LG CodePlus HCS7720 Series Operating and maintenance manual

© Copyright 2012 LG Electronics U.S.A., Inc. P/N: 206-4180 (Rev A)
HCS7720 CodePlus™ Series
DISH Network
® HD Transcoder
(MPEG-4 to MPEG-2)
Installation & Setup Guide
Warranty

2206-4180
WARNING:
TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL. ALL
CARDS MUST BE INSERTED AND REMOVED BY QUALIFIED SERVICE PERSONNEL ONLY.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert
the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence
of important operating and maintenance (servicing) instructions in the literature accompanying
the appliance.
WARNING:
TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE.
Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such
as vases, shall be placed on the apparatus.
L’appareil ne doit pas être exposé à des égouttements d’eau ou des éclaboussures et de plus
qu’aucun objet rempli de liquide tel que des vases ne doit être placé sur l’appareil.
REGULATORY INFORMATION:
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial envi-
ronment. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference
to radio communications. Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user should be required to correct the interference at
his own expense.
CAUTION:
Do not attempt to modify this product in any way without written authorization from LG
Electronics U.S.A., Inc. Unauthorized modification could void the user’s authority to operate
this product.
NOTE TO SATELLITE DISH INSTALLER:
This reminder is provided to call your attention to Articles 810 and 820 of the 2002 National
Electrical Code. Refer to Article 810, in particular 810-1 and 810-15, for required grounding of
the metal dish antenna. Refer also to 810-2 which, by reference to Article 820, requires that
the satellite dish coaxial cable shield be connected to the grounding system of the building as
close to the point of cable entry as practical.
COMPLIANCE:
The responsible party for this product’s compliance is: LG Electronics U.S.A., Inc.
2000 Millbrook Drive, Lincolnshire, IL 60069, USA • Phone: [phone]
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
For Customer Support/Service, please call: 1-888-865-3026
The latest product information and documentation is available online at:
www.LGsolutions.com/products
Marketed and Distributed in the United States by LG Electronics U.S.A., Inc.
2000 Millbrook Drive, Lincolnshire, IL 60069
© Copyright 2012 LG Electronics U.S.A., Inc.

206-4180 3
Important safeguards for you and your new product
THIS PRODUCT HAS BEEN MANUFACTURED AND TESTED WITH SAFETY IN MIND.
IMPROPER USE, HOWEVER, CAN RESULT IN POTENTIAL ELECTRICAL SHOCK OR
FIRE HAZARDS. TO AVOID DEFEATING THE SAFEGUARDS THAT HAVE BEEN BUILT
INTO THIS PRODUCT, PLEASE READ AND OBSERVE THE FOLLOWING SAFETY
POINTS WHEN INSTALLING AND USING THIS PRODUCT.
(Continued on next page)
1. Read these instructions.
Read all the safety and operating instructions
before operating the product.
2. Keep these instructions.
Retain the safety and operating instructions
for future reference.
3. Heed all warnings.
Adhere to all warnings on the product and in
the operating instructions.
4. Follow all instructions.
Follow all operating and use instructions.
5. Do not use this apparatus near water.
Do not use this product near water or moisture
or in an area, such as a basement, that might
become flooded.
6. Clean only with dry cloth.
Unplug this product before cleaning. Do not
use liquid cleaners or aerosol cleaners.
7. Refer all servicing to qualified service
personnel.
Servicing is required when the apparatus has
been damaged in any way, liquid has been
spilled or objects have fallen into the appara-
tus, the apparatus has been exposed to rain
or moisture, does not operate normally, or has
been dropped.
8. Object and Liquid Entry
Never push objects of any kind into this
product through openings as they may touch
dangerous voltage points or short-out parts
that could result in a fire or electric shock.
Never spill liquid of any kind on the product.
9. Outdoor Use
Warning: To prevent fire or shock
hazards, do not expose this product
to rain or moisture.
10. Wet Location
The apparatus shall not be exposed to drip-
ping or splashing and no objects filled with
liquids, such as vases, shall be placed on
the apparatus.
11. Test Equipment
In some cases, LG has supplied or recom-
mended the use of test equipment and
devices for the setup and testing of the
equipment. The operation and maintenance
of test equipment is described in their
associated instruction manuals. Please refer
to these manuals for explicit instructions
regarding the safe use and handling of the
equipment.
12. Damage Requiring Service
Unplug this product from the wall power
outlet and refer servicing to qualied service
personnel under the following conditions:
a. If liquid has been spilled, or objects have
fallen into the product.
b. If the product has been exposed to rain or
water.
c. If the product does not operate normally by
following the operating instructions. Adjust
only those controls that are covered by the
operating instructions, as an improper
adjustment of other controls may result in
damage and will often require extensive
work by a qualied technician to restore
the product to its normal operation.
IMPORTANT SAFETY INSTRUCTIONS

