OWNER’S MANUAL
COMMERCIAL WASHER
MODEL
GCW1069CS/GCW1069QS/GCW1069LS
GCW1069CD/GCW1069QD/GCW1069LD
www.lg.com
Before beginning installation, read these instructions carefully. This will simplify
installation and ensure that the washer is installed correctly and safely.
Leave these instructions near the washer after installation for future reference.
P/No.: MFL67360455

2PRODUCT FEATURES
PRODUCT FEATURES
DIRECT DRIVE SYSTEM
The advanced Brushless DC motor directly drives the drum without using a belt and pulley.
TILTED DRUM AND EXTRA LARGE DOOR OPENING
The tilted drum and extra large opening make it possible to load and unload clothing more easily.
ULTRA CAPACITY
The larger drum enables more tumbling action and greater centrifugal force, but also less tangling and wrinkling of the laundry.
Heavier loads, such as king size comforters, blankets, and curtains, can be washed.
SEE-THROUGH DOOR AND BIG DOOR
You can see the laundry throughout the cycle.
MAGNETIC DOOR PLUNGER
Safely and conveniently secure the door slightly ajar with the magnetic door plunger. This will promote air circulation and allow
the interior of the machine to dry. To use this feature, after the load has been removed, do not close the door completely. When
the magnetic door plunger comes into contact with the metal washer cabinet, it will secure the door slightly open allowing the
interior of the washer to dry.
STAINLESS STEEL DRUM
TUB CLEAN
Regular cleaning of the tub on a monthly basis using TUB CLEAN can help keep the tub clean and fresh.

3
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
WARNING
For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to
prevent property damage, injury to persons, or death.
Your Safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word DANGER, WARNING or CAUTION.
These words mean:
DANGER
You will be killed or seriously injured if you don’t immediately follow instructions.
WARNING
You can be killed or seriously injured if you don’t follow instructions.
CAUTION
You may be slightly injured or cause damage to the product if you do not follow instructions.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.

4IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
WARNING
For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to
prevent property damage, injury to persons, or death.
BASIC SAFETY PRECAUTIONS
WARNING
To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions, including the
following.
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of malfunction or breakdown, grounding will reduce the risk of electric shock by
providing a path of least resistance for electric current. This appliance is equipped with a cord having an equipment-grounding
conductor and grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
WARNING
Improper connection of the equipment-grounding conductor can result in risk of electric shock. Check with a qualified electrician
or servicer if you are in doubt as to whether the appliance is properly grounded. Do not modify the plug provided with the
appliance. If it does not fit the outlet, have a proper outlet installed by a qualified electrician. Failure to follow these warnings can
cause serious injury, fire, electric shock, or death.
•
Before use, the washer must be properly installed as
described in this manual.
•Do not wash articles that have been previously cleaned in,
washed in, soaked in, or spotted with gasoline, dry cleaning
solvents, or other flammable or explosive substances, as
they give off vapors that could ignite or explode.
•
Do not add gasoline, dry cleaning solvents, or other
flammable or explosive substances to the wash water.
These substances give off vapors that could ignite or
explode.
• Under certain conditions, hydrogen gas may be produced
in a hot water system that has not been used for 2 weeks
or more. HYDROGEN GAS IS EXPLOSIVE. If the hot water
system has not been used for such a period, before using
the washer, turn on all hot water faucets and let the water
flow from each for several minutes. This will release any
accumulated hydrogen gas. As the gas is flammable, do not
smoke or use an open flame during this time.
•Do not allow children to play on or in the washer. Close
supervision of children is necessary when the washer is
used near children.
•Before the washer is removed from service or discarded,
remove the door to prevent children from climbing inside.
•Do not install or store the washer where it will be exposed
to the weather or freezing temperatures.
•Do not tamper with controls.
•
Do not repair or replace any part of the washer or attempt
any servicing other than as described in this manual. We
strongly recommend that any service be performed by a
qualified technician.
• See Installation Instructions for grounding requirements.
•
ALWAYS follow the fabric care instructions supplied by the
garment manufacturer.
•
Do not place items exposed to cooking oil in your washer.
Items contaminated with cooking oils may contribute to a
chemical reaction that could cause a load to catch fire.
•
Use fabric softeners or products to eliminate static only as
recommended by the manufacturer.
• This washer is not designed for maritime use or for mobile
installations such as in RVs, aircraft, etc.
•
Turn off the water faucets and unplug the washer if the
machine is to be left for an extended period of time, such as
during vacations.
•
Do not use to dry articles containing foam rubber or
similarly textured rubber-like materials.
• Packaging material can be dangerous for children. There is a
risk of suffocation! Keep all packaging from children.
•
Always check the inside of the washer for foreign objects
before loading laundry. Keep the door closed when not in
use.
•
Do not reach into the appliance if the tub or agitator is
moving.

