LG WD-10467BD User manual

OWNER’S MANUAL
COMMERCIAL WASHER
Please read this manual carefully before operatin
your set and retain it for future reference.
MODEL
WD-10467BD
P/NO : MFL62526838 www.lge.com

2
PRODUCT FEATURES
CONTENTS
■ Direct Drive System
The advanced Brushless DC mo or direc ly drives he drum wi hou
using a bel and pulley.
■ Tilted Drum and Extra Large Door Opening
The il ed drum and ex ra large opening make i possible o load
and unload clo hing more easily.
■ Ultra Capacity
The larger drum enables more umbling ac ion and grea er cen rifugal
force, bu also less angling and wrinkling of he laundry. Heavier
loads, such as king size comfor ers, blanke s, and cur ains, can be
washed.
■ See-through Door and Big Door
You can see he laundry hroughou he cycle.
■ Stainless Steel Drum
The s ainless s eel drum doesn' rus .
PART 1. IMPORTANT SAFETY INSTRUCTIONS ...........................................................................3
PART 2. SPECIFICATIONS..............................................................................................................6
PART 3. IDENTIFICATION ...............................................................................................................7
PART 4. OPERATING YOUR WASHER ..........................................................................................9
PART 5. PROGRAMMING MODE..................................................................................................10
PART 6. ERROR MODE.................................................................................................................23
PART 7. POWER FAIL RECOVERY ..............................................................................................24
PART 8. DEFAULT WASHER SETTINGS......................................................................................24

3
Part 1 IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
WARNING
For your safety, the information in this manual must be followed to minimize the risk of fire or explosion,
electric shock, or to prevent property damage, personal injury, or loss of life.
IMPORTANT SAFETY INSTRUCTIONS
• Read all instructions before using the washer.
• o not wash articles that have been previously cleaned
in, washed in, soaked in, or spotted with gasoline, dry
cleaning solvents, or other flammable or explosive
substances, as they give off vapors that could ignite or
explode.
• o not add gasoline, dry cleaning solvents, or other
flammable or explosive substances to the wash water.
These substances give off vapors that could ignite or
explode.
• Under certain conditions, hydrogen gas may be
produced in a hot water system that has not been used
for 2 weeks or more. HY ROGEN GAS IS EXPLOSIVE.
If the hot water system has not been used for such a
period, before using the washing machine, turn on all
hot water faucets and let the water flow from each for
several minutes. This will release any accumulated
hydrogen gas. As the gas is flammable, do not smoke
or use an open flame during this time.
• o not allow children to play on or in the washer.
Close supervision of children is necessary when the
washer is used near children.
• Before the washer is removed from service or
discarded, remove the door to prevent children from
hiding inside.
• o not install or store the washer where it will be
exposed to the weather.
• o not tamper with the controls.
• o not repair or replace any part of the washer or
attempt any servicing unless specifically
recommended in the user-maintenance instructions or
published user-repair instructions that you understand
and have the skills to carry out.
• See Installation Instructions for grounding
requirements.
• ALWAYS follow the fabric care instructions supplied by
the garment manufacturer.
• o not place items exposed to cooking oil in your
washer. Items contaminated with cooking oils may
contribute to a chemical reaction that could cause a
load to catch fire.
• o not use fabric softeners or products to eliminate
static unless recommended by the manufacturer of the
fabric softener or product.
WARNING:To reduce he risk of fire, elec ric shock, or injury o persons when using he washer, follow basic
precau ions, including he following:
This appliance must be grounded. In the event of malfunction or breakdown, grounding will reduce the risk of
electric shock by providing a path of least resistance for electric current. This appliance is equipped with a cord
having an equipment-grounding conductor and grounding plug. The plug must be plugged into an appropriate
outlet that is properly installed and grounded in accordance with all local codes and ordinances.
• o not use an adapter or extension cord.
• o not remove ground prong.
• If you don’t have the proper outlet, consult an electrician.
GROUNDING INSTRUCTIONS
Your safety an the safety of others are very important.
WARNING:Improper connec ion of he equipmen -grounding conduc or can resul in risk of elec ric shock. Consul a
qualified elec rician or serviceman if you are in doub as o whe her he appliance is properly grounded.
Do no modify he plug provided wi h he appliance - if i does no fi he ou le , have a proper ou le ins alled
by a qualified elec rician.
!
!
!
DANGER:You can be killed or seriously injured if you don’ follow ins ruc ions.
!
WARNING:You can be killed or seriously injured if you don’ follow ins ruc ions.
!
!
We have provided many impor an safe y messages in his manual and on your appliance. Always read and obey all safe y messages.
All safe y messages will ell you wha he po en ial hazard is, ell you how o reduce he chance of injury, and ell you wha can
happen if he ins ruc ions are no followed.
This is he safe y aler symbol.
This symbol aler s you o po en ial hazards ha can kill or hur you and o hers.
All safe y messages will follow he safe y aler symbol and ei her he word DANGER or WARNING.
These words mean:
SAVE THESE INSTRUCTIONS

