LG WM3080CW User manual

Please read this owner's manual thoroughly before operating and
keep it handy for reference at all times.
WM3080C*
MFL70183003
Copyright © 2017 LG Electronics Inc. All Rights Reserved.
ENGLISH ESPAÑOL
OWNER’S MANUAL
WASHING
MACHINE
www.lg.com
9HU1512
FRANÇAIS

2PRODUCT FEATURES
PRODUCT FEATURES
INVERTER DIRECT-DRIVE MOTOR
The inverter motor, which is directly connected to the drum, produces little noise and vibration and offers
great durability and a long lifespan.
SMART DIAGNOSIS™
Should you experience any technical difficulty with your washing machine, it has the capability of
transmitting data by phone to the Customer Information Center. The call center agent records the data
transmitted from your machine and uses it to analyze the issue, providing a fast and effective diagnosis
(Refer to page 38).
TUB CLEAN
Regular cleaning of the tub on a monthly basis using Tub Clean can help keep the tub clean and fresh.
MAGNETIC DOOR PLUNGER
Safely and conveniently secure the door slightly ajar with the magnetic door plunger. This will promote air
circulation and allow the interior of the machine to dry. To use this feature, after the load has been removed,
do not close the door completely.
When the magnetic door plunger comes into contact with the metal washer cabinet, it will secure the door
slightly open allowing the interior of the washer to dry.
LARGE CAPACITY STAINLESS STEEL DRUM
The large capacity stainless steel drum offers extreme durability and is tilted to improve efficiency and allow
easier access for large items.
CHILD LOCK
Use this option to disable the controls during a wash cycle. This option can prevent children from changing
cycles or operating the machine.
DETERGENT DISPENSER DRAWER
The four-compartment dispenser drawer makes it easy to separate the pre-wash detergent, the main laundry
detergent, liquid bleach, and fabric softener into different compartments.
HIGH TEMPERATURE STEAM CYCLES
During LG's unique high-temperature steam cycles, the hot steam helps to remove tough stains.
TAG ON
The Tag On feature works on most NFC equipped smart phones by communicating with your Tag On
equipped LG appliance. Using the LG SmartThinQ application, the Tag On feature allows you to diagnose
your appliance, download new cycles, and see the status of your appliance by simply touching the smart
phone to the Tag On logo of the appliance.

3
ENGLISH
TABLE OF CONTENTS
TABLE OF CONTENTS
2PRODUCT FEATURES
4IMPORTANT SAFETY INSTRUCTIONS
4 BASIC SAFETY PRECAUTIONS
5 GROUNDING INSTRUCTIONS
6 SAFETY INSTRUCTIONS FOR INSTALLATION
7 SAFETY INSTRUCTIONS FOR USE, CARE,
CLEANING, AND DISPOSAL
8PRODUCT OVERVIEW
8 Parts
8 Accessories
9Control Panel Features
11 INSTALLATION
11 Installation Overview
12 Choosing the Proper Location
13 Unpacking and Removing Shipping Bolts
14 Connecting the Water Lines
15 Connecting the Drain Line
16 Leveling the Washer
17 Connecting to the Power Supply
17 Testing the Washer
18 PREPARATION
18 Sorting Wash Loads
19 - Fabric Care Labels
19 - Sorting Laundry
20 Using Detergent/Fabric Softener
20 -Recommended Detergent
20 - Loading the Dispenser
22 OPERATION
22 Using the Washer
23 Cycle Guide
24 Wash Cycles
24 - Bulky/Large: Blankets or Bulky Items
24 - Cotton/Normal: Normal Items
24 - Heavy Duty: Heavily Soiled Items
24 - Perm. Press:Wrinkle-Free Items
24 - Delicates: Sheer Items
24 - Towels
24 - Speed Wash: Washing Quickly
25 Cycle Modifier Buttons
25 Setting Options Before Cycle
25 - Wash Temp.
25 - Spin Speed
25 - Soil Level
26 - Signal
26 - Pre Wash
26 - Rinse + Spin
26 - Extra Rinse
26 - Delay Wash
27 - Water Plus
27 - Cold Wash™
27 - Fresh Care
28Setting Options During Cycle
28- Child Lock
28 - Add Garments
29 MAINTENANCE
29 Regular Cleaning
29 - Care After Wash
29 - Care in Cold Climates
30 Cleaning
30 - Tub Clean
31 - Cleaning the Detergent Dispenser Drawer
32 - Cleaning the Water Inlet Filters
33 - Cleaning the Drain Pump Filter
34 - Cleaning the Door Seal
35 TROUBLESHOOTING
35 Checking Error Messages
36 Before Calling for Service
37 SPECIFICATIONS
38 SMART FUNCTIONS
38 LG SmartThinQ Application
39 Smart Diagnosis™ Function
40 WARRANTY

4IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
WARNING
For your safety, the information in this manual must be followed to minimize the risk of fire or explosion,
electric shock, or to prevent property damage, injury to persons, or death.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and
obey all safety messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word DANGER, WARNING or CAUTION.
These words mean:
DANGER
You will be killed or seriously injured if you don’t immediately follow instructions.
WARNING
You can be killed or seriously injured if you don’t follow instructions.
CAUTION
You may be slightly injured or cause damage to the product if you do not follow instructions.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury,
and tell you what can happen if the instructions are not followed.
BASIC SAFETY PRECAUTIONS
WARNING
To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precau-
tions, including the following.
• Use this appliance only for its intended purpose as
described in this owner’s Manual.
• Before use, the washer must be properly installed as
described in this manual.
•Do not wash articles that have been previously
cleaned in, washed in, soaked in, or spotted with
gasoline, dry cleaning solvents, or other flammable or
explosive substances, as they give off vapors that
could ignite or explode.
• Do not add gasoline, dry cleaning solvents, or other
flammable or explosive substances to the wash water.
These substances give off vapors that could ignite
or explode.
• Under certain conditions, hydrogen gas may be
produced in a hot water system that has not been
used for 2 weeks or more. HYDROGEN GAS IS
EXPLOSIVE. If the hot water system has not been
used for such a period, before using the washer, turn
on all hot water faucets and let the water flow from
each for several minutes. This will release any accu-
mulated hydrogen gas. As the gas is flammable, do
not smoke or use an open flame during this time.
•Do not allow children or pets to play on, in or with the
appliance. Close supervision is necessary when the
appliance is used near children or pets.
•Before the washer is removed from service or dis-
carded, remove the lid to prevent children from climb-
ing inside.
•Do not install or store the washer where it will be
exposed to the weather or freezing temperatures.
•Do not tamper with controls.
•Keep the area underneath and around your appli-
ances free of combustible materials (lint, paper,
rags, etc.), gasoline, chemicals and other flammable
vapors and liquids.
• Do not repair or replace any part of the washer or
attempt any servicing other than as described in this
manual. We strongly recommend that any service
be performed by a qualified technician.
• See Installation Instructions for grounding require-
ments.
• ALWAYS follow the fabric care instructions supplied
by the garment manufacturer.
• Do not place items exposed to cooking oil in your
washer. Items contaminated with cooking oils may
contribute to a chemical reaction that could cause a
load to catch fire.
• Use fabric softeners or products to eliminate static
only as recommended by the manufacturer.
• This washer is not designed for maritime use or for
mobile installations such as in RVs, aircraft, etc.
• Turn off the water faucets and unplug the washer if
the machine is to be left for an extended period of
time, such as during vacations.
• Do not use to dry articles containing foam rubber or
similarly textured rubber-like materials.
• Packaging material can be dangerous for children.
There is a risk of suffocation! Keep all packaging
from children.
• Always check the inside of the washer for foreign
objects before loading laundry. Keep the lid closed
when not in use.
• Do not reach into the appliance if the tub or agitator is
moving.
•WARNING : This product contains chemicals known
to the State of California to cause cancer and birth
defects or other reproductive harm.
Wash hands
after handling.
86$RQO\

5
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
WARNING
For your safety, the information in this manual must be followed to minimize the risk of fire or explosion,
electric shock, or to prevent property damage, injury to persons, or death.
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of malfunction or breakdown, grounding will reduce the risk
of electric shock by providing a path of least resistance for electric current. This appliance is equipped with
a cord having an equipment-grounding conductor and grounding plug. The plug must be plugged into an
appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances.
WARNING
Improper connection of the equipment-grounding conductor can result in risk of electric shock. Check with a
qualified electrician or servicer if you are in doubt as to whether the appliance is properly grounded. Do not
modify the plug provided with the appliance. If it does not fit the outlet, have a proper outlet installed by a
qualified electrician. Failure to follow these warnings can cause serious injury, fire, electric shock, or death.

6IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
WARNING
For your safety, the information in this manual must be followed to minimize the risk of fire or explosion,
electric shock, or to prevent property damage, injury to persons, or death.
SAFETY INSTRUCTIONS FOR INSTALLATION
WARNING
To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic
precautions, including the following.
• Refer to INSTALLATION INSTRUCTIONS for detailed
grounding procedures. Installation instructions are
packed with the washer for installer’s reference. If
the washer is moved to a new location, have it
checked and reinstalled by a qualified service tech-
nician. Failure to follow this warning can cause
serious injury, fire, electric shock, or death.
• Do not, under any circumstances, cut or remove the
third (ground) prong from the power cord. Failure to
follow this warning can cause serious injury, fire,
electric shock, or death.
• For personal safety, this appliance must be properly
grounded. Failure to follow this warning can cause
serious injury, fire, electric shock, or death.
• The power cord of this appliance is equipped with a
3-prong (grounding) plug which mates with a standard
3-prong (grounding) wall outlet to minimize the pos-
sibility of electric shock from this appliance.
• This washer must be plugged into a 120 VAC, 60 Hz
grounded outlet. Failure to follow this warning can
cause serious injury, fire, electric shock, or death.
• Have the wall outlet and circuit checked by a qualified
electrician to make sure the outlet is properly ground-
ed. Failure to follow this warning can cause serious
injury, fire, electric shock, or death.
• Where a standard 2-prong wall outlet is encountered,
it is your personal responsibility and obligation to have
it replaced with a properly grounded 3-prong wall
outlet. Failure to follow this warning can cause
serious injury, fire, electric shock, or death.
• Do not install on carpet. Install washer on a solid floor.
Failure to follow this warning can cause serious
leak damage.
• Do not remove ground prong. Do not use an adapter
or extension cord. Plug into a grounded 3-prong out-
let. Failure to follow these warnings can cause
serious injury, fire, electric shock, or death.
• The washer should always be plugged into its own
individual electrical outlet which has a voltage rating
that matches the rating plate. This provides the best
performance and also prevents overloading house
wiring circuits which could cause a fire hazard from
overheated wires.
• Never unplug your washer by pulling on the power
cord. Always grip plug firmly and pull straight out
from the outlet. Failure to follow this warning can
cause serious injury, fire, electric shock, or death.
• Repair or immediately replace all power cords that
have become frayed or otherwise damaged. Do not
use a cord that shows cracks or abrasion damage
along its length or at either end. Failure to follow this
warning can cause serious injury, fire, electric
shock, or death.
• When installing or moving the washer, be careful not
to pinch, crush, or damage the power cord. Failure to
follow this warning can cause serious injury, fire,
electric shock, or death.
• The washer must be installed and electrically ground-
ed by a qualified service person in accordance with
local codes to prevent shock hazard and assure
stability during operation.
• The washer is heavy. Two or more people may be
needed to install and move the appliance. Failure to
do so can result in back or other injury.
• Store and install the washer where it will not be ex-
posed to temperatures below freezing or exposed to
outdoor weather conditions. Failure to follow this
warning can cause serious leak damage.
• Do not install the washer in humid spaces to reduce
the risk of electric shock. Failure to follow this warn-
ing can cause serious injury, fire, electric shock, or
death.
• To reduce the risk of injury to persons, adhere to all
industry recommended safety procedures including
the use of long sleeved gloves and safety glasses.
Failure to follow all of the safety warnings in this
manual could result in property damage, injury to
persons or death.

