LG MEDIA STATION MS400H User manual

MS400H
Network Twin HD Recorder
English
MEDIA STATION
To ensure proper use of this product, please read this
owner’s manual carefully and retain for future reference.

2
This lightning ash with arrowhead symbol within an
equilateral triangle is intended to alert the user to the
presence of uninsulated dangerous voltage within the
product’s enclosure that may be of sufcient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the product.
WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK
HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN OR
MOISTURE.
WARNING: Do not install this equipment in a confined space
such as a book case or similar unit.
CAUTION: The apparatus should not be exposed to water
(dripping or splashing) and no objects lled with liquids, such as
vases, should be placed on the apparatus.
CAUTION concerning the Power Cord
Most appliances recommend they be placed upon a
dedicated circuit;
That is, a single outlet circuit which powers only that appliance
and has no additional outlets or branch circuits. Check the
specication page of this owner's manual to be certain.
Do not overload wall outlets. Overloaded wall outlets, loose or
damaged wall outlets, extension cords, frayed power cords,
or damaged or cracked wire insulation are dangerous. Any of
these conditions could result in electric shock or re. Periodically
examine the cord of your appliance, and if its appearance
indicates damage or deterioration, unplug it, discontinue use
of the appliance, and have the cord replaced with an exact
replacement part by an authorized servicer.
Protect the power cord from physical or mechanical abuse, such
as being twisted, kinked, pinched, closed in a door, or walked
upon. Pay particular attention to plugs, wall outlets, and the point
where the cord exits the appliance.
To disconnect power from the unit, unplug the unit from the
outlet. When installing the product, ensure that the plug is easily
accessible.
Disposal of your old appliance
1. When this crossed-out wheeled bin symbol is
attached to a product it means the product is covered
by the European Directive 2002/96/EC.
2. All electrical and electronic products should be
disposed of separately from the municipal waste
stream via designated collection facilities appointed
by the government or the local authorities.
3. The correct disposal of your old appliance will help
prevent potential negative consequences for the
environment and human health.
4. For more detailed information about disposal of your
old appliance, please contact your city office, waste
disposal service or the shop where you purchased
the product.
For Wireless product European Union
Notice
Products bearing the CE marking comply
with the R&TTE Directive (1999/5/EC),
EMC Directive (2004/108/EC), and the
Low Voltage Directive (2006/95/EC) issued
by the Commission of the European
Community. Indoor use only.
Compliance with these directives implies conformity to the
following European Norms (in parentheses are the equivalent
international standards and regulations):
• EN 55022 (CISPR 22)-Electromagnetic Interference
• EN 55024 (IEC61000-4-2,3,4,5,6,8,11)-Electromagnetic
Immunity
• EN 60065 (IEC 60065) - Product Safety
• EN 300 328-Technical requirements for radio equipment
• 301 489-1 and EN 301 489-17-General EMC requirements for
radio equipment.
European representative :
LG Electronics Service Europe B.V.
Veluwezoom 15, 1327 AE Almere, The Netherlands
(Tel : [phone])
As an Energy Star® Partner, LG has
determined that this product or product
models meet the Energy Star®guidelines
for energy efciency.
Energy Star®is a U.S. registered mark.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK
OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.

