LG WM3250H User manual

OWNER’S MANUAL
WASHING MACHINE
WM3250H*A
Please read this owner’s manual thoroughly before operating and keep it handy for
reference at all times.
P/No.: MFL67737641 www.lg.com
ENGLISH
FRANÇAIS

2TABLE OF CONTENTS
TABLE OF CONTENTS
3 PRODUCT FEATURES
4 IMPORTANT SAFETY INSTRUCTIONS
4 BASIC SAFETY PRECAUTIONS
5 GROUNDING INSTRUCTIONS
6 SAFETY INSTRUCTIONS FOR INSTALLATION
7 SAFETY INSTRUCTIONS FOR USE, CARE,
CLEANING, AND DISPOSAL
8 INTRODUCING YOUR WASHING MACHINE
8 Parts and Accessories
9Control Panel Features
11 INSTALLATION INSTRUCTIONS
11 Preview Installation Order
12 Checking and Choosing the Proper Location
13 Unpacking and Removing Shipping Bolts
14 Connecting the Water Lines
15 Connecting the Drain Line
16 Leveling the Washing Machine
17 Plugging in the Power Cord and Grounding
17 Test Run
18 PREPARATION
18 Sorting Wash Loads
18 - Precautions for fabric care before wash cycle
19 - Fabric care labels
19 - Sorting laundry
20 Using detergent/fabric softener
20 - Recommended detergent
20 - Loading the dispenser
22 USING YOUR WASHING MACHINE
22 Basic operation
23 Cycle guide
24 Main cycle
24 - Reduce laundry allergen, Allergiene™
24 - Reduce bacteria on laundry, Sanitary
24 - Blankets or bulky items, Bulky/Large
24 - Normal items, Cotton/Normal
24 - Wrinkle free items, Perm. Press
24 - Sheer items, Delicates
24 - Items labeled wool or hand-washable, Hand Wash/
Wool
24 - Quick wash, Speed Wash
25 Cycle Modifier buttons
25 Setting options before cycle
25 - Setting the water temperature, Wash Temp
25 - Setting spin speed, Spin Speed
25 - Setting soil level of laundry, Soil Level
26 - Prewashing, Pre-Wash
26 - Rinse, drain and spin only, Rinse + Spin
26 - Adding an extra rinse cycle, Extra Rinse
26 - Adding extra water to the wash and rinse cycles,
Water Plus
26 - Presetting the start time, Delay Wash
26 - Efficiency cleaning, Steam
27 - Saving energy, ColdWash™
27 - Turning on/off melody and button tones, Signal
On/Off
27 Setting options during cycle
27 - Button lock feature, Child Lock
28 MAINTENANCE
28 Care
28 - Care after wash
28 - Care in cold climates
29 Cleaning
29 - Cleaning the drum, Tub Clean
30 - Cleaning the detergent dispenser drawer
31 - Cleaning the water inlet filters
32 - Cleaning the drain pump filter
33 - Cleaning the door seal
34 TROUBLESHOOTING
34 Checking error messages
35 Before calling for service
36 SPECIFICATIONS
37 USING SMART DIAGNOSIS™
38 WARRANTY

3
ENGLISH
PRODUCT FEATURES
PRODUCT FEATURES
INVERTER DIRECT-DRIVE MOTOR
The inverter direct drive motor, which is directly attached to the drum, is capable of producing multiple distinct different motions
for optimal washing performance with very little noise and vibration. The motor assembly also contains fewer moving parts,
thus resulting in fewer repairs.
SMART DIAGNOSIS™
Should you experience any technical difficulty with your washing machine, it has the capability of transmitting data by phone to
the Customer Information Center. The call center agent records the data transmitted from your machine and uses it to analyze
the issue, providing a fast and effective diagnosis (Refer to page 37).
TUB CLEAN
Regular cleaning of the tub on a monthly basis using Tub Clean can help keep the tub clean and fresh.
MAGNETIC DOOR PLUNGER
Safely and conveniently secure the door slightly ajar with the magnetic door plunger. This will promote air circulation and allow
the interior of the machine to dry. To use this feature, after the load has been removed, do not close the door completely.
When the magnetic door plunger comes into contact with the metal washer cabinet, it will secure the door slightly open
allowing the interior of the washer to dry.
LARGE CAPACITY STAINLESS STEEL DRUM
The large capacity stainless steel drum offers extreme durability and is tilted to improve efficiency and allow easier access for
large items.
CHILD LOCK
Use this option to disable the controls during a wash cycle. This option can prevent children from changing cycles or operating
the machine. It can also be used to disable controls for cleaning purposes.
DETERGENT DISPENSER DRAWER
The four-compartment dispenser drawer makes it easy to separate the pre-wash detergent, the main laundry detergent, liquid
bleach, and fabric softener into different compartments.
HIGH-EFFICIENCY STEAM CYCLES
During LG's unique high-efficiency Steam cycle, the hot steam gently removes tough stains.

4IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
WARNING
For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to
prevent property damage, injury to persons, or death.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word DANGER, WARNING or CAUTION.
These words mean:
DANGER
You will be killed or seriously injured if you don’t immediately follow instructions.
WARNING
You can be killed or seriously injured if you don’t follow instructions.
CAUTION
You may be slightly injured or cause damage to the product if you do not follow instructions.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
BASIC SAFETY PRECAUTIONS
WARNING
To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions, including the
following :
• Use this appliance only for its intended purpose as described
in this owner’s manual.
• Before use, the washer must be properly installed as
described in this manual.
•Do not wash articles that have been previously cleaned in,
washed in, soaked in, or spotted with gasoline, dry cleaning
solvents, or other flammable or explosive substances, as
they give off vapors that could ignite or explode.
• Do not add gasoline, dry cleaning solvents, or other
flammable or explosive substances to the wash water.
These substances give off vapors that could ignite or
explode.
• Under certain conditions, hydrogen gas may be produced in a
hot water system that has not been used for 2 weeks or
more. HYDROGEN GAS IS EXPLOSIVE. If the hot water
system has not been used for such a period, before using
the washer, turn on all hot water faucets and let the water
flow from each for several minutes. This will release any
accumulated hydrogen gas. As the gas is flammable, do not
smoke or use an open flame during this time.
•Do not allow children to play on or in the washer. Close
supervision of children is necessary when the washer is
used near children.
•Before the washer is removed from service or discarded,
remove the lid to prevent children from climbing inside.
•Do not install or store the washer where it will be exposed
to the weather or freezing temperatures.
•Do not tamper with controls.
•Keep the area underneath and around your appliances free of
combustible materials (lint, paper, rags, etc.), gasoline,
chemicals and other flammable vapors and liquids.
• Do not repair or replace any part of the washer or attempt
any servicing other than as described in this manual. We
strongly recommend that any service be performed by a
qualified technician.
• See Installation Instructions for grounding requirements.
• ALWAYS follow the fabric care instructions supplied by the
garment manufacturer.
• Do not place items exposed to cooking oil in your washer.
Items contaminated with cooking oils may contribute to a
chemical reaction that could cause a load to catch fire.
• Use fabric softeners or products to eliminate static only as
recommended by the manufacturer.
• This washer is not designed for maritime use or for mobile
installations such as in RVs, aircraft, etc.
• Turn off the water faucets and unplug the washer if the
machine is to be left for an extended period of time, such as
during vacations.
• Packaging material can be dangerous for children. There is a
risk of suffocation! Keep all packaging from children.
• Always check the inside of the washer for foreign objects
before loading laundry. Keep the lid closed when not in use.
• Do not reach into the appliance if the tub or agitator is
moving.
• WARNING : This product contains chemicals known to the
State of California to cause cancer and birth defects or other
reproductive harm. Wash hands after handling.

5
IMPORTANT SAFETY INSTRUCTIONS
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
WARNING
For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to
prevent property damage, injury to persons, or death.
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of malfunction or breakdown, grounding will reduce the risk of electric shock by
providing a path of least resistance for electric current. This appliance is equipped with a cord having an equipment-grounding
conductor and grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
WARNING
Improper connection of the equipment-grounding conductor can result in risk of electric shock. Check with a qualified electrician
or servicer if you are in doubt as to whether the appliance is properly grounded. Do not modify the plug provided with the
appliance. If it does not fit the outlet, have a proper outlet installed by a qualified electrician. Failure to follow these warnings can
cause serious injury, fire, electric shock, or death.

6IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
WARNING
For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to
prevent property damage, injury to persons, or death.
SAFETY INSTRUCTIONS FOR INSTALLATION
WARNING
To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions, including the
following :
• Refer to INSTALLATION INSTRUCTIONS for detailed
grounding procedures. Installation instructions are packed
with the washer for installer’s reference. If the washer is
moved to a new location, have it checked and reinstalled by
a qualified service technician. Failure to follow this warning
can cause serious injury, fire, electric shock, or death.
• Do not, under any circumstances, cut or remove the third
(ground) prong from the power cord. Failure to follow this
warning can cause serious injury, fire, electric shock, or
death.
• For personal safety, this appliance must be properly
grounded. Failure to follow this warning can cause serious
injury, fire, electric shock, or death.
• The power cord of this appliance is equipped with a 3-prong
(grounding) plug which mates with a standard 3-prong
(grounding) wall outlet to minimize the possibility of electric
shock from this appliance.
• This washer must be plugged into a 120 VAC, 60 Hz
grounded outlet. Failure to follow this warning can cause
serious injury, fire, electric shock, or death.
• Have the wall outlet and circuit checked by a qualified
electrician to make sure the outlet is properly grounded.
Failure to follow this warning can cause serious injury, fire,
electric shock, or death.
• Where a standard 2-prong wall outlet is encountered, it is
your personal responsibility and obligation to have it
replaced with a properly grounded 3-prong wall outlet.
Failure to follow this warning can cause serious injury, fire,
electric shock, or death.
• Do not install on carpet. Install washer on a solid floor.
Failure to follow this warning can cause serious leak damage.
• Do not remove ground prong. Do not use an adapter or
extension cord. Plug into a grounded 3-prong outlet. Failure
to follow these warnings can cause serious injury, fire,
electric shock, or death.
• The washer should always be plugged into its own individual
electrical outlet which has a voltage rating that matches the
rating plate. This provides the best performance and also
prevents overloading house wiring circuits which could cause
a fire hazard from overheated wires.
• Never unplug your washer by pulling on the power cord.
Always grip plug firmly and pull straight out from the outlet.
Failure to follow this warning can cause serious injury, fire,
electric shock, or death.
• Repair or immediately replace all power cords that have
become frayed or otherwise damaged. Do not use a cord
that shows cracks or abrasion damage along its length or at
either end. Failure to follow this warning can cause serious
injury, fire, electric shock, or death.
• When installing or moving the washer, be careful not to
pinch, crush, or damage the power cord. Failure to follow
this warning can cause serious injury, fire, electric shock, or
death.
• The washer must be installed and electrically grounded by a
qualified service person in accordance with local codes to
prevent shock hazard and assure stability during operation.
• The washer is heavy. Two or more people may be needed
to install and move the appliance. Failure to do so can result
in back or other injury.
• Store and install the washer where it will not be exposed to
temperatures below freezing or exposed to outdoor
weather conditions. Failure to follow this warning can cause
serious leak damage.
• To reduce the risk of electric shock, do not install the
washer in humid spaces. Failure to follow this warning can
cause serious injury, fire, electric shock, or death.
• To reduce the risk of injury to persons, adhere to all
industry recommended safety procedures including the use
of long sleeved gloves and safety glasses. Failure to follow
all of the safety warnings in this manual could result in
property damage, injury to persons or death.

7
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
WARNING
For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to
prevent property damage, injury to persons, or death.
SAFETY INSTRUCTIONS FOR USE, CARE, CLEANING, AND DISPOSAL
WARNING
To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions, including the
following :
SAVE THESE INSTRUCTIONS
• Unplug the washer before cleaning to avoid the risk of
electric shock.
• Never use harsh chemicals, abrasive cleaners, or solvents
to clean the washer. They will damage the finish.
• Do not put oily or greasy rags or clothing on top of the
washer. These substances give off vapors that could ignite
the materials.
• Do not wash items that are soiled with vegetable or cooking
oil. These items may contain some oil after laundering. Due
to the remaining oil, the fabric may smoke or catch fire by
itself.
• Disconnect this appliance from the power supply before
attempting any user maintenance. Turning the controls to
the OFF position does not disconnect this appliance from the
power supply. Failure to follow this warning can cause
serious injury, fire, electric shock, or death.
• Do not combine laundry products for use in one load unless
specified on the label.
• Do not mix chlorine bleach with ammonia or acids such as
vinegar. Follow package directions when using laundry
products. Incorrect usage can produce poisonous gas,
resulting in serious injury or death.
• Do not reach into the washer while parts are moving.
Before loading, unloading, or adding items, press the
START/PAUSE button and allow the drum to coast to a
complete stop before reaching inside. Failure to follow this
warning can cause serious injury, fire, electric shock, or
death.
• Do not allow children to play on or in the washer. Close
supervision of children is necessary when the washer is
used near children. As children grow, teach them the
proper, safe use of all appliances. Failure to comply with
these warnings could result in serious injury to persons or
death.
• Destroy the carton, plastic bag, and other packing materials
after the washer is unpacked. Children might use them for
play. Cartons covered with rugs, bedspreads, or plastic
sheets can become airtight chambers. Failure to comply
with these warnings could result in serious injury to persons
or death.
• Keep laundry products out of children’s reach. To prevent
injury to persons, observe all warnings on product labels.
Failure to comply with these warnings could result in serious
injury to persons or death..
• Before your washer is removed from service or discarded,
remove the door to the washing compartment to avoid the
danger of children or small animals getting trapped inside
before your washer is removed from service or discarded.
Failure to do so can result in serious injury to persons or
death.
• Make sure the dispenser drawer is closed at all times when
not being filled with laundry products. Failure to keep the
drawer closed can result in personal injury or flooding.