4
Part 1 IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
SAFETY INSTRUCTION FOR INSTALLATION
WARNING
For your safety, the information in this manual must be followed to minimize the risk of fire
or explosion, electric shock, or to prevent property damage, personal injury, or loss of life.
!
WARNING
To reduce the risk of fire, electric shock, or injury to persons when using the appliance,
follow basic precautions, including the following:
!
• Refer to I STALLATIO I STRUCTIO S for
detailed grounding procedures.
Installation instructions are packed in the washer for
installer's reference. If the washer is moved to a new
location, have it checked and reinstalled by a qualified
service person. Failure to follow this warning can cause
serious injury, fire, electrical shock or death.
• Do not, under any circumstances cut or remove the
third (ground) prong from the power cord.
Failure to follow this warning can cause serious injury,
fire, electrical shock or death.
• For personal safety, this appliance must be properly
grounded.
Failure to follow this warning can cause serious injury,
fire, electrical shock or death.
• The power cord of this appliance is equipped with a
3-prong (grounding) plug which fits a standard 3-
prong (grounding) wall outlet to minimize the
possibility of electric shock hazard from this appliance.
• This washer must be plugged into a 220-VAC, 50 Hz
grounded outlet. Failure to follow this warning can
cause serious injury, fire, electrical shock, or death.
• Have the wall outlet and circuit checked by a
qualified electrician to make sure the outlet is
properly grounded. Failure to follow this warning can
cause serious injury, fire, electrical shock, or death.
• Where a standard 2-prong wall outlet is encountered,
it is your personal responsibility and obligation to
have it replaced with a properly grounded 3-prong
wall outlet. Failure to follow this warning can cause
serious injury, fire, electrical shock, or death.
• Do not install on carpet. Install the washer on a solid
floor. Failure to follow this warning can cause serious
leak damage.
• Do not remove the ground prong.
Do not use an adapter or extension cord.
Plug into a grounded 3 prong outlet.
Failure to follow this warning can cause serious injury,
fire, electrical shock, or death.
• The washer should always be plugged into its own
individual electrical outlet which has a voltage rating
that matches the rating plate.
his provides the best performance and also prevents
overloading house wiring circuits which could cause a fire
hazard from overheated wires.
• ever unplug your washer by pulling on the power
cord. Always grip the plug firmly and pull straight out
from the outlet. Failure to follow this warning can cause
serious injury, fire, electrical shock, or death.
• Repair or replace all power cords that have become
frayed or otherwise damaged.
Do not use a cord that shows cracks or abrasion
damage along its length or at either end.
Failure to follow this warning can cause serious injury, fire,
electrical shock,or death.
• When installing or moving the washer, be careful not to
pinch, crush, or damage the power cord. Failure to
follow this warning can cause serious injury, fire, electrical
shock, or death.
• The washer must be installed and electrically grounded
by a qualified service person in accordance with local
codes, to prevent shock hazard and assure stability during
operation.
• The washer is heavy.
Two or more people are needed to install and move the
appliance.
Failure to do so can result in back or other injury
• Store and install the washer where it will not be
exposed to temperatures below freezing or exposed to
outdoor weather conditions.
Failure to follow this warning can cause serious leak
damage.
• Do not install the washer in humid spaces to reduce
the risk of electric shock.
Failure to follow this warning can cause serious injury, fire,
electrical shock, or death.