4206-4180
(Continued from previous page)
d. If the product has been dropped or the
cabinet has been damaged.
e. If the product exhibits a distinct change in
performance.
13. Servicing
Caution: These servicing instruc-
tions are for use by qualied ser-
vice personnel only. To reduce the
risk of electrical shock, do not perform
any servicing other than that described in
the operating instructions unless you are
qualied to do so.
14. Replacement Parts
When replacement parts are required, be
sure the service technician uses replacement
parts specied by the manufacturer or that
have the same characteristics as the original
parts. Unauthorized substitutions may result
in re, electric shock, or other hazards.
15. Safety Check
Upon completion of any service or repairs to
this product, ask the service technician to
perform safety checks to determine that the
product is in proper operating condition.
IMPORTANT SAFETY INSTRUCTIONS
Caution: Refer all servicing to qualied
service personnel.
IMPORTANT SAFETY INSTRUCTIONS

206-4180 5
Table of Contents
Safety Warnings ....................... 2
Important Safety Instructions. . . . . . . . . . . . 3 – 4
Table of Contents . . . . . . . . . . . . . . . . . . . . . . 5
Setup Information . . . . . . . . . . . . . . . . . . . . . . 6
HCS7720 Product Description . . . . . . . . . . . . 7
Transcoder Product Description . . . . . . . . . . . 8
HCS7720 Card Description . . . . . . . . . . . . . . . 9
Installing CodePlus Transcoder Cards . . 10 – 11
DISH Network Satellite STB & HCS7720
Initialization & Setup Connections . . . . . . . . . 12
System Setup . . . . . . . . . . . . . . . . . . . . . 13 – 14
Configuration Options . . . . . . . . . . . . . . . 15 – 23
Troubleshooting ....................... 24
Specifications ........................ 25
Document Revision History / Notes . . . . . . . 26
Open Source Software Notice . . . . . . . . . . . . 27
Warranty . . . . . . . . . . . . . . . . . . . . . Back Cover

6206-4180
This document provides installation and setup support only for an HCS7720 transcoder card.
The satellite dish antenna and a DISH Network
® ViP ® 222k satellite receiver must be installed
and operating before you can proceed to set up the HCS7720. LG recommends that the system
be professionally installed.
Check the following items before you begin HCS7720 installation and setup procedures.
Satellite Dish Antenna
__ The satellite dish must be located where it will have unobstructed access to the satellite
signals. At least RG-6 or larger coaxial cables must be installed between the satellite dish
antenna system and the ViP 222k. Refer to documentation provided with the satellite dish
antenna.
__ For MPEG-4 HD program reception, a 3-LNB satellite dish configuration is required. If the
number of transcoders exceeds the satellite dish antenna capacity, multi-switch equipment
will be required. For more information, refer to the manufacturer’s documentation.
Satellite Receiver
__ Refer to ViP 222k documentation, and carefully follow the system setup procedures for the
satellite receiver. (The satellite receiver provides the X-Port and HDMI signal inputs for the
HCS7720. Note that ViP 222 satellite receivers are not supported with HCS7720
transcoder cards.)
__ DISH Network authorization is required for HD programs. Contact DISH Network to get
subscription programming authorization for the ViP 222k satellite receiver.
ASI Output (Optional)
__ If applicable, install the DTV modulator and upconverter that will receive the ASI output
signal from the HCS7720. Refer to the manufacturer’s documentation.
HCS7720
__ Unpack the HCS7720 and all accessories.
HCS7720 Accessories: • 1 x 1 meter CAT5E Shielded Cable
• 1 x 1 meter HDMI Cable
__ If the HCS7720 will be used with a feature card (Example: HCS6320) in the card frame
CONTROLLER slot, you will need a copy of the Installation & Setup Guide for the feature
card in order to complete the HCS7720 system setup.
__ For HCS7720 Service Port connections, you must use an FTDI TTL-USB cable (P/N TTL-
232R-5V-AJ).
Setup Information

