resistor in parallel with a 0.15uF capacitor

between a known good earth ground (Water Pipe, Conduit, etc.)

and the exposed metallic parts.

Measure the AC voltage across the resistor using AC

voltmeter with 1000 ohms/volt or more sensitivity.

Reverse plug the AC cord into the AC outlet and repeat AC

voltage measurements for each esposed metallic part. Any

voltage measured must not exceed 0.75 volt RMS which is

corresponds to 0.5mA.

In case any measurement is out of the limits sepcified, there is

possibility of shock hazard and the set must be checked and

repaired before it is returned to the customer.

Leakage Current Hot Check circuit

1.5 Kohm/10W

To Instrument's

exposed

METALLIC PARTS

Good Earth Ground

such as WATER PIPE,

CONDUIT etc.

AC Volt-meter

IMPORTANT SAFETY NOTICE

0.15uF

- 4 -

1. Application Object

These instructions are applied to all of the PDP monitor, NP-

00LG.

2. Notes

(1) Because this is not a hot chassis, it is not necessary to use

an isolation transformer. However, the use of isolation

transformer will help protect test instrument.

(2) Adjustment must be done in the correct order.

(3) The adjustment must be performed in the circumstance of

25±5°C of temperature and 65±10% of relative humidity if

there is no specific designation.

(4) The input voltage of the receiver must keep 110~240V,

50/60Hz in adjusting.

(5) The receiver must be operated for about 15 minutes prior

to the adjustment.

¤After receiving 100% white pattern(06CH), the receiver

must be operate prior to adjustment.(Or white condition

in HEAT-RUN mode)

¤ŁEnter into HEAT-RUN mode

- Select the HEAT-RUN OFF by pressing ADJ button on

Remote Control for adjustment.

- Press the VOL + button in HEAT-RUN OFF.

(OSD display HEAT-RUN WHITE and screen display

100% full WHITE PATTERN)

¤ØSet is activated HEAT-RUN without signal generator in

this mode.

[Single color pattern of HEAT-RUN mode uses to check

PANEL.(RED/BLUE/GREEN)

[Caution] If you turn on a still screen more than 20 minutes, a

afterimage may be occur in the black level part of the

screen.

3. POWER PCB Assy Voltage Adjustment

[Replace PDP Module or Power Board, adjust certainly Power

PCB Assy Voltage.

3-1. Test Equipment

D.M.M 1EA

3-2. Connection Diagram for Measuring

Refer to Fig 1.

3-3. Adjustment Method

(1) Va Adjusment

¤Connect pin 1 of CN807(or CN804) to (+) jack of D.M.M.

¤ŁAfter turning the VR8105, voltage of D.M.M adjustment

as same as Va voltage which on label of panel

right/top.(Deviation : ±0.5V)

(2) Vs Adjustment

¤Connect pin 1 of CN811 to (+) jack of D.M.M.

¤ŁAfter turning the VR8102(Vs CTL), voltage of D.M.M

adjust as same as Vs voltage which indicated on label

of panel right/top.(Deviation : ±0.5V)

(3) V-y Adjustment

¤Connect pin 1 of CN809 to (+) jack of D.M.M.

¤ŁAfter turning the VR8103(V-y CTL), voltage of D.M.M

adjust as same as V-y voltage which indicated on label

of panel right/top.(Deviation : ±0.5V)

(4) Vsetup Adjustment

¤Connect pin 5 of CN809 to (+) jack of D.M.M.

¤ŁAfter turning the VR8104(VSETUP CTL), voltage of

D.M.M adjust as same as Vs voltage which indicated on

label of panel right/top.(Deviation : ±0.5V)

[Refer to Typical Voltage

1. Va : 60 ~ 75V

2. Vs : 170 ~ 185V

3. -Vy : -60 ~ -90V

4. Vsetup : 210 ~ 240V

4. Adjustment of RGB(Red, Green,

Blue) Cut-off and White Balance

4-1. Required Equipment

Color analyzer(CA-100 or same production)

4-2. Connection Diagram of Equipment for

Measuring

ADJUSTMENT INSTRUCTIONS

COLOR

ANALYZER

TYPE; CA-100

Window

CVBS Signal Input

High Light

85±5cd/m2

Low Light

8±3cd/m2 PDP MONITOR

MSPG-2100 or

MSTG-5200

<Fig 2> Connection Diagram of Automatic Adjustment

- 5 -

4-3. Adjustment of RGB Cut-Off

(1) Select RGB cut-off(adjustment 1) by pressing ADJ button

on Remote Control for adjustment. (If it enter to adjustment

mode, it is selected RF 13CH automatically)

(2) Press the VOL + or VOL - button.

(3) It displayed all of the black on the screen and then

adjustment is started.

