LG WD-1370 Series User manual

Washing Machine
OWNER’S MANUAL
WD-1370(5)F(H)B
WD-1270(5)F(H)B
WD-1170(5)F(H)B
WD-1070(5)F(H)(B)
WD-8070F(H)(B)
Thank you for buying a
LG Fully Automatic Washing machine.
Please read your owner’s manual carefully, it provides
instructions on safe installation, use and maintenance.
Retain it for future reference.
Record the model and serial numbers of your washing machine.

roduct Feature
P
ontents
C
2
Warnings....................................................................................3
Specification ..............................................................................4
Installation..................................................................................5
Care before washing................................................................11
Adding detergent .....................................................................12
Function...................................................................................13
How to use washer..................................................................14
Maintenance............................................................................21
Troubleshooting guide.............................................................24
" Jumbo drum
LG’s jumbo drum can wash about 40% more load than
conventional washing machines. A bigger drum improves the wash
performance.
" More economical by Intelligent Wash System
Intelligent Wash System detects the amount of load and water
temperature, and then determines the optimum water level and
washing time to minimize energy and water consumption.
" Child-Lock
The Child-Lock system has been used to prevent children from
pressing any button to change the program during operation.
" Low noise speed control system
By sensing the amount of load and balance, it evenly distributes
load to minimize the spinning noise level.
" Auto Restart
If the washing machine is turned off by a power failure, it will restart
automatically from the position it stopped at adjusting accordingly.
40%

arnings
W
3
For your safety, the information in this manual must be followed to minimize
the risk of fire or explosion, electric shock, or to prevent property damage,
personal injury, or loss of life.
!
READ ALL INSTRUCTIONS BEFORE USE
WARNING!
•Do not install or store the washer where it will
be exposed to the weather.
•Do not tamper with controls.
•Do not repair or replace any part of the washer
or attempt any servicing unless specifically
recommended in the user-maintenance
instructions or published user-repair instructions
that you understand and have the skills to carry
out.
•Keep the area underneath and around your
appliances free of combustible materials such as
lint, paper, rags, chemicals, etc.
•Close supervision is necessary if this appliance
is used by or near children.
Do not allow children to play on, with, or inside
this or any other appliance.
•Do not leave the washer door open.
An open door could entice children to hang on
the door or crawl inside the washer.
•Never reach into washer while it is moving. Wait
until the drum has completely stopped.
•The laundry process can reduce the flame
retardant of fabrics.
•Do not wash or dry articles that have been
cleaned in, washed in, soaked in, or spotted with
combustible or explosive substances (such as
wax, oil, paint, gasoline, degreasers, dry-
cleaning solvents, kerosene, etc.) which may
ignite or explode.
•To avoid such a result, carefully follow the
garment manufacturer’s wash and care
instructions.
•Do not slam the washer door closed or try to
force the door open when locked. This could
result in damage to the washer.
•To minimize the possibility of electric shock,
unplug this appliance from the power supply or
disconnect the washer at the household
distribution panel by removing the fuse or
switching off the circuit breaker before
attempting any maintenance or cleaning.
•Never attempt to operate this appliance if it is
damaged, malfunctioning, partially
disassembled, or has missing or broken parts,
including a damaged cord or plug.
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of malfunction or breakdown, grounding will reduce the risk
of electric shock by providing a path of least resistance for electric current. This appliance is equipped with
a cord having an equipment-grounding conductor and grounding plug. The plug must be plugged into an
appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinance.
•Do not use an adapter or otherwise defeat the grounding plug.
•If you don’t have the proper outlet, consult an electrician.
IMPORTANT SAFETY INSTRUCTIONS
WARNING :To reduce the risk of fire, electric shock, or injury to persons when using
the washer, follow basic precautions, including the following:
SAVE THESE INSTRUCTIONS
WARNING :Improper connection of the equipment-grounding conductor can result in risk of electric
shock. Check with a qualified electrician or serviceman if you are in doubt as to whether the appliance is
properly grounded. Do not modify the plug provided with the appliance - if it does not fit the outlet, have a
proper outlet installed by a qualified electrician.