5
Part 1 IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
SAFETY INSTRUCTION FOR SAFETY USE/CLEANING/CARE/DISCARD
WARNING
For your safety, the information in this manual must be followed to minimize the risk of fire
or explosion, electric shock, or to prevent property damage, personal injury, or loss of life.
!
WARNING
To reduce the risk of fire, electric shock or injury to persons when using the appliance,
follow basic precautions, including the following:
!
• Unplug the washer before cleaning to avoid the risk
of electric shock.
• ever use harsh chemicals, abrasive cleaners, or
solvents to clean the washer.
hey will damage the finish.
• Do not put oily or greasy rags or clothing on top of
the washer. hese substances give off vapors that
could ignite the materials.
• Do not wash items that are soiled with vegetable or
cooking oil. hese items may contain some oil after
laundering. Due to the remaining oil, the fabric may
smoke or catch fire by itself.
• Disconnect this appliance from the power supply
before attempting any user maintenance.
urning the controls to the OFF position does not
disconnect this appliance from the power supply.
Failure to follow this warning can cause serious injury,
fire, electrical shock, or death.
• Do not combine laundry products for use in 1 load
unless specified on the label. Do not mix chlorine
bleach with ammonia or acids such as vinegar.
Follow package directions when using laundry
products. Incorrect usage can produce poisonous gas-
resulting in serious injury or death.
• Do not reach into the washer while parts are
moving. Before loading, unloading, or adding items,
push in the cycle selector knob and allow the drum
to coast to a complete stop before reaching inside.
Failure to follow this warning can cause serious injury,
fire, electrical shock, or death.
• Do not allow children to play on or in the washer.
Close supervision of children is necessary when the
washer is used near children. As children grow, teach
them the proper, safe use of all appliances.
Failure to comply with these warnings could result in
serious personal injuries.
• Destroy the carton, plastic bag, and other packing
materials after the washer is unpacked.
Children might use them for play.
Cartons covered with rugs, bedspreads or plastic sheets
can become airtight chambers. Failure to comply with
these warnings could result in serious personal injuries.
• Keep laundry products out of children's reach.
o prevent personal injury, observe all warnings on
product labels. Failure to comply with these warnings
could result in serious personal injuries.
• Remove the door to the washing compartment to
avoid the danger of children or small animals getting
trapped inside before your washer is removed from
service or discarded.
Failure to do so can result injury or death.
• Before the washer is removed from service or
discarded, remove the washer door to prevent
accidental entrapment.
Failure to comply with these warnings could result in
serious personal injuries.

6
Part 2 SPECIFICATIONS
■
Accessories
■Name: Fron -loading Washing Machine
■Power supply: 220V~ 50Hz
■Size: 68.6 cm (W) X 75.6 cm (D) X 98.3 cm (H), 129.1 cm (D wi h door open)
27”(W) X 293/4”(D) X 3811/16”(H), 5013/16”(D wi h door open)
■Weigh : 190 lbs. (86 kg)
■Wash capaci y: 13 kg
■Spin speed: 1000 rpm max.
■Permissible wa er pressure: 14.5~116 psi (100~800 kPa)
Specifica ions subjec o change by manufac urer.
Note

