LG LFX25971ST Instruction Manual

P/No. MFL37933507
Please read this guide
thoroughly before
operating and keep it handy
for referen e at all times.
Veuillez lire e guide attentivement
avant la mise en servi e de l’appareil
et gardez-le à portée de main
pour le onsulter en as de besoin.
Lea detenidamente estas
instru iones antes utilizar
el frigorífi o y guárdelas omo
referen ia para el futuro.
LFX25971**, LFX21971**
To onta t LG Ele troni s, 24 hours a day,
7 days a week:
1-800-243-0000
Or visit us on the Web at: us.lge.com
Pour onta ter LG Ele troni s, 24 heures par
jour, 7 jours par semaine:
1-800-243-0000
Ou visitez notre site Web à l’adresse: us.lge.com
Para omuni arse on LG Ele troni s,
24 horas al día, 7 días a la semana:
1-800-243-0000
O visítenos en la Web en: us.lge.com

2
IMPORTANT SAFETY INFORMATION
Basi Safety Pre autions ........................................3
CFC Disposal ..........................................................4
How to Conne t Ele tri ity ......................................5
PARTS AND FEATURES
Spe ial Features .....................................................6
Key Parts and Components ....................................7
INSTALLATION
Choose the Proper Lo ation ...................................8
Clearan es ..............................................................8
Flooring ...................................................................9
Handle Removal......................................................9
Door and Drawer Removal....................................10
Conne ting the Water Supply ...............................16
Conne ting the Water Lines..................................16
Leveling the Refrigerator Doors ............................18
Starting..................................................................19
HOW TO USE
Control Panel Features .........................................20
The LED Display ...................................................21
Adjusting the Temperatures and Display .............22
Operating the Dispenser ......................................23
Setting the Fun tions ...........................................24
In-Door I e Bin .....................................................25
Automati I emaker .............................................26
Storing Foods .......................................................27
Lo ation of Foods .................................................28
Shelf Height Adjustment .......................................29
CARE AND CLEANING
Removing and Repla ing Components ................30
Cleaning the Refrigerator .....................................34
General Information .............................................34
Repla ing the Water Filter.....................................35
TROUBLESHOOTING
Before Calling for Servi e …………………………36
SPECIFICATIONS
Key Dimensions and Spe ifi ations .....................40
WARRANTY
Produ t Registration Information ..........................41
THANK YOU!
Congratulations on your pur hase
and wel ome to the LG family.
Your new LG Fren h Door
Refrigerator ombines
advan ed ooling te hnology
with simple operation and high
effi ien y. Follow the operating
and are instru tions in this
this manual and your refrigerator
will provide you with many years
of reliable servi e.