5
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
WARNING
For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to
prevent property damage, injury to persons, or death.
SAFETY INSTRUCTIONS FOR INSTALLATION
WARNING
To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions, including the
following.
•
Refer to INSTALLATION INSTRUCTIONS for detailed
grounding procedures. Installation instructions are packed
with the washer for installer’s reference. If the washer is
moved to a new location, have it checked and reinstalled by a
qualified service technician. Failure to follow this warning can
cause serious injury, fire, electric shock, or death.
•
Do not, under any circumstances, cut or remove the third
(ground) prong from the power cord. Failure to follow this
warning can cause serious injury, fire, electric shock, or
death.
•
For personal safety, this appliance must be properly
grounded. Failure to follow this warning can cause serious
injury, fire, electric shock, or death.
•
The power cord of this appliance is equipped with a 3-prong
(grounding) plug which mates with a standard 3-prong
(grounding) wall outlet to minimize the possibility of electric
shock from this appliance.
•
This washer must be plugged into a 120 VAC, 60 Hz
grounded outlet. Failure to follow this warning can cause
serious injury, fire, electric shock, or death.
•
Have the wall outlet and circuit checked by a qualified
electrician to make sure the outlet is properly grounded.
Failure to follow this warning can cause serious injury, fire,
electric shock, or death.
•
Where a standard 2-prong wall outlet is encountered, it
is your personal responsibility and obligation to have it
replaced with a properly grounded 3-prong wall outlet.
Failure to follow this warning can cause serious injury, fire,
electric shock, or death.
•
Do not install on carpet. Install washer on a solid floor.
Failure to follow this warning can cause serious leak damage.
•
Do not remove ground prong. Do not use an adapter or
extension cord. Plug into a grounded 3-prong outlet. Failure
to follow these warnings can cause serious injury, fire,
electric shock, or death.
•
The washer should always be plugged into its own individual
electrical outlet which has a voltage rating that matches the
rating plate. This provides the best performance and also
prevents overloading house wiring circuits which could cause
a fire hazard from overheated wires.
•
Never unplug your washer by pulling on the power cord.
Always grip plug firmly and pull straight out from the outlet.
Failure to follow this warning can cause serious injury, fire,
electric shock, or death.
•
Repair or immediately replace all power cords that have
become frayed or otherwise damaged. Do not use a cord
that shows cracks or abrasion damage along its length or at
either end. Failure to follow this warning can cause serious
injury, fire, electric shock, or death.
•
When installing or moving the washer, be careful not to
pinch, crush, or damage the power cord. Failure to follow
this warning can cause serious injury, fire, electric shock, or
death.
•
The washer must be installed and electrically grounded by
a qualified service person in accordance with local codes to
prevent shock hazard and assure stability during operation.
•
The washer is heavy. Two or more people may be needed
to install and move the appliance. Failure to do so can result
in back or other injury.
•
Store and install the washer where it will not be exposed
to temperatures below freezing or exposed to outdoor
weather conditions. Failure to follow this warning can cause
serious leak damage.
•
Do not install the washer in humid spaces to reduce the risk
of electric shock. Failure to follow this warning can cause
serious injury, fire, electric shock, or death.
•
To reduce the risk of injury to persons, adhere to all industry
recommended safety procedures including the use of long
sleeved gloves and safety glasses. Failure to follow all of
the safety warnings in this manual could result in property
damage, injury to persons or death.

6IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
WARNING
For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to
prevent property damage, injury to persons, or death.
SAFETY INSTRUCTIONS FOR USE, CARE, CLEANING, AND DISPOSAL
WARNING
To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions, including the
following.
SAVE THESE INSTRUCTIONS
•
Unplug the washer before cleaning to avoid the risk of
electric shock.
•
Never use harsh chemicals, abrasive cleaners, or solvents
to clean the washer. They will damage the finish.
•
Do not put oily or greasy rags or clothing on top of the
washer. These substances give off vapors that could ignite
the materials.
•
Do not wash items that are soiled with vegetable or cooking
oil. These items may contain some oil after laundering. Due
to the remaining oil, the fabric may smoke or catch fire by
itself.
•
Disconnect this appliance from the power supply before
attempting any user maintenance. Turning the controls to
the OFF position does not disconnect this appliance from
the power supply. Failure to follow this warning can cause
serious injury, fire, electric shock, or death.
•
Do not combine laundry products for use in one load unless
specified on the label.
•
Do not mix chlorine bleach with ammonia or acids such
as vinegar. Follow package directions when using laundry
products. Incorrect usage can produce poisonous gas,
resulting in serious injury or death.
•
Do not reach into the washer while parts are moving.
Before loading, unloading, or adding items, press the START/
PAUSE button and allow the drum to coast to a complete
stop before reaching inside. Failure to follow this warning
can cause serious injury, fire, electric shock, or death.
•
Do not allow children to play on or in the washer. Close
supervision of children is necessary when the washer
is used near children. As children grow, teach them the
proper, safe use of all appliances. Failure to comply with
these warnings could result in serious injury to persons or
death.
•
Destroy the carton, plastic bag, and other packing materials
after the washer is unpacked. Children might use them for
play. Cartons covered with rugs, bedspreads, or plastic
sheets can become airtight chambers. Failure to comply
with these warnings could result in serious injury to persons
or death.
•
Keep laundry products out of children’s reach. To prevent
injury to persons, observe all warnings on product labels.
Failure to comply with these warnings could result in serious
injury to persons or death..
•
Remove the door to the washing compartment to avoid the
danger of children or small animals getting trapped inside
before your washer is removed from service or discarded.
Failure to do so can result in serious injury to persons or
death.

7
TABLE OF CONTENTS
TABLE OF CONTENTS
2 PRODUCT FEATURES
3 IMPORTANT SAFETY INSTRUCTIONS
4BASIC SAFETY PRECAUTIONS
4GROUNDING INSTRUCTIONS
5SAFETY INSTRUCTIONS FOR INSTALLATION
6SAFETY INSTRUCTIONS FOR USE, CARE,
CLEANING, AND DISPOSAL
8 PARTS AND ACCESSORIES
8Parts
8Accessories
9
CONTROL PANEL FEATURES
9Coin type
10 Card / OPL type
12 INSTALLATION INSTRUCTIONS
12 Checking and choosing the proper location
13 Unpacking and removing shipping bolts
14 Connecting the water lines
15 Connecting the drain line
16 Leveling the washing machine
17 PREPARATION
17 Precautions for fabric care before wash cycle
18 Fabric Care Labels
18 Sorting laundry
19 Using detergent/fabric softener
19 - Recommended detergent
19 - About the dispenser
20 - Loading the dispenser
21 OPERATING YOUR WASHER
22 PROGRAMMING MODE
23 Card/Coin type
24 OPL type
25 Programming mode - Setup Mode
25 - 1. How to change regular price.
26 -2. How to change regular cold price.
27 -3. How to change regular warm price
28 -4. How to change regular hot price
29 -5. How to change special price
30 -6. How to change special cold price
31 -7. How to change special warm price
32 -8. How to change special hot price
33 -9. How to change add super wash price
34 -10. How to change add super wash type
35 -11. How to enter the
36 -11-1. Special price day setup
37 -11-2. Non stop rinse
38 -11-3. Add super wash setup
39 -11-4. Vend type setup - card type or coin type setup
40 -11-5. Pre-wash set up
41 -11-6. Twin spray set up
42 -12. How to enter the special price day
43 -12-1. How to change to Sunday
44 -13. Special price beginning time setup
45 -14. Special price ending time setup
46 -15. Washing time set up
47 -16. Rinsing times per cycle
48 -17. Rinsing time setup
49 -18. Top spin speed – final spin time depends on
RPM
50 -19. Value of coin 1
51 -20. Value of coin 2
52 -21. Penny increment pricing offset
53 -22. How to change the water level
54 -23. Beep volume
55 -24. Time to keep the coin (Use only for coin type)
56 -25. How to enter the
57 Programming Mode - Test mode
57 -1.
58 -2. Factory reset -
59 -3. Time set up
60 -4. Courtesy cycle
61 -5. Cycle Kill
62 -6. PASSWORD -
63 -7. Tub clean -
64 Programming Mode - Collect mode
65 Collect Mode Data lists
66 MAINTENANCE
66 Care after wash
66 -Storing the Washer
66 -Cleaning the Dispenser
67 -Cleaning the water inlet filters
68 -Cleaning the drain pump filter
69 -Cleaning the door seal
69 -Clean the drum, TUB CLEAN
70 ERROR MODE
71 POWER FAIL RECOVERY
71 DEFAULT WASHER SETTINGS
71 SPECIFICATIONS

