OWNER'S MANUAL
SIDE BY SIDE
REFRIGERATOR
Read this owner's manual thoroughly before operating the
appliance and keep it handy for reference at all times.
ENGLISH
LS23C4000V
MFL71798896
Rev.00_082223
www.lg.com
Copyright © 2023 LG Electronics Inc. All Rights Reserved.
Scan to see the online manual.

TABLE OF CONTENTS
2
3 IMPORTANT SAFETY
INSTRUCTIONS
3 READ ALL INSTRUCTIONS BEFORE USE
3WARNING
6CAUTION
7 PRODUCT OVERVIEW
7 Product Features
10 INSTALLATION
10 Before Installing
11 Choosing the Proper Location
12 Removing/Assembling Doors
15 Leveling and Door Alignment
16 Turning on the Power
17 OPERATION
17 Before Use
18 Control Panel
19 Sabbath Mode
20 Icemaker
20 Storing Food
22 Drawers
22 Refrigerator Shelves
23 InstaView
23 Door-in-Door
23 Door Bins
25 SMART FUNCTIONS
25 LG ThinQ Application
27 Smart Grid Function
28 Smart DiagnosisTM Feature
30 MAINTENANCE
30 Cleaning
30 Air Filter
31 Deodorizer
33 TROUBLESHOOTING
33 FAQs
34 Before Calling for Service
39 LIMITED WARRANTY
39 USA
43 Canada

3IMPORTANT SAFETY INSTRUCTIONS
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
Safety Messages
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and
follow all safety messages.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury,
and tell you what may happen if the instructions are not followed.
WARNING
WARNING
• To reduce the risk of explosion, fire, death, electric shock, scalding or injury to persons when using this
product, follow basic precautions, including the following:
Installation
• To reduce the risk of injury to persons, adhere to all industry recommended safety procedures including
the use of long-sleeved gloves and safety glasses.
• Never attempt to operate this appliance if it is damaged, malfunctioning, partially disassembled, or has
missing or broken parts, including a damaged cord or plug.
• Only connect this product to a dedicated grounded electrical outlet rated for use with this product (115
V, 60 Hz, AC only). It is the user’s responsibility to replace a standard 2-prong wall outlet with a standard
3-prong wall outlet.
• Do not use an outlet that can be turned off with a switch. Do not use an extension cord.
• The appliance must be positioned for easy access to a power source.
• When moving the refrigerator, be careful not to roll over or damage the power cord.
• Contact an authorized service center when installing or relocating the refrigerator.
• Do not, under any circumstances, cut or remove the third (ground) prong from the power cord.
• Keep packing materials out of the reach of children. Packaging material can be dangerous for children.
There is a risk of suffocation.
• Do not install the refrigerator in a damp or dusty place where insulation on electrical parts may
deteriorate.
• Do not place the refrigerator in direct sunlight or expose it to the heat from heating appliances such as
stoves or heaters.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or injure you and others. All safety messages
will follow the safety alert symbol and either the word WARNING or CAUTION.
These words mean:
WARNING
You may be killed or seriously injured if you do not follow instructions.
CAUTION
You may be injured or cause damage to the product if you do not follow instructions.