8INTRODUCING YOUR WASHING MACHINE
NOTE
yContact LG Customer Service at 1-800-243-0000 (1-888-542-2623 in Canada) if any accessories are missing.
yFor your safety and for extended product life, use only authorized components. The manufacturer is not responsible for
product malfunction or accidents caused by the use of separately purchased unauthorized components or parts.
yThe images in this guide may be different from the actual components and accessories, and are subject to change by the
manufacturer without prior notice for product improvement purposes.
INTRODUCING YOUR WASHING MACHINE
Parts and Accessories
Parts
Pedestal Stacking kit
Accessories
14" Pedestal Color
WDP4C Chardonnay
WDP4R Wild Cherry Red
WDP4S Titanium
WDP4V Graphite Steel
WDP4W White
WDP4N Midnight Blue
Stacking Kit Color
CSTK1 Chardonnay
RSTK1 Wild Cherry Red
SSTK1 Titanium
GSTK1 Pearl Gray
WSTK1 White
NSTK1 Midnight Blue
Hot/cold water hoses Non-skid pads Caps for covering
shipping bolt holes
Wrench Tie strap Elbow bracket
(for securing drain hose)
Detergent
dispenser
drawer
(See page 20)
Door
Magnetic door
plunger
(See page 3)
Control panel
(See page 9)
Door
seal
Tub
Leveling
feet
Drain pump filter cover
Drain pump filter
Drain hose
Water inlets
Shipping
bolts Power cord
Drain hose
Included Accessories OptIOnal Accessories

9
INTRODUCING YOUR WASHING MACHINE
ENGLISH
Button Description
yTurns the washing machine on and off.
y(During the wash cycle) stops operation, and cancels the settings.
yAllergiene™
- For cotton, underwear (see page 24)
ySanitary
- For underwear, diaper etc. (see page 24)
yBulky/Large
- For blankets or large bulky items (see page 24)
yCotton/Normal
- For general laundry, such as cotton T-shirts or towels (see page 24)
yPerm. Press
- For wrinkle-free fabrics (see page 24)
yDelicates
- For sheer and delicate fabrics (see page 24)
yHand Wash/Wool
- For wool or hand-wash fabrics (see page 24)
ySpeed Wash
- For small quantities of lightly soiled items (see page 24)
yTub Clean
- (Press and hold) For cleaning the wash tub (see page 29)
yStarts or pauses the washing machine cycle.
- If you do not press the Cbutton within 4 minutes of selecting a cycle, the washing machine will
turn off automatically.
y(Press repeatedly) Selects the water temperature for the wash cycle (see page 25).
- Select water temperature from five settings.
y(Press repeatedly) Selects the spin speed in the desired level (see page 25).
- Selects spin speed from five settings.
y(Press repeatedly) Selects a wash cycle by soil level (see page 25).
- Selects soil level from five settings.
Control Panel Features
Operation
Operation Display
Cycle selector
Soil
Level
Selection
Button
Spin
Speed
Selection
Button
Water
Temperature
Selection
Button
Start/
Pause
Button
Power
Button

