LG LFD21870 Series Instruction Manual

P/No. MFL37933517
Please read this guide
thoroughly before
operating and keep it handy
for referen e at all times.
Lea detenidamente estas
instru iones antes utilizar
el frigorífi o y guárdelas omo
referen ia para el futuro.
Veuillez lire e guide attentivement
avant la mise en servi e de l’appareil
et gardez-le à portée de main
pour le onsulter en as de besoin.
LFD21870**, LFD25870**
FOR LG CUSTOMER SERVICE:
1-888-LGCANADA
Or visit us on the Web at: http://www.lg.ca
EL SERVICIO DE ATENCIÒN AL CLIENTE DE LG:
1-888-LGCANADA
Ou visitez notre site Web à l’adresse:
http://www.lg.ca
POUR SERVICE À LA CLIENTÈLE DE LG:
1-888-LGCANADA
O visítenos en la Web en: http://www.lg.ca

2
IMPORTANT SAFETY INFORMATION
Basic Safety Precautions ........................................5
CFC Disposal ..........................................................5
Grounding Requirements ........................................6
PARTS AND FEATURES
Parts nd Features ...............................................11
REFRIGERATOR INSTALLATION
Unpacking Your Refrigerator ................................12
Installation ............................................................12
Base Cover ..........................................................12
Removing nd Replacing
Your Refrigerator Handles nd Doors .................13
Leveling nd Door lignment ...............................19
USING YOUR REFRIGERATOR
Ensuring Proper ir Circulation ............................20
Multi-Flow .............................................................20
Setting The Controls ............................................20
djusting Control Settings ....................................21
Food Storage Guide .............................................21
Storing Frozen Food ............................................22
Water Dispenser ...................................................22
Refrigerator Shelves ............................................23
Crisper Humidity Control ......................................24
Removing Crisper ................................................24
Glide‘N’Serve .......................................................24
Modular Door Bin .................................................25
Dairy Bin ...............................................................25
Utility Bin ..............................................................25
Tilting Door............................................................25
Ice Bin ..................................................................25
Tilt-Out Door Basket .............................................26
Durabase ..............................................................26
Durabase Divider .................................................26
Pull out Drawer .....................................................26
Filter ......................................................................27
CARE AND CLEANING
General Cleaning Tips .........................................28
Outside .................................................................28
Inside Walls ..........................................................28
Door Liner nd Gaskets .......................................28
Plastic Parts .........................................................28
Condenser Coils ...................................................28
Light Bulb Replacement .......................................28
Power Interruptions ..............................................29
When You Go On Vacation ..................................29
When You Move ...................................................29
TROUBLESHOOTING
Understanding sounds you may hear ..................34
WARRANTY
Product Registration Information ............................3 TH NK YOU!
Congratulations on your purchase
and welcome to the LG family.
Your new LG French Door
Refrigerator combines the most
advanced cooling technology
with simple operation and high
efficiency. Follow the operating
and care instructions in this
this manual and your refrigerator
will provide you with many years
of reliable service.