3
BASIC SAFETY PRECAUTIONS
This guide contains many important safety messages. Always read and obey all
safety messages.
w This is the safety alert symbol. It alerts you to safety messages that inform you of hazards that an kill
or hurt you or others or ause damage to the produ t. All safety messages will be pre eded by the safety
alert symbol and the hazard signal word DANGER, WARNING, or CAUTION. These words mean:
wDANGER You might be killed or seriously injured if you don’t follow instru tions.
wWARNING You can be killed or seriously injured if you don’t follow instru tions.
wCAUTION Indi ates an imminently hazardous situation whi h, if not avoided, may
result in minor or moderate injury, or produ t damage.
All safety messages will identify the hazard, tell you how to redu e the han e of injury, and tell you
what an happen if the instru tions are not followed.
wWARNING
To reduce the risk of fire, electric shock, or
injury to persons when using your product,
basic safety precautions should be followed,
including the following.
Read all instructions before using this appliance.
• NEVER unplug your refrigerator by pulling on the
power ord. Always grip the plug firmly and pull it
straight out from the outlet.
• Repair or repla e immediately all ele tri servi e
ords that have be ome frayed or otherwise
damaged. Do not use a ord that shows ra ks or
abrasion damage along its length or at either the
plug or onne tor end.
• When moving your refrigerator away from the wall,
be areful not to roll over or damage the power ord.
• DO NOT store or use gasoline or other flammable
vapors and liquids in the vi inity of this or any other
applian e.
• DO NOT allow hildren to limb, stand, or hang on
the refrigerator doors or shelves in the refrigerator.
They ould damage the refrigerator and seriously
injure themselves.
• Keep fingers out of pin h point areas; learan es
between the doors and abinet are ne essarily
small. Be areful losing doors when hildren are
in the area.
• Unplug your refrigerator before leaning or making
any repairs.
NOTE: Servi e should be performed by a qualified
te hni ian.
• Before repla ing a burned-out light bulb, unplug the
refrigerator or turn off power at the ir uit breaker
or fuse box in order to avoid onta t with a live wire
filament. (A burned-out light bulb may break when
being repla ed.)
NOTE: Some models have LED interior lighting and
servi e should be performed by a qualified
te hni ian.
NOTE: Setting either or both ontrols to the OFF
position does not remove power to the light ir uit.
• When you are finished, re onne t the refrigerator to
the ele tri al sour e and reset the ontrol
(Thermostat Refrigerator Control, or Freezer
Control, or Freezer Control, depending on the
model) to the desired setting.
• This refrigerator must be properly installed in
a ordan e with the Installer Instructions that
were taped to the front of the refrigerator.
• After your refrigerator is in operation, do not tou h
the old surfa es in the freezer ompartment when
hands are damp or wet. Skin may adhere to the
extremely old surfa es.
• In refrigerators with automati i emakers, avoid
onta t with the moving parts of the eje tor
me hanism or with the heating element that
releases the ubes. DO NOT pla e fingers or hands
on the automati i emaking me hanism while the
refrigerator is plugged in.
• Do not modify or extend the power cord length.
It will ause ele tri sho k or fire.

4
BASIC SAFETY PRECAUTIONS (CONT.)
• DO NOT refreeze frozen foods whi h have
thawed ompletely. The United States
Department of Agri ulture in Home and Garden
Bulletin No. 69 says:
…You may safely refreeze frozen foods that have
thawed if they still ontain i e rystals or if they are
still old—below 40°F (4°C).
…Thawed ground meats, poultry, or fish that have
any off-odor or off- olor should not be refrozen
and should not be eaten. Thawed i e ream
should be dis arded. If the odor or olor of any
food is poor or questionable, dispose of it. The
food may be dangerous to eat.
Even partial thawing and refreezing redu es the
quality of foods, parti ularly fruits, vegetables,
and prepared foods. The eating quality of red
meats is affe ted less than that of many other
foods. Use refrozen foods as soon as possible to
save as mu h of their quality as you an.
CFC DISPOSAL
Your old refrigerator may have a ooling system
that used CFCs ( hlorofluoro arbons). CFCs are
believed to harm stratospheri ozone.
If you are throwing away your old refrigerator,
make sure the CFC refrigerant is removed for
proper disposal by a qualified servi er. If you
intentionally release this CFC refrigerant, you an
be subje t to fines and imprisonment under
provisions of environmental legislation.
wDANGER
Risk of Child Entrapment
Dis arded or abandoned refrigerators are
dangerous, even if they will sit for just a few
days. If you are disposing of your old refrigerator,
please follow the instru tions below to help prevent
a idents.
Before you throw away your old refrigerator or
freezer:
• Take off the doors.
• Leave the shelves in pla e so that hildren may
not easily limb inside.