7
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
WARNING
For your safety, the information in this manual must be followed to minimize the risk of fire or explosion,
electric shock, or to prevent property damage, injury to persons, or death.
SAFETY INSTRUCTIONS FOR USE, CARE, CLEANING, AND DISPOSAL
WARNING
To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic
precautions, including the following.
SAVE THESE INSTRUCTIONS
• Unplug the washer before cleaning to avoid the risk
of electric shock.
• Never use harsh chemicals, abrasive cleaners, or
solvents to clean the washer. They will damage the
finish.
• Do not put oily or greasy rags or clothing on top of the
washer. These substances give off vapors that
could ignite the materials.
• Do not wash items that are soiled with vegetable or
cooking oil. These items may contain some oil after
laundering. Due to the remaining oil, the fabric may
smoke or catch fire by itself.
• Disconnect this appliance from the power supply
before attempting any user maintenance. Turning the
controls to the OFF position does not disconnect this
appliance from the power supply. Failure to follow
this warning can cause serious injury, fire, electric
shock, or death.
• Do not combine laundry products for use in one load
unless specified on the label.
• Do not mix chlorine bleach with ammonia or acids
such as vinegar. Follow package directions when
using laundry products. Incorrect usage can produce
poisonous gas, resulting in serious injury or death.
• Do not reach into the washer while parts are moving.
Before loading, unloading, or adding items, press the
START/PAUSE button and allow the drum to coast to a
complete stop before reaching inside. Failure to fol-
low this warning can cause serious injury, fire,
electric shock, or death.
• Do not allow children or pets to play on, in or with the
appliance. Close supervision is necessary when the
appliance is used near children or pets. Failure to
comply with these warnings could result in serious
injury to persons or death.
• Destroy the carton, plastic bag, and other packing
materials after the washer is unpacked. Children
might use them for play. Cartons covered with rugs,
bedspreads, or plastic sheets can become airtight
chambers. Failure to comply with these warnings
could result in serious injury to persons or death.
• Keep laundry products out of children’s reach. To
prevent injury to persons, observe all warnings on
product labels. Failure to comply with these warn-
ings could result in serious injury to persons or
death..
• Remove the door to the washing compartment to
avoid the danger of children or small animals getting
trapped inside before your washer is removed from
service or discarded. Failure to do so can result in
serious injury to persons or death.
• Make sure the dispenser drawer is closed at all times
when not being filled with laundry products. Failure to
keep the drawer closed can result in personal injury
or flooding.

8PRODUCT OVERVIEW
NOTE
yContact LG Customer Service at 1-800-243-0000 (1-888-542-2623 in Canada) if any accessories are missing.
yFor your safety and for extended product life, use only authorized components. The manufacturer is not
responsible for product malfunction or accidents caused by the use of separately purchased unauthorized
components or parts.
yThe images in this guide may be different from the actual components and accessories, and are subject to
change by the manufacturer without prior notice for product improvement purposes.
PRODUCT OVERVIEW
Parts
Pedestal
(sold separately)
Stacking Kit
(sold separately)
Accessories
Non-skid pads Caps for covering
shipping bolt holes
Wrench Tie strap Elbow bracket
(for securing drain hose)
Detergent
dispenser
drawer
(See page 20)
Door
Magnetic Door
Plunger
(see page 2)
Control panel
(See page 9)
Door
seal
Water
circulation
and steam
nozzles
Tub
Leveling
feet
Drain pump filter cover
Drain pump filter
Drain hose
Water inlets
Shipping
bolts Power cord
Drain hose
Included Accessories Optional Accessories
Required Accessory (sold separately)
•Required accessory is sold
separately. It can be ordered
through LG Website.
US: www.lg.com/us
$BOBEBXXXMHDPNHot/cold water hoses
Part Number
• 5215FD3715U : Hot water hose
• 5215FD3715V : Cold water hose

9
ENGLISH
PRODUCT OVERVIEW
Button Description
yTurns the washing machine on and off.
y(During the wash cycle) stops operation, and cancels the settings.
yHeavy Duty
- For heavily soiled cotton fabric
yBulky/Large
- For blankets or large bulky items
yCotton/Normal
- For general laundry, such as cotton T-shirts or towels
yPerm.Press
- For wrinkle-free fabrics
yDelicates
- For sheer and delicate fabrics
yTowels
- For towels
ySpeed Wash
- For small quantities of lightly soiled items
yDownloaded
- This position is for downloadable cycles. The default cycle in this position is Small
Load. (see page 38)
yTub Clean
- For tub clean (see page 30)
yStarts or pauses the washing machine cycle.
- If you do not press the Cbutton within 60 minutes of selecting a cycle, the washing
machine will turn off automatically.
y(Press repeatedly) Selects the water temperature for the wash cycle (see page 25).
- Select water temperature from 5 settings.
y(Press repeatedly) Selects the spin speed in the desired level (see page 25).
- Selects spin speed from 5 settings.
y(Press repeatedly) Selects a wash cycle by soil level (see page 25).
- Selects soil level from 5 settings.
y(Press repeatedly) Adjust the volume of the melody and button tones
(see page 26).
Control Panel Features
Operation
Operation Display
Cycle selector
Soil
Level
Selection
Button
Signal
Sound
Selection
Button
Spin
Speed
Selection
Button
Water
Temperature
Selection
Button
Start/
Pause
Button
Power
Button

