OWNER’S MANUAL
WIRELESS SPEAKER
NP6530
Please read this manual carefully before operating
your set and retain it for future reference.
www.lg.com
ENGLISH
ČEŠTINA
SIOVENČINA
ROMÂNĂ POLSKI MAGYAR HRVATSKI SRPSKI
БЪЛГАРСКИ
МАКЕДОНСКИ
NP6530-B0.BPOLLLK_ENG_MFL67789511.indd 1 2013-11-12  6:09:28

1 Getting Started
Getting Started2
Getting Started
1
Safety Information
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER (OR BACK) NO
USER-SERVICEABLE PARTS INSIDE REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
This lightning ash with arrowhead
symbol within an equilateral triangle
is intended to alert the user to the
presence of uninsulated dangerous
voltage within the product’s
enclosure that may be of sucient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an
equilateral triangle is intended
to alert the user to the presence
of important operating and
maintenance (servicing)
instructions in the literature accompanying the
product.
WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK
HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE.
WARNING: Do not install this equipment in a
conned space such as a book case or similar unit.
NOTICE: For safety marking information including
product identication and supply ratings, please
refer to the main label on the bottom of the
apparatus.
CAUTION concerning the Power Cord
Most appliances recommend they be placed upon
a dedicated circuit;
That is, a single outlet circuit which powers only
that appliance and has no additional outlets or
branch circuits. Check the specication page of this
owner’s manual to be certain. Do not overload wall
outlets. Overloaded wall outlets, loose or damaged
wall outlets, extension cords, frayed power cords, or
damaged or cracked wire insulation are dangerous.
Any of these conditions could result in electric
shock or re. Periodically examine the cord of your
appliance, and if its appearance indicates damage
or deterioration, unplug it, discontinue use of the
appliance, and have the cord replaced with an
exact replacement part by an authorized service
center. Protect the power cord from physical or
mechanical abuse, such as being twisted, kinked,
pinched, closed in a door, or walked upon. Pay
particular attention to plugs, wall outlets, and
the point where the cord exits the appliance. To
disconnect power from the mains, pull out the
mains cord plug. When installing the product,
ensure that the plug is easily accessible.
This device is equipped with a portable battery or
accumulator.
Safety way to remove the battery or the
battery from the equipment: Remove the
old battery or battery pack, follow the steps
in reverse order than the assembly. To prevent
contamination of the environment and bring on
possible threat to human and animal health, the
old battery or the battery put it in the appropriate
container at designated collection points. Do
not dispose of batteries or battery together with
other waste. It is recommended that you use
local, free reimbursement systems batteries and
accumulators. The battery shall not be exposed to
excessive heat such as sunshine, re or the like.
NP6530-B0.BPOLLLK_ENG_MFL67789511.indd 2 2013-11-12  6:09:28

Getting Started 3
Getting Started
1
CAUTION:
yThe apparatus should not be exposed to water
(dripping or splashing) and no objects lled with
liquids, such as vases, should be placed on the
apparatus.
yNo naked ame sources, such as lighted candles,
should be placed on the apparatus.
yInternal lithium battery in the unit should not be
replaced by user because of danger of explosion
if battery is incorrectly replaced, and must be
replaced with the same type battery by expert.
yOnly use the AC adapter supplied with this
device. Do not use a power supply from another
device or another manufacturer. Using any other
power cable or power supply may cause damage
to the device and void your warranty.
yTo avoid re or electric shock, do not open the
unit. contact to qualied personnel only.
yDo not leave the unit in a place near the heating
appliances or subject to direct sunlight, moisture,
or mechanical shock.
yTo clean the unit, use a soft, dry cloth. If the
surfaces are extremely dirty, use a soft cloth
lightly moistened with a mild detergent solution.
Do not use strong solvents such as alcohol,
benzine, or thinner, as these might damage the
surface of the unit.
yDo not use volatile liquids such as insecticide
spray near the unit. Wiping with strong pressure
may damage the surface. Do not leave rubber
or plastic products in contact with the unit for a
long period of time.
yDo not place the unit over the vehicle’s air bag.
When the air bag deploys, it may result in injury.
Before using in the car, x the unit.
yDo not use the handsfree function during driving
a car.
yDo not leave the unit on an unstable place such
as high shelves. It may fall down because of the
vibration of the sound.
Disposal of your old appliance
1. When this crossed-out wheeled bin
symbol is attached to a product it
means the product is covered by
the European Directive 2002/96/EC.
2. All electrical and electronic products
should be disposed of separately
from the municipal waste stream
via designated collection facilities
appointed by the government or
the local authorities.
3. The correct disposal of your
old appliance will help prevent
potential negative consequences
for the environment and human
health.
4. For more detailed information about
disposal of your old appliance,
please contact your city office,
waste disposal service or the shop
where you purchased the product.
NP6530-B0.BPOLLLK_ENG_MFL67789511.indd 3 2013-11-12  6:09:28

