Liebert 115V User manual

USER MANUAL
English / Deutsch / Français /
Italiano / Español
350-700 VA
115V & 230V
POWERSURE™ PROACTIVE

2
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
This manual contains important safety instructions that should be followed during
the installation and maintenance of the UPS and batteries. Please read this
manual thoroughly before attempting to install or operate this UPS.
WARNING:
§To prevent the risk of fire or electric shock, install the UPS in a temperature
and humidity controlled room, free of conductive contaminants.
§Operate the UPS only from a properly grounded/earthed AC supply.
§To reduce the risk of electric shock, do not remove the cover, as it has no
user-serviceable parts inside. Some components are live, even when AC
power is disconnected. For service, contact a qualified technician.
§To reduce the risk of fire, use the proper rating when replacing the fuse.
CAUTION:
Although your UPS has been designed and manufactured to assure personal
safety, improper use can result in electrical shock or fire. To insure safety,
please observe the following rules:
§Turn off and unplug your UPS before cleaning. Do not use liquid or aerosol
cleaners. A dry cloth is recommended to remove dust from the surface of
your UPS.
§Do not install or operate your UPS in or near water.
§Do not place UPS on an unstable cart, stand, or table.
§Do not place UPS under direct sunlight or close to heat emitting sources.
§To allow proper ventilation of UPS, do not block or cover sides of unit.
§Do not place UPS power cord in any area where it may get damaged by
heavy objects.
§Follow all warnings and instructions marked on the UPS. Do not attempt to
service the UPS, as it has no user-serviceable parts inside. Refer all repairs
to qualified service personnel.
ATTENTION:
Turn off and unplug your UPS from the outlet and contact qualified service
personnel if:
§The power cord or plug is damaged.
§Liquid has been spilled on the UPS.
§The fuse blows frequently.
§The UPS does not operate even when user follows the operating
instructions.
CONDITIONS OF USE: The input receptacle must be within 6 feet (1.8 meters)
of the UPS.
Your UPS provides conditioned power to connected equipment. Maximum load
must not exceed that shown on UPS rating label. If uncertain, consult your
distributor or Liebert.
Placing magnetic storage media on top of the UPS may result in data corruption.
This equipment can be operated by individuals without previous training.

3
GENERAL INSTALLATION
32 - 104 F
0 - 40 C 4 inches
110 mm
R
Remove from box Check for damage
Plug in loads
Plug UPS into AC / Mains
Press On button
R
Or

4
INTRODUCTION & SYSTEM DESCRIPTION
Congratulations on your choice of the Liebert PowerSure ProActive
Uninterruptible Power System (UPS). It provides conditioned power to
microcomputers and other sensitive electronic equipment.
The PowerSure ProActive is a compact, “Automatic Voltage Regulation” UPS. It
offers “line-interactive” features by continuously conditioning and regulating
output voltage, whether the utility power is present or not. It supplies connected
equipment with stepped approximation to sinewave power to simulate the power
generated by the utility.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment uses, generates and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference with radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and the receiver.
-Connect the equipment into an outlet on a circuit different from that which
the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
BATTERY OPERATION
Battery mode occurs in event of extreme input conditions or complete utility
failure. During battery mode the Utility LED will flash every second and an alarm
will sound every 3 seconds. This will change to a beep every second when
battery runs low (approximately 2 minutes remaining).
WARNING: Turning off the UPS while in battery mode will result in loss of output
power.
Press Battery Test button occasionally to ensure battery is fully charged.
AUDIBLE ALARM CONDITIONS
CONDITION ALARM
Battery mode
(utility failure) One short beep every three seconds; more than two minutes of run time remaining
Low battery One beep every second; less than two
minutes of run time remaining
Battery replacement Two second beep every minute
UPS output overload Continuous tone
UPS fault Continuous tone

5
MAJOR COMPONENTS
R
BACK
FRONT
AC / Mains Battery Mode
ON / Standby
UPS Test
DB-9 Interface
for SiteNet
MultiLink cable
Output
Receptacles
AC Input /
Fuse Holder
Phone / Fax /
Modem / Network
Interface
Alarm Silence
!
Overload
Fault
Continuous Flashing