8PARTS AND ACCESSORIES
PARTS AND ACCESSORIES
Parts
Accessories
Detergent
dispenser
drawer
Door
Magnet Door
Plunger
(see page 2)
Control panel
Door
seal
Tub
Leveling
feet
Drain pump filter cover
Drain pump filter
Drain hose
Water inlets
Shipping
bolts Power cord
Drain hose
Hot and Cold
Water Hoses
Non-skid pads Caps (4)
(for covering shipping bolt holes)
Wrench
(for removing
shipping bolts and adjusting
leveling feet)
Tie Strap
(for securing drain hose)
Elbow Bracket
(for securing drain hose)

9
CONTROL PANEL FEATURES
1 25
1 25
4 3
1 25
4 3
1 25
4 3
Optional function button
1. Display LED
2. Cycle button
3. Optional cycle button
4. Start button
5. Status LED
CONTROL PANEL FEATURES
Coin type
- Side by side (GCW1069QS)
Card type
- Side by side (GCW1069CD)
1 25
1 25
4 3
1 25
4 3
1 25
4 3
Optional function button

10 CONTROL PANEL FEATURES
1. Display LED
2. Cycle button
3. Optional cycle button
4. Start button
5. Status LED
1 25
1 25
4 3
1 25
4 3
1 25
4 3
Optional function button
OPL type
- Side by side (GCW1069LD)

11
CONTROL PANEL FEATURES
Start button
Display LEDStatus LED Cycle button
Display LED
The display shows the vend price and remaining time and
programming options. Error codes are also displayed here.
Optional function button
Wash time or rinse cycle can be added when additional coin
is inserted or a valid cash card is entered.
Start button
The START LED flashes when the full vend price has been
satisfied and the cycle has been chosen.
Status LED
LED Description
LED flashes whenever the washing cycle is in
operation.
LED flashes whenever the Rinsing cycle is in
operation.
LED flashes whenever the Spining cycle is in
operation.
LED flashes whenever the door lock is
activated.
Cycle button
Press the CYCLE button to select the desired cycle based
on laundry types and conditions.
Whites
Use for hot washing for heavy fabrics, such as white
clothes, table linens, and heavily soiled clothes.
Colors
Use for warm washing for heavy fabrics, such as jeans,
corduroys, or work clothes.
Perm.Press
Use for warm washing for sturdy fabrics, such as work
casual work.
Delicates
Use for cold washing for synthetic fabrics, such as washable
knit fabric and no-iron finishes.
Optional function button

12 INSTALLATION INSTRUCTIONS
Space requirements
You must allow sufficient space for water lines, the drain
line, and airflow.
Installing on a floor
Install the washing machine on a solid floor that is strong
and rigid enough to support the weight of the washing
machine, even when fully loaded, without flexing or
bouncing. If the floor has too much flex, you may need to
reinforce it to make it more rigid. If the floor is not solid, it
may cause severe vibration and noise.
1Clean the floor before installation.
- Make sure to select solid and smooth ground.
2Two or more people are needed for moving and
unpacking the washing machine.
3Allow for sufficient space between the walls and the
washing machine for installation.
Checking and choosing the proper
location
293/4”
(75.6 cm)
51”
(129.7 cm)
4”
(10 cm)
221/4”
(57 cm)
27”
(68.6 cm)
1”
(2.5 cm)
1”
(2.5 cm)
INSTALLATION INSTRUCTIONS
NOTE
• Be sure to allow for wall, door, or floor moldings that
may increase the required clearances.
NOTE
• The floor must be strong and rigid enough to support
the weight of the washer, when fully loaded, without
flexing or bouncing. If your floor has too much flex,
you may need to reinforce it to make it more rigid.
A floor that is adequate for a top-loading washer may
not be rigid enough for a front loading washer, due to
the difference in the spin speed and direction. If the
floor is not solid, your washer may vibrate and you may
hear and feel the vibration throughout your house.
• Before installing the washer, make sure the floor is
clean, dry and free of dust, dirt, water and oils so the
washer feet can not slide easily. Leveling feet that can
move or slide on the floor can contribute to excess
vibration and noise due to poor contact with the floor.

