LG N1910LZ-BF User manual

www.lg.com
OWNER'S MANUAL
NETWORK MONITOR
N1910LZ
Please read the safety information carefully before using the product.
Network Monitor Model
English

2
ENG
English
Table of Contents
TABLE OF CONTENTS
3ASSEMBLING AND
PREPARING
3 Unpacking
4 Parts and buttons
6 Setting Up the Monitor set
6 - Attaching the Stand Base
6 - Detaching the stand base
7 - Adjusting the stand height
7 - Adjusting the angle
8 - Mounting on a table
8 - Using the Kensington locking device
9 - Detaching the stand body
9 - Installing the wall mount plate
10 - Mounting on a wall
11 USING THE MONITOR SET
11 Connecting Input Signal Cable
11 - D-SUB IN connection - PC
11 - D-SUB OUT connection - PCoIP
12 - DVI connection - PCoIP
13 Connecting LAN/Peripherals
13 - LAN connection - PCoIP
14 - Peripheral device connection
15 - Self Image Adjustment
16 CUSTOMIZING SETTINGS
16 Accessing The Main Menus
17 MENU Settings
17 - Picture
18 - Color
19 - Display
20 - Others
21 MODE Settings
21 - F-ENGINE
22 - PHOTO EFFECT
23 AUTO Settings : D-SUB Input
23 -/ /- Settings : PCoIP Input
24 TROUBLESHOOTING
26 PRODUCT SPECIFICATION
27 Preset Mode
27 Power Indicator
28 PROPER POSTURE
28 Proper posture for using the monitor
29 USING PCOIP SOLUTION

3
ENG
English
ASSEMBLING AND PREPARING
ASSEMBLING AND PREPARING
Unpacking
Please check whether all the components are included in the box before using the product. If there are
missing components, contact the retail store where you purchased the product. Note that the product and
components may look different from those shown here.
yOnly use an approved LG power adapter.
yDamage caused by other power adapters is not covered by warranty.
yNote that the components may look different from those shown here.
yWithout prior notice, all information and specifications in this manual are subject to change to improve
the performance of the product.
yTo purchase optional accessories, visit an electronics store or online shopping site or contact the retail
store where you purchased the product.
Power CordUser Manual/Card
Stand Base
Adaptor
CAUTION
NOTE
15-pin D-SUB Signal Cable

4
ENG
English
ASSEMBLING AND PREPARING
Parts and buttons
Power Indicator
yLED On : Power is on
yLED Off: Power is off
Front Side Buttons
Input Connectors (See p.11 to 14)
(Power Button)
Input Connectors
(See p.14 )

5
ENG
English
ASSEMBLING AND PREPARING
Button Description
MENU Activates the main menu.
OSD Lock/Unlock
Functions
Locks/unlocks the OSD screen.
yTo lock the OSD screen, press and hold the MENU button
for several seconds. The "OSD LOCKED" message will be
displayed and the screen will be locked.
yTo unlock the OSD screen, press and hold the MENU
button again for several seconds. The "OSD UNLOCKED"
message will be displayed and the screen will be unlocked.
MODE Moves to the F-ENGINE and PHOTO EFFECT options.
AUTO To adjust the monitor settings, press the AUTO button on the MONITOR SETUP OSD
menu (only supported for analog signal).
For optimal screen display, use the following resolution.
Optimal Resolution 1280 x 1024
INPUT Allows selection of the input signal.
yIf you connect the monitor to a computer using a D-SUB cable, select either the PCoIP
or D-SUB input signal.
yIf only one computer is connected to the monitor, the input signal is detected automati-
cally. The initial input signal is PCoIP.
EXIT Exits the OSD menu.
(Power Button)
yD-SUB Input: Power On/Off
yPCoIP Input
Monitor Off: Press the power button twice, or press the power button and wait for 10
seconds.
PCoIP Off: Press the power button, then press the EXIT button located next to the
power button.
PCoIP On: Press the power button.
Remote PC Power Control: Press the power button for at least five seconds to turn
the PC on/off.
* To use the Remote PC Power Control function, separate settings are required for the PC.
Power Indicator When the monitor is in operating mode, the power indicator
will turn white (on mode).
When the monitor is in power saving mode, the power indica-
tor will blink white.

6
ENG
English
ASSEMBLING AND PREPARING
yThe components appearing in the illustra-
tions may look different from the actual prod-
uct.
yDo not carry the monitor upside-down as this
may cause it to fall off its stand, resulting in
damage or injury.
yTo avoid damaging the screen when lifting
or moving the monitor, only hold the stand or
the plastic cover. This avoids putting unnec-
essary pressure on the screen.
yOnly remove the tape and the locking pin
when the monitor is mounted on the stand
base and is in an upright position. Otherwise,
the stand body may protrude, which may
lead to injury.
Detaching the stand base
1Place the monitor's screen face down.
To protect the screen from scratches, cover the
surface with a soft cloth.
Setting Up the Monitor set
Attaching the Stand Base
1Place the monitor's screen face down.
yTo protect the screen from scratches, cover
the surface with a soft cloth.
3Using a coin, turn the screw clockwise to se-
cure the stand base.
2Check the position (at the front and rear) of
the stand body, then mount the stand base on
the stand body as shown in the figure.
Stand Body
Stand Base
Stand Base
2Using a coin, turn the screw in the stand base
counterclockwise. Detach the stand base from
the stand body.
Stand Body
Stand Base
CAUTION
CAUTION