10 PRODUCT OVERVIEW
Display
Operation (continued)
Button Description
yPre-wash heavily soiled laundry (See page. 26).
y(Press and hold during wash cycle) Lock/unlock the button (See page. 27).
yUse this option to add extra water to the wash and rinse cycles for better wash and
rinse performance (Stain Treatment) with large or bulky items (See page. 27).
y(Press before wash cycle) Add an extra rinse to the selected cycle (See page. 26).
y(Press before wash cycle) Use this option to rinse detergent from load (See page. 26).
ySet delay time of starting cycle (See page. 26).
yTumbles clothes to prevent wrinkle (See page. 28).
yUse this option to consume less energy (See page. 27).
yUse this function to add garments or remove foreign objects like coins or keys after the
cycle has started (See page. 28).
Display Icon Description
yThis portion of the display shows which stage of the wash cycle is currently
underway (Load Sensing, Wash, Rinse or Spin).
yIndicates that the door is locked. The washer door will lock while the washer is operating.
The door can be unlocked by pressing the Start/ Pause button to stop the washer.
yThis indicator shows that the washer has been set for Delay Wash. The washer
will start automatically after the set delay time has passed.
yWhen the Start/Pause button is pressed, the washer automatically detects the wash load
(weight) and optimizes the washing time, based on the selected cycle and options. The
display will then indicate the estimated time remaining for the selected wash cycle.
Door lock
indicator
Estimated time remaining/
error message display
(See page 35)
Cycle
process
indicator
Delay
wash
indicator

11
ENGLISH
INSTALLATION
INSTALLATION
Installation Overview
WARNING
yWasher is heavy! Two or more people are required when moving and unpacking the washer. Failure to do so
can result in back or other injury.
yStore and install the washer where it will not be exposed to temperatures below freezing or exposed to
outdoor weather conditions. Failure to follow this warning can cause serious injury, fire, electric shock, or
death.
yProperly ground washer to conform with all governing codes and ordinances. Failure to follow this warning
can cause serious injury, fire, electric shock, or death.
yTo reduce the risk of electric shock, do not install the washer in humid spaces. Failure to follow this warning
can cause serious injury, fire, electric shock, or death.
yThe base opening must not be obstructed by carpeting when the washer is installed on a carpeted floor.
yDo not remove ground prong. Do not use an adapter or extension cord. Plug into a grounded 3-prong outlet.
Failure to follow this warning can cause serious injury, fire, electric shock, or death.
Choosing the proper
location
Unpacking and
removing shipping bolts
Connecting the water line
Connecting the drain line Leveling the washer Connecting to the power
supply
Testing the washer

12 INSTALLATION
Choosing the Proper Location
Install the washing machine on a solid floor that is
strong and rigid enough to support the weight of the
washing machine, even when fully loaded, without
flexing or bouncing. If the floor has too much flex,
you may need to reinforce it to make it more rigid. If
the floor is not solid, it may cause severe vibration
and noise.
1Clean the floor before installation.
- Make sure to select solid and smooth ground.
2Two or more people are needed for moving and
unpacking the washing machine.
3Allow for sufficient space between the walls and
the washing machine for installation.
Space Requirements
You must allow sufficient space for water lines, the
drain line, and airflow.
NOTE
Be sure to allow for wall, door, or floor moldings
that may increase the required clearances.
Clearances
NOTE
The floor must be strong and rigid enough to
support the weight of the washer, when fully
loaded, without flexing or bouncing. If your
floor has too much flex, you may need to
reinforce it to make it more rigid. A floor that is
adequate for a top-loading washer may not be
rigid enough for a front loading washer, due to
the difference in the spin speed and direction.
If the floor is not solid, your washer may
vibrate and you may hear and feel the vibration
throughout your house.
Before installing the washer, make sure the
floor is clean, dry and free of dust, dirt, water
and oils so the washer feet can not slide easily.
Leveling feet that can move or slide on the floor
can contribute to excess vibration and noise
due to poor contact with the floor.
If a drip pan must be used, take extra care
to follow the instructions provided with the
drip pan and make sure the leveling feet are
adjusted for firm and even contact with the pan.
Use of drip pans and failure to properly level
the machine may result in increased vibration
and noise during operation.
Installing on a Pedestal or Stacking Kit
NOTE
Refer to the instructions packaged with the
optional PEDESTAL or STACKING KIT before
installing with a PEDESTAL or a STACKING KIT.