6
MAINTENANCE
The PowerSure ProActive UPS requires very little maintenance. The batteries
are valve regulated, nonspillable, lead acid, and require that they be kept
charged to obtain their designed life. When ON, the UPS continuously charges
the batteries when connected to the utility supply.
When storing the UPS for any length of time, it is recommended to plug in and
turn on the UPS for at least 24 hours every four to six months to ensure full
recharge of the batteries.
The following will help ensure trouble-free operation for years to come:
-Vacuum dust from the ventilation intake occasionally.
-Wipe the cover periodically with a dry cloth.
-Occasionally press the UPS test button to test the condition of the batteries.
FUSE REPLACEMENT PROCEDURES
Insert flat blade screw
driver into slot and pull
fuse holder out to remove
AC Inlet
Fuse Holder
Input Fuse
Spare Fuse
CAUTION: Before changing the supply fuse, turn off the UPS, and unplug the
input cord from the AC input power supply and from the UPS.
1. Remove the fuse holder by inserting a flat blade screwdriver into the slot and
pulling out as indicated in the figure above.
2. Remove the input fuse.
3. Remove the spare fuse from its position by using the screwdriver to push it
out.
4. Place spare fuse in the input fuse position, and replace the fuse holder. The
fuse holder will lock into position.
5. Reconnect the input power lead to the UPS, and the input power lead to the
input AC supply.
6. Restart the UPS. The UPS is ready for normal operation.
ProActive Model # Fuse Type
PSA350-120 5A / 125V
PSA470-120 6A / 125V
PSA700-120 8A / 125V
PSA350-230 3.15A / 250V
PSA470-230 4A / 250V
PSA700-230 6.3A / 250V

7
COMMUNICATIONS
You can use SiteNet® MultiLink™ to allow your UPS to communicate to
your computer via your DB-9 communications port. Download MultiLink
from our web site at www.liebert.com.
Pin Configuration
Pin # Function
9On Battery (N.O.)
8On Battery (Common)
6On Battery (N.C.)
1Low Battery
7Low Battery
5UPS Ground
4UPS Off
TROUBLESHOOTING
If the UPS fails to operate properly, turn off the unit and repeat the steps in the
installation section of this manual. If the problem persists, refer to the chart
below:
PROBLEM CAUSE SOLUTION
UPS will not start Overload/Short Circuit Check fuse at rear of UPS. If blown, replace it
and restart the UPS. For further help, call your
Liebert representative.
UPS starts on
battery, but will
not switch to AC
UPS not plugged in
Fuse blown
Power not available at
utility receptacle
Input voltage below
threshold
AC overvoltage
Plug in power
cord securely.
Replace fuse and restart UPS.
Call a qualified electrician.
Wait until voltage rises to appropriate level
AC voltage must be less than 144 VAC for
115V, 270 VAC for 230V.
UPS shuts down Overload/Short Circuit
Low Battery
Sitenet 1 Shutdown
Check the fuse holder at rear of UPS. If fuse is
blown, replace it and restart the UPS. If problem
persists, disconnect some of the equipment from
your UPS - the total wattage of your equipment
may exceed the capacity of the UPS. For
further help, call your Liebert representative.
Turn OFF equipment and recharge UPS battery
for at least 8 hours. If problem persists, contact
your Liebert representative.
Consult the Sitenet 1 User Manual or contact
your LAN administrator.
PIN ASSIGNMENT

8
115V SPECIFICATIONS
Model Number PSA350-120 PSA470-120 PSA700-120
Model Rating VA/W 350VA/210W 470VA/282W 700VA/420W
DIMENSIONS: in (mm)
Unit
H x W x D 6.5 x 4.5 x 13.9 (166 x 115.5 x 352.5) 6.5 x 4.5 x 13.9 (166 x 115.5 x 352.5) 6.5 x 4.5 x 13.9 (166 x 115.5 x 352.5)
Shipping
H x W x D 8.8 x 6.2 x 15.8 (226 x 156 x 404) 8.8 x 6.2 x 15.8 (226 x 156 x 404) 8.8 x 6.2 x 15.8 (226 x 156 x 404)
WEIGHT: lbs (kg)
Unit 13.2 (6) 15.4 (7) 22 (10)
Shipping 15 (6.8) 17.2 (7.8) 23.8 (10.8)
INPUT AC PARAMETERS
Voltage Range
without Battery Operation 87 to 144VAC
Line to Boost Transfer 104VAC
Line to Buck Transfer 124VAC
Frequency 47-53 Hz or 57-63 Hz; auto sensing
Input Power Cord 6 ft. detachable, w/ NEMA 5-15 P
OUTPUT AC PARAMETERS
Output Receptacles (4) 5-15R
Voltage (Battery Mode) 115 VAC +5%
Waveform (Battery Mode) Stepped Sinewave
Voltage (Normal) VIN * (1.0)
Voltage (Boost Mode) VIN * (1.16)
Voltage (Buck Mode) VIN * (0.84)
Frequency 50 Hz or 60 Hz; auto sensing
Overload Warning
(Utility and Battery Modes) 101 – 120%
Overload Shutdown
(Utility and Battery Modes) Overload + (15 – 30W) Overload + (20 – 40W) Overload + (30 – 60W)
BATTERY PARAMETERS
Type Valve-regulated, nonspillable, lead acid
Quantity x Voltage x Rating (1) x 12V x 7.0 Ah (1) x 12V x 7.0 Ah (1) x 12V x 10 Ah
Approved Battery
Manufacturers: CSB, Panasonic, and Yuasa
Transfer Time 4 – 6 ms typical
At 77°F (25°C), resistive loading, with fully charged batteries:
> 5 minutes typical
Back-up Time:
Full load
Half load > 15 minutes typical > 12 minutes typical > 13 minutes typical
Recharge Time 7-10 hours to 90% capacity, after full discharge into 100% resistive load
ENVIRONMENTAL
Operating Temperature +32° F to + 104° F (0° C to +40° C)
Storage Temperature +5° F to + 122° F (-15° C to +50° C)
Relative Humidity 0% to 90%, non-condensing
Operating Elevation Up to 10,000 ft. (3000 m) at 95° F (35° C) without derating
Audible Noise < 40 dBA, at 1 meter
AGENCY
Safety UL 1778, c-UL Listed
Surge IEEE C62.41 Category A
ESD IEC 801-2, Level 3, Criterion<2
Susceptibility IEC 801-3, Level 3, Criterion<2
Electrical Fast Transient/Burst IEC 801-4, Level 4, Criterion<2
Emissions FCC Part 15, Subpart B, Class B
Transportation ISTA Project 1A