LG ELECTRONICS, INC.
LG REFRIGERATOR LIMITED WARRANTY - USA
3
Your LG Refrigerator will be repaired or repla ed, at LG’s option, if it proves to be defe tive in material or workmanship
under normal use, during the warranty period ("Warranty Period") set forth below, effe tive from the date ("Date of
Pur hase") of original onsumer pur hase of the produ t. This warranty is good only to the original pur haser of the
produ t and effe tive only when used in the United States, in luding Alaska, Hawaii, and U.S. Territories.
THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTY, EXPRESS OR IMPLIED, INCLUDING WITHOUT
LIMITATION, ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TO THE
EXTENT ANY IMPLIED WARRANTY IS REQUIRED BY LAW, IT IS LIMITED IN DURATION TO THE EXPRESS
WARRANTY PERIOD ABOVE. NEITHER THE MANUFACTURER NOR ITS U.S. DISTRIBUTOR SHALL BE LIABLE
FOR ANY INCIDENTAL, CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY NATURE,
INCLUDING WITHOUT LIMITATION, LOST REVENUES OR PROFITS, OR ANY OTHER DAMAGE WHETHER
BASED IN CONTRACT, TORT, OR OTHERWISE. Some states do not allow the exclusion or limitation of incidental or
consequential damages or limitations on how long an implied warranty lasts, so the above exclusion or limitation may not
apply to you. This warranty gives you specific legal rights and you may also have other rights that vary from state to state.
THIS LIMITED WARRANTY DOES NOT APPLY TO:
• Servi e trips to your home to deliver, pi k up, and/or install the produ t, instru t, or repla e house fuses or orre t wiring, or
orre tion of unauthorized repairs.
• Damages or operating problems that result from misuse, abuse, operation outside environmental spe ifi ations or ontrary to the
requirements of pre autions in the Operating Guide, a ident, vermin, fire, flood, improper installation, a ts of God, unauthorized
modifi ation or alteration, in orre t ele tri al urrent or voltage, or ommer ial use, or use for other than intended purpose.
• Repairs when your LG refrigerator is used in other than normal, single-family household use.
• Damages aused during and/or after delivery.
• Display, dis ount, or refurbish units pur hased with s rat hes, dents, or defe ts.
The ost of repair or repla ement under these ex luded ir umstan es shall be borne by the onsumer.
Proof of pur hase is required and must be provided to LG in order to validate warranty.
CUSTOMER INTERACTIVE CENTER NUMBERS
TO CONTACT LG ELECTRONICS BY MAIL:
LG Customer Intera tive Center
P. O. Box 240007
201 James Re ord Road
Huntsville, Alabama 35813
ATTN: CIC
WARRANTY PERIOD:
REFRIGERATOR/FREEZER
LABOR: One Year from the Date of Pur hase.
PARTS: One Year from the Date of Pur hase.
SEALED SYSTEM (Compressor, Condenser, and
Evaporator)
LABOR: One Year from the Date of Pur hase.
PARTS: Seven years from the Date of Pur hase.
Repla ement Units and Repair Parts are warranted for
the remaining portion of the original unit’s warranty
period.
HOW SERVICE IS HANDLED:
In-Home Service (Ex ept Model GR051):
Please retain dealer’s dated bill of sale or delivery
ti ket as eviden e of the Date of Pur hase for proof of
warranty, and submit a opy of the bill of sale to the
servi e person at the time warranty servi e is
provided.
Please call 1-800-243-0000 and choose the
appropriate option to locate your nearest LG
Authorized Service Center. (Phones are answered
24 hours a day, 365 days per year.)
Or visit our website at: http://www.lgservice.com
To obtain Customer Assistance, Product Information, or
Dealer or Authorized Service Center location: Call 1-800-243-0000 (24 hours a day, 365 days per year)
and sele t the appropriate option from the menu.
Or visit our website at: http://us.lgservice.com

4
visit our web site/http://www.lg.ca LG Electronics
LIMITED WARRANTY
CANADA
LG Electronics will repair or at its option replace, without charge, your product which proves to be defective
in material or workmanship under normal use during the warranty period listed below from the date of
original purchase.
This warranty is good only to the original purchaser of the product during the warranty period as long as it
is in Canada.
WARRANTY PERIOD:
REFRIGERATOR/FREEZER
LABOR: One Year from the Date of Purchase.
PARTS: One Year from the Date of Purchase.
SEALED SYSTEM (Compressor, Condenser, and Evaporator)
LABOR: One Year from the Date of Purchase.
PARTS: Seven years from the Date of Purchase.
Replacement Units and Repair Parts are warranted for the remaining portion of the original unit’s warranty
period.
No other express warranty is applicable to this product. THE DURATION OF ANY IMPLIED WARRANTIES.
INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY, IS LIMITED TO THE DURATION OF
THE EXPRESS WARRANTY HEREIN. LG ELECTRONICS SHALL NOT BE LIABLE FOR THE LOSS OF
USE OF THE PRODUCT, INCONVIENCE, LOSS OR ANY OTHER DAMAGES, DIRECT OR
CONSEQUENTIAL, ARISING OUT OF THE USE OF OR INABILITY TO USE, THIS PRODUCT OR FOR
ANY BREACH OF ANY EXPRESS OR IMPLIED WARRANTY, INCLUDING THE IMPLIED WARRANTY
OF MERCHANTABILITY APPLICABLE TO THIS PRODUCT.
Some States do not allow the exclusion or limitation of incidental or consequential damages or limitations on how
long an implied warranty lasts; so these limitations or exclusions may not apply to you. This warranty gives you
specific legal rights and you may also have other rights which vary from state to state.
THIS LIMITED WARRANTY DOES NOT APPLY TO:
• Service trips to your home to deliver, pick up, and/or install the product, instruct, or replace house fuses or correct
wiring, or correction of unauthorized repairs.
• Damages or operating problems that result from misuse, abuse, operation outside environmental specifications or
contrary to the requirements of precautions in the Operating Guide, accident, vermin, fire, flood, improper
installation, acts of God, unauthorized modification or alteration, incorrect electrical current or voltage, or
commercial use, or use for other than intended purpose.
• Repairs when your LG refrigerator is used in other than normal, single-family household use.
• Damages caused during and/or after delivery.
• Display, discount, or refurbish units purchased with scratches, dents, or defects.
The cost of repair or replacement under these excluded circumstances shall be borne by the consumer.
Proof of purchase is required and must be provided to LG in order to validate warranty.
CUSTOMER ASSISTANCE NUMBERS:
To obtain Warranty Coverage: Retain your Bill of Sale to prove date of purchase.
A Copy of your Sales Receipt must be submitted at the time
warranty service is provided.
To obtain Product or Customer Call 1-888-542-2623
Service Assistance: Press the appropriate menu option, and have your product
type (Refrigerator), model number, serial number, and
ZIP/Postal Code ready.
To obtain the nearest Call 1-888-542-2623
Authorized Service Center: Press the appropriate option, and have your product type
(Refrigerator), model number, serial number, and ZIP/Postal
Code ready.