13
ENGLISH
INSTALLATION
1Starting with the bottom two shipping bolts,
use the wrench (included) to fully loosen all four
shipping bolts by turning them counterclockwise.
Remove the bolt assemblies by wiggling them
slightly while pulling them out.
Shipping
bolt
Retainer
2Locate the four hole caps included in the
accessory pack and install them in the shipping
bolt holes.
Cap
NOTE
ySave the bolt assemblies for future use. To
prevent damage to internal components, DO
NOT transport the washer without reinstalling
the shipping bolts.
yFailure to remove shipping bolts and retainers
may cause severe vibration and noise, which
can lead to permanent damage to the washer.
The cord is secured to the back of the washer
with a shipping bolt to help prevent operation
with shipping bolts in place.
Unpacking and Removing Shipping Bolts
When removing the washer from the carton base, be
sure to remove the foam drum support in the middle of
the carton base.
If you must lay the washer down to remove the base
packaging materials, always lay it carefully on its
side.
Do NOT lay the washer on its front or back.

14 INSTALLATION
Connecting the Water Lines
1Check the rubber seals on both sides of the hose.
- Insert a rubber seal into the threaded fittings on
each hose to prevent leaking.
Rubber seal
Water hose
(To water inlet on the
washing machine)
Rubber seal
Water hose
(To faucet)
2Connect the water supply hoses to the HOT and
COLD water faucets tightly by hand and then
tighten another 2/3 turn with pliers.
- Connect the blue hose to a cold water faucet and
the red hose to a hot water faucet.
WARNING
yDo not overtighten. Damage to the coupling can
result.
3After connecting inlet hose to water faucets,
turn on the water faucets to flush out foreign
substances (dirt, sand or sawdust) in the water
lines. Let water drain into a bucket, and check the
water temperature.
4Connect the hoses to the water inlets tightly
by hand and then tighten another 2/3 turn with
pliers.
- Connect the blue hose to the cold water inlet
and the red hose to the hot water inlet.
Cold
water
inlet
Hot water
inlet
WARNING
yDo not overtighten the hoses. Overtightening
can damage the valves resulting in leaking and
property damage.
5Check for leaks by turning on the faucets.
- If water leaks, check steps 1 to 4 again.
NOTE
yFor your safety, and for extended product
life, use only authorized components. The
manufacturer is not responsible for product
malfunction or accidents caused by the use
of separately purchased, unauthorized parts.
yUse new hoses when you install the washing
machine. Do not reuse old hoses. LG does
not recommend the use of aftermarket
hoses.
yPeriodically check the hoses for cracks, leaks
and wear, and replace the hoses every five
years.
yDo not stretch the water hoses intentionally,
and make sure that they are not crushed by
other objects.
yWater supply pressure must be between 20
psi and 120 psi (138–827 kPa). If the water
supply pressure is more than 120 psi, a
pressure reducing valve must be installed.
yTo provide optimum washing performance
the hot water temperature should be set
at 120-135°F (48-57°C) and the cold at 60°F
(15°C).

15
ENGLISH
INSTALLATION
Connecting the Drain Line
Secure the drain hose in place to prevent moving
and leaking.
NOTE
yThe drain hose should be properly secured.
Failure to properly secure the drain hose can
result in flooding and malfunction.
yThe end of the drain hose should not be less
than 29 inches (73.7 cm) or more than 96 inches
(243.8 cm) from the bottom of the washer.
yThe drain must be installed in accordance with
any applicable local codes and regulations.
yMake sure that the water lines are not stretched,
pinched, crushed, or kinked.
Using a Standpipe
1Clip the end of the hose into the elbow bracket.
- Connect the elbow bracket within 4 inches (10
cm) from the end of the drain hose. If the drain
hose is extended more than 4 inches (10 cm)
beyond the end of the elbow bracket, mold or
microorganisms could spread to the inside of
the washer.
No more than
4 inches (10 cm)
Elbow bracket
2Insert the end of the drain hose into the standpipe.
Drain Hose
Elbow Bracket
3Use a tie strap to secure the drain hose in place.
Using a Laundry Tub
1Clip the end of the hose into the elbow bracket.
- Connect the elbow bracket within 4 inches (10
cm) from the end of the drain hose. If the drain
hose is extended more than 4 inches (10 cm)
beyond the end of the elbow bracket, mold, or
microorganisms could spread to the inside of
the washer.
No more than
4 inches (10 cm)
Elbow bracket
2Hang the end of the drain hose over the side of
the laundry tub.
Elbow Bracket
Drain Hose
3Use a tie strap to secure the drain hose in place.