9
230V SPECIFICATIONS
Model Number PSA350-230 PSA470-230 PSA700-230
Model Rating VA/W 350VA/210W 470VA/282W 700VA/420W
DIMENSIONS: mm (in)
Unit
H x W x D 166 x 115.5 x 352.5 (6.5 x 4.5 x 13.9) 166 x 115.5 x 352.5 (6.5 x 4.5 x 13.9) 166 x 115.5 x 352.5 (6.54 x 4.55 x 13.9)
Shipping
H x W x D 226 x 156 x 404 (8.8 x 6.2 x 15.8) 226 x 156 x 404 (8.8 x 6.2 x 15.8) 226 x 156 x 404 (8.8 x 6.2 x 15.8)
WEIGHT: kg (lbs)
Unit 6 (13.2) 7 (15.4) 10 (22)
Shipping 6.8 (15) 7.8 (17.2) 10.8 (23.8)
INPUT AC PARAMETERS
Voltage Range without
Battery Operation 166 to 275VAC
Line to Boost Transfer 198VAC
Line to Buck Transfer 250VAC
Frequency 47-53 Hz or 57-63 Hz; auto sensing
Input Power Receptacle EN60320/C14 recessed plug
OUTPUT AC PARAMETERS
Output Receptacles (4) EN60320/C13 sockets, (2) detachable EN60320-2-2 1.8m (6’) power
cords
Voltage (Battery Mode) 230 VAC +5%
Waveform (Battery Mode) Stepped Sinewave
Voltage (Normal) VIN * (1.0)
Voltage (Boost Mode) VIN * (1.13)
Voltage (Buck Mode) VIN * (0.85)
Frequency 50 Hz or 60 Hz; auto sensing
Overload Warning
(Utility and Battery Modes) 101 – 120%
Overload Shutdown
(Utility and Battery Modes) Overload + (15 – 30W) Overload + (20 – 40W) Overload + (30 – 60W)
BATTERY PARAMETERS
Type Valve-regulated, nonspillable, lead acid
Quantity x Voltage x Rating (1) x 12V x 7.0 Ah (1) x 12V x 7.0 Ah (1) x 12V x 10 Ah
Approved Battery
Manufacturers: CSB, Panasonic, and Yuasa
Transfer Time 4 – 6 ms typical
At 25°C (77°F), resistive loading, with fully charged batteries:
> 5 minutes typical
Back-up Time:
Full load
Half load > 15 minutes typical > 12 minutes typical > 13 minutes typical
Recharge Time 7-10 hours to 90% capacity, after full discharge into 100% resistive load
ENVIRONMENTAL
Operating Temperature 0° C to +40° C (+32° F to + 104° F)
Storage Temperature -15° C to +50° C (+5° F to + 122° F)
Relative Humidity 0% to 90%, non-condensing
Operating Elevation Up to 3000 m. (10,000 ft) at 35° C (95° F) without derating
Audible Noise <40 dBA, at 1 meter
AGENCY
Safety EN50091-1, TUV/GS listed, CE Compliance Mark
Surge IEC 801-5, Level 3
ESD IEC 801-2, Level 3, Criterion<2
Susceptibility IEC 801-3, Level 3, Criterion<2
Electrical Fast
Transient/Burst IEC 801-4, Level 4, Criterion<2
Emissions EN50091-2, EN55011 Class B
Transportation ISTA Project 1A