5
HOW TO CONNECT ELECTRICITY
IMPORTANT: Please read carefully.
wWARNING
Electrical Shock Hazard
For personal safety, this appliance must be
properly grounded. Have the wall outlet and
the circuit checked by a qualified electrician to
make sure the outlet is properly grounded.
RECOMMENDED GROUNDING METHOD
The refrigerator should always be plugged into
its own individual properly grounded ele tri al
outlet rated for 120 volts, 60 Hz, AC only, and
fused at 20 amperes. This provides the
best performan e and also prevents overloading
house wiring ir uits whi h ould ause a fire
hazard from overheated wires. It is
re ommended that a separate ir uit serving
only this applian e be provided.
Use a re epta le whi h annot be turned off with
a swit h or pull hain. Do not use an extension
ord. Where a standard two-prong wall outlet is
en ountered, it is your personal responsibility
and obligation to have it repla ed with a properly
grounded three-prong wall outlet.
Do not, under any circumstances, cut or
remove the third (ground) prong from the
power cord.
Do not use an adapter plug.
NOTE: Some models have LED interior lighting and
servi e should be performed by a qualified te hni ian.
When you are finished, re onne t the refrigerator to
the ele tri al sour e and reset the ontrol
(Thermostat, Refrigerator Control, or Freezer Control,
depending on the model) to the desired setting.
USE OF EXTENSION CORDS
Because of potential safety hazards under
certain conditions, we strongly recommend
against the use of an extension cord.
However, if you still ele t to use an extension
ord, it is absolutely ne essary that it be a UL-listed
(USA), 3-wire grounding-type applian e
extension ord having a grounding-type plug
and outlet and that the ele tri al rating of the
ord be 20 amperes (minimum) and 120 volts.
Use of an extension ord will in rease the
learan e needed for the ba k of the
refrigerator.
SAVE THESE INSTRUCTIONS

6
SPECIAL FEATURES
CONTROL PANEL LED DISPLAY SCREEN
Simple ele troni ontrols are user-friendly.
The LED s reen shows refrigerator and freezer
temperatures, displays water filter status,
dispenser information, and more.
ICE PLUS
When this feature is a tivated, the freezer se tion
will run at the oldest temperature for a 24- hour
period to in rease i e produ tion by about 20
per ent.
FILTERED WATER AND ICE DISPENSER
The water dispenser offers fresh, hilled, filtered
water through the door. The i e dispenser offers
ubed or rushed i e.
DOOR ALARM
A warning alarm sounds at 30-se ond intervals
when the refrigerator or freezer door is left open
for more than 60 se onds.
IN-DOOR ICE BIN
The i emaker automati ally produ es 80–130
i e ubes in a 24-hour period to keep the i e
dispenser fully supplied. The in-door design
reates more shelf spa e.
CRISPERS
LG’s rispers preserve humidity and
help vegetables stay risp.
1
2
3
4
5
6
1
2
3
4
5
6

7
KEY PARTS AND COMPONENTS
In addition to the spe ial features and
omponents outlined in the Special Features
se tion, there are several other important
omponents that are referen ed in this manual.
ADJUSTABLE REFRIGERATOR SHELVING
The refrigerator ompartment shelves are
adjustable to allow flexibility for storage needs.
MODULAR DOOR BINS
Three inter hangeable bins an be arranged to
suit your storage needs.
REMOVABLE ICE STORAGE BIN
The i e storage bin an be removed to fill i e
bu kets, oolers, or pit hers.
LED INTERIOR LAMPS
Two separate LED arrays light the freezer and
refrigerator interiors.
NON TILTING DOOR BIN
FIXED DOOR BIN
1
2
4
5
36
3
5
4
6
1
2
4

8
CHOOSE THE PROPER LOCATION
wWARNING
Excessive Weight Hazard
Two or more people are required when
moving and unpacking the appliance.
• Store and install the refrigerator where it will not
be exposed to temperatures below freezing or
exposed to outdoor weather onditions.
• Install this applian e in an area where the
temperature is between 55°F (13°C) and 110°F
(43°C). If the temperature around the applian e
is too low or too high, ooling ability may be
adversely affe ted.
• If this refrigerator is installed where the
temperature is above 110°F (43°C), the
freezing apa ity is ompromised and the ost
of ele tri ity used in reases.
• To redu e the risk of ele tri sho k, do not
install the refrigerator in a wet or damp area.
• Sele t a pla e where a water supply an be
easily onne ted for the automati i emaker
and dispenser.
• Unstable installation may ause vibration and
noise. If the floor is not even, make the
refrigerator level by rotating the height adjusting
s rews.
• Properly ground the refrigerator to onform with
all governing odes and ordinan es.
wCAUTION
Avoid placing the unit near heat sources,
direct sunlight, or moisture.
CLEARANCES
• Too small a distan e from adja ent items may
result in lowered freezing apability and
in reased ele tri ity onsumption harges.
Allow at least 24 in. (61 m) in front of the
refrigerator to open the doors.
NOTE: For omplete dimensions and spe ifi ations,
see page 40.
1" (2.54 m)