10 INTRODUCING YOUR WASHING MACHINE
Display
Operation (continued)
Button Description
y(Press before wash cycle) For pre-washing heavily soiled laundry (see page. 26).
y(Press and hold during wash cycle) To lock/unlock the buttons (see page. 27).
yRinse + Spin
For items that only require rinsing and spinning (see page 26).
y(Press before wash cycle) To add an extra rinse cycle to the selected cycle (see page. 26).
y(Press before wash cycle) To add water during wash and rinse cycle (see page. 26).
y(Press and hold) To turn on/off melody and button tones (see page. 27).
yTo set a delayed start time for the cycle (see page. 26).
yUse this option for heavily soiled loads that need improved stain treatment (see page. 26).
yUse this option to reduce your energy consumption (see page. 27).
Button Description
yAt the beginning of the cycle, the washer tumbles the load and detects the weight of the clothes.
The display will indicate the approximate load size in the LOAD SIZE display. This allows you to
adjust the amount of detergent and other additives for best results and improved efficiency.
yThis portion of the display shows which stage of the wash cycle is currently underway (LOAD
SENSING, WASH, RINSE or SPIN).
yIndicates that the door is locked. The washer door will lock while the washer is operating. The door
can be unlocked by pressing the START/ PAUSE button to stop the washer.
yThis indicator shows that the washer has been set for Delay Wash. The washer will start
automatically after the set delay time has passed.
yWhen the START/PAUSE button is pressed, the washer automatically detects the wash load (weight)
and optimizes the washing time, based on the selected cycle and options. The display will then
indicate the estimated time remaining for the selected wash cycle.
Door lock
indicator
Load size sensing indicator
(See page. 27)
Estimated time remaining/
error message display
(See page 34)
Cycle
process
indicator
Delay
wash
indicator

11
INSTALLATION INSTRUCTIONS
ENGLISH
INSTALLATION INSTRUCTIONS
Preview Installation Order
WARNING
yWasher is heavy! Two or more people are required when moving and unpacking the washer. Failure to follow this warning
can result in back or other injury.
yStore and install the washer where it will not be exposed to temperatures below freezing or exposed to outdoor weather
conditions. Failure to follow this warning can cause serious injury, fire, electric shock, or death.
yProperly ground washer to conform with all governing codes and ordinances. Failure to follow this warning can cause
serious injury, fire, electric shock, or death.
yTo reduce the risk of electric shock, do not install the washer in humid spaces. Failure to follow this warning can cause
serious injury, fire, electric shock, or death.
yThe base opening must not be obstructed by carpeting when the washer is installed on a carpeted floor.
yDo not remove ground prong. Do not use an adapter or extension cord. Plug into a grounded 3-prong outlet. Failure to
follow this warning can cause serious injury, fire, electric shock, or death.
Checking and choosing the
proper location
Unpacking and removing
shipping bolts
Connecting the water line
Connecting the drain line Leveling the washing
machine
Plugging in the power cord
and grounding
Test run

12 INSTALLATION INSTRUCTIONS
Checking and Choosing the Proper
Location
Install the washing machine on a solid floor that is strong and
rigid enough to support the weight of the washing machine,
even when fully loaded, without flexing or bouncing. If the
floor has too much flex, you may need to reinforce it to make
it more rigid. If the floor is not solid, it may cause severe
vibration and noise.
1Clean the floor before installation.
- Make sure to select solid and smooth ground.
2Two or more people are needed for moving and
unpacking the washing machine.
3Allow for sufficient space between the walls and the
washing machine for installation.
Space requirements
You must allow sufficient space for water lines, the drain
line, and airflow.
NOTE
yBe sure to allow for wall, door, or floor moldings that
may increase the required clearances.
Installing on a floor
293/4"
(75.6 cm)
4"
(10 cm)
51"
(129.5 cm)
221/4"
(57 cm)
27"
68.6 cm
1"
(2.5 cm) 1" (2.5 cm)
NOTE
yThe floor must be strong and rigid enough to support
the weight of the washer, when fully loaded, without
flexing or bouncing. If your floor has too much flex,
you may need to reinforce it to make it more rigid.
A floor that is adequate for a top-loading washer may
not be rigid enough for a front loading washer, due to
the difference in the spin speed and direction. If the
floor is not solid, your washer may vibrate and you may
hear and feel the vibration throughout your house.
yBefore installing the washer, make sure the floor is
clean, dry and free of dust, dirt, water and oils so the
washer feet can not slide easily. Leveling feet that can
move or slide on the floor can contribute to excess
vibration and noise due to poor contact with the floor.
yIf a drip pan must be used, take extra care to follow the
instructions provided with the drip pan and make sure
the leveling feet are adjusted for firm and even contact
with the pan. Use of drip pans and failure to properly
level the machine may result in increased vibration and
noise during operation.
Installing on a pedestal or stacking kit
29 3/4"
(75.6 cm)
4"
(10 cm)
27"
(68.6 cm)
1"
(2.5 cm)
1"
(2.5 cm)
771/2"
(196.8 cm)
NOTE
yRefer to the instructions packaged with the optional
PEDESTAL or STACKING KIT before installing with a
PEDESTAL or a STACKING KIT.