4IMPORTANT SAFETY INSTRUCTIONS
• Do not bend or pinch the power cord excessively or place heavy objects on it.
• When positioning the appliance, ensure the supply cord is not trapped or damaged.
• Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance.
Operation
• This appliance is intended to be used in household and similar applications such as:
- staff kitchen areas in shops, offices and other working environments;
- farm houses and by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments;
- catering and similar non-retail applications.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
• This product is not to be used for special purposes such as the storage of medicine or test materials or
for use on ships, etc.
• DO NOT allow children to climb, stand, or hang on the refrigerator doors or on the shelves in the
refrigerator. They could damage the refrigerator and seriously injure themselves.
• Do not allow children to climb into the refrigerator. They could be trapped and suffocated.
• Children should be supervised to ensure that they do not play with the refrigerator.
• Keep fingers out of pinch point areas; clearances between the doors and cabinets are necessarily small.
Be careful closing doors when children are nearby.
• Do not touch frozen food or the metal parts in the freezer compartment with wet or damp hands. Doing
so may cause frostbite.
• Do not refreeze frozen food that has thawed completely. Doing so may result in a serious health hazard.
• Do not use an adapter plug or plug the power plug into a multi-outlet extension cord.
• If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly
qualified person in order to avoid a hazard.
• Do not operate the refrigerator or touch the power cord with wet hands.
• Do not modify or extend the power cord.
• Do not use an uncertified power outlet. Do not plug appliance into a damaged wall outlet.
• Do not put hands, feet or other objects into the air vents or bottom of the refrigerator. Doing so could
result in personal injury or electric shock.
• In the event of a gas leak (propane/LPG), ensure the area is adequately ventilated and contact an
authorized service center before resuming use. Do not touch the refrigerator or power cord of the
refrigerator.
• Disconnect the power cord immediately and contact an authorized service center if there is a strange
noise, odor, or smoke coming from the appliance.
• Do not use any fuse (such as copper, steel wire, etc.) other than a standard fuse.
• Do not put animals inside the appliance.
• Do not place heavy or fragile objects, liquid filled containers, combustible substances, or flammable
objects (such as candles and lamps) on the appliance.
• If connected to a circuit protected by fuses, use time delay fuse.
• Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.
• Do not use mechanical devices or other means to accelerate the defrosting process, other than those
recommended by the manufacturer.
• Do not use electrical appliances inside the food storage compartments of the appliance, unless they are
of the type recommended by the manufacturer.

5IMPORTANT SAFETY INSTRUCTIONS
ENGLISH
• Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.
• Do not damage the refrigerant circuit.
• This appliance incorporates an earth connection for functional purposes.
• Connect to potable water supply only.
- If connected to a water supply, connect to a potable water supply only.
• Fill with potable water only.
- If using an icemaker or dispenser water tank, make sure to fill it with potable water only.
Maintenance
• Do not use a hair dryer to dry the inside of the refrigerator.
• Do not light a candle to remove odors in the refrigerator.
• In the event of a refrigerant leak, move flammable objects away from the refrigerator. Ensure the area is
adequately ventilated and contact an authorized service center.
• Keep flammable materials and vapors, such as gasoline, away from the refrigerator.
• Unplug the power plug before cleaning or repairing the refrigerator.
• The refrigerator and freezer compartment lights are interior LED lighting, and service should be
performed by a qualified technician.
• Unplug the power plug immediately in the event of a blackout or thunderstorm.
• Turn the power off if water or dust penetrates into the refrigerator. Call a service agent.
• Do not store glass containers or soda in the freezer compartment. Contents may expand when frozen,
break the container and cause injury.
• Do not store, disassemble or repair the appliance yourself or allow unqualified personnel to do so.
Disposal
• Risk of child entrapment. Junked or abandoned refrigerators are dangerous, even if they are sitting for
only a few days. When disposing of the refrigerator, remove the packing materials from the door or take
off the doors but leave the shelves in place so that children may not easily climb inside.
• If disposing of a refrigerator, make sure the refrigerant and insulation foam are removed for proper
disposal by a qualified servicer. If you release the refrigerant or throw away the insulation foam, you
may be fined or imprisoned in accordance with the relevant environmental law. Insulation foam contains
flammable blowing gas.
• When discarding the appliance, remove the door gasket while leaving the shelves and bins in place, and
keep children away from the appliance.
Grounding Instructions
• Improper connection of the equipment-grounding conductor can result in a risk of electric shock. Check
with a qualified electrician or service personnel if you are in doubt whether the appliance is properly
grounded. Do not modify the plug provided with the appliance; if it will not fit the outlet, have a proper
outlet installed by a qualified electrician.
• Have a certified electrician check the wall outlet and wiring for proper grounding.
• Never unplug the appliance by pulling on the power cord. Always grip the plug firmly and pull straight
out from the outlet. Failure to do so may damage the power cord, resulting in a risk of fire and electric
shock.

6IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
Risk of Fire and Flammable Materials
CAUTION
CAUTION
• To reduce the risk of minor or moderate injury to persons, malfunction, or damage to the product or
property when using this product, follow basic precautions, including the following:
Installation
• Do not install the refrigerator where there may be a danger of the unit falling.
• The refrigerator must be properly installed in accordance with the Installation Instructions.
• This appliance does not require changes in installation or use based on altitude.
Operation
• Do not use aerosols near the refrigerator.
• This appliance is intended to be used only in domestic and similar applications.
• Do not strike or apply excessive force to any glass surface. Do not touch glass surfaces if they are
cracked or broken. You may be injured.
• Do not overfill or pack items too tightly into door bins. Doing so may cause damage to the bin or
personal injury if items are removed with excessive force.
Maintenance
• Do not use strong detergents like wax or thinners for cleaning. Clean with a soft cloth.
• Remove foreign objects (such as dust and water) off the prongs of the power plug and contact areas. Do
not use a wet or damp cloth when cleaning the plug.
• Do not spray water directly on the inside or outside of the refrigerator.
• Do not clean glass shelves or covers with warm water when they are cold. They may break if exposed to
sudden temperature changes.
This symbol alerts you to flammable materials that can ignite and cause a fire if you do not
take care.
This appliance contains a small amount of isobutane refrigerant (R600a), which is combustible.
When transporting and installing the appliance, care should be taken to ensure that no parts
of the refrigerating circuit are damaged. Refrigerant squirting out of the pipes could ignite or
cause an eye injury. If a leak is detected, avoid any naked flames or potential sources of
ignition and air out the room in which the appliance is standing for several minutes.
In order to avoid the creation of a flammable gas air mixture if a leak in the refrigerating
circuit occurs, the size of the room in which the appliance may be sited depends on the
amount of refrigerant used. The room must be 10.8 square feet (1 square meter) in size for
every 8g of R600a refrigerant inside the appliance. The amount of refrigerant in your
particular appliance is shown on the identification plate inside the appliance. Never start up an
appliance showing any signs of damage. If in doubt, consult your dealer.

7PRODUCT OVERVIEW
ENGLISH
PRODUCT OVERVIEW
Product Features
The images in this guide may be different from the actual components and accessories, which are subject
to change by the manufacturer without prior notice for product improvement purposes.
Exterior
† This feature is only available on some models.
aDoor-in-Door†
This is a convenient storage area for frequently-used items that require easy access.
bDoor-in-Door Lever†
Opens Door-in-Door.
cInstaView Door-in-Door†
The InstaView Door-in-Door compartment allows for easy access to commonly used food items.
dInstaView†
Knock twice on the glass to turn the LED light inside the InstaView on or off.

8PRODUCT OVERVIEW
Interior
† This feature is only available on some models.
aLED Interior Lighting
Lights up the inside of the refrigerator.
bTemperature Sensor†
This sensor senses the temperature of the fridge compartment.
• Leave space between the sensor and food so the sensor can accurately sense the air temperature.
cFreezer Shelf
Stores frozen food such as meat, fish, and ice cream.
dIcemaker†
Manually produces and stores ice.
eFreezer Drawer†
Stores frozen food for longer storage.
fFreezer Door Bin
Stores small packages of frozen food. Do not store ice cream or food which will be stored for a long
period of time.
gRefrigerator Shelf
Stores refrigerated foods and fresh foods.
• Store foods with higher moisture content at the front of the shelf.
• The shelf height can be adjusted by inserting the shelf in another groove at a different height.
• The actual number of shelves will differ from model to model.
hBottle Rack†
Stores containers and tall bottles.