3
Copyrights
l Recording equipment should be used only for lawful
copying and you are advised to check carefully what
is lawful copying in the area in which you are making
a copy. Copying of copyright material such as films or
music is unlawful unless permitted by a legal exception
or consented to by the rights owner.
lThis product incorporates copyright protection
technology that is protected by method claims of certain
U.S. patents and other intellectual property rights owned
by Macrovision Corporation and other rights owners.
Use of this copyright protection technology must be
authorized by Macrovision Corporation, and is intended
for home and other limited viewing uses only, unless
otherwise authorized by Macrovision corporation.
Reverse engineering or disassembly is prohibited.
lCONSUMERS SHOULD NOTE THAT NOT ALL
HIGH DEFINITION TELEVISION SETS ARE FULLY
COMPATIBLE WITH THIS PRODUCT AND MAY
CAUSE ARTIFACTS TO BE DISPLAYED IN THE
PICTURE. IN CASE OF 625 PROGRESSIVE SCAN
PICTURE PROBLEMS, IT IS RECOMMENDED
THAT THE USER SWITCH THE CONNECTION TO
THE ‘STANDARD DEFINITION’ OUTPUT. IF THERE
ARE QUESTIONS REGARDING OUR TV SET
COMPATIBILITY WITH THIS MODEL 625p UNIT
PLEASE CONTACT OUR CUSTOMER SERVICE
CENTRE.
Licenses
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby
Laboratories.
Manufactured under license under U.S. Patent #’s:
5,451,942; 5,956,674; 5,974,380; 5,978,762; 6,487,535 &
other U.S. and worldwide patents issued & pending. DTS
and DTS 2.0+ Digital Out are registered trademarks and
the DTS logos and Symbol are trademarks of DTS, Inc. ©
1996-2008 DTS, Inc. All Rights Reserved.
HDMI, the HDMI logo and High-Definition Multimedia
Interface are trademarks or registered trademarks of
HDMI licensing LLC.
YouTube is a trademark of Google Inc.
Picasa Web Albums is a trademark of Google Inc.
DLNA and DLNA CERTIFIED are trademarks and/or
service marks of Digital Living Network Alliance.
WIFI CERTIFIED 802.11n based on Draft 2.0.
Draft 2.0 refers to the version of the not-yet-ratified IEEE
802.11n standard used in Wi-Fi Alliance as of June 2007.
The “HD TV” Logo is trademark of DIGITALEUROPE.
Trademark of DVB Digital video Broadcasting Project
(1991 to 1996)
WARNING:
l Media contents including but not limited to broadcast
materials, movie, music, and photo les are protected
by copyright and that recording copy and playback of
those contents would only be permissible by permission
of the copyright owner. LG has no right to grant such
permission. Permission should always be sought from
the copyright owner.
lAndio and Video recordings and copies you make
using this products are for your personal and non-
commercial use only. You may sell, lend or rent them to
other people. LG is not responsible for your panelties,
disadvantages by illegal use of this product.
About the Symbol Display
“ ” may appear on your TV display during operation
and indicates that the function is not permitted by this
recorder or specific media.
Symbol Used in this Manual
Indicates special notes and operating features.
Indicates tips and hints for making the task easier.
Caution
Indicates hazards likely to cause harm to the recorder
itself or other material damage.

4
Table of contents
File requirement.........................................................................5
File compatibility........................................................................... 5
Home Menu Overview ...............................................................6
Remote control ..........................................................................8
Main unit.....................................................................................9
HDD Installation.......................................................................10
Connection overview .............................................................. 11
Connections to Your TV...............................................................11
(Option A) Best quality - HDMI connection (includes audio and
video).......................................................................................... 12
(Option B) Excellent quality - Component video and stereo audio
connection .................................................................................. 13
(Option C) Connections to your TV (Composite or Scart) .......... 13
Connecting to an Amplier.......................................................... 14
Network connection ................................................................15
Wired network connection .......................................................... 15
Wireless network connection...................................................... 17
Setup Wizard (Initial install)....................................................21
DTV ........................................................ 22
DTV Installation .......................................................................22
Settings for Digital TV.............................................................23
Selecting a Region ..................................................................... 23
Scanning programmes automatically ......................................... 23
Scanning programmes manually................................................ 23
Editing Programme List .............................................................. 24
Setting the Lock System............................................................. 24
Setting a new password ............................................................. 24
Adjusting TV Rating level ........................................................... 25
Setting the antenna power ......................................................... 25
Setting the permanent Timeshift................................................. 25
Setting a recording storage location........................................... 25
Using the Digital TV functions ...............................................26
Viewing the Digital TV ................................................................ 26
Adjusting volume of audio out .................................................... 26
Changing Digital TV programmes .............................................. 26
Setting favorite programmes ...................................................... 26
Viewing the programme information........................................... 26
Selecting DTV audio language................................................... 26
Selecting DTV subtitle language ................................................ 27
Viewing the EPG (Electronic Programme Guide) Display.......... 27
Using the timeshift function manually......................................... 27
Using the permanent timeshift.................................................... 28
Using the teletext (Viewing Teletext) .......................................... 28
Recording TV programmes ....................................................29
Normal Recording....................................................................... 29
Dual Programme Recording....................................................... 29
Timer Recording (Manual).......................................................... 29
Timer Recording (EPG) .............................................................. 30
Canceling a timer recording........................................................ 30
Checking the history................................................................... 30
Editing a timer recording............................................................. 31
Instant Timer Recording ............................................................. 31
Media ..................................................... 32
Playback functions..................................................................33
General playback........................................................................ 33
Sorting the recorded titles .......................................................... 33
Frame-by-Frame playback ........................................................ 34
Fast forward and fast reverse .................................................... 34
Slow down the playing speed .................................................... 34
Skip to the next/previous le ...................................................... 34
Resume playback ...................................................................... 34
Enlarges the playback image .................................................... 34
Selecting a subtitle language .................................................... 34
Selecting a subtitle language code ............................................ 34
Selecting an audio language ..................................................... 35
Repeat playback ........................................................................ 35
Playback from selected time ...................................................... 35
Add les to the Playlist .............................................................. 35
Delete a le/folder from the list .................................................. 35
Renaming a le .......................................................................... 36
Playing selected les ................................................................. 36
Selecting a slideshow speed ..................................................... 36
Selecting a slideshow effect ...................................................... 36
Listening to music while viewing a slideshow ............................ 36
Playing les on your PC .........................................................37
Accessing to your PC ................................................................. 37
Editing the [My_Shortcuts].......................................................... 37
Using [File Copy] features......................................................38
Copying or moving les/folders .................................................. 38
Deleting les/folders ................................................................... 38
DLNA...................................................... 39
About DLNA .............................................................................39
Notes on DLNA features............................................................. 39
Installing Nero MediaHome 4 Essentials.................................... 40
Sharing les and folders............................................................. 40
Operating DLNA feature..........................................................41
General operation....................................................................... 41
YouTube™ ............................................. 42
Operating YouTube™ feature .................................................42
General operation....................................................................... 42
Searching YouTube videos......................................................... 43
Selecting your local site.............................................................. 43
Picasa ................................................... 44
Operating Picasa Web Albums feature..................................44
General operation....................................................................... 44
Searching Picasa Web Albums .................................................. 45
Viewing your Picasa Web Albums .............................................. 45
Removing an ID from the ID List ................................................ 45
Setup...................................................... 46
General Setup Operation ........................................................46
DTV settings............................................................................... 46
Audio settings............................................................................. 47
Display settings .......................................................................... 47
Record settings........................................................................... 48
Network settings......................................................................... 48
System settings .......................................................................... 49
Others settings ........................................................................... 49
Reference .................................................................................50
Software update via the Internet ................................................ 50
Software update via built-in tuner............................................... 50
Formatting HDD.......................................................................... 50
About the HDD ........................................................................... 51
Connecting an USB Device........................................................ 51
Controlling a TV with the Supplied Universal Remote Control ... 52
Code numbers of controllable TVs ............................................. 53
Troubleshooting.......................................................................... 55
Specications ............................................................................. 57
IMPORTANT INFORMATION RELATING TO NETWORK
SERVICES ................................................................................58
Open source software notice .................................................59