13
INSTALLATION INSTRUCTIONS
ENGLISH
Unpacking and Removing Shipping Bolts
When removing the washer from the carton base, be sure to
remove the foam drum support in the middle of the carton
base.
If you must lay the washer down to remove the base
packaging materials, always lay it carefully on its side.
Do not lay the washer on its front or back.
1Remove the bottom two shipping bolts with the wrench
(included). Fully loosen all four shipping bolts by turning
them counterclockwise and then pull them out.
Shipping
bolt
Retainer
2Locate the four hole caps included in the accessory pack
and install them in the shipping bolt holes.
Cap
NOTE
ySave the bolt assemblies for future use. To prevent
damage to internal components, Do not transport the
washer without reinstalling the shipping bolts.
yFailure to remove shipping bolts and retainers may
cause severe vibration and noise, which can lead to
permanent damage to the washer. The cord is secured
to the back of the washer with a shipping bolt to help
prevent operation with shipping bolts in place.

14 INSTALLATION INSTRUCTIONS
Connecting the Water Lines
1Check the rubber seals on both sides of the hose.
- Insert a rubber seal into the threaded fittings on each
hose to prevent leaking.
Rubber seal
Water hose
(To water inlet on the
washing machine)
Rubber seal
Water hose
(To faucet)
2Connect the water supply hoses to the HOT and COLD
water faucets tightly by hand and then tighten another
2/3 turn with pliers.
- Connect the blue hose to a cold water faucet and the
red hose to a hot water faucet.
WARNING
yDo not overtighten. Damage to the coupling can result.
3After connecting inlet hose to water faucets, turn on the
water faucets to flush out foreign substances (dirt, sand
or sawdust) in the water lines. Let water drain into a
bucket, and check the water temperature.
4Connect the hoses to the water inlets tightly by hand and
then tighten another 2/3 turn with pliers.
- Connect the blue hose to the cold water inlet and the
red hose to the hot water inlet.
Cold
water
inlet
Hot water
inlet
WARNING
yDo not overtighten the hoses. Overtightening can
damage the valves resulting in leaking and property
damage.
5Check for leaks by turning on the faucets.
- If water leaks, check steps 1 to 4 again.
NOTE
yFor your safety, and for extended product life, use
only authorized components. The manufacturer is not
responsible for product malfunction or accidents caused
by the use of separately purchased unauthorized parts.
yUse new hoses when you install the washing machine.
Do not reuse old hoses. Use only the inlet hoses
provided with the washer. LG does not recommend the
use of aftermarket hoses.
yPeriodically check the hoses for cracks, leaks and wear,
and replace the hoses every 5 years.
yDo not stretch the water hoses intentionally, and make
sure that they are not crushed by other objects.
yWater supply pressure must be between 14.5 PSI and
116 PSI (100~800 kPa). If the water supply pressure is
more than 116 PSI, a pressure reducing valve must be
installed.
yTo provide optimum washing performance the hot
water temperature should be set at 120-135°F (48-57°C)
and the cold at 60°F (15°C).

15
INSTALLATION INSTRUCTIONS
ENGLISH
Connecting the Drain Line
Secure the drain hose in place to prevent moving and leaking.
NOTE
yThe drain hose should be properly secured. Failure to
properly secure the drain hose can result in flooding
and malfunction.
yTotal height of the hose end should not exceed
96 inches (244.8 cm) from the bottom of the washer.
yThe drain must be installed in accordance with any
applicable local codes and regulations.
yMake sure that the water lines are not stretched,
pinched, crushed, or kinked.
Using a standpipe
1Clip the end of the hose into the elbow bracket.
- Connect the elbow bracket within 4 inches (10 cm) of
the end of the drain hose. If the drain hose is extended
more than 4 inches (10 cm) beyond the end of the
elbow bracket, mold or microorganisms could spread to
the inside of the washer.
No more than
4 inches (10 cm)
Elbow bracket
2Insert the end of the drain hose into the standpipe.
Drain Hose
Elbow Bracket
3Use a tie strap to secure the drain hose in place.
Using a laundry tub
1Clip the end of the hose into the elbow bracket.
- Connect the elbow bracket within 4 inches (10 cm) of
the end of the drain hose. If the drain hose is extended
more than 4 inches (10 cm) beyond the end of the
elbow bracket, mold, or microorganisms could spread to
the inside of the washer.
No more than
4 inches (10 cm)
Elbow bracket
2Hang the end of the drain hose over the side of the
laundry tub.
Elbow Bracket
Drain Hose
3Use a tie strap to secure the drain hose in place.