(4) If adjustment is finished, exit from adjustment mode by

pressing enter button.

4-4. Adjustment of White Balance

• White Balance should be done after RGB cut-off become

adjustment.

• Operate the Zero-calibration of the CA—100, then stick

sensor to PDP module surface when you adjust.

(1) Select WHITE PATTERN of HEAT RUN mode by pressing

ADJ button on Remote Control for adjustment then operate

HEAT RUN more than 15 minute.

(2) Supply 10 step gray scale bar signal or window pattern in

pattern generater. (When using the STB, input RF 13CH, it

does not use, input AV.)

[When adjustment is operated manually, perate process (3)

to (6) regular sequence, when adjustment is operated

automatically perate process (1) to (2).

(3) To adjust Low Light, stick sensor to 9th pattern(Dark),

select the R cut(adjustment 8)/B cut(adjustment 10) by

pressing ADJ button on Remote Control for adjustment

and adjust it until color coordination becomes

X=0.270±0.003, Y=0.280±0.003 and color temperature

becomes 10.000cK ± 500cK by pressing VOL+, - button.

(G-cut fixation)

(4) To adjust High Light, stick sensor to 2th pattern(White).

Select the R Gain(adjustment 5)/G Gain(adjustment 6) by

pressing ADJ button on Remote Control for adjustment

and adjust R Gain/G Gain until color coordination becomes

X=0.270±0.003, Y=0.280±0.003 and color temperature

becomes 10.000cK ± 500cK.(B-Gain fixation)

(5) Confirm the result of the High Light adjustment.

If the deviation of High Light occur, operate the adjustment

of Low Light and High Light again.

(6) Exit adjustment mode using Enter button.

5. Color Temperature of STB

White Balance Adjustment

5-1. Required Equipment

Color Analyzer(CA-110, CA-100 or same production)

5-2. Connection diagram of equipment for

measuring

(1) To adjust the deviation of the STB signal output.

(2) Use regular PDP Monitor(JIG).

5-3. Adjustment Method

• Connect the STB to regular PDP Monitor.

• Operate the zero-calibration of the CA-100, then stick

sensor to surface of PDP module when you adjust.

(1) Select ITE PATTERN of HEAT RUN mode by pressing

ADJ button on Remote Control for adjustment, then

operate HEAT RUN more than 15 minute.

(Operate the HEAT RUN to adjust the STB at first, then if

OFF hour don’t keep more than 3 minutes, operate next

adjustment of the STB without HEAT RUN.)

(2) Supply 10 step gray scale bar signal or window pattern in

pattern generator(RF 13CH or AV1)

[When adjustment is operated manually, perate process (3)

to (7) regular sequence, when adjustment is operated

automatically perate process (1) to (2).

CVBS Signal Input

CVBS

Signal Input

Adjustment Adjustment

<Fig 3> Connection Diagram of Manual Adjustment

COLOR

ANALYZER

TYPE; CA-100

CVBS Signal Input

PDP MONITOR

SETTOP BOX

Window Pattern

MSPG-2100 or MSTG-5200

High Light

120±4cd/m2

Low Light

6±1cd/m2

<Fig 4> Connection Diagram of STB Automatic Adjustment

Signal Input

Adjustment Adjustment

<Fig 5> Connection Diagram of STB Manual Adjustment

(3) Select CXA2101 ADJ STB(CH+/- button) by pressing

INSTART button on Remote Control for adjustment.

Select adjustment mode with VOL+ or VOL-.(Adjustment

0~4)

(4) To adjust Low Light, stick sensor to 9th pattern(Dark).

Select the B Cut(adjustment 0)/R Cut(adjustment 1), then

adjust the B Cut/R Cut until color coordination becomes

X=0.280±0.003, Y=0.310±0.003 and color temperature

becomes 8.800cK ± 500cK by pressing VOL+, - button.

(5) To adjust High Light, stick sensor to 2th pattern(White).

Select the R Gain(adjustment 2)/G Gain(adjustment 3),

then adjust the R Gain/G Gain until color coordination

becomes X=0.280±0.003, Y=0.310±0.003 and color

temperature becomes 8.800cK ±500cK. (B-Gain fixation)

(6) Confirm the result of the High Light adjustment.

If the deviation of High Light occur, operate the adjustment

of Low Light and High Light again.

(7) Exit adjustment mode using Enter button.