Getting Started4
Getting Started
1
Disposal of waste batteries/accumulators
1. When this crossed-out wheeled
bin symbol is attached to batteries/
accumulators of Your product
it means they are covered by
European Directive 2006/66/EC.
2. This symbol may be combined with
chemical symbols for mercury(Hg),
cadmium(Cd) or lead(Pb) if the
battery Contains more that 0.0005%
of mercury,0.002% of cadmium or
0.004% of lead.
3. All batteries/accumulators should
be disposed separately from
the municipal waste stream via
designated collection facilities
appointed by the government or
the local authorities.
4. The correct disposal of Your old
batteries/accumulators will help
to prevent potential negative
consequences for the environment,
animal and human health.
5. For more detailed information
about disposal of Your old batteries/
accumulators, please contact Your
city office, waste disposal service or
the shop where You purchased the
product.
LG Electronics hereby declares that this/these
product(s) is/are in compliance with the essential
requirements and other relevant provisions of
Directive 1999/5/EC, 2004/108/EC, 2006/95/EC,
2009/125/EC and 2011/65/EU.
Contact oce for compliance of this product:
LG Electronics Inc.
EU Representative, Krijgsman 1,
1186 DM Amstelveen, The Netherlands
yPlease note that this is NOT a Customer Service
contact point. For Customer Service Information,
see Warranty Card or contact the dealer that you
purchased this product.
In door use only.
RF Radiation Exposure Statement
This equipment should be installed and operated
with minimum distance 20 cm between the
radiator and your body.
NP6530-B0.BPOLLLK_ENG_MFL67789511.indd 4 2013-11-12  6:09:29
Please click HERE for DoC.

Table of Contents 5
1
2
3
4
Table of Contents
1 Getting Started
3 Safety Information
6 Main Features
6 Accessories
6 Introduction
7 Main Unit
8 Charging the Unit
8 – Connecting the AC adapter
8 – Checking the charging status
8 – Battery protection
2 Operating
9 Basic Operations
9 – Using power button
9 – Using volume button
9 Listening to Music from Your External
Device
10 – About ferrite core (Optional)
10 Using a Bluetooth Wireless Technology
10 – Listening to music of a bluetooth
device
12 – Using bluetooth app
14 Other Operations
14 – Using handsfree function
14 – Auto power down
14 – LG Tag On
15 – LG Sound Sync
3 Troubleshooting
16 Troubleshooting
16 – General
4 Appendix
17 About 1/! Button’s Condition
18 Trademarks and Licenses
18 Handling the Unit
19 Specifications
NP6530-B0.BPOLLLK_ENG_MFL67789511.indd 5 2013-11-12  6:09:29