16 INSTALLATION INSTRUCTIONS
Leveling the Washing Machine
The washer tub of your new washing machine spins at very
high speeds. To minimize vibration, noise, and unwanted
movement, the floor must be perfectly level and solid.
1Check that the washing machine is level.
- Ensure it is level by rocking the top edges of the
washing machine or placing a level on the washing
machine. The slope beneath the washing machine must
not exceed 1°, and all four leveling feet must rest firmly
on the floor.
Level
1°
2Turn the lower leveling feet clockwise to level the
washing machine.
- Turning the lower leveling feet clockwise raises the
washing machine.
Raise
3Turn the locknuts counterclockwise and tighten them
when the washing machine is level.
Tighten all 4 lock
nuts securely using
the wrench.
4Check again to make sure the machine is level.
- Push or rock the top edges of the washing machine
gently to make sure that the washing machine does not
rock.
- If the washing machine rocks, repeat steps 1 to 3.
WARNING
yUsing the washing machine without leveling, it may
result in malfunction caused by the production of
excess vibration and noise.
yIf you are installing the washing machine on the
optional pedestal, you must adjust the leveling feet
on the pedestal to level the washing machine. The
washing machine´s leveling feet should be minimized
and the locknuts turned counterclockwise to secure
them.
yUse the leveling feet only when you level the washing
machine. If you raise the leveling feet unnecessarily, it
may cause abnormal vibration of the washing machine.
Using non-skid pads (optional)
If you install the washing machine on a slippery surface, it
may move because of excessive vibration. Incorrect leveling
may cause malfunction through noise and vibration. If this
occurs, lay the non-skid pads under the leveling feet and
adjust the level.
1Clean the floor to attach the non-skid pads.
- Use a dry rag to remove and clean foreign objects or
moisture. If moisture remains, the non-skid pads may
slip.
2Adjust the level after placing the washing machine in the
installation area.
3Place the adhesive side of the non-skid pad on the floor.
- It is most effective to install the non-skid pads under the
front legs. If it is hard to place the pads under the front
legs, place them under the back legs.
Remove
backing
This side up
Adhesive
side
4Check the washing machine’s level again.
- Push or rock the top edges of the washing machine
gently to make sure that the washing machine does not
rock. If the washing machine rocks, level the washing
machine again.

17
INSTALLATION INSTRUCTIONS
ENGLISH
Plugging in the Power Cord and
Grounding
Make sure to ground the washing machine to prevent a short
circuit or an electric shock when plugging in.
Using a 3-prong outlet
Plug in the electrical outlet without additional grounding.
WARNING
yThe power outlet must be within 60 inches (1.5 m) of either
side of the washer.
yThe appliance and outlet must be positioned so that the plug
is easily accessible.
yDo not overload the outlet with more than one appliance.
yThe outlet must be grounded in accordance with current
wiring codes and regulations.
yTime-delay fuse or circuit breaker is recommended.
yIt is the personal responsibility and obligation of the product
owner to have a proper outlet installed by a qualified
electrician.
yDo not use a worn or damaged power cord or power plug.
Replace or repair it immediately. Failure to do so may result
in death, fire, electric shock, or malfunction.
yDo not modify the power cord and take care not to damage
it when installing or moving the washing machine. Failure to
follow this warning may result in death, fire, electric shock, or
malfunction.
yMake sure that the washing machine is grounded.
yConnect this washing machine to a grounded outlet
conforming to the rating prior to use. Failure to do so may
result in fire, electric shock, or malfunction.
yDo not use adaptors or extension cords. The washing
machine should always be plugged into its own individual
electrical outlet which has a voltage rating that matches the
rating plate. Failure to do so may result in fire, electric shock
or malfunction.
yDo not damage or cut off the ground prong of the power
cord. Doing so may cause death, fire, electric shock, or
product malfunction.
Test Run
Check if the washing machine is properly installed and run a
test cycle.
1Load the washing machine with 6 pounds of laundry.
2Press
A
3Press .
4Press
C.
- The wash cycle starts.
5Check if water is supplied, that the washing machine
does not rock or vibrate excessively, and that it drains
well during the spin cycle.
- If water leaks during water supply, see page 14,
Connecting the Water Lines to connect them properly.
- If the washing machine rocks and vibrates excessively,
see page 16, Leveling the Washing Machine to level it
again.
- If the drain does not work, see page 15, Connecting the
Drain Line to install it properly.

