Lg F12u2hdm series User manual

WASHING MACHINE

SERVICE MANUAL

CAUTION

READ THIS MANUAL CAREFULLY TO DIAGNOSE PROBLEMS

CORRECTLY BEFORE OFFERING SERVICE.

BEFORE SERVICING THE WASHING MACHINE, UNPLUG THE POWER

CORD TO AVOID THE RISK OF AN ELECTRIC SHOCK.

WHEN SERVICING INTERNAL PARTS, USE ONLY SERVICE PARTS

SUPPLIED FROM LG.

AFTER SERVICING THE ELECTRIC WIRE, INSURE THAT INSULATION

TAPE IS APPLIED TO PREVENT AN ELECTRICAL SHORT.

MODEL : F12U2HDM(P)(0~9)N

website : http://biz.lgservice.com

e-mail : http://LGEservice.com/techsup.html

CONTENTS1.SPECIFICATIONS.............................................................................................................................32.FEATURES & TECHNICAL EXPLANATION.....................................................................................43.PARTS IDENTIFICATION .................................................................................................................64.INSTALLATION..................................................................................................................................75.OPERATION ................................................................................................................................... 126.WIRING DIAGRAM / PCBLAYOUT................................................................................................ 197.TROUBLESHOOTING......................................................................................................................217-1.BEFORE PERFORMINGSERVICE .........................................................................................217-2.LOAD TEST MODE ..................................................................................................................217-3.HOW TO CHECKTHE WATER LEVEL FREQUENCY ............................................................227-4.ERRORDISPLAY .....................................................................................................................237-5.TROUBLESHOOTINGWITHERROR ..................................................................................... 25 IE (Water Inlet Error) ..............................................................................................................26 UE (Unbalanced Error) ...........................................................................................................27 OE (Water Outlet Error) ..........................................................................................................28 FE (Over Flow Error) ..............................................................................................................30 PE (Pressure Sensor S/W Error) ............................................................................................31 dE2 (Door open Error)............................................................................................................33 dE1 (Door switch Error) ..........................................................................................................33 tE (Thermistor (Heating) Error) ...............................................................................................35 dHE (Dry Heater Error) .............................................................................................................42 LE (Motor Lock Error) .............................................................................................................388.TROUBLESHOOTINGWITHOUT ERROR CODES .......................................................................45 Power Failure or no power......................................................................................................45 Vibration & Noise during spin .................................................................................................46 Detergent & Softener does not flow in ....................................................................................47 Before using the Tag On function.........................................................................................50 Water Leak .............................................................................................................................489. PART INSPECTION........................................................................................................................529-1.FILTER ASSEMBLY (LINE FILTER) .........................................................................................529-2.DOOR LOCK SWITCH ASSEMBLY ......................................................................................... 539-3.STATOR ASSEMBLY ...............................................................................................................559-4.

PUMP MOTOR ASSEMBLY

.......................................................................................................589-5.INLET VALVE ASSEMBLY .......................................................................................................5910. DISASSEMBLY INSTRUCTIONS .................................................................................................. 6011. EXPLODED VIEW AND PART LIST ..............................................................................................68

1. SPECIFICATION

To reduce the risk of personal injury, adhere to all industry recommended safety procedures including

the use of long sleeved gloves and safety gla

Failure to follow all of the safety warnings in this

manual could result in property damage, personal

injury or death.

WARNING

ITEM

POWER SUPPLY

PRODUCT WEIGHT

OPERATION WATER PRESSURE

CONTROL TYPE

WASH CAPACITY

DIMENSION

WASH PROGRAM

RINSE

DOOR SWITCH TYPE

WATER LEVEL

RESERVATION

SENSING LAUNDRY AMOUNT

FUZZY LOGIC

DISPLAY REMAINING TIME

ERROR DIAGNOSIS

POWER AUTO OFF

CHILD LOCK

AUTO RESTART

TIME SAVE

ELECTRICITY

CONSUMPTION

WASHING

SPIN

DRAIN MOTOR

WASH HEATER

REVOLUTION

SPEED

WASH

SPIN

F12U2HDM(P)(0~9)N: No Spin / 400 /600/ 800 / 1000 / 1100 / 1200

46 rpm

100 ~ 1000 kPa (1.0 kgf / cm2~ 10.0 kgf / cm2)

Electronic

Refer to the Rating Label

F12U2HDM(P)(0~9)N : 600mm x 450mm x 850mm

Cotton,Cotton Large,Mix,Easy Care,Durvet,Hygiene,

Baby Care,Sports Wear,Gentle Care,Direct Wear,Stain

Care,Quick 30,Wash+Dry(4kg),Download Cycle

Normal, Rinse+, Rinse Hold

PTC+Solenoid

by Pressure Sensor S/W

From 3 hours to 19 hours

Adapted

No Adapted

Adapted

12 items

Adapted

SMART NFC (Tag On function)