9
FLOORING
• To minimize noise and vibration, the refrigerator
MUST be installed on a solidly onstru ted
floor.
• To avoid vibration, the unit must be level. If
required, adjust the leveling legs to ompensate
for unevenness of the floor. The front should be
slightly higher than the rear to aid in door
losing. The leveling legs an be turned easily
by pushing against the top of the refrigerator to
take the weight off the feet. Turn the leveling
legs lo kwise to raise the unit or
ounter lo kwise to lower it.
• Carpeting and soft tile surfa es are not
re ommended.
• Never install the refrigerator on a platform or
weakly supported stru ture.
NOTE: When moving the refrigerator for leaning
or servi e, be sure to prote t the floor. Always
pull the refrigerator straight out when moving it.
Do not wiggle or walk the refrigerator when trying
to move it; floor damage ould o ur.
HANDLE REMOVAL
To move the refrigerator through a house door, it
may be ne essary to remove the refrigerator
door handles.
NOTE: Handle appearan e may vary from
illustrations on this page.
wCAUTION
• Use spe ial are when removing handles to
prevent s rat hing the doors.
• The handle ould be damaged if you hit it with
a hammer while removing or atta hing.
• When you assemble or disassemble a handle,
you must push or pull with reasonable for e.
NOTE: It is re ommend that the doors be removed when it is ne essary to move the refrigerator through a
narrow opening.
Loosen the set s rews with a 2.5 mm (3/32")
Allen wren h and remove the handle.
NOTE: If the handle mounting fasteners need
to be tightened or removed, use a 1/4" Allen
wren h.
1 Loosen the set s rews lo ated on the lower
side of the handle with a 2.5 mm (3/32") Allen
wren h and remove the handle.
NOTE: If the handle mounting fasteners need
to be tightened or removed, use a 1/4" Allen
wren h.
2
Mounting
Fasteners
Set Screw
Allen Wrench

10
HANDLE REMOVAL (CONT.)
HANDLE REINSTALLATION
DOOR AND DRAWER REMOVAL
DOOR REMOVAL
wWARNING
Electric Shock Hazard
• Dis onne t ele tri al supply to the refrigerator
before installing. Failure to do so ould result in
death or serious injury.
• Do not put hands or feet or metal sti ks into the air
vents, base grille, or bottom of the refrigerator. You
may be injured or re eive an ele tri al sho k.
• Be areful when you work with the hinge, base
grille, and stopper. You may be injured.
Before you begin, remove food and bins from the
doors.
If your entran e door is too narrow for the refrigerator
to pass through, remove the refrigerator door and
move the refrigerator sideways through the doorway.
Pla e the handle on the door by aligning
handle footprints to fit mounting fasteners and
tighten the set s rews with a 2.5 mm (3/32 " )
Allen wren h.
NOTE: If the handle mounting fasteners need
to be tightened or removed use a 1/4 " Allen
wren h
1Pla e the handle on the door by aligning
handle footprints to fit mounting fasteners and
tighten the set s rews on the bottom of the
handle with a 2.5 mm (3/32 " ) Allen wren h.
NOTE: If the handle mounting fasteners need
to be tightened or removed use a 1/4 " Allen
wren h.
2
To remove the left refrigerator door:
Pull the water tube out of the fitting while
pressing the release ring on the fitting.
NOTE : When you pull out the tube, first you
have to push the ollet by opposite dire tion
of arrow in the upper pi ture and pull the tube
out by dire tion of arrow.
1
Mounting
Fasteners
Collet