18 PREPARATION
uCheck all pockets to make sure that they are empty.
-Items such as clips, matches, pens, coins, and keys can
damage both your washer and your clothes.
uClose zippers, hooks, and drawstrings to prevent these
items from snagging or tangling on other clothes.
uPretreat heavily stained areas before washing.
- Doing so will produce clean, stain-free results.
uCombine large and small items in a load. Load large items
first.
uLarge items should not be more than half of the total
washload.
uThe washer can be fully loaded, but the drum should not be
tightly packed with items.
-The door of the washer should close easily.
uDo not wash single items, except for bulky items such as
blankets. Make sure to wash laundry in similar types of
loads.
- Washing a single small item may result in the tub
becoming unbalanced, vibrating and making a noise.
uDo not wash waterproof clothes.
- This may cause abnormal vibration, or may cause the load
to bounce, which could damage the tub.
uCheck if there are any other foreign objects in the door seal
and take extra care that clothes do not get caught there.
- Foreign objects in the door seal may stain clothes, and
water may leak if clothes get caught in the door seal.
uWash underwear or small, light items in a laundry net.
- Small, light items may get caught in the door seal, and a
brassiere hook may damage other items or the tub.
uBrush heavy soil, dust, or hair off fabrics before washing.
- Laundry may not wash clean if there is dirt or sand on the
fabrics, or they may be damaged due to particles rubbing
against sheer fabrics.
uWash blankets individually.
- Washing more than one blanket in a load may produce
inferior results due to tangling or an unbalanced load.
uAlways separate fabrics according to their colors and wash
them separately to prevent colors from running.
- Fabrics may be damaged or become stained due to fabric
dyes running, or due to foreign objects transferring from
one fabric to another.
PREPARATION
Sorting Wash Loads
Precautions for Fabric Care Before Wash Cycle
Read and observe the following to prevent shrinkage or damage to clothes.

19
PREPARATION
ENGLISH
Category Label Directions
Washing
Hand Wash
Machine Wash, Normal Cycle
Use Permanent Press/Wrinkle
Resistant washing machine
setting (which has a cool down or
cold spray before the reduced
spin)
Use Gentle/Delicate washing
machine setting (slow agitation
and/ or reduced wash time).
Do Not Wash
Do Not Wring
Water Temperature
Hot
Warm
Cold/Cool
Bleach symbols
Any Bleach (When Needed)
Only Non-Chlorine Bleach (When
Needed)
Do Not Bleach
Colors Whites / Lights / Darks
Soil Heavy / Normal / Light
Fabric Delicates / Easy Care / Sturdy Cottons
Lint Lint Producers / Lint Collectors
Fabric Care Labels
Most articles of clothing feature fabric care labels that include
instructions for proper care.
Sorting Laundry
It is recommended that you sort laundry into similar loads
that are washable in the same cycle.
Refer to the following chart for sorting clothes

20 PREPARATION
Loading the Dispenser
The detergent dispenser drawer of the washing machine has
a dispenser compartment for each detergent type. Add each
detergent to its appropriate compartment.
1Pull out the detergent dispenser drawer.
2Add each detergent to its appropriate compartment.
- If you use a liquid detergent, check if the liquid
detergent cup is in place.
- If you use a powdered detergent, remove the liquid
detergent cup and put the powder in the main wash
detergent compartment.
Liquid chlorine
bleach
compartment
Liquid
detergent
cup
Main wash
detergent
compartment
Pre-wash
detergent
compartment
Liquid fabric
softener
compartment
3Close the detergent dispenser drawer slowly.
- Slamming the detergent dispenser drawer may result in
the detergent overflowing into another compartment or
pouring into the tub earlier than programmed.
NOTE
yIt is normal for a small amount of water to remain in
the dispenser compartments at the end of the cycle.
Using Detergent/Fabric Softener
Recommended Detergent
Make sure to use HE (High-Efficiency) detergent for front-
loading washing machines. HE detergents dissolve more
efficiently and produce fewer suds to ensure efficient
washing and rinsing. Use the correct amount of detergent as
indicated on the detergent packaging.
Specially designed to use only
HE (High-Efficiency) detergent
NOTE
yOnly use HE detergents, because using a regular
detergent may produce excessive suds.
yHE detergents produce fewer suds, dissolve more
efficiently to improve washing and rinsing performance,
and help to keep the interior of your washer clean.
yUse less detergent for soft water.
yWipe up any spills immediately, as liquids could
damage the finish and the control panel of the washing
machine.
yUsing too much detergent can cause a build-up in
the tub resulting in unsatisfactory performance and
machine malfunction.
yIf you use a detergent that does not dissolve easily or a
detergent with high viscosity, it will leave a residue on
the tub, which may not rinse properly.