Smart Diagnosis function (3.0)

155 W

490 W

37 W

1700 W

1350 W

220 V - 240 V ~, 50 Hz

F12U2HDM(P)(0~9)N:64kg

Refer to 1 page



2.FEATURES & TECHNICAL EXPLANATION2-1.Product FeaturesInverter Direct Drive system

The advanced Brushless DC motor directly drives the drum without belt and pulley.Low noise speed control system

By sensing the amount of load and balance, it evenly distributes loadto minimize the spinning noise level.Child Lock

The Child Lock prevents children from pressing any button to changethe settings during operation.More economical with Intelligent Wash system

Intelligent Wash System detects the size of load and water temperature,and then determines the optimum water level and washing time tominimize energy and water consumption.Tag on

This is a function that may use Diagnosis, Download Course, WashingCoach, One Touch Washing, etc. when you touch the Tag On logo ofthe washing machine by using your smartphone with NFC. 6 Motion

Washer is able to perform various drum actions or a combination ofdifferent actions depending on the wash program selected. Combined with a controlled spin speed and the ability of the drum torotate both left and right, the wash performance of the machine is greatlyimproved, giving you perfect results every time.Auto Restart

Auto Restart allows the program to restart all by itself in case of powerfailure. It does from the stage where it stopped.SmartDiagnosis™

Should you experience any technical difficulty with your washingmachine, it has the capability of transmitting data by phone to theCustomer Information Center. The call center agent records the datatransmitted from your machine and uses it to analyze the issue,providing a fast and effective diagnosis.

2-2. WATER LEVEL CONTROLThis model adopts a pressure sensor which can sense the water level in the tub.

Water supply is stopped when the water level reach the preset level, then washing program proceeds.

Spinning does not proceed until the water in the tub reduces to a certain level.2-3. THE DOOR CAN NOT BE OPENEDWhile program is operating.WhileDoor Locklight is on.2-4. NFC (Tag On Function)The Tag On function can only be used with smart phones equipped with the NFC function and based on the Android operating system (OS).Position your smart phone so that the NFC antenna on the back of your smart phone matches the position of the Tag On icon on the appliance.NFC reading performance of your smart phone must be higher thana certain level for using this function.

3.PARTS IDENTIFICATION

Accessories

Inlet hoseSpanner

4. INSTALLATION

INSTALLATION

The appliance should be installed as follows.

Check the conditions of installation area.

1. Check level ground.

On raised foundations or upper level homes, the vibrations can be caused by the type of flooring.

It may be necessary to move the machine to a different area in the home or have the floor

reinforced to properly support the operation of the unit.

2. Check for humidity or any foreign objects under the feet.

Clean the floor, there should be no foreign objects under the feet.

If the unit has foreign objects underneath the feet, this will prevent the unit from being leveled properly

and will cause vibrations and slipping.

Remove any foreign objects, if any from underneath the machine and level unit properly.

See below for examples of foreign objects.

Open the box and check appliance condition.

horizontal

Carpet Paper Laminated

paper

Purchased

stopper

Base Packing

Washer

Spanner

This leveling (or spanner) wrench must

be used to remove the shipping bolts

and level the unit. This should be kept

for future use.

1. 2. 3.

Connect Drain Hose.

Connect power plug.

If the drain hose is not installed properly, the unit will not drain properly.

This allows water to back flow into the unit which can cause odors.

Refer to Owner Manual for proper drain hose installation.

The odor could also be coming from the home’s drain to which the drain hose is attached.

In this type of drain hose installation, the odor could be coming from the standpipe.

This odor can come up the drain hose and into the unit.

Pour a cup or two of bleach or vinegar down the home drain

and let it sit for 24 hours before running another cycle.

This will help eliminate odor from the home drain.

If a cycle is started too soon after doing this, it will not help the issue.

Connect the power plug to the wall outlet. Avoid connecting several electric devices,

it may be the cause of a fire.

about 100 cm

about 145 cm

about 105 cm

Laundry tub

Max. 100cm

min. 60cm

Max. 100cm

min. 60cm

Retainer

Tie

strap

Hose

min. 60 cm

max. 100 cm

Rubber Cup

Check the horizontality with a level (Gage).

Step 1

If washing machine legs are loose or not Screwed in, then tighten with the spanner wrench.

Using the level, level the washing machine from front to back and side to side.

Step 2

Use the spanner wrench to adjust Legs until level and try the Diagonal test.

Step 3

Perform a Rinse and Spin with some clothing in the machine.

To do this, put 2~3kg of clothing in the unit, turn on the unit, Select the Rinse+Spin

and then start. When the unit reaches the spin cycle, watch for vibrations.

If the unit is vibrating, make small adjustments to the leg until they subside. (Repeat step 2)

Step 4

Tighten the lock nut against the base of the machine to lock the position leg.