- 6 -

- Vy

Vsetup

Vs

Va

Vsetup ADJ

VR8104

Va ADJ

VR8105

Vs ADJ

VR8102

- Vy ADJ

VR8103

<Fig 1> Connection Diagram of POWERWEL Power Adj. for Measuring

- 7 -

BLOCK DIAGRAM

1. VSC Board

P101

V/R/L

P102

DVD

DS102

DS101

IC203

VPC3230

Decoder

80Pin

IC203

VPC3230

Decoder

80Pin

3

Y,Cb,Cr

CVBS

C236

C209

C210

C211

(A)

1IC204

SDA9410

Deinterlace

D/A

100Pin

IC204

SDA9410

Deinterlace&

D/A

100Pin

8 LU0-7

C646

C650

C645

C651

8CHR0-7

IC303

CXA2101AQ

Video&

80Pin

IC303

CXA2101AQ

Video &Chroma

80Pin

STB-R/G/B/HS/VS( : C323~319A)

5

PC-R/G/B/HS/VS ( : C317~319A)

5

DTV-Y/Pb/Pr ( : C382~384

R220

A)

3

IC304

THS8083

100Pin

IC304

THS8083

100Pin

3 CXA-R (A )

IC401

MX88L284

3X2M

Scan converter

208Pin

IC401

MX88L284

3X2M

Scan converter

208Pin

Vout

(R/G/B)(D)

(D)

3X8

IC501

74F541

IC502

74F541

IC503

74F541

IC504

74F541

8

DOR0-7

8

DOG0-7

8

DOB0-7

PVS/PHS_OUT

2

PAR0-7

8

PAG0-7

8

PAB0-7

8

PD501

(41Pin)

D-sub

25

D-sub

15

IC604

LA7222M

(Audio S/W)

(A)

P601

L/R

STB/PC

AV/DVD/DTV IC602

CXA2022S

(Tone Control)

IC602

CXA2022S

(Tone Control)

IC603

TDA2616

Audio Amp.

(12Wx2)

IC603

LA4282 Pin7

Pin11

C619

C610 Audio Amp.

(12Wx2)

Lout

Rout

P007A

(Spk. Jack)

IC001

M37270

EEPROM

Micro-Co

IC001

M37270

EEPROM

Micro-Com

I2CBus

TV-Y/U/ V/HVs

(A)4

57

26 353739

27

56

Hs:R208

Vs

Hs

Vs

H:R212

V:R213

H:R301

V:R302

Y:C305

G

B

R G B

H:R319

V:R318

R:C362

G:C366

B:C370(Bottom)

H:R345

V:R344

IC405

PLL-H:R355

6

THS-CLP

H

V203

100

204

BA407

Vs Hs

HV

13

15

BA408

IC407

OSD IC

OSD-R/G/B/YS

Bottom

- 8 -

2. VSC Signal Flow(R/G/B-H/V)

P101

V/R/L

P102

DVD

DS102

DS101

IC203

VPC3230

Decoder

80Pin

IC203

VPC3230

Decoder

80Pin

3

Y,Cb,Cr

CVBS

C236

C209

C210

C211

(A)

1IC204

SDA9410

Deinterlace

D/A

100Pin

IC204

SDA9410

Deinterlace&

D/A

100Pin

8 LU0-7

C646

C650

C645

C651

8CHR0-7

IC303

CXA2101AQ

Video&

80Pin

IC303

CXA2101AQ

Video &Chroma

80Pin

STB-R/G/B/HS/VS( : C323~319A)

5

PC-R/G/B/HS/VS ( : C317~319A)

5

DTV-Y/Pb/Pr ( : C382~384

R220

A)

3

IC304

THS8083

100Pin

IC304

THS8083

100Pin

3 CXA-R (A )

IC401

MX88L284

3X2M

Scan converter

208Pin

IC401

MX88L284

3X2M

Scan converter

208Pin

Vout

(R/G/B)(D)

(D)

3X8

IC501

74F541

IC502

74F541

IC503

74F541

IC504

74F541

8

DOR0-7

8

DOG0-7

8

DOB0-7

PVS/PHS_OUT

2

PAR0-7

8

PAG0-7

8

PAB0-7

8

PD501

(41Pin)

D-sub

25

D-sub

15

IC604

LA7222M

(Audio S/W)

(A)

P601

L/R

STB/PC

AV/DVD/DTV IC602

CXA2022S

(Tone Control)

IC602

CXA2022S

(Tone Control)

IC603

TDA2616

Audio Amp.

(12Wx2)

IC603

LA4282 Pin7

Pin11

C619

C610 Audio Amp.