11
DOOR AND DRAWER REMOVAL (CONT.)
DOOR REMOVAL (CONT.)
• Open the door. Remove the top hinge over
s rew (1 ).
• Use a flat-head s rewdriver to pry ba k the
hooks (not shown) on the front underside of
the over (2). Lift up the over.
• Remove the over. Pull out the tube (3).
• Dis onne t all the wire harnesses (4).
• Remove the grounding s rew(5)
• Rotate hinge lever (6) ounter lo kwise and
remove. Lift the top hinge (7) free of the
hinge lever lat h (8).
IMPORTANT: When lifting the hinge free of
the lat h, be areful that the door does not fall
forward.
• Lift the door from the middle hinge pin and
remove the door.
• Pla e the door, inside fa ing up, on a non-
s rat hing surfa e.
(1)
(2)
(4)
(3)
(6)
(7) (8)
(5)
2To remove the right refrigerator door:
• Open the door. Remove the top hinge over
s rew (1 ). Lift up the over (2).
• Remove the over.
• Dis onne t the wire harness (3).
• Rotate the hinge lever (4) lo kwise and
remove. Lift the top hinge (5) free of the
hinge lever lat h (6).
IMPORTANT: When lifting the hinge free of
the lat h, be areful that the door does not fall
forward.
• Lift the door from the middle hinge pin and
remove the door.
• Pla e the door, inside fa ing up, on a non-
s rat hing surfa e.
(1)
(2)
(4) (5)
(6)
(3)
3

12
DOOR AND DRAWER REMOVAL (CONT.)
DOOR REINSTALLATION
Install the right-side door first.
• Lower the door onto the middle hinge pin as
shown.
1• Fit the top hinge (1) over the hinge lever
lat h (2) and into pla e. Insert the hinge
lever (3) under the lever lat h. Rotate the
lever ounter lo kwise to se ure the hinge.
• Conne t the wire harness (4).
• Hook the tab on the door-swit h side of the
over (5) under the edge of the wire opening
in the abinet top. Position the over into
pla e. Insert and tighten the over s rew (6).
(3)
(2)
(1)
(6)
(5)
(4)
2
Install the left-side door.
• Lower the door onto middle hinge pin.
3• Fit the top hinge (1) over the hinge lever
lat h (2) and into pla e. Insert the hinge
lever (3) under the lever lat h. Rotate the
lever lo kwise to se ure the hinge.
• Install the grounding s rew (4) and onne t
all the wire harnesses (5).
(2)
(1)
(3)
(4) (5)
4

13
DOOR AND DRAWER REMOVAL (CONT.)
DOOR REINSTALLATION (CONT.)
• Push the water supply tube (6) into the hole
on the top ase and pull it through the
ba kplate.
(6)
5Insert the water supply tube into the
onne tor.
• Insert the tube at least 5/8 in. (15 mm) into
the onne tor.
• Hook the tab on the door-swit h side of the
over under the edge of the wire opening in
the abinet top. Position the over into
pla e. Insert and tighten the over s rew.
6
Cover Cover S rew
wCAUTION
1. Insert the tube until you an see only one of the lines printed on the tube.
2. After inserting, pull the tube to as ertain that it is se ure.
3. Assemble the lip.
Collet
Correct Incorrect
Insert Line
Clip
Tube

14
DOOR AND DRAWER REMOVAL (CONT.)
FREEZER DRAWER REMOVAL
wCAUTION
• To avoid possible injury or produ t or property
damage, you will need two people to perform the
following instru tions.
• When you remove the drawer, do not hold the
handle. It may ome off and ould ause injury.
• When laying the drawer down, be areful not to
damage the floor or hurt your feet with the sharp
edges on the hinge side.
w CAUTION: When you remove the drawer, do not hold the handle. If it may ome off and it ould ause personal injury.
w CAUTION: When laying the drawer down, be areful not to damage the floor or hurt your feet by the sharp edges on hinge side.
To remove the freezer drawer, pull the drawer
open to full extension. Remove the lower
DuraBase ® basket by lifting the basket from
the rail system.
1
Separate the left and right rail over2
With both hands, hold both sides of the door
and pull it up to separate it from the rails.
4With both hands, flex the enter bar enough
to allow the gears on both ends to release
from the tra k.
5
Remove the s rews of the rail on
both sides.
3