206-4180 7
HCS7720 Product Description
The HCS7720 is one of the LG CodePlus™ series transcoder cards. Pairing an HCS7720
card in the appropriate CodePlus card frame with a DISH Network ViP 222k satellite receiver
will provide one program of DISH Network content.
Features:
• Part of modular system, easily scaled for each application
• Transcodes MPEG-4 satellite content to MPEG-2 transport stream
• Built-in Pro:Idiom
® content protection
• Integral Auto Tuning feature with congurable parameters
• DVB-ASI output available to connect to external MUX or modulator
• Internal LVDS serial output available at CONTROLLER card slot on mother board
• Transcoded output supports Closed Captions and V-Chip (Parental Control) *
• Short 3U height prole to minimize rack space usage
The HCS7720 is intended to provide access for existing Pro:Idiom TV (MPEG-2 only)
installations to DISH Network MPEG-4 encoded programming. The HCS7720 converts the
DISH Network MPEG-4 HD programming to an encrypted MPEG-2 encoded transport stream.
HCS7720
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
* If included in the signal source.

8206-4180
Typical DISH Network HD Transcoder System Overview
The LG HCS7720 DISH Network HD transcoder represents a single-program MPEG-4 to
MPEG-2 HDTV solution for commercial and institutional MATV systems (hotels, hospitals,
etc.).
A typical DISH Network HD Transcoder System includes:
• One HCS7720 DISH Network HD transcoder card for each HD program offered in the
facility’s MATV system.
• A CodePlus series card frame (Example: HCS6150R) specied for the HCS7720.
• A DISH Network 3-LNB dish antenna system, required for MPEG-4 support and reception. *
• A DISH Network ViP 222k satellite receiver for each transcoder card. (Note that ViP 222
satellite receivers are not supported with HCS7720 transcoder cards.) *
• A QAM or VSB modulator with ASI input for each transcoder or an LG CodePlus series
HCS6320 MUX/MOD feature card. Multiplexers can be used in front of the modulator if
multiple programs are desired and 256-QAM is used. *
• (For each modulator, if applicable) An upconverter compatible with digital modulation. *
• A 19-inch rack for mounting. *
• Miscellaneous cables and installation hardware (see also setup information on page 6). *
The integrated elements of the DISH Network HD Transcoder System:
• Receive a selected HD program from DISH Network service.
• Transcode the received digital video and audio stream to an MPEG-2 compatible transport
stream.
• Encrypt the transcoded digital data stream.
• Modulate the stream in QAM or VSB.
• Upconvert the modulated, encrypted transport stream to an RF channel.
A Pro:Idiom compatible television with a QAM/VSB tuner is required to view premium HD
content. The HCS7720 converts the DISH Network encryption to Pro:Idiom encryption; thus,
a proper session ID must be set at the TV in order for Pro:Idiom decryption to be enabled.
LG’s Pay-Per-View (PPV) partners can set up this session through their interface. LG’s
Free-To-Guest (FTG) Mode of operation also enables Pro:Idiom decryption.
Note: The RF output from the Transcoder System can be combined with other channels in
the site’s distribution grid.
Transcoder Product Description
* Purchased separately.
Note: Design and specifications subject to change without prior notice.