IMPORTANT SAFETY INSTRUCTIONS
5
This guide ontains many important safety messages. Always read and obey all safety messages.
BASIC SAFETY PRECAUTIONS
All safety messages will identify the hazard, tell you how to redu e the han e of injury, and tell you what an happen if
the instru tions are not followed.
This is the safety alert symbol. It alerts you to safety messages that inform you
of hazards that an kill or hurt you or others, or ause damage to the produ t.
All safety messages will be pre eded by the safety alert symbol and the hazard
signal word DANGER, WARNING, CAUTION. These words mean:
You will be killed or seriously injured if you don’t follow instru tions.
You can be killed or seriously injured if you don’t follow instru tions.
Indi ates an imminently hazardous situation whi h, if not avoided,
may result in minor or moderate injury, or produ t damage only.
DANGER
WARNING
CAUTION
DANGER: RISK OF CHILD ENTRAPMENT
Child entrapment and suffo ation are not problems of the
past. Junked or abandoned refrigerators are still
dangerous…even if they will sit for just a few days. If you
are getting rid of your old refrigerator, please follow the
instru tions at right to help prevent a idents.
BEFORE YOU THROW AWAY
YOUR OLD REFRIGERATOR
OR FREEZER
• Take off the doors.
•Leave the shelves in pla e so that
hildren may not easily limb inside.
Your old refrigerator may have a ooling system that used
CFCs ( hlorofluoro arbons). CFCs are believed to harm
stratospheri ozone.
If you are throwing away your old refrigerator, make sure
the CFC refrigerant is removed for proper disposal by a
qualified servi er. If you intentionally release this CFC
refrigerant, you an be subje t to fines and imprisonment
under provisions of environmental legislation.
CFC DISPOSAL

GROUNDING REQUIREMENTS
6
IMPORTANT: Please read arefully.
TO CONNECT ELECTRICITY
RECOMMENDED GROUNDING METHOD
The refrigerator should always be plugged into its own
individual properly grounded ele tri al outlet rated for
115 Volts, 60 Hz, AC only, and fused at 15 or 20 amperes.
This provides the best performan e and also prevents
overloading house wiring ir uits whi h ould ause a fire
hazard from overheated wires. It is re ommended that a
separate ir uit serving only this applian e be provided.
Use a re epta le whi h annot be turned off with a swit h
or pull hain. Do not use an extension ord.
Where a standard two-prong wall outlet is en ountered,
it is your personal responsibility and obligation to have it
repla ed with a properly grounded three-prong wall outlet.
Do not, under any circumstances, cut or remove the
third (ground) prong from the power cord.
NOTE: Before performing any type of installation,
leaning, or removing a light bulb, turn the ontrol
(Thermostat, Refrigerator Control or Freezer Control,
depending on the model) to OFF and then dis onne t the
refrigerator from the ele tri al sour e. When you are
finished, re onne t the refrigerator to the ele tri al sour e
and reset the ontrol (Thermostat, Refrigerator Control or
Freezer Control, depending on the model) to the desired
setting.
USE OF EXTENSION CORDS
Because of potential safety hazards under certain
conditions, we strongly recommend against the use
of an extension cord. However, if you still ele t to use
an extension ord, it is absolutely ne essary that it be a
UL-listed (USA), 3-wire grounding type applian e
extension ord having a grounding type plug and outlet,
and that the ele tri al rating of the ord be 15 amperes
(minimum) and 120 volts.
Use of an extension ord will in rease the learan e
needed for the ba k of the refrigerator.
WARNING
Electrical Shock Hazard
FOR PERSONAL SAFETY, this applian e must be
properly grounded. Have the wall outlet and the ir uit
he ked by a qualified ele tri ian to make sure the
outlet is properly grounded.
3-prong
grounding
plug
3-prong
grounding type
wall re epta le
Ensure proper
ground exists
before use.
SAVE THESE INSTRUCTIONS
WARNING
• Repair or repla e immediately all ele tri servi e ords that
have be ome frayed or otherwise damaged. Do not use a
ord that shows ra ks or abrasion damage along its length
or at either the plug or onne tor end.
• When moving your refrigerator away from the wall, be
areful not to roll over or damage the power ord.
• Keep fingers out of pinch point areas; learan es between
the doors and abinet are ne essarily small. Be areful
losing doors when hildren are in the area.
• This refrigerator must be properly installed in a ordan e
with the Attention Installer Instructions that were taped to
the front of the refrigerator.
• Don’t tou h the lamp, in ase of light on the long time,
Be ause it an be very hot.
• DO NOT refreeze frozen foods whi h have thawed
ompletely. The United States Department of Agri ulture in
Home and Garden Bulletin No. 69 says:
…You may safely refreeze frozen foods that have thawed if
they still ontain i e rystals or if they are still old—below
40°F (4°C).
…Thawed ground meats, poultry or fish that have any off-
odor or off- olor should not be refrozen and should not be
eaten. Thawed i e ream should be dis arded. If the odor
or olor of any food is poor or questionable, get rid of it.
The food may be dangerous to eat.
Even partial thawing and refreezing redu es the eating
quality of foods, parti ularly fruits, vegetables and prepared
foods. The eating quality of red meats is affe ted less than
that of many other foods. Use refrozen foods as soon as
possible to save as mu h of their quality as you an.