pecification
S
4
Power plug
Control panel
Door
Lower cover
Leveling leg
(For detergent and
fabric softener)
Drawer
Drum
Drain hose
Lower cover cap
Drain pump filter
Drain plug
If the supply cord is damaged,
it must be replaced by the
manufacturer or its service agents
or a similarly qualified person in
order to avoid a hazard.
"Name : Front loading washing machine
"Power supply : 220-240V~, 50Hz
"Size : 600mm(W) 600mm(D) 850mm(H)
"Weight / Max.Watt : 63kg / 2100W [WD-1370(5)F(H)B, WD-1270(5)F(H)B
WD-1170(5)F(H)B, WD-1070(5)F(H)B
WD-8070F(H)B]
67kg / 2200W [WD-1070(5)F(H), WD-8070F(H)]
"Wash capacity : 7.0kg
"Spin speed : No Spin/400/600/800[WD-8070F(H)(B)]
No Spin/400/600/800/1000[WD-1070(5)F(H)B]
No Spin/400/600/800/1100[WD-1170(5)F(H)B]
No Spin/400/600/800/1000/1200[WD-1270(5)F(H)B]
No Spin/400/600/800/1100/1300[WD-1370(5)F(H)B]
"Water consumption : 75 (10.7 / kg )
"Permissible water pressure : 0.3-10kgf/ (30-1000kPa)
❋The appearance and specifications may be varied without notice to raise the units quality.
Inlet hose(1EA) Option : Hot/Cold(2EA) Spanner
" Accessories

nstallation
I
5
1. To prevent internal damage during
transport, the special 4 bolts are locked.
Before operating the washer, remove
the bolts along with the rubber bungs.
•If they are not removed, it may cause heavy
vibration, noise and malfunction.
3. Take out the 4 bolts along with the rubber
bungs by slightly twisting the bung. Keep
the 4 bolts and the spanner for future use.
•Whenever the appliance is transported, the
transit bolts must be refitted.
The appliance is fitted with transit bolts to prevent internal damage during transport.
2. Unscrew the 4 bolts with
the spanner supplied. 4. Close the holes with the caps supplied.
" Transit bolts
Install or store where it will not be exposed to temperatures below freezing or exposed to the weather.
Properly ground washer to conform with all governing codes and ordinances.
The base opening must not be obstructed by carpeting when the washing machine is installed on a
carpeted floor.
" Removing transit bolts
cap

nstallation
I
6
Level floor :
Allowable slope under entire washer is 1˚
Power outlet :
Must be within 1.5 meters of either side of location
of washer. Do not overload the outlet with more
than one appliance.
Additional Clearance :
For wall, door and floor modeling is required.
(10cm : rear /2cm:right & left side)
Do not place or store laundry products on top of
washer at any times.
They can damage the finish or controls.
" Installation place requirement
Laundry
Tub
Washer
approx.
2cm
Drain Hose
" BS Plug Safety Details (For U.K. User)
IMPORTANT
THE WIRES IN THIS MAINS LEAD ARE COLOURED IN
ACCORDANCE WITH THE FOLLOWING CODE:
GREEN AND YELLOW: EARTH
BLUE: NEUTRAL
BROWN: LIVE
This appliance must be earthed
As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings
identifying the terminals in your plug, proceed as follows:
The wire which is coloured Green and Yellow must be connected to the terminal in the plug which is marked with the
letter E or by the earth symbol ( ) or coloured Green or Green and Yellow.
The wire which is coloured Blue must be connected to the terminal which is marked with the letter N or coloured Black.
The wire which is coloured Brown must be connected to the terminal which is marked with the letter L or coloured Red.
If a 13 amp (BS 1363) plug is used, fit a 13 amp BS 1362 fuse.
Green andYellow(Earth)
Brown(Live)
Blue(Neutral) Fuse
Cord
grip
E
L
N
650
850
600

7
nstallation
I
Water supply pressure must be between
30kPa and 1000kPa (0.3~10kg.f/cm2)
Don’t strip or crossthread when connecting
Inlet hose to the valve.
If the water supply pressure is more than
1000kPa, a decompression device should be
installed.
•Two rubber seals are supplied with the
water inlet hoses these are in order to
prevent water leaks.
•Check water tightness of washing
machine connections by turning the tap
completely on.
•Periodically check the condition of the
hose and replace the hose if necessary.
•Make sure that there is no kink on the
hose and that it is not crushed.
When your washer has two valves,
•The Inlet hose which has red connector is
for the hot water tap.
•If the washer has two valves, the energy
is saved by using hot valve.
" Washing Machine is to be connected to the water mains using new hose-
sets and that old hose-sets should not be used.
" Connecting water supply hose
Rubber seal
Hose connector
Hot water tap
Cold Hot(option) Cold
water
tap
1. Do not use an extension cord or double adapter.
2. If the supply cord is damaged, it must be replaced by the manufacturer or its service agents
or similarly qualified person in order to avoid a hazard.
3. Always unplug the machine and turn off the water supply after use.
4. Connect the machine to an earthed socket in accordance with current wiring regulations.
5. The appliance must be positioned so that the plug is easily accessible.
" Electrical connection

