LG NP3530 User manual
Wireless Speaker
NP3530
ENGLISH OWNER’S MANUAL
Please read this manual carefully before operating your set and retain it
for future reference.
Product Overview Charging Bluetooth Connection
App Installation
Using handsfree function About LED Indicator Additional Information
Press and hold to turn on or o.
Note
Operating time is approx. 15 hours. (Based on 30% volume, 1kHz
signal, 500 mV portable input and fully charged status)
It may vary depending on the battery status and operational
conditions.
Press and hold to disconnect.
Within 10 m Select “LG Portable(XX:XX)”on your Bluetooth device.
(XX:XX means the last four digits of BT address.)
yDepending on the bluetooth device, you need to enter the PIN code (0000).
yOnce a pairing operation is performed, it does not need to be performed
again every time you turn on the unit. (Only if the PORT.IN is not connected
and the unit is registered on the Bulutooth device.)
To use this unit more comfortably, install “LG Bluetooth Remote”on
your bluetooth devices. Select a way of installation ( , or ).
Searching for“LG Bluetooth Remote” on the
Google Play Store.
Scanning QR code below.
Tagging on the NFC sticker, if available.
Press to hang up the call.
Press and hold to reject an incoming call.
Press and hold to toggle the voice output.
Preparation: Your smartphone must be paired with the unit via bluetooth.
Press to accept an incoming call.
Turned on red Turned on white Turned o Beep sound
X 2
X 2
In Charging Fully Charged (Power O mode)
X 2
X 2
In Charging Fully Charged (Power On mode)
X 2
X 2
Power is turned on.
X 2
X 2
Bluetooth is paired.
X 2
X 2
Battery is discharged. (Blinks rapidly.)
X 2
X 2
A button is pressed.
X 2
X 2
The unit operates abnormally. Leave the unit at room temperature (0 - 35 °C) for a while and try again.
In case that the unit freezes due to malfunction, press the reset
hole for 5 seconds using an object like a thin pin.
Reset hole
Resetting
LG Bluetooth Remote
Scan to install the App.
Notice for Auto Power Off
This unit is turned o automatically, if no button is pressed for 6
hours when the bluetooth is disconnected.
Press and hold to turn on the unit.
NFC for Easy Pairing: You can pair simply and easily by
tagging on the NFC sticker.
ON
Approx. 3 hours
LG Customer Information Center
1-800-243-0000 USA, Consumer
1-888-865-3026 USA, Commercial
Register your product Online!
www.lg.com
Wired Connection
Note: When bluetooth device is connected without BT remote
App, PORT. IN connection does NOT work.
About Ferrite Core (Optional)
How to attach the ferrite core
This ferrite core can reduce noises.
1. Pull the stopper [a] of the ferrite core to open.
2. Wind the portable cable and USB cable on the ferrite core.
3. Close the ferrite core until it clicks.
Printed in Indonesia
http://www.lg.com
5 V 02.0 A
Safety Information
NP3530-B0_BUSALLK_OM_MFL67786219_20130328.indd 1 2013-03-28 �� 6:23:35
Specification
Power Supply:
-5 V 02.0 A (AC Adapter)
-Built-in rechargeable battery
AC Adaptor:
-Model: WB-10A05FU
-Manufacturer: Yang Ming Industrial
-Input: AC100-240 V, 50/60 Hz
-Output: 5 V 02.0 A
Dimensions (W x H x D): Approx. 193 mm x 65 mm x 65 mm
Net Weight: Approx. 520 g
Operating Temperature: 0 °C to 35 °C
Operating Humidity: 5 % to 60 %
External Connector:
-ø 3.5 mm mini jack
-Micro USB port for charging battery
Communication: Bluetooth 3.0
Amplier:
-3 W + 3 W (8 Ω at 1 kHz)
-THD: 10%
Speaker:
-Type : Built-in
-Impedance Rate : 8 Ω
-Rated Input Power : 3 W
-Max. Input Power : 6 W
Android O/S for App installation:
-Version 2.3.3 (or higher)
yDesign and specications are subject to change without notice.
Troubleshooting
No power
yThe battery is discharged. Recharge the battery.
yConnect the unit to the power supply with the AC adapter
No sound or sound distortion
yThe unit or your smart device’s volume is set to minimum. Check and adjust the
volume of the unit or bluetooth device’s volume.
yWhen you use an external device at high volume, the sound quality may be
deteriorated. Lower the volume of the devices.
yIf you use the unit for purposes other than listening to music, the sound quality may
be lowered or the unit may not work properly.
Bluetooth pairing does not work well.
ySwitch bluetooth o and on again on your bluetooth device, then try pairing again.
yBe sure your bluetooth device is on.
yRemove the obstacle in the path of the bluetooth device and the unit.
yDepending on the type of the bluetooth device or surrounding environment, your
device may not be paired with the unit.
yWhile using Bluetooth, you may not be able to activate BT app. Disconnect
Bluetooth device you have connected before to use BT app properly.
yWhen your Bluetooth device have been already connected with other unit,
disconnect the Bluetooth connection rst. Then you can control your unit through
BT app.
yDepending on the Bluetooth device, BT app may work restrictively not work.
yThe connection you’ve made may be disconnected if you select other application
or change the setting of the connected device via BT app. In such case, please
check the connection status.
The unit does not operate normally.
yIn case of malfunction, LED indicator is lit in red and white alternately. Please use
the unit in proper place where the temperature or humidity is not so high or low.