13
INSTALLATION INSTRUCTIONS
Foam Tub Support Carton Base
NOTE
• Save the bolt assemblies for future use. To prevent
damage to internal components, DO NOT transport the
washer without reinstalling the shipping bolts.
• Failure to remove shipping bolts and retainers may
cause severe vibration and noise, which can lead to
permanent damage to the washer. The cord is secured
to the back of the washer with a shipping bolt to help
prevent operation with shipping bolts in place.
1Remove the bottom two shipping bolts with the wrench
(included) to fully loosen all four shipping bolts by turning
them counterclockwise and then pulling them out.
2Locate the four hole caps included in the accessory pack
and install them in the shipping bolt holes.
Unpacking and removing shipping
bolts
When removing the washer from the carton base, be sure
to remove the foam drum support in the middle of the
carton base.
If you must lay the washer down to remove the base
packaging materials, always lay it carefully on its side.
DO NOT lay the washer on its front or back.
Shipping
bolt
Retainer
Cap

14 INSTALLATION INSTRUCTIONS
NOTE
• For your safety, and for extended product life, use only
authorized components. The manufacturer is not re-
sponsible for product malfunction or accidents caused
by the use of separately purchased unauthorized parts.
• Use new hoses when you install the washing machine.
Do not reuse old hoses. Use only the inlet hoses
provided with the washer. LG does not recommend the
use of aftermarket hoses.
• Periodically check the hoses for cracks, leaks and wear,
and replace the hoses every 5 years.
• Do not stretch the water hoses intentionally, and make
sure that they are not crushed by other objects.
• Water supply pressure must be between 14.5 PSI and
116 PSI (100~800 kPa). If the water supply pressure is
more than 116 PSI, a pressure reducing valve must be
installed.
• To provide optimum washing performance the hot wa-
ter temperature should be set at 120-135°F (48-57°C)
and the cold at 60°F (15°C).
Connecting the water lines
1Check the rubber seals on both sides of the hose.
- Insert a rubber seal into the threaded fittings on each
hose to prevent leaking.
2Connect the water supply hoses to the HOT and COLD
water faucets tightly by hand and then tighten another
2/3 turn with pliers.
- Connect the blue hose to a cold water faucet and the
red hose to a hot water faucet.
4Connect the hoses to the water inlets tightly by hand and
then tighten another 2/3 turn with pliers.
- Connect the blue hose to the cold water inlet and the
red hose to the hot water inlet.
5Check for leaks by turning on the faucets.
- If water leaks, check steps 1 to 4 again.
3After connecting inlet hose to water faucets, turn on the
water faucets to flush out foreign substances (dirt, sand
or sawdust) in the water lines. Let water drain into a
bucket, and check the water temperature.
Cold
water
inlet
Hot water
inlet
Rubber seal
Water hose
(To water inlet on the
washing machine)
Rubber seal
Water hose
(To faucet)
WARNING
• Do not overtighten. Damage to the coupling can result.
WARNING
• Do not overtighten the hoses.
Overtightening can damage the valves resulting in
leaking and property damage.

15
INSTALLATION INSTRUCTIONS
Connecting the drain line
Secure the drain hose in place to prevent moving and
leaking.
Using a standpipe
1Clip the end of the hose into the elbow bracket.
- Connect the elbow bracket within 4 inches (10 cm) from
the end of the drain hose. If the drain hose is extended
more than 4 inches (10 cm) beyond the end of the
elbow bracket, mold or microorganisms could spread to
the inside of the washer.
Using a laundry tub
1Clip the end of the hose into the elbow bracket.
- Connect the elbow bracket within 4 inches (10 cm) from
the end of the drain hose. If the drain hose is extended
more than 4 inches (10 cm) beyond the end of the
elbow bracket, mold, or microorganisms could spread to
the inside of the washer.
2Hang the end of the drain hose over the side of the
laundry tub.
3Use a tie strap to secure the drain hose in place.
Drain Hose
Elbow Bracket
Drain Hose
NOTE
• The drain hose should be properly secured. Failure to
properly secure the drain hose can result in flooding
and malfunction.
• Total height of the house end should not exceed 96
inches (244.8 cm) from the bottom of the washer.
• The drain must be installed in accordance with any ap-
plicable local codes and regulations.
• Make sure that the water lines are not stretched,
pinched, crushed, or kinked.
No more than
4 inches (10 cm)
Elbow Bracket
No more than
4 inches (10 cm)
Elbow Bracket
Elbow
Bracket
Tie Strap
Laundry Tub
max. 96”
(2.4 m) max. 96”
(2.4 m)
2Insert the end of the drain hose into the standpipe.
3Use a tie strap to secure the drain hose in place.