5
File requirement
File compatibility
l Because the compatibility and available playback
functions on the [DLNA] menu are tested on the
bundle DLNA server (Nero MediaHome 4 Essentials)
environment, file requirements and playback functions
on the [DLNA] menu may differ depending on the media
servers.
lThe file requirements on this page are not always
compatible for DLNA features. There may have some
restrictions by file features and media server's ability.
l This unit can recognize file/folder name less than 512
characters include path name.
l This unit can recognize filles less than 4000 file/folders
is one folder.
l Depending on the size and number of the files, it may
takes several minutes to read the contents of the media.
Movie le
• Available resolution size: 1920 x1080 (W x H) pixels.
• The file names of movie and subtitle are limited to 50
characters.
• Supported extensions: “.avi”, “.divx”, “.mpg”, “.mpeg”, “.m2ts”,
“.mp4”, “.mkv”, “.wmv”, “.ts”, “.xvid”, “.asf”, “.mov”, “.trp”,
“.dat”, “.flv”, “.mts”, “.tp”
• Supported encodings: DIVX3.xx, DIVX4.xx, DIVX5.xx, XVID”,
“DIVX6.xx (Standard playback only), MPEG1/2,
H.264/MPEG-4 AVC, WMV9, VC-1
• This device might not playback the file which is not encoded
on the list, even though its extesion belongs to “Supported
extensions” above.
• Playable movie subtitle: SubRip (.srt / .txt), SAMI (.smi),
SubStation Alpha (.ssa/.txt), MicroDVD (.sub/.txt), SubViewer
2.0 (.sub/.txt), VobSub (“.idx” and “.sub” files should be
together in the media)
• Playable Audio format: “Dolby Digital”, “DTS”, “MP3”, “WMA”,
“AAC”
• Not all WMA Audio formats are compatible with this recorder.
• Sampling frequency: within 8 - 48 kHz (MP3),
within 32 - 48 kHz (WMA)
• Bit rate: within 8 - 320 kbps (MP3),
within 32 - 192 kbps (WMA)
• This recorder supports H.264/MPEG-4 AVC profile Main,
High at Level 4.1. and Baseline at Level 3.1
• For a file with higher level, the recorder will ask whether you
want to play or not.
• Displaying subtitle on DLNA is only available for bundle
DLNA server (Nero MediaHome 4 Essentials) environment.
• This recorder does not support the file that are recorded with
GMC. (GMC: Global Motion Compensation)
Music files
• File extensions: “.mp3”, “.wma”, “.aac”, “.ogg”, “.asf”, “.flac”,
“.mp4”
• Sampling frequency: within 8 - 48 kHz (MP3),
within 32 - 48kHz (WMA)
• Bit rate: within 8 - 320kbps (MP3),
within 32 - 192kbps (WMA)
• This recorder does not support the information of ID3 Tag in
the MP3 file.
• The total playback time indicated on the screen may not
correct for VBR files.
• The total playback time will not be displayed for “.aac”, and
“.flac” files.
Photo file
• File extensions: “.jpg”, “.jpeg”, “.bmp”, “.png”, “.gif”, “.tif/tiff”
• Photo files with “.png”, “.gif” or “.tif/.tiff” extensions are not
be completely supported on this recorder. Only limited basic
format of them are supported.
• Recommended size:
Less than 4,000 x 3,000 x 24 bit/pixel
Less than 3,000 x 3,000 x 32 bit/pixel
• Progressive and lossless compression photo image files are
not supported.