Getting Started6
Getting Started
1
Main Features
Made for iPod/iPhone/iPad or
Android device
Enjoys music from iPod/iPhone/iPad or Android
device with simple connection.
Compatible iPod/iPhone/iPad models
iPhone 5, iPhone 4S, iPhone 4, iPhone 3GS, iPad (3rd
and 4th generation), iPad 2, iPad, iPad mini, iPod
touch (3rd through 5th generation),
AirPlay, iPad, iPhone, iPod nano, and iPod touch are
trademarks of Apple Inc., registered in the U.S. and
other countries. Lightning is a trademark of Apple
Inc.
Portable In
Listens to music from your portable device.
LG Sound Sync
Controls volume level of this unit by the remote
control of your LG TV that is compatible with LG
Sound Sync.
LG Bluetooth Remote
You can control this unit with your iPod touch/
iPhone/iPad or Android device via Bluetooth. This
unit and your device must be paired for Bluetooth.
Visit “Apple App Store”or “Google Android Market
(Google Play Store)” or use the QR code shown
below to search for “LG Bluetooth Remote”app. For
detailed information, refer to page 12.
(Apple iOS) (Android OS)
Accessories
Please check and identify the supplied accessories.
AC adapter (1) Power cord (1)
Portable Cable (1)
Introduction
Symbol used in this manual
, Note
Indicates special notes and operating features.
> Caution
Indicates cautions for preventing possible damages
from abuse.
NP6530-B0.BPOLLLK_ENG_MFL67789511.indd 6 2013-11-12  6:09:29

Getting Started 7
Getting Started
1
Main Unit
a 1/!
- Turns on / off : Press and hold
1/!
- Selects the function and input source.
b
+/- (Volume) : Adjusts speaker volume.
c
Phone button
d
Speaker
e
Microphone
fSOUND SYNC
Synchronizes this unit and your LG TV.
gReset hole
hDC IN (AC adapter input)
i
PORT.IN (3.5 mm)
Listens to music from your portable device.
j
NFC Tag (page 14)
Precautions in using the touch buttons
yUse the touch buttons with clean and dry
hands.
- In a humid environment, wipe out any
moisture on the touch buttons before using.
yDo not press the touch buttons hard to
make it work. - If you apply too much
strength, it can damage the sensor of the
touch buttons.
yTouch the button that you want to work in
order to operate the function correctly.
yBe careful not to have any conductive
material such as metallic object on the
touch buttons. It can cause malfunctions.
> Caution
NP6530-B0.BPOLLLK_ENG_MFL67789511.indd 7 2013-11-12  6:09:29

Getting Started8
Getting Started
1
Charging the Unit
Connecting the AC adapter
This device uses built-in battery. Before using it,
charge the battery by connecting the AC Adapter.
1. Connect the supplied AC power cord to the AC
adapter.
2. Connect the AC adapter cable to DC IN adapter
input.
3. Plug the AC power cord into an AC outlet.
AC Adapter
AC power cord
Only use the AC adapter supplied with this
device. Do not use a power supply from
another device or manufacturer. Using any
other power cable or power supply may cause
damage to the device and void your warranty.
> Caution
Checking the charging status
When AC Adapter is connected, battery charging
is started. You can check the charging status with
1/!
button. (Refer to the page 17 for details)
yCharging : The
1/!
button blinks red or white.
yFully charged : The
1/!
button turns red or
white.
Operating time is approx. 10 hours. (Based on
30% volume, 1kHz signal, 500 mV portable
input and fully charged status)
It may vary depending on the battery status
and operational conditions.
, Note
Battery protection
If AC adapter is connected and the unit is in high
or low temperature, the battery may not function
properly. Please reference the table below to fully
understand the battery protection feature.
In this case, use the unit in proper place where the
temperature or humidity is not so high or low.
Battery temperature : Very low
Power
O
(Red) (White)
Warning
Battery temperature : Very High
Power
On
(Red) (White) (O )
Blinks
10 sec
NP6530-B0.BPOLLLK_ENG_MFL67789511.indd 8 2013-11-12  6:09:30

2 Operating
Operating 9
Operating
2
Basic Operations
Using power button
Power On / Off
Power On / O: Press and hold the
1/!
button
Changing the mode
When turing on the unit, you can change the
mode. Press
1/!
button repeatedly, the mode is
changed with the voice sound.
(Portable In -> bluetooth -> Portable In)
You can enjoy the Sound Sync feature by
pressing SOUND SYNC button. Refer to page
15
, Note
Using volume button
You can adjust speaker volume. When you touch
the volume button, the
1/!
button blinks twice in
white color.
While adjusting volume if you try to increase
the volume when it is already at maximum
level, a beep is played on the unit.
, Note
Listening to Music
from Your External
Device
The unit can be used to listen to the music from
many types of external device.
MP3 or PMP etc
1. Connect the external device to the PORT.IN
connector of the unit.
2. Turn the power on by pressing
1/!
button.
3. Press
1/!
button repeatedly to select portable
in mode.
4. Turn the external device on and start playing.
NP6530-B0.BPOLLLK_ENG_MFL67789511.indd 9 2013-11-12  6:09:30