10
LIMITED WARRANTY
Liebert Corporation extends the following LIMITED WARRANTY to the purchaser
and to its customer (collectively referred to as the "Purchaser"): the enclosed
Uninterruptible Power System (UPS) and components are free from defects in
materials and workmanship under normal use, service, and maintenance FOR A
PERIOD OF TWO YEARS FROM THE DATE OF ORIGINAL PURCHASE from
Liebert or the Liebert dealer or retailer. THE FOREGOING WARRANTY IS THE
ONLY WARRANTY GIVEN AND NO OTHER WARANTY IS PROVIDED, EXPRESS
OR IMPLIED, INCLUDING WITHOUT LIMITATION, MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE. Certain aspects of disclaimers are not
applicable to consumer products acquired by individuals and used for personal,
family, or household purposes (as distinguished from industrial or other purposes).
Local laws may not allow limitations on how long an implied warranty lasts, so the
above limitation may not apply to you. This warranty gives you specific legal rights,
and you may have other rights which vary according to local law.
Certain repairs or services are the responsibility of the Purchaser and the Purchaser
is expected to pay for them. This warranty does not extend either to products with
removed or altered serial numbers or to any losses or damages due to act of God or
source external to the product, misuse, accident, abuse, neglect, negligence,
unauthorized modification, alteration, or repair, use beyond rated capacity, or
improper installation, maintenance, application or use, including, without limitation,
use in a manner contrary to the accompanying instructions or applicable codes.
WARNING: Warranty is void if the battery is allowed to discharge below the minimum
battery cutoff point. To prevent such discharge DO NOT leave the unit power switch
"ON" for more than two (2) days without AC power being supplied to the UPS. The
battery must be recharged every four (4) to six (6) months when not in use.
If the UPS fails to conform with the above warranty within the two year warranty
period, Liebert will repair or replace the UPS, at Liebert's option. Repairs or
replacements are warranted for the remainder of the original warranty period. To
make a warranty claim, purchaser should call a Liebert Representative to obtain a
Returned Goods Authorization number and shipping instructions. Return
transportation costs to Liebert are the responsibility of the Purchaser.
"LIFE SUPPORT" POLICY
This product is not recommended, and the Company will not knowingly sell this
product, for use with life support and other designated "critical" devices. ANY SUCH
USE BY A USER AUTOMATICALLY VOIDS AND DISCLAIMS ANY AND ALL
WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY,
IMPLIED WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE, AND
EXPRESS WARRANTIES THAT THIS PRODUCT WILL CONFORM TO ANY
AFFIRMATION OR PROMISE, FOR THIS PRODUCT AND THE USER AGREES
THAT IN NO EVENT SHALL THE COMPANY BE LIABLE FOR CONSEQUENTIAL
OR INDIRECT DAMAGES.

11
Technical Support
U.S.A. 1-800-222-5877
Outside the U.S.A. 614-841-6755
U.K. [phone]
France [phone]
Germany [phone]
Italy [phone]
Netherlands +00 31 475 503333
E-mail [email protected]
Web site http://www.liebert.com
Worldwide FAX tech support [phone]
The Company Behind The Products
With more than 500,000 installations around
the globe, Liebert is the world leader in
computer protection systems. Since its
founding in 1965, Liebert has developed a
complete range of support and protection
systems for sensitive electronics:
•Environmental systems: close-control air
conditioning from 1.5 to 60 tons.
•Power conditioning and UPS with power
ranges from 250 VA to more than 1000 kVA.
•Integrated systems that provide both
environmental and power protection in a
single, flexible package.
•Monitoring and control — on-site or remote —
from systems of any size or location
•Service and support, through more than 100
service centers around the world, and a 24-
hour Customer Response Center.
350- 700 VA
115V & 230V
POWERSURE™ PROACTIVE
While every precaution has been taken
to ensure accuracy and completeness of
this literature, Liebert Corporation
assumes no responsibility, and
disclaims all liability for damages
resulting from use of this information or
for any errors or omissions.
©1998 Liebert Corporation All rights
reserved throughout the world.
Specifications subject to change without
notice.
® Liebert and the Liebert logo are
registered trademarks of Liebert
Corporation. All names referred to are
trademarks or registered trademarks of
their respective owners.
SLI-23256 (1/99) Rev. 2