9PRODUCT OVERVIEW
ENGLISH
CAUTION
• Do not store short bottles or containers. The items may fall and cause an injury or appliance damage.
iSnack Drawer†
Stores commonly used food items such as beverages and snacks.
jDoor-in-Door Compartment†
A convenient storage area for frequently-used items that require easy access.
kRefrigerator Door Bin
Stores small packages of refrigerated foods, drinks and sauce containers.
lRefrigerator Drawer
Stores fruits and vegetables to keep fresh for as long as possible.
mEgg Box†
Stores eggs.
• Do not use it to store ice or place it on the top shelf or in the drawer.
nBottom Drawer Cover
Cover for the bottom drawer.
CAUTION
• Do not store any items at the front of the bottom shelf. The items may fall and cause an injury or
appliance damage.
oControl Panel
Sets the refrigerator and freezer temperatures.
Product Specifications
The appearance and specifications listed in this manual may vary due to constant product improvements.
Electrical requirements: 115 V, 60 Hz
Model Description Net weight
LS23C4000V Standard-depth, Side by Side Refrigerator 234 lb (106 kg)

10 INSTALLATION
INSTALLATION
Before Installing
Installation Overview
Please read the following installation instructions first after purchasing this product or transporting it to
another location.
aUnpacking the Refrigerator
bChoosing the Proper Location
cDisassembling/Assembling
dLeveling and Door Alignment

11INSTALLATION
ENGLISH
Unpacking the Refrigerator
WARNING
• Use two or more people to move and install the
refrigerator. Failure to do so can result in back
injury or other injury.
• The refrigerator is heavy. Protect the floor when
moving the refrigerator for cleaning or service.
Always pull the refrigerator straight out when
moving it. Do not wiggle or walk the refrigerator
when trying to move it, as floor damage could
occur.
• Keep flammable materials and vapors, such as
gasoline, away from the refrigerator. Failure to
do so can result in fire, explosion, or death.
NOTE
• Remove tape and any temporary labels from
your refrigerator before using. Do not remove
any warning labels, the model and serial number
label, or the Tech Sheet that is located under the
front of the refrigerator.
• To remove any remaining tape or glue, rub the
area briskly with your thumb. Tape or glue
residue can also be easily removed by rubbing a
small amount of liquid dish soap over the
adhesive with your fingers. Wipe with warm
water and dry.
• Do not use sharp instruments, rubbing alcohol,
flammable fluids, or abrasive cleaners to remove
tape or glue. These products can damage the
surface of your refrigerator.
• Reinstall or adjust shelves as needed.
Refrigerator shelves are installed in the shipping
position. Reinstall shelves according to your
individual storage needs.
Choosing the Proper
Location
Electricity
Use an individual, grounded outlet:115 Volts, 60
Hz, AC, 15 amps minimum.
WARNING
• Do not overload house wiring and cause a fire
hazard by plugging in multiple appliances in the
same outlet with the refrigerator.
• To reduce the risk of electric shock, do not install
the refrigerator in a wet or damp area.
Flooring
To avoid noise and vibration, the unit must be
installed and leveled on a solidly constructed floor.
If required, adjust the leveling legs to compensate
for the unevenness of the floor.
NOTE
• Installing on carpeting, soft tile surfaces, a
platform or weakly supported structure is not
recommended.
Ambient Temperature
Install this appliance in an area where the
temperature is between 55 °F (13 °C) and 110 °F
(43 °C).
If the temperature around the appliance is too low
or high, cooling ability may be adversely affected.
The internal temperatures could be affected by the
location of the appliance, the ambient
temperature, the frequency of door opening and
other factors.