WARNING
7
1. When connecting the power
The dedicated outlet should be used.
• Using several devi es at one
outlet may ause fire.
• The ele tri leakage breaker
may damage food and the
dispenser may be leaked.
Do not allow the power cord bent or pressed by the
heavy object to be damaged.
It may damage the power
ord to ause fire or ele tri
sho k.
Unplug the power plug when cleaning, handling or
replacing the interior lamp of the refrigerator.
• It may ause ele tri sho k or
injury.
• When repla ing the interior lamp
of the refrigerator, make sure
that the rubber ring for
preventing the ele tri spark
within the so ket is not taken off.
Remove water or dust from the power plug and insert
it with the ends of the pins securely connected.
Dust, water or unstable
onne tion may fire or ele tri
sho k.
When the power cord or the power plug is damaged
or the holes of the outlet are loosed, do not use them.
It may ause ele tri sho k or
short ir uit to make fire.
Do not allow the power plug to face upward or to be
squeezed at the back of the
refrigerator.
Water may be flown into or
the plug may be damaged,
whi h auses fire or ele tri
sho k.
Do not extend or modify the length of the power plug.
It auses ele tri sho k or fire
by the ele tri damage of the
power ord or others.
Do not pull out the cord or touch the power plug with
wet hands.
• It may ause ele tri sho k or
injury.
Make sure of grounding.
The in orre t grounding may
ause breakdown and ele tri
sho k.
To reduce the risk of fire, electric shock, or injury to persons when using your product, basic safety
precautions should be followed, including the following. Read all instructions before using this appliance.
Grounding
Conductor
Copper
flat
More than
75cm

IMPORTANT SAFETY INSTRUCTIONS
8
2. When using the refrigerator
Do not place the heavy object or
the dangerous object (container
with liquid) on the refrigerator.
It may be dropped to ause
injury, fire or ele tri sho k
when opening or losing the
door.
Do not cling to the door or the shelves of the door or
the home bar of the freezer or the cool chamber.
It may make the refrigerator
fallen down or damage the
hands. Espe ially, do not allow
the hildren to do the above.
Do not place the lit candle within
the refrigerator to deodorize.
It may ause explosion or fire.
Do not store the medicine or the academic
materials at the refrigerator.
When the material with the stri t
temperature ontrol is stored, it
may be deteriorated or it may
make an unexpe ted rea tion to
ause any risk.
Avoid the heating devices.
It may ause fire.
Do not install the refrigerator in the wet place or the
place which water or rain splashes.
Deterioration of insulation of
ele tri parts may ause
ele tri leakage.
Do not use or store inflammable materials ether,
benzene, alcohol, medicine,
LP gas, spray or cosmetics
near or in the refrigerator.
It may ause explosion or
fire.
Do not insert the hands into
the ice bucket or the ice dispenser.
Operating the i e maker may
ause injury.
Do not use the combustible
spray near the refrigerator.
It may ause fire.
Do not place flower vase, cup,
cosmetics, medicine or any
container with water on
the refrigerator.
It may ause fire, ele tri sho k
or injury by dropping down.
Use the submerged refrigerator after checking it.
It may ause ele tri sho k
or fire.
When gas is leaked, do not touch the refrigerator or
the outlet and ventilate the room immediately.
• The explosion by spark may ause fire or burn.
• Be ause this refrigerator uses natural gas (isobutene,
R600a) as the environment-friendly refrigerant, even a
small amount (80~90g) is
ombustible. When the gas is
leaked by the severe damage
during delivering, installing or
using the refrigerator, any
spark may ause fire or burn.
The Academic
Medicine
The Medicine
Benzene
Ether
Thinner