8
nstallation
I
" Normal Tap without thread & screw type inlet hose
" Normal Tap without thread & one touch type inlet hose
1.Unscrew the fixing screw to
attach the tap. 2.Push the connector up till the rubber packing is in tight contact
with the tap. Then tighten the 4
screws.
3.Push the water supply hose
vertically upwards so that the
rubber packing within in the
hose can adhere completely to
the tap and then tighten it by
screwing it to the right.
1.Untighten the upper connector
screw. 2.Push the upper connector up till the rubber packing is in tight
contact with the tap. Then
tighten the 4 screws.
3. Connect the water supply hose
to the middle connector,
pushing the plate down.
•Your machine comes with only
cold water connection.
•Make sure that there are no
kinks in the hose and that it is
not crushed.
•Make sure that the rubber seal
is inside the hose connector.
Upper
Connector Rubber
packing
Middle
connector
Fixing screw
Guide plate
Connector
Rubber seal
Hose connector
Used the horizontal tap
Horizontal tap
Extension tap
Square tap
Rubber packing
Upper
Connector
Middle
connector
Plate
Upper
Connector
Water supply
hose
•In case the diameter of the tap is
large remove the guide plate.
•Turn the middle connector not
to have water leaked. •To separate the water supply
hose from the middle connector
shut off the tap. Then pull the
inlet hose down, pushing the
plate down.

9
nstallation
I
" Installation of drain hose
max. 100 cm
min. 60 cm
ca. 105 cm
ca. 145 cm
ca. 100 cm
max. 100cm
min. 60cm
Hose
Retainer
Laundry tub
Tie
strap max. 100cm
min. 60cm
max. 100 cm
ca. 105 cm
ca. 145 cm
ca. 100 cm
min. 60 cm
•The drain hose should not be placed
higher than 100 cm above the floor.
•Proper securing the drain hose will
protect the floor from damage due to
water leakage.
•When the drain hose is too long, please
don’t fill into the washer. This will cause
abnormal noise.
•When installing the drain hose sink,
secure it tightly with a string.
•Proper securing the drain hose will protect
the floor from damage due to water
leakage.
•When installing the drain hose sink,
secure it tightly with a string.
•Proper securing the drain hose will protect
the floor from damage due to water
leakage.

10
nstallation
I
" Level adjustment
1. Leveling the washing machine properly
prevents excessive noise and vibration.
Install the appliance on a solid and level
floor surface, preferably in a corner of
the room.
2. If the floor is uneven, adjust the leveling
feet as required. (do not insert pieces of
wood etc. under the feet)
Make sure that all four feet are stable
and resting on the floor and then check
that the appliance is perfectly level. (use
a spirit level)
❊ Diagonal Check
When pushing down the edges of the
washing machine top plate diagonally, the
machine should not move up and down at
all. (Please, check both of two directions)
If machine rocks when pushing the machine
top plate diagonally, adjust the legs again.
Leveling leg
Higher Lower
Leveling leg

11
are before washing
C
1. Care Labels
Look for a care label on your clothes. This will tell you about the fabric content of your
garment and how it should be washed.
2. Sorting
To get the best results, Sort clothes into loads that can be washed with the same wash cycle.
Water temperature and spin speed and different fabrics need to be washed in different ways.
Always sort dark colors from pale colors and whites. Wash separately as dye and lint
transfer can occur causing discoloration of white etc. If possible, do not wash heavily
soiled items with lightly soiled one.
Soil (Heavy, Normal, Light) Separate clothes according to amount of soil.
Color (White, Lights, Darks) Separate white fabrics from colored fabrics.
Lint (Lint producers, Collectors) Wash lint producers and lint collectors
separately.
3. Caring before loading
" Caring before washing
" Combine large and small items in a load. Load large items first. Large items should not be more
than half the total wash load.
Do not wash single items. This may cause an out-of-balance load. Add one or two similar items.
•Check all the pockets to make sure
that they are empty. Things such
as nails, hair clip, matches, pens,
coins and keys can damage both
your washer and your clothes.
•Close zippers, hook and strings to
make sure that these items don’t
snag on other clothes.
•Pre treat dirt and stains by brushing
a little detergent dissolved in water
onto stains like collars and cuffs to
help shift dirt.