(12Wx2)

Lout

Rout

P007A

(Spk. Jack)

IC001

M37270

EEPROM

Micro-Co

IC001

M37270

EEPROM

Micro-Com

I2CBus

TV-Y/U/ V/HVs

(A)4

57

26 353739

27

56

Hs:R208

Vs

Hs

Vs

H:R212

V:R213

H:R301

V:R302

Y:C305

G

B

R G B

H:R319

V:R318

R:C362

G:C366

B:C370(Bottom)

H:R345

V:R344

IC405

PLL-H:R355

6

THS-CLP

H

V203

100

204

BA407

Vs Hs

HV

13

15

BA408

IC407

OSD IC

OSD-R/G/B/YS

Bottom

- 9 -

3. STB Main

Single chip multi-standard

sound processors

MONO/STEREO/Bilingual

A/V 1

SVHS

A/V 2

MNT

OUT

DTV2

in

IC 201

CXA2069Q

64pin

IC 201

CXA2069Q

64pin

3 (VRL)

2(Y/C)

3

MNT-L/R/V

TUNER

IC 601

MSP3401

80pin

IC 601

MSP3401

80pin

DCF(3D)

(Digital Comb Filter)

TV Signal

(CVBS)

2

TV-L/R

2

AV-L/R

2

DCF-C/Y

1DCF-VIN IC 301

VPC3230

80pin

IC 301

VPC3230

80pin

IC 701

LGTV1001

64pin

IC 701

LGTV1001

64pin

IC 302

SDA9410

100pin

IC 302

SDA9410

100pin

IC 001

M37272

u-COM

IC 001

M37272

u-COM

KEY-1

DVD

in

3

Y/U/V

IC 401

CXA2101AQ

80pin

IC 401

CXA2101AQ

80pin

IC 402

BA7657

24pin

IC 402

BA7657

24pin

P003

3OSD R/G/B/YS

3 SCL_A, SDA_B

PC/DTV

1 S-MUTE

3

W/F-OUT(OPT)

OUT-L

OUT-R

3

KIN

KOUT 3

5

SDA-HS/VS/U/V/Y

3

SDA Y/V/U

2

SDA-

HS/VS

8

CHROMA0-7

8

LUMA0-7 8 C0-7

8

Y0-7

2

SCL-A

SDL-A

3

CXA R/G/B

2

CXA HS/VS

1

CXA-PC 5

R/G/B/HS/VS

P401

P402

P403

PC

R/G/B

HS/VS

DTV

R/G/B

HS/VS

PC

DTV

PC-R/L

ICX 001

BA7657F

ICX 001

BA7657F

DTV 1

IN

PC IN PC

RGB/HV

PC/DTV-OUT

5

DTV-R/G/B

HS/VS 3PC-R/G/B

2

PC-HS/VS IS 501

(25Pin

Cable)

Input select switch for high

definition display

Internal broadband RGB s/w

2

Y/C

3

(DTV 2)Y/U/V

PDPMODULE

Interface Board

TV Audio(SIF)

(VRL)

(Y,Cb,Cr)

(R,L)

IC 602/3/4

SRS block

(option)

IC 602/3/4

SRS block

(option)

7input/3output

widebandvideo Amp(20MHz,-3dB)

Y/C mix circuit

A/V switch featuring I2

C BUS

DTV2

(R,L)

(Y,Pb,Pr)

SCL-A

SDL-A

2

CXA2069Q

(pin 23/25)

R/L

PC Audio(Stereo)

DTV

RGB/HV

(R,L)

Comb filter video processor

TV Digital Y/Cr/Cb

Multi-standard color decoder

A/D converter

8bit UVin 8bitUVout

8bit Yin 8bitYout


Format converter

Interlace

Progressive

Multi-Component Processor

Analog R/G/B

R/G/B

Y/U/V

- 10 -

4. STB Signal Flow(R/G/B-H/V)

IC 201

CXA2069Q

64pin

IC 201

CXA2069Q

64pin

3

MNT-L/R/V

TUNER

IC 601

MSP3401

80pin

IC 601

MSP3401

80pin

DCF(3D)

(Digital CombFilter)

DCF(3D)

(Digital CombFilter)

2

TV-L/R

2

AV-L/R

IC301

VPC3230

80pin

IC301

VPC3230

80pin

IC 701

LGTV1001

64pin

IC 701

LGTV1001

64pin

IC302

SDA9410

100pin

IC302

SDA9410

100pin

IC 001

M37272

u-COM

IC 001

M37272

u-COM

KEY-1

IC 401

CXA2101AQ

80pin

IC 401

CXA2101AQ

80pin

IC 402

BA7657

24pin

IC 402

BA7657

24pin

P003

OSD R/G/B/

3 SCL_A, SDA_B

PC/DTV

1 S-MUTE

3

W/F-OUT

OUT-L

OUT-R

3

KIN

KOUT 3

5

SDA-Hs/Vs/V/U/Y

8

CHROMA0-7

8

LUMA0-7 8 C0-7

8

Y0-7

2

SCL-A

SDL-A

3

CXA R/G/B

P401

P402

P403

PC

R/G/B

HS/VS

DTV

R/G/B

HS/VS

PC

DTV

PC-R/L

ICX 001

BA7657F

ICX 001

BA7657F

DTV 1

IN

PC IN PC

RGB/HV

PC/DTV-OUT

5

DTV-R/G/B

HS/VS

IS 501

(25Pin

Cable)

