LG WM3070HRA User manual

INNOVATIONS
•TurboWash™ Technology
•Steam Technology
•AAFA Certified Allergiene™ Cycle
•NSF Certified Sanitary Cycle
•ColdWash™ Option
•6Motion™ Technology
•SmartDiagnosis™
•TrueBalance™ Anti-Vibration System
•Magnet Ventilation
•ENERGY STAR Most Efficient 2012
•LoDecibel™ Quiet Operation
•SenseClean™
•Delay Wash (Up to 19 Hours)
•10° TilTub™
BUCKLE YOUR SEATBELT:
TURBOWASH™ IS FAST!
You’ve got better things to do than spend all day doing
your laundry. LG’s amazing TurboWash™ Technology
allows you to save 20 minutes per load, even on
larger loads!* This state-of-the-art washer showcases
supercharged steam cleaning that virtually eliminates
dirt and wrinkles, plus ColdWash™ powered by
6Motion™ technology to save you some bucks. With
so many amazing features, you might be sorry that it
all happens so quickly!
Tired of spending hours on end finishing
your family’s laundry? Now, those days
are gone. LG’s revolutionary TurboWash™
Technology allows you to save 20 minutes
on larger loads*, with outstanding cleaning
performance! It’s like pressing the fast
forward button on your laundry.
Towers of towels, piles of sweatshirts, and a
mountain of jeans? Go for it. The extra large
capacity (3.7 cu.ft.) tub lets you do more
laundry in fewer loads. That’s time saved
and sore backs avoided.
There’s no clean like a steam clean. Our
Steam Technology gently but powerfully
penetrates fabrics to virtually eliminate dirt,
odors and wrinkles.
Extra Large Capacity TurboWash™ Washer
WM3070H_A
TurboWash™ Technology Extra Large Capacity Steam Technology
SPECIFICATIONS
•3.7 cu. ft. Ultra Large Capacity with
NeveRust™ Stainless Steel Drum
•Direct Drive Motor with
10-Year Limited Warranty
•1,200 RPM
•12 Washing Programs
•5 Temperature Settings
(All Cold Rinses)
STYLISH DESIGN
•Upfront Electronic Control Panel with
Dual LED Display and Dial-A-Cycle™
•Chrome Rimmed Glass Door
•Stackable with Matching Dryer
(Stacking Kit Sold Separately)
•Optional Matching Drawer Pedestal
* Based on AHAM-HLW-1-2010 test protocol. Cotton/Normal or comparable cycle at default settings, 8-lb loads, front load washers only.
Excludes other LG manufactured products. Excludes quick wash or comparable cycles intended for small, lightly soiled loads only.

Design, features and specifications are subject to change without notice.
Non-metric weights and measurements are approximate.
© 2012 LG Electronics USA, Inc. All rights reserved. “LG Life’s Good” is a
registered trademark of LG Corp. All other product and brand names are
trademarks or registered trademarks of their respective companies. 3/29/12
Extra Large Capacity TurboWash™ Washer
WM3070H_A
CapaCit y
Capacity 3.7 cu. ft.
appEaRaNCE
Design Look Front Control
Intelligent Electronic Controls with Dual LED Display •
Dial-A-Cycle™ •
ENERGy
Energy Star •
2012 ENERGY STAR MOST EFFICIENT •
WaSH pROGRaMS
No. of Programs 12
Wash Programs
Cotton/Normal, Bulky/Large, Perm. Press, Delicates, Hand Wash/Wool,
Speed Wash, Sanitary, Heavy Duty, BrightWhites™, Towels, Allergiene™, Tub Clean
No. of Options 11
Options Prewash, Rinse+Spin, Delay Wash, Custom Program, Extra Rinse,
Child Lock, ColdWash™, Signal On/Off, Steam, FreshCare™, TurboWash™
No. of Wash/Rinse Temps Extra Hot, Hot, Warm, Cold, Tap Cold (All Cold Rinses)
Spin Speeds Extra High (1,200 max.), High, Medium, Low, No Spin
No. of Water Levels Automatically adjusts to the size of load
No. of Soil Levels 5
FaBRiC CaRE FEatURES
TurboWash™ •
Steam •
ColdWash™ Option •
Allergiene™ Cycle •
SenseClean™ System •
CONVENiENCE FEatURES
4 Tray Dispenser Prewash, Main Wash (with liquid detergent cup),
Bleach, Fabric Softener
TrueBalance™ Anti-Vibration System •
SmartDiagnosis™ •
LoadSense •
Status Indicator(s) •
End of Cycle Signal •
Child Lock •
Auto Suds Removal •
Forced Drain System •
Internal Water Heater •
LoDecibel™ Quiet Operation •
Leveling Legs 4 Adjustable Legs
Easy Loading TilTub™ •
MOtOR aND aGitatOR
Motor Type Direct Drive Motor
Motor Speed Variable
Max RPM 1,200
Axis Horizontal
MatERiaLS aND FiNiSHES
NeveRust™ Stainless Steel Drum •
Cabinet PCM
Control Panel Plastic
Top Plate Painted
Transparent Glass Door •
Door Rim Chrome Rimmed Glass Door
Available Colors Wild Cherry Red (R), White (W)
pOWER SOURCE
Ratings UL Listed
Electrical Requirements 120V, 10 Amps
Type Electric
OptiONS
Pedestal WDP4W, WDP4R
Pedestal (WxHxD) 27" x 13 3/5" x 28 2/5"
Stacking Kit KSTK1
DiMENSiONS
Product (WxHxD) 27" x 38 11/16" x 29 3/4"
(51" D with door open)
Carton (WxHxD) 29 1/2" x 42 1/4" x 31 1/4"
Weight (Product/Carton) 213.9 lbs/224.8 lbs
LiMitED WaRRaNty
1 Year Parts and Labor,
10 Years Motor
Lifetime on Drum
UpC CODES
WM3070HRA Washer (Wild Cherry Red) 048231 012713
WM3070HWA Washer (White) 048231 012683
DLEX3070R Electric Dryer (Wild Cherry Red) 048231 012720
DLGX3071R Gas Dryer (Wild Cherry Red) 048231 012737
DLEX3070W Electric Dryer (White) 048231 012690
DLGX3071W Gas Dryer (White) 048231 012706
WDP4R Pedestal (Wild Cherry Red) 048231 011204
WDP4W Pedestal (White) 048231 011211
KSTK1 Stacking Kit (Chrome) 048231 013024
LG Electronics U.S.A., Inc.
1000 Sylvan Avenue Englewood Cliffs, NJ 07632
Customer Service and Technical Support: [phone]
LG.com
Optional
dryer & pedestals
sold separately.