IMPORTANT SAFETY INSTRUCTIONS
9
2. When using the refrigerator
Do not spray water at the outside or the inside of the
refrigerator or do not clean it
with benzene or thinner.
Deterioration of insulation of
ele tri parts may ause ele tri
sho k or fire.
Do not allow any person except the qualified engineer
to disassemble, repair or alter
the refrigerator.
It may ause injury, ele tri
sho k or fire.
When disposing the refrigerator, remove the packing
materials from the door.
It may ause to lo k out the
hild.
Do not insert the hands or the metal stick into the exit
of cool air, the cover, the
bottom of the refrigerator, the
heatproof grill (exhaust hole)
at the backside.
It may ause ele tri sho k
or injury.
When any strange smell or smoke is detected from
the refrigerator, disconnect
the power plug immediately
and contact to the service
center. Service center
It may ause fire.
CAUTION
Violating this direction may cause injury or damage house or furniture. Always be careful, please.
Do not touch food or containers at the freezer with
wet hands.
It may ause frostbite.
Do not put ice in thin crystal cup or ceramic ware.
It may break up or erami
ware to ause injury.
Do not use the refrigerator for non-domestic purpose
(storing medicine or testing
material, using at the ship, etc.).
It may ause an unexpe ted
risk su h as fire, ele tri sho k,
deterioration of stored material
or hemi al rea tion.
Install the refrigerator on the solid and level floor.
Installing it on the unstable
pla e may ause death by
falling down the refrigerator
when opening or losing the
door.
When you want to dispose the refrigerator, contact to
the down-block office.
When you want to dispose the
large living waste su h as
ele tri home applian e and
furniture, you’d better onta t
the lo al down-blo k offi e.
Thinner
Down-block
office
Service
center

CAUTION
10
Wait for 5 minutes or longer when reconnecting the
plug.
It may ause the operation of
the freezer to fail.
Pull out the power plug not by grasping
the cord but the plug of its end.
It may ause ele tri sho k or
short ir uit to fire.
Do not insert the hands into
the bottom of the refrigerator.
The iron plate of the bottom
may ause injury.
Because opening or closing the door of the
refrigerator may cause injury
to the person around it, be
careful, please.
Opening or losing the door
may ause feet or hands to be
aught in the hink in door or
the hild to be get hurt by the
orner.
Do not put any living animal
in the refrigerator.
Supply the automatic ice maker with drinkable water
only (only for the model
with the dispenser).
Otherwise, it may ause any
risk.
Do not put bottle in the freezer.
It may freeze the ontents to
break the bottle to ause injury.
Do not install the refrigerator in
the wet place or the place which
water or rain splashes.
Deterioration of insulation of
ele tri parts may ause
ele tri leakage.
Carry the refrigerator with the handle bar at the
bottom of the front and the
top of the rear.
Otherwise, your hands may be
slipped to ause injury.
After
5minutes
Drinkable
water

PARTS AND FEATURES
11
Digital Sensor Control
Filter (Inside) (p. 27)
Modular Door Bins (p. 25)
Shelves (p. 23)
Crisper (p. 24)
(Keeps fruits and vegetable fresh and risper)
Glide’N’Serve (p. 24)
Custom ube I emaker (p. 30)
N
A
B
O
C
D
E
F
G
H
M
C
I
J
L
K
Use this page to be ome more familiar with the parts and features. Page referen es are in luded for your onvenien e.
NOTE: This guide covers several different models. The refrigerator you have purchased may have some or all of
the items listed below. The locations of the features shown below may not match your model.
A
B
C
D
E
F
G
I e Bin (p. 25)
Pull out Drawer (p. 26)
Durabase (p. 26)
Divider (p. 26)
Tilt-Out Door Basket (p. 26)
Dairy Bin (p. 25)
Utility Bin (p. 25)
Water Tank Cover
H
I
J
K
L
M
N
O