7
Part 3 IDENTIFICATION
■ WD-10467BD
1. DISPLAY LED
2. CYCLE BUTTON
3. START BUTTON
4. STATUS LED
5. CYCLE LED
1 2
5 4 3

8
Part 3 IDENTIFICATION
The START LED flashes when the full vend price
has been satisfied then the cycle has been chosen.
33START BUTTON
• LED flashes whenever the washing
cycle is in operation.
• LED flashes whenever the Rinsing
cycle is in operation.
• LED flashes whenever the Spining
cycle is in operation.
• LED flashes whenever the door lock
is in operation.
44STATUS LED
EDICAL 90, NOR AL 75, NOR AL 60,
NOR AL 40, and DELICATES 30 is lit for the
cycle is in operation.
55CYCLE LED
The display shows the vend price and remaining time
and programming options. In addition to this, if the
appliance has a problem, it displays error messages.
11DISPLAY LED
By pressing the cycle button, select the desired
cycle based on laundry types and conditions.
Use it for the more medical wash than NOR AL
75 such as white clothes, baby clothes, sheets and
underwear.
22CYCLE BUTTON
* MEDICAL 90
Use it for heavy soiled fabrics such as white clothes,
baby clothes, sheet and underwear.
* NORMAL 75
Use it for heavy soiled fabrics such as baby wear,
underwear and white clothes.
* NORMAL 60
Use it for normal soiled fabrics such as cotton,
linen, towels, shirts and jeans.
* NORMAL 40
1 2
5 4 3
CYCLE LED STATUS LED START BUTTON
DISPLAY LED CYCLE BUTTON
Use it for lightly soiled fabrics such as delicate
fabrics, washable woolens.
* DELICATES 30

9
Part 4 OPERATING YOUR WASHER
The cycle LEDs is lit at the same time, and displayed
‘PUSH’.
11Ready mode
Press the desired button and press the start button.
The display LED will show the remaining time and
the selected cycle starts.
22Select the cycle
You cannot change the course while the machine is
running.
33Change course
The machine stops and LED display shows “End”
with beeper sound.
44Cycle finish
❋Do not work any button and stop the washer
(When the washer is operating) or (when a cycle is
in progress)
■Select cycles designed for different
types of fabric and soil levels.
Cycle
MEDICAL 90 Ex ra Ho /Cold High
NORMAL 75 Ex ra Ho /Cold High
NORMAL 60 Ho /Cold High
NORMAL 40
DELICATES 30 Cold/Cold Low
Warm/Cold High
Wash/Rinse Temp. Spin Speed

10
Part 5 PROGRAMMING MODE
Press Button
MEDICAL 90
NORMAL 75
NORMAL 60
START
escription
Move o upper level or
Comes back o Idle S a e
Move o he mode in he
same level (+)
Move o he modes in he
same level (-)
En er he selec ed mode
How to enter "Programming mode"
You can enter programming mode
only for ready step and pause step.
- Noncoin type
1) Push the EDICAL 90 and NOR AL 60 button
at the same time.
2) Push the NOR AL 75 button 3times.
3) Push the START button.
4) ‘LqC1’ will show on the display.
: You can check machine information or change setting on “Program setup”, ”Diagnostic Test”.
There are two methods that you can enter programming mode.
You can change Washer vend price, cycle time and
Cycle parameters, etc.
How to use button
❁ Programming mode
❁ Case1. Check the programming mode by button
- NONCOIN TYPE -

11
Part 5 PROGRAMMING MODE
• Do no use , .
• I is only used in inspec ing he machine.
Note
1. The me hod of en ering se up mode.
1) Push he MEDICAL 90 and NORMAL 60 bu on a he
same ime.
2) Push he NORMAL 75 bu on 3 imes.
3) Push he START bu on.
4) ‘LqC1’ will show on he display.
2. Press he MEDICAL 90 bu on o move o he upper level.
3. Press he NORMAL 75 or he NORMAL 60 bu on if you wan
o be a he same level.
4. Press START bu on o en er he de ails of Se up, Diagnos ic
Tes s.
is o se price value, ime value, and vend ype e c.
consis s of line es , rese , free cycle, and kill cycle.
Is o collec he usage da a (Card ype or coin ype se up).
■ Algorithm flow chart shows how to control programming mode.
■ Before program set, check the structure of programming mode.
■ STRUCTURE OF PROGRAMMING MODE

12
Part 5 PROGRAMMING MODE - Setup Mode
• Special price days apply or no
• Clear escrow enable or no (coin ype only)
• Add super wash apply or no
• Selec vend ype
• Sense dry apply or no (only for dryer)
Pre-wash apply or no
Top off apply or no (only for dryer)
■Structure of
11How to enter the
Entering set up mode.
You will see LqC1
Button Display
■Content of
Press he ME ICAL 90 bu on.
Press he NORMAL 75 or he NORMAL 60
bu on un il appears in he display.
Press he START bu on.
Press he NORMAL 75 or he NORMAL 60
bu on un il appears in he display.