206-4180 9
HCS7720 Card Description
HCS7720
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
ASI OUT
DTV signal output
Retaining Screw
Install after inserting
HCS7720 card
Retaining Screw
Install after inserting
HCS7720 card
X-PORT LINK
Ethernet port to ViP 222k
satellite receiver
RESET
Resets card
STATUS
Blinking pattern indicates
condition of card
SERVICE PORT
TTL-USB serial port
connection (use FTDI
TTL-232R-5V-AJ cable)
HDMI IN
To ViP 222k HDMI (Out)

10 206-4180
Installing CodePlus Transcoder Cards
Note: The CodePlus series products are NOT designed to be hot-swappable!!! Power
must be removed to the card frame before any CodePlus transcoder cards are inserted
or removed.
Note: All cards used in the card frame must be inserted and removed by qualified
service personnel only.
Note: Use extreme care when handling an HCS7720 card. Always observe proper
precautions with respect to static electricity and mechanical shock. When not installed
in a card frame, return the HCS7720 card to the anti-static bag in which it was shipped.
Note: The card slots in the card frame are NOT all identical!!! In an HCS6150R card
frame, for example, HCS7720 cards can only be installed in the following slots: 1, 2, 4, 5,
8, 9, 11, and 12. The CONTROLLER slot between Slots 6 and 7 is dedicated for optional
feature cards and is not compatible with HCS7720 cards.
Note: When installing cards, remove blank cover plates and insert new cards as
applicable. For ports that will not be used, leave the blank cover plates in place for
proper ventilation and FCC and safety agency compliance.
Refer to the diagram on page 11, and follow the procedure below to install the CodePlus
transcoder card(s).
1. If not already done, unpack the HCS7720 unit(s) and all accessories (see also HCS7720
setup information on page 6).
2. Select the slot(s) in the card frame in which to install the HCS7720. Note: All cards must
be used in an LG-approved card frame for this product.
3. Remove the AC power cord for the card frame from the power outlet.
4. Remove the blank cover plate from each slot into which a card is to be inserted.
5. Without using force, slide each new card into its designated slot, and ensure that it is fully
inserted.
6. Engage and tighten the top and bottom thumbscrews securely. Note that the thumbscrews
should only be nger tight; overtightening may damage the assembly.
7. Refer to the diagram on page 12 for cable connections, and complete the system
installation procedure on pages 13 and 14.

206-4180 11
HCS7720
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS7720
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS7720
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS7720
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS7720
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS7720
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS6320
RF OUT
ETHERNET
Slot 1 Slot 12Slot 5
CONTROLLER
Slot
Slot 6 Slot 7 Slot 8 Slot 9 Slot 10 Slot 11
Slot 2
Slots
3 & 4
HCS6400 HCS6400 HCS6400
SERVICE
PORT
RESET
STATUS
HCS7720
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
No more than eight HCS7720 cards may be installed in a
13-slot card frame, such as the HCS6150R. HCS7720 cards
should be inserted in the following slots: 1, 2, 4, 5, 8, 9, 11,
and 12. HCS6400 fan cards are pre-installed in the following
slots: 3, 6, 7, and 10.
Installing CodePlus Transcoder Cards (Cont.)
CONTROLLER Slot
The card in this slot may vary
depending on system features.

12 206-4180
AC
Power
Cord
Power Outlet
(120V 60Hz AC)
X-Port Link to
HCS7720
ViP 222k
HCS7720
in Card Frame
Chassis
HDMI to
HCS7720
HCS7720
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS7720
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS7720
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS7720
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
HCS7720
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
RF OUT
HCS6400
HCS6400 HCS6400
SERVICE
PORT
RESET
STATUS
HCS7720
X PORT LINK
RESET
STATUS
SERVICE
PORT
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
HDMI-IN
Modulator
ASI Out
from
HCS7720
Upconverter
Combiner
RF
Distribution
System
Room
Receiver
Room
Receiver
Room
Receiver
Laptop
PC
.....
.....
TTL-USB
Service Port
Connection
VIDEO
AUDIO
SATELLITE IN SATELLITE IN
VIDEO
AUDIO
Digital Audio
OUTPUT
HDMI
120V AC~ 60 Hz
85 WATTS
ETHERNET
PHONE
S-VIDEO
DISH
Network
Satellite
Signal
Satellite
Distribution
NTSC
Monitor
Composite Video
and L/R Audio
to NTSC Monitor
Power Outlet
(120V 60Hz AC)
HD
Channel
DISH Network Satellite STB & HCS7720
Initialization & Setup Connections
Note: This diagram shows setup connections
where an HCS7720 card is connected to an
external modulator and upconverter.