UNPACKING YOUR REFRIGERATOR
Remove tape and any temporary labels from your
refrigerator before using. Do not remove any warning-type
labels, the model and serial number label, or the
Te hSheet that is atta hed to ba k wall of the refrigerator.
To remove any remaining tape or glue, rub the area
briskly with your thumb. Tape or glue residue an also be
easily removed by rubbing a small amount of liquid dish
soap over the adhesive with your fingers. Wipe with warm
water and dry.
Do not use sharp instruments, rubbing al ohol, flammable
fluids, or abrasive leaners to remove tape or glue. These
produ ts an damage the surfa e of your refrigerator. For
more information, see the Important Safety Instructions
se tion.
Refrigerator shelves are installed in the shipping position.
Please reinstall shelves a ording to your individual
storage needs.
INSTALLATION
1. To avoid vibration, the unit must be leveled. If required,
adjust the leveling legs to ompensate for unevenness
of the floor. The front should be slightly higher than the
rear to aid in door losing. Leveling legs an be turned
easily by tipping the abinet slightly. Turn the leveling
legs lo kwise ( ) to raise the unit, ounter lo kwise
( ) to lower it.
2. Install this applian e in an area where the temperature
is between 55°F (13°C) and 110°F (43°C.) If the
temperature around the applian e is too low or high,
ooling ability may be adversely affe ted.
3. Allow the learan e of at least 2 in h from the eiling
and 1 in h from the side walls for better ooling
effi ien y, ease of installation, proper air ir ulation and
ele tri al onne tions.
: Avoid pla ing the unit near heat sour es,
dire t sunlight or moisture.
NEXT
1. Clean your refrigerator thoroughly and wipe off all dust
a umulated during shipping.
2. Install a essories su h as i e ube bin, drawers,
shelves, et ., in their proper pla es. They are pa ked
together to prevent possible damage during shipment.
3. Let your refrigerator run for at least 2 or 3 hours before
putting food in it. Che k the flow of old air in the
freezer ompartment to ensure proper ooling. Your
refrigerator is now ready for use.
• Be areful when you work with hinge, base grille,
stopper et . You may be injured.
• Do not put hands or foot or metal sti ks into air vents,
base grille, or bottom of refrigerator. You may be injured
or re eive an ele tri al sho k.
BASE COVER
To remove the base cover
1. Open the Freezer Drawer. (Drawer not shown for larity.)
2. On e drawer is open there is suffi ient learan e to
remove s rews on top of over.
To replace base cover:
• Pla e over into position and insert and tighten s rews.
REFRIGERATOR INSTALLATION
12
WARNING
Excessive Weight Hazard
Use two or more people to move and install
refrigerator.
Failure to do so an result in ba k or other injury.
WARNING
When Moving Your Refrigerator:
Your refrigerator is heavy. When moving the
refrigerator for leaning or servi e, be sure to prote t
the floor. Always pull the refrigerator straight out
when moving it. Do not wiggle or walk the refrigerator
when trying to move it, as floor damage ould o ur.
WARNING
Explosion Hazard
Keep flammable materials and vapors, su h as
gasoline, away from refrigerator.
Failure to do so an result in death, explosion, or fire.
CAUTION
WARNING

REFRIGERATOR INSTALLATION
13
HOW TO REMOVE DOOR HANDLES
To move refrigerator through a house door, it maybe ne essary to remove refrigerator and freezer door handles.
NOTE: Handle appearan e may vary from
illustrations on this page.
1. Removing Refrigerator Handle
• Loosen the set s rews with the 3/32” Allen
wren h and remove the handle.
NOTE: If the handle mounting fasteners
need to be tightened or removed, use a 1/4”
Allen wren h.
2. Removing Freezer Drawer Handle
• Loosen the set s rews lo ated on the lower
side of the handle with the 3/32” Allen
wren h and remove the handle.
NOTE: If the handle mounting fasteners
need to be tightened or removed, use a 1/4”
Allen wren h.
Set Screw
Allen Wrench
Mounting
Fasteners

REFRIGERATOR INSTALLATION
14
HOW TO REPLACE DOOR HANDLES
NOTE: Handle appearan e may vary from illustrations on this page.
1. Replacing Refrigerator Door Handle
• Pla e the handle on the door by adjusting handle
footprints to fit mounting fastners and tighten the set
s rews with the 3/32” Allen wren h.
NOTE: If the handle mounting fasteners need to be
tightened or removed use a 1/4” Allen wren h.
2. Replacing Freezer Drawer Handle
• Pla e the handle on the door by adjusting handle
footprints to fit mounting fastners and tighten the set
s rews on the bottom of the handle with a 3/32” Allen
wren h.
NOTE: If the handle mounting fasteners need to be
tightened or removed use a 1/4” Allen wren h.
Mounting
Fasteners