Setup Wizard
(page 21)
DTV Installation
(page 22)
Settings for Digital TV
(page 23-25)
Using the Digital TV functions
(page 26-28)
Recording TV programmes
(page 29-31)
File requirement
(page 5)
Playback functions
(page 33-36)
Playing les on your PC
(page 37)
Using [File Copy] features
(page 38)
Network connection
(page 15-20)
About DLNA
(page 39)
Installing Nero MediaHome 4
Essentials
(page 40)
Operating DLNA feature
(page 41)
6
Home Menu Overview
Starting from HOME
To access numerous functions of the recorder, press the “HOME” button on the remote.

7
Home Menu Overview
Basic button operations
- HOME : Accesses or removes the HOME menu.
- b/ B :Used to navigate on-screen displays.
- OK ( ): Acknowledges menu selection.
- BACK (O): Exits the menu.
Operating YouTube feature
(page 42)
General operation
(page 42)
Searching YouTube videos
(page 43)
Selecting your local site
(page 43)
Operating Picasa Web Albums
feature
(page 44)
General operation
(page 44)
Searching Picasa Web Albums
(page 45)
Viewing your Picasa Web
Albums
(page 45)
Removing an ID from the ID
List
(page 45)
General Setup Operation
(page 46)
DTV settings
(page 46)
Audio settings
(page 47)
Display settings
(page 47-48)
Record settings
(page 48)
Network settings
(page 48)
System settings
(page 49)
Others settings
(page 49)

POWER (1): Switches the recorder ON or OFF.
TV/PVR: To view channels selected by the recorder tuner or by the TV tuner.
VOL (- / +): Adjusts the sound level of the recorder.
TV Control Buttons: You can control the programme selection, sound level, input
source, and power switch of your TV (see page 52).
0-9 numerical buttons: Selects numbered options in a menu.
REC (z): Starts recording and copying.
TIMESHIFT: Pauses live TV/playback (timeshift) for a live TV programme (see page
27).
m/ M(SCAN): Searches backward or forward.
./ >(SKIP): Goes to next or previous track/le.
X(PAUSE): Pauses playback.
B(PLAY): Starts playback.
x(STOP): Stops playback.
HOME: Accesses or exits the HOME menu.
GUIDE: Displays the EPG menu.
b/ B/ v/ V(left/right/up/down): Navigates on-screen displays.
OK ( ): Acknowledges menu selection or displays the programme list.
BACK (O): Exits the menu or back to previous step.
INFO ( ): Displays or exits On-Screen Display.
PR (U/ u): Scans up or down through memorized programmes.
PAGE (U/ u): Moves to next or previous page of contents/TV list.
REPEAT: Repeats a desired sequence.
ZOOM: Displays or exits the [ZOOM] menu.
MARKER ( ): Used for selecting multiple files or folders in certain operation.
EDIT: Displays an editing menu
Coloured buttons: Used for [MOVIE], [PHOTO] and [MUSIC] menu or when an
EPG screen is displayed. The function of each button will be described on-screen,
and changes depending on the screen being displayed.
PR LIST: Displays the programme list.
FAV: Displays the favorite programme list.
AUDIO ( ): Selects an audio language or audio channel.
SUBTITLE ( ): Selects a subtitle language.
TIMER REC: Display [Timer Recording] menu.
TEXT: Switches between teletext mode and normal TV viewing.
GOTO: Displays the time search option during movie playback.
RESOLUTION: Sets the output resolution for HDMI and COMPONENT VIDEO
OUT jacks. (This key only work in TV watching mode or Home Menu mode.)
8
Remote control