12 INSTALLATION
Dimensions and Clearances
• Check the dimensions of the appliance and the installation path to ensure there is sufficient room to
move the refrigerator through doors or narrow openings.
• If an opening is too narrow to fit the refrigerator through, remove the refrigerator doors. See Removing/
Assembling the Doors and Drawers in this manual.
• The installation location chosen for the refrigerator should allow space behind the unit for connections
and airflow and space in front to open the doors and drawers.
• Too small of a distance from adjacent items may result in lowered freezing capability and increased
electricity consumption charges. Allow at least 2 inches (50 mm) between the back of the refrigerator
and the wall.
• Remember to allow enough room in front of the refrigerator to fully open the doors and drawers.
Removing/Assembling
Doors
If the entrance door is too narrow for the
refrigerator to pass through, remove the
refrigerator doors and move the refrigerator
sideways through the doorway.
CAUTION
• Use two or more people to remove and install
the refrigerator doors.
• Disconnect the electrical supply to the
refrigerator before installing.
• Do not put hands, feet or other objects into the
air vents or bottom of the refrigerator.
• Be careful when handling the hinge and hinge
lever.
• Remove food and bins before detaching the
doors.
• Do not hold the handle when removing or
replacing the doors as the handle may come off.
• Tools Needed
- Flat-head screwdriver
- Phillips screwdriver
-Dimension/Clearance LS23C4000V
A Depth without Handle 28 7/8" (735 mm)
B Width 36" (913 mm)
C Height to Top of Case 68 7/8" (1750 mm)
D Height to Top of Hinge 70 1/2" (1790 mm)
E Back Clearance 2" (50 mm)
F Depth without Door 24 3/8" (620 mm)
G Depth (Total with Door Closed) 28 7/8" (735 mm)
H Depth (Total with Door Open 90°) 46 1/2" (1180 mm)
B
A
CD
FH
E
G

13INSTALLATION
ENGLISH
Removing the Hinge Cover
Remove the screws from the hinge cover at the top
of the refrigerator. Lift the hook (not visible),
located at the bottom of the front side of the cover
with a flat-head screwdriver.
Removing the Freezer Door
1 Disconnect all the wire harnesses a. Unscrew
the ground wire b.
NOTE
• The number of wire harnesses may vary
depending on the model.
• Ground wire is only present on some models.
2 Rotate the hinge lever ecounterclockwise.
Lift the top hinge dfree of the hinge lever
latch c.
CAUTION
• When lifting the hinge free of the latch, be
careful that the door does not fall forward.
3 Lift the door from the bottom hinge pin f
and place it, inside facing up, on a non-
scratching surface.
Removing the Refrigerator Door
1 Detach all the wire harnesses a. Unscrew the
ground wire b.
NOTE
• The number of wire harnesses may vary
depending on the model.
• Ground wire is only present on some models.
2 Rotate the hinge lever cclockwise. Lift the
top hinge dfree of the hinge lever latch e.
CAUTION
• When lifting the hinge free of the latch, be
careful that the door does not fall forward.

14 INSTALLATION
3 Lift the door from the bottom hinge pin f.
4 Place the door, inside facing up, on a non-
scratching surface.
Assembling the Refrigerator Door
1 Place the door onto the bottom hinge pin a.
2 Fit the hinge bover the hinge lever latch c
and slot it into place. Rotate the lever d
counterclockwise to secure the hinge.
NOTE
• Align the refrigerator door with the cabinet to
help fit the top hinge in place.
3 Connect all the wire harnesses e. Screw in
the ground wire f.
NOTE
• The number of wire harnesses may vary
depending on the model.
• Ground wire is only present on some models.
Assembling the Freezer Door
1 Install the freezer door onto the bottom hinge
pin a.
2 Fit the hinge bover the hinge lever latch c
and slot it into place. Rotate the lever d
clockwise and fasten the hinge.
NOTE
• Align the freezer door with the cabinet to help fit
the top hinge in place.
3 Connect all the wire harnesses and the
ground wire.