206-4180 13
System Setup
Typical HCS7720 System Installation
(see also Typical Setup Flow Charts on page 14)
1. Verify that the ViP 222k satellite receiver is set up and functioning (i.e., check that the
ViP 222k is connected to an NTSC monitor [for tuning purposes], that it is powered up,
that initialization is complete, and that the NTSC monitor is displaying the default channel
properly—refer to the ViP 222k documentation).
Note: 720p display resolution is required for standard HCS7720 operation.
Before you continue, use the ViP 222k menu system (Setup > HDTV Setup > TV
Type) to ensure the resolution is set to 720p.
2. Make sure the ViP 222k is in Single Mode, and then tune the receiver to the desired
MPEG-4 HD channel using the controls on the front panel or the IR remote control.
3. Connect the supplied CAT5E shielded cable between the X-PORT LINK port on the
HCS7720 and the ETHERNET port on the ViP 222k. Then, connect the supplied HDMI
cable between the HDMI IN port on the HCS7720 and the HDMI (Out) port on the ViP 222k.
Note: Once you make the connections between the ViP 222k and the HCS7720, ViP 222k
remote control functionality will be disabled by default. If required, you can enable remote
control functionality using the “Enable/Disable RC Functions” option described on page 23
(under “Satellite Receiver Menu Commands”). It is also possible to set/change the satellite
receiver channel via the HCS7720 Satellite Receiver Menu.
4. Perform one of the following per your installation:
• If the HCS7720 will be used with an external modulator and upconverter, connect a 75
ohm BNC-to-BNC coaxial cable between ASI OUT on the HCS7720 and ASI IN on the
modulator. Then, continue with step 5.
Note: The BNC cable must be less than 30 feet (9.2 meters) in length.
• If the HCS7720 will be used with an HCS6320 MUX/MOD feature card (internal modulator
and upconverter functionality), the cable to the ASI OUT port will not be required. Refer to
the HCS6320 CodePlus™ Series MUX/MOD Feature Card Installation & Setup Guide
for further instruction before you continue this setup procedure.
5. For an installation with an external modulator and upconverter: Connect an RF coaxial
cable between IF OUT on the modulator and IF IN on the upconverter, and then check the
modulator and upconverter for correct settings (QAM type, channel number, etc.).
6. Repeat steps 1 to 5 for each of the ViP 222k/transcoder pairs.
7. Plug in the power to the CodePlus card frame containing the newly installed HCS7720
card(s). The green STATUS LED will blink approximately once every second while the
HCS7720 card boots up. The boot-up process for an HCS7720 may take up to two
minutes, and there is no ASI output (if applicable) during boot-up.
When the boot-up is complete, both the green STATUS LED and the amber LED at the
base of the X-PORT LINK connector will be lit continuously.
(Continued on next page)