Operating10
Operating
2
About ferrite core (Optional)
This ferrite core can reduce noises.
How to attach the ferrite core
1. Pull the stopper [a] of the ferrite core to open.
2. Wind the portable cable on the ferrite core.
3. Close the ferrite core until it clicks.
Using a Bluetooth
Wireless Technology
About Bluetooth
Bluetooth® is wireless communication technology
for short range connection.
The available range is within 10 meters.
(The sound may be interrupted when the
connection interfered by the other electronic wave
or you connect the bluetooth in the other rooms.)
Connecting individual devices under Bluetooth®
wireless technology does not incur any charges. A
mobile phone with Bluetooth® wireless technology
can be operated via the Cascade if the connection
was made via Bluetooth® wireless technology.
Available Devices : Mobile phone, MP3, Laptop,
PDA.
Bluetooth profiles
In order to use Bluetooth wireless technology,
devices must be able to interpret certain proles.
This unit is compatible with following prole.
A2DP (Advanced Audio Distribution Prole)
Listening to music of a
bluetooth device
Before you start the pairing procedure, make
sure the Bluetooth feature is turned on in to your
Bluetooth device. Refer to your Bluetooth device’s
user guide. Once a pairing operation is performed,
it does not need to be performed again.
1. Select the Bluetooth function by pressing the
1/!
button repeatedly.
2. Operate the Bluetooth device and perform the
pairing operation. When searching for this unit
with the Bluetooth device, a list of the devices
found may appear in the Bluetooth device
display depending on the type of Bluetooth
device. Your unit appears as “LG Portable
(XX:XX)”.
NP6530-B0.BPOLLLK_ENG_MFL67789511.indd 10 2013-11-12  6:09:31

Operating 11
Operating
2
XX:XX means the last four digits of BT address.
For example, if your unit has a BT address such
as 9C:02:98:4A:F7:08, you will see “LG Portable
(F7:08)” on your Bluetooth device.
, Note
3. Enter the PIN code.
PIN code : 0000
Depending on the Bluetooth device type,
some devices do not require a PIN code.
, Note
4. When this unit successfully is connected with
your Bluetooth device, the
1/!
button blinks
twice in white color.
yDepending on the Bluetooth device type,
some devices have a dierent pairing way.
yTry pairing procedure if your device name is
not in the device list.
, Note
5. Listen to music.
To play a music stored on your Bluetooth device,
refer to your Bluetooth device’s user guide.
According to your Bluetooth device’s volume
level, the volume level of Bluetooth will be
adjusted.
ySound from the unit can be distorted if you
raise the volume of Bluetooth device up to
two-thirds or more.
yWhen you use the Bluetooth function,
adjust the volume of a Bluetooth device to
a proper level to listen to.
, Note
yOn portable in mode, After your device
is connected to the unit via Bluetooth,
the function switches to Bluetooth mode
automatically.
yAfter searching for this unit on your
Bluetooth device, connect the Bluetooth
device to this unit. Then play music you
want.
yThe sound may be interrupted when
the connection interfered by the other
electronic wave.
yYou cannot control the Bluetooth device
with this unit.
yPairing is limited one Bluetooth device per
one unit and multi-pairing is not supported.
yAlthough the distance between your
Bluetooth and the set is less than 10 m,
there are obstacles between both, your
Bluetooth device cannot be connected.
yDepending on the type of the device,
you may not be able to use the Bluetooth
function.
yYou can enjoy wireless system using phone,
MP3, Notebook, etc.
yThe electrical malfunction due to devices
using same frequency such as Medical
equipment, Microwaves or wireless
LAN devices, the connection will be
disconnected.
yWhen someone stands and interrupts
communication between Bluetooth device
and the player, the connection will be
disconnected.
yIf the gotten away of the distance between
Bluetooth and the unit, the sound quality
is lower and lower. The connection will
disconnect when the space between the
Bluetooth and the unit gets out of the
operating range of Bluetooth.
yThe device with Bluetooth wireless
technology is disconnected, if you turn o
the main unit or put the device away from
the main unit more than 10 m.
yIf the Bluetooth device is disconnected, you
should connect the Bluetooth device to
your unit.
, Note
NP6530-B0.BPOLLLK_ENG_MFL67789511.indd 11 2013-11-12  6:09:31