12
dding detergent
A
•Main wash only U
•Pre Wash + Main Wash U
•Do not exceed the maximum fill line.
Overfilling can cause early dispensing
of the fabric softener which could stain
clothes.
•Do not leave the fabric softener in the
detergent drawer for more than 2 days.
(Fabric softener could harden)
•Softener will automatically be added
during last rinse cycle.
•Do not open the drawer when water is
supplied.
•Solvents(benzene, etc) are not
allowable.
1. The Dispenser Drawer
• The detergent should be used according to the
instruction of the detergent manufacture.
• If too much detergent is used more than the
recommended amount, too many suds can
occur and this will decrease the washing result
or cause heavy load to the motor. (Causing a
malfunction)
• Use powder detergent only for the front
loading washer.
•Detergent usage may need to be adjusted
for water temperature, water hardness,
size and soil level of the load. For best
results, avoid oversudsing.
❋ Tips
Full load : according to
manufacturer’s recommendation.
Part load : 3/4 of the normal amount.
Minimum load : 1/2 of full load.
•Detergent is flushed from the dispenser at
the beginning of the cycle.
3. Detergent dosage
2. Adding Fabric Softener
" Adding detergent and fabric softener
MAX
max
( )
125 ml
MAX MAX
125 ml
NOTE
Do not pour fabric softener
directly on the clothes

13
unction
F
" Recommended courses according to the laundry type
❋ Pre Wash : If the laundry is heavily soiled, “Pre Wash”course is effective. Pre Wash is available in
Coloureds, Whites and Synthetic Program.
❋ Eco : By selecting Eco function, the water temperature is reduced and washing time is
lengthened. So you can economize in your consumption of energy.
❋ Rinse+ : If you wish to rinse more, the Rinse+ function will remove any trace of detergents.
❋ Bio : If you want to elimenate protein stains (milk, blood, chocolate...), you may select Bio function
by pressing the option button.
❋ You can select Bio function and Eco function when temperature is higher than 60˚C in Whites,
Coloureds and Synthetic.
Fabric Proper Maximum Water Energy Time
Program Option in in in
Type Temp. Load Liter kWh Minutes
Whites
Coloureds
Synthetic
Delicate
Wool
Hand
Wash
First check if
laundry is machine
washable.
(white cotton, linen
towel and sheets...)
Color fast gaments
(shirts, night dresses,
pajamas...)and
lightly soiled white
cotton(underwear...)
Polyamide, Acryic,
Polyester
Delicate laundry
easily damaged
(silk, curtains...)
Machine washable
woolens with pure
new wool only
“Hand Wash”
marked delicate and
wool laundry
95˚C
(60˚C, 50˚C,
40˚C)
40˚C
(50˚C, 60˚C,
Cold, 30˚C)
40˚C
(50˚C, 60˚C,
Cold, 30˚C)
30˚C
(40˚C, Cold)
30˚C
(40˚C, Cold)
Cold(30˚C,
40˚C)
Pre Wash
Eco
Rinse+
Bio
Rapid
Pre Wash
Eco
Rinse+
Bio
Rapid
Pre Wash
Eco
Rinse+
Bio
Rinse+
Rinse+
Rinse+
Rating
Rating
Less than
4.0 kg
Less than
3.0 kg
Less than
2.0 kg
Less than
2.0 kg
85
75
58
58
53
51
2.74
0.72
0.6
0.41
0.28
0.03
158
115
88
58
58
57

14
ow to use washer
H
•Push the Power button to start.
•Push the Start/Pause button.
•Initial condition
- Wash : Only main wash
- Rinse : 3 times
- Spin : 800 rpm
- Water temperature : 40˚C
- Program : Coloureds
•Push the Power button to start.
•Select the conditions which you want to
use, by pressing each button.
For selecting the each conditions, please
refer to the page15~page20
•Push the Start/Pause button.
1. For use in the initial
programme (Coloureds) 2. Manual Selecting