3
4
7
8
6
2
5
1
4
7
8
6
2
5
1
REFRIGERATOR INSTALLATION
15
REMOVING AND REPLACING
REFRIGERATOR DOORS
To remove the left refrigerator door:
Pull the water tube out of the fitting while pressing the
release ring on the fitting. When you pull out the tube, first
you have to push the ollet by opposite dire tion of arrow
in the upper pi ture and tube pull out by dire tion of arrow.
:Before you begin, remove food and bins
from the doors.
• Open the door. Remove the top hinge over s rew (1).
• Use a flat-head s rewdriver to pry ba k the hooks
(not shown) on the front underside of the over (2).
Lift up the over.
• Remove the over. Pull out the tube (3).
• Dis onne t all the wire harnesses (4).
• Remove the grounding s rew(5)
• Rotate hinge lever (6) ounter lo kwise and remove.
Lift the top hinge (7) free of the hinge lever lat h (8).
IMPORTANT: When lifting the hinge free of the lat h, be
areful that the door does not fall forward.
• Lift the door from the middle hinge pin and remove the
door.
• Pla e the door, inside fa ing up, on a nons rat hing
surfa e.
To remove the right refrigerator door:
• Open door.Loosen top hinge over s rew (1).
Lift up over (2).
• Remove over.
• Dis onne t wire harness (4).Remove the grounding
s rew (5).
• Rotate hinge lever (6) lo kwise and remove.
Lift top hinge (7)free of hinge lever lat h (8).
IMPORTANT: When lifting the hinge free of the lat h, be
areful that the door does not fall forward.
CAUTION

REFRIGERATOR INSTALLATION
16
Replacing Refrigerator Door:
❿Right Door
• Lower the door onto middle hinge pin (9).
• Fit top hinge (7) over hinge lever lat h (8) and into pla e. Insert hinge lever (6) under lever lat h. Rotate lever
ounter lo kwise to se ure hinge.
• Install the grounding s rew (5) and onne t wire harnesses (4).
• Hook tab on door swit h side of over under edge of wire opening in abinet top. Position over (2) into pla e. lnsert and
tighten over s rew (1).
❿Left Door
• Lower the door onto middle hinge pin (9).
• Fit top hinge (7) over hinge lever lat h (8) and into pla e. Insert hinge lever (6) under lever lat h. Rotate lever lo kwise
to se ure hinge.
• Install the grounding s rew (5) and onne t the three wire harnesses (4).
• Push the water supply tube into the hole on the top ase and pull it out on the ba kplate.
• Insert the water supply tube (3) into the onne tor tube until you see only one s ale mark. (Fully insert the tube over
5/8”(15mm)).
• Hook tab on door swit h side of over (2) under edge of wire opening in abinet top. Position over into pla e. Insert and
tighten over s rew (1).
9
9
Correct
Incorrect

1
2
REFRIGERATOR INSTALLATION
17
HOW TO REMOVE AND INSTALL THE
PULLOUT DRAWER
IMPORTANT: To avoid possible injury or produ t or
property damage, you will need two people to perform the
following instru tions.
1. Removing Pullout Drawer
• Pull the drawer open to full extension. Remove the
lower basket (1) by lifting basket from rail system.
(If you tilt the door, it will be easier.)
• Press both hangers with your thumbs to lift it up.
• Separate the left and right rail over.
• Remove the s rews(2) of the rail on both sides.
• With both hands, hold both sides of the door and pull it
up to separate it from the rails.
• With both hands, hold the enter bar and push it in to let
both rails fitted simultaneously.
: When you remove the drawer, do not
hold the handle. If it may ome off and it ould ause
personal injury.
: When laying the drawer down, be areful
not to damage the floor or hurt your feet by the sharp
edges on hinge side.
CAUTION
CAUTION

3
2
1
4
REFRIGERATOR INSTALLATION
18
HOW TO REMOVE AND INSTALL THE
PULLOUT DRAWER
IMPORTANT: To avoid possible injury or produ t or
property damage, you will need two people to perform the
following instru tions.
2. Installing Pullout Drawer
• With both hands, hold the enter bar and push it out to
let both rails out to full extension simultaneously.
• Hook door supports (1) into rail tabs (2).
• Lower door into final position and tighten the s rews (3).
• Make sure you have a right rail over for ea h side.
• Align the top holes of the rail over with the top holes of
the door supports to assemble the rail overs.
• With the drawer pulled out to full extension, insert the
lower basket (4) in the rail assembly.
: To prevent a idental hild and pet
entrapment or suffo ation risk. DO NOT allow them to
play inside of drawer.
: DO NOT step or sit down on freezer
door.
Right
Rail Cover
Assembly Hole
Left
Rail Cover
WARNING
WARNING