14 206-4180
System Setup (Cont.)
Satellite In
ASI Out
ASI In
IF Out
IF In
RF Out
QAM or VSB
Modulator
DTV
Upconverter
ViP 222k
Satellite
Receiver
DISH Network Satellite Signal *
A/V Cables
(for monitor only)
RF
Coaxial
Cable
RF
Cable
NTSC
Monitor
X-Port Link In
HCS7720
RF
Cable
Ethernet
ASI
Satellite In
ViP 222k
Satellite
Receiver
X-Port Link In
HCS7720
RF
Cable
Ethernet
RF Out
MUX/MOD
Feature
Card
(Up to 8
Inputs)
Card
Frame
Combiner
Laptop
PC
Service Port
Connection
RF
Distribution
System
Laptop
PC
Service Port
or Ethernet
Connection
Data Bus on
Card Frame
Backplane
A/V Cables
(for monitor only) NTSC
Monitor
DISH Network Satellite Signal *
RF
Cable
Combiner
RF
Distribution
System
HDMI Out HDMI In
HDMI Out
HDMI In
Typical Setup Flow Charts for a Single HD Program
HCS7720 Connected to External Modulator and Upconverter
HCS7720 Controlled by MUX/MOD Feature Card
Satellite In
ASI Out
ASI In
IF Out
IF In
RF Out
QAM or VSB
Modulator
DTV
Upconverter
ViP 222k
Satellite
Receiver
DISH Network Satellite Signal *
A/V Cables
(for monitor only)
RF
Coaxial
Cable
RF
Cable
NTSC
Monitor
X-Port Link In
HCS7720
RF
Cable
Ethernet
ASI
Satellite In
ViP 222k
Satellite
Receiver
X-Port Link In
HCS7720
RF
Cable
Ethernet
RF Out
MUX/MOD
Feature
Card
(Up to 8
Inputs)
Card
Frame
Combiner
Laptop
PC
Service Port
Connection
RF
Distribution
System
Laptop
PC
Service Port
or Ethernet
Connection
Data Bus on
Card Frame
Backplane
A/V Cables
(for monitor only) NTSC
Monitor
DISH Network Satellite Signal *
RF
Cable
Combiner
RF
Distribution
System
HDMI Out HDMI In
HDMI Out
HDMI In
(Continued from previous page)
The green LED on the X-PORT LINK connector should be blinking once every two to three
seconds (if video is present on the Ethernet).
8. If applicable, connect the RF output on the upconverter to the combiner.
9. Check one or more room receivers to make sure all content is properly mapped and
available.
* Multi-switch will be
necessary if the number of
transcoders exceeds the dish
antenna’s capacity.
* Multi-switch will be
necessary if the number of
transcoders exceeds the dish
antenna’s capacity.

206-4180 15
The HCS7720 contains several internal registers for different configuration options. There
are two methods available for configuration purposes:
• Service Port Method
• Controller Card Method
This document describes configuration procedures using the Service Port Method, which
requires that you connect a PC directly to the transcoder Service Port. For configuration
procedures using the Controller Card Method, refer to the Installation & Setup Guide for the
feature card installed in the card frame CONTROLLER slot.
Note: Before you proceed with any additional configuration, the ViP 222k
satel lite receiver(s) and the HCS7720 card(s) should be installed and operating
as described in the Installation and Setup sections in this manual.
Connect a PC to the HCS7720 Service Port
Connect the PC to the HCS7720 Service Port using the FTDI TTL-USB cable (P/N TTL-
232R-5V-AJ):
• Plug the USB end of the cable into an open USB port on your PC. If necessary, install the
device driver.
• Plug the other end of the cable into the Service Port jack on the HCS7720 front panel.
Access the HCS7720 Main Menu
1. Using HyperTerminal or an equivalent terminal emulation program on the PC, configure
the serial port as follows:
• Bits per second/baud = 115200
• Data bits = 8
• Parity = None
• Stop bits = 1
• Flow Control = None
Then, initiate communication with the HCS7720.
2. Press Enter to refresh the menu display in the terminal.
You now have access to the HCS7720 conguration Main Menu (see example on following
page). Note that Main Menu options may vary from the example shown, depending on the
transcoder rmware version.
3. At the Command > prompt, type the desired menu command and press Enter.
The following sections describe the configuration commands.
Conguration Options

16 206-4180
Example: HCS7720 Main Menu
-----------------------------------------
Main Menu (Copyright 2012 - LGE USA)
-----------------------------------------
1. Install PI Key
2. Read PI Key Checksum
3. Reload PI Key
4. Read Transcoder Information
5. Reset Transcoder
6. Update Firmware
7. Satellite Receiver Menu
8. Read MUX Bitrates
Command >
Install a Pro:Idiom Key
The Pro:Idiom encrypter built into the HCS7720 contains a default encryption key. When first
installed, the HCS7720 will use this key to encrypt content. This command enables you to
change the encryption key, if necessary.
Note: In order for a Pro:Idiom encrypted channel to be displayed, the receiver
must contain a Pro:Idiom decrypter, and the receiver must be congured to allow
decryption of the desired channel.
Note: The process of updating the encryption key will synchronize the decryption
key in any receiver tuned to this card’s output. If the target receiver is turned off or
viewing a different card, the synchronization will not occur, and the output will be
scrambled. Ensure that all encrypters and decrypters in a system are synchronized
to the same key.
1. Confirm the directory location of the Pro:Idiom key (.hex) file.
2. Connect a PC to the HCS7720 Service Port, and access the Main Menu as described on
the previous page.
3. At the Main Menu Command > prompt, type the menu command that corresponds to the
Install PI Key option and press Enter.
4. At the Setup PI key. Continue (y/n)? prompt, type y and press Enter to
continue.
5. The system will request a key file. Transfer the new Pro:Idiom key file using Xmodem
protocol.
For example, in HyperTerminal, select Transfer and then Send File.... In the Send File
window, enter or select the appropriate Pro:Idiom key file in the Filename field, and select
Xmodem in the Protocol field.
The system will print out the result of the update process. Note that the new key will be stored
in non-volatile storage regardless of process results.
Conguration Options (Cont.)