15INSTALLATION
ENGLISH
NOTE
• The number of wire harnesses may vary
depending on the model.
• Ground wire is only present on some models.
Assembling the Hinge Cover
Position the hinge cover in its place. Insert and
tighten the cover screws.
Leveling and Door
Alignment
Leveling
The refrigerator has two front leveling legs. Adjust
the legs to alter the tilt from front-to-back or side-
to side. If the refrigerator seems unsteady, or the
doors do not close easily, adjust the refrigerator’s
tilt using the instructions below:
1 Turn the leveling leg to the left to raise that
side of the refrigerator or to the right to lower
it. It may take several turns of the leveling leg
to adjust the tilt of the refrigerator.
NOTE
• A flare nut wrench works best, but an open-end
wrench will suffice. Do not over-tighten.
2 Open both doors and check to make sure that
they close easily. If the doors do not close
easily, tilt the refrigerator slightly more to the
rear by turning both leveling legs to the left. It
may take several more turns, and be sure to
turn both leveling legs the same amount.
Door Alignment
Both the left and right refrigerator doors have an
adjustable nut, located on the bottom hinge, to
raise and lower them to align properly.
If the space between the doors is uneven, follow
the instructions below to align the doors evenly:
Use the wrench (included with the owner's
manual) to turn the nut in the door hinge to adjust
the height.
1 Open the door and use the wrench to loosen
the keeper nut by turning it to the left.
2 Use the wrench to adjust the height by
turning the adjustment hinge pin to the right
to raise the door or to the left to lower it.

16 INSTALLATION
3 Use the wrench to fasten the keeper nut by
turning it to the right.
CAUTION
• Do not overtighten the door adjustment screw.
The hinge pin can be pulled out and the
adjustable range of height is a maximum of 1/8"
(3 mm).
Turning on the Power
• After installing, plug the refrigerator’s power
cord into a 3-prong grounded outlet and push
the refrigerator into the final position.
CAUTION
• Connect to a rated power outlet.
• Have a certified electrician check the wall outlet
and wiring for proper grounding.
• Do not damage or cut off the ground terminal of
the power plug.
Position the Refrigerator
• If the refrigerator is connected to water, arrange
the coil of tubing so that it does not vibrate
against the back of the refrigerator or against
the wall. Push the refrigerator back toward the
wall, leaving adequate clearance.

17OPERATION
ENGLISH
OPERATION
Before Use
Checklist
Clean the refrigerator.
Clean the refrigerator thoroughly and wipe off all dust that accumulated
during shipping.
CAUTION
• Do not scratch the refrigerator with a sharp object or use a detergent that
contains alcohol, a flammable liquid or an abrasive when removing any
tape or adhesive from the refrigerator. Remove adhesive residue by wiping
it off with your thumb or dish detergent.
• Do not peel off the model or serial number label or the technical
information on the rear surface of the refrigerator.
Open doors and drawers to ventilate the interior.
The inside of the refrigerator may smell like plastic at first. Remove any
adhesive tape from inside the refrigerator and open the refrigerator doors
and drawers for ventilation.
Connect the power supply.
Check if the power supply is connected before use.
Turn off the icemaker.
Turn off the icemaker if the refrigerator is not yet connected to the water
supply.
NOTE
• The icemaker water valve may buzz if the icemaker is turned on while the
refrigerator is not connected to the water supply.
Wait for the refrigerator to cool.
Allow the refrigerator to run for at least two to three hours before putting
food in it. Check the flow of cold air in the freezer compartment to ensure
proper cooling.
CAUTION
• Putting food in the refrigerator before it has cooled could cause the food to
spoil, or a bad odor to remain inside the refrigerator.
The refrigerator makes a loud noise after initial operation.
This is normal. The volume will decrease as the temperature decreases.

18 OPERATION
Control Panel
Depending on the model, some of the following functions may not be available.
The actual control panel may differ from model to model.
Control Panel Features
aRefrigerator
Indicates the set temperature of the refrigerator compartment in Celsius (℃) or Fahrenheit (℉). The
default refrigerator temperature is 37 ℉(3 ℃). Press the Refrigerator button repeatedly to select a
new set temperature from 33 ℉to 43 ℉(1 ℃to 7 ℃).
NOTE
• To change the temperature mode from ℉to ℃(or vice versa) press and hold the Refrigerator and
Freezer buttons simultaneously for approximately five seconds. The temperature indicator on the
display window switches between Celsius and Fahrenheit.
• The displayed temperature is the target temperature, and not the actual temperature of the refrigerator.
The actual refrigerator temperature depends on the food inside the refrigerator.
bFreezer
Indicates the set temperature of the freezer compartment in Celsius (℃) or Fahrenheit (℉). The default
freezer temperature is 0 ℉(-18 ℃). Press the Freezer button repeatedly to select a new set
temperature from - 7 ℉to 5 ℉(-23 ℃to -15 ℃).