Safety Information
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER
(OR BACK) NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
This lightning ash with arrowhead symbol within an equilateral
triangle is intended to alert the user to the presence of
uninsulated dangerous voltage within the product’s enclosure
that may be of sucient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature
accompanying the product.
WARNING:
yTo prevent re or electric shock hazard, do not expose this product to rain or
moisture.
yDo not install this equipment in a conned space such as a book case or similar
unit.
WARNING:
This product contains chemicals known to the State of California to cause
cancer and birth defects or other reproductive harm.
Wash hands after handling.
CAUTION:
yThe apparatus should not be exposed to water (dripping or splashing) and no
objects lled with liquids, such as vases, should be placed on the apparatus.
yNo naked ame sources, such as lighted candles, should be placed on the
apparatus.
yInternal lithium battery in the unit should not be replaced by user because of
danger of explosion if battery is incorrectly replaced ,and must be replaced with the
same type battery by expert.
yOnly use the AC adaptor supplied with this device. Do not use a power supply from
another device or another manufacturer. Using any other power cable or power
supply may cause damage to the device and void your warranty.
yTo avoid re or electric shock, do not open the unit. contact to qualied personnel
only.
yDo not leave the unit in a place near the heating appliances or subject to direct
sunlight, moisture, or mechanical shock.
yTo clean the unit, use a soft, dry cloth. If the surfaces are extremely dirty, use a soft
cloth lightly moistened with a mild detergent solution. Do not use strong solvents
such as alcohol, benzine, or thinner, as these might damage the surface of the unit.
yDo not use volatile liquids such as insecticide spray near the unit.Wiping with
strong pressure may damage the surface. Do not leave rubber or plastic products in
contact with the unit for a long period of time.
yDo not place the unit over the vehicle’s air bag. When the air bag deploys, it may
result in injury. Before using in the car, x the unit.
yDo not use the handsfree function during driving a car.
yDo not leave the unit on an unstable place such as high shelves. It may fall down
because of the vibration of the sound.
CAUTION concerning the Power Cord
Most appliances recommend they be placed upon a dedicated circuit;
That is, a single outlet circuit which powers only that appliance and has no additional
outlets or branch circuits. Check the specication page of this owner’s manual to be
certain. Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall
outlets, extension cords, frayed power cords, or damaged or cracked wire insulation
are dangerous. Any of these conditions could result in electric shock or re. Periodically
examine the cord of your appliance, and if its appearance indicates damage or
deterioration, unplug it, discontinue use of the appliance, and have the cord replaced
with an exact replacement part by an authorized service center. Protect the power cord
from physical or mechanical abuse, such as being twisted, kinked, pinched, closed in
a door, or walked upon. Pay particular attention to plugs, wall outlets, and the point
where the cord exits the appliance. To disconnect power from the mains, pull out the
mains cord plug. When installing the product, ensure that the plug is easily accessible.
This device is equipped with a portable battery or accumulator.
Safety way to remove the battery or the battery from the equipment: Remove
the old battery or battery pack, follow the steps in reverse order than the assembly.
To prevent contamination of the environment and bring on possible threat to human
and animal health, the old battery or the battery put it in the appropriate container at
designated collection points. Do not dispose of batteries or battery together with other
waste. It is recommended that you use local, free reimbursement systems batteries and
accumulators. The battery shall not be exposed to excessive heat such as sunshine, re
or the like.
NOTICE: For safety making information including product identication and supply
ratings, please refer to the main label on the bottom of the apparatus.
FCC Compliance Statement
This device complies with part 15 of the FCC rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment o and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
yReorient or relocate the receiving antenna.
yIncrease the separation between the equipment and receiver.
yConnect the equipment into an outlet on a circuit dierent from that to which
the receiver is connected.
yConsult the dealer or an experienced radio/TV technician for help.
CAUTION: Any changes or modications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment.
FCC WARNING: This equipment may generate or use radio frequency energy. changes
or modications to this equipment may cause harmful interference unless the
modications are expressly approved in the instruction manual. The user could lose the
authority to operate this equipment if an unauthorized change or modication is made.
FCC RF Radiation Exposure Statement: This equipment complies with FCC radiation
exposure limits set forth for an uncontrolled environment. This equipment should
be installed and operated with minimum distance 20 cm between the radiator and
your body. End users must follow the specic operating instructions for satisfying RF
exposure compliance.
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
CAUTION: Regulations of the FCC and FAA prohibit airborne operation of radio-
frequency wireless devices because their signals could interfere with critical aircraft
instruments.
Responsible Party :
LG Electronics USA, Inc. 1000 Sylvan Avenue Englewood Clis, NJ 07632
TEL. : +1-800-243-0000
Important Safety
Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manu-
facturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding
type plug has two blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided plug does not fit into
your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from the appa-
ratus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only the cart, stand, tripod, bracket, or table specified by the manufac-
turer, or sold with apparatus. When a cart is used, use caution when moving
the cart/ apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long peri-
ods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, such as power- supply cord or
plug is damaged, liquid has been spilled or objects have fallen into the appa-
ratus, the apparatus has been exposed to rain or moisture, does not operate
normally, or has been dropped.
NP3530-B0_BUSALLK_OM_MFL67786219_20130328.indd 2 2013-03-28 �� 6:23:36
Other LG Speakers manuals