206-4180 17
View the Pro:Idiom Key Checksum
Use the following procedure to display the Pro:Idiom key checksum.
1. Connect a PC to the HCS7720 Service Port, and access the Main Menu as described on
page 15.
2. At the Main Menu Command > prompt, type the menu command that corresponds to the
Read PI Key Checksum option and press Enter to display the Pro:Idiom key checksum,
for example:
PI key checksum is xxxxxxxxxx
where xxxxxxxxxx is a 10-digit number that identifies the Pro:Idiom key file installed on
the transcoder.
Note: All transcoder cards in the card frame must have the same Pro:Idiom key
file installed.
Reload the Pro:Idiom Key
Use the following procedure, as necessary, to reload the Pro:Idiom key.
1. Connect a PC to the HCS7720 Service Port, and access the Main Menu as described on
page 15.
2. At the Main Menu Command > prompt, type the menu command that corresponds to the
Reload PI Key option and press Enter.
3. At the Reload PI key. Continue (y/n)? prompt, type y and press Enter to
continue.
When the reload is complete, the system will display: Reload PI complete OK
View System Information
Use the following procedure to display HCS7720 hardware and software information.
1. Connect a PC to the HCS7720 Service Port, and access the Main Menu as described on
page 15.
2. At the Main Menu Command > prompt, type the menu command that corresponds to the
Read Transcoder Information option and press Enter.
The System Information display contains important information about the HCS7720, including
the unit hardware ID (firmware version), software versions, MAC address, and serial number,
for example:
Conguration Options (Cont.)
(Continued on next page)

18 206-4180
(Continued from previous page)
System Information
---------------------------
Hardware ID: 7720-v1.1-2011-1026
OS version: HCS7720-943-2011-1025
Application version: 2.5
Encoder version: 1.2
MAC address: 00:0C:63:00:1D:87
S/N: 001-12420016
It is recommended that you record this information for future reference. If you find it necessary
to call customer service or engineering support, please have this information available.
Reset the HCS7720
Use the following procedure to reset the HCS7720.
1. Connect a PC to the HCS7720 Service Port, and access the Main Menu as described on
page 15.
2. At the Main Menu Command > prompt, type the menu command that corresponds to the
Reset Transcoder option and press Enter.
The system resets the HCS7720. During the reset process, several pages of status and
diagnostic messages may be displayed. After reset, the system displays the System
Information banner and Main Menu prompt, and the HCS7720 resumes normal operation.
Update HCS7720 Firmware
If you are not sure of the current firmware version, view and record the System Information for
the transcoder before you initiate the firmware update. See “View System Information” above.
1. Confirm the directory location of the required firmware update configuration (.cfg) and
package (.pkg) files. Note: For a TFTP file transfer, the firmware update files must be
available on the same machine as the TFTP server.
2. Connect a PC to the HCS7720 Service Port, and access the Main Menu as described on
page 15.
3. At the Main Menu Command > prompt, type the menu command that corresponds to the
Update Firmware option and press Enter.
The Firmware Update Menu is displayed:
Firmware Update Menu
--------------------
1. Update Using Serial Xmodem File Transfer
2. Update Using TFTP Transfer
r. Return to Main Menu
>
Conguration Options (Cont.)
(Continued on next page)