7
ENG
English
ASSEMBLING AND PREPARING
yOnce the pin is removed, it is not necessary
to re-insert it to adjust the height.
Adjusting the stand height
1Place the monitor mounted on the stand base
in an upright position.
Adjusting the angle
1Place the monitor mounted on the stand base
in an upright position.
2Remove the tape attached at the bottom rear
of the stand body, then pull out the locking
pin.
3The height can be adjusted up to 110 mm.
2Adjust the angle of the screen. The angle of the
screen can be adjusted up to 15° forwards and
5° backwards for a comfortable viewing experi-
ence.
yTo avoid injury to the fingers when adjusting
the screen, do not hold the lower part of the
monitor's frame as illustrated below.
yDo not put your finger be-
tween the screen and the
base (chassis) when adjust-
ing the screen's height.
yBe careful not to touch or press the screen
area when adjusting the angle of the monitor.
15- 5
Front Side Rear Side
15- 5
Tape
Locking Pin
Stand Body
110.0 mm
CAUTION
WARNING
WARNING

8
ENG
English
ASSEMBLING AND PREPARING
Mounting on a table
1Lift the monitor and place it on the table in an
upright position.
Install at least 10 cm away from the wall to
ensure sufficient ventilation.
2Connect the adaptor to the monitor, then plug
the power cord into the wall outlet.
3Press the (Power) button on the front of the
monitor to turn on the monitor.
10 cm
10 cm
10 cm
10 cm
yUnplug the power cord prior to moving or
installing the monitor. There is risk of electric
shock.
Using the Kensington locking
device
The connector for the Kensington lock is located
on the rear of the monitor.
For more information on installation and usage,
refer to the Kensington lock user manual or visit
the website at http://www.kensington.com.
Connect the monitor to the table with the Kensing-
ton lock cable.
yUsing the Kensington lock is optional. The
accessories can be purchased at your local
electronics store.
CAUTION
NOTE

9
ENG
English
ASSEMBLING AND PREPARING
Installing the wall mount plate
This monitor has a VESA compatible mount on the
back. Most mounts will require an LG mounting
plate.
Detaching the stand body
1Place the monitor's screen face down. To
protect the screen from scratches, cover the
surface with a soft cloth.
2Using a screwdriver, remove the four screws
and detach the stand from the monitor.
1Place the monitor's screen face down. To
protect the screen from scratches, cover the
surface with a soft cloth.
2Place the wall mount plate on the monitor and
align it with the screw holes on the monitor.
3Using a screwdriver, tighten the four screws to
fix the plate onto the monitor.
yThe wall mount plate is sold separately.
yFor more information on the installation, refer
to the wall mount plate's installation guide.
Wall Mount Plate
NOTE

10
ENG
English
ASSEMBLING AND PREPARING
10 cm
10 cm
10 cm 10 cm
If you want to mount the monitor on the wall (op-
tional), attach the wall mounting bracket to the rear
of the monitor.
Make sure that the wall mounting bracket is se-
curely fixed to the monitor and to the wall.
Use the wall mount plate and screws that comply
with the VESA standard as specified below.
y784.8 mm (30.9 inch) or less
* Thickness of the wall mount plate: 2.6 mm
* Fastening screw: Diameter 4.0 mm x Pitch 0.7
mm x
Length 10 mm
y787.4 mm (31.0 inch) or greater
* Use the wall mount plate and screws con-
forming to the VESA standard.
yUnplug the power cord before moving or in-
stalling the monitor to avoid electric shocks.
yInstalling the monitor on the ceiling or on a
slanted wall may result in the monitor falling
off, which could lead to injury. Please use
a LG wall mounting bracket when using a
VESA mount. For more information, contact
your local retail store or a qualified installer.
yApplying excessive force when fastening
screws may cause damage to the moni-
tor. Damage caused in this way will not be
covered by the product warranty.
yUse the wall mounting bracket and screws
that conform to the VESA standard. Dam-
age caused by the use or misuse of inap-
propriate components will not be covered
by the product warranty.
yUse the screws specified in the VESA stan-
dard.
yThe wall mount kit includes the installation
guide and necessary parts.
yThe wall mounting bracket is optional. The
accessories can be purchased at your local
retail store.
yThe length of the screw may differ for each
wall mounting bracket. Ensure the correct
length of the screw is used.
yFor more information, please refer to the user
manual for the wall mounting bracket.
Model N1910LZ
VESA (A x B) 75 x 75
Stand Screw M4
Required Screw 4
Wall Mount Plate
(Optional)
RW120
Mounting on a wall
Install the monitor at least 10 cm away from the
wall and leave about 10 cm of space at each side
of the monitor to ensure sufficient ventilation. De-
tailed installation instructions can be obtained from
your local retail store. Please refer to the manual
to install and set up a tilting wall mounting bracket.
CAUTION
NOTE