REFRIGERATOR INSTALLATION
19
LEVELING AND DOOR ALIGNMENT
Leveling
After installing, se ure the produ t with the LEG not to
move left or right.
Your refrigerator has two front leveling legs—one on the
right and one on the left. If your refrigerator seems
unsteady or you want the doors to lose easier, adjust the
refrigerator’s tilt using the instru tions below:
1. Plug the refrigerator’s power ord into a 3-prong
grounded outlet. Move the refrigerator into its final
position.
2. Turn the leveling leg lo kwise to raise that side of the
refrigerator or ounter lo kwise to lower it. It may take
several turns of the leveling leg to adjust the tilt of the
refrigerator.
NOTE: Having someone push against the top of the
refrigerator takes some weight off the leveling legs.
This makes it easier to adjust the legs.
3. Open both doors again and he k to make sure that
they lose easily. If not, tilt the refrigerator slightly more
to the rear by turning both leveling legs lo kwise. It
may take several more turns, and you should turn both
leveling legs the same amount.
4. Re-adjust if ne essary.
5. Repla e the base over.
NOTE: Your new refrigerator is uniquely designed with
two fresh food doors. Either door an be opened or
losed independently of one another. You may have to
exert slight pressure on doors to get them to lose
ompletely.
Door Alignment
If the spa e between your doors is uneven, follow the
instru tions below to align the doors:
1. With one hand, lift up the door you want to raise at
middle hinge.
2. With other hand, use pliers to insert snap ring as
shown.
3. Insert additional snap rings until the doors are aligned.
(Three snap rings are provided with unit.)

USING YOUR REFRIGERATOR
20
ENSURING PROPER AIR CIRCULATION
In order to ensure proper temperatures, air must flow
between the refrigerator and freezer se tions. As shown
in the illustration below, air enters at top of the freezer and
ir ulates down. From the bottom of the freezer, air is
for ed up to the top of the refrigerator. Air enters
refrigerator through the top vent, then ir ulates and
exists at the bottom, where it returns to the freezer.
MULTI-FLOW
• Multi-Flow means powerful and effe tive ooling
operation. This is espe ially noti eable when new food is
pla ed in the refrigerator ompartment.
• If water or foreign substan es enter the ool air vent
while leaning, effi ien y will be lowered. In addition, if
gasket is damaged, effi ien y may be lowered be ause
of es aping ool air.
Do not block any of cool air vents with food pa kages.
If the vents are blo ked, airflow will be interrupted and
temperature and moisture problems may o ur.
IMPORTANT: Be ause air ir ulates between both
se tions, any odors formed in one se tion will transfer to
the other. You must thoroughly lean both se tions to
eliminate odors. To prevent odor transfer and drying out of
food, wrap or over foods tightly. (See the Food Storage
Guide se tion for details.)
SETTING THE CONTROLS
• Your refrigerator has a ontrol pad on the dispenser that
lets you regulate the temperature in the freezer and
refrigerator ompartments.
• Initially set the REFRIGERATOR CONTROL at 37°F
(3°C) and the FREEZER CONTROL at 0°F (–18°C).
Leave it at this setting for 24 hours (one day) to stabilize.
Then adjust the ompartment temperature as desired.
• Refrigerator Temp Control: 33°F to 46°F (0°C to 8°C)
The lower the number setting, the older the refrigerator
ompartment will be ome.
• Freezer Temp Control: -6°F to 8°F (-21°C to -13°C)
When the setting is at a lower number, the freezer
ompartment be omes older. The refrigerator
ompartment be omes warmer be ause less old air
flows into the refrigerator.
NOTE: If you want to hange °F to °C or the reverse,
press and hold FREEZER key and REFRIGERATOR key
simultaneously for 5 se onds or more.
NOTE: If you want to off display, press and hold ICE
PLUS key and FREEZER key over 5 se onds at the same
time.
NOTE: Tou h display on e to a tivate, then tou h again
to hange the settings or a tivate a fun tion. If 10 se onds
has passed sin e the display has been tou hed, it will be
ne essary to tou h “on e” again to rea tivate.
☞ This is to prevent a idental display setting hanges.
• ICE PLUS : Press the ICE PLUS button and the LED will
turn on. This fun tion will remain a tivated for 24 hours
and in rease the ooling speed of the freezer and the
amount of i e produ ed.
• Dispenser Lo k : Press and hold the LOCK button for 3
se onds to lo k the dispenser. When it is lo ked, the
dispenser will not operate. To unlo k, press and hold the
LOCK button for 3 se onds.
• Filter Reset : It displays in months the number of months
left to ex hange the filter from the moment power is
onne ted to the refrigerator. If you have hanged the
filter after 6 months of use, press and hold the FILTER
button 3 se onds or more and the filter display will be
initialized with a buzzing sound.
NOTE: The average life of the filter is 6 months.
: If a door is open, the dispenser does not
work.
WARNING