PDPMODULE

Interface Board

IC 602/3/4

SRS block

(option)

IC 602/3/4

SRS block

(option)

DTV2

(R,L)

SCL-A

SDL-A

2

CXA2069Q

(pin 23/25)

R/L

PC Audio(Stereo)

DTV

RGB/HV

4

5SCL:R101

SDA:R102

4Video:R108

C225

C-out: R228 Y-out: R225

1

10

3

5

9

Vin:C231

Cout:R241

Yout:R237

SDA:R242

SCL:R243

72

63 58 56

71

Yin:C329

Cin:C328

1 2 3 1314

SCL:R304

SDA:R305

57

Vs:R308

2325 27

SDA:R704

SCL:R705

Ho:R706

4

5

Ho:R321

Vo:R322

24252627

SDA:R323

SCL:R324

Vi:R321

Hi:R322

84

90

V:R417

U:R418

C407/408/409/410/411

28 29 35 37 39

R:R431

G:R432

B:R433

IC501

OPA3682

16pin

IC501

OPA3682

16pin

1

3

5

12 14

15

19

21

22

24

C460/461/462

Vs-in

Hs-in

R:L452

G:L453

B:L454

Hs-out

Vs-out

25

8

R:C501

G:C502

B:C503

1412

10

R:C513

G:C514

B:C515

MEMO

- 11 -

- 12 -

EXPLODED VIEW

301

303

302

200

203

201

202

205 211

204

207

208

209

206

400

540

401

550

551

530520

560

570

300

212

305

- 13 -

EXPLODED VIEW PARTS LIST

200 6348Q-E032D PDP,42” 16:9 852*480 FOR DND INTER

201 6871QTH023A PCB ASSEMBLY,ZCNT ASSY HAND INSERT 42SD3 Z_

202 6871QZH020A PCB ASSEMBLY,ZSUS ASSY HAND INSERT 42SD3 Z_

203 6871QTH024A PCB ASSEMBLY,ZCNT ASSY HAND INSERT 42SD3 Z_

204 6871QRH013A PCB ASSEMBLY,XRRT ASSY HAND INSERT 42SD3 4L

205 6871QLH015A PCB ASSEMBLY,XRLT ASSY HAND INSERT 42SD3 4L

206 6871QYH018A PCB ASSEMBLY,YSUS ASSY HAND INSERT 42SD3

207 6871QDP026A PCB ASSEMBLY,YDRV ASSY SMD TOP INSERT BTM 4

208 6871QDP025A PCB ASSEMBLY,YDRV ASSY SMD TOP INSERT TOP 4

209 6871QCH013A PCB ASSEMBLY,CTRL ASSY HAND INSERT 42SD3 1C

211 4980V00240A SUPPORTER,VERTICAL EGI

212 4980V00240B SUPPORTER,VERTICAL EGI

300 3091V00333B CABINET ASSY

301 4980V00266A SUPPORTER ASSY,FILTER TOP AL

302 4980V00267A SUPPORTER ASSY,FILTER BOTTOM AL

303 4980V00268A SUPPORTER ASSY,FILTER SIDE AL

305 3790V00279A WINDOW,GLASS MITSUI

400 3809V00279C BACK COVER ASSEMBLY

401 3300V00096A PLATE,A/V

520 6871VMM838A PCB ASSEMBLY,MAIN NP-00LG 42 VSC MAIN

530 3501V00076A BOARD ASSEMBLY,PDP POWER LINE-FILTER

540 6871VSM717A PCB ASSEMBLY,CTL MP-00MA FD-36X33 LOCAL KEY

550 6871VSM911B PCB ASSEMBLY,SUB MP-00MC POWER S/W

551 5020V00457A BUTTON,KEY

560 6871VSMA69A PCB ASSEMBLY,SPK NP-00LE