a1(POWER) Button
Switches the recorder ON or OFF.
bExternal HDD Slot
Mounting an additional HDD here.
cDisplay window
Shows the current status of the recorder.
dRemote Sensor
Point the remote control here.
eRESET
Press this button to reboot.
fz(REC.)
Starts recording.
gPROG. v/V
Scans up or down through memorized programmes.
hUSB Port
Connect a USB Device.
9
Main unit
aAC IN connector
Connect the supplied power cord.
bUSB Port
Connect the supplied Wireless LAN Adapter.
cLAN port
Connect a network with an always-on broadband
connection.
dHDMI OUT
Connect to TV with HDMI inputs. (Interface for digital
audio and video)
eCOMPONENT VIDEO OUT (Y PBPR)
Connect to a TV with Y PBPRinputs.
fDIGITAL AUDIO OUT (COAXIAL)
Connect to digital (coaxial) audio equipment.
gANTENNA IN
Connect the antenna to this terminal.
hVIDEO OUT
Connect to a TV with video inputs.
iAUDIO OUT (Left/Right)
Connect to a TV with audio inputs.
jDIGITAL AUDIO OUT (OPTICAL)
Connect to digital (optical) audio equipment.
kANTENNA OUT (TO TV)
Passes the signal from the ANTENNA IN jack to your
TV/monitor.
lSCART (TO TV)
Connect to a TV with SCART jack.
PUSH / OPEN
 a b c d e f g h
hijk l
 a b cd e fg

10
HDD Installation
You can install an additional HDD to the external HDD slot.
Preparations:
lPrepare a 3.5” SATA HDD.
lIt is strongly recommended to use SATA
standard HDD of makers for the external HDD.
(Seagate, Western Digital, Hitachi, Samsung)
lThe recorder must be turned off before
installation.
1 Press PUSH/OPEN on the front of the recorder.
PUSH / OPEN
2 Grab the holder and extract it completely to the arrow
direction.
3 Stretch out the Right/Left hooks as shown below.
Match the hooks with External case. Push and fit the
HDD into the place completely.
HDD
External HDD case
4 Fasten the hooks as shown below.
5 Insert the HDD to the recorder as shown below and
push it to fit into the recorder completely.
2
1
If you want to completely fix the HDD, fix the screws as
below.
If an external SATA HDD is not installed on the HDD slot, Timeshif, Playlist functions and downloading Picasa Web
Albums are not available.
The external SATA HDD on the HDD slot must be formatted from this unit. (Refer to "Formatting HDD" on page 50.)

11
lDepending on your TV and other equipment you wish to connect, there are various ways you could connect the
recorder. Use only one of the connections described on pages 12-14.
l Please refer to the manuals of your TV, Stereo System or other devices as necessary to make the best connections.
Be sure to switch off the recorder before installation and connection.
Broadband
Service
Wireless LAN
Adapter
Broadband
Service
Connections to Your TV
Make one of the following connections, depending on the capabilities of your existing equipment.
Connect to your TV with option A, B or C.
Caution
lMake sure the recorder is connected directly to the TV. Tune the TV to the correct video input source.
l Do not connect the recorder’s AUDIO OUT jack to the phono in jack (record player) of your audio system.
l Do not connect your recorder via your VCR. The image could be distorted by the copy protection system.
Connection overview