wWARNING: To prevent a idental hild and
pet entrapment or suffo ation risk.
DO NOT allow them to play inside
of drawer.
wWARNING: DO NOT step or sit down on freezer.
15
DOOR AND DRAWER REMOVAL (CONT.)
FREEZER DRAWER REINSTALLATION
wCAUTION
• To avoid possible injury or produ t or property
damage, you will need two people to perform the
following instru tions.
wDANGER
Risk of Child Entrapment
• To prevent a idental hild and pet entrapment
or suffo ation risk, DO NOT allow them to play
inside of the freezer drawer.
• DO NOT step or sit on the freezer drawer.
To reinstall the freezer drawer, hold the enter
bar with both hands and pull it out until both
rails are fully extended.
1Hook door supports (1) into rail tabs (2).
2
1
2
Lower door into final position and tighten the
s rews (3). Make sure you have a right rail
over for ea h side.
3
With the drawer pulled out to full extension,
insert the lower basket in the rail assembly.
5
Align the top holes of the rail over with the
top holes of the door supports to assemble
the rail overs.
4
Right
Rail Cover Assembly Hole
Left
Rail Cover

16
CONNECTING THE WATER SUPPLY
wWARNING
Connect to safe drinking water supply
only.
• The water pressure must be between 21 and
121 p.s.i. (1.5~8.5 kgf/ m2 ) on models without a
water filter and between 43 and 121 p.s.i.
(3~8.5 kgf/ m2) on models with a water filter.
• If water pressure does not rea h 21 psi
(1.5kgf/ m2) or falls below, it is ne essary to
pur hase a separate pressure pump for normal
automati i emaker and water dispensing
operation.
• It is re ommended that the total length of the
water feed tube does not ex eed 26 ft. (8 m).
• Install the water supply line where it will not be
affe ted by heat.
IMPORTANT: Read all dire tions thoroughly
before you begin.
• If operating the refrigerator before installing the
water onne tion, turn the i emaker to the OFF
position to prevent operation without water.
• All installations must be in a ordan e with lo al
plumbing ode requirements.
• Use opper tubing and he k for leaks.
• Install tubing only in areas where temperatures
will remain above freezing.
• It may take up to 24 hours for the i emaker to
begin produ ing i e.
Tools Required
• Standard s rewdriver
• 7/16-in. and 1/2-in. open-end wren hes or two
adjustable wren hes
• 1/4-in. nut driver
• 1/4-in. drill bit
• Hand drill or ele tri drill (properly grounded)
NOTE: Refrigerator dealers offer a kit with a 1/4-in.
saddle-type shutoff valve, a union, and opper
tubing. Before pur hasing, make sure a saddle-
type valve omplies with lo al plumbing odes.
Do not use a piercing-type or 3/16-in. saddle
valve which reduces water flow and clogs more
easily.
NOTE: The Commonwealth of Massa husetts
Plumbing Code 248CMR shall be adhered to.
Saddle valves are illegal and use is not permitted in
Massa husetts. Consult with your li ensed plumber.
Cold Water Supply
• The i emaker water valve ontains a flow washer
whi h is used as a water pressure regulator.
• The i emaker needs to be onne ted to a old
water line with water pressure between 21~121
psi (1.5~8.5 kgf/ m2) on models without a water
filter and between 43 and 121 p.s.i. (3~8.5kgf/ m2)
on models with a water filter.
CONNECTING THE WATER LINES
IMPORTANT: Before onne ting the tubing to
the water line, unplug the refrigerator or
dis onne t the power.
• Turn off the main water supply and open the
nearest fau et to relieve pressure in the line.
Opening an outside fau et may help drain
water from the line in the house.
• Find a 1/2-in. verti al COLD water pipe near
the refrigerator.
NOTE: A horizontal pipe will work, but the
following pre aution must be taken: drill on the
top of the pipe, not the bottom. This will help
keep water away from the drill and also keep
normal sediment from olle ting in the valve.
• To determine the length of opper tubing you
will need, measure from the onne tion on the
lower left rear of the refrigerator to the water
pipe. Add 7 ft. (2.1 m) to allow for moving the
refrigerator for leaning. Use 1/4-in. O.D.
(outside diameter) opper tubing. Be sure both
ends of the opper tubing are ut square.
• Using a drill, drill a 1/4-in. hole in the old water
pipe you have sele ted.