206-4180 19
(Continued from previous page)
4. Refer to the appropriate subsection below, depending on the file transfer option used.
(Note: To return to the Main Menu without updating firmware, type r and press Enter.)
Xmodem File Transfer
a) At the > prompt, type 1 and press Enter to select the Xmodem File Transfer option.
b) The system will request a configuration (.cfg) file. Transfer the new configuration file
using Xmodem protocol.
For example, in HyperTerminal, select Transfer and then Send File.... In the Send
File window, enter or select the appropriate configuration file in the Filename field,
and select Xmodem in the Protocol field.
c) Upon receipt of the configuration file, the system will request a package (.pkg) file.
Transfer the package file using Xmodem protocol.
TFTP Transfer
The HCS7720 must be connected to an IP network for a TFTP transfer. TFTP transfer
also requires that you set up a TFTP server on the PC. The TFTP server must be on
subnet 192.168.0.x, where x can be any number between 0 and 255, except 200.
a) Connect an Ethernet cable between the HCS7720 X-Port Link and the PC. For this
purpose, you can disconnect the satellite receiver end of the ViP 222k/HCS7720
Ethernet cable, and connect it to the PC.
b) Make sure the firmware update files are available on the same machine as the TFTP
server. Then, set up the TFTP server, and point to the directory in which the firmware
update files are located.
Note the name of the configuration file; you will need it to initiate the transfer.
c) At the menu > prompt, type 2 and press Enter to select the TFTP Transfer option.
d) At the Enter TFTP server IP prompt, type the server's IP address and press
Enter, or simply press Enter if the default IP address shown in square brackets is
correct.
e) At the prompt for the package name, type the configuration file name in the format
“filename.cfg” and press Enter. This will initiate the installation of both the configuration
and package files.
5. The system will display progress messages as well as the result of the update process
(which may take several minutes). When the firmware update is successfully completed,
initiate a reset of the card (see “Reset the HCS7720” on page 18).
6. Repeat steps 2 to 5 for each HCS7720 card that requires a firmware update.
Conguration Options (Cont.)

20 206-4180
View MUX Bitrate Data
Bitrate data is useful for system monitoring and troubleshooting purposes. Use the following
procedure to view MUX bitrate data.
1. Connect a PC to the HCS7720 Service Port, and access the Main Menu as described on
page 15.
2. At the Main Menu Command > prompt, type the menu command that corresponds to the
Read MUX Bitrates option and press Enter.
MUX bitrate data is displayed in millions of bits per second (Mbit/s), for example:
HDMI Input Bitrate: 14.120 Mbit/s (raw 14.120 Mbit/s)
Ethernet Input Bitrate: 0 (raw 9.210 Mbit/s)
Data Output Bitrate: 16.881 Mbit/s
Total Output Bitrate: 19.396 Mbit/s
The bitrate output data indicates the following:
• HDMI Input Bitrate: The data bitrate of the HDMI input. A low or zero value indicates an
HDMI input malfunction.
• Ethernet Input Bitrate: The data bitrate of the Ethernet input. The rst value will be zero,
and the raw value should be non-zero. A raw value of zero indicates an Ethernet input
malfunction.
• Data Output Bitrate: The non-null data bitrate output on the ASI port (if applicable).
If the HDMI Input bitrate is non-zero, a Data Output bitrate of zero indicates an indeterminate
error. In this case, refer to the troubleshooting information in this document, and troubleshoot
the satellite STB and/or the transcoder card.
• Total Output Bitrate: Under standard operating conditions, this value should be nominally
19.396 Mbit/s. If the bitrate differs from this value by more than 1%, troubleshoot the satellite
STB and/or the transcoder card (see troubleshooting information in this document), and then
if necessary, verify that the card frame chassis is properly installed.
Satellite Receiver Menu Commands
Use the following procedure to access the Satellite Receiver Menu.
1. Connect a PC to the HCS7720 Service Port, and access the Main Menu as described on
page 15.
2. At the Main Menu Command > prompt, type the menu command that corresponds to the
Satellite Receiver Menu option and press Enter.
You now have access to the Satellite Receiver Menu (see example on following page).
3. At the Command > prompt, type the desired menu command and press Enter.
The following subsections provide information on each of the commands.
Conguration Options (Cont.)