13
Part 5 PROGRAMMING MODE - Setup Mode
22Pre-wash set up
Entering set up mode.
You will see LqC1
Button Display
One or he o her will
display.
• oFF ( op off ) is no available in washer (Only for dryer)
Note
Press he ME ICAL 90 bu on.
Press he NORMAL 75 or he NORMAL 60
bu on un il appears in he display.
Press he START bu on.
Press he he NORMAL 75 or he NORMAL 60
bu on un il appears in he display.
Press he START bu on.
Display .
Press he START bu on.
Press he NORMAL 75 or he NORMAL 60 bu on and hen
selec or .
Press he START bu on.
The machine se s up he special price day.
1. Con inue o se up he nex mode.
2. S op he change of se up value and go back o ready mode.
• Noncoin ype – Press MEDICAL 90 bu on un il ready
mode appears in he display.
Disable
Enable

14
Part 5 PROGRAMMING MODE - Setup Mode
33Washing time set up
Entering set up mode.
You will see LqC1
Button Display
Press he ME ICAL 90 bu on.
Press he NORMAL 75 or he NORMAL 60
bu on un il appears in he display.
Press he START bu on.
Press he NORMAL 75 or he NORMAL 60
bu on un il appears in he display.
Press he START bu on.
Display previous wash ime.
Press he NORMAL 75(+) or he NORMAL 60(-) bu on o
selec wash ime. (Maximum 15 minu es, Minimum 5 minu es.)
Press he START bu on.
The machine se s up he wash ime, hen advances o he
nex process au oma ically.
1. Con inue o se up he nex mode.
2. S op he change of se up value and go back o ready mode.
• Noncoin ype – Press MEDICAL 90 bu on un il ready
mode appears in he display.

15
Part 5 PROGRAMMING MODE - Setup Mode
44Rinsing times per cycle
Entering set up mode.
You will see LqC1
Button Display
Press he ME ICAL 90 bu on.
Press he NORMAL 75 or he NORMAL 60
bu on un il appears in he display.
Press he START bu on.
Press he NORMAL 75 or he NORMAL 60
bu on un il appears in he display.
Press he START bu on.
Display previous rinsing imes per cycle.
Press he NORMAL 75(+) or he NORMAL 60(-) bu on o
selec rinsing imes per cycle.( Max 5, Min 1)
Press he START bu on.
The machine se s up he rinsing imes per cycle, hen
advances o he nex process au oma ically.
1. Con inue o se up he nex mode.
2. S op he change of se up value and go back o ready mode.
• Noncoin ype – Press MEDICAL 90 bu on un il ready
mode appears in he display.

16
Part 5 PROGRAMMING MODE - Setup Mode
55Rinsing time setup
Entering set up mode.
You will see LqC1
Button Display
Press he ME ICAL 90 bu on.
Press he NORMAL 75 or he NORMAL 60
bu on un il appears in he display.
Press he ME ICAL 90 bu on.
Press he NORMAL 75 or he NORMAL 60
bu on un il appears in he display.
Press he START bu on.
Display previous rinsing ime.
Press he NORMAL 75(+) or he NORMAL 60(-) bu on o
selec rinse cycle.( Max 15min, Min 8min)
Press he START bu on.
The machine se s up he rinsing ime, hen advances o he
nex process au oma ically.
1. Con inue o se up he nex mode.
2. S op he change of se up value and go back o ready mode.
• Noncoin ype – Press MEDICAL 90 bu on un il ready
mode appears in he display.

17
Part 5 PROGRAMMING MODE - Setup Mode
66Top spin speed – final spin time depends on RPM
Entering set up mode.
You will see LqC1
Button Display
Top spin speed
0: 1000rpm
1: 900 rpm
2: 800 rpm
3: 600 rpm
4: 400 rpm
If you selec 800 or below, he final spin ime will be reduced by 9minu es
If you selec 1000 ,900 rpm , he final spin ime is fixed by 13 minu es
Note
Press he ME ICAL 90 bu on.
Press he NORMAL 75 or he NORMAL 60
bu on un il appears in he display.
Press he START bu on.
Press he NORMAL 75 or he NORMAL 60
bu on un il appears in he display.
Press he START bu on.
Display previous op spin speed.
Press he NORMAL 75(+) or he NORMAL 60(-) bu on o
selec op spin speed. (0~4)
Press he START bu on.
The machine se s up he op spin speed, hen advances o he
nex process au oma ically.
1. Con inue o se up he nex mode.
2. S op he change of se up value and go back o ready mode.
• Noncoin ype – Press MEDICAL 90 bu on un il ready
mode appears in he display.