16 INSTALLATION
Leveling the Washer
The washer tub of your new washing machine
spins at very high speeds. To minimize vibration,
noise, and unwanted movement, the floor must be
perfectly level and solid.
1Check that the washer is level.
- Rock the top edges of the washing machine or
place a level on the washing machine. The slope
beneath the washing machine must not exceed
1°, and all four leveling feet must rest firmly on
the floor. Level
1°
2Turn the lower leveling feet clockwise to level the
washing machine.
- Turning the lower leveling feet clockwise raises
the washing machine.
Raise
3Turn the locknuts counterclockwise and tighten
them when the washing machine is level.
Tighten all 4 lock
nuts securely using
the wrench.
4Check again that the washer is level.
- Push or rock the top edges of the washing
machine gently to make sure that the washing
machine does not rock.
- If the washing machine rocks, repeat steps 1 to 3.
WARNING
yUsing the washing machine without leveling,
it may result in malfunction caused by the
production of excess vibration and noise.
yIf you are installing the washing machine on the
optional pedestal, you must adjust the leveling
feet on the pedestal to level the washing
machine. The washing machine´s leveling feet
should be minimized and turn the locknuts
counterclockwise to secure.
yUse the leveling feet only when you level the
washing machine. If you raise the leveling feet
unnecessarily, it may cause abnormal vibration
of the washing machine.
Using Non-Skid Pads (Optional)
If you install the washing machine on a slippery
surface, it may move because of excessive vibration.
Incorrect leveling may cause malfunction through
noise and vibration. In the event of this, lay the non-
skid pads under the leveling feet and adjust the level.
1Clean the floor to attach the non-skid pads.
- Use a dry rag to remove and clean foreign
objects or moisture. If moisture remains, the
non-skid pads may slip.
2Level the washer after placing it in the installation
area.
3Place the adhesive side of the non-skid pad on the
floor.
- It is most effective to install the non-skid pads
under the front legs. If it is hard to place the pads
under the front legs, place them under the back
legs.
Remove
backing
This side up
Adhesive
side
4Check again that the washer is level.
- Push or rock the top edges of the washing
machine gently to make sure that the washing
machine does not rock. If the washing machine
rocks, level the washing machine again.

17
ENGLISH
INSTALLATION
Connecting to the Power Supply
Make sure to ground the washing machine to
prevent a short circuit or an electric shock when
plugging in.
Using a 3-Prong Outlet
Plug in the electrical outlet without additional
grounding.
WARNING
yThe power outlet must be within 60 inches (1.5 m) of
either side of the washer.
yThe appliance and outlet must be positioned so that the
plug is easily accessible.
yDo not overload the outlet with more than one
appliance.
yThe outlet must be grounded in accordance with
current wiring codes and regulations.
yTime-delay fuse or circuit breaker is recommended.
yIt is the personal responsibility and obligation of the
product owner to have a proper outlet installed by a
qualified electrician.
yDo not use a worn or damaged power cord or power
plug. Replace or repair it immediately. Failure to
do so may result in death, fire, electric shock, or
malfunction.
yDo not modify the power cord and take care not to
damage it when installing or moving the washing
machine. Failure to do so may result in death, fire,
electric shock, or malfunction.
yMake sure that the washing machine is grounded.
yConnect this washing machine to a grounded outlet
conforming to the rating prior to use. Failure to do so
may result in fire, electric shock, or malfunction.
yDo not use adaptors or extension cords. The washing
machine should always be plugged into its own
individual electrical outlet which has a voltage rating
that matches the rating plate. Failure to do so may
result in fire, electric shock or disorder.
yDo not damage or cut off the ground prong of the
power cord. Doing so may cause death, fire, electric
shock, or product malfunction.
Testing the Washer
Check if the washing machine is properly installed
and run a test cycle.
1Load the washing machine with 6 pounds of
laundry.
2Press Aand turn Bto the right.
3Press to Rinse + Spin.
4Press C.
- The wash cycle starts.
5Check if water is supplied, that the washing
machine does not rock or vibrate excessively, and
that it drains well during the spin cycle.
- If water leaks during water supply, see page
14, Connecting the Water Lines to connect them
properly.
- If the washing machine rocks and vibrates
excessively, see page 16, Leveling the Washer to
level it again.
- If the drain does not work, see page 15,
Connecting the Drain Line to install it properly.

