LG ON9 Specification sheet

www.lg.com
Copyright © 2020 LG Electronics Inc. All Rights Reserved.2004_Rev02
MFL71662725
SIMPLE MANUAL
Mini Hi-Fi
Audio
Please read this manual carefully before operating your set and retain it for
future reference.
To view the instructions of advanced features, visit http://www.lg.com and
then download Owner’s Manual. Some of the content in this manual may
differ from your unit.
MODEL
ON9
Additional Information
Specifications
Power Requirements Refer to the main label on
the unit.
Power Consumption Refer to the main label on
the unit.
Dimensions (W x H x D) Approx. 330.0 mm x
1,056.0 mm x 368.0 mm
Bus Power Supply (USB) 5 V 0500 mA
Design and specications are subject to change without
notice.
Caution
yConnect the power cord to wall outlet directly if
possible. Or when you use an extension cable, it is
highly recommended to use an extension cable of 110
V / 15 A or 230 V / 15 A, otherwise the unit may not
operate properly because of the lack of power supply.
yDo not overload the extension cord with excessive
electrical load.
Note
yDo not look directly at the light emitting part when the
LIGHTING is turned on.
yIf the illumination brightness is glaring, switch on the
room lights or turn off the LIGHTING of the unit.
Replacement of battery
(R03)
(R03)
POWER: This unit operates on a mains supply of 200 -
240 V ~ 50 / 60 Hz.
Wiring: This unit is supplied with a BS 1363 approved
main plug. When replacing the fuse, always use a
fuse of the same rating approved to BS 1362. Never
use this plug with the fuse cover omitted. To obtain
a replacement fuse cover contact your dealer. If the
type of plug supplied is not suitable for the mains
sockets in your home, then the plug should be removed
and a suitable type tted. Please refer to the wiring
instructions below:
Warning: A mains plug removed from the mains lead of
this unit must be destroyed. A mains plug with bared
wires is hazardous if inserted in a mains socket. Do not
connect either wire to the earth pin, marked with the
letter E or with the earth symbol 6or coloured green
or green and yellow. If any other plug is tted, use same
rating of fuse in the plug.
Important: The wires in this mains lead are coloured in
accordance with the following codes:
- BLUE: NEUTRAL, BROWN: LIVE: As the colours of the
wires in the mains lead of this unit may not correspond
with the coloured marking identifying the terminals in
your plug, proceed as follows: The wire which is coloured
blue must be connected to the terminal which is marked
with the letter N or coloured black. The wire which is
coloured brown must be connected to the terminal
which is marked with the letter L or coloured red.
ENGLISH
ON9-F.DLKALLK_SIM_ENG_MFL71662725.indd 2 2020-04-07  5:07:31

Top panel
nlk i
j
h
f
g
a
b
c
d
e
m
o
a 1(Standby)
Turns the power on or off.
bUSB REC / DEMO
- Records to USB.
- Stops recording.
- In power off status, if you press USB REC / DEMO, show
demo mode.
cUSB 1 Port
You can play sound les by connecting the USB device.
dDisplay window
eUSB 2 Port
You can play sound les by connecting the USB device.
fF (Function)
Selects the function and input source.
gLIGHTING
Selects the lighting mode.
h3TWIN
Connects two units for TWIN mode in WIRELESS PARTY LINK.
iC/V(Skip/Search)
- Skips backward or forward.
- Searches for a section within a track/le.
- Selects the radio stations.
N(Play/Pause)
- Starts or pauses playback.
- Selects stereo/mono.
- Bluetooth connection lock (BT LOCK): Select the Bluetooth
function by pressing Frepeatedly. And long press Nto limit
Bluetooth connection to only BT and LG TV.
Z(Stop)
Stops playback or cancels DELETE function.
VOL (Volume) -/+
Adjusts speaker volume.
MIC (Microphone) / GUITAR -/+
Adjusts Microphone volume or Guitar volume.
j (Auto Music Play)
Plays the audio currently playing by tagging the mobile (with
“LG XBOOM” App) to this unit. (Android Only)
k VOICE CANCELLER
You can reduce the vocal tones during music playback from
various input sources.
B(Open/Close)
Opens and closes the disc tray.
l CLUB, DRUM, USER (DJ PAD)
Selects CLUB, DRUM or USER sound effect to mix.
(If you want to use USER, you have to register a source with
“LG XBOOM” app.(Android Only))
1, 2, 3 (DJ PAD)
Press a desired sound pad.
mMIC (Microphone) ECHO
Selects ECHO mode.
VOCAL EFFECTS
Selects various vocal effects mode.
KEY CHANGER (l/L)
Changes the key to suit your vocal range.
nRemote sensor
oSPECIAL EQ / BASS BLAST (or BASS BLAST+)
- Chooses special equalizer.
- Press and hold to select BASS (or BASS+) effect directly.
SEARCH
Moves to folder or file in selection mode.
OK
Selects a folder when searching a file.
USER EQ
Selects the equalizer created by your own.
Multi jog
- Searches a folder or a file.
- Turns clockwise or counterclockwise to control the USER EQ
level.
- Chooses special equalizer.
aDisc tray
bLighting
c Remote sensor
dOPTICAL IN: Connect an optical device.
e GUITAR IN: Connect a guitar.
f MIC (Microphone) IN:Connect a microphone.
gANTENNA (FM)
hAC IN socket
Make sure to properly align and connect the
optical cable; improper alignment may cause
damage to the jack.
Front panel / Rear panel
a
b
c
h
fg
e
d
Download the LG XBOOM App to your device. For more information, download the online owner’s
manual. http://www.lg.com
LG Sound Sync
Controller App
Android iOS