570 3501V00077B BOARD ASSEMBLY,POWER BOARD

No. Part No. Description

REPLACEMENT PARTS LIST

LOCA. NO PART NO DESCRIPTION

Q106

Q107

Q108

Q109

Q110

Q111

Q112

Q201

Q202

Q301

Q302

Q303

Q305

Q306

Q307

Q601

D001

D002

D003

D004

D005

D006

D009

D010

D011

D012

D013

D014

D101

D102

D103

D104

D105

D106

D107

D108

D201

D202

D203

D301

D302

D401

D402

D601

D602

D603

D604

0TR387500AA

0TR150400BA

0TR102009AG

0TR150400BA

0DD226239AA

0DD184009AA

0DD226239AA

0DD184009AA

0DD181009AB

CHIP 2SC3875S(ALY) KEC

CHIP 2SA1504S(ASY) KEC

CHIP KRC102S SOT-23 TP KEC

CHIP 2SA1504S(ASY) KEC

CHIP KDS226 SOT-23

KDS184S CHIP 85V 300MA KEC TP

CHIP KDS226 SOT-23

KDS184S CHIP 85V 300MA KEC TP

KDS181 TP KEC - 85V - - - 300M

LOCA. NO PART NO DESCRIPTION

IC001

IC002

IC003

IC004

IC101

IC102

IC103

IC201

IC202

IC203

IC204

IC205

IC301

IC302

IC303

IC304

IC401

IC402

IC403

IC404

IC405

IC406

IC407

IC501

IC502

IC503

IC504

IC601

IC602

IC603

IC604

IC804

IC005

IC006

Q001

Q002

Q020

Q021

Q022

Q101

Q102

Q103

Q104

Q105

0IZZVA0038A

0IAL240800A

0IFA753307A

0IFA754207A

0IPH827150A

0IFA754207A

0ISH323422A

0IIT323000D

0ISM941000A

0ISH323422A

0ISH092100B

0ISH323422A

0ISO210100B

0ITI808300B

0IMR882840B

0IEB121616A

0ISH323422A

0IPH748600D

0ISH323422A

0ICTMMO004A

0IPRPFA003A

0ISH092100B

0ISO202200A

0ISA428200A

0ISA722200A

0IKE780500Q

0TR830009BA

0TR319809AA

0TR387500AA

0TR319809AA

0TR387500AA

MITSUBISHI 64 ST M37280 NP00LG

AT24C08 8D EEPROM(8K,IIC)

KA75330ZTA(KA7533ZTA) 3P,TO-92

KA75420ZTA(KA7542ZTA) 3P,TO-92

P82B715T 8SOP R/TP IIC EXTENDE

KA75420ZTA(KA7542ZTA) 3P,TO-92

PQ3RF23 4P(TO-220) 3.3V REGUL

VPC3230D QA B4 80P QFP TRAY SO

SDA9410 100QFP BK SCAN CONVERT

PQ3RF23 4P(TO-220) 3.3V REGUL

PQ09RD21 4SIP ST REGULATOR

PQ3RF23 4P(TO-220) 3.3V REGUL

CXA2101AQ 80P,QFP BK VIDEO SIG

THS8083 100QFP BK ADC IC PD-40

MX88L284-V 208QFP BK SCALE MF0

M12L16161A-7T 50P TSOP ST 16M(

PQ3RF23 4P(TO-220) 3.3V REGUL

74HC86 SOIC-14 TP QUAD 2-INPUT

PQ3RF23 4P(TO-220) 3.3V REGUL

SC786108DWR2 MOTOROLA 16 R/TP

74AC541SCX FAIRCHILD 20P SOIC

PQ09RD21 4SIP ST REGULATOR

CXA2022S 30P SDIP ST TONE CONT

LA4282 12S 2CHX10W AUDIO AMP

LA7222 (1280 AUDIO)