Lower the foot until there is no gap between floor and foot.

And only use adjustment rubber when difference at the leg adjustment is more than 10mm.

Place your right hand on the back, right corner and your left hand on the front,

left corner of the unit, then attempt to rock the unit from corner to corner.

Then, move your right hand to the front, right side and your left hand to the

back, left corner and attempt to rock the unit from corner to corner.

If the unit is level, it will not rock. However, if the unit is not level, it will rock.

If the unit rocks, it will be necessary to adjust the leveling feet of the unit.

Adjust the foot under the hand that is on the front of the machine.

How to perform a diagonal test:

A level

Higher

Tighten

Adjustable feet

Diagonal test

Tighten

Adjustable feet

Higher

Tighten

Adjustable feet

Lower

4620ER4002B

(Gray)

for Wooden floors

Rubber Cup

4620ER4002A

(Black)

for Tile floors

Lock nut

10mm

Adjustable bolt

Tighen the lock nut

Floor

No Gap

Floor

No Gap

Floor

Gap

Test operation91Preparationforwashing.·Connect the power plug to theoutlet.·Connect the inlet hose. 2Touch the power button.3Touch the START/PAUSEbutton.6Check the water heating.·Touch the Wash and Spinbutton simultaneously and thepresent temperature will bedisplayed.·Check if the drum rotatesclockwise and counterclockwise. 5

Check automatic reverse turn.

4Check the water supply.·Check if water is supplied throughthe detergent dispenser.7Check the drain and spinfunctions.·Turn power off and then power on.·Select the spin rpm·Touch the START PAUSE button.·Check the spin and drainfunctions.·Turn power off and then power on.·To turn off, touch the power button for 1sec·Listen for a click to determine if thedoor is unlocking.8Turn power off and openthe door.9Water removal.·If SVC is needed during check,remove the remaining water bypulling out the hose cap.·In case of Coloreds program.

5. OPERATION

How to use washer

Spin Speed level can be selected bytouching 'Spin' button repeatedly. Spin Only1. Touch the Power button.2. Touch the Spin button to select RPM.3. Touch the Start/Pause.

Spin

Rinse plus ( ) :Add rinse once.

Rinse ( )

1. Touch the Power button.2. Select a cycle.3. Touch the Time Delay button and set timerequired.4. Touch the Start/Pause button.You can set a time delay so that the washingmachine will start automatically and nishafter a specied time interval.

Delay ( )

NOTE The delay time is the time to the endof the programme, not the start. The actual running time may varydue to water temperature, wash loadand other factors.

When you select "No Spin", it will stillrotate for a short time with low speed todrain quickly.

NOTE

How to use washer

The Beep on/off function can be set only during the washing cycle.1. Touch the Power button.2. Touch the Start/Pause button.3. Touch and hold the Temp. .andCrease Care button simultaneously for three seconds to set Beep on/off function.Once the Beep on/off function is set, the settingis memorized even after the power is turned off.Locking the control panel1. Touch and hold the Child Lock button for 3 seconds.2. A beeper will sound, and ' ' will appear onthe LED display.When the child lock is set, all buttons arelocked except the Power button.

Select this function to lock the buttons on the control assembly to prevent tampering."Child Lock" can be set only during the washing cycle.

Unlocking the control panel1. Touch and hold the Child Lockbutton for 3 seconds.2. A beeper will sound and the remaining timefor the current programme will reappear onthe LED display.

Child Lock

Beep On / Off NOTE

Turning off the power will not reset thechild lock function. You must deactivatechild lock before you can access anyother functions.

NOTE

If you want to turn the Beeper off,simply repeat this process.

Crease Care

How to use washer

Tub Clean is a special cycle to clean the inside of the washing machine. A higher water level is used in this cycle at higher spin speed. Perform this cycle regularly.

1. Remove any clothing or items from thewasher and close the door.2. Open the dispenser drawer and add Antilimescale(e.g. Calgon) to the main washcompartment.3. Close the dispenser drawer slowly.4.

Power On and then touch and hold TubClean button for 3 seconds. Then

' '

andtub clean pictogram will be displayed on theLED display.

5. Touch the Start/Pause button to start. 6. After the cycle is complete, leave the dooropen to allow the washer door opening,flexible gasket and door glass to dry. “Door Lock” - For safety reasons, thedoor will lock while machine is in use and the“Door Lock” icon will light up. You can safelyopen the door after the “Door Lock” iconturns off. While"Detecting"is shown on thedisplay the washing machine rotates slowlyand detects how much laundry is loaded inthe drum.It will take a short time.Tub Clean ( )

Door Lock & Detecting

NOTE Do not add any detergent to the detergent compartments. Excessive suds may generate and leak from the washer.CAUTION If there is a child, be careful not to leave the door open for too long.