18 PREPARATION
Check all pockets to make sure that they are
empty.
- Items such as clips, matches, pens, coins, and
keys can damage both the washer and your
clothes.
Close zippers, hooks, and drawstrings to prevent
these items from snagging or tangling on other
clothes.
Pretreat heavily stained areas before washing.
- Doing so will produce clean, stain-free results.
Combine large and small items in a load. Load
large items first.
Large items should not be more than half of the
total washload.
The washer can be fully loaded, but the drum
should not be tightly packed with items.
-The door of the washer should close easily.
Do not wash single items, except for bulky items
such as blankets. Make sure to wash laundry in
similar types of loads.
- Washing a single small item may result in the tub
becoming unbalanced, vibrating and making a
noise.
Do not wash waterproof clothes.
- This may cause abnormal vibration, or may
cause the load to bounce, which could damage
the tub.
Check if there are any other foreign objects in the
door seal and take extra care that clothes do not
get caught there.
- Foreign objects in the door seal may stain
clothes, and water may leak if clothes get caught
in the door seal.
Wash underwear or small, light items in a laundry
net.
- Small, light items may get caught in the door
seal, and a brassiere hook may damage other
items or the tub.
Brush heavy soil, dust, or hair off fabrics before
washing.
- Laundry may not wash clean if there is dirt or
sand on the fabrics, or particles may rub against
and damage sheer fabrics.
Wash blankets individually.
- Washing more than one blanket together may
produce unsatisfactory results due to tangling or
an unbalanced load.
Always separate fabrics according to their colors
and wash them separately to prevent colors from
running.
- Fabrics may damage or become stained due to
fabric dyes running, or due to foreign objects
transferring from one fabric to another.
For best performance, load clothes as shown.
1
3
2
4
- Load clothes loosely, and do not overfill the
drum. Clothes need room to circulate in order
to get clean.
- Do not press down on items while stacking
them in the drum.
PREPARATION
Sorting Wash Loads
Read and observe the following to prevent shrinkage or damage to clothes.

19
ENGLISH
PREPARATION
Category Label Directions
Washing
Hand Wash
Machine Wash, Normal Cycle
Use Permanent Press/Wrinkle
Resistant washing machine
setting (which has a cool
down or cold spray before the
slower spin)
Use Gentle/Delicate washing
machine setting (slow
agitation and/ or reduced
wash time).
Do Not Wash
Do Not Wring
Water Temperature
Hot
Warm
Cold/Cool
Bleach symbols
Any Bleach (When Needed)
Only Non-Chlorine Bleach
(When Needed)
Do Not Bleach
Colors Whites / Lights / Darks
Soil Heavy / Normal / Light
Fabric Delicates / Easy Care / Sturdy Cottons
Lint Lint Producers / Lint Collectors
Fabric Care Labels
Most articles of clothing feature fabric care labels
that include instructions for proper care.
Sorting Laundry
It is recommended that you sort laundry into similar
loads that are washable in the same cycle.
Refer to the following chart for sorting clothes

20 PREPARATION
Loading the Dispenser
The detergent dispenser drawer of the washing
machine has a dispenser compartment for each
detergent type. Add each detergent to its appropriate
compartment.
1Pull out the detergent dispenser drawer.
2Add the appropriate detergent to its appropriate
compartment.
- If you use a liquid detergent, check if the liquid
detergent cup is in place.
- If you use a powdered detergent, remove the
liquid detergent cup and put the powder in the
main wash detergent compartment.
Liquid chlorine
bleach
compartment
Liquid
detergent
cup
Main wash
detergent
compartment
Pre-wash
detergent
compartment
Liquid fabric
softener
compartment
3Close the detergent dispenser drawer slowly.
- Slamming the detergent dispenser drawer may
result in the detergent overflowing into another
compartment or pouring into the tub earlier than
programmed.
NOTE
yIt is normal for a small amount of water to
remain in the dispenser compartments at the
end of the cycle.
Using Detergent/Fabric Softener
Recommended Detergent
Make sure to use HE (High-Efficiency) detergent
for front-loading washing machines. HE detergents
dissolve more efficiently and produce fewer suds to
ensure efficient washing and rinsing. Use the correct
amount of detergent as indicated on the label of the
detergent packaging.
Designed specially to use only
HE (High-Efficiency) detergent
NOTE
yOnly use HE detergents, because using a
regular detergent may produce excessive suds.
yHE detergents produce fewer suds, dissolve
more efficiently to improve washing and rinsing
performance, and help to keep the interior of
the washer clean.
yUse less detergent for soft water.
yWipe up any spills immediately, as liquids could
damage the finish and the control panel of the
washing machine.
yUsing too much detergent can cause a build-
up in the tub resulting in unsatisfactory
performance and machine malfunction.
yIf you use a detergent that does not dissolve
easily or a detergent with high viscosity, it will
leave a residue on the tub, which may not rinse
properly.