KIA7805API 3P TO-220 ST REGULA

BSS83 TP PHILIPS NON N-CHANNEL

KTC3198 TP KEC - - -Y (KTC1815

CHIP 2SC3875S(ALY) KEC

KTC3198 TP KEC - - -Y (KTC1815

CHIP 2SC3875S(ALY) KEC

IC

TRANSISTOR

- 14 -

RUN DATE : 2002.4.9

DIODE

- 15 -

LOCA. NO PART NO DESCRIPTION

LD001

LED001

LED002

LED003

ZD001

ZD101

ZD102

ZD103

ZD104

ZD105

ZD106

ZD201

C001

C002

C003

C008

C011

C016

C022

C026

C031

C038

C041

C050

C051

C105

C107

C109

C111

C112

C115

C118

C124

C201

C203

C206

C207

C212

C225

C229

C231

C233

C235

C238

C240

C241

C242

C243

C244

C245

0DL200000CA

0DL233309AC

0DZRM00178A

0CN1040K949

0CE476DD618

0CE477BF618

0CE108DF618

0CE107DD618

0CE105CK636

0CE105DK618

0CE107DD618

0CE476SF6DC

0CE476DF618

0CE476SF6DC

0CQ3331N509

0CE107DD618

0CK224DF56A

0CE107DD618

0CE476DF618

0CE107DD618

0CE476DF618

0CE107DD618

LED,SAM5670(DL-2LRG) BK Y-GREEN -

LED,SAM2333 TP KWANG GREEN/RED GRE

ZENERS,UDZS TE-17 5.1B

0.1M 50V Z

47UF STD 10V 20%

470UF KME 16V M

1000UF STD 16V M

100UF STD 10V M

1UF SHL,SD 50V M

1UF STD 50V M

100UF STD 10V M

47UF MVG 16V M

47UF STD 16V M

47UF MVG 16V M

0.033U 100V K

100UF STD 10V M

220000PF 2012 16V 10%

100UF STD 10V M

47UF STD 16V M

100UF STD 10V M

47UF STD 16V M

100UF STD 10V M

LOCA. NO PART NO DESCRIPTION

C306

C318

C325

C326

C330

C338

C340

C343

C347

C349

C351

C353

C355

C357

C360

C401

C412

C414

C415

C418

C420

C424

C433

C445

C453

C457

C459

C470

C502

C601

C602

C603

C604

C605

C606

C607

C608

C609

C610

C611

C612

C613

C614

C615

C616

C617

C618

C619

C620

C621

C622

C623

0CE476DF618

0CE105DK618

0CE107DF618

0CE477BF618

0CE476DF618

0CE106DF618

0CE476DF618

0CE107DD618

0CE477BF618

0CE106SF6DC

0CE107DD618

0CE476DF618

0CE107DD618

0CE477BF618

0CE107DD618

0CE477BF618

0CE107DD618

0CE106DF618

0CQ1042K439

0CQ4721N509

0CE475DK618

0CE106DF618

0CQ4721N509

0CE106DF618

0CQ1042K439

0CE475DK618

0CQ1042K439

0CQ2231N509

0CQ4721N509

0CQ8221N519

0CE106DF618

0CE475DK618

0CQ8221N519

0CQ1042K439

0CE476DF618

47UF STD 16V M

1UF STD 50V M

100UF STD 16V M

470UF KME 16V M

47UF STD 16V M

10UF STD 16V M

47UF STD 16V M

100UF STD 10V M

470UF KME 16V M

10UF MVG 16V 20%

100UF STD 10V M

47UF STD 16V M

100UF STD 10V M

470UF KME 16V M

100UF STD 10V M

470UF KME 16V M

100UF STD 10V M

10UF STD 16V M

0.1UF S 50V 5%

0.0047U 100V K

4.7UF STD 50V 20%

10UF STD 16V M

0.0047U 100V K

10UF STD 16V M

0.1UF S 50V 5%

4.7UF STD 50V 20%

0.1UF S 50V 5%

0.022U 100V K

0.0047U 100V K

0.0082U 100V K

10UF STD 16V M

4.7UF STD 50V 20%

0.0082U 100V K

0.1UF S 50V 5%

47UF STD 16V M

CAPACITOR

For Capacitor & Resistors,

the charactors at 2nd and 3rd

digit in the P/No. means as

follows;