18
Part 5 PROGRAMMING MODE - Setup Mode
77How to change the water level
You can change the water level by selecting two options.
1. LO indicate water level 23.8 [KHz]
2. HI indicate water level 23.7 [KHz]
Entering set up mode.
You will see LqC1
Button Display
• This func ion is only con rolled in machine.
(I is no applied in se up card.)
Note
Press he ME ICAL 90 bu on.
Press he NORMAL 75 or he NORMAL 60
bu on un il appears in he display.
Press he START bu on.
Press he NORMAL 75 or he NORMAL 60
bu on un il appears in he display.
Press he START bu on.
Press he NORMAL 75 or he NORMAL 60 bu on and hen selec
Press he NORMAL 75(+) or he NORMAL 60(-) bu on o
selec value of PIPo. (0~4)
Press he START bu on.
The machine se s up he value of PIPo, hen advances o he
nex process au oma ically.
1. Con inue o se up he nex mode.
2. S op he change of se up value and go back o ready mode.
• Noncoin ype – Press MEDICAL 90 bu on un il ready
mode appears in he display.
One or he o her will
display.
or
23.8 [KHz] 23.7 [KHz]

19
Part 5 PROGRAMMING MODE - Test Mode
Data Name
Entering
the test mode
1. Entering programming mode
2. MEDICAL 90
3. START
Push and hold the MEDICAL 90 and NORMAL 60 at the same time.
After that push NORMAL 75 button for 3 times. Push START button.
Press the MEDICAL 90 button. Then appears in the
display.
Enter the diagnostic test mode.
Button Display Description
Entering the test mode
Diagnostic tests: (display)
This program has been added for testing the washer and detecting errors.
11
According to pressing START button, test move to the next step.
• Make sure he drum is emp y when a diagnos ic es is performed. Do no use .
Note
Number of times the
START button is pressed Check Point
None
1 ime
2 imes
3 imes
4 imes
5 imes
6 imes
7 imes
8 imes
9 imes
10 imes
11 imes
12 imes
13 imes
14 imes
15 imes
16 imes
17 imes
Turns on all lamps and locks he door
Tumble Clockwise.
Low Speed Spin
High Speed Spin
Inle valve for main wa er urns on.
Inle valve for ho wash urns on.
Inle valve for sof ener urns on.
Inle valve for bleach urns on.
Tumble coun er clockwise.
Turn on he hea er
Drain Pump urns on
Turn on Circula ion Pump
Turns on all lamps.
Bu on Checks.
High Speed Spin
PDA Signal Check
Display
Displayed EU XX and LE XX al erna ely
(Version)
rpm (40~50)
rpm (600)
rpm (1000)
Wa er level frequency (261~)
Wa er level frequency (261~)
Wa er level frequency (261~)
Wa er level frequency (261~)
rpm (40~50)
Displayed 0XX
Wa er level frequency (261~)
Displayed 0XX
Displayed EU XX and LE XX al erna ely
Displayed EU XX and LE XX al erna ely
rpm(1000)
his func ion is no applied in his machine

20
Part 5 PROGRAMMING MODE - Test Mode
22Factory reset - EEPt
After factory reset, machine information is changed to the default value.
Entering set up mode.
You will see LqC1 Press he NORMAL 75 or he NORMAL 60
Bu on un il appears in he display.
Press he START bu on.
Press he NORMAL 75 bu on un il appears in he
display.
Press he START bu on, hen fac ory rese is done.
is displayed.
1. Con inue o se up he nex mode.
2. S op he change of se up value and go back o ready mode.
• Noncoin ype – Press MEDICAL 90 bu on un il ready mode
appears in he display.
Button Display
• Washing time 10 minutes
• Rinse cycle twice
• Top spin speed 1,000 RPM
• Water level is HI(23.7Kh)
Note