• Fasten the shutoff valve to the old water pipe
with the pipe lamp. Be sure the outlet end is
solidly in the 1/4-in. drilled hole in the water
pipe and the washer is under the pipe lamp.
Tighten the pa king nut. Tighten the pipe lamp
s rews arefully and evenly so the washer
makes a watertight seal. Do not overtighten or
you may rush the opper tubing, espe ially if
soft ( oiled) opper tubing is used. Now you are
ready to onne t the opper tubing.
• Slip the ompression sleeve and the
ompression nut onto the opper tubing as
shown. Insert the end of the tubing into the
outlet end squarely as far as it will go. S rew
the ompression nut onto the outlet end with a
wren h. A flare nut wren h works best, but an
open-end wren h will suffi e. Do not
overtighten.
• Pla e the free end of the tubing into a ontainer
or sink, and turn on the main water supply.
Flush out the tubing until the water is lear.
Turn off the shutoff valve on the water pipe.
Coil the opper tubing as shown below.
17
CONNECTING THE WATER LINES (CONT.)
IMPORTANT: Before onne ting the tubing to the
refrigerator, be sure the refrigerator power ord is
not plugged into the wall outlet.
NOTE: If your refrigerator is equipped with an
internal water filter, an external in-line water filter
should not be used.
• Remove the plasti flexible ap from the water
valve.
• Pla e the ompression nut and ferrule (sleeve)
onto the end of the tubing as shown.
• Insert the end of the opper tubing into the
onne tion as far as possible. While holding the
tubing, tighten the fitting.
IMPORTANT: Tighten any onne tions that leak.
Open the water at the shutoff valve.
• Plug in the refrigerator.
• Arrange the oil of opper tubing behind the
refrigerator so it does not vibrate against the
ba k of the refrigerator or against the wall.
• Che k for leaks.
• Before onne ting the water line to house, purge
house line for 2 minute.
NOTE: It may take a few se onds for water to
begin to flow as the internal tank fills and air lears
from the lines.
• Push the refrigerator ba k to the wall.
• Set the i emaker swit h to the ON position.
NOTE: The i emaker will not begin to operate until
it rea hes its operating temperature of 15°F (-9°C).
It will then begin operation automati ally.
NOTE: Throw away the first few bat hes of i e
(about 20 pie es).
Pa king
Nut
Shutoff
Valve
Compression
Sleeve
Compression
Nut
Cold Water Pipe
Pipe Clamp
Coil of Polyethelyne
or Copper Tubing
Ferrule
(Sleeve)
Refrigerator
Conne tion
Water
valve
Tubing
Clamp
1/4"
Tubing
1/4"
Compression
Nut

18
LEVELING THE REFRIGERATOR DOORS
wWARNING
Electrical Shock Hazard
• Be areful when you work with the hinges,
base grille, and stopper. You may be injured.
• Do not put hands, feet, or metal items into
the air vents, base grille, or the bottom of the
refrigerator. You may be injured or re eive
an ele tri al sho k.
Leveling
After installing, se ure the produ t with the LEG
not to move left or right.
Your refrigerator has two front leveling legs—
one on the right and one on the left. Adjust the
legs to alter the tilt from front to ba k or side to
side. If your refrigerator seems unsteady or you
want the doors to lose more easily, adjust the
refrigerator’s tilt using the following instru tions:
wCAUTION
• To avoid possible injury or produ t or property
damage, you will need two people to perform the
following instru tions.
Plug the power ord into a 3-prong grounded
outlet, and move the refrigerator into its final
position. Remove the ki k plate s rews and
then the ki k plate.
• Open the Freezer Drawer.
• On e the drawer is open, there is suffi ient
learan e to remove the s rews on top of
the ki k plate.
NOTE: To repla e the ki k plate, pla e it into
position, and then insert and tighten the
s rews.
1
Level the refrigerator by using an 11/32 in h
(8mm) wren h or a flat blade s rew driver.
Turn the leveling legs (CCW) to raise or (CW)
to lower the height of the front of the
refrigerator.
NOTE: The front of the refrigerator should be
slightly higher than the ba k.
NOTE: If someone pushes ba kward against
the top of the refrigerator, weight is lifted off of
the leveling legs, whi h makes adjustment
easier.
Open both doors to make sure they lose
easily. If not, raise the leveling legs higher by
turning both lo kwise the same amount.
On e the refrigerator is level, repla e the ki k-
plate.
NOTE: Your new refrigerator is uniquely
designed with two fresh food doors. Either
door an be independently opened or losed.
You will have to exert slight pressure on the
doors to lose them ompletely.
NOTE: In order not to move the refrigerator
ba k and forth, fix it with the 'Adjust' to the
floor to install and use.
2
Ki k Plate

