LG SteamWasher WM3360HVCA User manual

A DECISION YOU’LL LOVE TO MAKE
Wouldn’t you choose a cycle that gives you cold-water savings with
warm-water performance? Wouldn’t you be surprised by a technology
that automatically customizes washing motions to ensure a better clean,
no matter the load? And, wouldn’t you find extra comfort in an allergen-
fighting cycle that can kill over 95% of the most common household
allergens? We think you most certainly would.
LAUNDRY
WM3360H_CA
SteamWasher™
with Dual LED Display
HIGHLIGHTS
ColdWash™ Option
6Motion™ Technology
Allergiene™ Cycle
6Motion™ Technology
Get your clothes cleaner and
help them last longer with revolutionary 6Motion™
Technology. Each wash cycle combines up to 6
different wash motions to provide outstanding
cleaning while being gentle on fabrics.
Allergiene™ Cycle
The Allergiene™ cycle uses the power of steam
to gently remove over 95% of common
household allergens, like dust mites and pet
dander, from even the most delicate fabrics.
Now doing the laundry may save some sniffles.
ColdWash™ Option
Now using the cold cycle
on your washer doesn’t mean compromising how
clean your clothes are. ColdWash™ option uses
cold water and enhanced washing motions to
penetrate deep into fabrics, giving you cold water
savings with warm water performance.
SMART TECHNOLOGY
• 4.5cu.ft.ExtraLargeCapacitywith
NeveRust™StainlessSteelDrum(IEC)
• ColdWash™Option
• 6Motion™Technology
• DirectDriveMotor(10YearWarranty)
• TrueBalance™Anti-VibrationSystem
• TrueSteam™Technology
• 1200RPM
• Allergiene™Cycle
• SteamFresh™Cycle
• LoDecibel™QuietOperation
• HighlyEnergyandWaterEfcient
• SenseClean™
• 12WashingPrograms
• 5TemperatureSettings
• SanitaryCyclewithAdded
SteamOption
• DelayWash(Upto19Hours)
• 10°TilTub™
• SmartDiagnosis™
STYLISH DESIGN
• UpfrontElectronicControlPanelwith
DualLEDDisplayandDial-A-Cycle™
• LargeStainlessSteelFinish
DoorwithGlass
• StackablewithMatchingDryer
• OptionalMatchingDrawerPedestal

HAL-WM3360H-SS12/20/10
LAUNDRY
WM3360H_CA
www.LG.com
LGElectronicsU.S.A.,Inc.
1000SylvanAvenueEnglewoodCliffs,NJ07632
CustomerServiceandTechnicalSupport:(800)243-0000
Dimensionsandweightsareapproximate.Design,featuresandspecifications
subjecttochangewithoutnotice.

©2010LGElectronicsUSA,Inc.Allrightsreserved.“LGLife’sGood”isa
registeredtrademarkofLGCorp.Allotherproductandbrandnamesare
trademarksorregisteredtrademarksoftheirrespectivecompanies.
CAPACITY
Capacity IEC4.5cu.ft.
DryLinenCapacity >10.1kg
APPEARANCE
DesignLook FrontControl
IntelligentElectronicControlswithDualLEDDisplay •
Dial-A-Cycle™ •
ENERGY
EnergyStarCompliant •
WASH PROGRAMS
12Programs Allergiene™,Sanitary(158°F),SteamFresh™,
 BrightWhite,Bulky/Large,Cotton/Normal,
 PermPress,HeavyDuty,Delicates,
 HandWash/Wool,SpeedWash,Rinse+Spin
5Wash/RinseTemps ExtraHot/Cold,Hot/Cold,Warm/Warm,
 Warm/Cold,Cold/Cold
SpinSpeeds ExtraHigh(1200max.),
 High,Medium,Low,NoSpin
No.ofWaterLevels Automaticallyadjuststothesizeofload
No.ofSoilLevels 5
9Options Steam,ColdWash™,Prewash,FreshCare™,ExtraRinse,
 StainCare™,ChildLock,TubClean,DelayWash
FABRIC CARE FEATURES
ColdWash™Option •
Allergiene™Cycle •
SteamFresh™Cycle •
SenseClean™System •
CONVENIENCE FEATURES
4TrayDispenser Prewash,MainWash(withliquid
 detergentcup),Bleach,Softener
LoDecibel™QuietOperation •
EndofCycleSignal •
ChildLock •
TrueSteam™Generator •
TrueBalance™Anti-VibrationSystem •
SmartDiagnosis™ •
LoadSense •
AutoSudsRemoval •
ForcedDrainSystem •
StatusIndicator(s) •
InternalWaterHeater(1000W) •
LevelingLegs 4AdjustableLegs
EasyLoadingTilTub™ •
MOTOR AND AGITATOR
MotorType DirectDriveMotor
MotorSpeed Variable
Axis Horizontal
MATERIALS AND FINISHES
NeveRust™StainlessSteelDrum •
Cabinet PaintedSteel
ControlPanel Plastic
TopPlate Painted
TransparentGlassDoor •
DoorRim StainlessSteelFinish
AvailableColors GraphiteSteel(V),
 WildCherryRed(R),White(W)
POWER SOURCE
Ratings ULListed
ElectricalRequirements 120V,10Amps
Type Electric
OPTIONS
Pedestal WDP4V,WDP4R,WDP4W
Pedestal(WxHxD) 27"x133/5"x282/5"
StackingKit SSTK1,RSTK1,WSTK1
DIMENSIONS
Product(WxHxD) 27"x3811/16"x293/4"
 (51"Dwithdooropen)
Carton(WxHxD) 291/2"x421/4"x311/4"
Weight(Product/Carton) 192lbs./210.5lbs.
WARRANTY
 1YearPartsandLabor,
 10YearsMotor,LifetimeonDrum
UPC CODES
WM3360HVCA Washer–GraphiteSteel 048231011556
WM3360HRCA Washer–WildCherryRed 0482310 1 1 1 3 6
WM3360HWCA Washer–White 0482310 1 1 1 4 3
WDP4V Pedestal–GraphiteSteel 0482310 1 1 1 9 8
WDP4R Pedestal–WildCherryRed 048231011204
WDP4W Pedestal–White 0482310 1 1 2 1 1
SSTK1 StackingKit–Titanium 048231008587
RSTK1 StackingKit–WildCherryRed 048231008983
WSTK1 StackingKit–White 048231008327
Wild Cherry Red White Graphite Steel