19OPERATION
ENGLISH
cAir Filter
The air filter helps remove odors from the refrigerator.
NOTE
• Replace the air filter when the air filter indicator turns on. After replacing the air filter, press and hold the
Air Filter button for 3 seconds to turn the indicator off. Replace the air filter approximately every six
months.
dWi-Fi
The Wi-Fi button, when used with the LG ThinQ app, allows the refrigerator to connect to a home Wi-Fi
network. Refer to Smart Functions for information on the initial setup of the application.
The Wi-Fi indicator shows the status of the refrigerator's network connection. The indicator illuminates
when the refrigerator is connected to the Wi-Fi network.
Press and hold the Wi-Fi button for 3 seconds to connect to the network. The indicator blinks while the
connection is being made and then turns on once the connection is successfully made.
eSmart Grid
Press the Smart Grid button to turn the function On/Off. When the function is on, the indicator
illuminates. The function automatically turns on when the refrigerator is connected to the Wi-Fi
network. The Smart Grid function is only available if your electric utility company supports the function.
fGrid On
When the refrigerator is responding to a Demand Response (DR) message from the electric company,
the Grid On indicator illuminates.
gIce Plus
This function increases both ice making and freezing capabilities.
•PresstheIce Plus button to illuminate the indicator and activate the function for 24 hours. The
function automatically shuts off after 24 hours.
• Stop the function manually by pressing the button once more.
hLock
The lock function disables every other button on the display.
• When power is initially connected to the refrigerator, the lock function is off.
• To lock the control panel buttons, press and hold the Lock button until the indicator appears in the
display and the function is activated.
• To disable the function, press and hold the Lock button for approximately three seconds.
Sabbath Mode
Using the Sabbath Mode
Sabbath mode is used on the Jewish Sabbath and
Holidays.
• To turn Sabbath mode on, touch the display to
activate it, then press and hold the Freezer and
Wi-Fi buttons for 3 seconds until sb appears in
the display.
• To turn Sabbath mode off manually, press and
hold the Freezer and Wi-Fi buttons for 3
seconds.
NOTE
• Sabbath mode automatically turns off after 96
hours.
• Once turned on, Sabbath mode is maintained
even after a power outage.
• Selecting Sabbath mode automatically turns off
the alarm functions.
• The dispenser and InstaView are disabled in
Sabbath mode, on applicable models.

20 OPERATION
Icemaker
Before Using the Icemaker
WARNING
• Fill the icemaker or dispenser water tank with
potable water only.
NOTE
• The icemaker produces ice normally once
approximately 48 hours have passed after the
appliance is initially installed.
• If half-frozen ice is put into the ice storage bin, it
will cause the exiting ice cubes to lump together.
It takes about 4 hours at -4 ℉(-20 ℃) for ice
production.
• If the freezer door is frequently opened, warm
air enters the freezer compartment. It may take
a longer time to freeze ice.
• Be careful not to twist the icemaker with force or
it may break.
• Do not freeze the ice in the ice storage bin. This
could break it and cause appliance damage or
injury.
Using the Icemaker
† This feature is only available on some models.
Icemaker Type A†
1 Hold the handle of ice tray and pull it out.
2 Fill the ice tray with potable water up to the
water line.
3 Place the ice tray back in position carefully.
4 Rotate the icemaker handle clockwise.
5 To use the ice, lift the ice storage bin slightly
to remove it.
Icemaker Type B†
1 Fill the ice tray with potable water and place it
in the freezer compartment.
2 After the water is frozen, hold the ice tray at
its ends and twist gently.
NOTE
• You can remove the icemaker or ice storage bin
to create more space inside the freezer if you do
not use it.
Storing Food
NOTE
• If you are leaving home for a short period, like a
short vacation, the refrigerator should be left on.
Refrigerated foods that are able to be frozen will
stay preserved longer if stored in the freezer.