12
(Option A) Best quality - HDMI connection (includes audio and video)
If you have a HDMI TV or monitor, you can connect it to this recorder using a HDMI cable H. Connect the HDMI jack on
the recorder to the HDMI jack on a HDMI compatible TV or monitor. Set the TV’s source to HDMI (refer to TV’s Owner’s
manual).
l You must select a HDMI audio output and a maximum sampling frequency that your TV accepts using [Digital Output]
option on the [Setup] menu (see page 47).
l If a connected HDMI device does not accept the audio output of the recorder, the HDMI device’s audio sound may be
distorted or may not output.
l When you use HDMI connection, you can change the resolution for the HDMI output by pressing RESOLUTION
button in TV watching mode or in Home Menu mode.
Caution
l Changing the resolution when the connection has already been established may result in malfunctions. To solve the
problem, turn off the recorder and then turn it on again.
l When the HDMI connection with HDCP is not verified, TV screen is changed to black screen. In this case, check the
HDMI connection, or disconnect the HDMI cable.
l If there is noise or lines on the screen, please check the HDMI cable (length is generally limited to 4.5m).
Additional Information for HDMI
l When you connect a HDMI or DVI compatible device make sure of the following:
- Try switching off the HDMI/DVI device and this recorder. Next, switch on the HDMI/DVI device and leave it for
around 30 seconds, then switch on this recorder.
- The connected device’s video input is set correctly for this Recorder.
- The connected device is compatible with 720x576p, 1280x720p, 1920x1080i or 1920x1080p video input.
l Not all HDCP-compatible HDMI or DVI devices will work with this recorder.
- The picture will not be displayed properly with non-HDCP device.
- This recorder does not playback and TV screen is changed to black screen.

13
(Option B) Excellent quality - Component video and stereo audio con-
nection
Connect the COMPONENT VIDEO OUT jacks on the Recorder to the corresponding input jacks on the TV using Y PB
PR cables C. Connect the left and right AUDIO OUT jacks of the Recorder to the audio left and right IN jacks on the TV
using the audio cables A.
When you cannot use the screen, you can change resolution for the component VIDEO OUT by pressing RESOLUTION
button in TV watching mode or in Home menu mode (Refer to “Resolution setting” on page 47.)
(Option C) Connections to your TV (Composite or Scart)
Connect the VIDEO OUT jack on the Recorder to the video in jack on the TV using the video cable supplied V. Connect
the Left and Right AUDIO OUT jacks on the Recorder to the audio left/right in jacks on the TV using the supplied audio
cables A.
Connect one end of the scart cable into the AV1 SCART jack S on the unit and other end to the corresponding in jack
on your TV. You can get Audio and Video signals together with this connection.
If you use this connection, set the TV’s source selector to VIDEO.

14
Connecting to an Amplifier
Make one of the following connections, depending on the capabilities of your existing equipment.
Connecting to an Amplifier via 2 Channel Audio Output
Connect the Left and Right 2CH AUDIO OUT jacks (A) on the player to the audio left and right in jacks on your amplifier,
receiver, or stereo system, using audio cables.
Connecting to an Amplifier via Digital Audio Output (Optical or Coaxial)
Connect the player’s DIGITAL AUDIO OUT (OPTICAL or COAXIAL) jack to the corresponding in jack (OPTICAL Oor
COAXIAL X) on your amplifier. Use an optional digital (optical Oor coaxial X) audio cable. You will need to activate the
unit’s digital output. (See “[Audio] Menu” on page 47.)
AOX
Amplifier/Receiver
Connecting to an Amplier via HDMI Output
Connect the unit HDMI OUT jack to the corresponding in jack on your amplier. Use a HDMI cable (H1). You will need to
activate the player’s digital output. (See “[Audio] Menu” on page 47.)
H2
H1
Digital Multi-channel sound
A digital multi-channel connection provides the best sound quality. For this you need a multi-channel Audio/Video
Receiver that supports one or more of the audio formats supported by your player. Check the receiver manual and the
logos on the front of the receiver. (LPCM, Dolby Digital, Dolby Digital Plus and DTS)
Connect the amplier’s HDMI output jack to HDMI input jack on your TV using a HDMI cable (H2) if your amplier has
HDMI output jack.

15
This recorder can be connected to the local area network (LAN) via the LAN port or the wireless LAN adapter.
Be sure to set the network configuration before using this recorder.
You can use the wired and/or wireless network depending on your network environment.
Wired network connection
Using a wired network provides the best performance, because the attached devices connect directly to the network and
are not subject to radio frequency interference.
Please refer to the documentation for your network device for further instructions.
The following connection example explain how to connect to the internet using LAN cable.
If you want to access content from PCs or DLNA servers, this recorder must be connected to the same local area
network with them via a router.
Router
Other devices 
such as DLNA server
PC
Other devices 
such as DLNA server PC
PC
Access point 
or wireless router
PC
Other devices
such as DLNA server
Broadband
Internet
Broadband
Internet
Router
Or
Caution
l When plugging or unplugging the LAN cable, hold the plug portion of the cable. When unplugging, do not pull on the
LAN cable but unplug while pressing down on the lock.
l Do not connect a modular phone cable to the LAN port.
lSince there are various connection configurations, please follow the specifications of your telecommunication carrier
or internet service provider.
Network connection