Operating12
Operating
2
Using bluetooth app
About “LG Bluetooth Remote” app
“LG Bluetooth Remote”app brings a suite of new
features to this unit.
To enjoy more features, you are recommended to
download and install free“LG Bluetooth Remote”
app.
Install “LG Bluetooth Remote”
app through “Apple App Store” or
“Google Android Market (Google
Play Store)”
1. Tap the “Apple App Store” icon or “Google
Android Market (Google Play Store)”icon.
2. In the search bar, type in the “LG Bluetooth
Remote” and search it.
3. In the search result list, find and tap “LG
Bluetooth Remote” to start downloading
Bluetooth app.
4. Tap an icon for installation.
5. Tap an icon for downloading.
yMake sure that your Bluetooth device is
connected to the Internet.
yMake sure that your Bluetooth device is
equipped with “Apple App Store” or “Google
Android Market (Google Play Store)”.
yIf you want to get more information, refer to
explanation of BT app in “Apple App Store”
or “Google Android Market (Google Play
Store)”
, Note
Install “LG Bluetooth Remote” app
by using QR code
1. Install “LG Bluetooth Remote” app through QR
code. Use the scanning software to scan the QR
code.
(Apple iOS) (Android OS)
2. Tap an icon for installation.
3. Tap an icon for downloading.
yMake sure that your Bluetooth device is
connected to the Internet.
yMake sure that your Bluetooth device has a
scanning software application. If you don’t
have one, download one from “Apple App
Store” or “Google Android Market (Google
Play Store)”.
, Note
NP6530-B0.BPOLLLK_ENG_MFL67789511.indd 12 2013-11-12  6:09:31

Operating 13
Operating
2
Activate bluetooth with “LG
Bluetooth Remote” app
“LG Bluetooth Remote”app helps to connect your
bluetooth device to this unit.
In case of iOS device ;
After performing the pairing operation,
activate Bluetooth with LG Bluetooth Remote
App.
, Note
1. Tap “LG Bluetooth Remote” app icon on the
home screen to open“LG Bluetooth Remote”
app, and go to the main menu.
2. Tap [Setting] and select the unit you want.
3. If you want to get more information to operate,
tap [Setting] and [Help].
yBT app will be available in the software
version as follow;
Android O/S : Ver 2.3.3 (or later)
iOS O/S : Ver 4.3 (or later)
yThis unit does not support the multi-pairing.
If this unit is already connected with other
Bluetooth device, disconnect that device
and then try again.
yDepending on the Bluetooth device, “LG
Bluetooth Remote” app may not work.
y“LG Bluetooth Remote”app for Apple iOS is
slightly dierent from that of Android OS.
yThe connection you’ve made may be
disconnected if you select other application
or change the setting of the connected
device via “LG Bluetooth Remote” app. In
such a case, please check the connection
status.
yTo prevent a malfunction, you are
recommended to connect only one device
to this unit.
yAfter connection of BT app, music may be
output from your device. In this case, try
connecting procedure again.
, Note
NP6530-B0.BPOLLLK_ENG_MFL67789511.indd 13 2013-11-12  6:09:31