16 INSTALLATION INSTRUCTIONS
Leveling the washing machine
The washer tub of your new washing machine spins at very
high speeds. To minimize vibration, noise, and unwanted
movement, the floor must be perfectly level and solid.
1Check the washing machine’s level.
- Check the precise level by rocking the top edges of
the washing machine or placing a level on the washing
machine. The slope beneath the washing machine must
not exceed 1°, and all four leveling feet must rest firmly
on the floor.
2Turn the lower leveling feet clockwise to level the washing
machine.
- Turning the lower leveling feet clockwise raises the
washing machine.
3Turn the locknuts counterclockwise and tighten them
when the washing machine is level.
4Check the washing machine’s level again.
- Push or rock the top edges of the washing machine
gently to make sure that the washing machine does not
rock.
- If the washing machine rocks, repeat steps 1 to 3.
Using non-skid pads (optional)
If you install the washing machine on a slippery surface, it
may move because of excessive vibration. Incorrect leveling
may cause malfunction through noise and vibration. In the
event of this, lay the non-skid pads under the leveling feet
and adjust the level.
1Clean the floor to attach the non-skid pads.
- Use a dry rag to remove and clean foreign objects or
moisture. If moisture remains, the non-skid pads may
slip.
2Adjust the level after placing the washing machine in the
installation area.
3Place the adhesive side of the non-skid pad on the floor.
- It is most effective to install the non-skid pads under the
front legs. If it is hard to place the pads under the front
legs, place them under the back legs.
4Check the washing machine’s level again.
- Push or rock the top edges of the washing machine
gently to make sure that the washing machine does not
rock. If the washing machine rocks, level the washing
machine again.
Level
1°
Raise
Tighten all 4 lock
nuts securely using
the wrench.
Remove
backing
This side up
Adhesive
side
WARNING
• Using the washing machine without leveling, it may re-
sult in malfunction caused by the production of excess
vibration and noise.
• Use the leveling feet only when you level the washing
machine. If you raise the leveling feet unnecessarily, it
may cause abnormal vibration of the washing machine.

17
PREPARATION
Check all pockets to make sure that they are empty.
u
-Items such as clips, matches, pens, coins, and keys can
damage both your washer and your clothes.
Close zippers, hooks, and drawstrings to prevent these
u
items from snagging or tangling on other clothes.
Pretreat heavily stained areas before washing.
u
- Doing so will produce clean, stain-free results.
Combine large and small items in a load. Load large items
u
first.
Large items should not be more than half of the total
u
washload.
The washer can be fully loaded, but the drum should not be
u
tightly packed with items.
-The door of the washer should close easily.
Do not wash single items, except for bulky items such as
u
blankets. Make sure to wash laundry in similar types of
loads.
- Washing a single small item may result in the tub
becoming unbalanced, vibrating and making a noise.
Do not wash waterproof clothes.
u
- This may cause abnormal vibration, or may cause the load
to bounce, which could damage the tub.
Check if there are any other foreign objects in the door seal
u
and take extra care that clothes do not get caught there.
- Foreign objects in the door seal may stain clothes, and
water may leak if clothes get caught in the door seal.
Wash underwear or small, light items in a laundry net.
u
- Small, light items may get caught in the door seal, and a
brassiere hook may damage other items or the tub.
Brush heavy soil, dust, or hair off fabrics before washing.
u
- Laundry may not wash clean if there is dirt or sand on
the fabrics, or they may damage due to particles rubbing
against sheer fabrics.
Wash blankets individually.
u
- Washing more than one blanket together may produce
unclean results due to tangling or an unbalanced load.
Always separate fabrics according to their colors and wash
u
them separately to prevent colors from running.
- Fabrics may damage or become stained due to fabric dyes
running, or due to foreign objects transferring from one
fabric to another.
PREPARATION
Precautions for fabric care before wash cycle
Read and observe the following to prevent shrinkage or damage to clothes.

