LG ON5 Specification sheet

ENGLISH DEUTSCH FRANÇAIS NEDERLANDS ITALIANO ESPAÑOL ΕΛΛΗΝΙΚΑ PORTUGUÊS MAGYAR
ČESKY SLOVENČINA POLSKI ROMÂNĂ LATVIEŠU HRVATSKI SRPSKI БЪЛГАРСКИ МАКЕДОНСКИ
SLOVENŠČINA SHQIP BOSANSKI SVENSKA DANSK NORSK SUOMI
www.lg.com
Copyright © 2020 LG Electronics Inc. All Rights Reserved.
SIMPLE MANUAL
Mini Hi-Fi
Audio
Please read this manual carefully before operating your set and
retain it for future reference.
To view the instructions of advanced features, visit
http://www.lg.com and then download Owner’s Manual. Some of the
content in this manual may differ from your unit.
MODEL
ON5
2004_Rev02
MFL71664325
ON5-C.DEUSLLK_SIM_ENG_MFL71664325.indd 1 2020-04-14   9:37:03

nlk i
j
h
f
g
a
b
c
d
e
m
o
a 1(Standby)
Turns the power on or off.
bUSB REC / DEMO
- Records to USB.
- Stops recording.
- In power off status, if you press USB REC / DEMO, show
demo mode.
cUSB 1 Port
You can play sound les by connecting the USB device.
dDisplay window
eUSB 2 Port
You can play sound les by connecting the USB device.
fF (Function)
Selects the function and input source.
gLIGHTING
Selects the lighting mode.
h3TWIN
Connects two units for TWIN mode in WIRELESS PARTY LINK.
iC/V(Skip/Search)
- Skips backward or forward.
- Searches for a section within a track/le.
- Selects the radio stations.
- Scans DAB+ stations by pressing and holding.
N(Play/Pause)
- Starts or pauses playback.
- Selects stereo/mono.
- Bluetooth connection lock (BT LOCK): Select the Bluetooth
function by pressing Frepeatedly. And long press Nto limit
Bluetooth connection to only BT and LG TV.
Z(Stop) / RDS
- Stops playback or cancels DELETE function.
- Radio Data System
VOL (Volume) -/+
Adjusts speaker volume.
MIC (Microphone) / GUITAR -/+
Adjusts Microphone volume or Guitar volume.
j(Auto Music Play)
Plays the audio currently playing by tagging the mobile
(with "LG XBOOM" App) to this unit. (Android Only)
k VOICE CANCELLER
You can reduce the vocal tones during music playback from
various input sources.
B(Open/Close)
Opens and closes the disc tray.
l CLUB, DRUM, USER (DJ PAD)
Selects CLUB, DRUM or USER sound effect to mix.
(If you want to use USER, you have to register a source with
“LG XBOOM” app. (Android Only))
1, 2, 3 (DJ PAD)
Press a desired sound pad.
mMIC (Microphone) ECHO
Selects ECHO mode.
VOCAL EFFECTS
Selects various vocal effects mode.
KEY CHANGER (l/L)
Changes the key to suit your vocal range.
nRemote sensor
oSPECIAL EQ / BASS BLAST (or BASS BLAST+)
- Chooses special equalizer.
- Press and hold to select BASS (or BASS+) effect directly.
SEARCH
Moves to folder or file in selection mode.
OK
Selects a folder when searching a file.
USER EQ
Selects the equalizer created by your own.
Multi jog
- Searches a folder or a file.
- Turns clockwise or counterclockwise to control the USER EQ
level.
- Chooses special equalizer.
Top panel
ON5-C.DEUSLLK_SIM_ENG_MFL71664325.indd 2 2020-04-14   9:37:05

Front panel / Rear panel
aDisc tray
b Lighting
cRemote sensor
dGUITAR IN: Connect a guitar.
e MIC (Microphone) IN: Connect a microphone.
fDAB+/FM ANTENNA
gAC IN socket
Download the LG XBOOM App to your device. For more information, download the online owner’s
manual. http://www.lg.com
LG Sound Sync (Wireless)
Controller App
a
b
c
fde
g
Android iOS
ON5-C.DEUSLLK_SIM_ENG_MFL71664325.indd 3 2020-04-14   9:37:06

Additional Information
Specifications
Power Requirements Refer to the main label on
the unit.
Power Consumption
Refer to the main label on
the unit.
Networked standby : 0.5 W
(If all network ports are
activated.)
Dimensions (W x H x D) Approx. 330,0 mm x
685,0 mm x 344,0 mm
Bus Power Supply (USB) 5 V 0500 mA
Design and specications are subject to change without
notice.
Caution
yConnect the power cord to wall outlet directly if
possible. Or when you use an extension cable, it is
highly recommended to use an extension cable of 110
V / 15 A or 230 V / 15 A, otherwise the unit may not
operate properly because of the lack of power supply.
yDo not overload the extension cord with excessive
electrical load.
Note
yDo not look directly at the light emitting part when the
LIGHTING is turned on.
yIf the illumination brightness is glaring, switch on the
room lights or turn off the LIGHTING of the unit.
How to disconnect the wireless network
connection or the wireless device
Turn off the unit by pressing the power button for more
than 5 seconds.
Replacement of battery
(R03)
(R03)
Declaration of Conformity
Hereby, LG Electronics declares that the radio equipment type
MINI HI-FI AUDIO is in compliance with Directive 2014/53/EU. The full
text of the EU declaration of conformity is available at the following
internet address:
http://www.lg.com/global/support/cedoc/cedoc#
For consideration of the user, this device should be installed and
operated with a minimum distance of 20 cm between the device
and the body.
Frequency range Output power (Max.)
2402 to 2480 MHz 10 dBm
ON5-C.DEUSLLK_SIM_ENG_MFL71664325.indd 4 2020-04-14   9:37:06