Operating14
Operating
2
Other Operations
Using handsfree function
Preparation: Your smartphone must be paired
with the unit via bluetooth.
1. When a call cames in, press {to receive the
phone.
yWhile listening to music, if incoming calls,
the music pauses automatically. Then the
unit and your smartphone ring at the same
time.
yDepending on the type of bluetooth-
enabled phone or surrounding
environment, the sound quality may be
lowered or the unit may not work properly.
, Note
2. You can select the desired option by using {
button, refer to below.
Condition Press {Press and
Hold {
Incoming
Call Answer Call Reject Call
During Call Hang Up
Switch Call
from unit to
Phone
Auto power down
This unit will be off itself to save electronic
consumption in the case main unit is not
connected to external device and is not used for 25
minutes.
Also this unit will power down if no input is
connected using the analogue input after six hours.
LG Tag On
LG Tag On allows you to install and open “LG
Bluetooth Remote” app to NFC-enabled phone.
1. Activates the NFC feature of your NFC-enabled
phone.
2. Turn on the unit.
3. Tag the back of your NFC-enabled phone over
the unit.
-If “LG Bluetooth Remote” app is not installed on
your NFC-enabled phone, the linked screen with
“LG Bluetooth Remote“ app is displayed.
-If “LG Bluetooth Remote” app is installed on your
NFC-enabled phone, “LG Bluetooth Remote”
app is activated and Blutooth is connected
automatically.
yYou must activate the NFC feature of your
NFC-enabled phone.
yIf your NFC-enabled phone’s screen is
locked, it will not read the NFC.
yIf your smart phone case is plated with
chrome, NFC is unavailable. Depending on
your case’s material or thickness, NFC may
not be read well.
, Note
NP6530-B0.BPOLLLK_ENG_MFL67789511.indd 14 2013-11-12  6:09:31

Operating 15
Operating
2
LG Sound Sync
You can control some functions of this unit by
your TV’s remote control with LG Sound Sync. It is
compatible with the LG TV that is supported LG
Sound Sync. Make sure of the LG Sound Sync logo
on your TV.
Controllable function by LG TV’s remote control :
Volume up/down, mute
Refer to the TV’s instruction manual for the details
of LG Sound Sync.
yWhen the connections failed, make sure of
the condition of the TV and power of it.
yMake sure of the condition of this unit and
the connection in the cases below when
using LG Sound Sync.
-Turned o the unit.
-Changing the function to the others.
-Disconnecting the wireless connection
caused by interference or a distance.
, Note
With wireless connection
1. Turn on the unit.
2. Press SOUND SYNC to select the LG Sound
Sync function.
1/!
button will stay in Green
color.
3. Set up LG Sound Sync (Wireless) on the TV. Refer
to the TV’s instruction manual.
4. When this unit successfully is connected with
your LG TV, the
1/!
button blinks twice in
Green color.
If your unit and LG TV are connected normally,
1/! button will blink or stop blinking defending
on battery condition. (Refer to“Battery” on page
17)
yOnce LG TV function is selected, the unit
connects automatically the TV which is
connected lately when restarting.
yThe device with Bluetooth wireless
technology will be disconnected, if Sound
Sync function is selected. Bluetooth
remote app you’ve already connected is
disconnected either.
yIn LG Sound Sync function, you can search
and connect this unit through LG TV only.
yIn LG Sound Sync function, the volume step
of this unit will be changed to the volume
step of LG TV.
, Note
NP6530-B0.BPOLLLK_ENG_MFL67789511.indd 15 2013-11-12  6:09:31