18 PREPARATION
Category Label Directions
Washing
Hand Wash
Machine Wash, Normal Cycle
Use Permanent Press/Wrinkle
Resistant washing machine
setting (which has a cool down or
cold spray before the reduced
spin)
Use Gentle/Delicate washing
machine setting (slow agitation
and/ or reduced wash time).
Do Not Wash
Do Not Wring
Water Temperature
Hot
Warm
Cold/Cool
Bleach symbols
Any Bleach (When Needed)
Only Non-Chlorine Bleach (When
Needed)
Do Not Bleach
Fabric care labels
Most articles of clothing feature fabric care labels that include
instructions for proper care.
Colors Whites / Lights / Darks
Soil Heavy / Normal / Light
Fabric Delicates / Easy Care / Sturdy Cottons
Lint Lint Producers / Lint Collectors
Sorting laundry
It is recommended that you sort laundry into similar loads
that are washable in the same cycle.
Refer to the following chart for sorting clothes

19
PREPARATION
NOTE
• It is normal for a small amount of water to remain in the
dispenser compartments at the end of the cycle.
About the dispenser
The automatic dispenser consists of three compartments
which hold:
• Liquid chlorine bleach.
• Liquid fabric softener.
• Liquid and powdered detergent and color-safe bleach for
main wash.
All laundry products can be added at once in their respective
dispenser compartments. They will be dispensed at the
appropriate time for the most effective cleaning.
After adding the laundry products to the dispenser, close the
dispenser cover.
To add detergent, bleach, and fabric softener to the automatic
dispenser:
1. Open the dispenser cover.
2. Load the laundry products into the appropriate
compartments.
3. Slowly close the dispenser cover to avoid early dispensing of
the laundry products.
NOTE
• Only use HE detergents, since using a regular deter-
gent may produce excessive suds.
• HE detergents produce fewer suds, dissolve more ef-
ficiently to improve washing and rinsing performance,
and help to keep the interior of your washer clean.
• Use less detergent for soft water.
• Wipe up any spills immediately, as liquids could dam-
age the finish and the control panel of the washing
machine.
• Using too much detergent can cause a build-up in the
tub resulting in unsatisfactory performance and ma-
chine malfunction.
• If you use a detergent that does not dissolve easily or a
detergent with high viscosity, it will leave a residue on
the tub, which may not rinse properly.
Using detergent/fabric softener
Recommended detergent
Make sure to use HE (High-Efficiency) detergent for front-
loading washing machines. HE detergents dissolve more
efficiently and produce fewer suds to ensure efficient washing
and rinsing. Use the correct amount of detergent as indicated
on the label of the detergent packaging.
Designed specially to use only
HE (High-Efficiency) detergent

20 PREPARATION
Loading the dispenser
Designed specially to use only
HE (High-Efficiency) detergent
Main Wash Detergent Compartment
This compartment holds laundry detergent for the main
wash cycle, which is added to the load at the beginning of
the cycle. Always use HE (High-Efficiency) detergent with
your washing machine.
Follow the detergent manufacturer's instructions with
respect to the amount of detergent to use, and never use
more than the recommended amount. Using too much
detergent can result in detergent buildup in clothing and the
washer. Either powdered or liquid detergent may be used.
Liquid Bleach Compartment
This compartment holds liquid chlorine bleach, which will be
dispensed automatically at the proper time during the wash
cycle.
Fabric Softener Compartment
This compartment holds liquid fabric softener, which will be
automatically dispensed during the final rinse cycle.
Liquid Fabric
Softener
Compartment
Liquid Chlorine
Bleach
Compartment
Main Wash
Detergent
Compartment
NOTE
• Liquid or powdered color-safe bleach may be added
to the main wash compartment with detergent of the
same type.
NOTE
• Do not add powdered or liquid color-safe bleach to this
compartment.
• Always follow the manufacturer’s recommendations
when adding bleach. Do not exceed the maximum fill
line. Using too much bleach can damage fabrics.
• Never pour undiluted liquid chlorine bleach directly onto
the load or into the drum. Fabric damage can occur.
NOTE
• Always follow the manufacturer’s recommendations
when adding fabric softener. Do not exceed the maxi-
mum fill line. Using too much fabric softener may result
in stained clothes.
• Dilute concentrated fabric softeners with warm water.
Do not exceed the maximum fill line.
• Never pour fabric softener directly onto the load or into
the drum.