Wired network setting (Auto)
If there is a DHCP server on the local area network (LAN)
via wired connection, this recorder will automatically be
allocated an IP address.
Preparation:
Before setting the wired network, you need to:
– connect the broadband internet to your home
network.
1Press HOME.
2Use b/B to select the [Setup], and press OK.
3Use b/B to select the [Network] option.
4Use v/V to select the [Wired LAN Setup], and press
OK.
5Use v/V to select the [Auto], and press OK.
lIf you want to set the IP address of the DNS server,
use v/V/b/B to select the [DNS server] field and
input the IP address using numerical buttons.
6Use v/V to select the [OK], and press OK.
7Use b/B to select the [OK], and press OK.
Wired network setting (Manual)
If there is no DHCP server on the network and you want
to set the network manually, follow the instructions as
below.
1Follow the steps 1-3 from “Wired network setting
(Auto)” on page 16.
2Use v/V to select the [Wired LAN Setup], and press
OK.
3Use v/V/b/B to move to the [IP Address], [Subnet
Mask], [Gateway] and [DNS Server] fields, and fill
them using numerical buttons.
4Press OK when you finish inputting all the network
information.
5Use b/B to select the [OK], and press OK.
16

17
Wireless network connection
Another network connection is using the supplied wireless adapter.
This recorder supports an IEEE 802.11n wireless module using supplied wireless LAN adapter, which also supports
the 802.11b/g standards. For the best wireless performance, we recommend the use of a IEEE 802.11n certified Wi-Fi
network (access point or wireless router).
Refer to the setup instructions supplied with your access point or wireless router for detailed connection steps and
network settings.
The following connection example explain how to connect to the internet using an access point or wireless router.
If you want to access content from PCs or DLNA servers, this recorder must be connected to the same local area
network with them via a wireless network device.
Router
Other devices 
such as DLNA server
PC
Other devices 
such as DLNA server PC
PC
Access point 
or wireless router
Other devices
such as DLNA server
Broadband
Internet
PC
PC
Access point
or wireless router
Wireless
communication
If you do not have a wireless network at your home, you can connect directly to the wireless network equipped computer
using peer to peer (Ad-Hoc) setting.
Refer to page 19 for more information of peer to peer connection.
Wireless
communication
Caution
Using wireless network can be affected by the household devices using radio frequencies.Therefore, operating quality
may not good with wireless network connection. Wired network connection is strongly recommended.

Wireless LAN adapter connection
1 Connect the supplied wireless LAN adapter to the USB
port on the rear panel.
2Fold the wireless LAN adapter to the upper direction.
Wireless network setting (Infrastructure)
If there is a DHCP server on the local area network (LAN)
via wired connection, this recorder will automatically be
allocated an IP address.
Preparation:
Before setting the wireless network, you need to:
– connect the broadband internet to the wireless
home network.
– connect the wireless LAN adapter on the USB
port.
– set the access point or wireless router.
– note the SSID and security code of the network.
1Press HOME.
2Use b/B to select the [Setup], and press OK.
3Use b/B to select the [Network] option.
4Use v/V to select the [Wireless Setup], and press OK.
5Use v/V to select a [Profile Name], and press OK.
l A maximum of 3 profile names can be set for the
wireless network setup.
6Use v/V to select the [Infrastructure (AP)], and press
OK.
l The recorder scans for all of the available access
points or wireless routers within range and displays
them as a list.
7Use v/V to select a SSID, and press OK.
If you have security on your access point or wireless
router, verify that the WEP or WPA key that was
entered into the recorder matches the router’s
information exactly.
You need to input the security code as necessary.
l Select [Alphabet Capital], [Alphabet Small] or
[Symbol], and press OK to change the character set
of the virtual keyboard.
l[Space]: Inserts a space at the cursor position.
l[Delete]: Delete a previous character at the cursor
position.
l[T t]: Moves cursor to the left or right.
l[OK]: Complete inputting security code.
l[Cancel]: Cancels the naming, and return to the
previous.
8Check the network information, and press OK to finish
the network setup.
18