3 Troubleshooting
Troubleshooting16
3
Troubleshooting
Troubleshooting
General
Problem Cause & Correction
No Power.
yThe battery is discharged. Recharge the battery.
yConnect the unit to the power supply with the AC adapter.
No sound or sound
distortion.
yThe unit or your smart device’s volume is set to minimum. Check and adjust
the volume of the unit or bluetooth device’s volume.
yWhen you use an external device at high volume, the sound quality may be
deteriorated. Lower the volume of the devices.
yIf you use the unit for purposes other than listening to music, the sound
quality may be lowered or the unit may not work properly.
Bluetooth pairing does
not work well.
ySwitch bluetooth o and on again on your bluetooth device, then try pairing
again.
yBe sure your bluetooth device is on.
yRemove the obstacle in the path of the bluetooth device and the unit.
yDepending on the type of the bluetooth device or surrounding
environment, your device may not be paired with the unit.
yWhile using Bluetooth, you may not activate BT app. Disconnect Bluetooth
device you have connected before to use BT app properly.
yWhen your Bluetooth device have been already connected with other unit,
disconnect the Bluetooth connection rst. Then you can control your unit
through BT app.
yDepending on the Bluetooth device, BT app may work restrictively not work.
yThe connection you’ve made may be disconnected if you select other
application or change the setting of the connected device via BT app. In
such case, please check the connection status.
The unit does not
operate normally.
yIn case of malfunction,
1/!
button is lit in red and white alternately. Please
use the unit in proper place where the temperature or humidity is not so
high or low.
Above solutions do not
work.
yPress Reset hole with a pointed thing like mechanical pencil.
NP6530-B0.BPOLLLK_ENG_MFL67789511.indd 16 2013-11-12  6:09:32

4 Appendix
Appendix 17
Appendix
4
About
1/!
Button’s Condition
Turned on
white
Turned on
red Turned on Green Turned o Beep Sound
Battery
Power AC Adapter Condition Color
O Connected Charging Full charge
On Disconnected Low battery Blinks
quickly
On Connected Charging Full charge
- Connected Has a problem with the
battery
Warning
message
Bluetooth
Power AC Adapter Condition Color
On - Bluetooth paired Blinks twice
LG Sound Sync
Power AC Adapter Condition Color
On - Sound Sync disconnected
(On Sound Sync mode) (Green)
On - Sound Sync connected (Green) Blinks twice
NP6530-B0.BPOLLLK_ENG_MFL67789511.indd 17 2013-11-12  6:09:32

Appendix18
Appendix
4
Trademarks and
Licenses
Bluetooth® wireless technology is a system which
allows radio contact between electronic devices
within a max. range of 10 meters.
Connecting individual devices under Bluetooth®
wireless technology does not incur any charges.
A mobile phone with Bluetooth® wireless
technology can be operated via the Cascade if
the connection was made via Bluetooth® wireless
technology.
The Bluetooth® word mark and logos are owned
by the Bluetooth® SIG, Inc. and any use of such
marks by LG Electronics is under license.
Other trademarks and trade names are those of
their respective owners.
Handling the Unit
When shipping the unit
Please save the original shipping carton and
packing materials. If you need to ship the unit, for
maximum protection, re-pack the unit as it was
originally packed at the factory.
Keeping the exterior surfaces clean
yDo not use volatile liquids such as insecticide
spray near the unit.
yWiping with strong pressure may damage the
surface.
yDo not leave rubber or plastic products in
contact with the unit for a long period of time.
Cleaning the unit
To clean the player, use a soft, dry cloth. If the
surfaces are extremely dirty, use a soft cloth lightly
moistened with a mild detergent solution. Do not
use strong solvents such as alcohol, benzine, or
thinner, as these might damage the surface of the
unit.
NP6530-B0.BPOLLLK_ENG_MFL67789511.indd 18 2013-11-12  6:09:32

Appendix 19
Appendix
4
Specifications
General
Power requirements DC 12 V 01.5 A
AC adapter requirements 100 - 240 V, 50 / 60 Hz
Power consumption 18 W
Dimensions (W x H x D) 300 mm x 95 mm x 98 mm
Net Weight (Approx.) 1.3 kg
Operating temperature 5 °C - 35 °C
Operating humidity 5 % - 60 %
Inputs
PORT. IN 0.5 Vrms (3.5 mm stereo jack)
Amplier
Output Power (Adapter) 10 W x 2 ch (6 Ω at 1 kHz)
Output Power (Battery) 5 W x 2 ch (6 Ω at 1 kHz)
T.H.D 10 %
Speakers
Type built-in
Impedance Rated 6 Ω
Rated Input Power 10 W
Max Input Power 20 W
yDesign and specications are subject to change without notice.
NP6530-B0.BPOLLLK_ENG_MFL67789511.indd 19 2013-11-12  6:09:32

NP6530-B0.BPOLLLK_ENG_MFL67789511.indd 20 2013-11-12  6:09:32