15
ow to use washer
H
(1) Button : Option
(2) Button : Spin
(3) Button : Temp.
(4) Child lock
(5) Button : Time Delay
(6) Button : Rapid
(7) Button : Start/Pause
(8) Dial : Program
(9) Button : Power
(1) (2) (3) (4) (5) (6) (7) (8) (9)
1. Bio
2. Rinse+
Option
•By pressing the Option
button, the Option function
can be selected.
- Bio
- Rinse+
- Eco
- Pre Wash
•
If you want to elimenate protein stains(milk, blood,
chocolate...), you may select Bio function by
pressing the option button.
[You can select Bio function when temperature is
higher than 60 C in Whites, Coloureds and
Synthetic.]
•If you wish to rinse more, Rinse+function
will remove any trace of detergents.
•By selecting Rinse+function, the Rinse
Time and the Rinse water are increased.
4. Pre Wash
3. Eco
•By selecting Eco function, the water
temperature is reduced and washing time is
lengthened. So you can economize in your
consumption of energy.
[You can select Eco function when
temperature is higher than 60 C in Whites,
Coloureds and Synthetic.]
•If the laundry is heavily soiled, “Pre Wash”
course is effective.
•Pre Wash is available in Whites,
Coloureds and Synthetic.
If lamp turns on, that function has been
selected.

16
ow to use washer
H
1. Spin selection
Spin
•By pushing the Spin button, the spin rpm
can be chosen.
[WD-1070(5)F(H)(B)] [WD-1170(5)F(H)B]
•Spin speed is available according to the
program as follows.
•WD-8070F(H)(B)
- Whites / Coloureds / Synthetic
800URinse HoldUNo SpinU400U600
- Delicate / Wool / Hand Wash
400U600U800URinse HoldUNo Spin
•WD-1070(5)F(H)(B)
- Whites / Coloureds/Synthetic
800U1000URinse HoldUNo
SpinU400U600
- Delicate
400U600U800URinse HoldUNo Spin
- Wool / Hand Wash
400U600U800U1000URinse HoldUNo
Spin
•WD-1170(5)F(H)B
- Whites / Coloureds/Synthetic
800U1100URinse HoldUNo
SpinU400U600
- Delicate
400U600U800URinse HoldUNo Spin
- Wool / Hand Wash
400U600U800U1100URinse HoldUNo
Spin
•WD-1270(5)F(H)B
- Whites / Coloureds
800U1000U1200URinse HoldU
No SpinU400U600
- Synthetic
800U1000URinse HoldUNo SpinU
400U600
- Delicate
400U600U800URinse HoldUNo Spin
- Wool / Hand Wash
400U600U800U1000URinse HoldUNo
Spin
[WD-8070F(H)(B)]
[WD-1270(5)F(H)B] [WD-1370(5)F(H)B]

17
ow to use washer
H
2. No spin
•WD-1370(5)F(H)B
- Whites / Coloureds
800U1100U1300URinse HoldU
No SpinU400U600
- Synthetic
800U1100URinse HoldUNo SpinU
400U600
- Delicate
400U600U800URinse HoldUNo Spin
- Wool / Hand Wash
400U600U800U1100URinse HoldUNo
Spin
3. Rinse Hold
•If you desire to leave fabrics in the machine
without spinning after rinse to prevent them
from getting wrinkled, you may select rinse
hold by pressing the spin button.
•If you want to drain and spin, when Rinse
Hold function is proceed, Push the
Start/Pause button to cancel the Rinse Hold
function and select spin speed or program.
Push the Start/Pause button again to start
program.
•If you want to drain only, select the no spin
or pump program.
If lamp turns on, that function has been selected.
•If no spin is selected, the washer stops after
draining water.
If lamp turns on, that function has been
selected.
1. Water Temperature
Water Temp.
•By pushing the Temp
button, the water
temperature can be
selected.
- Cold
- 30˚C / 40˚C / 50˚C / 60˚C /
95˚C
•Water temperature can be selected as
below according to the program.
- Whites
95˚C
U 40˚C U 50˚C U 60˚C
- Coloureds & Synthetic
40˚C
U 50˚C U 60˚C U Cold U 30˚C
- Delicate & Wool
30˚C
U 40˚C U Cold
- Hand Wash
Cold
U 30˚C U 40˚C
Selected temperature’s lamp turns on.
For the more detailed information, please refer
to the page13.