19
LEVELING THE REFRIGERATOR DOORS (CONT.)
DOOR ALIGNMENT
STARTING
Before loading your refrigerator with fresh foods:
• Remove tape and any temporary labels from
your refrigerator before using. To remove any
remaining adhesive residue, rub the area briskly
with your thumb, or rub a small amount of liquid
dish soap over the adhesive with your fingers.
Wipe with warm water and dry. Do not use sharp
instruments, rubbing al ohol, flammable fluids,
or abrasive leaners to remove tape or glue.
NOTE: Do not remove any warning-type labels,
the model and serial number label, or the te h
sheet that is taped to the ba k of the refrigerator.
• Thoroughly lean your refrigerator and wipe off all
dust that may have a umulated during shipping.
• Install a essories su h as the i e ube bin,
drawers, and shelves, in their proper pla es.
They are pa ked together to prevent possible
damage during shipment.
• Adjust the desired temperature for the
refrigerator and freezer (see Adjusting the
Temperature and Fun tions).
• Let your refrigerator run for at least 2 or 3 hours
before putting food in it. Che k the flow of old
air in the freezer ompartment to ensure proper
ooling. Your refrigerator is now ready for use.
If the spa e between your doors is uneven,
follow the instru tions below to align the
doors:
• With one hand, lift up the door you want to
raise at middle hinge.
• With other hand, use pliers to insert snap
ring as shown.
• Insert additional snap rings until the doors
are aligned.
(Three snap rings are provided with the
refrigerator.)
1

20
CONTROL PANEL FEATURES
For omplete details on button fun tions, see pages 22–24.
LED DISPLAY
The LED display shows the temperature
settings, dispenser options, water filter,
door alarm, and lo king status messages.
ICE TYPE BUTTON
The ICE TYPE button is used to sele t Cubed I e or
Crushed I e.
FREEZER BUTTON
Press the FREEZER button to adjust the temperature
in the freezer ompartment.
NOTE: When pressed simultaneously with the
REFRIGERATOR button for more than five se onds,
the temperature display will hange from Fahrenheit
to Celsius or vi e versa.
REFRIGERATOR BUTTON
Press the REFRIGERATOR button to adjust the
temperature in the refrigerator ompartment.
NOTE: When pressed simultaneously with the
FREEZER button for more than five se onds, the
temperature display will hange from Fahrenheit to
Celsius or vi e versa.
ICE PLUS BUTTON
Press this button to turn on the ICE PLUS. feature,
whi h in reases i emaking apabilities up to about 20
per ent.
LIGHT/FILTER BUTTON
The LIGHT/FILTER button ontrols the lamp in the
dispenser.
The LIGHT/FILTER button resets the water filter
repla ement indi ator when the water filter has been
repla ed.
ALARM/LOCK BUTTON
Press this button to ontrol the door-open alarm.
Press this button to lo k or unlo k all the other
fun tion buttons on the ontrol panel, in luding
operation of the dispenser.
2
1
3
4
5
6
7
ICE TYPE
ICE TYPE
FREEZER
REFRIGERATOR
ICE PLUS
ALARM / LOCK 3SECS
LIGHT / FILTER
