LG OM5560 Specification sheet

*MFL68962851* www.lg.com
To view the instructions of advanced features,
visit http://www.lg.com and then download Owner’s Manual.
Some of the content in this manual may differ from your unit.
MODEL
OM5560
SIMPLE MANUAL
Mini Hi-Fi
Audio
ENGLISH
Additional Information
Specifications
Power Requirements Refer to the main label on
the unit.
Power Consumption
Refer to the main label on
the unit.
Networked standby : 0.5 W
(If all network ports are
activated.)
Dimensions (W x H x D) Approx. 330 mm x
715 mm x 302 mm
Net Weight Approx. 13.3 kg
Bus Power Supply (USB) 5 V 0500 mA
Amplier
(Total RMS output power) 500 W
Design and specications are subject to change without
notice.
Caution
yConnect the power cord to wall outlet directly if
possible. Or when you use an extension cable, it is highly
recommended to use an extension cable of 110 V / 15 A
or 230 V / 15 A, otherwise the unit may not operate
properly because of the lack of power supply.
yDo not overload the extension cord with excessive
electrical load.
How to disconnect the wireless network
connection or the wireless device
Turn off the unit by pressing the power button for more
than 5 seconds.
Replacement of battery
(R03)
(R03)
OM5560-FB.DZAFLLB_SIMPLE_ENG_MFL68962851.indd 2 2016-07-21 �� 3:52:11

Top panel
a
b
c
d
e
f
g
h
n
o
m
l
k
j
i
aUSB 1 Port
You can play or record sound les by connecting the USB
device.
b1/!(Standby/On)
cMIC. (Microphone volume)
Controls microphone’s volume.
dVOICE CANCELLER
You can enjoy the function while playing the music, by
reducing singer vocal of music in the various source.
Press to switch this mode on or off.
KEY CHANGER (b/#)
Changes the key to suit your vocal range.
LIGHTING / PARTY LINK
- Turns on/off the lighting effects.
- Press and hold to select the PARTY LINK.
eSCRATCH / LEVEL / SYNC SET
Turn clockwise or counterclockwise to make Scratch sound.
/ Adjust DJ EFFECT level. / Sets Delay value in PARTY LINK
mode.
fDJ EFFECT
Selects DJ EFFECT mode.
USER EQ
Selects the sound effect created by your own.
gPARTY THRUSTER
Slide the lever to create a party atmosphere.
hCLUB, DRUM, USER (DJ PRO)
Selects CLUB, DRUM or USER sound effect to mix.
(If you want to use USER, you have to register a source with
“Music Flow Bluetooth” app.)
1, 2, 3 (DJ PRO PAD)
Press a desired sound pad.
iSEARCH
Moves to folder or file in selection mode.
OK
Selects a folder when searching a file.
j Y , U & SEARCH (Skip/Search)
- Searches a folder or a file.
- Searches for a section within a track/file.
- Selects the radio stations.
k T(Play/Pause)
- Starts or pauses playback.
- Selects Stereo/Mono.
I(Stop)
Stops playback or cancels DELETE function.
R(Open/Close)
Opens and closes the disc tray.
REGION EQ / BASS BLAST
- Chooses region equalizer.
- Press and hold to select BASS effect directly.
l VOL. (Volume)
Adjusts speaker volume.
mUSB REC / DEMO
Records to USB. / Shows Demo mode.
F (Function) / WIRELESS LINK
- Selects the function and input source.
- Press and hold for 3 seconds to select WIRELESS PARTY
LINK mode.
nUSB 2 Port
You can play or record sound les by connecting the USB
device.
oDisplay window
Download the Music Flow Bluetooth App to your
device.
For more information, download the online owner’s
manual. http://www.lg.com
LG Sound Sync (Wireless)
Controller App
Front panel / Rear panel
aDisc tray
bMIC (Microphone) 1 / 2 jack
c PORT. IN
d
Remote sensor
eANTENNA (FM)
fAUX IN / OUT
gAC in socket
OUT IN
e
f
g
a
b
c