18
ow to use washer
H
Child lock
Time Left
Time Left
Change
the desired
program
If you want to lock all the buttons to prevent
operation by a child or infirm persons, this
function can be used.
•Child lock can be set by pressing the Temp.
button and Time Delay button simultaneously.
• When child lock is set, all buttons are inoperable.
•To deactivate Child lock system, push Temp. and
Time Delay button simultaneously again.
•If you want to change the program when Child
lock is active,
1. Press both Temp. and Time Delay together.
2. Press the Start/Pause button.
3. Change the desired program and press the
Start/Pause button.
•The child lock can be set at any time and it is
automatically canceled when operational errors
occur. Also Child lock works when power is off.
1. Child lock
Time Left Time Left
Time Delay
1. Time Delay
Preparing washing before starting “Time
Delay”
- Turn on the water tap.
- Load laundry and close the door.
- Place the detergent and fabric softener in
the drawer.
•How to set “Time Delay”
- Push Power button.
- Turn the Programme dial to select
the program you require.
- Push Time Delay button and set the
desired time.
- Push the Start/Pause button.
(“:”blinks.)
•If Time Delay button is pushed, “3:00”is
displayed. The maximum delayed time is
19:00 hours and the minimum time is 3:00
hours.
•Each pushing of the button advances on
time delay by one hour.
•To cancel the time delay, push the Power
button.
•Time Delay is ‘expected time’from the
present to the completion of washing cycle
or selected process (Wash, Rinse, Spin).
• According to the condition of water supply and
temperature, the delayed time and the actual
washing time may vary.

19
ow to use washer
H
Rapid
1. Rapid
•By pressing the Rapid
button, Rapid function is
selected.
•Rapid function reduces the whole time
including the washing and rinsing time
about by half an hour.
•Rapid is available in Whites, Coloureds
program.
If lamp turns on, that function has been selected.
Start/Pause
•This Start/Pause button is used to start
wash cycle or pause the cycles.
•If temporary stop of wash cycle is needed,
push “Start/Pause”button.
•After the pause button is pressed, the power
is turned off automatically 4 minutes later.
1. Start
2. Pause
Programme
•9 programs
are available
according to
the laundry
type.
1. Program
2. Course
•When Start/Pause button is pushed,
Coloureds program is automatically selected.
- By turning the Program dial, the program is
selected in orders of “Coloureds
U
Synthetic U Delicate U Wool U
Hand Wash U Rinse+Spin U Spin U
Pump U Whites”.
Regarding to the laundry type for each program
Please refer to the page13.
- Whites
- Coloureds
- Synthetic
- Delicate
- Wool
- Hand Wash
- Rinse+Spin
- Spin
- Pump
(Programme)
1. Power
2. Initial Program
Power
•Press the Power button to turn power on
and off
•To cancel the Time Delay function, it
can also be used.
•When the Power button is pushed, the
washer is ready for Coloureds program.
And the other initial conditions as follows.
•So, if you want to advance into the
washing cycle without selecting the
program, just push Start/Pause button
and then the washer will proceed.
Initial program
- Coloureds Program / Main wash /
Normal Rinse/800 rpm / 40˚C

20
ow to use washer
H
•If the washer has a trouble, the trouble
type is displayed.
“”: Sensing water pressure error
“”: Problem of overfilling water
“”: Door is not closed
“”: Over load in moter.
“”: Over load in moter.
“”: Water inlet trouble
“”: Drainage trouble
“”: Imbalance trouble
“”: Water temperature trouble
If this error letters are displayed, please refer
to the troubleshooting page24 and follow the
guide.
Display
•When child lock is selected, the
“”is displayed.
•When time delay is selected, it shows
the remaining times to finish the selected
program.
•When washing cycle is completed,
“”is displayed on the “Multi
display”.
•During washing cycle, the remaining
washing time is displayed.
•Recommended program by
manufacturer.
- Whites : around 2 hours and 38 minutes
- Coloureds : around 1 hour and 55 minutes
- Synthetic : around 1 hour and 28 minutes
- Delicate : around 58 minutes
- Wool : around 58 minutes
- Hand Wash : around 57 minutes
- Rinse+ Spin : around 19 minutes
- Spin : around 11 minutes
- Pump : around 1 minute
•The washing time may vary by the
amount of laundry, water pressure,
water temperature and other washing
conditions.
•If the imbalance is detected or if the
suds removing program works, the
wash time shall be longer.
(Max. increasing time is 45minutes.)
1. Special function display
3. Completion of washing
4. Time left
2. Self diagnose display