CC, CX, CK, CN : Ceramic

CQ : Polyestor

CE : Electrolytic

RD : Carbon Film

RS : Metal Oxide Film

RN : Metal Film

RF : Fusible

- 16 -

LOCA. NO PART NO DESCRIPTION

C624

C625

C626

C630

C631

C635

C641

C643

C644

C645

C646

C647

C650

C651

C653

C654

C655

C656

C659

C660

C661

JP1

P101

P102

P601

L001

L003

L115

L214

R001

R002

R003

R006

R007

R225

R226

R618

R619

R655

R656

SW001

SW002

0CQ4721N509

0CQ1042K439

0CE107DF618

0CE108DF618

0CE106DK618

0CE476DF618

0CE106DK618

0CE477DK618

0CE106DF618

0CE476DF618

0CE106DF618

0CE477DK618

0CE107DH618

181-120K

0CE107DH618

181-120K

0CE107DH618

6612VLH002A

380-389N

380-389P

6612VJH018A

0LA0102K119

0LA0221K119

6140VB0006A

0LA0102K119

0RD3302F609

0RD1002F609

0RD3001F609

0RD3300F609

0RN5602F409

0RN2202F409

0RD0331H609

0RD4700H609

140-315A

0.0047U 100V K

0.1UF S 50V 5%

100UF STD 16V M

1000UF STD 16V M

10UF STD 50V M

47UF STD 16V M

10UF STD 50V M

470UF STD 50V 20%

10UF STD 16V M

47UF STD 16V M

10UF STD 16V M

470UF STD 50V 20%

100UF STD 25V M

2200PF 4KV M

100UF STD 25V M

2200PF 4KV M

100UF STD 25V M

JACK,RCA SP026B 4P RD/BK/BK/R

JACK,RCA S-456S-N A/V 3P RD-W

JACK,RCA S-456S-P A/V 3P GR-B

JACK,RCA PJ6058C-A A/V 2P MON

INDUCTOR,10UH K

INDUCTOR,2.2UH K

COIL,CHOKE 12UH 0.3PHY,PHY 15.5TURN

INDUCTOR,10UH K

33K OHM 1/6 W 5.00%

10K OHM 1/6 W 5.00%

3K OHM 1/6 W 5.00%

330 OHM 1/6 W 5.00%

56K OHM 1/6 W 1.00%

22K OHM 1/6 W 1.00%

3.3 OHM 1/2 W 5.00%

470 OHM 1/2 W 5.00%

SWITCH,TACT SKHV17910B NON 12V

LOCA. NO PART NO DESCRIPTION

SW003

SW004

SW800

BA301

BA302

BA303

BA304

BA305

BA306

BA407

BA408

BA409

BA410

BA411

BA412

BA413

BA414

BA415

BA416

BA417

BA418

BA419

BA420

BA421

BA422

BA423

BA424

F601

F602

L001

L002

L104

L105

L106

L107

L108

L201

L202

L203

L204

L205

L206

L207

L208

L209

L210

L211

L213

L301

L302

140-315A

6600VM2006A

6210VC0004A

6200VJS001A

6210VC0006A

6210VC0005A

6210VC0006A

6210VC0005A

6210VC0006A

6210VC0005A

6210VC0006A

SWITCH,TACT SKHV17910B NON 12V

SWITCH,PUSH SDDF3PATP011

FILTER,EMC BK3216 4S600

FILTER,EMC ZJY51R5-4P

FILTER,EMC FBMH3216 HM501NT

FILTER,EMC BK2125 HS 750

FILTER,EMC FBMH3216 HM501NT

FILTER,EMC BK2125 HS 750

FILTER,EMC FBMH3216 HM501NT

FILTER,EMC BK2125 HS 750

FILTER,EMC FBMH3216 HM501NT

JACK

COIL

SWITCH

FILTER & CRYSTAL

For Capacitor & Resistors,

the charactors at 2nd and 3rd

digit in the P/No. means as

follows;

CC, CX, CK, CN : Ceramic

CQ : Polyestor

CE : Electrolytic

RD : Carbon Film

RS : Metal Oxide Film

RN : Metal Film

RF : Fusible

RESISTOR

- 17 -

LOCA. NO PART NO DESCRIPTION

L303

L304

L305

L306

L401

L402

L403

L404

L405

L407

L408

L409

L410

L501

L502

L601

L602

L603

L604

L605

X001

X201

X301

X401

PA001

A1

A2

A3

A4

6210VC0006A

6210VC0005A

6210VC0006A

6210VC0005A

6210VC0006A

150-F09A

6210VC0006A

6200JB8007L

156-A01P

6202VDB007B

6202VDT002B

6726VH0001A

3828VA0296B

6710V00049V

6410VUH005A

6410VEH003B

6866VA9001B

FILTER,EMC FBMH3216 HM501NT

FILTER,EMC BK2125 HS 750

FILTER,EMC FBMH3216 HM501NT

FILTER,EMC BK2125 HS 750

FILTER,EMC FBMH3216 HM501NT

FILTER,EMC SQE2222 7-14MH 0.37PHY 48TURN

FILTER,EMC FBMH3216 HM501NT

FILTER,EMC HH2012 1M221JT

RESONATOR,CRYSTAL HC49U 8.000MHZ 30

RESONATOR,CRYSTAL HC49U 20.250MHZ 3

RESONATOR,CRYSTAL SX-1SMD 14.318MHZ

REMOTE CONTROLLER RECEIVER,38KHZ

MANUAL,OWNERS NP00LG MP-42PZ10/12

REMOTE CONTROLLER,38KEY

POWER CORD,PS204 125V/13A VOLEX UL/CSA 2

POWER CORD,M2511A VOLEX VDE/SEM

CONNECTOR,2990-9C UL 1161 AWG 26 TWI 700

LOCA. NO PART NO DESCRIPTION

MISCELLANEOUS

ACCESSORIES

For Capacitor & Resistors,

the charactors at 2nd and 3rd

digit in the P/No. means as

follows;

CC, CX, CK, CN : Ceramic

CQ : Polyestor

CE : Electrolytic

RD : Carbon Film

RS : Metal Oxide Film

RN : Metal Film

RF : Fusible

April, 200

Printed in KoreP/NO : 3828VD0113X

PRINTED CIRCUIT BOARD

MAIN(TOP)

CONTROLSPK(TOP)

SPK(BOTTOM)

POWER S/W

MAIN(BOTTOM)

LG MP-42PZ12 User manual

Popular Monitor manuals by other brands