19
Wireless network setting (peer to peer)
If you do not have a wireless network device at your
home, you can connect directly to the wireless network
equipped computer using [Peer to Peer (Ad Hoc)] setting.
For this connection, features which require internet
connection such as YouTube, Picasa Web Albums cannot
be operated.
Preparation:
Before setting the peer to peer connection, you need
to:
– connect the wireless LAN adapter on the USB
port.
– prepare the wireless network equipped computer.
1 Follow the steps 1-5 from “Wireless network setting
(Infrastructure)” on page 18.
2Use v/V to select the [Peer to Peer (Ad Hoc)], and
press OK.
3Use v/V to select the [Wireless SSID], and press OK
to display the virtual keyboard.
l Select [Alphabet Capital], [Alphabet Small] or
[Symbol], and press OK to change the character set
of the virtual keyboard.
l[Space]: Inserts a space at the cursor position.
l[Delete]: Delete a previous character at the cursor
position.
l[T t]: Moves cursor to the left or right.
l[OK]: Complete inputting SSID.
l[Cancel]: Cancels the naming, and return to the
previous.
4If you want to set the security, use v/V to select the
[Shared key (WEP)], and press OK to display the
virtual keyboard.
l Refer to step 3 above for using virtual keyboard.
lIf you do not want to set the security for the wireless
connection, select the [Open System], and press
OK.
5Use v/V to select the [Host IP] field, and input the IP
address using numerical buttons.
lUsing default IP address is recommended.
6 Press yellow coloured button to complete the [Ad-Hoc
Setup] settings.
7Check the network information, and press OK to finish
the network setup.
8 On your computer, the SSID you have set can be
found on the wireless network list.
lPlease refer to the documentation for your computer
or operating system for further instructions.
There may be various ways to get Ad-Hoc connection
to your computer depending on the operating system,
wireless network application,

Notes on Network Connection
l Many network connection problems during set up can
often be fixed by re-setting the router or modem.
After connecting the recorder to the home network,
quickly power off and/or disconnect the power cable of
the home network router or cable modem. Then power
on and/or connect the power cable again.
lDepending on the internet service provider (ISP), the
number of devices that can receive internet service
may be limited by the applicable terms of service. For
details, contact your ISP.
l Our company is not responsible for any malfunction of
the recorder and/or the internet connection feature due
to communication errors/ malfunctions associated with
your broadband internet connection, or other connected
equipment.
l Some internet contents may require a higher bandwidth
connection.
lEven if the recorder is properly connected and
configured, some internet contents may not operate
properly because of internet congestion, the quality or
bandwidth of your internet service, or problems at the
provider of the content.
l Some internet connection operations may not be
possible due to certain restrictions set by the Internet
service provider (ISP) supplying your broadband
Internet connection.
l Any fees charged by an ISP including, without limitation,
connection charges are your responsibility.
l A10 Base-T or 100 Base-TX LAN port is required for
wired connection to this recorder. If your internet service
does not allow for such a connection, you will not be
able to connect the recorder.
l You must use a Router to use xDSL service.
lADSL modem is required to use DSL service and a
cable modem is required to use cable modem service.
Depending on the access method of and subscriber
agreement with your ISP, you may not be able to
use the internet connection feature contained in
this recorder or you may be limited to the number of
devices you can connect at the same time. (If your ISP
limits subscription to one device, this recorder may
not be allowed to be connected when a PC is already
connected.)
l The use of a “Router” may not be allowed or its
usage may be limited depending on the policies and
restrictions of your ISP. For details, contact your ISP
directly.
l The wireless network operate at 2.4GHz radio
frequencies that are also used by other household
devices such as cordless telephone, Bluetooth®
devices, microwave oven, and can be affected by
interference from them.
lTurn off all unused network equipment in your local
home network. Some devices may generate network
traffic.
l For the purpose of better transmission, place the
recorder as close as possible to the access point.
lIn some instances, placing the access point or wireless
router at least 1.5 ft (0.45m) above the floor may
improve the reception.
l Move closer to the access point if possible or re-orient
the recorder so there is nothing between it and the
access point.
lThe reception quality over wireless depends on many
factors such as type of the access point, distance
between the recorder and access point, and the location
of the recorder.
lADSL modem is required to use DSL service and a
cable modem is required to use cable modem service.
Depending on the access method of and subscriber
agreement with your ISP, you may not be able to
use the internet connection feature contained in this
recorder or you may be limited to the number of devices
you can connect at the same time. (If your ISP limits
subscription to one device, this recorder may not be
allowed to connect when a PC is already connected.)
l The use of a “Router” may not be allowed or its
usage may be limited depending on the policies and
restrictions of your ISP. For details, contact your ISP
directly.
l Your ISP may protect this recorder from being
connected to network when confirming MAC
ADDRESS. In that case, contact your ISP to request to
initialize MAC ADDRESS.
20
